Custom Autosound CONCOURS SERIES User manual

Owner's Manual
ELECTRONICALLY TUNED AM/FM RECEIVER,
CASSETTE PLAYER:CUSTOM MADE FOR
"THE GREAT CLASSIC VEHICLES!"
FEATURES
◆ AUXILIARY INPUTS,IPOD,MP3,ETC. ◆RCA PRE-AMP OUTPUTS
◆ NEW ELECTRONIC VOLUME AND ◆AUTO-REVERSE CASSETTE
TUNING CONTROLS ◆PUSH TAPE EJECT CONTROL
◆TAPE PROGRAM SELECT ◆POWER ON/OFF & VOLUME
◆AUTO-ANTENNA LEAD ◆FRONT/FEAR FADER
◆HIGH POWER 200 WATTS (50 x 4) ◆LEFT/RIGHT BALANCE
◆12AM 18FM STATION MEMORY ◆SWITCHABLE USA/EURO
FREQUENCY SELECTOR
CONCOURS SERIES
USA-1
LIMITED WARRANTY
If your product does not work properly because of a defect in material or work-
manship, Custom Autosound Mfg.,Inc. (the Company) will for the length of the
period indicated on the chart below, which starts with the date of original pur-
chase (“Limited Warranty period”), at its option either (a) repair your product with
new or refurbished parts, or (b) replace it with a new or refurbished product. The
decision to repair or replace will be made by the company.
During the “Labor” Limited Warranty period there will be no charge for labor.
During the “Parts” Limited Warranty period, there will be no charge for parts. This
Limited Warranty is extended only to the original purchaser and only covers
product purchased as new. A purchase receipt or other proof of the original pur-
chase date is required for Limited Warranty service.
To obtain repairs or replacement within the terms of this warranty, the product
should be delivered, transportation prepaid, to the Company at the address
shown below.
This warranty does not extend to the elimination of car static or motor noise cor-
rection antenna problems, costs incurred for removal or reinstallation of product,
or damage of tapes, speakers accessories or car electrical systems.
This warranty does not apply to any product or part thereof which has been
damaged through alteration, mishandling, misuse neglect, or accident.
ANY IMPLIED WARRANTY IS LIMITED TO THE DURATION OF THIS WRIT-
TEN WARRANTY. UNDER NO CIRCUMSTANCES SHALL THE COMPANY BE
LIABLE FOR ANY LOSS OR DAMAGE, DIRECT OR CONSEQUENTIAL, ARIS-
ING OUT OF THE USE OR INABILITY TO USE THIS PRODUCT: No person or
representative is authorized to assume for the Company any liability other than
expressed herein in connection with the sale of this product.
Some states do not allow limitations on how long an implied warranty last or the
exclusion or limitation of incidental or consequential damage to the above limita-
tions or exclusion may not apply to you.
This warranty gives you specific legal rights and you may also have other rights
which vary from state to state.
1030 W. Williamson Ave. Fullerton CA. 92833
800-888-8637 714-773-1423 FAX [phone]
Product or Part Name PARTS LABOR
All In-dash car radios, radio/tape
player combinations. Two (2) Years One (1) Year

Table of Contents
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
General Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Radio Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Low Level Output Connection . . . . . . . . . . . . . . . . . . . .4
Wiring Diagram. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Controls and Display . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Receiver Basic Operation . . . . . . . . . . . . . . . . . . . . . . .7
Programming The Preset Memory . . . . . . . . . . . . . . . . . 8
Digital Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Receiver Special Functions . . . . . . . . . . . . . . . . . . . .8-9
Preset Scan And Auto Store . . . . . . . . . . . . . . . . . . . . .9
Auxiliary Input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Cassette Player Basic Operation . . . . . . . . . . . . . . .9-10
Cassette Auto Reverse Operation . . . . . . . . . . . . . . . .10
Setting the Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Cassette Care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Noise Suppression . . . . . . . . . . . . . . . . . . . . . . . . .11-12
Trouble Shooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
1
Radio Specifications
FM Section
Tuner Type . . . . . . . . . . . . . . . . . . . . . . . . .PLL
Frequency Range . . . . . . . . . . .87.5-1 08 MHz
Image Rejection . . . . . . . . . . . . . . . . . . . .50dB
Quieting Sensitivity . . . . . . . . . . . . . . . . . .4uV
T.H.D . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1%
IF Rejection . . . . . . . . . . . . . . . . . . . . . . .60dB
AM Section
Frequency Range . . . . . . . . . . . .530-1710KHz
S/N Ratio . . . . . . . . . . . . . . . . . . . . . . . . .50dB
Selectivity . . . . . . . . . . . . . . . . . . . . . . . . . 25dB
Audio Section
Output Channel . . . . . . . . . . . . . . . . . . . .50X4
Output Impedance . . . . . . . .4ohm per speaker
Response . . . . . . . . . . . . . . . . . . .30Hz-18KHz
Tape Section
Mechanism Type . . . . . . . . . . . . .Auto Reverse
Tape Speed . . . . . . . . . . . . . . . . .4.76cm/SEC
Response . . . . . . . . . . . . .40Hz-10KHz NORM
Separation . . . . . . . . . . . . . . . . . . . . . . . .45dB
General
Power Supply . . . . . .12VDC Negative Ground
Speaker impedance . . . . . . . . . . . . . .4-8 ohm
Stand-By Current . . . . . . . . . . . . . . . . . .0.02A
Chassis .... 200mm(7 7/8”)(w)X57(2 -1/4")mm
. X142.8(5 5/8")mm(D)
IF Frequency . . . . . . . . . . . . .10.7MHZ
Sensitivity . . . . . . . . . . . . . . . . . . .2.6V
S/N Ratio . . . . . . . . . . . . . . . . . .60dB
Capture Ratio . . . . . . . . . . . . . . .1.5dB
Separation . . . . . . . . . . . . . . . . .35dB
IF Frequency . . . . . . . . . . . . .450KHz
Sensitivity . . . . . . . . . . . . . . . . . .20uV
System Power . . . . . . . . . . .200 Watts
THD . . . . . . . . . . . . . . . . . . . . . . .0.5%
Playback System . . . . . . . .4TRK2CH
Wow and Flutter . . . . . . . . . . . . 0.35%
Crosstalk . . . . . . . . . . . . . . . . . . . 50dB
S/N Ratio . . . . . . . . . . . . . . . . . . .49db
14

Introduction
Thank you for your purchase of a Custom Autosound radio.
This factory made AM/FM cassette receiver is specifically designed and manufactured for
your classic special interest vehicle. It is a reflection of over 25 years of customer feedback
regarding preferred features,vehicle compatibility, cosmetics and quality components.
The quality of the components and various parts that are used in our radios were devel-
oped in a California audio research laboratory. The laboratory researched and assembled
the finest affordable CD C controller radio tuner and amplifier sections.
Custom Autosound and its staff own over 16 classic special interest cars and trucks.
These vehicles are used for research and development, car shows meets and much per-
sonal pleasure. We find that our custom radios only sound as good as the speakers they
are matched with and a quality installation.
We also manufacture a full line of rear and dual front and dual voice coil speaker assem-
blies to fit in the original speaker areas, rear and overhead speaker assemblies and cus-
tom radios for over 300 different year groups and makes of classic vehicles plus
Secretaudio the hideaway AM/FM CD Controller radio for any vehicle.
Your Custom Autosound authorized dealer has information regarding our speakers and
special speaker assemblies, as well as information regarding custom radios for cars other
than yours.
Again, we thank you for your purchase! You have increased the value and "Driving
Pleasure" of your classic without damaging the originality.
Regards, Carl Sprague
President
Custom Autosound
It Is advised that you do Not return defective units to your dealer. There is generally no
"exchange" e.g.(as is standard Electronics Industry Policy). Also, most dealers do not have
radio technicians, test benches, etc and a return to factory through a dealer can extend
turn-around times by weeks!
Please call Custom Autosound, requesting technical assistance if a problem occurs. We
will gladly trouble shoot/advise step by step.
If your unit is in need of repair, Please ship to us, UPS preferably. We will repair or replace
and return ASAP! Normal turn around time is 7 business days plus shipping time.
Custom Autosound Mfg, Inc. 800-8888637
1030 West Williamson Ave Fax [phone]
Fullerton, CA 92833 www.custom-autosound.com
2
Problem Cause Solution
NO Lights, NO Sound
Power Lead:Red Wire not
connected or Power not get-
ting to radio
Check fuse in filter
box.Check all connections
on this wire and verify that
radio is getting 12Volts on
this wire.
Lights but No Sound
Power Lead:Orange Wire not
Connected or power not get-
ting to radio
Check fuse in filter
box.Check all connections
on this wire and verify that
radio is getting 12Volts on
this wire
Lights,Numbers
Displayed but No Sound
Problem with a speaker or
speaker wire
Verify all speakers used
are 4ohm or greater. Verify
that none of the speakers
are going to ground.
Verify that none of the
speaker wires are shorting
to themselves or ground.
Sound only heard on
one side
Noise with Radio
Reception
Speaker wires disconnected
Balance control set to one
side
Antenna not fully extended
Car underneath Fluorescent
lights
Check all connections
Adjust balance control to
center position
Extend antenna to full
length.
Back vehicle out of garage
and test again
13

General Installation
Thank you for your purchase of this Custom Autosound product!
Owner- Installer: Please review installation instructions and owners manual.
Keep in mind that your radio and/or speakers are custom equipment designed specifi-
cally for your year vehicle. It should be handled carefully and installed preferably by an
auto radio specialist. We suggest that you 'Bench Test" the unit before installation, as
we do, prior to shipment.This is to insure that the equipment functions properly before
the time is spent for installation. This way, if a careless installation occurs and the unit
becomes "fried" or some other possible damage,the installer is responsible. Shipping
damage does occasionally occur. If you should suspect shipping damage, please con-
tact the delivery company at once.
Please read the owners manual thoroughly before using your radio.
It is recommended that you disconnect the negative lead from the battery before
installing any electronic equipment in your vehicle. Reconnect when wiring is complete.
First, you will need to remove the original knobs, bezels and shaft nuts. Unplug the
main wire harness and speaker leads from the back of the radio. Disconnect antenna
lead and remove mounting strap from the back of the radio. The radio is now ready to
be removed from the dash. Check the original radio for signs of water or oil damage
from leaks. If leaks are present, do not install the new radio. Water, oil or any other liq-
uid damage is not covered under the new radio warranty.
REAR MOUNTING STRAP OMISSION VOIDS WARRANTY!
Attach the rear mounting strap to rear of radio. Install the radio from behind the dash.
Now attach the mounting strap to the dash or firewall using an existing bolt or screw.
Now install any outer custom trim bezel, if one was furnished for this application and
attach shaft nuts to secure the radio in the dash. Once the radio is centered and
secured, you can install the knobs.
Please refer to wiring instructions on page 4&5.
Plug in antenna lead On speaker hook up make sure the positive lead goes to the posi-
tive terminal and the negative lead to the negative terminal of the speakers. A minimum
of two speakers are required for this stereo radio. DO NOT CONNECT ANY TWO
SPEAKER LEADS TO EACH OTHER OR TO VEHICLE GROUND. Radio damage will
occur. If less than four speakers are used, tape off remaining speaker leads to prevent
a short.
Plug in or wire the red power wire to a switched 12volt source. Plug in or wire the
orange memory wire to a constant 12volt source. Wire the black ground wire to a clean,
solid chassis point or original ground wire from the factory radio.
Good Listening! Audio quality is only as good as speaker quality!
312
Antenna Noise
A static or crackle heard through the speakers, usually when the car is running ,but
sometimes present with the ignition off. If a crackling static if present, follow the steps out-
lined below to confirm the antenna as the source of the noise.
1. Start the car engine.
2. Switch on the USA-1.
3. Adjust the volume so that noise is audible.
4. Reduce volume setting of the car stereo but do not switch it off. If noise
decrease.or disappears, the signal is most likely being picked up by the
car antenna. If the noise persists after following the steps listed below,
proceed to ignition Noise.
Elimination
1. Test or have tested the antenna lead for any breaks or shorts. Signs of crimping,
kinking fraying or rust usually indicates damage to the cable. Replace the
antenna or cable if necessary.
Ignition Noise
A popping or crackling noise heard through the speakers. The noise will vary as the
engine rpm varies,The noise will Only be present with the engine running
Elimination
1. Install an L.C. Filter Network in the power lead of the USA-1. The filter should
be rated at a minimum of 3 amps.
2. Inspect spark plug and distributor cable for signs of wear or damage. Replace
as necessary using resistor cable only. Metal conductor ignition cables
increase static interference.
NOTE: Do not use spark plug or distributor noise filters as these can create more prob-
lems than they can solve. They decrease the quality of the spark generated by the spark
plugs and they may create more static than they eliminate.
Accessory Noise
A popping heard when the lights, turn indicators, windshield wipers, cigarette lighter, etc.
are switched on indicate a vehicle wiring deficiency. Most occurrences are minor and pre-
set no risk to the stereo system other than the annoyance to the listener. However, severe
cases may damage the speakers, minor occurrences can be remedied. A professional
must attend to severe occurrences, as they present a threat to not only the stereo system
but to the vehicle wiring itself.
Elimination
1. Install an L.C. Filter Network in the power leads of the USA-1. The filter should
be rated at a minimum of 3 amps.
2. If the noise persists, consult a professional automotive service technician.

Power and Speaker Connections (Refer to Wiring Diagram on page 5.)
A-Main Power-Red Wire B+
Connect the RED wire (B+) to an accessory fuse that is switched OFF when the
key switch is in the OFF position and is switched ON when the key switch is
switched to the ON or accessory position. (This does not apply to cars with
6volt system)
B-Memory Back-Up-Orange Wire B+
Connect the orange wire (memory B+) to an accessory fuse that is always ON
regardless of the position of the key switch.The lead supplies power to the pro-
gram memory and the clock circuit when the USA-1 is switched off.(This does
not apply to cars with 6volt system)
C-Power Antenna (Auto-Antenna) - Yellow Wire
This wire can be connected to the positive switch terminal of the relay for the
auto antenna (if your car is equipped )or to the remote on switch of the amplifier
or booster (if equipped). NOTE:DO NOT connect this wire to a negative position
or to any device that requires high current Otherwise the radio may fail or
become "fried". If your car is not equipped with an auto antenna,leave this wire
sealed and do not allow it to short to any other positions.
D - Ground Wire - Black
Connect the black ground wire to any clean paint and contaminant free area of
vehicle chassis.
NOTE: Proper grounding is essential for optimum performance of your radio.
E - Speaker Wires
Connect the speaker wires as shown in Figure 1.
Low Level Output (Line Out Jacks) Connection
The USA-1 is equipped with low level, high impedance outputs. The low level
outputs (RCA type Line Out Jack) will not drive speakers. If you are connecting
an amplifier or plan on it in the future, it is recommended to use these leads. It
makes for a cleaner and easier Installation.
Auxiliary Input
This feature is for connecting optional portable audio devices such as:
CD/MP3/TV/DVD/iPod, Satellite Radio etc. An extension lead for quick con-
nect/disconnect is included (connect to RCA’s “CD-IN” at rear of radio).
4
11
Maintenance
It is recommended that the tape head and capstan be cleaned after every 10-15 hours
of play. Liquid tape head cleaners may be used following manufacturer’s instructions or
you may use denatured alcohol applied with a cotton swab. Most tape head cleaning
cassettes should not be used as they may damage the tape head due to the abrasive
textured coating they employ. Use of such tapes may void your warranty.
The tape head should also be demagnetized after every forty hours of play. Tape
demagnetizing cassettes should be used Do not open the unit to use discrete demag-
netizes. Either use the special cassette or let your Autosound dealer perform this serv-
ice .The tape head is delicate and easily damaged if you don’t know what you are
doing.
Noise Suppression
All CAM Systems are designed for maximum electrical noise rejection. In some installa-
tions however, electrical noise may affect the quality of sound reproduction.
The procedures described under Noise is present after installing the USA-1, identify the
source of the noise using the descriptions under Sources Of Electrical Noise. To elimi-
nate the noise follow the procedures described under Elimination of the specific noise
source.
Noise Suppression
1. Check all ground connections. Remove paint from painted surfaces to secure a .
good electrical ground.
2. Check battery posts. If contacts are corroded or loose ,clean and tighten both
. terminals.
3. Check battery or add fluid.
4. Check condition of spark plug and distributor leads. Worn or damaged leads will
. generate noise than can be very difficult to eliminate.
5. Check installation of factory noise suppressor(s). Verify that the connections are . .
. solid. Refer to the vehicles service manual for nose suppressor location or allow a .
. qualified mechanic to inspect the device (s) for you.
6. (Optional) Some professional installers will install a simple L.C. noise filter even if .
. . there is no noise present in the system. This is a simple and relatively inexpensive
. . device available at your nearest Autosound dealer or electronic supply store. Most
. . filters designed for car stereos carry a current rating of 3 amps or more. Follow
the manufacturers installation instructions. This filter is installed in the power lines
of the car stereo.
Sources Of Electrical Noise
Alternator Noise
This noise is generally a high pitch whine present when engine running.The pitch of the
whine will vary as engine RPM varies. Alternator noise usually becomes more apparent
with an electrical load to the system. Switching the headlights on usually increases the
noise.
Elimination
1. Install an L.C.noise filter (available from your Autosound dealer or your nearby .
electronic or automotive supply store) in the power lines of your USA-1. This filter . .
should be rated at 3 amps minimum.
2. Start the car’s engine, switch on the lights (to accentuate the noise) and switch . .
on the USA-1. If noise is still present, proceed to step 3.
3. Install an alternator noise filter (available from your Autosound dealer or your . . .
nearby electronic or automotive supply store). Follow manufacturer’ s installation .
. instructions.

5
5. To rewind the tape,press the Tape Advance Control (6 or 7) with the two arrows that
point in the opposite direction of the tape direction indicator.
6. Fast forward or rewind will stop when the opposite control is depressed or when the
tape reaches the end of a side.
7. To eject the cassette ,depress the Tape Eject Control (3).The tape will be ejected
from the cassette door and the unit will go back to the radio mode automatically.
NOTE: If a cassette does not fully eject,reinsert the tape and depress the Eject Control
(3)until the cassette can be easily removed. Never force the tape from the cassette door.
Cassette Auto Reverse Operation
The USA-1 features an Auto Reverse Cassette Deck. This feature eliminates the need to
eject, remove and reinsert the cassette at the end of one sides play. The other side of the
cassette will be played when the tape reaches the end of one side. This allow for continu-
ous cassette play. The tape program can also be reversed at any time during the normal
cassette playing cycle. To reverse the direction of tape play, momentarily depress both of
the Tape Advance Control (6 and 7) simultaneously. The tape will reverse direction and the
Tape Direction Indicator (18 )will reverse.
Setting The Time
The following procedure must be preformed with the radio ON.
1. With the unit on press and release the Time/Frequency Recall Button (12)so the time
is displayed.
2. Press the Time/Frequency Recall Button (12) for 5 seconds. The hour should be
blinking on the display. Release the button and rotate the Manual Tuning Control (10)
gently to the right, the Hour will advance, Rotating the Manual Tuning Control (10)
gently to the left, the Hour will decrease.
3. Press and release the time/Frequency Recall Button (12) and now the minutes
should be blinking on the display. Rotating the Manual Tuning Control (10) gently to
the right, the Minute will advance. Rotating the Manual Tuning Control (10) gently to
the left, the Minute will decrease.
4. When finished setting the time, press display button. The hours and the minutes will
stop blinking, the clock will show on the display for 5 seconds, and then will revert
back to the radio station display.
Cassette Care
Before inserting cassette it is recommended that any excess tape slack be eliminated For
best performance follow these simple “Do’s and Don’ts.”
Do not store cassettes in direct sunlight to avoid warping the cassette case and damaging
the USA-1 tape mechanism.
Do not leave a cassette inserted when the unit is switched off. This minimizes wear to the
capstan and pinch roller.
Do not store cassettes near any device that might generate a magnetic field (any device
with a transformer, motor or any electrical windings, car speakers, permanent magnets,
etc.).
10

6
9
The USA-1 has built in feature of automatically scanning the presets and automatically
storing new presets.Control this feature by using the Preset Scan and Auto Store
Button(13)-”P/S”.
1. Preset Scan
Momentarily pressing the P/S button (13) will provide recalling stations that are
programmed into the 6 preset buttons. The receiver will search for the station
programmed on preset button 1 and hold that station for 5 seconds and then start
searching again for the station programmed on preset button 2. The receiver will
continue to search until momentarily pressing the P/S button again or any other
button on the face of the radio.
NOTE: if you have no pre-programmed stations on each preset button ,the radio will search
through its default stations. These defaults may not correspond to any radio station in your
area, which will make the radio continually search for a station.
2. Auto Store(Automatic Preset Memory System)
Start by pressing and holding the P/S button for at least 1 second. The radio will then
start to search for stations beginning at the frequency currently being received. The
radio searches for stations in ascending order of the frequency. The preset memories
are updated once all of the frequencies are searched through.
AUX Input Operation
This feature is for connecting an optional portable audio device such as: IPOD,
CD/MP3/TV/DVD/Satellite radio etc. The USA-1 radio comes with an AUX cable that can
plug directly into a headphone connector of a portable device, If this is not the style of con-
nector on your portable device,you may need to purchase the appropriate cables or parts
separately, Once you have connected your portable device to the USA-1, turn on the
USA-1 and the portable device.
1. Depress the AUX button (16) on the USA-1. “AUX” will be visible on the LCD display.
2. Adjust the Volume (1) on the USA-1 to the desired level. If the volume level of the
radio and the portable device are not the same, you may need to adjust the volume
level of the portable device,
3. Control your portable device in the way you normally would. The portable device
should be Playing through the speakers in your vehicle.
Cassette Playing Basic Operation
1. Insert a cassette into the Cassette (4) .The open end of the cassette should be facing
the right side of the USA-1. The Tape Direction lndicators (18) on the left
side of the LCD Display (5). “Tape” will be visible on the LCD display.
2. Adjust the Volume (1), to the desired position.
3. Determine which direction the tape is traveling by viewing the Tape Direction
Indicator (18).
4. To fast forward the tape, press the Tape Advance Control (6 or 7) with the two arrows
pointing in the same direction as the tape direction indicator.

7
Receiver Basic Operation
1. Switch the receiver “ON” by de pressing the power ON/OFF control knob.
2. Press the AUX (16) button to use the auxiliary inputs.
3. Press the TAPE (11) button to play the cassette that is already inserted into the
USA-1.
4. Depress the AM/FM Band Selector (17) to the desired position. In the AM mode, the
AM1 or AM2 lndicator (18) will be visible. In the FM mode, one of FM1, FM2 or FM3
indicator will appear on the LCD Display(5)(18).
5. Manually tune the receiver using the Manual Up-Down Tuning Control (10). A slight
clockwise rotation tunes the radio up-wards and counter clockwise rotation tunes
down-wards. View the currently tuned station on the LCD Display(5)(23).
6. To adjust Bass, Treble, Balance, Fader levels, depress tuning knob(10) until desired
feature is shown on the display, When desired feature is shown on the display, adjust
the level of each feature by turning the Power ON/OFF control(1) clockwise or
counter clockwise to increase or decrease levels.
Station Seek Control
The USA-1 will automatically SEEK the next station in the tuning range by using the Seek
Auto Tuning Control (11). This seek function can be operated on both AM and FM radio
band. If this Seek button is pressed once momentarily the receiver searches for a station
broadcast and holds that station.
Station Scan Control
The USA-1 will automatically SCAN the next station in the tuning range by using the Scan
Auto Tuning(12). This Scan button can be operated on both AM and FM radio band. If the
Scan button is pressed once momentarily, the receiver searches for the next strongest
station and holds that station for approximately 5 seconds and then starts again to search
for the next station. This cycle will be repeated until the Scan button is pressed again
momentarily. Then the unit will hold the station where this cycle was ended.
The USA-1 features 12 AM and 18 FM stations memory presets, using the numbered
buttons located across the bottom of the display will access these presets.
Programming The Preset Memory
The USA-1 features 12 AM and 18 FM stations memory presets, using the numbered
buttons located across the bottom of the display will access these presets.
Programming The Preset Memory
The USA-1 features 12 AM and 18 FM stations memory presets, using the numbered
buttons located across the bottom of the display will access these presets.
A-FM programming
1. Set the AM/FM Band Selector(17) in the FM position (one of the FM bands) and
view the FM Band Indicator(18) on the LCD Display(5).
2. Select the station desired by using the Manual UP-Down Tuning Control (10)
3. Depress one of the 6 preset buttons for approximately 5 seconds. Then the sound will
fade out momentarily and return again. The station is now programmed at that button
and the Preset Channel Number (22) will appear on the LCD display.
4. Repeat above 2-3 steps to program another station on another button. Repeat above
steps until 6 stations are programmed in FM2 and 6 in FM3 for a total of 18 stations.
B-AM Programming
1. Repeat the steps 2-3 above but with the AM/FM Band Selector(17) in the AM band.
2. Repeat above 2-3 steps until you program 6 stations in the AM1 and AM2 bands on
each button.
Digital Display
The USA-1 features a multi-mode liquid crystal digital display(5). It will perform as follows
under various operating conditions (Page 6).
1. When the USA-1 is switched OFF and/or ignition key is switched OFF, the internal
circuitry will continue to keep the stations that you have preset.
2. When the USA-1 is switched ON in the radio mode, the display will indicate the
currently tuned station. The time can be recalled by pressing the Time/Frequency
recall button. (12) The radio will revert back to the current station display after
approximately 5 seconds.
Receiver Special Functions
1. Automatic Mono/Stereo (Built-In) & Stereo Indicator
The built-in Automatic Mono/Stereo (FMO-Frequency Modulation Optimizer) is used
to improve stereo FM reception in weak signal areas without manually changing the
mode.
When the FM station is too weak to receive a clear stereo signal, and noise and
interference increases, the USA-1 will change its mode to Mono automatically. When
the USA-1 is tuned to a strong FM signal, the Stereo lndicator (20) will appear on
the LCD.
2. Channel Space Selection
This feature is used to select how the radio receives signals for either in the USA or a
European style of broadcast.
(1) Disconnect the main power and the memory power.
Move the channel space switch to “USA” position. This changes the channel space to
200KHz for FM and 10KHz for AM.Move channel space switch to”EUR” position to
change the channel space to 50KHz for FM and 9KHz for AM.
8
