INSTRUCTION MANUAL
TABLE TOP FRIDGE
CTT50W15
CTT50W15_IB_RC_151218_grace.indd 1 18/12/15 2:57 pm

Contents
Safety Warnings........................................................................................................................... 3
Unpacking.................................................................................................................................... 5
Installation ................................................................................................................................... 6
Location ..................................................................................................................................................................... 6
Levelling the Unit ................................................................................................................................................... 6
Installing the Spacers............................................................................................................................................ 6
Free Space Requirements.................................................................................................................................... 6
Reversing the Door Swing................................................................................................................................... 7
Cleaning Before Use ............................................................................................................................................10
Before Using Your Unit........................................................................................................................................10
Product Overview...................................................................................................................... 11
Front View ...............................................................................................................................................................11
Rear View .................................................................................................................................................................11
Operation ................................................................................................................................... 12
Switching On Your Unit ......................................................................................................................................12
Adjusting the Temperature...............................................................................................................................12
Noises Inside the Unit!........................................................................................................................................12
Tips for Keeping Food in the Unit...................................................................................................................12
Cleaning ..................................................................................................................................... 13
Defrosting ...............................................................................................................................................................13
Cleaning the Interior and the Exterior of the Unit....................................................................................13
Maintenance .............................................................................................................................. 14
Care When Handling / Moving the Unit.......................................................................................................14
Servicing..................................................................................................................................................................14
Switching O for Long Periods of Time........................................................................................................14
Condensation.........................................................................................................................................................14
Disposal...................................................................................................................................... 14
Specications............................................................................................................................. 15
CTT50W15_IB_RC_151218_grace.indd 2 18/12/15 2:57 pm

3
Safety Warnings
For your continued safety and to reduce the risk of injury or electric shock,
please follow all the safety precautions listed below.
• Read all instructions carefully before using the unit and keep them for
future reference.
• Retain the manual. If you pass the unit onto a third party, make sure to
include this manual.
• This appliance is intended for indoor household use and similar
applications such as:
- sta kitchen areas in shops, oces and other working environments;
- farm houses and by clients in hotels, motels and other residential type
environment;
- bed and breakfast type environment;
- catering and similar non-retail applications.
• Ensure that the plug is easily accessible to enable disconnection from
the mains supply.
• If the mains cable is damaged, it must be replaced by the manufacturer,
its service agent or a qualied technician in order to avoid a hazard.
• Choose a location for your unit away from heat sources such as radiators
or res as refrigerant and vesicant are burnable.
• The unit must be manoeuvred by a minimum of 2 persons.
• This appliance can be used by children aged from 8 years and above
and persons with reduced physical, sensory or mental capabilities or
lack of experience and knowledge if they have been given supervision
or instruction concerning use of the appliance in a safe way and
understand the hazards involved. Children shall not play with the
appliance. Cleaning and user maintenance shall not be made by
children without supervision.
• Children should be supervised to ensure that they do not play with the
unit.
• If your unit is tted with a lock to prevent children being trapped inside,
keep the key out of reach and not in the vicinity of the unit.
• Do not store explosive substances such as aerosol cans with a
ammable propellant in this appliance.
CTT50W15_IB_RC_151218_grace.indd 3 18/12/15 2:57 pm

4
WARNING
• Keep ventilation openings in the unit enclosure or in the built-in
structure clear of obstructions.
• Do not use mechanical devices or other means to accelerate
the defrosting process, other than those recommended by the
manufacturer.
• Do not use electrical appliances inside the food storage
compartments of the unit, unless they are of the type
recommended by the manufacturer.
• Do not damage the refrigerant circuit (The refrigerant is a very
environmental-friendly gas but is also combustible. Take care when
transporting or moving the unit to ensure that the refrigeration
circuit is not damaged. In the event of damage avoid naked ames
or ignition sources and ventilate the room in which the unit is
placed for a few minutes.)
WARNING
IT IS HAZARDOUS FOR ANYONE OTHER THAN AUTHORISED
SERVICE PERSONNEL TO CARRY OUT SERVICING OF REPAIRS WHICH
INVOLVE THE REMOVAL OF COVERS.
TO AVOID THE RISK OF AN ELECTRICAL SHOCK DO NOT ATTEMPT
REPAIRS YOURSELF.
CTT50W15_IB_RC_151218_grace.indd 4 18/12/15 2:57 pm

5
Unpacking
Remove all items from the packaging. Retain the packaging. If you dispose of it please do so
according to local regulations.
The following items are included:
The Main Unit
Wire Shelf Top Wire Rack
Thank you for purchasing your new Fridge.
We recommend that you spend some time reading this instruction manual
in order that you fully understand all the operational features it offers.
Read all the safety instructions carefully before use and keep this
instruction manual for future reference.
If items are missing or damaged please contact Partmaster (UK only).
Tel: [phone] for assistance.
Instruction Manual
Bottom Wire Rack
Instruction
Manual
Rear Spacer x 2
CTT50W15_IB_RC_151218_grace.indd 5 18/12/15 2:57 pm

INSTALLATION
6
Installation
Location
When selecting a position for your unit you should make sure the floor is flat and firm, and
the room is well ventilated with an average room temperature of between 16°C and 38°C.
If the room temperature drops below 16°C your freezer may start to defrost. Avoid locating
your unit near a heat source, e.g. cooker, boiler or radiator. Also avoid direct sunlight as it
may increase the electrical consumption. Extreme cold ambient temperatures may also
cause the unit not to perform properly. This unit is not designed for use in a garage or
outdoor installation. Do not drape the unit with any covering.
Levelling the Unit
To do this adjust the two levelling feet at the front of the unit.
If the unit is not level, the doors and magnetic seal alignments
will not be covered properly.
Installing the Spacers
Screw the spacers to the left and right side
of the unit’s rear part.
Free Space Requirements
When installing the unit, ensure that 25 mm
of free space is left at both sides, 50 mm
at the rear of the unit and 25 mm at the
top of the unit. The door can be opened to
the right or the left, depending on which
best suits the location. Please ensure there
is more than twice the width and depth
distance space of the unit to fully open the
door to a maximum angle of 160°.
Max. 160°
Y mm
X mm
CTT50W15_IB_RC_151218_grace.indd 6 18/12/15 2:57 pm

INSTALLATION
7
Reversing the Door Swing
Tools required: Philips style screwdriver / Flat bladed screwdriver / Hexagonal spanner
• Ensure the unit is unplugged and empty.
• To take the door off it is necessary to tilt the unit backwards. You should rest the
unit on something solid, e.g. a chair just below the top panel.
• All parts removed must be saved to do the reinstallation of the door.
• Do not lay the unit flat as this may damage the coolant system.
• We recommend that 2 people handle the unit during assembly.
• If you want to have the door swing reversed, we recommend that you contact a
qualified technician. You should only try to reverse the door yourself if you believe
that you are qualified to do so.
1. Remove the top right hinge cover.
2. Undo the screws. Then remove the hinge
bracket.
CTT50W15_IB_RC_151218_grace.indd 7 18/12/15 2:57 pm

INSTALLATION
8
3. Remove the top left screw cover.
4. Move the core cover from left side to
right side. And then lift the door and
place it on a padded surface to prevent it
from scratching.
5. Remove the screws and bottom hinge.
Then remove the levelling feet from both
side. Unscrew
CTT50W15_IB_RC_151218_grace.indd 8 18/12/15 2:57 pm

INSTALLATION
9
Unscrew
Screw
Screw
6. Unscrew and remove the bottom hinge
pin, turn the bracket over and replace it.
7. Refit the bracket fitting the bottom hinge
pin. Replace both levelling feet.
8. Place the door back on. Ensure the door
is aligned horizontally and vertically
so that the seals are closed on all sides
before finally tightening the top hinge.
9. Insert the hinge bracket and screw it to
the top of the unit.
10. Use a spanner to tighten it if necessary.
CTT50W15_IB_RC_151218_grace.indd 9 18/12/15 2:57 pm

INSTALLATION
10
11. Put the hinge cover and the screw cover
back.
12. With the door closed, check that the
door is aligned horizontally and vertically
and that the seals are closed on all sides
before finally tightening the bottom
hinge. Re-adjust the levelling feet as
needed.
Cleaning Before Use
Wipe the inside of the unit with a weak solution of bicarbonate soda. Then rinse with warm
water using a ‘wrung-out’ sponge or cloth. Wash the shelf in warm soapy water and dry
completely before replacing in the unit. Clean the exterior of the unit with a damp cloth.
If you require more information refer to the Cleaning section.
Before Using Your Unit
Before placing any food in your unit, turn it on and wait for 24 hours, to make sure it is
working properly and to allow it time to fall to the correct temperature. Your unit should not
be overfilled.
• Before Plugging in YOU MUST
Check that you have a socket which is compatible with the plug supplied with the
unit.
• Before Turning On!
Do not turn on until two hours after moving the unit. The coolant fluid needs time
to settle.
CTT50W15_IB_RC_151218_grace.indd 10 18/12/15 2:57 pm

11
Product Overview
Front View
Adjustable
Shelf
Thermostat
Control Dial
(at rear side)
Thermostat
Control Dial
(at rear side)
Ice Box
Levelling Feet
Door Racks
Rear View
CTT50W15_IB_RC_151218_grace.indd 11 18/12/15 2:57 pm

12
Operation
Switching On Your Unit
1. Connect the mains cable to the mains socket. The
internal temperature of your unit is controlled by a
thermostat. There are six settings, of which position
5is the coldest and position 0turns the unit off.
2. Adjust the thermostat control dial to the desired
position, bear in mind that the higher the
number, the lower the temperature. Position 3
recommended setting when operating at normal
room temperature (between 16°C and 38°C).
3. The unit may not operate at the correct
temperature if it is in a particularly hot or a
particularly cold room, or if you open the door
often.
4. To ensure that the unit is cool enough to sufficiently
chill your food, wait 24 hours before filling it with
food.
5. If you are concerned that your unit is not being kept
cold enough and wish to check the temperature,
you will need a special fridge/freezer thermometer.
These are available from most supermarkets and
hardware shops.
Place the thermometer in the centre of the unit,
where it can be read easily. Leave overnight, the
temperature in the unit should be between 4°C or
lower.
Adjusting the Temperature
The internal temperature of the unit is controlled by a thermostat. The recommended position
is between 1to 3for colder working environments (i.e. during winter) and between 4to 5for
hotter environments. Please adjust according to the environment.
Noises Inside the Unit!
You may notice that your unit makes some unusual noises. Most of these are perfectly normal,
but you should be aware of them!
These noises are caused by the circulation of the refrigerant liquid in the cooling system. It has
become more pronounced since the introduction of CFC free gases. This is not a fault and will
not affect the performance of your unit. This is the compressor motor working, as it pumps the
refrigerant around the system.
Tips for Keeping Food in the Unit
• Cooked meats/fishes should always be stored on a shelf above raw meats/fishes to avoid
bacterial transfer. Keep raw meats/fishes in a container which is large enough to collect
juices and cover it properly. Place the container on the lowest shelf.
0
1
2
3
4
5
CTT50W15_IB_RC_151218_grace.indd 12 18/12/15 2:57 pm

13
• Leave space around your food, to allow air to circulate inside the unit. Ensure all parts of the
unit are kept cool.
• To prevent transfer of flavours and drying out, pack or cover the food separately. Fruit and
vegetables do not need to be wrapped.
• Always let pre-cooked food cool down before you put in the unit. This will help to maintain
the internal temperature of the unit.
• To prevent cold air escaping from the unit, try to limit the number of times you open the
door. We recommend that you only open the door when you need to put food in or take
food out.
Cleaning
Defrosting
Frost might build up in the unit after it has been used for a period of time. Scrape away the frost
using a plastic scraper (not included).
Do not use a metal or sharp instrument to scrap away the frost, nor should you use any
electrical appliances to aid defrosting.
We recommend that defrosting should be carried out when the frost layer builds up to 10 mm
(0.39”). Choose a time when the stock of frozen food is low, follow these procedures:
1. Take out the food, turn the unit off at the mains supply and leave the door open. Ideally, the
frozen food should be put into another freezer. If this is not possible, wrap the food in several
sheets of newspaper or large towels and then a thick blanket to keep it cool.
2. Place a shallow bowl or pan below the unit. Scrape away the frost
using the plastic scraper. Defrosting the remaining frost can be
speeded up by placing a bowl of hot water inside the unit and
closing the door. As the solid frost loosens, scrape it away with the
plastic scraper and remove.
3. When defrosting is complete, clean your unit’s interior and exterior.
Cleaning the Interior and the Exterior of the Unit
• Remove the shelf before cleaning.
• Wipe the inside of the unit with a weak solution of bicarbonate soda and then rinse with
warm water using a ‘wrung-out’ sponge or cloth. Wipe completely dry before replacing the
shelf.
• Use a damp cloth to clean the exterior, and then wipe with a standard furniture polish. Make
sure that the door is closed to avoid the polish getting on the magnetic door seal or inside
the unit.
• The grille of the condenser at the back of the unit and the adjacent components can be
vacuumed using a soft brush attachment.
CTT50W15_IB_RC_151218_grace.indd 13 18/12/15 2:57 pm

14
Maintenance
Care When Handling / Moving the Unit
Hold the unit around its sides or base when moving it. Under no circumstances should it be
lifted by holding the edges of the top surface.
Servicing
The unit should be serviced by an authorised engineer and only genuine spare parts should be
used. Under no circumstances should you attempt to repair the unit yourself. Repairs carried
out by inexperienced persons may cause injury or serious malfunction. Contact a qualified
technician.
Switching O for Long Periods of Time
When the unit is not in use for a long period of time, disconnect it from the mains supply, empty
all food and clean the appliance, leaving the door ajar to prevent unpleasant smells.
Condensation
Condensation may appear on the outside of the unit. This may be due to a change in room
temperature. Wipe off any moisture residue. If the problem continues, please contact a qualified
technician for assistance.
Disposal
Old units still have some residual value. An environmentally friendly method of disposal will
ensure that valuable raw materials can be recovered and used again. The refrigerant used in
your unit and insulation materials require special disposal procedures. Ensure that none of the
pipes on the back of the unit are damaged prior to disposal.
Up to date information concerning options of disposing of your old unit and packaging from
the new one can be obtained from your local council office.
When disposing of an old unit break off any old locks or latches and remove the door as a
safeguard.
CTT50W15_IB_RC_151218_grace.indd 14 18/12/15 2:57 pm

15
Specications
Model CTT50W15
Storage Volume - Fresh Food Storage
Compartment 42L
Storage Volume - Ice Box 4L
Storage Temperature - Fridge fridge: 0 - 8°C, average ≤ 4°C
Energy Consumption 0.295kWh / 24h
Energy consumption 107 kWh per year, based on standard test results for 24 hours.
Actual energy consumption will depend on how the appliance is used and where it is located.
Household Appliances Category Category 1
(Refrigerator)
Energy Grading A+
EU Ecolabel N/A
Defrosting Type Manual Defrost
Climate Class ST
This appliance is intended to be used at an ambient temperature between 16°C and 38°C.
Airborne Acoustical Noise 41dB
Rated Voltage 220-240V~
Rated Current 0.45A
Overall Dimension (H x W x D) 510 x 440 x 470 mm
Features and specifications are subject to change without prior notice.
CTT50W15_IB_RC_151218_grace.indd 15 18/12/15 2:57 pm

DSG Retail Ltd. (co. no. 504877)
1 Portal Way, London, W3 6RS, UK
IB-CTT50W15-151218V2
The symbol on the product or its packaging indicates that this
product must not be disposed of with your other household
waste. Instead, it is your responsibility to dispose of your waste
equipment by handing it over to a designated collection point
for the recycling of waste electrical and electronic equipment.
The separate collection and recycling of your waste equipment
at the time of disposal will help conserve natural resources
and ensure that it is recycled in a manner that protects human
health and the environment.
For more information about where you can drop o your waste
for recycling, please contact your local authority, or where you
purchased your product.
Visit Partmaster.co.uk today for the easiest way to buy
electrical spares and accessories. With over 1 million
spares and accessories available we can deliver direct
to your door the very next day. Visit www.partmaster.co.uk or call 0344 800 3456
(UK customers only) Calls charged at National Rate.
For general information about this appliance
and handy hints and tips, please visit
www.knowhow.com/knowledgebank or call 0344 5611234.
CTT50W15_IB_RC_151218_grace.indd 16 18/12/15 2:57 pm
