Daewoo KOG-311M User manual

TIME
DEFROST
WEIGHT AUTO
START
LOCK g
GRILL
NO/
CUPS
M/W
COMBI
BEVERAGE
FROZEN
PIZZA
MORE LESS
DINNER
PLATE
START
STOP / CLEAR
Clock /
A. Start
1
4
978
6
0
32
AUTO COOK
1. Baked Potato
2. Fresh Vegetable
3. Soup
4. Fish Fillets
5. Meat Loaf
MENU
WEIGHT
SPEEDY
COOK
5
Power
MICROWAVE GRILL OVEN RANGE
COMBI
GRILL
AUTO
DEFROST
OPERATING
INSTRUCTIONS
Before operating this oven, please read these instructions completely.
MICROWAVE OVEN
KOG-311M

1
TABLE OF CONTENTS
PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO
EXCESSIVE MICROWAVE ENERGY ········································1
TABLE OF CONTENTS ·················································1
EARTHING INSTRUCTIONS··············································2
INSTALLATION ······················································2
SAFETY INSTRUCTIONS FOR GENERAL USE ·································3
SPECIFICATIONS ··················································· 4
FEATURES DIAGRAM ·················································5
OPERATION PROCEDURE ··············································7
CONTROLS ·······················································8
SETTING THE CLOCK ··············································8
WEIGHT DEFROSTING ··············································8
TIME DEFROSTING ················································9
COOKING IN ONE STAGE ············································9
GRILL COOKING ················································· 10
COMBI COOKING ················································· 10
AUTO START ··················································· 11
TO CHECK AUTO START TIME ········································ 11
SPEEDY COOK ··················································11
ONE TOUCH COOKING ············································· 12
AUTO COOK (MENU & WEIGHT) ······································· 13
MORE, LESS ····················································14
CHILD SAFETY LOCK ··············································14
TO STOP THE OVEN WHILE THE OVEN IS OPERATING ························14
UTENSIL TEST ·····················································14
MICROWAVE UTENSILS ·············································· 15
CARE OF YOUR MICROWAVE OVEN ······································ 16
USE YOUR MICROWAVE OVEN SAFELY ··································· 17
BEFORE YOU CALL FOR SERVICE ······································· 18
QUESTIONS AND ANSWERS ··········································· 18
PRECAUTIONS TO AVOID POSSIBLE
EXPOSURE TO EXCESSIVE MICROWAVE
ENERGY
(a) Do not attempt to operate this oven with the door open since open-door operation can
result in harmful exposure to microwave energy. It is important not to defeat or tamper with
the safety interlocks.
(b) Do not place any object between the oven front face and the door or allow soil or cleaner
residue to accumulate on sealing surfaces.
(c) Do not operate the oven if it is damaged.
It is particularly important that the oven door close properly and that there is no damage to
the: (1) door (bent), (2) hings and latches (broken or loosened), (3) door seals and sealing
surfaces.
(d) The oven should not be adjusted or repaired by anyone except properly qualified service
personnel.

2
INSTALLATION
Steady, flat location
This oven should be set on a steady, flat surface. This oven is designed for counter top use only.
Leave space behind and side
All air vents should be kept a clearance. If all vents are covered during operation, the oven may be
overheated and, eventually, failed.
Away from radio and TV sets
Poor television reception and radio interference may result if the oven is located close to a TV, Radio
antenna, feeder and so on.
Position the oven, as far from them as possible.
Away from heating appliance and water taps
Keep the oven away from hot air, steam or splash when choosing a place to position it, or the
insulation might be adversely affected and breakdowns occur.
Power supply
•Check your local power source. This oven requires a current of approximately 15 amperes, 220V
60Hz.
•Power supply cord is about 1.1 meters long.
•The voltage used must be the same as specified on this oven. Using a higher voltage may result in
a fire or other accident causing oven damage. Using low voltage will cause slow cooking. We are not
responsible for damage resulting from use of this oven with a voltage of ampere fuse other than those
specified.
•This appliance is supplied with cable of special type, which, if damaged, must be repaired with
cable of same type. Such a cable can be purchased from DAEWOO and must be installed by a
Qualified Person.
Examine the oven after unpacking for any damage such as:
A misaligned door, Broken door, A dent in cavity. If any of the above are visible, DO NOT INSTALL,
and notify dealer immediately.
Do not operate the oven if it is colder than room termperature.
(This may occur during delivery in cold weather.) Allow the oven to become room temperature before
operating.
EARTHING INSTRUCTIONS
This appliance must be earthed. In the event of an electrical short circuit, earthing reduces the risk of
electric shock by providing an escape wire for the electric current. This appliance is equipped with a cord
having a earthing wire with a earthing plug. The plug must be plugged into an outlet that is properly
installed and earthed.
1
2
3
4
5
6
7
WARNING: Improper use of the earthing plug can result in a risk of electric shock. Consult a
qualified electrician or serviceman if the earthing instructions are not completely
understood, or if doubt exists as to whether the appliance is properly earthed. If it is
necessary to use an extension cord, use only a 3-wire extension cord that has a 3-
blade earthing plug, and a 3-slot receptacle that will accept the plug on the appliance.
The marked ratign of the extension cord should be equal to or greater than the
electrical rating of the appliance.

3
SAFETY INSTRUCTIONS FOR GENERAL USE
Listed below are, as with all appliances, certain rules to follow and safeguards to assure top
performance from this oven:
1. Do not use the oven for any reason other than food preparation, such as for drying clothes, paper, or
any other nonfood items or for sterilizing purposes.
2. Do not use the oven when empty, this could damage the oven.
3. Do not use the oven cavity for any type of storage, such as papers, cookbook, cookware, etc.
4. Do not operate the oven without the glass tray in place. Be sure it is properly sitting on the rotating
base.
5. Make sure you remove caps or lids prior to cooking when you cook food sealed in bottles.
6. Do not put foreign material between the oven surface and door. It could result in excessive leakage of
microwave energy.
7. Do not use recycled paper products for cooking. They may contain impurities which could cause
sparks and/or fires when used during cooking.
8. Do not pop popcorn unless popped in a microwave approved popcorn popper or unless it's
commercially packaged and recommended especially for microwave ovens. Microwave popped corn
produces a lower yield than conventional popping; there will be a number of unpopped kernels. Do not
use oil unless specified by the manufacturer.
9. Do not cook any food surrounded by a membrane, such as egg yolks, potatoes, chicken livers, etc.,
without first piercing them several times with a fork.
10. Do not pop popcorn longer than the manufacturer's directions. (popping time is generally below 3
minutes).
Longer cooking does not yield more popped corn, it can cause scorchings and fire.
Also, the cooking tray can become too hot to handle or may break.
11. Should the microwave oven emit smoke in quantity to indicate a fire, keep the oven door shut, switch
the appliance off and disconnect the mains lead from the outlet.
12. When flammable food containers are used in the oven (e.g. packet popcorn) be sure to check the
cooking process periodically in case fire has occurred.
13. Always stir and/or shake the containers of baby foods prior to testing their temperature and serving
the contents.
14. Always test the temperature of food or drink which has been heated in a microwave oven before you
give it to somebody, especially to children or elderly people. This is important because things which
have been heated in a microwave oven carry on getting hotter even though the microwave oven
cooking has stopped.

4
* Specifications subject to change without notice.
POWER SUPPLY 220V ~60 Hz SINGLE PHASE WITH EARTHING
POWER CONSUMPTION MICROWAVE 1500 W
GRILL 1150 W
COMBI 2600 W
MICROWAVE ENERGY OUTPUT 950 W (IEC 705)
MICROWAVE FREQUENCY 2450 MHz
OUTSIDE DIMENSIONS (W X H X D) 564 X 310 X 413 mm
CAVITY DIMENSIONS (W X H X D) 374 X 233 X 372 mm
NET WEIGHT APPROX. 18 Kg
TIMER 59 min. 99 sec.
FUNCTION SELECTIONS MICROWAVE/GRILL/COMBINATION
MICROWAVE POWER LEVELS 10 LEVELS
SPECIFICATIONS
IMPORTANT
The wires in this mains lead are coloured in accordance with the following code.
Green-and-yellow : Earth
Blue : Neutral
Brown : Live
As the colours of the wires in the mains lead of this appliance may not correspond with the
coloured markings identifying the terminals in your plug, proceed as follows:
The wire which is coloured green-and-yellow must be connected to the terminal in the plug
which is marked with the letter 'E' or by the earth symbol or green-and-yellow. The wire which
is coloured blue must be connected to the terminal which is marked with the letter 'N' or
coloured black.
The wire which is coloured brown must be connected to the terminal which is marked with the
letter 'L' or coloured red.
WARNING: This appliance must be earthed.

5
1. Door latch-When the door is closed it will
automatically lock shut. If the door is opened
while the oven is operating, the magnetron will
automatically shut off.
2. Door seal-The door seal maintains the
microwave within the oven cavity and prevents
microwave leakage.
3. Oven cavity
4. Spatter shield-Protects the microwave outlet
from splashes of cooking foods.
5. Safety interlock system-Prevents the oven
from operating while the door is opened.
6. Door release button-Pushing this button
stops oven operation and opens the door.
7. Glass cooking tray-Made of specical heat
resistant glass. The tray must always be in
proper position before operating.
Do not cook food directly on the tray.
8. Roller guide-Supports the glass cooking tray.
9. Door screen-Allows viewing of food.
The screen is designed so that light can pass
through, but not the microwaves.
10. Reflector (Insulator Heater)
11. Heating Element.
12. Metal Rack
FEATURES DIAGRAM
TIME
DEFROST
WEIGHT AUTO
START
LOCK g
GRILL
NO/
CUPS
M/W
COMBI
BEVERAGE
FROZEN
PIZZA
MORE LESS
DINNER
PLATE
START
STOP / CLEAR
Clock /
A. Start
1
4
978
6
0
32
AUTO COOK
1. Baked Potato
2. Fresh Vegetable
3. Soup
4. Fish Fillets
5. Meat Loaf
MENU
WEIGHT
SPEEDY
COOK
5
Power
MICROWAVE GRILL OVEN RANGE
COMBI
GRILL
AUTO
DEFROST
12 3 0 q 4 5
6
7
9
8
w

6
13. Time set pad-Used to set the cooking time
and the present time.
14. Display-Cooking time, power level, indicators
and present time are displayed.
15. Speedy cook-Touch to set the desired
reheat time.
16. One touch-Used to cook or reheat specific
quantities of food. See pages 12-14.
17. More-Used to add time to one touch cooking.
18. Less-Used to remove time from one touch
cooking.
19. Auto defrost-Used to defrost foods.
20. Power-Used to set power level.
21. Clock/A.start (Auto Start)-Used to set clock
and also used to set a delayed auto start.
22. Stop/Clear-Used to stop the oven operation
or to delete the cooking data.
23. Start-Used to start the oven.
24. Menu-Used to select foods.
25. Weight-Used to select quantity of foods.
26. Grill-Used to cook Grill.
27. Combi-Used to cook Combi.
FEATURES DIAGRAM (continued)
t
i
j
h
o
p
s
y
u
r
f
g
y
e
a
d
TIME
DEFROST
WEIGHT AUTO
START
LOCK g
GRILL
NO/
CUPS
M/W
COMBI
BEVERAGE
FROZEN
PIZZA
MORE LESS
DINNER
PLATE
START
STOP / CLEAR
Clock /
A. Start
1
4
978
6
0
32
AUTO COOK
1. Baked Potato
2. Fresh Vegetable
3. Soup
4. Fish Fillets
5. Meat Loaf
MENU
WEIGHT
SPEEDY
COOK
5
Power
MICROWAVE GRILL OVEN RANGE
COMBI
GRILL
AUTO
DEFROST

7
The oven light is on only when the microwave
oven is operating.
The oven door can be opened at any time
during operation by touching the door release
button on the control panel. The oven will
automatically shut off.
Each time a pad is touched, a BEEP will sound
to acknowledge the touch.
The oven automatically cooks on full power
unless set to a lower power level.
The display will show ":0" when the oven is
plugged in.
Time clock returns to the present time when
the cooking time ends.
When the STOP/CLEAR pad is touched during
the oven operation, the oven stops cooking and
all information retained.
To erase all information (except the present
time), touch the STOP/CLEAR pad once more.
If the oven door is opened during the oven
operation, all information is retained.
If the START pad is touched and the oven does
not operate, check the area between the door
and door seal for obstructions and make sure
the door is closed securely.
The oven will not start cooking until the door is
completely closed or the program has been
reset.
OPERATION PROCEDURE
This section includes useful information about oven operation.
1. Plug power supply cord into a 220V AC 60Hz power outlet.
2. After placing the food in a suitable container, open the oven door and put it on the glass tray.
The glass tray and roller guide must always be in place during cooking.
3. Shut the door. Make sure that it is firmly closed.
1
2
3
4
5
6
7
8
Make sure the oven is properly installed and
plugged into the electrical outlet.
WATTAGE OUTPUT CHART
●The power-level is set by pressing the POWER pad. The chart shows the display, the power level and
the percentage of power.
Power Level (Display) Approximate Percentage of Power
Touch POWER pad,
Once the Touch
POWER P-HI 100%
9 P-90 90%
8 P-80 80%
7 P-70 70%
6 P-60 60%
5 P-50 50%
4 P-40 40%
3 P-30 30%
2 P-20 20%
1 P-10 10%
0 P-0 0%

8
CONTROLS
SETTING THE CLOCK
When the oven is first plugged in, the display will flash ":0" and a tone will sound. If the AC power
ever goes off, the display shows ":0" when the power comes back on.
1. Touch CLOCK/A.START pad.
This is a 12 hour clock system.
2. Touch CLOCK/A.START pad
once more.
This is a 24 hour clock system.
3. Enter the correct time of day by touching the numbers
in sequence.
4. Touch CLOCK/A.START pad.
NOTE: If you attempt to enter an incorrect time, the time will not be set and a error signal tone will
sound. Touch the CLOCK/A.START pad and re-enter the time.
The display stops blinking, and the colon
start blinking. If you selected 12 hour clock
system, this digital clock allows you to set
from 1:00 to 12:59. If you selected 24 hour
clock system, this digital clock allows you to
set from 0:00 to 23:59.
WEIGHT DEFROSTING
WEIGHT DEFROST lets you easily defrost food by eliminating guesswork in determining defrosting
time. The minimum weight for WEIGHT DEFROST is 200 grams. The maximum weight for
WEIGHT DEFROST is 3000 grams. Follow the steps below for easy defrosting.
The defrosting time is automatically determined by the weight entered.
The g indicator goes off and the WEIGHT DEFROST indicator blinks and the defrosting time counts down
in the display window. The oven beeps during the defrosting cycle to signal that the food needs to be
turned or rearranged. When the defrosting time ends, you will hear 3 beeps.
NOTE: This oven has multiple clock
systems. If you want 12 hour
clock system, omit this step.
(step 2)
1. Touch AUTO DEFROST pad.
2. Touch number pads for the desired defrosting weight.
3. Touch START pad.
The WEIGHT DEFROST indicator lights
and "0" is displayed and the g indicator
starts blinking.
The display will show the numbers you
pressed in the order you touched.
WEIGHT DEFROSTING begins.
CLOCK/
A.START
CLOCK/
A.START
AUTO
DEFROST

9
TIME DEFROSTING
When TIME DEFROST is selected, the automatic cycle divides the defrosting time into periods of
alternating defrost and stand times by cycling on and off.
When you touch START pad, the TIME DEFROST indicator starts blinking to show the oven is in the
TIME DEFROST mode.The display counts down the time to show you how much defrosting time is left in
the TIME DEFROST mode. The oven beeps during the defrosting cycle to signal that the food needs to
be turned or rearranged. When the defrosting time ends, you will hear 3 beeps.
1. Touch AUTO DEFROST pad.
2. Touch AUTO DEFROST pad once more.
3. Touch number pads, for the desired defrosting time.
4. Touch START pad.
The WEIGHT DEFROST indicator light and
"0" is displayed. And the g indicator starts
blinking.
The TIME DEFROST indicator lights and
":0" is displayed.
The display will show the numbers you
pressed in the order you touched.
COOKING IN ONE STAGE
When you touch START pad, the M/W indicator starts blinking to show the oven is cooking. The display
counts down the time to show how much cooking time is left. When the cooking time ends, you will hear 3
beeps.
1. Touch POWER pad.
2. Touch the number pad for desired power level.
3. Touch number pads for the cooking time.
4. Touch START pad.
The M/W indicator lights and "P-" is
displayed.
This display will show what you touched.
This example shows power level 3.
Note: If steps 1 and 2 are omitted, the oven
will cook at full power.
The display will show the numbers you
pressed in the order you touched.
Note: Your oven can be programmed for 59
minutes 99 seconds.(59:99)
3
NOTE: Using lower power levels increases the cooking time which is recommended for foods such
as cheese, milk and slow cooking of meats.
AUTO
DEFROST
POWER
