Daewoo LM32L1 Series User manual

48586602E101-R0
All manuals and user guides at all-guides.com
all-guides.com

LCD TELEVISION
INSTRUCTION MANUAL
LM32L1/LM32L1B1M
LM32L2/LM32L2BSM
LM32L2Z/LM32L2BZM
LM32L2K/LM32L2BKM
LM32L2R/LM32L2BRM
LM37L1/LM37L1B1M
LM37L2/LM37L2BSM
LM37L2Z/LM37L2BZM
LM37L2K/LM37L2BKM
LM37L2R/LM37L2BRM
LM42L1/LM42L1B1M
LM42L2/LM42L2BSM
LM42L2Z/LM42L2BZM
LM42L2K/LM42L2BKM
LM42L2R/LM42L2BRM
All manuals and user guides at all-guides.com

Caution
2
WARNIN : TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK HAZARD, DO NOT EXPOSE
THIS APPLIANCE TO RAIN OR MOISTURE.
CAUTION : TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION : TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICIN TO QUALIFIED SERVICE PERSONNEL.
The l ghtn ng flash w th arrowhead symbol, w th n an equ lateral
tr angle, s ntended to alert the user to the presence of un nsulat-
ed “dangerous voltage” w th n the product’s enclosure that may
be of suff c ent magn tude to const tute a r sk electr c shock.
The exclamat on po nt w th n an equ lateral tr angle s ntended to
alert the user to the presence of mportant operat ng and serv c-
ng nstruct ons n the l terature accompany ng the appl ance.
All manuals and user guides at all-guides.com

Important
Safeguards
3
Please read the follow ng safeguards for your TV and reta n for future reference.
Always follow all warn ngs and nstruct ons marked on the telev s on.
1. Read, Retain and Follow All Instructions
Read all safety and operat ng nstruct ons before operat ng the TV. Reta n them safely
for future reference. Follow all operat ons and nstruct ons accord ngly.
2. Heed Warnings
Adhere to all warn ngs on the appl ance and n the operat ng nstruct ons.
3. Cleaning
Unplug the TV from the wall outlet before clean ng. Do not use l qu d, abras ve, or aerosol cleaners.
Cleaners can permanently damage the cab net and screen. Use a l ghtly dampened cloth for
clean ng.
4. Attachments and Equipment
Never add any attachment and/or equ pment w thout approval of the manufacturer as such add t ons may
result n the r sk of f re, electr c shock or other personal njury.
5. Water and Moisture
The apparatus shall not be exposed to dr pp ng or splash ng and that no objects f lled w th l qu ds,
such as vases, shall be placed on the apparatus.
6. Setting
Do not place th s TV on an unstable cart, stand or table. Plac ng the TV on an unstable base can
cause the TV to fall, result ng n ser ous personal njur es as well as damage to the TV. Use only a
cart, stand, bracket or table recommended by the manufacturer or salesperson.
7. Ventilation
Slots and open ngs n the cab net are prov ded for vent lat on and to ensure rel able operat on of the TV and to
protect t from overheat ng. Do not cover the vent lat ons open ngs n the cab net and never place the set n a conf ned
space such as bu lt- n cab net unless proper vent lat on s prov ded. Leave a m n mum 10 cm gap all around the un t.
8. Power Source
Th s TV should be operated only from the type of power source nd cated on the mark ng label. If you are not
sure of the type of power suppl ed to your home, consult your appl ance dealer or local power company.
9. rounding or Polarization
Th s TV s equ pped w th a polar zed alternat ng current l ne plug (a plug hav ng one blade w der than the other). Th s
plug w ll f t nto the power outlet only one way. Th s s a safety feature. If you are unable to nsert the plug fully nto
the outlet, try revers ng the plug. If the plug should st ll fa l to f t, contact your electr c an to replace your obsolete
outlet. Do not defeat the safety purpose of the polar zed plug. A warn ng that an apparatus w th CLASS I construct on
shall be connected to a MAINS socket outlet w th a protect ve earth ng connect on.
10. Power-Cord Protection
Power-supply cords should be routed so that they are not l kely to be walked on or p nched by tems placed
upon or aga nst them, pay ng part cular attent on to cords at plugs, wall outlets, and the po nt
where they ex t from the TV. MAINS plug s used as the d sconnect dev ce, the d sconnect dev ce shall rema n read ly operable.
11. Lightning
For added protect on for th s TV dur ng a l ghtn ng storm, or when t s left unattended and unused for long
per ods of t me, unplug t from the wall outlet and d sconnect the antenna or cable system. Th s w ll prevent
damage to the TV due to l ghtn ng and power-l ne surges.
12. Wall or Ceiling Mounting
When mount ng the product on a wall or ce l ng, be sure to nstall the product us ng the des gnated
mount ng tool accord ng to the method recommended by the manufacturer.
All manuals and user guides at all-guides.com

Important
Safeguards
4
13. Power Lines
An outs de antenna system should not be located n the v c n ty of overhead power l nes or other electr c l ght
or power c rcu ts, or where t can fall nto such power l nes or c rcu ts. When nstall ng an outs de antenna
system, extreme care should be taken to keep from touch ng such power l nes or c rcu ts as contact w th
them m ght be fatal.
14. Overloading
Do not overload wall outlets and extens on cords as th s can result n a r sk of f re or electr c shock.
15. Object and Liquid Entry
Never push objects of any k nd nto th s TV through open ngs as they may touch dangerous voltage po nts or
short-out parts that could result n f re or electr c shock. Never sp ll l qu d of any k nd on or nto the TV.
16. Outdoor Antenna rounding
If an outs de antenna or cable system s connected to the TV, be
sure the antenna or cable system s grounded so as to prov de
some protect on aga nst voltage surges and bu lt-up stat c charges.
Sect on 810 of the Nat onal Electr c Code, ANSI /NFPA No. 70-1984,
prov des nformat on w th respect to proper ground ng of the mast
and support ng structure, ground ng of the lead n w re to an antenna
d scharge un t, s ze of ground ng conductors, locat on of
antenna d scharge un t, connect on to ground ng electrodes, and
requ rements for the ground ng electrode.
17. Servicing
Do not attempt to serv ce th s TV yourself as open ng or remov ng covers may expose you to dangerous
voltage or other hazards. Refer all serv c ng to qual f ed serv ce personnel.
18. Damage Requiring Service
Unplug the TV from the wall outlet and refer serv c ng to qual f ed serv ce personnel under the follow ng
cond t ons:
(a) When the power-supply cord or plug s damaged.
(b) If l qu d has been sp lled, or objects have fallen nto the TV.
(c) If the TV has been exposed to ra n or water.
(d) If the TV does not operate normally by follow ng the operat ng nstruct ons. Adjust only those controls
that are covered by the operat ng nstruct ons as an mproper adjustment of other controls may result n
damage and w ll often requ re extens ve work by a qual f ed techn c an to restore the TV to ts normal operat on.
(e) If the TV has been dropped or the cab net has been damaged.
(f) When the TV exh b ts a d st nct change n performance - th s nd cates a need for serv ce.
19. Replacement Parts
When replacement parts are requ red, be sure the serv ce techn c an has used replacement parts spec f ed
by the manufacturer or have the same character st cs as the or g nal part. Unauthor zed subst tut ons may
result n f re, electr c shock or other hazards.
20. Safety Check
Upon complet on of any serv ce or repa r to the TV, ask the serv ce techn c an to perform safety checks to
determ ne that the TV s n safe operat ng cond t on.
21. Heat
The product should be s tuated away from heat sources such as rad ators, heat reg sters,
stoves, or other products ( nclud ng ampl f ers) that produce heat.
22. Disconnection
Please place the TV set n such a way that the ma n plug can be eas ly d sconnected.
ANTENNA
LEAD IN WIRE
ANTENNA
DISCHARGE UNIT
(NEC SECTION 810-20)
GROUNDING
CONDUCTORS
(NEC SECTION 810-21)
GROUND CLAMPS
POWER SERVICE GROUNDING
ELECTRODE SYSTEM
(NEC ART 250, PART H)
GROUND CLAMP
ELECTRIC
SERVICE
EQUIPMENT
NEC — NATIONAL ELECTRICAL CODE
EXAMPLE OF ANTENNA GROUNDING
All manuals and user guides at all-guides.com

Warning
5
This section must be read carefully and followed by the user prior to the operation of the product.
The manual states mportant nstruct ons for the user's own safety, and the proper operat on of the product.
In case of an accident, please unplug the unit from the outlet immediately.
Hold the plug when unplugging the unit
from the outlet. The cord may cause fire
or electric shock if damaged.
Do not cause the product to lean or put it in
an unstable place since it may cause a
serious injury to a person, as well as damage
to the product if it falls.
Do not put any object that contains water -
such as flowerpot - near to the unit.
The water may penetrate into the unit, and
be a cause of fire or hazardous electric
shock.
To reduce the risk of electric shock, do
not remo e co er or back. No user -
ser iceable parts inside. Refer to qualified
ser ice personnel for repair.
Do not put on or use the product near water
and moisture-such as in a bathroom,
washbowl, etc. It may be a cause of fire and
electric shock hazards.
To pre ent fire and damages to the product,
unplug the unit from the outlet during
lightning storm, or when it is left unattended
and unused for a long period of time.
Do not let children hang on or climb on
the product since it may be a cause of
serious injury.
Slots and openings in the case are pro ided
for entilation to ensure reliable operation of
the product. Ne er put in any item-such as a
coin, paper, match- through these openings
since it may touch dangerous oltage points
that could result in fire or shock hazard.
Do not put olatile substance-such as
benzene, naphtha- near the product since it
may cause a change in the product's colour.
Do not iew the TV too closely since it
may cause damage in your eyesight.
Do not spill water or drop the remote
controller since it may be a cause of
malfunctioning.
Refer ser icing to qualified ser ice
personnel for cleaning at least once a year
since dust inside the TV set may be a result
or fire and malfunctioning of the product.
All manuals and user guides at all-guides.com
all-guides.com

Warning
6
The product should be situated away from
any heat source-such as radiators, heat
registers, sto es, or other products that
produce heat.
Do not put on any hea y item on the
power cord since it may result in fire or
hazardous electric shock if the cord is
damaged.
Do not co er the top of the tele ision set.
Ventilation will be pre ented, and it may
be a cause of fire if the product is
internally o erheated.
Unplug the power from the outlet and all the
related connections from the unit to pre ent
electric shock. At least two people must work
together to mo e the TV set when transporting
to pre ent the TV from falling, and
consequently, any serious injury or damage.
Do not touch the power cord with
moisturized or wet hands when plugging
to or unplugging from the outlet since it
may be a cause of electric shock.
Please be ad ised of electric wires and cables
when installing the antenna. It may be a cause of
hazardous electric shock and fire if the antenna
touches or falls on the electric wire; thus, it must be
installed firmly, and far away from the cables.
This section must be read carefully and followed by the user prior to the operation of the product.
The manual states mportant nstruct ons for the user's own safety, and the proper operat on of the product.
Please keep the user's manual n a safe place for future reference.
Do not expose the product to a dusty or
moisturized place since it may be a cause
of malfunctioning.
Please place the TV set in such a way
that the main plug can be easily
disconnected.
The screen case of the product is scratched
easily.
When cleaning, use the microfiber sheet
which enclosed.
When a force to gi e it cleans strongly, it
will be scratched and the product's colour
will be changed. If foreign material gets in
the fiber, the product will be scratched.
Shake off the fiber cleanly and use.
All manuals and user guides at all-guides.com

Table of
Contents
7
Installation and Maintenance
Stand Construct on 9
Antenna Connect on 11
V deo Connect on 14
Camcorder & V deo Game Connect on 15
DVD Player Connect on 16
STB Connect on 17
PC Connect on 18
Cable TV Broadcast ng Connect on 20
Connect w th the Dolby D g tal AMP 21
Name of Each Part 22
Basic uide
Parts of the Remote Controller 24
Method To Use Bas c Menu 26
To Watch TV 27
Sett ng Up TV Stat ons 29
Select on of AV and Mult med a Input S gnal 33
Application uide
Screen Adjustment 35
PIP Mode 39
Sound Adjustment 41
Select on of Language 43
Adjustment of T me 44
Teletext 45
Troubleshoot ng 46
Standard of Product 48
All manuals and user guides at all-guides.com

Supplied
Accessories
8
Make sure that the following accessories are provided with the product.
AC cord
AC cord Instruct on manual Remote controller Batter es
Cover Bottom
-When you nstall wall mount ng you set
up cover bottom l ke upper p cture.
Cable holder
M crof ber sheet
(For C1/L1/L2)
1
23
The method of wire arrangement
1. Assemble the cable holder enclosed on the back
of TV. (PICTURE 1)
(ASSEMBLY METHOD: After you push the
"A"(prom nence part of cable holder) n the
hole, rotate the cable holder clockw se as an
angle of 90°. You can separate n reverse order
of assembly.)
2. Open the cable holder. (PICTURE 2)
( you can open the cable holder that press and
push "B" part.)
3. After arrange l nes w th the cable holder, lock the
"B" aga n. (PICTURE 3)
T
V
/
A
V
R
E
C
A
L
L
P
I
P
P
R
P
I
P
P
R
L
O
C
K
S
T
I
L
L
M
E
N
U
POWER
S
L
E
E
P
VOL
MUTE
P.SIZEPIPINPUTSWAP
OK
PR
M
U
L
T
I
M
E
D
I
A
Wall Mount ng Un t
(OPTION)
All manuals and user guides at all-guides.com

Stand
Construction
9
32” Stand Assy Construction
1. F x a cover frame stand to the stand assy base. 2. F x a frame stand to the stand assy.
3. Assemble plate stand base and frame stand
w th screw 4EA.
4. Assemble TV set and stand w th screw 3EA.
󱈺
󱈺
󱈺
󱈺
󱈺
󱈺
󱈺
When attaching stand to TV set, be
sure to cover the surface to protect
from accidental damage.
All manuals and user guides at all-guides.com

Stand
Construction
10
37” Stand Assy Construction
1. F x a TV set to the stand assy. 2. Assemble plate stand base and frame stand w th
screw 5EA
3. Assemble TV set and stand w th screw 5EA.
󱈺
󱈺
󱈺
󱈺
󱈺
When attaching stand to TV set, be
sure to cover the surface to protect
from accidental damage.
All manuals and user guides at all-guides.com
all-guides.com

Indoor Antenna Connection
1. Connect the feeder cable of the antenna to the comb n ng adapter.
WHEN THE IMA E IS NOT CLEAR : Unclear screen mage and bad recept on may be a cause of wrong
antenna connect on. Be sure to check ts d rect on and place when
nstall ng.
2. Connect the comb n ng adapter to the antenna nput at back of the TV set.
WHEN USIN THE COMBININ ADAPTER : You may obta n the comb n ng adapter at your closest
Serv ce Center.
Antenna Input
BACK OF THE TV SET
Antenna
Connection
11
All manuals and user guides at all-guides.com

Antenna
Connection
12
Antenna socket at the left s de of the TV set
ANT/CABLE
ANT/CABLE
CTV Antenna Connection
Such commun ty TV Antenna nstallat on may be found n most of co-op apartments.
When a coaxial cable is used : Plug the coax al cable to the antenna socket, and f x t f rmly by turn ng t to
the r ght.
When a feeder cable is used : Plug the coax al cable to the antenna socket, and f x t f rmly by turn ng t to
the r ght.
Antenna socket at the left s de of the TV set
All manuals and user guides at all-guides.com

Antenna
Connection
13
Outdoor Antenna Connection
Outdoor Antenna connect on-such as VHF or/and UHF-may be necessary for nstallat on at pr vate houses
Single Antenna Connection
Separate Antenna Connection.
VHF Antenna
UHF Antenna
ANT/CABLE
TV
ANT/CABLE
All manuals and user guides at all-guides.com

Video
Connection
14
OUTPUT AV1
R AUDIO L VIDEO
MONITOR OUT
L - AUDIO - R
POWER CH VOL MENU
PLAY INPUT REW PLAY F.FWD STOP/
EJECT
STAND
-BY
AV1
VIDEO
R-AUDIO-L VIDEO
S-VIDEO
AV2
INPUT
1. Prepare the RCA cable for p cture / sound.
2. Connect the RCA to Mon tor out term nal of 1’st TV set.
3. Connect the RCA to AV1 or AV2 nput term nal of 2’st TV set.
4. Turn on the TV sets.
Note :
• If your AV dev ce has both V deo OUT term nal and S-V deo OUT term nal, the S-V deo connect on s
recommended for better p cture qual ty.
Note :
• Mon tor out works only CVBS s gnal. : RF, AV1, AV2(S-V deo)
Connecting with an External Source
Connecting with the Monitor Out.
You may connect an S-V deo nput to enjoy clearer and br ghter p cture mages. You can make the
connect on w th the AV1,AV2 nputs.
S-V deo
TV
TV
All manuals and user guides at all-guides.com

Camcorder & Video
ame Connection
15
Note :
* If your AV dev ce has both V deo OUT term nal and S-V deo OUT term nal, the S-V deo connect on s
recommended for better p cture qual ty.
Watching the Camcorder Recording on TV
1. Prepare the S-v deo and RCA connector.
2. These connectors connect to S-V deo or AV1, AV2 as shown n the p cture below.
3. Turn on the TV set and camcorder/v deo game.
4.
Select AV1, AV2(S-V deo) mode, us ng the ”TV/AV” button of the Remote controller or “” button of
the TV set.
OUTPUT AV1
R AUDIO L VIDEO
Video game
R-AUDIO-L VIDEO
S-VIDEO
AV2
INPUT
TV
All manuals and user guides at all-guides.com
all-guides.com

DVD Player
connection
16
OUTPUT
UP-GRADE
PORT
AV1
Pr
R AUDIO L
R AUDIO L VIDEO
Pb Y
COMPONENT
OPTICAL
HDMI
3
PC
HDMI
2
HDMI
1
INPUT
PC AUDIO
R-AUDIO-L VIDEO
S-VIDEO
AV2
INPUT
Note :
• When you connect w th the component v deo, please check the colour of the cable between the DVD and
TV set.
Note :
• If your AV dev ce has both V deo OUT term nal and S-V deo OUT term nal, the S-V deo connect on s
recommended for better p cture qual ty.
When connecting with a component cable
When connecting with a S-VHS cable and RCA cable
TV
TV
All manuals and user guides at all-guides.com

STB(Set Top Box)
Connection
17
Set Top Box
OUTPUT
UP-GRADE
PORT
AV1
Pr
R AUDIO L
R AUDIO L VIDEO
Pb Y
COMPONENT
OPTICAL
HDMI
3
PC
HDMI
2
HDMI
1
INPUT
PC AUDIO
Set Top Box
OUTPUT
UP-GRADE
PORT
AV1
Pr
R AUDIO L
R AUDIO L VIDEO
Pb Y
COMPONENT
OPTICAL
HDMI
3
PC
HDMI
2
HDMI
1
INPUT
PC AUDIO
When connecting with a HDMI cable
When connecting with a component cable
TV
TV
All manuals and user guides at all-guides.com

PC
Connection
18
OUTPUT
UP-GRADE
PORT
AV1
Pr
R AUDIO L
R AUDIO L VIDEO
Pb Y
COMPONENT
OPTICAL
HDMI
3
PC
HDMI
2
HDMI
1
INPUT
PC AUDIO
1. F rst adjust resolut on of the PC. (Refer to table n page 17.)
2. Connect between PC and TV set us ng the D-sub and Aud o cable as shown n the p cture below.
3. Turn on the PC and TV set.
4. select PC mode by press ng “MULTIMEDIA” button on the remote control or ” ” button of the TV
set.
OUTPUT
UP-GRADE
PORT
AV1
Pr
R AUDIO L
R AUDIO L VIDEO
Pb Y
COMPONENT
OPTICAL
HDMI
3
PC
HDMI
2
HDMI
1
INPUT
PC AUDIO
1. F rst adjust resolut on of the PC. ((Refer to table n page 17.)
2. Connect between PC and TV set us ng the HDMI and Aud o cable as shown n the p cture below.
3. Turn on the PC and TV set.
4.
select HDMI mode by press ng “MULTIMEDIA” button on the remote control or
”” button of the TV
set.
When connecting with PC(D-Sub) cable.
When connecting with a HDMI cable.
Note : If the graph c card of the PC only supports a DVI s gnal, you must connect the Aud o cable as shown n the
p cture upper.
TV
TV
All manuals and user guides at all-guides.com

PC
Connection
19
PC CONNECTION NOTES:
1) The resolut on of the TV set s best at 1360(6) X768(WXGA).
2) If there s a [Vert cal Frequency] sett ng menu n the [D splay] Menu of the PC, adjust the frequency to 60Hz.
3) If the PC resolut on s too h gh, t may be hard to detect s gnals. Select a su table resolut on.
4) HDMI nput port rece ves only d g tal S gnal.
5) Depend ng on the graph c card when you plug & unplug the HDMI connect on the screen may not d splay
correctly. Restart the computer f th s happens.
6) Depend ng on graph c card, problems l ke no s gnal detected or l ne no ses can occur. If these problems do
occur contact the graph c card company for help.
Multi input resolution available in LCD TV.
Resolut on V-freq HDMI PC(D-Sub) Component Standard
60Hz O O X
640 X 480 72Hz O O X
75Hz O O X VESA Standard
60Hz O O X VESA Standard
800 X 600 72Hz O O X VESA Standard
75Hz O O X
60Hz O O X VESA Standard
1024 X 768 70Hz O O X VESA Standard
75Hz O O X VESA Standard
1360(6) X 768 60Hz O O X
(1280 X 768) 75Hz O O X
720 X 480 60Hz O X O
720 X 576 50Hz O X O
1280 X 720 50Hz O O O
60Hz O O O
1920 X 1080 50Hz O X O
60Hz O X O
720 X 480 60Hz X X O
720 X 576 50Hz X X O
Note : • When you connect w th component, D-Sub, and HDMI, you must check the nput resolut on of external
dev ces.
•1280 X 720 mode s commonly used for Component.
•So f th s mode s used at PC mode, the screen can be enlarged.
•”1360(6) X 768” s same w th “1280 X 768”.(Only d fferent from OSD d splay)
All manuals and user guides at all-guides.com
