cymatic audio Live Player LP-16 User manual

User Manual
LP-16
October 2015

Table of Contents 2
User Manual
LP-16
October 2015
Table of Contents
Table of Contents...........................................................................................................................................................2
1. SAFETY PRECAUTIONS......................................................................................................................................4
1.1. AC adapter ...................................................................................................................................................4
1.2. Environment .................................................................................................................................................4
1.3. Handling .......................................................................................................................................................4
1.4. Connecting cables and input and output jacks .............................................................................................4
1.5. Alterations.....................................................................................................................................................4
1.6. Volume .........................................................................................................................................................4
2. USAGE PRECAUTIONS.......................................................................................................................................5
2.1. Electrical interference...................................................................................................................................5
2.2. Cleaning .......................................................................................................................................................5
3. LIMITED WARRANTY...........................................................................................................................................5
4. INTRODUCTION...................................................................................................................................................6
5. WHAT’S IN THE BOX ...........................................................................................................................................6
6. LP-16 CONNECTIONS AND USER INTERFACE.................................................................................................7
6.1. Front Panel...................................................................................................................................................7
6.2. Rear Panel....................................................................................................................................................8
6.3. Top Panel.....................................................................................................................................................9
7. MODES OF OPERATION...................................................................................................................................10
7.1. Multi-Track Mode........................................................................................................................................10
7.2. Stereo Mode...............................................................................................................................................10
7.3. USB Interface Mode ...................................................................................................................................10
8. SIGNAL FLOW....................................................................................................................................................11
9. LP-16 FOLDER STRUCTURE............................................................................................................................12
10. LP-16 TRANSPORT BEHAVIOR ........................................................................................................................12
10.1. Using the Stop Button.................................................................................................................................12
10.2. Playing back from an offset position...........................................................................................................12
10.3. Accessing a Playlist....................................................................................................................................12
11. WORKING WITH USB MEDIA............................................................................................................................12
11.1. Test failed: Wrong file system.....................................................................................................................13
11.2. Test failed: Disk error..................................................................................................................................13
12. MULTI-TRACK (MT) MODE OPERATIONS AND MENUS.................................................................................14
12.1. Multitrack Mode Home Screen ...................................................................................................................14
12.2. Multitrack Mode Menus...............................................................................................................................15
12.2.1. Playback Mode ..................................................................................................................................15
12.2.2. Select Playlist.....................................................................................................................................15
12.2.3. MIDI Settings .....................................................................................................................................16
12.2.4. Outputs..............................................................................................................................................16
12.2.5. Foot Switch settings...........................................................................................................................16
12.2.6. Display settings..................................................................................................................................17

Table of Contents 3
User Manual
LP-16
October 2015
12.2.7. Format USB Device...........................................................................................................................17
13. STEREO (ST) MODE OPERATIONS AND MENUS...........................................................................................18
13.1. Stereo Mode Screen...................................................................................................................................18
13.2. Stereo Mode Menus ...................................................................................................................................19
13.2.1. Playback Mode ..................................................................................................................................19
13.2.2. Play-out Channels..............................................................................................................................19
14. CONNECTING THE LP-16 TO AN AUDIO MIXER.............................................................................................20
14.1. Connecting LP-16 to a Mixer with Unbalanced Line Inputs ........................................................................20
14.2. Connecting the LP-16 to a Mixer with Balanced Line Inputs.......................................................................20
15. USB INTERFACE MODE....................................................................................................................................21
15.1. Using the LP-16 as an Audio Interface with Microsoft Windows.................................................................22
15.1.1. Minimum System Requirements........................................................................................................22
15.1.2. WDM and ASIO Driver Installation.....................................................................................................22
15.2. LP-16 Mixer / Control Panel for PC ............................................................................................................22
15.2.1. Mixer View .........................................................................................................................................22
15.2.2. Settings View: Synchronization Tab...................................................................................................25
15.2.3. Settings View: Buffers Tab.................................................................................................................26
15.2.4. Settings View: Input Channels Tab....................................................................................................27
15.2.5. Settings View: Output Channels Tab.................................................................................................28
15.2.6. Settings View: About Tab...................................................................................................................29
15.3. Using the LP-16 as an Audio Interface with OS X ......................................................................................30
15.3.1. Minimum System Requirements........................................................................................................30
15.3.2. Driver Installation...............................................................................................................................30
15.4. Using the LP-16 as an Audio Interface with an Apple® iPad® ...................................................................30
15.4.1. Minimum System requirements..........................................................................................................30
15.4.2. Driver Installation...............................................................................................................................30
16. UPDATING THE FIRMWARE ON YOUR LP-16.................................................................................................30
17. TROUBLESHOOTING ........................................................................................................................................31
17.1. Standalone Player Mode ............................................................................................................................31
17.2. USB Audio Interface Mode.........................................................................................................................31
18. SPECIFICATIONS ..............................................................................................................................................32
19. Legal Disclaimer..................................................................................................................................................32

SAFETY PRECAUTIONS 4
User Manual
LP-16
October 2015
1. SAFETY PRECAUTIONS
1.1. AC adapter
Be sure to use only the supplied 12 V DC, 1000 mA AC adapter, which is equipped with a “center-positive”
plug. The use of an adapter other than the specified type may damage the unit and could pose a safety
hazard.
Connect the AC adapter only to an AC outlet that supplies the rated voltage required by the adapter.
When disconnecting the AC adapter from the AC outlet, always grasp the adapter itself and do not pull at
the cable.
During lightning or when not using the unit for an extended period, disconnect the AC adapter from the AC
outlet.
1.2. Environment
To prevent the risk of fire, electric shock or malfunction, avoid using your Live Player LP-16 in environments where it
will be exposed to:
Extreme temperatures
Heat sources
Excessive humidity or moisture
Excessive dust or sand
Excessive vibration or shock
1.3. Handling
Never place objects filled with liquids on the LP-16, as this can cause electric shock.
Do not place an open flame source, such as a lighted candle, on the LP-16 since this can cause fire.
The LP-16 is a precision instrument. Do not exert undue pressure on the keys and other controls. Also take
care not to drop the unit, and do not subject it to shock or excessive pressure.
Take care that no foreign objects (coins, pins etc.) or liquids can enter the unit.
1.4. Connecting cables and input and output jacks
Always turn off the power to the LP-16 and all other equipment before connecting or disconnecting the power source.
Make sure to disconnect all connection cables and the power cord before moving the LP-16.
1.5. Alterations
Do not open the case of the LP-16, or attempt to modify the product in any way. Doing so will void the warranty.
There are no serviceable parts inside the unit.
1.6. Volume
Do not use the headphone output of the LP-16 at a loud volume for a long time since this can cause hearing
impairment

USAGE PRECAUTIONS 5
User Manual
LP-16
October 2015
2. USAGE PRECAUTIONS
2.1. Electrical interference
For safety considerations, the LP-16 has been designed to provide maximum protection against the emission of
electromagnetic radiation from inside the device, and protection from external interference. However, equipment that
is very susceptible to interference or that emits powerful electromagnetic waves should not be placed near the LP-16,
as the possibility of interference cannot be ruled out entirely. With any type of digital control device, the LP-16
included, electromagnetic interference can cause malfunctioning and can corrupt or destroy data. Care should be
taken to minimize the risk of damage.
2.2. Cleaning
Use a soft, dry cloth to clean the LP-16. If necessary, slightly moisten the cloth. Do not use abrasive cleanser, wax, or
solvents (such as paint thinner or cleaning alcohol), since these may dull the finish or damage the surface.
3. LIMITED WARRANTY
For the applicable warranty terms and conditions and additional information on Cymatic Audio’s Limited Warranty,
please see complete details online at www.cymaticaudio.com/warranty
This product complies with the European Union Council Directives and
Standards relating to Directive 2004/108/EC for Electromagnetic compatibility
(EMC) and Low Voltage Directive 2006/95/EC
This product is compliant with the EU Directive 2011/65/EU for the Restriction of
the use of Certain Hazardous Substances in Electrical and Electronic Equipment.
No lead (Pb), cadmium (Cd), mercury (Hg), hexavalent chromium (Cr+6), PBB or
PBDE is intentionally added to this device. Any traces of impurities of these
substances contained in the parts are below the RoHS specified threshold levels.
This equipment has been tested and found to comply with the requirements of 47
CFR of PART 15 limit for radiation and conduction emission relating to FCC rules
Part 15B: 2010.
A NOTE ABOUT DISPOSAL:
This product must be disposed in accordance with the local recycling regulations.
The crossed out wheeled bin symbol informs you that the product should not be
disposed of along with municipal waste and invites you to use the appropriate
separate take-back systems licensed for the recycling of electrical and electronic
equipment (EEE).
CERTIFICATIONS

INTRODUCTION 6
User Manual
LP-16
October 2015
4. INTRODUCTION
Cymatic Audio Live Player LP-16 is an easy to use direct from USB player that can play back 16-tracks of audio
along with a MIDI file. It can also be used as 18-output, 2-input USB audio interface for PC, Mac® and iPad®.
The LP-16 works as a dedicated multi-track player for live performances, while sparing users the hassles of using a
laptop and computer audio interface in a live environment. The LP-16 audio tracks can be connected directly into the
line inputs of a live sound mixer. These tracks can be individually mixed alongside the audio from live performers to
augment their performance.
Used in connection with a Windows PC, Mac® or iPad®, the LP-16 also serves as an 18-output/ 2-input USB audio
interface. With a large number of outputs, the individual tracks of a multi-track DAW session can easily be connected
to the individual inputs of an analog studio mixer, perfect for analog summing and mixing “out of the box”, imparting
classic analog flavor to your next mix session.
The LP-16 User Manual contains in-depth details of your Live Player’s features and functionality which include:
Direct from USB hard drive multi-track playback (16 tracks at 44.1/48kHz and 16/24 bit)
MIDI I/O with synchronized Standard MIDI File player functionality
16 unbalanced analog 1/4” tip-sleeve outputs
1/8” Stereo Line level input¨
Front panel ¼” headphone output with dedicated level control
Zero latency hardware input monitoring (USB Interface Mode)
2-input / 18-output USB audio interface, 24 bit/44.1/48 kHz USB Class Compliant
Mac® OS-X® compatible: Core Audio plug and play drivers
Windows® PC compatible (Windows XP, Vista, 7 & 8 32-bit/64-bit) WDM and ASIO® drivers.
IPad® compatible: Plug and play. USB adapter required including
Apple® Lightning to USB Camera Adapter
Apple® USB Camera Connection Kit
Foot Switch connector for hands free playback/pausing of track playback
Creation and editing of songs and playlist files offline, using Cymatic’s uTool software
5. WHAT’S IN THE BOX
LP-16 player
AC/DC power adapter and power cable
USB cable
Quick Start Guide

LP-16 CONNECTIONS AND USER INTERFACE 7
User Manual
LP-16
October 2015
6. LP-16 CONNECTIONS AND USER INTERFACE
6.1. Front Panel
1. USB Storage Connector
Attach a USB thumb drive or USB hard drive to this connector, to playback songs direct from USB.
2. MIDI input
The MIDI input receives incoming MIDI messages, and can also be configured as a MIDI thru using the MIDI settings
menu.
3. MIDI Output
The MIDI output connector can output the MIDI data from Standard MIDI Files (SMF) synchronously with a multitrack
song. With this capability, the LP-16 can trigger external MIDI hardware such as MIDI synthesizers or MIDI-enabled
lighting controllers.
4. Foot Switch Connector
The footswitch connector allows connection of a standard on/off foot pedal, which can be configured to start play or to
play and pause the current song.
5. Headphone Out
The headphone connector outputs a stereo signal, which works as follows:
•In MT mode, it outputs a mono mix of the 16 tracks
•In ST mode, it outputs the stereo file currently being played back
•In USB mode, it outputs the stereo DAW signal
6. Headphone Volume
This knob allows volume adjustment of the front-panel headphone output.
! For more details of the above connectors’ functions, refer to the “Menus” section of this user’s manual
1
3
2
4
5
6

LP-16 CONNECTIONS AND USER INTERFACE 8
User Manual
LP-16
October 2015
6.2. Rear Panel
1. Mono Line-Level Output Connectors
These unbalanced connectors each output a separate mono audio track, sourced from the multi-track song being
played back.
2. Stereo 3.5mm Input
This connector is used as a 2-channel, unbalanced line-level input when the LP-16 is operating in USB interface
mode.
3. USB Device Connector
This female USB connector is used to attach the LP-16 to an OS X or Windows computer, or an iOS device,
allowing the LP-16 to act as a 2-input, 18-output audio interface.
4. External Power Supply Connector
Connect the included external power supply to this connector.
5. Power Switch
Use this switch to turn power on/off to the LP-16
1
3
2
4
5

LP-16 CONNECTIONS AND USER INTERFACE 9
User Manual
LP-16
October 2015
6.3. Top Panel
The top panel buttons perform the following functions, depending on which of the three modes is currently active:
Multitrack Mode
Stereo Mode
USB Interface Mode
1
Switch to stereo mode
Switch to multitrack mode
No Function
2
Show multitrack mode menu
Show stereo mode menu
Show input settings menu
3
Go back to previous screen
Go back to previous screen
Go back to previous screen
4
Increment playback offset
Increment playback offset
No Function
5
Decrement playback offset
Decrement playback offset
No Function
6
Pause/Stop playback
Pause/Stop playback
No Function
7
Start playback
Start playback
No Function
8
Show folder contents screen
Show folder contents screen
No Function
9
Selection up
Selection up
Selection up
10
Select
Select
Select
11
Selection down
Selection down
Selection down
In addition, four separate key combinations are also available that perform the following functions:
Stop & Play Toggles between playlist mode and normal player mode the LP-16
Long press Stop Send midi all notes off in multi-track player mode
1
3
2
4
5
6
7
8
9
10
11

MODES OF OPERATION 10
User Manual
LP-16
October 2015
7. MODES OF OPERATION
The LP-16 offers three different modes of operation, depending on your specific needs:
7.1. Multi-Track Mode
This mode, hereby abbreviated as “MT Mode”, is the main operational mode of the LP-16. In MT mode, the unit can
play back up to 16 separate tracks of audio along with a MIDI file. Each audio track is output to a separate physical
¼” output connector on the rear panel of the unit. MIDI is played on the MIDI port on the front panel of LP-16.
7.2. Stereo Mode
The LP-16 also offers a “stereo player mode”, hereby referred to as “ST Mode”. This mode is ideal for playback of
stereo audio songs, such as pre-show, post-show, and break music. The stereo songs can be configured to be output
from a specific pair of outputs on the rear panel.
NOTE: The LP-16 only plays back stereo files in the “.wav” format.
NOTE: The mode button can be used to toggle between Multitrack mode and stereo mode.
Cymatic Audio provides a software application called uTool. Songs and Playlist projects (both multitrack and stereo)
can be created in uTool and exported to a USB drive. The USB drive can then be plugged into the LP-16 for
playback. uTool software and user manual are available at www.cymaticaudio.com/downloads.
7.3. USB Interface Mode
In USB Interface mode, the LP-16 acts as a 2-input, 18-output audio interface for OS X, Windows, and iOS. For more
details, please refer to the section titled “USB Interface Mode”. The interface mode is not available when the LP-16 is
being used in standalone for playback with the USB drive.

SIGNAL FLOW 11
User Manual
LP-16
October 2015
8. SIGNAL FLOW
The LP-16 contains 16 separate line-level outputs, which are sent out on 16 separate mono, unbalanced
line-level outputs.
In MT mode, the LP-16 also contains an internal digital mixer that provides a mono mix down of the 16
separate audio streams, mixed together at unity gain. This internal mix is sent out of the front-panel
headphone output.
When operating as a USB computer audio interface, the stereo line input allows recording of 2 incoming
channels to the DAW, while 18 separate DAW output channels can be sent to the LR-16 (16 to the rear-
panel outputs and an additional stereo channels sent to the headphone output).

LP-16 FOLDER STRUCTURE 12
User Manual
LP-16
October 2015
9. LP-16 FOLDER STRUCTURE
The uTool software exports the songs and playlist projects into specific folders on the USB drive. All the multitrack
songs are exported to the “Recording” folder and all the Multitrack playlists are exported to “Recording/#PLAYLISTS”
folder. All the stereo songs are exported to the “Music” folder and all the stereo playlists are exported to
“Music/#PLAYLISTS” folder.
10. LP-16 TRANSPORT BEHAVIOR
10.1. Using the Stop Button
When the LP-16 is currently playing back a song:
The first press of the stop button pauses the playback.
The second press stops the playback.
10.2. Playing back from an offset position
To start playback of a song from an offset position:
Press the skip forward or skip backward button to start the playback offset overlay. Use the same buttons to
increment or decrement the start offset. Long press helps to jump with higher granularity. After a desired
offset is reached, press the play button to start playback from the selected offset position. The offset overlay
disappears after playback starts,
Press the back button to remove the offset overlay.
10.3. Accessing a Playlist
To navigate to a playlist folder, use one of the three following methods:
Press the “folder” button; the folder active for the current mode opens up. You can then navigate to the
playlist folder.
Press the stop and play buttons at the same time to toggle between normal playback mode and playlist
mode.
Press the “menu” button and then select the “Go to Playlist” menu option
11. WORKING WITH USB MEDIA
Connect the LP-16 to its external power supply and turn it on. After the brief display of start-up screen, you
will see the following screen:
Plug in a USB hard drive or USB thumb drive into the USB storage connector on the front of the LP-16.
If the LP-16 determines that the storage device is suitable for playback, a new screen will appear for a few
seconds, displaying the amount of free space available on the attached drive
After displaying this information for a few seconds, the LP-16 display will switch to the playback “home screen”.
NOTE: We recommend the use of USB hard drives instead of USB thumb drives because the USB hard drives
traditionally tend to offer a more reliable and predictable read speed than USB thumb drives

WORKING WITH USB MEDIA 13
User Manual
LP-16
October 2015
11.1. Test failed: Wrong file system
If the inserted drive is not formatted in the required FAT32 format, the LP-16 will display an error message.
Follow the instructions on screen to format the USB drive.
Please keep in mind that formatting the attached USB drive will erase all data currently residing on the drive.
11.2. Test failed: Disk error
If the inserted drive is defective the screen will give a “Disk Error”

MULTI-TRACK (MT) MODE OPERATIONS AND MENUS 14
User Manual
LP-16
October 2015
12. MULTI-TRACK (MT) MODE OPERATIONS AND MENUS
12.1. Multitrack Mode Home Screen
After the attached USB drive has been successfully tested, the LP-16’s screen will display the MT mode “home
screen”.
Single Playback Screen Playlist Screen
1. LP-16 Mode
Shows the currently selected playback mode for the LP-16: Multitrack (MT), Stereo (ST), or USB (USB). When
the LP-16 is in USB interface mode, the status message will display “PC” or “MAC” ¨
2. Playback offset overlay
Playback offset overlay can be used to play the song from an offset. Use Skip forward and Skip backward
buttons to choose the offset and then the Play button to start playing from the offset.
3. Playback Status
This icon shows the current state of the playback transport (play/stop/pause).
4. Playback Mode Icon
This icon displays the playback mode. Playback mode for MT is explained in detail in the section 12.2.1.
5. Remaining time
This number represents the remaining playback time of the currently playing song.
6. Active Song Position/Active Playlist Name
Displays the position of the active song inside the folder. In playlist screen, displays the name of the playlist.
7. Active song name
Displays the name of the currently active song in single mode.
8. Signal Level Meters (-30dB / -3dB / 0dB)
This group of meters displays the approximate signal strength of the audio tracks that are playing back.
9. MIDI Input Indicator Light
This circle flashes in time with the data stream of any incoming MIDI signals that are feeding the MIDI input
connector.
10. MIDI Output Indicator Light
This circle flashes in time with the data stream of any outgoing MIDI signals that are sent out of the MIDI output
connector.
2
1
8
9
5
4
10
3
6
7
5
4
6
11
12

MULTI-TRACK (MT) MODE OPERATIONS AND MENUS 15
User Manual
LP-16
October 2015
11. Next Song Icon
This icon indicates how the next song will play back relative to the currently playing song:
There will be no pause between the current and the next song
The next song will pause until play / footswitch is pressed
The next song will play after seconds specified in playlist. Can be overruled by play button / footswitch
12. Next Song Name in Playlist
This line displays the name of the next song in the playlist, which will play when the current song is completed.
12.2. Multitrack Mode Menus
Pressing the Menu Button while in multitrack mode will take you to the Multitrack Mode Menu.
Use the Up/Down buttons, to navigate to the desired menu setting. Use the Select button to choose the settings. Use
Up/Down to modify values and Select to confirm the changes. Back button can be used to go one level back without
changing the parameters.
12.2.1. Playback Mode
This screen allows you to select between the two playback modes available in MT mode:
Playlist Mode: In this mode, the LP-16 will play back files in the order that has been set up in the playlist. To
make a playlist, use the uTool software.
Single Mode: In this mode, any MT song residing in the currently selected folder can be chosen. Playback
will play only the single selected song and then stop.
12.2.2. Select Playlist
This screen allows you to select a playlist to load into memory.

MULTI-TRACK (MT) MODE OPERATIONS AND MENUS 16
User Manual
LP-16
October 2015
Use the up and down buttons to scroll to the desired playlist and select button to choose the playlist.
12.2.3. MIDI Settings
This screen allows adjustment of various setting related to the MIDI input and output connectors.
MIDI Thru: Use this menu to toggle a “MIDI Thru” function on/off for the front panel MIDI output.
When MIDI through is activated, all MIDI messages coming into the LP-16 will be merged with the currently
playing MIDI file (if one is being played back) and then routed to the LP- 16’s MIDI output.
If MIDI through is turned off, this merge activity does not occur
MIDI Offset: Adjust this setting to provide an offset (delay) between the start time of a loaded standard MIDI file,
and the start time of the associated song. This setting allows you to fine-tune the synchronization timing between
the MIDI file and the triggered audio.
Send All Notes Off: Select this menu to issue an “all notes off” out of the LP-16’s MIDI output, message to a
connected MIDI device, useful if any “stuck notes” occur on a connected MIDI playback device. To issue the
command immediately, long press the Stop button in any state.
12.2.4. Outputs
Every multitrack song can have mixer fader settings for the headphone outputs (using uTool). The 16 line outputs of
LP-16 can be chosen to be pre or post fader. The appropriate option can be chosen from outputs settings. Choose
pre-fader when you do not want the mixer fader settings to affect your 16 line outputs.
12.2.5. Foot Switch settings
The LP-16 can use a standard ¼” equipped footswitch to perform various functions. The foot switch settings screen
allows you to adjust what specific actions occur when you press the attached foot switch.
Type: Adjust the “type” setting to tell the LP-16 if you are using a “normally open” or “normally closed” type footswitch.
Consult your footswitch’s documentation to determine which type you have.
Function: Adjust this setting to configure what specific function the footswitch will perform, when it is pressed
Play: Pressing the footswitch mimics the top panel “play” button.
Play and Pause: Pressing the footswitch will begin playback. A second press of the footswitch will pause
playback, and a third press will un-pause the playback.

MULTI-TRACK (MT) MODE OPERATIONS AND MENUS 17
User Manual
LP-16
October 2015
12.2.6. Display settings
This screen allows you to adjust the LCD display’s contrast, as well as its brightness, in order to ensure optimal
readability at different viewing angles.
12.2.7. Format USB Device
The format function can be used to format an attached hard drive or thumb drive that is connected to the Live Player.
This operation can be useful in the following scenarios:
The attached drive has not passed the LP-16’s drive test, because it is not currently formatted in the
required FAT-32 disk format
The attached drive has been previously formatted in the correct FAT-32 format, but has not had its data
blocks optimized properly by the computer it was formatted on, resulting in a failure of the LP-16 disk test.
In these cases, formatting the drive on the LP-16 may allow the disk to pass, since the LP-16 will format the attached
disk with the required optimal settings.
!
All data as well as all partitions on the thumb or
hard drive will be deleted when the format
function is used!

STEREO (ST) MODE OPERATIONS AND MENUS 18
User Manual
LP-16
October 2015
13. STEREO (ST) MODE OPERATIONS AND MENUS
13.1. Stereo Mode Screen
Pressing the mode button when in MT mode switches the LP-16 into stereo mode. The stereo mode screen has a
different layout compare to MT mode.
Other Modes Playlist Mode
1. LP-16 Mode
This icon will display “ST” to show that the LP-16 is currently operating in Stereo mode.
2. Playback offset overlay
Playback offset overlay can be used to play the song from an offset. Use Skip forward and Skip backward
buttons to choose the offset and then the Play button to start playing from the offset.
3. Playback Status
This icon shows the current state of the playback transport (play/stop/pause)
4. Playback Mode Icon
This icon displays the playback mode. Playback mode for ST is explained in detail in the section 13.2.1.
5. Remaining Time In Song
This counter shows the remaining time left in the currently playing song
6. Song List
All the stereo songs of the active folder are displayed in the song list field. The songs can be browsed using the
up/down buttons. Any highlighted song can be chosen for playback. A small play icon appears against the
currently playing song.
7. Level Meters (-30dB / -3dB / 0dB)
These meters show the output level of the currently playing song. In ST mode, only the 2 output channels that
have been assigned the stereo playback will illuminate with meter activity.
8. Playlist Name
This field shows the name of the song in the playlist that is currently playing back
9. Next Song Icon in Playlist
This icon indicates how the next song will play back relative to the currently playing song:
There will be no pause between the current and the next song
The next song will pause until play / footswitch is pressed
The next song will play after seconds specified in playlist. Can be overruled by play button / footswitch
10. Next Song Name in Playlist
This field shows the name of the next song in the playlist that will play back when the current one is completed.
2
1
7
5
4
3
6
9
5
4
8
10

STEREO (ST) MODE OPERATIONS AND MENUS 19
User Manual
LP-16
October 2015
13.2. Stereo Mode Menus
Pressing the Menu Button while in stereo mode will take you to the Stereo Mode Menu.
Use the Up/Down buttons, to navigate to the desired menu setting. Use the Select button to choose the settings. Use
Up/Down to modifiy values and Select to confirm the changes. Back button can be used to go one level back without
changing the parameters.
13.2.1. Playback Mode
This menu allows you to set the stereo playback mode in LP-16:
Playlist: Files within a playlist will be played back as they are configured to playback using uTool.
Single: Only a single song will be played back until the end.
Repeat all: All the songs of the currently active folder will be played back repeatedly.
Repeat one: A single song is repeatedly played back.
Shuffle: The LP-16 will shuffle the songs in a folder for playback.
The currently selected playback mode will be shown, as an icon, at the top of the home page, to the left of the
time counter.
13.2.2. Play-out Channels
This menu allows you to set which specific pair of rear-panel outputs the stereo audio file will be output to.
Use the up/down buttons to change the channels and use Select button to choose the playout channels.
NOTE: Rest of the menu options are common with MT menu and are explained in the section 12.2.

CONNECTING THE LP-16 TO AN AUDIO MIXER 20
User Manual
LP-16
October 2015
14. CONNECTING THE LP-16 TO AN AUDIO MIXER
14.1. Connecting LP-16 to a Mixer with Unbalanced Line Inputs
The LP-16 offers 16 unbalanced analog ¼” output connectors, using a TS (tip-sleeve) configuration. Thus, it is best
connected to a mixing console with unbalanced, tip-sleeve line inputs.
The illustration above shows the following connections:
Upto 16 tracks of audio are sent from the LP-16 to the line inputs of a live sounding mixing console
MIDI keyboard connected to LP-16 MIDI in, MIDI sound module connected to MIDI out
Additional live musicians are fed into other inputs of the console, using its mic inputs
The live sound engineer mixes the backing tracks of the LP-16 alongside the live signals. In effect, the pre-
recorded tracks from the LP-16 act as “virtual band members”.
14.2. Connecting the LP-16 to a Mixer with Balanced Line Inputs
In some situations, the LP- 16 will be connected to inputs of a mixing console that only offers balanced inputs, in the
form of tip-ring-sleeve (TRS) inputs. As long as the mixing console has a properly designed balanced input, you can
use a normal unbalanced TS to TS ¼” cable, with no special cables or adapters required.
If you are using a console that does not have a properly balanced input, use a TS to TS cable, and on the end of the
cable that connects to the mixing console’s balanced TRS inputs, add a TS-to-TRS adapter. This will convert the
unbalanced signal from the LP-16 to a TRS signal that will operate correctly with the console’s balanced inputs.
TS-to-TRS Adapter (ring not
