Culligan 12-WL2200-CUL User guide

CULLIGAN®
Executive
Bottle-free Cooler
Featuring:
• Biocote® Protection
• In-Tank UV Protection
Models:
12-WL2200-CUL
©2010 Culligan International Com pa ny
Cat. No. 01021716
Rev. B 06/01/10
DCO # 011761
Installation, Operation
& Service Instructions
with Parts List
Printed in USA

Attention Culligan Customer:
Your local independently operated Culligan dealer employs trained service and maintenance personnel who are experienced
in the installation, function and repair of Culligan equipment. This publication is written specifically for these individuals and is
intended for their use.
We encourage Culligan users to learn about Culligan products, but we believe that product knowledge is best obtained by con-
sulting with your Culligan dealer. Untrained individuals who use this manual assume the risk of any resulting property damage
or personal injury.
Culligan Coolers are combined with selected Culligan water treatment components to create a system specifically tailored to
match the customer application.
WARNING! Prior to servicing equipment, disconnect power supply to prevent electrical
shock.
NOTE This system is not intended for use where water is microbiologically unsafe or with water of un-
known quality.
WARNING! If incorrectly installed, operated or maintained, this product can cause severe
injury. Those who install, operate, or maintain this product should be trained in
its proper use, warned of its dangers, and should read the entire manual before
attempting to install, operate, or maintain this product.
Products manufactured and marketed by Culligan International Company (Culligan) and its affiliates are protected by patents
issued or pending in the United States and other countries. Culligan reserves the right to change the specifications referred to
in this literature at any time, without prior notice. Culligan, Aqua-Cleer, Culligan Man and www.culligan.com are trademarks of
Culligan International Company or its affiliates.
Culligan International Company
9399 West Higgins Road, Suite 1100
Rosemont, Illinois 60018
For Technical Service Help call: 1-800-723-3426 ext. 2
To Order Innowave Parts call: 1-800-723-3426 ext.1
To Order Culligan Parts call: 1-800-428-2828
www.culligan.com
WARNING! This device complies with part 15 of the FCC rules subject to the two follow-
ing conditions: 1) This device may not cause harmful interference, and 2) This
device must accept all intereference received including interference that may
cause undesired operation.
This equipment complies with Part 15 of the FCC rules. Any changes or modifications not expressly approved by the manufac-
turer could void the user’s authority to operate the equipment. Changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate the equipment.

Contents iii
Cat. No. 01021716
Installation
and Operation
Instructions with
Parts List
Culligan® Executive
Bottle-free Cooler
Models from 2010
Contents
Attention Culligan Customer: ..............................................ii
Key Pre-Delivery Activities ................................................iv
Introduction ........................................................................ 1
Executive Overview ........................................................... 3
Main Parts Layout.............................................................. 4
Safety Information ............................................................. 5
Inspection and First-Time Setup Procedure ...................... 6
Installing the Executive Cooler .......................................... 9
Operating an Executive Cooler........................................ 12
Dispensing Hot/Cold/Ambient Water ............................... 13
Maintenance and Service ................................................ 14
Sanitizing the Executive Cooler ....................................... 16
Descaling the Executive Cooler....................................... 18
Troubleshooting ............................................................... 21
Technical Specifications .................................................. 22
Warranty .......................................................................... 23
BioCote® .......................................................................... 24
Electrical Wiring Diagram ................................................ 25
Executive Cooler Wetted Parts List ................................. 26
Executive Cooler Wetted Parts Illustration ...................... 27
Executive Cooler Main Parts List..................................... 28
Executive Cooler Main Parts Illustration .......................... 29
Single Head Manifold and Available Cartridges .............. 30
Appendix Overview.......................................................... 31
Appendix A....................................................................... 32
Appendix B ...................................................................... 33
Appendix C ...................................................................... 36
Appendix D ...................................................................... 40

iv Culligan® Executive Cooler iv Cat. No. 01021716
Key Pre-Delivery Activities
CAUTION! The cooler and the water treatment equipment must be properly prepared before the
system is delivered to the customer.
Executive Filter Systems
Executive Aqua-Cleer Filter—see Appendix A, Figure 10, on page 36.
• Uses: Carbon block filter and Total Defense filter in two (2) E-Z Change heads.
Executive Reverse Osmosis Systems
Executive Aqua-Cleer RO—see Appendix B, Figure 13 on pages 37–39.
• Uses: Carbon block and RO 50 cartridges in two (2) E-Z Change heads with storage tank and inline post carbon
filler.
• For detailed instructions about Aqua-Cleer components please refer to the complete Installation, Operation and
Service Manual, Cat. No. 01020219.
Executive LC-100 RO—see Appendix C, Figure 17 on pages 40.
• Uses: Preferred Series 250 Filter and LC-100 RO with storage tank and inline post carbon filter.
• For detailed instructions about Aqua-Cleer LC components please refer to the complete Installation, Operation and
Service Manual, Cat. No. 01882074.
Executive AC50 RO—see Appendix D, Figure 21 on page 44.
• Uses: AC50 inline post carbon filter and storage tank.
• For detailed instructions about AC 50 components please refer to the complete Installation, Operation and Service
Manual, Cat. No. 01018587.

Key Pre-Delivery Activities v
Cat. No. 01021716
Pre-Delivery Activity: Prepare and Flush Water Treatment Components
CAUTION! All RO Membranes will require a 24-hour flush to drain. All flushing of membranes
and filters must be done with chlorine-free, filtered, softened water.
Activity Executive
Aqua-Cleer
Filter
Executive
Aqua-Cleer RO
Executive LC-
100 RO
Executive AC50
RO
Flush the filters to drain for at least five (5) min-
utes with filtered soft water
c
Verify that system includes Automatic Shut-Off
Valve (P1021587)
ccc
Verify that system includes Check Valve
(P1021588)
ccc
Verify system includes Air Gap (44403001 or
equivalent) for system drain
ccc
Flush the RO cartridge to a drain with filtered
softened water for 24 hours prior to installation
ccc
Flush the carbon block filter to drain for at least
five (5) minutes until there are no more carbon
fines observed.
c
Activate the Preferred Series 250 cartridge and
thoroughly flush per the detailed instructions
c
Flush the pre-carbon filter and sediment filters
to drain
c
Flush the carbon post filter to drain ccc
Sanitize and flush the storage tank ccc
Pre-Delivery Activity: Prepare and Flush Cooler for Service
Activity Executive Cooler
Unpack the Cooler. c
Inspect the Cooler for any shipping damage. c
Flush and test the Cooler. c
See the appendixes for details about these activities.

vi Culligan® Executive Cooler vi Cat. No. 01021716
This page intentionally left blank.

Introduction 1
Cat. No. 01021716
Introduction
Thank you for purchasing the Culligan Executive Cooler. The Culligan Executive Cooler brings a unique, fresh approach
and a new look to point-of-use water treatment systems in the marketplace. The system’s contemporary color scheme
complements every office environment. Unlike a bottled water cooler, incoming tap water is treated as it is needed, so the
water is always fresh and great tasting. Best of all, there are no bottles to change and the supply is virtually unlimited.
The Culligan Executive Cooler is enhanced with BioCote® technology. BioCote® is a unique anti-microbial agent, based on
silver ion technology, that inhibits the growth of a broad range of micro-organisms. BioCote® is incorporated into the plas-
tic parts of the system at the time of manufacture, giving it built-in continuous anti-microbial protection against bacteria,
mold and fungi, making it cleaner and safer.
Culligan Executive Cooler systems come with a 1 gallon (4 liters) cold tank with an 8-watt in-tank UV lamp. Therefore, the
Culligan Executive Cooler systems are protected on the inside by UV and on the outside by BioCote providing the ultimate
in cleanliness for your cooler.
The Culligan Executive Cooler comes with two empty single heads installed inside that will enable you to configure it for
the condition of the incoming water supply. You decide on the filtration needed and then simply twist the filters into the
filter heads behind the lower front panel.
To create the most common two stage filtration system in the tower model, we recommend the following:
• First: 5 micron Carbon Block (Culligan P1020266) to reduce chlorine.
• Second: Total Defense cartridge (Culligan P1020274) for additional fine filtration as well as the reduction of chlo-
rine, chloramines, mercury, lead, cysts, MTBE and VOCs.
Of course, your local water conditions may require alternate selections for the wide range of Aqua-Cleer® cartridges of-
fered by Culligan.
In order for the water treatment system to continue to provide high quality water, a thorough understanding of the system
and its operation is required. Review this manual before making any attempt to install, operate, or service the system.
Installation or maintenance done on this system by an untrained service person can cause major damage to equipment or
property damage.
This publication is based on information available when approved for printing. Continuing design refinements could cause
changes that may not be included in this publication.
Safe Practices
Throughout this manual there are paragraphs set off by special headings.
Notice
Notice is used to emphasize installation, operation or maintenance information which is important, but does not present
any hazard. For example,
NOTICE The nipple must extend no more than 1 inch above the cover plate.
Caution
Caution is used when failure to follow directions could result in damage to equipment or property. For example,
CAUTION! Disassembly while under water pressure can result in flooding.

2 Culligan® Executive Cooler 2 Cat. No. 01021716
Warning
Warning is used to indicate a hazard which could cause injury or death if ignored. For example,
WARNING! Electrical shock hazard! Unplug the unit before removing the timer mechanism or
cover plates!
The CAUTION and WARNING paragraphs are not meant to cover all possible conditions and situations that may occur. It
must be understood that common sense, caution, and careful attention are conditions which cannot be built into the equip-
ment. These MUST be supplied by the personnel installing, operating, or maintaining the system.
Be sure to check and follow the applicable plumbing codes and ordinances when installing this equipment. Local codes
may prohibit the discharge of acid or caustic solutions to drain. An extra solution tank should be used to neutralize the
solution before discharging to drain.
Use protective clothing and proper face or eye protection equipment when handling chemicals or power tools.
NOTE The Culligan Executive Cooler is not intended for use with water that is microbiologically unsafe or of
unknown quality without adequate disinfection either before or after the system.
NOTE Check with your public works department for applicable local plumbing and sanitation codes. Follow
local codes if they differ from the standards used in this manual. To ensure proper and efficient opera-
tion of the Executive Cooler to your full satisfaction, carefully follow the instructions in this manual.

Executive Cooler Overview 3
Cat. No. 01021716
Executive Overview
Cold Tank
The cold tank is manufactured from 304 Stainless Steel which is non-corrosive, inert and reflects Ultraviolet (UV) light.
The cold water temperature is preset at approximately 41°F (5°C) by the factory. The capacity of the cold tank is 1 gallon
(4 liters). The water stored in the cold tank is chilled and exposed to UV at the same time. This inhibits bacterial growth
in the water and on the internal surfaces of the tank. The cold tank temperature is controlled by a thermostat that is set at
the factory.
Hot Tank
The hot water tank has a 0.4 gallon (1.5 liters) capacity. It is manufactured from 304 stainless steel which is non-corrosive
and inert. Heating is provided by an 800 watt heating element. The temperature of the Hot Tank is set at the factory to
185°F (85°C). A BI-metal overload thermostat is fitted to stop the tank overheating and is reset manually.
Room Temperature Water
This only provides filtration of your water. No further cooling, heating or treatment is done to the water in this option. The
temperature of the water will be the same as the room temperature. The room temperature water should be flushed after
long periods of non use, including weekends.
UV Lamp
The UV light is a TUV lamp with a wavelength of 253.7 nm, which is very efficient at controlling bacteria. UV light inacti-
vates bacteria by compromising their DNA. An 8 watt UV lamp is used in the Executive unit. The UV lamp is immersed
in the center of the cold tank. It is protected by a quartz sleeve which allows UV light to pass through to the water. The UV
lamp should be changed every 12 months. The quartz sleeve should be removed and cleaned when the lamp is changed.
PCB
The PCB (Printed Circuit Board) is the control unit for the Executive Cooler. It is responsible for the selection and dispens-
ing of water. The PCB drives an LED which informs the user of the status of the unit. The PCB has a power on indicator
and also indicates to the user what option of water is currently selected by changing color. Cold water will always be the
default option. Hot water must be selected and then the main button pressed in order to dispense hot water.
Compressor
The compressor uses R134a non-ozone depleting refrigerant gas. The compressor is controlled by an electromechanical
thermostat, which controls the temperature of the water in the cold tank unit.
Water Pipe and Fittings
All water connection fittings are approved to NSF standard 61. The machine is connected to the water supply by a 1/4”
female bulkhead fitting. The entire internal water circuit and all components which come in contact with water are food
grade NSF / WRAS approved.
Water Valves
Water dispensing to the customer is achieved by means of a 24V DC electrical solenoid valve. The valves are energized
each time the customer pushes the dispense button for a drink. DC voltage is used for safety.
Plastic Panels
The molded panels are made from recyclable ABS plastic. All the ABS plastic panels are UV resistant and meet the stan-
dards of CE and UL.
Executive Overview

4 Culligan® Executive Cooler
Executive Cooler Layout—Hot, Cold, and Ambient
Figure 1. Executive Cooler layout.
Main Parts Layout

Safety Information 5
Cat. No. 01021716
Electrical Safety
• Only connect the power cord to a 120V, 15A (GFI preferred) properly grounded outlet.
• Never pull the power plug from the outlet with a wet hand or allow the plug to get wet.
• Keep the power cord out of heavy traffic areas. To avoid a fire hazard, never put the power cord under rugs, near
radiators, stoves or heaters.
• Do not use a damaged power cord or plug. If the power cord is damaged, a qualified service technician must
replace it.
• Do not use an extension cord with the Executive Cooler.
Installation and Usage Safety
• Keep the Executive Cooler away from direct sunlight and excessive humidity.
• Keep at least 3 inches from the wall.
• Do not lay the Executive Cooler down on its side. If for some reason the unit was placed on its side, it must stand
upright for a minimum of 2 hours before operation to allow the compressor to stabilize.
• Connect the water supply to a cold water line only. Feed water over 105°F (41°C) can damage the filters.
• Never install the system where it could freeze.
• If the feed water pressure is over the recommended operating pressure of 60 psi (4 bar), install a pressure-reduc-
ing valve in the water line. Be aware of pressure transients.
• Filters should be replaced on schedule. Overused filters will deteriorate the performance of the system.
• Drain the water out of the Executive Cooler after long periods of non-use; this will allow a fresh batch of water to fill
the system.
Safety Information

6 Culligan® Executive Cooler 6 Cat. No. 01021716
Unit Inspection
1. In your shop, unpack and carry out a visual inspection of the unit for any shipping damage.
NOTE All preparation work should be done in a clean area. A separate room is recommended.
2. A Culligan IQR form is shipped with each unit. Fill out the IQR form and return to Culligan Quality
Department.
3. Remove the top cover of the machine. This is retained by two screws located under the front edge at the
bottom of the cover and two clips in the same location. Remove the screws and push clips up to release. To
gain easier access to the screws, tilt the machine backward at an angle of 10 degrees.
10°
Figure 2. Executive Cooler unit balancing screws.
4. Visually inspect the internals of the machine for any wires or pipes that may have come loose in shipping.
CAUTION! The unit is now live. Take suitable safety precautions.
Prepare the Unit for Sanitizing
1. Plug the filter heads based on the configuration of the unit.
Aqua-Cleer® Filter Use bypass plugs (P1020279).
Aqua-Cleer® RO Use bypass plugs (P1020279).
LC 100 RO Use bypass plugs (01010098). Plug the
restrictor outlet in the RO head with a
3/8" stem plug (01005650).
AC 50 RO Attach empty housings to manifold.
2. Open the top cover and unplug one of the UV wire connectors. UV light can break down some sanitizers.
3. Using the sanitizer cartridge, remove the bottom screw plug of the sanitizer cartridge and pour in 15 mL of
unscented, liquid chlorine bleach (6% Sodium Hypochlorite)
4. Carefully screw the bottom plug into the cartridge and insert cartridge into the left hand single head inside
cooler
5. Connect a clean, filtered, soft water supply to the unit. Pressure must be 40–60psi (2.8–4.1 bar).
Inspection and First-Time Setup Procedure

Inspection and First-Time Setup Procedure 7
Cat. No. 01021716
6. Ensure the red switch on the rear of the unit is in the OFF position. Connect the power cord to the unit and
to a power supply. 15A with GFI is recommended.
NOTE It may take several minutes before the hot tank is full and water begins to flow from the dispensing
head. Flush approximately 3 gallons (11 liters) of water through the hot tank.
Sanitize the Unit
1. Slowly turn ON the water supply. The incoming water will mix with the chlorine.
2. Press and hold the large dispense (Cold) button to start flushing water through the unit.
3. Stop flushing when water with a chlorine smell starts to flow from the dispensing head.
4. Do not dispense any of the sanitizing solution through the hot tank.
5. Allow the sanitizer solution to stand in the unit for 20–30 minutes.
6. Activate and hold the large dispense (Cold) button. Flush 3 gallons through the unit and the cold tank.
7. Activate and hold the Hot button. Flush 3 gallons through the hot tank.
8. Activate and hold the room temperature button. Flush 1 gallon (4 liters) through the unit.
9. Verify that all chlorine has been rinsed from the hot, cold, and room faucets with a chlorine test.
Remove the Sanitizing Cartridge
1. Turn OFF the water supply. Activate the dispense button to relieve any pressure in the unit.
2. Unplug the power cord.
3. Remove the sanitizer cartridge and EZ head. Reconnect the inlet feed tubing to the unit.
4. Remove all bypass plugs from the heads or the empty housings on an AC 50 RO configuration.
NOTE Prepare all filters, RO cartridges, and the RO storage tank strictly in accordance with the instructions
included in the Appendix section of this manual.
Install and Flush the Water Treatment Components
NOTE If prep station has a plumbed in RO, then use the RO water for final rinse, bypassing the installed
cartridges.
1. If the unit is going to be configured with an LC-100 or
AC 50 RO system, remove the EZ heads and install the other components.
2. Install the properly prepared water treatment equipment inside the POU Cooler.
3. Reconnect the UV wiring connectors in the top of the unit.
4. Turn ON the water supply and plug in the unit.
2. Slowly turn ON the water supply. Open the ball valve on the top of the full RO water storage tank.
6. Flush 1–2 gallons (4–8 liters) of hot water, 1–2 gallons (4–8 liters) of cold water, and 1 gallon (4 liters) of
water through the unit to flush the new water treatment components and the water in the unit. Verify the
water is running clear of any carbon fines or color.

8 Culligan® Executive Cooler 8 Cat. No. 01021716
7. Visually verify that the UV Lamp is working—look for a faint blue glow underneath the silicon fitting on the
top of the UV Lamp.
8. Verify that the compressor starts by feeling the head of the compressor for vibration. The temperature in
the cold tank should reach its target temperature within 45 minutes. When the unit has reached target cold
temperature, the compressor will cycle off. The target temperature range is between 41° F and 46° F (5°
and 8° C) (+/- 5%). The hot tank will take considerably less time to reach its target temperature of 185° F
(+/- 5%).
9. Adjust the cold water temperature by regulating the thermostat situated at the back of the unit. This ther-
mostat is set at a specific point at the factory. This point is marked out by a small dot situated on the out-
side of the thermostat.
10. After 45 minutes, verify proper heating and chilling.
11. Turn the Red Power Switch OFF.
12. Hold a pitcher under the Hot dispensing faucet. Depress the Hot unlock button, followed by the Hot dis-
pense button, and allow water to continuously run through the hot tank until the water runs cool from the
faucet. This is done to avoid scalding during draining.
13. Disconnect the power cord from the 120 Volt electrical outlet.
14. Turn off the water supply to the unit.
15. Disconnect the water supply from the unit.
16. Open the hot and cold tank drain caps on the back of the unit and drain completely. Wipe down any
excess water inside and around the unit and replace the lower front panel.
17. Return cooler to the original box.
18. The Executive Cooler should be installed within 24 hours.
NOTE Prepare all filters, RO cartridges, and the RO storage tank strictly in accordance with the instructions
included in the Appendix section of the manual

Installing the Executive Cooler 9
Cat. No. 01021716
Position the Unit
NOTE Per Culligan Corporate policy, you must install an external leak controller during install of the Executive Cooler
(Part # D1018733)
1. Locate the unit as close to an electrical connection and feedwater water supply as possible with a 3 inch (8
cm) clearance at both sides and back of the unit.
2. Mount the unit on a firm flat surface so that it cannot topple over.
3. Level the machine using the adjustable feet.
CAUTION! The machine should not be exposed to direct sunlight, heat sources, or an ambient
air temperature above 90°F (32°C) or below 37°F (3°C).
NOTE The water supply and electrical supply should be within 6 ft (1.8 m) of the unit for ease of installation.
4. Remove the lower front cover. This is retained by two screws located under the front edge at the bottom of
the cover and two clips in the same location.
5. Remove the screws and push clips up to release. To gain easier access to the screws, tilt the unit backward
at an angle of 10 degrees.
10°
Figure 3. Executive unit balancing screws.
Establish the Water Connection
1. Establish the water connection.
2. The use of a pressure regulator is recommended for water supplies that have pressure fluctuations. This
should be installed on the water supply before the inlet connection to the unit. Minimum operating pressure
for the unit to work suitably is 40 psi (2.8 bar). The ideal operating pressure is of 60 psi (4.1 bar).
NOTE At pressures higher than 80 psi (5.5 bar), the unit will not function correctly and can lead to leaks.
Pressure below 40 psi (2.8 bar) will require the use of a booster pump for proper RO performance.
3. Set pressure regulators at 60 psi (4.1 bar).
4. Flush the water supply pipe until it runs clear before making the water connection to rear of the unit.
Installing the Executive Cooler

10 Culligan® Executive Cooler 10 Cat. No. 01021716
5. The filters were already installed in the unit at the shop during initial start up.
6. Plug the power lead into the back of the unit. As soon as you plug the unit into a suitable power supply (15A
GFI outlet is preferred), voltage will be available to the PCB and solenoid valves, and you can now start to
flush water through the machine.
7. The hot water temperature is set at 185°F (85°C) (+/- 5%) and the cold water temperatures is set at 41°F
(5°C) (+/- 5%)at the factory. It is not possible to adjust the hot water temperature.
8. Verify proper temperature at install.
CAUTION! The unit is now live. Take suitable safety precautions.
NOTE Do not turn on the red switch (heater and compressor switch) at the rear of the machine. This switch
should only be turned on once the hot tank is filled with water.
NOTE Do not adjust the cold thermostat past the factory set point of 41°F (5°C), as this may result in the
system freezing.
Flush and Fill the Unit
NOTE For units using RO treatment: Because the RO make-up rate is so slow, use a full storage tank (with
RO treated water) for the following fill and flush steps.
1. Connect the full storage tank of RO water to a tee installed ahead of the unit solenoids.
2. Slowly turn on the water supply and open the ball valve on the full RO storage tank.
3. Select the hot water option. Press and hold the dispense button to start flushing water through the filters and
hot tank.
NOTE It may take several minutes before the hot tank is full and water begins to flow from the dispensing
head. Flush one to two (1–2) gallons (4–8 liters) of water.
4. Select the cold water option. Press and hold the cold dispense button to fill the cold tank.
NOTE It may take several minutes before the cold tank is full and water begins to flow from the dispensing
head. Flush one to two (1–2) gallons (4–8 liters) of water.
5. Check the unit for any water leaks and ensure that all water fittings are secured properly.
6. Replace the lower front cover.
Heat and Cool the Water
1. Once you are satisfied that water is passing through both the hot and cold tank successfully, then turn on
the red switch (heater/compressor switch) located at the rear of the unit. The unit will now start to heat and
chill.
2. Heat the water to approximately 185°F (85°C) (+/- 5%).
3. Cool the water in the cold tank. When the unit has reached the set temperature, the compressor will stop
running. The temperature may continue to drop as any ice that has formed on the sides of the tanks will start
to melt and equalize the tank temperature.

Installing the Executive Cooler 11
Cat. No. 01021716
4. Test the water temperatures.
5. Taste the water. If you are not satisfied with the quality of the water, check the filters and flush additional
water through the unit.
Inspect the Unit
1. Check the unit to make sure it is electrically safe.
2. Check that the unit is clean and functions to the customer’s satisfaction.
3. Apply service maintenance label to the side of cooler.
4. Apply marketing cross-sell to top of cooler.
5. Answer any customer questions regarding use of the unit and operation of the buttons.

12 Culligan® Executive Cooler 12 Cat. No. 01021716
Your Executive Cooler is ready for use when the three (3) colored LEDs on the front panel are all illuminated. If the LEDs
are not illuminated, the machine has entered sleep mode. Push any button to bring the machine out of sleep mode.
Operating the machine is very simple.
1. First, place a cup in the dispense area.
2. Select the water temperature of your choice.
3. Press the dispense button until your cup is filled to the required level.
CAUTION! HOT WATER
c Always place cup / mug in the center of the bulls eye marking on the
drip tray.
c Always use a ceramic cup or a cup suitable for use with hot water.
c Do not hold cup or place hands in dispensing area while dispensing
water.
c Do not dispense water in a stop-start style of vending. Hold button
continuously until cup is full).
c Never try to ll more than one vessel at a time.
Operating the Executive Cooler

Dispensing Hot/Cold/Ambient Water 13
Cat. No. 01021716
Dispensing Cold Water (Default Mode)
1. Push the dispense/cold water default button.
The button backlight will light blue and the
blue LED will blink. The machine will dis-
pense cold water.
Dispensing Ambient Water
1. Push the room temperature water button on
the right. The button backlight will light green
and the green LED will blink.
2. Push the dispense button. The machine will
dispense room temperature water.
Dispensing Hot Water
1. Push the hot water button in the middle and
hold for three (3) seconds. The button back-
light will light red and the red LED will blink.
2. Push the dispense button. The machine will
dispense hot water.
Dispensing Extra Hot Water
1. Push the hot water button in the middle twice
within one (1) second. The middle LED will
light orange while the extra heating takes
place. Once the extra heating is complete the
LED reverts to red. If the LED is not orange
then the temperature is already extra hot.
2. Push the dispense button. The machine will
dispense extra hot water.
Dispensing Hot/Cold/Ambient Water

14 Culligan® Executive Cooler 14 Cat. No. 01021716
NOTE All personnel should be aware of company requirements for their own cleanliness and hygiene when
servicing and sanitizing a unit.
Executive Cooler
Maintenance/12-Month Service Interval
Every twelve (12) months, the filters and UV lamp should be changed. Units in dusty or high use locations may need more
frequent servicing. A machine with the hot water option may require removing any Calcium build-up inside the hot tank,
depending on local water conditions and the type of water treatment.
NOTE A full RO storage tank must be available for flushing steps.
CAUTION! The machine should not be exposed to direct sunlight, heat sources, or an ambient
air temperature above 90°F (32°C) or below 37°F (3°C).
Do not clean this appliance with a water jet.
NOTE You must use latex gloves when handling the filters, UV bulb, quartz sleeve or any components that
have contact with the drinking water.
Prepare the Unit for Sanitizing
1. Turn OFF the water supply. Activate the dispense button to relieve any pressure in the unit.
2. Turn OFF the red switch at the rear of the unit and unplug the power cord.
3. On RO systems, close the ball valve on the top of the RO storage tank.
4. Remove and dispose of all old filters from the unit.
5. Open the top cover and remove the UV lamp.
6. Unscrew the UV retaining nut and remove the Quartz Sleeve by pulling straight up. Clean the Quartz Sleeve
with isopropyl rubbing alcohol and remove any surface lime scale that may have adhered to the sleeve sur-
face. Check and replace the black O ring if necessary.
7. Replace quartz sleeve if etched, cracked or unable to be cleaned.
8. Reinstall the Quartz Sleeve and retighten the UV retaining nut. Tighten about ¼ turn after the gasket makes
contact.
9. Replace the UV lamp and wiring harness/starter. Leave one of the wires disconnected until after the saniti-
zation procedure is complete.
CAUTION! Do not touch the UV lamp or the Quartz sleeve with bare hands.
10. On units using RO, disconnect the storage tank from the product line tee and plug the tubing tee with a ¼”
stem plug (01001142). Sanitize the storage tank separately.
11. Plug the filter heads based on the configuration of the unit.
Aqua-Cleer® Filter Use bypass plugs (P1020279).
Aqua-Cleer® RO Use bypass plugs (P1020279).
Maintenance and Service
