Dürkopp Adler M-TYPE H867 User manual

H867
Service manual

All rights reserved.
Property of Dürkopp Adler AG and protected by copyright. Any reuse of these contents,
including extracts, is prohibited without the written approval of Dürkopp Adler AG in advance.
Copyright © Dürkopp Adler AG - 2013
www.promelectroavtomat.ru

Table of contents
Service manual H867 Version 00.0 - 08/2013 1
1 General information ............................................................................................ 3
1.1 Scope of application of the manual....................................................................... 3
1.2 Declaration of conformity....................................................................................... 3
1.3 Applicable documentation..................................................................................... 3
1.4 Damage during transport....................................................................................... 3
1.5 Limitation of liability............................................................................................... 3
2 Safety instructions.............................................................................................. 4
2.1 General safety instructions.................................................................................... 4
2.2 Layout of safety instructions.................................................................................. 5
3 Environmental protection information.............................................................. 7
3.1 General information on environmental protection ................................................. 7
3.2 Layout of environmental protection information .................................................... 7
4 Working basis...................................................................................................... 8
4.1 Symbols in the text................................................................................................ 8
4.2 Sequence of the settings....................................................................................... 9
4.3 Cable routing......................................................................................................... 9
4.4 Removing the covers........................................................................................... 10
4.4.1 Access to the machine bottom section................................................................ 10
4.4.2 Removing and fitting the arm cover..................................................................... 11
4.4.3 Removing and fitting the head cover................................................................... 11
4.4.4 Removing and fitting the valve cover .................................................................. 12
4.4.5 Opening and closing the throat plate slide.......................................................... 13
4.4.6 Removing and inserting the throat plate.............................................................. 14
4.4.7 Removing and inserting the feed-dog ................................................................. 15
4.5 Surfaces on shafts............................................................................................... 16
4.6 Locking the sewing machine in place.................................................................. 16
4.7 Putting the handwheel into position..................................................................... 17
5 Setting the handwheel scale ............................................................................ 18
6 Positioning the arm shaft crank....................................................................... 19
7 Positioning the toothed belt wheels................................................................ 20
7.1 Upper toothed belt wheel .................................................................................... 21
7.2 Lower toothed belt wheel .................................................................................... 22
8 Setting the stitch length adjusting wheels ..................................................... 24
8.1 Setting the upper stitch length adjusting wheel................................................... 25
8.2 Setting the lower stitch length adjusting wheel.................................................... 27
8.3 Stitch length limit................................................................................................. 28
8.4 Setting the eccentric for the forward and backward stitches............................... 30
9 Setting the feed-dog.......................................................................................... 31
9.1 Setting the feed-dog position............................................................................... 31
9.1.1 Moving the feed-dog............................................................................................ 32
9.1.2 Moving the feed-dog carrier ................................................................................ 33
9.1.3 Aligning the feed-dog carrier together with the stitch regulator gear................... 34
9.2 Setting the feed-dog movement.......................................................................... 37
9.2.1 Setting the feed movement ................................................................................. 37
9.2.2 Setting the feed-dog height in the top dead center ............................................. 38
9.2.3 Setting the stroke movement............................................................................... 39
9.2.4 Setting the compensating weight ........................................................................ 40

Table of contents
2Service manual H867 Version 00.0 - 08/2013
10 Aligning the needle bar linkage ....................................................................... 41
10.1 Moving the needle bar linkage sideways............................................................. 41
10.2 Aligning the needle bar linkage in the sewing direction....................................... 43
11 Position of the hook and needle...................................................................... 45
11.1 Setting the hook side clearance.......................................................................... 45
11.2 Setting the loop stroke position........................................................................... 47
11.3 Adjusting the needle guard.................................................................................. 49
11.4 Setting the needle bar height .............................................................................. 51
12 Setting the spool housing lifter ....................................................................... 53
12.1 Setting the lifting gap........................................................................................... 54
12.2 Setting the point in time of opening..................................................................... 55
13 Sewing feet ........................................................................................................ 56
13.1 Setting an even sewing foot stroke ..................................................................... 57
13.2 Setting the stroke movement for the feeding foot................................................ 58
13.3 Setting the sewing foot pressure......................................................................... 60
13.4 Setting the sewing foot lifting height.................................................................... 61
14 Adjusting the needle thread tension ............................................................... 62
14.1 Setting the thread regulator................................................................................. 62
14.2 Setting the thread tensioning spring.................................................................... 63
15 Winder ................................................................................................................ 65
15.1 Position of the winder wheel in long arm machines ............................................ 65
15.2 Setting the winder................................................................................................ 66
15.3 Setting the hook thread guide ............................................................................. 69
16 Thread cutter ..................................................................................................... 70
16.1 Setting the position of the thread-pulling knife .................................................... 70
16.1.1 Setting the height of the thread-pulling knife....................................................... 70
16.2 Setting the cutoff curve........................................................................................ 71
16.3 Setting the cutting pressure................................................................................. 73
16.4 Setting the point in time for cutting...................................................................... 74
17 Setting the potentiometer................................................................................. 76
18 Setting the safety snap-on coupling ............................................................... 78
18.1 Attaching the safety snap-on coupling ................................................................ 78
18.2 Setting the torque................................................................................................ 79
19 Lubrication......................................................................................................... 80
19.1 Lubrication of the upper part of the machine....................................................... 81
19.2 Hook lubrication................................................................................................... 82
20 Maintenance work ............................................................................................. 83
20.1 Pneumatic system............................................................................................... 83
20.1.1 Setting the operating pressure:........................................................................... 83
20.1.2 Draining the water condensation......................................................................... 84
20.1.3 Cleaning the filter element................................................................................... 85
20.2 Cleaning work...................................................................................................... 86
20.2.1 Cleaning the machine.......................................................................................... 86
20.2.2 Cleaning the motor fan sieve............................................................................... 87
20.3 Checking the toothed belt.................................................................................... 88

General information
Service manual H867 Version 00.0 - 08/2013 3
1 General information
1.1 Scope of application of the manual
This manual describes the setting and maintenance work on the H867
flatbed machine. It applies to all submodels.
The intended use and set-up is described in the operating manual.
1.2 Declaration of conformity
The machine complies with the European regulations specified in the dec-
laration of conformity or in the installation declaration.
1.3 Applicable documentation
The device contains built-in components of other manufacturers,
e.g. drive motors. The corresponding manufacturers have performed a
hazard assessment for these purchased parts and confirmed compliance
of the design with the European and national specifications. The intended
use of the built-in components is described in the corresponding manuals
of the manufacturers.
1.4 Damage during transport
Dürkopp Adler cannot be held liable for any damage during transport.
Check the delivered product immediately after receiving it. Report any
damage to the last transport manager. This also applies if the packaging
is not damaged.
Keep the machines, devices, and packaging material in the condition they
were at the time the damage was identified. That secures any claims
towards the transport company.
Report all other complaints to Dürkopp Adler immediately after receiving
the product.
1.5 Limitation of liability
All information and notes in this operating manual have been compiled in
accordance with the latest technology and the applicable standards and
regulations.
The manufacturer accepts no liability for any damage due to:
• Failure to observe the instructions in the manual
• Improper use
• Unauthorized modifications to the machine
• The deployment of untrained personnel
• Damage during transport
• Using spare parts not approved

Safety instructions
4Service manual H867 Version 00.0 - 08/2013
2 Safety instructions
This section contains basic instructions for your safety. Read the instruc-
tions carefully before setting up, programming, maintaining, or operating
the machine.
Make sure to follow the information included in the safety instructions.
Failure to do this can result in serious injury and damage to the machine.
2.1 General safety instructions
Only authorized persons may use the machine. Every person who works
with the machine must have read the operating manual first.
The machine may only be used as described in this manual.
The operating manual must be available at the machine's location at all
times.
Observe the generally applicable safety and accident prevention regula-
tions and the legal regulations concerning industrial safety and the protec-
tion of the environment.
Observe the safety instructions and the operating manual of the drive
motor's manufacturer.
All warnings on the machine must always be in legible condition and may
not be removed. Missing or damaged labels must be replaced immedi-
ately.
In the following situations, the machine must be disconnected from the
power supply using the main switch or by disconnecting the power plug:
• Threading
• Replacing the needle or other sewing tools
• Leaving the workplace
• Performing maintenance work and repairs
Inspect the machine while in use for any externally visible damage. Inter-
rupt your work if you notice any changes to the machine. Report any
changes to your supervisor. A damaged machine may not be used any
more.
Machines or machine parts that have reached the end of their service life
must not continue to be used. They have to be disposed of correctly and
in accordance with the applicable statutory provisions.
Only qualified specialists may set up the machine.
Only qualified specialists may perform maintenance work and repairs.
Safety equipment may not be removed or put out of service. If this cannot
be avoided for a repair operation, the safety equipment must be refitted
and put back into service immediately afterwards.

Safety instructions
Service manual H867 Version 00.0 - 08/2013 5
Only qualified electrical specialists may perform work on electrical equip-
ment.
The connecting cable must have a power plug approved in the specific
country. The power plug may only be connected to the power cable by a
qualified specialist.
Work on live components and equipment is prohibited.
Exceptions are defined in the specifications in DIN VDE 0105.
Only use original spare parts from the manufacturer. Missing or faulty
spare parts could impair safety and damage the machine.
2.2 Layout of safety instructions
The safety instruction text is surrounded by colored bars.
Signal words specify the severity of a danger:
•Danger: Death or serious injury will occur.
•Warning: Death or serious injury is possible.
•Caution: Moderate to minor injuries are possible.
•Attention:Material damage is possible.
In the case of dangers to personnel, the following symbols indicate the
type of hazard:
General danger
Danger due to sharp objects
Danger due to electric shock
Danger due to crushing

Safety instructions
6Service manual H867 Version 00.0 - 08/2013
Examples of the layout of the safety instructions in the text:
Type and source of the danger
Consequences in the event of noncompliance
Measures for avoiding the danger
Thisiswhatahazardnote lookslikefora hazardthatwillresult
in serious injury or even death if not complied with.
DANGER
Type and source of the danger
Consequences in the event of noncompliance
Measures for avoiding the danger
This is what a hazard note looks like for a hazard that could
result in serious injury or even death if not complied with.
WARNING
Type and source of the danger
Consequences in the event of noncompliance
Measures for avoiding the danger
This is what a hazard note looks like for a hazard that could
result in moderate or minor injury if not complied with.
CAUTION
Type and source of the danger
Consequences in the event of noncompliance
Measures for avoiding the danger
This is what a hazard note looks like for a hazard that could result in
material damage if not complied with.
ATTENTION

Environmental protection information
Service manual H867 Version 00.0 - 08/2013 7
3 Environmental protection information
3.1 General information on environmental protection
Machines or machine parts that have reached the end of their service life
must be disposed of correctly and in compliance with the legal require-
ments concerning environmental protection.
Use consumables sparingly and dispose of them correctly and in compli-
ance with the legal requirements concerning environmental protection.
3.2 Layout of environmental protection information
The environmental protection text is surrounded by green bars.
The following symbol indicates the type of environmental protection mea-
sure:
Example of the layout of environmental protection information in
text form
Reference to correct disposal
Type and source of the danger
Consequences in the event of noncompliance
Measures for avoiding the danger
This is what environmental protection information on correct
disposal looks like and could lead to environmental damage if
not complied with.
ENVIRONMENTAL PROTECTION

Working basis
8Service manual H867 Version 00.0 - 08/2013
4 Working basis
4.1 Symbols in the text
The following symbols at the side and in the text show which type of infor-
mation the text contains.
Correct setting
Specifies the correct setting.
Faults
Specifies the faults that can occur due to an incorrect setting.
Cover
Specifies which covers have to be removed in order to access the compo-
nents going to be set.
Steps to be performed for servicing, maintenance, and installation
Steps to be performed via the software control panel
The individual steps are numbered:
1. First setting step
2. Second setting step
3. Third setting step, etc.
The sequence of setting steps must always be followed.
Result of performing an operation
If the machine is changed in one particular setting step or a new notifica-
tion text appears in the display which is considered as important feedback
for you, then this change will be identified by an arrow: 
Specifiessetting stepsforthesoftware viathecontrolpanel. Thestepsare
numbered. The sequence of setting steps must always be followed.
Important
Specifies what you have to be particularly careful about during the work
step.
Information
Provides additional information.
Sequence
Specifies the work to be performed before or after a setting.
Reference
 A reference is provided to another place in the text.
1.
2.
3.
...


Working basis
Service manual H867 Version 00.0 - 08/2013 9
4.2 Sequence of the settings
Observe the
sequence! The setting positions for the sewing machine are interdependent.
Always adhere to the specified sequence for the individual setting steps.
Always observe all information on requirements and following settings
marked at the side with .
4.3 Cable routing
Tying the cable
together Ensure that all cables in the machine are laid such that moving parts are
not impaired in their ability to function correctly.
1. Lay any excess cabling neatly in proper cable snakes.
2. Tie the snakes together using a cable tie.
If possible, bind the snakes to fixed parts.
The cables must be fixed firmly in place.
3. Cut off any protruding part of the cable tie.
Machine damage due to incorrect sequence
Always adhere to the working sequence specified in this man-
ual.
ATTENTION
Machine damage and malfunctions can be caused by laying the
cables incorrectly.
Excess cabling may obstruct moving machine parts in their ability to
function correctly. This will affect the sewing function and may cause
damage.
Lay excess cabling as described above.
ATTENTION

Working basis
10 Service manual H867 Version 00.0 - 08/2013
4.4 Removing the covers
Inmany types of settingwork, you willhave to remove themachine covers
first in order to access the components.
Described here is how to remove the individual covers and how to refit
them. Just the cover that needs to be removed is then specified in the text
for that particular type of setting work.
4.4.1 Access to the machine bottom section
In order to access the components at the machine bottom section, you
must first tilt the machine upper section backwards.
Figure 1: Tilt the machine upper section backwards and erect it again
Tilting the machine upper section backwards
1. Tilt the machine upper section backwards as far as it will go.
Erecting the machine upper section
1. Erect the machine upper section again.
Risk of injury
Crushing injuries from moving parts
Switch the sewing machine off before you remove the cov-
ers or refit them.
WARNING

Working basis
Service manual H867 Version 00.0 - 08/2013 11
4.4.2 Removing and fitting the arm cover
Figure 2: Removing and fitting the arm cover
Removing the arm cover
1. Position the left adjusting wheel for the sewing foot stroke (2) to 2.
Important: You can only remove the arm cover when the adjusting
wheel is positioned at 2.
2. Loosen the arm cover screws (1).
3. Hold the arm cover (3) at the adjusting wheels and remove it.
Fitting the arm cover
1. Fit the arm cover (3).
2. Screw the arm cover screws (1) firmly in place.
4.4.3 Removing and fitting the head cover
Figure 3: Removing and fitting the head cover
Removing the head cover
1. Loosen the head cover screws (1).
2. Remove the head cover (2).
1
2
3
3
(1) - Arm cover screws
(2) - Left adjusting wheel for the sewing foot stroke (3) - Arm cover
1
2
2
(1) - Head cover screws (2) - Head cover

Working basis
12 Service manual H867 Version 00.0 - 08/2013
Fitting the head cover
1. Fit the head cover (2).
2. Screw the head cover screws (1) firmly in place.
4.4.4 Removing and fitting the valve cover
Figure 4: Removing and fitting the valve cover
Removing the valve cover
1. Loosen all four valve cover screws (1).
2. Remove the valve cover (2).
Important: When removing the valve cover, be sure not to pull off any
cables.
Fitting the valve cover
1. Fit the valve cover (2).
2. Screw all four valve cover screws (1) firmly in place.
Important: When fitting the valve cover, be sure not to trap any cables.
22
11
1
1
(1) - Valve cover screws (2) - Valve cover

Working basis
Service manual H867 Version 00.0 - 08/2013 13
4.4.5 Opening and closing the throat plate slide
Figure 5: Opening and closing the throat plate slide
Opening the throat plate slide
1. Press the clamping spring (3) downwards.
2. Push the throat plate slide (1) apart.
Pushing the throat plate slide back into place
1. Push the throat plate slide (1) back to its initial position.
13
22
11
(1) - Throat plate slide
(2) - Throat plate (3) - Clamping spring

Working basis
14 Service manual H867 Version 00.0 - 08/2013
4.4.6 Removing and inserting the throat plate
Figure 6: Removing and inserting the throat plate
Removing the throat plate
1. Open the throat plate slide.
(Section 4.4.5 Opening and closing the throat plate slide, page 13)
2. Loosen the throat plate screws (2).
3. Remove the throat plate (1).
Inserting the throat plate
1. Fit the throat plate (1).
2. Screw the throat plate screws (2) firmly in place.
3. Push the throat plate slide back into place.
(Section 4.4.5 Opening and closing the throat plate slide, page 13)
Risk of injury
Switch the sewing machine off before you remove or insert the
throat plate.
WARNING
2
1
(1) - Throat plate (2) - Throat plate screws

Working basis
Service manual H867 Version 00.0 - 08/2013 15
4.4.7 Removing and inserting the feed-dog
Figure 7: Removing and inserting the feed-dog
Removing the feed-dog
1. Remove the throat plate.
(Section 4.4.6 Removing and inserting the throat plate, page 14)
2. Loosen the feed-dog screws (3).
3. Take the feed-dog (1) off the feed-dog carrier (2).
Inserting the feed-dog
1. Place the feed-dog (1) onto the feed-dog carrier (2).
2. Screw the feed-dog screws (3) firmly in place.
3. Insert the throat plate.
(Section 4.4.6 Removing and inserting the throat plate, page 14)
Important: Check the feed-dog position in its movement by turning the
handwheel. The feed-dog must not hit against the throat
plate.
Risk of injury
Switch the sewing machine off before you remove or insert the
feed-dog.
WARNING
2
3
1
(1) - Feed-dog
(2) - Feed-dog carrier (3) - Feed-dog screws

Working basis
16 Service manual H867 Version 00.0 - 08/2013
4.5 Surfaces on shafts
Screwing
components
onto the surface
Figure 8: Surfaces on shafts
Some shafts have flat surfaces at those points where the components are
screwed on. This strengthens the connection and setting work is made
easier.
Important: Always make sure that the whole screw is seated com-
pletely on the surface.
4.6 Locking the sewing machine in place
With some settings, the machine has to be locked in place. To do this, the
locking peg from the accessory pack is inserted into a groove on the arm
shaft crank to block the arm shaft.
Figure 9: Locking peg and arresting grooves on the arm shaft crank
There are two securing positions:
•Position 1: Loop stroke position
• 5 mm end in the large groove
• Setting the loop stroke and needle bar height
•Position 2: Handwheel zero position
• 3 mm end in the small groove
• Setting the handwheel position and checking the top dead center for
the needle bar
2
1
(1) - Surface (2) - Shaft
1
2
4
3
(1) - Locking peg
(2) - Large arresting groove (3) - Small arresting groove (4) - Arm shaft crank

Working basis
Service manual H867 Version 00.0 - 08/2013 17
Figure 10: Locking the sewing machine in place
Locking the machine in place
1. Remove the plug (2) from the locking opening (1).
2. Turn the handwheel until the appropriate groove (3) is in front of the
locking opening (2):
• Small groove at handwheel position 0°
• Large groove at handwheel position 200 – 205°
3. Insert the locking peg (3) with the appropriate end into the groove (4).
Removing the locking mechanism
1. Pull the locking peg (3) out of the groove (4).
2. Insert the plug (2) into the locking opening (1).
4.7 Putting the handwheel into position
With some settings, the graduated scale on the handwheel has to be put
into a certain position.
Figure 11: Putting the handwheel into position
Setting steps
1. Turn the handwheel until the specified number on the graduated
scale (1) is next to the pointer (2).
1
2
4
3
(1) - Locking opening
(2) - Plug (3) - Locking peg (4) - Groove
2
1
(1) - Graduated scale (2) - Pointer

Setting the handwheel scale
18 Service manual H867 Version 00.0 - 08/2013
5 Setting the handwheel scale
Checking the correct setting
Lock the machine in place in the handwheel zero position (page 16):
The handwheel is at position 0°.
If a different degree number is next to the pointer (2) in the handwheel
zero position (page 16), then you will have to reset the graduated
scale. Otherwise you will not be able to work with the handwheel positions
you need for specific settings.
Figure 12: Setting the handwheel scale
Setting steps
The handwheel is fastened using two screws, which you can see through
the screw opening (1).
1. Turn the handwheel such that one screw is under the opening (1).
2. Loosen the screw using a 3 mm hex key through the opening (1).
3. Turnthehandwheelsuchthatthesecondscrewisundertheopening (1).
4. Loosen the screw using a 3 mm hex key through the opening (1).
5. Lock the machine in place in the handwheel zero position (page 16).
6. Turn the handwheel scale such that the 0° marking is exactly in the
center of the pointer (2).
7. Firmly tighten the screw using a 3 mm hex key through the opening (1).
8. Remove the locking mechanism (page 17).
9. Put the handwheel into the 50° position.
10.Firmly tighten the second screw using a 3 mm hex key through the
opening (1).
Risk of injury
Switch the sewing machine off before you check and set the
position of the handwheel on the arm shaft.
WARNING
2
1
(1) - Screw opening (2) - Pointer
