Dürkopp Adler D887 e-con User manual

Operating Instructions
D887 e-con

All rights reserved.
Property of the corporation Dürkopp Adler GmbH and protected by
copyright. Any reuse of these contents, including extracts, is prohibited
without the prior written approval of Dürkopp Adler GmbH.
Copyright © Dürkopp Adler GmbH 2023
IMPORTANT
READ CAREFULLY BEFORE USE KEEP
FOR FUTURE REFERENCE

Table of Contents
Operating Instructions D887 e-con - 00.0 - 11/2023 1
1 About these instructions .................................................................... 5
1.1 For whom are these instructions intended? ..........................................5
1.2 Representation conventions – symbols and characters........................6
1.3 Other documents...................................................................................7
1.4 Liability ..................................................................................................8
2 Safety.................................................................................................... 9
2.1 Basic safety instructions........................................................................ 9
2.2 Signal words and symbols used in warnings.......................................10
3 Machine description.......................................................................... 15
3.1 Components of the machine ............................................................... 15
3.2 Proper use...........................................................................................16
3.3 Declaration of Conformity....................................................................17
4 Operation ........................................................................................... 19
4.1 Preparing the machine for operation ...................................................19
4.2 Switching on and off the machine .......................................................20
4.3 Switching on and off the sewing light ..................................................21
4.4 Inserting or changing the needle .........................................................22
4.4.1 For one-needle machines.................................................................... 22
4.4.2 For two-needle machines .................................................................... 24
4.5 Threading the needle thread ...............................................................25
4.5.1 For one-needle machines.................................................................... 26
4.5.2 For two-needle machines .................................................................... 29
4.6 Winding the hook thread .....................................................................35
4.7 Changing the bobbin ........................................................................... 38
4.8 Thread tension ....................................................................................40
4.8.1 Adjusting the needle thread tension ....................................................40
4.8.2 Adjusting the hook thread tension .......................................................41
4.9 Adjusting the needle thread regulator .................................................42
4.9.1 For one-needle machines.................................................................... 42
4.9.2 For two-needle machines .................................................................... 43
4.10 Lifting the sewing foot..........................................................................44
4.11 Sewing backwards with the stitch regulator (optional) ........................ 47
4.12 Quick functions on the push buttons ...................................................47
4.12.1 Activating function keys.......................................................................48
4.12.2 Assigning a function to the favorite buttons......................................... 51
4.13 Sewing.................................................................................................52
4.14 Controlling the trimmer ........................................................................ 54
4.14.1 Switching the trimmer on and off.........................................................54
4.14.2 Adjusting the material guide ................................................................ 55

Table of Contents
2 Operating Instructions D887 e-con - 00.0 - 11/2023
5 Programming Commander DELTA .................................................. 57
5.1 Control panel Commander Delta......................................................... 57
5.2 Navigating the Commander DELTA control panel ..............................58
5.2.1 Symbols and buttons ........................................................................... 59
5.2.2 Entering values....................................................................................60
5.2.3 Navigating the burger menu ................................................................61
5.2.4 Navigation during the start of the control panel ................................... 61
5.2.5 User login ............................................................................................63
5.2.6 Login with USB key .............................................................................65
5.2.7 Login with file on USB key................................................................... 67
5.3 User Configuration ..............................................................................68
5.3.1 Setting the language ...........................................................................71
5.3.2 Adjusting the brightness ......................................................................72
5.3.3 Setting the volume...............................................................................72
5.3.4 User Management administration ....................................................... 73
5.3.5 Machine head light brightness.............................................................73
5.3.6 Sewing light brightness (integrated LED sewing light) ........................74
5.3.7 Setting the smart keys configuration ...................................................74
5.3.8 Desk height adjustment.......................................................................76
5.3.9 Setting the screen configuration.......................................................... 80
5.4 User Management ............................................................................... 80
5.4.1 Authorizations as Default Technician ...................................................................... 80
5.4.2 Authorizations as Default Technician ...................................................................... 83
5.5 Information ..........................................................................................91
5.6 Software operating modes ..................................................................92
5.7 Using Manual mode ............................................................................ 93
5.7.1 Setting up the user interface ...............................................................94
5.7.2 Setting the parameters........................................................................ 98
5.7.3 Setting cross-segment parameters .......................................................................101
5.7.4 Setting the Seam Begin parameters .................................................... 116
5.7.5 Setting the Segment parameters ........................................................ 119
5.7.6 Setting the Seam End parameters.......................................................120
5.7.7 Using bobbin wind mode ...................................................................123
5.8 Using Automatic mode ......................................................................124
5.8.1 Sewing in Automatic mode................................................................125
5.8.2 Canceling a program in Automatic mode .......................................... 127
5.9 Using Programming mode.................................................................127
5.9.1 Managing programs .......................................................................... 129
5.9.2 Managing seams ...............................................................................132
5.9.3 Editing the segments of a seam........................................................133

Table of Contents
Operating Instructions D887 e-con - 00.0 - 11/2023 3
5.9.4 Managing segments .......................................................................... 134
5.9.5 Setting program parameters..............................................................134
5.9.6 Setting the Seam Begin/Segment Begin parameters ............................. 150
5.9.7 Setting the Segment parameters ........................................................ 153
5.9.8 Setting the Segment End/Seam End parameters................................... 159
5.10 Importing/exporting programs ........................................................... 162
5.11 Performing a software update ...........................................................163
6 Maintenance..................................................................................... 165
6.1 Cleaning ............................................................................................ 166
6.2 Lubricating.........................................................................................168
6.2.1 Lubricating the machine head ...........................................................169
6.2.2 Lubricating the hook ..........................................................................170
6.3 Servicing the pneumatic system........................................................ 171
6.3.1 Adjusting the operating pressure.......................................................171
6.3.2 Draining the water-oil mixture............................................................172
6.3.3 Cleaning the filter element................................................................. 174
6.4 Parts list.............................................................................................175
7 Setup ................................................................................................ 177
7.1 Checking the scope of delivery .........................................................177
7.2 Removing the transport locks............................................................177
7.3 Assembling the stand ........................................................................178
7.4 Assembling the pedal and setpoint device ........................................179
7.5 Tabletop ............................................................................................180
7.5.1 Completing the tabletop ....................................................................180
7.5.2 Assembling the tabletop to the stand ................................................181
7.6 To adjust the working height: ............................................................182
7.7 Assembling the control ......................................................................183
7.8 Inserting the machine head ...............................................................184
7.9 Bringing the machine head to a vertical position ............................... 188
7.9.1 Possible errors while assembling the locking mechanism................. 189
7.10 Assembling the tilt sensor .................................................................190
7.11 Changing the handwheel................................................................... 191
7.12 Assembling the knee button ..............................................................193
7.13 Assembling the oil extraction line ......................................................194
7.14 Assembling the LED sewing light ......................................................195
7.15 Electrical connection ......................................................................... 199
7.15.1 Establishing equipotential bonding.................................................... 199
7.15.2 Connecting the control ...................................................................... 201
7.15.3 Connecting the sewing light transformer ........................................... 202
7.16 Pneumatic connection (optional) ....................................................... 202
7.16.1 Assembling the compressed air maintenance unit ............................204
7.16.2 Adjusting the operating pressure.......................................................205
7.17 Checking the lubrication ....................................................................206

Table of Contents
4 Operating Instructions D887 e-con - 00.0 - 11/2023
7.18 Performing a test run.........................................................................206
8 Decommissioning ........................................................................... 207
9 Disposal ........................................................................................... 209
10 Troubleshooting .............................................................................. 211
10.1 Customer Service .............................................................................. 211
10.2 Messages of the software .................................................................211
10.3 Errors in sewing process ...................................................................240
11 Technical data ................................................................................. 243
11.1 Data and characteristic values ..........................................................244
11.2 Requirements for fault-free operation................................................ 245
12 Appendix .......................................................................................... 247
12.1 Wiring diagram .................................................................................. 247
12.2 Tabletop drawings ............................................................................. 262

About these instructions
Operating Instructions D887 e-con - 00.0 - 11/2023 5
1 About these instructions
These instructions have been prepared with utmost care. They
contain information and notes intended to ensure long-term and
reliable operation.
Should you notice any discrepancies or if you have improvement
requests, then we would be glad to receive your feedback through
Customer Service (p. 211).
Consider the instructions as part of the product and store them in
a place where they are readily available.
1.1 For whom are these instructions intended?
These instructions are intended for:
• Operators:
This group is familiar with the machine and has access to
the instructions. Specifically, chapter Operation (p. 19)
is important for the operators.
• Specialists:
This group has the appropriate technical training for
performing maintenance or repairing malfunctions.
Specifically, the chapter Setup (p. 177) is important
for specialists.
Service Instructions are supplied separately.
With regard to minimum qualification and other requirements to be
met by personnel, please also follow the chapter Safety (p. 9).

About these instructions
6 Operating Instructions D887 e-con - 00.0 - 11/2023
1.2 Representation conventions – symbols and
characters
Various information in these instructions are represented or high-
lighted by the following characters in order to facilitate easy and
quick understanding:
Proper setting
Specifies proper setting.
Disturbances
Specifies the disturbances that can occur from an incorrect setting.
Cover
Specifies which covers must be disassembled in order to access
the components to be set.
Steps to be performed when operating the machine (sewing
and equipping)
Steps to be performed for service, maintenance, and
installation
Steps to be performed via the software control panel
The individual steps are numbered:
First step
Second step
The steps must always be followed in the specified order.
Lists are marked by bullet points.
Result of performing an operation
Change to the machine or on the display/control panel.
Important
Special attention must be paid to this point when performing a step.
1.
2.
...
•


About these instructions
Operating Instructions D887 e-con - 00.0 - 11/2023 7
Information
Additional information, e.g. on alternative operating options.
Order
Specifies the work to be performed before or after an adjustment.
References
 Reference to another section in these instructions.
Safety Important warnings for the user of the machine are specifically
marked. Since safety is of particular importance, hazard symbols,
levels of danger and their signal words are described separately
in the chapter Safety (p. 9).
Location
information
If no other clear location information is used in a figure, indications
of right or left are always from the user's point of view.
1.3 Other documents
The machine includes components from other manufacturers.
Each manufacturer has performed a hazard assessment for these
purchased parts and confirmed their design compliance with appli-
cable European and national regulations. The proper use of the built-
in components is described in the corresponding manufacturer's
instructions.

About these instructions
8 Operating Instructions D887 e-con - 00.0 - 11/2023
1.4 Liability
All information and notes in these instructions have been compiled
in accordance with the latest technology and the applicable stan-
dards and regulations.
Dürkopp Adler cannot be held liable for any damage resulting
from:
• Breakage and transport damages,
• Failure to observe these instructions,
• Improper use,
• Unauthorized modifications to the machine,
• Use of untrained personnel,
• Use of unapproved spare parts.
Transport
Dürkopp Adler cannot be held liable for breakage and transport
damages. Inspect the delivery immediately upon receiving it.
Report any damage to the last transport manager. This also
applies if the packaging is not damaged.
Leave machines, equipment and packaging material in the con-
dition in which they were found when the damage was discovered.
This will ensure any claims against the transport company.
Report all other complaints to Dürkopp Adler immediately after
receiving the product.

Safety
Operating Instructions D887 e-con - 00.0 - 11/2023 9
2 Safety
This chapter contains basic information for your safety. Read the
instructions carefully before setting up or operating the machine.
Be sure to follow the information in the safety instructions.
Failure to do so can result in serious injury and property damage.
2.1 Basic safety instructions
The machine may only be used as described in these instructions.
The instructions should be available at the machine's location at
all times.
Work on live components and equipment is prohibited. Exceptions
are defined in the DIN VDE 0105.
For the following work, the machine must be disconnected from
the power supply using the main switch or by disconnecting
the power plug:
• Replacing the needle or other sewing tools
• Leaving the workstation
• Performing maintenance work and repairs
• Threading the needle thread
Missing or faulty parts could impair safety and damage the ma-
chine. Only use original parts from the manufacturer.
Transport Use a lifting carriage or stacker to transport the machine. Raise the
machine max. 20 mm and secure it to prevent it from slipping off.
Setup The connecting cable must have a power plug approved in
the relevant country. The power plug may only be assembled
to the power cable by qualified specialists.
Obligations
of the operator
Follow the country-specific safety and accident prevention regu-
lations and the legal regulations concerning industrial safety and
the protection of the environment.

Safety
10 Operating Instructions D887 e-con - 00.0 - 11/2023
All the warnings and safety signs on the machine must always be
in legible condition. Do not remove!
Missing or damaged warnings and safety signs must be replaced
immediately.
Requirements
to be met by
the personnel
Only qualified specialists may be used for:
• Setting up the machine
• Performing maintenance work and repairs
• Performing work on electrical equipment
Only authorized persons may work on the machine and must first
have understood these instructions.
Operation Inspect the machine for any externally visible damage during use.
Stop working if you notice any changes to the machine. Report
any changes to your supervisor. Do not use a damaged machine
any further.
Safety
equipment
Safety equipment should not be disassembled or deactivated. If it
is essential to disassemble or deactivate safety equipment for a
repair operation, it must be assembled and put back into operation
immediately afterward.
2.2 Signal words and symbols used in warnings
Warnings in the text are distinguished by color bars. The color
scheme is based on the severity of the danger. Signal words
indicate the severity of the danger.
Signal words Signal words and the hazard they describe:
Signal word Meaning
DANGER (with hazard symbol)
If ignored, fatal or serious injury will result
WARNING (with hazard symbol)
If ignored, fatal or serious injury can result

Safety
Operating Instructions D887 e-con - 00.0 - 11/2023 11
Symbols The following symbols indicate the type of danger to personnel:
CAUTION (with hazard symbol)
If ignored, moderate or minor injury can result
CAUTION (with hazard symbol)
If ignored, environmental damage can result
NOTICE (without hazard symbol)
If ignored, property damage can result
Icon Type of danger
General
Electric shock
Puncture
Crushing
Environmental damage

Safety
12 Operating Instructions D887 e-con - 00.0 - 11/2023
Examples Examples of the layout of warnings in the text:
This is what a warning looks like for a hazard that will result
in serious injury or even death if ignored.
This is what a warning looks like for a hazard that could
result in serious or even fatal injury if ignored.
This is what a warning looks like for a hazard that could
result in moderate or minor injury if the warning is ignored.
DANGER
Type and source of danger!
Consequences of non-compliance.
Measures for avoiding the danger.
WARNING
Type and source of danger!
Consequences of non-compliance.
Measures for avoiding the danger.
CAUTION
Type and source of danger!
Consequences of non-compliance.
Measures for avoiding the danger.

Safety
Operating Instructions D887 e-con - 00.0 - 11/2023 13
This is what a warning looks like for a hazard that could
result in property damage if ignored.
This is what a warning looks like for a hazard that could
result in environmental damage if
NOTICE
Type and source of danger!
Consequences of non-compliance.
Measures for avoiding the danger.
CAUTION
Type and source of danger!
Consequences of non-compliance.
Measures for avoiding the danger.

Safety
14 Operating Instructions D887 e-con - 00.0 - 11/2023

Machine description
Operating Instructions D887 e-con - 00.0 - 11/2023 15
3 Machine description
3.1 Components of the machine
Fig. 1: Components of the machine
(1) - Motor-driven thread tension
(2) - Favorite buttons
(3) - Electronic jog dial
(4) - Push buttons
(5) - Service Stop button
(6) - Electronic stitch regulator
(optional)
(7) - Oil level indicator
(8) - Control panel Commander Delta
① ⑦⑧
③⑥②⑤④

Machine description
16 Operating Instructions D887 e-con - 00.0 - 11/2023
3.2 Proper use
The machine may only be used with sewing material that satisfies
the requirements of the specific application at hand.
The machine is intended only for use with dry sewing material.
The sewing material must not contain any hard objects.
The needle thicknesses permissible for the machine are listed in
the Technical data (p. 243) chapter.
The seam must be completed with a thread that satisfies the
requirements of the specific application at hand.
The machine is intended for industrial use.
The machine may only be set up and operated in dry conditions on
well-maintained premises. If the machine is operated on premises
that are not dry and well-maintained, then further measures may
be required which must be compatible with DIN EN 60204-31.
Only authorized persons may work on the machine.
Dürkopp Adler cannot be held liable for damages resulting from
improper use.
WARNING
Risk of injury from live, moving and cutting parts
as well as from sharp parts!
Improper use can result in electric shock,
crushing, cutting and punctures.
Follow all instructions provided.
NOTICE
Non-observance will lead to property damage!
Improper use can result in material damage at the machine.
Follow all instructions provided.

Machine description
Operating Instructions D887 e-con - 00.0 - 11/2023 17
3.3 Declaration of Conformity
The machine complies with European regulations ensuring health,
safety, and environmental protection as specified in the declara-
tion of conformity or in the declaration of incorporation.

Machine description
18 Operating Instructions D887 e-con - 00.0 - 11/2023
