DèLonghi EO 4035 User manual

9
IMPORTANT SAFEGUARDS
Read all the instructions carefully before using the ap-
pliance. Keep these instructions
Please note:
This symbol identies important advice or information for the
user.
• Beforeusingtheovenforthersttime,removeanypaper
and other material inside the oven such as protective card-
board,booklets,plasticbags,etc.
• Theappliancemustbekeptatadistanceofatleast20cm
fromthemainspowersockettowhichitisconnected.
• After positioning the appliance on the worktop, leave a
spaceofatleast10cmbetweenthesurfacesoftheappli-
anceandthesideandatleast10cmabovetheoven.
• Before using for the rst time, operate the oven empty
with the thermostat at maximum for at least 15 minutes
toeliminatethe“new”smellandanysmokecausedbythe
presenceofprotectivesubstancesappliedtotheheating
elements before transport.Ventilate the room.
• Washallaccessoriesthoroughlybeforeuse.
Important!
Failuretoobservethewarningcouldresultininjuryordamage
to the appliance.
• Thisovenisdesignedtocookfood.Itmustneverbeused
forotherpurposes,modiedortamperedwithinanyway.
• When you have unpacked the appliance, make sure the
door is undamaged and working correctly.  The door is
made from glass and is therefore fragile. If it is visibly
chipped,scoredorscratched,itshouldbereplaced.While
using,cleaningormovingtheappliance,avoidslamming
orknockingthedoorviolently.Donotpourcoldliquidonto
theglasswhiletheapplianceishot.
• Placetheapplianceonahorizontalsurfaceataheightofat
least 85 cm and out of reach of children.
• This appliance can be used by children
aged 8 upwards and by persons with
reducedphysical,sensoryormentalca-
pabilitiesorwholackofexperienceand
knowledgeiftheyaresupervisedorhave
beengiveninstructions concerninguse
of the appliance in a safe way and un-
derstandthehazardsinvolved.Children
mustnotplaywiththeappliance.Clean-
ingandusermaintenancemustnotbe
carried out by children unless they are
older than 8 and supervised. Keep the
appliance and its cord out of the reach of
childrenunder8yearsofage.
• Donotmovetheappliancewhileinuse.
• Donotusetheapplianceif:
- The power cable is faulty
- the appliance has been dropped, is visibly damaged or
malfunctions.Inthesecases,toavoidallrisktaketheap-
pliance to your nearest authorised customer services.
• Neverpositiontheappliancenearheatsources.
• Donotusetheapplianceasaheatsource.
• Neverplacepaper,cardboardorplasticinsidetheovenand
neverrestanythingontopoftheappliance(utensils,wire
racks,otherobjects).
• Neverinsertanythingintotheventilationopenings.Make
sure they are unobstructed.
• Thisovenisnotdesignedforbuilt-ininstallation.
• Donotrestheavyobjects,boilingpansorcontainersonthe
opendoor.Donotpullthehandledownwards.
• Professionalorinappropriateuse,orfailuretoobservethe
instructions absolves the manufacturer from all responsi-
bilityandinvalidatestheguarantee.
• This is a household appliance only.
 Itisnotintendedtobeusedin:insta
kitchenareasinshops,ocesandoth-
erworkingenvironments;farmhouses;
by clients in hotels, motels and other
residentialtypeenvironments;bedand
breakfasttypeenvironments.
• Whennotinuseandbeforecleaning,alwaysunplugthe
appliance.
• The appliance must not be operated by
a timer or a separate remote control sys-
tem.
• Theappliancemustbeplacedandoperatedwiththeback
next to the wall.
• Beforecleaning,alwaysturntheapplianceobysetting
thetimerto“0”andunpluggingitfromthemainssocket.
Danger of burns!
Failuretoobservethewarningcouldresultinscaldsorburns.
• Wheninoperation,thedoorandaccessi-

10
ble external surfaces could become very
hot.Alwaysusetheknobs,handlesand
buttons.Nevertouchmetalpartsorthe
glass.Useovenglovesifnecessary.
• Thiselectricalapplianceoperatesathigh
temperatures which could cause burns.
• Donotleaveinammableproductsneartheovenorunder
theworksurfacewhereitislocated.
• Neveroperatetheapplianceunderawallcupboardorshelf
ornearinammablematerialssuchascurtains,blinds,etc.
• Iffoodorotherpartsoftheovencatchre,nevertryand
putouttheameswithwater.Closethedoor,unplugfrom
themainsandsmothertheameswithadampcloth.
Danger!
Failure to observe the warning may result in life threatening
injurybyelectricshock.
• Beforepluggingintothemains,makesurethat:
- Themainsvoltagecorrespondstothevoltageindicatedon
theratingplate.
- The mains socket has a minimum rating of 16A and an
earth wire.
The manufacturer declines all liability in the event that this
important accident-prevention rule is not respected.
• Donotletthepowercabledangleandavoidtouchinghot
partsoftheoven.Neverunplugtheappliancebypulling
on the power cable.
• Ifyouintendtouseanextension,makesureitisingood
condition,thattheplugisearthedandthatthecrosssec-
tionofthewiresisatleastequaltothatofthepowercable
provided with the appliance.
• Toavoidallriskofelectricshock,neverimmersethepower
cable,plugorapplianceitselfinwater.
• Ifthepowercableisdamaged,itmust
be replaced by the manufacturer, the
manufacturer’s customer services or a
qualiedelectricianinordertoeliminate
allrisk.
• Foryourpersonalsafety,nevertaketheappliancetopieces
onyourown.AlwayscontactCustomerServices.
TECHNICAL SPECIFICATION
Voltage:220-240V~50/60Hz
Absorbedpower:1800W
ExternaldimensionWxDxH:535x405x355
Weight:approximately10kg
TheappliancecomplieswiththefollowingECdirec-
tives:
• LowVoltageDirective2006/95/ECandsubsequentamend-
ments;
• EMCDirective2004/108/ECandsubsequentamendments
• Materialsandaccessoriescomingintocontactwith food
conformtoEuropeanregulation(EC)no.1935/2004.
DISPOSAL
In compliance with European directive 2002/96/EC,
the appliance must not be disposed of with house-
holdwaste,buttakentoanauthorisedwastesepara-
tionandrecyclingcentre.
DESCRIPTION OF APPLIANCE
A thermostatknob
B functionselectorknob
C timerknob
D indicatorlight
E glassdoor
F wirerack
G wirerack(ifsupplied)
H bakepan
I wirerackhandle(ifsupplied)
L spit
M spithandle
N crumbtray
O bottomheatingelement
P topheatingelement
Q turnspit mount
R turnspit support
GUIDE
1
2
3
4

11
TIMER KNOB (C)
Thetimerknob(C)canbesetupto120minutes.
Theovenwillnotturnonwithoutthetimerbeingset.
Whenthetimerknobisinthe“0”position,theovenwillnot
operate.
Toselectthecookingtime,turnthetimerknobclockwisetothe
desired time.
Indicatorlight(D)islitonlywhentimehasbeenset.
Whenthetimerknobhasreachedthe“0”position,anaudible
signalwillbeemittedandtheappliancewillturno.
Thecookingtimecanbechangeduringcookingcycle.Justturn
thetimerknobtothedesiredtimeandcontinuecooking.
Forusetheappliancewithouttimecontrol,turnthetimerknob
toONposition.Inthiscase,the appliancewillworkuntilthe
timerknobissetto“0”position.
Thecookingtimesdependonthequalityoftheproducts,onthe
temperature of the food and on personal tastes.
THERMOSTAT KNOB (A)
Turnthethermostatknob(A)clockwisetothedesiredtempera-
turesetting.Thetemperaturecanbesetupto230°C.
FUNCTION SELECTOR KNOB (B)
Thisknobisusedtoselectthecookingfunctionsavailable.
Whencookingwiththeconvectionoven,traditionalovenand
grilling,alwayspreheattheovenfor5minutestothesettem-
perature.
Thecookingfunctionsare:
DEFROST (only on some models)
Forproperdefrostinginashorttime,proceedasfollows:
• Insertthebakepan(H)inguide4,thewirerack(F)inthe
guide3andrestthefoodtobedefrosted.
• Turnthefunctionselectorknob(B)tothe position.
• Turnthethermostatknob(A)tothe“ •”position.
• Turn thetimerknob(C)totheONpositionor selectthe
desiredcookingtime,thenclosethedoor.
• Tocookfrozenfoodsrefertotherecommendedtimeson
theproductpackaging.
KEEP WARM
• Insertthebakepan(H)inguide3andrestthefood.
• Turnthefunctionselectorknob(B)tothe position.
• Turnthethermostatknob(A)tothe position.
• Turn thetimerknob(C)totheONpositionor selectthe
desiredcookingtime,thenclosethedoor.
 Itisrecommendednottoleavethefoodsintheovenfor
toolong,asthesemaydryout.
• Usewirerackhandle(I)(ifsupplied)tobringthewirerack
andbakepanoutoftheovenwhenitishot.
SLOW BAKE
Idealforpastryandcakes.Goodresultsarealsoachievedwhen
completingthecookingofthebottomofthefoodsorforcook-
ingthatrequiresheataboveallatthebottom.
• Insertthebakepan(H)inguide3andrestthefood.
• Turnthefunctionselectorknob(B)tothe position.
• Selecttherequiredtemperature,from100°Cto160°C,us-
ingthethermostatknob(A).
• Turn thetimerknob(C)totheONpositionor selectthe
desiredcookingtime,thenclosethedoor.
• Usewirerackhandle(I)(ifsupplied)tobringthewirerack
andbakepanoutoftheovenwhenitishot.
BAKE
This function is ideal for all types of sh, stued vegetables,
cakes with whipped egg-whites and cakes thatrequire long
cookingtimes(over60min.).Proceedasfollows:
• Insertthewirerack(F)orthebakepan(H)tothedesired
guide.
• Turnthefunctionselectorknob(B)tothe position.
• Selecttherequiredtemperaturebyturningthethermostat
knob(A).
• Turn thetimerknob(C)totheONpositionor selectthe
desiredcookingtime,thenclosethedoor.
• Afterhavingpre-heatedtheovenfor5minutes,placethe
food inside.
• Usewirerackhandle(I)(ifsupplied)tobringthewirerack
andbakepanoutoftheovenwhenitishot.
CONVECTION (only on some models)
Usetheconvectionfunctionformeat,bakingpizzaandbread.
• Insertthewireracktothedesiredguideandrestthefood.
• Turnthefunctionselectorknob(B)tothe position.
• Selecttherequiredtemperaturebyturningthethermostat
knob(A).
• Turn thetimerknob(C)totheONpositionor selectthe
desiredcookingtime,thenclosethedoor.
• Usewirerackhandle(I)(ifsupplied)tobringthewirerack
andbakepanoutoftheovenwhenitishot.
GRILL
Thisfunctionisidealfortoast,sh,steak,vegetables,etc.
• Placethefoodtobegrilledonthewirerack(F)insertedon
thebakepan(H),andplacethemtogetherintheguide1.
• Turnthefunctionselectorknob(B)tothe position.
• Turnthethermostatknob(A)tothe position.

12
• Turn thetimerknob(C)totheONpositionor selectthe
desiredcookingtime,thenclosethedoor.
• Turnhalfwaythroughcooking.
• Usewirerackhandle(I)(ifsupplied)tobringthewirerack
andbakepanoutoftheovenwhenitishot.
ROTISSERIE
Thisfunctionisidealforcookingchickensonthespit,fowlin
general,roastporkandveal.
• Placethefoodonthespit(L)andholditrmusingforks
(forbestresults,tiethemeatusingkitchenstring).
• Insertthebakepan(H)inguide4andthespit(L)inthe
turnspitmount(Q)andturnspitsupport(R).
• Turnthefunctionselectorknob(B)tothe position.
• Turnthethermostatknob(A)tothe position.
• Turn thetimerknob(C)totheONpositionor selectthe
desiredcookingtime,thenclosethedoor.
• Oncethecookingtimehasbeencompleteandyouhave
checked the internal temperature of the food to ensure
thatithas cooked properly, youcanremovethespit (L)
withthespithandle(M).
INTERIOR LIGHT (ONLY ON SOME MODELS)
Turnthefunctionselectorknob(B)tothe position and the
interiorlightstayon.
CLEANING
Frequentcleaningwillpreventtheformationofsmokeandbad
smellsduringcooking.
Beforeperforminganycleaningoperations,alwaysunplugthe
appliancefromthepowersocket.
Neverimmersetheapplianceinwater;donotwashitbyspray-
ingitwithwater.
Thewirerack(F),bakepan(H),crumbtray(N)arewashedlike
normaldishes,byhandorinthedishwasher.
Alwaysuseadampspongetocleantheoutersurface.
Avoidusingabrasiveproductsthatmaydamagethesurfacen-
ish.Makesurewaterorliquidsoapdoesnotinltratethrough
theslitsontherighthandsideoftheoven.
Tocleantheinsideoftheoven,neverusecorrosiveproductsand
donotscrapethewallswithsharpobjectsorblades.
Onlyusenon-abrasiveliquiddetergents.Donotattempttopush
forks, knives or sharp objects into the openings on the right
hand side and the rear of the oven.
Removethecrumbtraybypullingitoutwards.Incaseofdi-
culty,wettheoutsidepartsofthetray.Removeanydirtwitha
dampcloth.Drythoroughlyandthenputthetraybackinplace.

13
COOKING TABLE
food
EO 4035 EO 4055
function selector knob
thermostat knob
timer knob
wire rack / bake pan
position
function selector knob
thermostat knob
timer knob
wire rack / bake pan
position
savoury pie 200° 40-45 3 200° 35-40 3
freshpizza 200° 30-35 3 200° 30-35 3
frozenpizza 200° 15-20 3 200° 15-20 3
cannelloni 200° 55-60 4 200° 55-60 4
lasagne 200° 55-60 4 200° 55-60 4
wholechicken 230° 120 -230° 120 -
roastpork 230° 100 -230° 100 -
kebabs 200° 35-40 3 200° 35-40 3
bakedsh 180° 35-40 3 180° 35-40 3
frozen potatoes 200° 50-55 3 200° 45-50 3
fresh potatoes 200° 55-60 3 200° 50-55 3
jamtart 200° 40-45 3 200° 35-40 3
Neapolitanpastry 200° 55-60 3 200° 55-60 3
spongecake 200° 25-30 3 200° 20-25 3
Thecookingtimesinthetablearemerelyindicativeanddependontheweight,theinitialtemperatureofthefoodandtheconsistency
and structure.
