Daewoo KOR-611Q User manual

Before operating this oven, please read these instructions completely.
OPERATING
INSTRUCTIONS
MICROWAVE OVEN
STAGE DEFROST AUTO
START
12
WEIGHT TIME
LOCK NO CUPS oz lbs
Popcorn
Muffin
Baked
Potato
Dinner
Plate
Power Clock/
A.Start
Soup
Beverage
Frozen
Pizza
Fresh
Vegetable
SPEEDY
COOK
More
Less
AUTO
DEF.
STOP/
CLEAR START
1 2 3
4 5 6
7 8 9
0
ONE TOUCH COOKING
KOR-611Q
KOR-611Q0A(¿ )02.2.1912:29PM˘`1

TABLE OF CONTENTS
PRECAUTIONS............................................................................................................................................. 1
IMPORTANT SAFETY INSTRUCTIONS..................................................................................................... 2
FEDERAL COMMUNICATIONS COMMISSION RADIO FREQUENCY
INTERFERENCE STATEMENT (U.S.A. ONLY).......................................................................................... 3
GROUNDING INSTRUCTIONS.................................................................................................................... 3
INSTALLATION.............................................................................................................................................. 4
SPECIFICATIONS......................................................................................................................................... 5
FEATURES DIAGRAM.................................................................................................................................. 6
OPERATION PROCEDURE......................................................................................................................... 8
CONTROLS ................................................................................................................................................... 9
SETTING THE CLOCK............................................................................................................................ 9
WEIGHT DEFROSTING.......................................................................................................................... 9
TIME DEFROSTING.............................................................................................................................. 10
COOKING IN ONE STAGE................................................................................................................... 10
COOKING IN TWO STAGES................................................................................................................ 11
WEIGHT DEFROSTING AND COOKING IN TWO STAGES............................................................. 11
AUTO START......................................................................................................................................... 12
TO CHECK AUTO START TIME.......................................................................................................... 13
SPEEDY COOK..................................................................................................................................... 13
ONE TOUCH COOKING....................................................................................................................... 13
MORE, LESS.......................................................................................................................................... 15
CHILD SAFETY LOCK.......................................................................................................................... 16
TO STOP THE OVEN WHILE THE OVEN IS OPERATING............................................................... 16
UTENSIL TEST...................................................................................................................................... 16
MICROWAVE UTENSILS ..................................................................................................................... 16
CARE OF YOUR MICROWAVE OVEN .............................................................................................. 18
USE YOUR MICROWAVE OVEN SAFELY......................................................................................... 19
BEFORE YOU CALL FOR SERVICE................................................................................................... 20
1
PRECAUTIONS TO AVOID POSSIBLE
EXPOSURE TO EXCESSIVE MICROWAVE
ENERGY
(a) Do not attempt to operate this oven with the door open since open-door operation can result in
harmful exposure to microwave energy. It is important not to defeat or tamper with the safety
interlocks.
(b) Do not place any object between the oven front face and the door or allow soil or cleaner
residue to accumulate on sealing surfaces.
(c) Do not operate the oven if it is damaged. It is particularly important that the oven door close
properly and that there is no damage to the : (1) door (bent), (2) hinges and latches (broken or
loosened), (3) door seals and sealing surfaces.
(d) The oven should not be adjusted or repaired by anyone except properly qualified service
personnel.
KOR-611Q0A(¿ )02.2.1912:29PM˘`1

2
IMPORTANT SAFETY INSTRUCTIONS
When using electrical appliances, basic safety precautions should be followed, including the following :
WARNING - To reduce the risk of burns, electric shock, fire, injury to persons or exposure to excessive
microwave energy :
SAVE THESE INSTRUCTIONS
11.Read all instructions before using the
appliance.
12.Read and follow the specific
“PRECAUTIONS TO AVOID POSSIBLE
EXPOSURE TO EXCESSIVE
MICROWAVE ENERGY” found on page 1.
13.This appliance must be grounded.
Connect only to properly grounded outlet.
See “GROUNDING INSTRUCTIONS”
found on page 3.
14.Install or locate this appliance only in
accordance with the provided installation
instructions.
15.Some products such as whole eggs and
sealed containers - for example, closed
glass jars - may explode and should not
be heated in this oven.
16.Use this appliance only for its intended
use as described in this manual.
17.As with any appliance, close supervision
is necessary when used by children.
18.Do not operate this appliance if it has a
damaged cord or plug, if it is not working
properly, or if it has been damaged or
dropped.
19. This appliance should be serviced only
by qualified service personnel.
Contact nearest authorized service
facility for examination, repair or
adjustment.
10.Do not cover or block any opening on the
appliance.
11. Do not use outdoors.
12. Do not immerse cord or plug in water.
13. Keep cord away from heated surfaces.
14. Do not let cord hang over edge of table or
counter.
15. When cleaning surfaces of door and oven
that comes together on closing the door,
use only mild, non-abrasive soaps or
detergents applied with a sponge or soft
cloth.
16. To reduce the risk of fire in the oven
cavity:
(a) Do not overcook food. Carefully
attend appliance if paper, plastic, or
other combustible materials are
placed inside the oven to facilitate
cooking.
(b) Remove wire twist - ties from paper
or plastic bags before placing bag in
oven.
(c) If materials inside the oven should
ignite, keep oven door closed, turn
oven off, and disconnect the power
cord, or shut off power at the fuse or
circuit breaker panel.
17. Do not this microwave oven to heat
corrosive chemicals (for example,
sulfides and chlorides). Vapours from
such corrosive chemicals may interact
with the contact and springs of the safety
interlock switches thereby rendering them
inoperable.
KOR-611Q0A(¿ )02.2.1912:29PM˘`2

3
FEDERAL COMMUNICATIONS COMMISSION
RADIO FREQUENCY INTERFERENCE
STATEMENT (U.S.A. ONLY)
GROUNDING INSTRUCTIONS
This appliance must be grounded. In the event of an electrical short circuit, the grounding plug
reduces the risk of electric shock by providing an escape wire for electric current. This appliance is
equipped with a cord having a grounding wire with a grounding plug, The plug must be plugged into
an outlet that is properly installed and grounded.
WARNING:
This equipment generates and uses ISM frequency energy and if not installed and used
properly, that is in strict accordance with the manufacturer’s instructions, may cause interference
to radio and television reception.
It has been type-tested and found to comply with limits for an ISM equipment pursuant to part 18
of FCC rules, which are designed to provide reasonable protection against such interference in a
residential installation.
However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the followings.
• Reorient the receiving antenna of radio or television.
• Relocate the microwave oven with respect to the receiver.
• Move the microwave oven away from the receiver.
• Plug the microwave oven into a different outlet so that microwave oven and
receiver are on different branch circuits.
THE MANUFACTURER is not responsible for any radio or TV interference caused by
UNAUTHORIZED MODIFICATION to this microwave oven. It is the reponsibility of the user to
correct such interference.
WARNING: Improper use of the grounding can in a risk of electric shock.
Consult a qualified electrician or serviceman if the grounding instructions are not
completely understood, or if doubt exists as to whether the appliance is properly
grounded, and either :
(1) If it is necessary to use an extension cord, sue only a 3-wire extension cord
that has a 3-blade grounding plug, and a 3-slot receptacle that will accept the
plug on the appliance. The marked rating of the extension cord shall be equal
to or greater than the electrical rating of the appliance, or
(2) Do not use an extension cord, if the power supply cord is too short, have a
qualified electrician or serviceman install an outlet near the appliance.
KOR-611Q0A(¿ )02.2.1912:29PM˘`3

INSTALLATION
1. Examine the oven after unpacking.
check fork damage such as a misaligned door, broken door or dent in the cavity.
If any damage is visible, DO NOT INSTALL, and notify your dealer immediately.
2. Level, flat location.
Install the microwave oven on a level, flat surface.
3. Ventilation
Do not block air vents. If they are blocked during operation, the oven may overheat and eventually
cause a failure. For proper ventilation, allow 3 inches of space between oven top, sides, rear and
adjacent surfaces.
4. Away from radio and TV sets.
Poor television reception and radio interference may result if the oven is located close to a TV,
radio, antenna, fee, etc. Place the oven as far from them as possible.
5. Away from heating appliances and water taps.
Keep the oven away from heat, steam or splashing liquids. These things can adversely affect
oven wiring and contacts.
6. Power supply
This microwave oven requires a power supply of approximately 15 Amperes, 120 Volts, 60 Hz
and a grounded outlet. A short power cord is provided to reduce the risk of the user becoming
entangled in or tripping over a longer cord. Longer cord sets or extension cords are available and
may be used if care is exercised.
If an extension cord is used, the marked electrical rating of the cord should be at least as great as
the electrical rating of the oven.
The extension cord must be a grounding-type 3 wire cord. The longer cord should be arranged so
it does not drape over the table top or counter where children can pull on it or trip over it.
4
When use 3-pronged plug When use grounding adaptor, make sure the
receptacle box is fully grounded
Receptacle
Box cover
3-prong plug
3-prong Receptacle Grounding Lead Receptacle Box Cover
Grounding Adaptor
Receptacle
KOR-611Q0A(¿ )02.2.1912:29PM˘`4

SPECIFICATIONS
* Specifications subject to change without notice.
5
POWER SUPPLY 120V AC 60 Hz SINGLE PHASE WITH GROUNDING
POWER CONSUMPTION 920W
MICROWAVE OUTPUT POWER 600W (IEC 705)
FREQUENCY 2450 MHZ
OUTSIDE DIMEXIONS (WXHXD) 465X274X352 mm (18.3X10.8X13.9 in.)
CAVITY DIMENSIONS (WXHXD) 290X200X290 mm (11.4X7.9X11.4 in.)
NET WEIGHT APPROX. 12.5KG (27.6 lbs.)
TIMER 59 min. 99 SEC.
POWER SELECTIONS 10 LEVELS
18.3 in 13.9 in
10.8 in
STAGE DEFROST AUTO
START
12
WEIGHT TIME
LOCK NO CUPS oz lbs
Popcorn
Muffin
Baked
Potato
Dinner
Plate
Power Clock/
A.Start
Soup
Beverage
Frozen
Pizza
Fresh
Vegetable
SPEEDY
COOK
More
Less
AUTO
DEF.
STOP/
CLEAR START
1 2 3
4 5 6
7 8 9
0
ONE TOUCH COOKING
KOR-611Q0A(¿ )02.2.1912:30PM˘`5

FEATURES DIAGRAM
6
1 52
9 6
7
8
3 4
STAGE DEFROST AUTO
START
12
WEIGHT TIME
LOCK NO CUPS oz lbs
Popcorn
Muffin
Baked
Potato
Dinner
Plate
Power Clock/
A.Start
Soup
Beverage
Frozen
Pizza
Fresh
Vegetable
SPEEDY
COOK
More
Less
AUTO
DEF.
STOP/
CLEAR START
1 2 3
4 5 6
7 8 9
0
ONE TOUCH COOKING
1. Door latch - when the door is closed it will
automatically lock shut. If the door is
opened while the oven is operating, the
magnetron will automatically shut off.
2. Door seal - The door seal maintains the
microwave within the oven cavity and
prevents microwave leakage.
3. Oven cavity
4. Spatter shield - Protects the microwave
outlet from splashes of cooking foods.
5. Safety interlock system - Prevents the
oven from operating while the door is
opened.
6. Door release button - Pushing this button
stops oven operation and opens the door.
7. Glass cooking tray - Made of special heat
resistant glass. The tray must always be in
proper position before operating.
Do not cook food directly on the tray.
8. Roller guide - Supports the glass cooking
tray.
9. Door screen - Allows viewing of food.
The screen is designed so that light can
pass through, but not the microwaves.
KOR-611Q0A(¿ )02.2.1912:30PM˘`6

FEATURES DIAGRAM (continued)
7
11
10
13
18
20
12
14
15
16
17
19
STAGE DEFROST AUTO
START
12
WEIGHT TIME
LOCK NO CUPS oz lbs
Popcorn
Muffin
Baked
Potato
Dinner
Plate
Power Clock/
A.Start
Soup
Beverage
Frozen
Pizza
Fresh
Vegetable
SPEEDY
COOK
More
Less
AUTO
DEF.
STOP/
CLEAR START
1 2 3
4 5 6
7 8 9
0
ONE TOUCH COOKING
10.Time set pad - Used to set the cooking
time and the present time.
11. Display - Cooking time, power level,
indicators and present time are displayed.
12.Speedy cook - Touch to set the desired
reheat time.
13.One touch - used to cook or reheat
specific quantities of food. See pages 13-
15.
14.More - Used to add time to one touch
cooking.
15.Less - Used to remove time from one
touch cooking.
16.Auto defrost - Used to defrost foods.
17.Power - Used to set power level.
18.Clock/A.start (Auto Start) - Used to set
clock and also used to set a delayed auto
start.
19.Stop/Clear - Used to stop the oven
operation or to delete the cooking data.
20.Start - Used to start the oven.
KOR-611Q0A(¿ )02.2.1912:30PM˘`7

OPERATION PROCEDURE
This section includes useful information about oven operation.
1. Plug power supply cord into a standard 3 - pronged 15 Amp, 120V AC 60Hz power outlet.
2. After placing the food in a suitable container, open the oven door and put it on the glass tray.
2. The glass tray and roller guide must always be in place during cooking.
3. Shut the door. Make sure that it is firmly closed.
WATTAGE OUTPUT CHART
•The power - level is set by pressing the POWER pad. The chart shows the display, the power level
and the percentage of power.
8
1
The oven light is on only when the micro-
wave oven is operating.
2
The oven door can be opened at any
time during operation by touching the
door release button on the control panel.
The oven will automatically shut off.
3
Each time a pad is touched, a BEEP will
sound to acknowledge the touch.
4
The oven automatically cooks on full
power unless set to a lower power level.
5
The display will show “: 0 ”when the
oven is plugged in.
6
Time clock returns to the present time
when the cooking time ends.
7
When the STOP/CLEAR pad is touched
during the oven operation, the oven stops
cooking and all information retained.
To erase all information (except the
present time), touch the STOP/CLEAR
pad once more. If the oven door is
opened during the oven operation, all
information is retained.
8
If the START pad is touched and the
oven does not operate, check the area
between the door and door seal for
obstructions and make sure the door is
closed securely.
The oven will not start cooking until the
door is comletely closed or the program
has been reset.
Make sure the oven is properly installed and
plugged into the electrical outlet.
Touch POWER pad Power level (Display) Approximate Percentage
Once the Touch of Power
POWER P-HI 100%
9 P-90 90%
8 P-80 80%
7 P-70 70%
6 P-60 60%
5 P-50 50%
4 P-40 40%
3 P-30 30%
2 P-20 20%
1 P-10 10%
0 P-0 0%
KOR-611Q0A(¿ )02.2.1912:30PM˘`8

CONTROLS
SETTING THE CLOCK
When the oven is first plugged in, the display will flash “: 0 ”and a tone will sound. If the AC power
ever goes off, the display shows “: 0 ”when the power comes back on.
1. Touch CLOCK/A.START pad.
This is a 12 hour clock system.
2. Touch CLOCK/A.START pad
once more.
3. Enter the correct time of day by touching the
numbers in sequence.
4. Touch CLOCK/A.START pad.
WEIGHT DEFROSTING
WEIGHT DEFROST lets you easily defrost food by eliminating guesswork in determining defrosting
time. The minimum weight for WEIGHT defrost is 0.5 pounds. The maximum weight for WEIGHT
DEFROST is 6.5 pounds. Follow the steps below for easy defrosting.
1. Touch AUTO DEFROST pad.
2. Touch number pads for the desired defrosting
weight.
3. Touch START pad.
The defrosting time is automatically determined by the weight entered.
The lb indicator goes off and the weight defrost indicator blinks and the defrosting time counts down
turned or rearranged. When the defrosting time ends, you will hear 3 beeps.
9
NOTE : If you attempt to enter an incorrect time, the time will not be set and a error signal tone
will sound. Touch the CLOCK/A.START pad and re-enter the time.
NOTE : This oven has multiple clock
system. If you want 12 hour clock
system, omit this step(step2).
The display stops blinking, and the colon
starts blinking. If you selected 12 hour
clock system, this digital clock allows you
to set from 1:00 to 12:59. If you selected
24 hour clock system, this digital clock
allows you to set from 0:00 to 23:59.
The WEIGHT DEFROST indicator lights
and “0.0”is displayed and the lb indicator
starts blinking.
The display will show the numbers you
pressed in the order you touched.
WEIGHT DEFROSTING begins.
CLOCK/
A.START
CLOCK/
A.START
AUTO
DEFROST
KOR-611Q0A(¿ )02.2.1912:30PM˘`9

TIME DEFROSTING
When TIME DEFROST is selected, the automatic cycle divides the defrosting time into periods of
alternating defrost and stand times by cycling on and off.
1. Touch AUTO DEFROST pad.
2. Touch AUTO DEFROST pad once more.
3. Touch number pads, for the desired defrosting
time.
4. Touch START pad.
When you touch START pad, the TIME DEFROST indicator starts blinking to show the oven is in the
TIME DEFROST mode. The display counts down the time to show you how much defrosting time is
left in the TIME DEFROST mode. The oven beeps during the defrosting cycle to signal that the food
needs to be turned or rearranged. When the defrosting time ends, you will hear 3 beeps.
COOKING IN ONE STAGE
1. Touch POWER pad.
2. Touch the number pad for desired power level.
3. Touch number pads for the cooking time.
4. Touch START pad.
When you touch START pad, the STAGE1 indicator starts blinking to show the oven is cooking.
The display counts down the time to show how much cooking time is left. When the cooking time
ends, you will hear 3 beeps.
10
The WEIGHT DEFROST indicator lights
and “0.0”is displayed and the lb indicator
starts blinking.
The TIME DEFROST indicator lights and “:
0 ”is displayed.
The display will show the numbers you
pressed in the order you touched.
The STAGE1 indicator lights and “P-”is
displayed.
The display will show what you touched.
This example shows power level 3.
Note : If steps 1 and 2 are omitted, the oven
will cook at full power.
The display will show the numbers you
pressed in the order you touched.
Note : Your oven can be programmed for
59 minutes 99 seconds.(59 : 99)
AUTO
DEFROST
POWER
3
NOTE : Using lower power levels increases the cooking time which is recommended for foods
such as cheese, milk and slow cooking of meats.
KOR-611Q0A(¿ )02.2.1912:30PM˘`10

COOKING IN TWO STAGES
For best results, some recipes call for one power level for a certain length of time and another power
level for a different length of time.
Your microwave oven can be set to change from one to another.
1. Touch number pads for the
desired cooking time in the
first stage.
2. Touch POWER pad.
3. Touch the number pad for desired power level in
the second stage.
4. Touch the number pads for desired cooking timer
in the second stage.
5. Touch START pad.
When you touch START pad, both STAGE1 & 2 indicator lights come on, STAGE1 indicator light
starts blinking to show you that the oven is cooking in the first of two cook stages.
The oven will cook at the power you selected for stage one. At the end of stage one, the oven will
beep and start stage two, the STAGE1 indicator goes off and the STAGE2 indicator starts blinking.
The display counts time remaining in stage two when stage two ends, you will hear 3 beeps.
WEIGHT DEFROSTING AND COOKING IN TWO STAGES
All recipes require frozen foods to be defrosted fully before cooking.
This oven can be programmed to automatically defrost foods before cooking.
1. Touch AUTO DEFROST pad.
2. Touch number pads for the defrosting weight you
want.
3. Touch POWER pad.
4. Touch POWER pad once
more.
5. Touch number pads, for desired cooking time in
the first stage.
11
The STAGE1 indicator lights and the
display will show the numbers you pressed
in the order you touched.
This example shows 5 minutes 30 seconds
at full power.
The STAGE 2 indicator lights and “P-”is
displayed.
The display will show what you touched.
The display will show the numbers you
pressed in the order you touched.
The WEIGHT DEFROST indicator lights
and “0.0”is displayed and the lb indicator
starts blinking.
The display will show the numbers you
pressed in the order you touched.
The STAGE1 indicator lights and “p-”is
displayed.
“P-HI”will appear in the display window.
This example shows fulll power(100%).
The display will show the number you
pressed in the order you touched.
5 3 0
AUTO
DEFROST
POWER
POWER
KOR-611Q0A(¿ )02.2.1912:30PM˘`11

WEIGHT DEFROSTING AND COOKING IN TWO STAGES(CONTINUED)
6. Touch POWER pad.
7. Touch number pad for desired power level in the
second stage.
8. Touch number pads for cooking time in the second
stage.
9. Touch START pad.
When you touch START pad, the WEIGHT DEFROST, STAGE1 and STAGE2 indicators come on to
confirm the power levels selected. The WEIGHT DEFROST indicator starts blinking to show you that
the oven is in WEIGHT DEFROST mode. The display counts down the time remaining in WEIGHT
DEFROST mode.
When the oven beeps, turn over, break apart and or redistribute the food. At the end of WEIGHT
DEFROST mode, the oven will beep and start stage one. The WEIGHT DEFROST indicator goes off
and the STAGE1 indicator starts blinking. The display counts down the time remaining in stage one.
At the end of stage one, the oven will beep and start stage two.
The STAGE1 indicator goes off and the STAGE2 indicator starts blinking. The display counts down
the time remaining in stage two. When stage two ends, you will hear 3 beeps.
AUTO START
Auto start can be programmed for up to two cooking stages.
Auto start can not be programmed for auto defrost.
1. Program the desired power level and cooking time for food to be cooked.
2. Touch CLOCK/A.START pad.
3. Enter the desired start time by pressing the
number.
4. Touch START pad.
When you touch START pad, the present time appears in the display and the cooking program
indicators come on. The AUTO START indicator and the colon start blinking. When the selected start
time arrive, the oven begins operating and the oven light turns on. The AUTO START indicator goes
off and the next stage indicator begins to blink. When the cooking is completed you will hear 3 beeps.
The oven turns off and the present time appears in the display.
12
The STAGE2 indicator lights and “p-”is
displayed.
The display will show what you touched.
The display will show the numbers you
pressed in the order you touched.
The AUTO START indicator lights and
“: 0 ”is displayed.
The display will show the numbers you
press pads in the order you touched.
POWERPOWER
CLOCK/
A.START
NOTE : AUTO START can be used for time cooking, if the clock is set. If the oven door is opened
after programming AUTO START, it is necessary to touch the START pad for the time of
day to appear in the readout so that the oven will automatically begin programmed
cooking at the chosen AUTO START time.
Before setting, check to make sure the clock is showing the correct time of day.
KOR-611Q0A(¿ )02.2.1912:30PM˘`12

TO CHECK AUTO START TIME
Once you have correctly programmed the oven for AUTO START, the present time will appear on the
display.
1. Touch CLOCK/A.START pad.
SPEEDY COOK
SPEEDY COOK allows you to reheat for 30 seconds at 100% (full power) by simply touching the
SPEEDY COOK pad.
By repeatedly touching the SPEEDY COOK pad, you can also extend reheating time to 5 minutes in
30 second increments.
1. Touch SPEEDY COOK pad.
ONE TOUCH COOKING
One touch cook allows you to cook or reheat many of your favorite foods by touching just one pad.
To increase quantity, touch chosen pad until number in display is same as desired quantity to cook.
(except for MUFFIN & DINNER PLATE)
1. Touch POPCORN pad once
for a 3.5 oz bag or twice for a
1.75 oz bag.
13
The programmed AUTO START time will
appear on the display for 3 seconds.
When you touch SPEEDY COOK, “: 30 ”is
displayed.
After 1.5 seconds, the oven starts
reheating.
When you touch POPCORN pad once,
“3.5”is displayed.
After 1.5 seconds, the display shows the
cooking time and the oven starts cooking.
CLOCK/
A.START
SPEEDY
COOK
POPCORN
*POPCORN*
•3.5 oz : Touch POPCORN once.
•1.75 oz : Touch POPCORN twice within 1.5 seconds.
NOTE : 1. Use prepackaged room-temperature microwave popcorn.
2. Place bag in oven according to manufacturer’s directions.
3. Pop only one bag at a time.
4.After popping, open bag carefully, popcorn and steam are extremely hot.
5. Do not reheat unpopped kernels or reuse bag.
6. Do not leave oven unattended while popping popcorn.
CAUTION : If prepackged popcorn is of a different weight then the recommended weight, do not
use the popcorn pad. Follow the manufacturer instruction.
KOR-611Q0A(¿ )02.2.1912:30PM˘`13

ONE TOUCH COOKING(CONTINUED)
1. Touch FROZEN PIZZA pad
once for a 7 oz pizza or twice
for a 10 oz pizza.
1. Touch BEVERAGE pad once
for 1 cup, twice for 2 cups or
three times for 3 cups.
1. Touch DINNER PLATE pad
once for an 11 oz dinner plate
of food.
1. Touch MUFFIN pad once to
cook 5 muffins.
14
*FROZEN PIZZA*
•7 oz : Touch FROZEN PIZZA once.
•10 oz : Touch FROZEN PIZZA twice within 1.5 seconds.
*BEVERAGE* (250ml/cup)
•1 cup (mug) : Touch BEVERAGE once.
•2 cups (mugs) : Touch BEVERAGE twice within 1.5 seconds.
•3 cups (mugs) : Touch BEVERAGE three times within 1.5 seconds.
NOTE: 1. Use only one frozen pizza at a time
2. Use only frozen pizza made for microwave ovens.
3. If the cheese of frozen pizza does not melt sufficiently, cook a few seconds longer.
4. Some brands of frozen pizza may require more or less cooking time.
NOTE: 1. This setting is good for restoring cooled beverage to a better drinking temperature.
2. Stir after cooking.
FROZEN
PIZZA
DINNER
PLATE
MUFFIN
BEVERAGE
When you touch FROZEN PIZZA pad
once, “7”is displayed.
After 1.5 seconds, the display shows the
cooking time and the oven starts cooking.
When you touch BEVERAGE pad once, “1’
is displayed.
After 1.5 seconds, the display changes into
cooking time for quantity and the oven
starts cooking.
When you touch DINNER PLATE pad
once, “11”is displayed.
After 1.5 seconds, the display shows
cooking time and the oven starts cooking.
When you touch MUFFIN pad, “5”is
displayed. After 1.5 seconds, the display
shows the cooking time and the oven starts
cooking.
KOR-611Q0A(¿ )02.2.1912:30PM˘`14

ONE TOUCH COOKING (CONTINUED)
1. Touch SOUP pad once for a 8
oz soup or twice for a 12 oz.
1. Touch FRESH VEGETABLE
pad once for a 8 oz of fresh
vegetable or twice for 12 oz of
fresh vegetable.
1. Touch BAKED POTATO pad
once for each 5.5 oz ~ 6.5 oz
baked potato.
MORE, LESS
MORE pad : adds 10 seconds to 20 secods.
LESS pad : removes 10 seconds to 20 seconds.
This pad only works with one touch cooking.
Always input prior to one touch sequence.
15
*SOUP*
•8 oz : Touch SOUP once.
•12 oz : Touch SOUP twice within 1.5 seconds.
*FRESH VEGETABLE*
•8 oz : Touch FRESH VEGETABLE once.
•12 oz : Touch FRESH VEGETABLE twice within 1.5 seconds.
*BAKED POTATO*(5.5 OZ~6.5OZ/EA.)
•1 NO (ea.) : Touch BAKED POTATO once.
•2 NO (ea.) : Touch BAKED POTATO twice within 1.5 seconds.
•3 NO (ea.) : Touch BAKED POTATO three times within 1.5 seconds.
NOTE : For best results, consult the cookbook.
When you touch SOUP pad once, “8”is
displayed. After 1.5 seconds, the display
shows the cooking time and the oven starts
cooking.
When you touch FRESH VEGETABLE pad
once, “8”is displayed.
After 1.5 seconds, the display shows the
cooking time and the oven starts cooking.
When you touch BAKED POTATO pad
once, “1”is displayed,
After 1.5 seconds, the display shows
cooking time and the oven starts cooking.
SOUP
FRESH
VEGETABLE
BAKED
POTATO
KOR-611Q0A(¿ )02.2.1912:30PM˘`15

CHILD SAFETY LOCK
The safety lock prevents unwanted oven operation such as by small children.
To set, press and hold STOP/CLEAR for 3 seconds, LOCK indicator lights.
To cancel, press and hold STOP/CLEAR for 3 seconds, LOCK indicator goes off.
TO STOP THE OVEN WHILE THE OVEN IS OPERATING
1. Press STOP/CLEAR pad.
•You can restart the oven by touching START pad.
•Touch STOP/CLEAR once more to erase all instructions.
•You must enter in new instructions.
2. Open the door.
•You can restart the oven by closing the door and touching START.
MICROWAVE UTENSILS
Glass, Ceramic and China
Ovenproof glass or ceramic baking dishes are the most used microwave utensils.
Many of these items are readily available in most homes : glass measures, custard cups, mixing
bowls, covered casseroles, pie plates and round or square cake dishes. Ovenproof dinner ware is
usually safe to use in the microwave.
Do not heat or cook in glass jars or bottles.
Do not use dishes with silver, gold, platinum or other metal trim. Arcing may occur and /or the dish
may break.
Do not use delicate or stemmed glassware. Although the glass may be transparent to microwave
energy, heat from the food may cause the glassware to crack.
16
NOTE : Oven stops operating when door is opened.
UTENSIL TEST Dishes that do not absorb microwave energy are best for microwave
cooking. Lock on the label to verify that particular cups, glasses,
plates are indeed suitable, especially paper goods. If you are not
sure, try this utensil test to check.
•Put the empty utensil in the microwave oven.
•Put one cup of water in a glass measure next to the empty utensil.
•Heat on HI for 1 minute.
•After 1 minute the water should be warm but the utensil should not.
If the utensil is warm, it is not suitable for microwave cooking.
KOR-611Q0A(¿ )02.2.1912:30PM˘`16

Plastics
Plastic dishes, cups, mugs and bowls may be used in the oven for short periods of time. None of
these should be used in the oven for prolonged periods because distortion and melting may occur.
Check manufacturer’s recommendations concerning microwave safety.
Plastic wrap can be used to cover dishes in most recipes if the dish is deep enough to avoid plastic
wrap touching the food. Always vent the wrap by folding back one corner to allow excess steam to
escape.
Plastic cooking bags should be slit before cooking so excess steam can escape,
Do not use wire twist ties to close the bag. Wire twist ties can cause arcing which can damage the
oven.
Paper
Paper cups, wax paper, napkins, paper towels, and plates may be used for short cooking. Prolonged
time in the oven can cause paper to burn. Do not use recycled paper products, such as brown paper
bags.
They contain impurities which may cause arcing and damage the oven.
Metal
Metal utensils should not be used in the oven. Metal reflects microwave energy so foods will not cook
so foods will not cook evenly.
Metal can cause arcing and damage the oven.
17
KOR-611Q0A(¿ )02.2.1912:30PM˘`17

CARE OF YOUR MICROWAVE OVEN
18
1. Turn the oven off before cleaning.
2. Keep the inside of the oven clean.
When food spatters or spilled liquids
adhere to oven walls, wipe with a damp
cloth.
Mild detergent may be used if the oven gets
very dirty. The use of harsh detergent or
abrasives is not recommended.
3. The outside oven surface should be
cleaned with soap and water, rinsed and
dried with a soft cloth.
To prevent damage to the operating parts
inside the oven, water should not be
allowed to seep into the ventilation
openings.
4. If the Control Panel becomes wet, clean
with a soft, dry cloth. Do not use harsh
detergents or abrasives on Control Panel.
5. If steam accumulates inside or around the
outside of the oven door, wipe with a soft
cloth. This may occur when the microwave
oven is operated under high humidity
conditions and in no way indicates
malfunction of the unit.
6. It is occasionally necessary to remove the
glass tray for cleaning. Wash the tray in
warm sudsy water or in a dishwasher.
7. The roller guide and oven cavity floor
should be cleaned regularly to avoid
excessive noise.
Simply wipe the bottom surface of the oven
with mild detergent water or window
cleaner and dry. The roller guide may be
washed in mild sudsy water.
1. The ROLLER GUIDE and oven floor
should be cleaned frequently to
prevent excessive noise.
2. The ROLLER GUIDE MUST ALWAYS
be used for cooking together with the
Glass Tray.
1. DO NOT operate the oven without the
Glass Tray in place.
2. DO NOT use any other Glass Tray
with this oven.
3. If Glass Tray is hot, ALLOW TO COOL
before cleaning or placing it in water.
4. DO NOT cook directly on the Glass
Tray.
ROLLER GUIDE
GLASS TRAY
Glass Tray Roller Guide
KOR-611Q0A(¿ )02.2.1912:30PM˘`18

USE YOUR MICROWAVE OVEN SAFELY
General Use
Do not attempt to defeat or tamper with safety interlocks.
Do not place any object between the oven front frame and the door or allow residue to build up on
sealing surfaces. Wipe with a mild detergent, rinse and dry. Never use abrasive powders or pads.
Do not subject the oven door strain or weight such as a child hanging on an open door.
This could cause the oven to fall forward resulting in injury to you and damage to the oven.
Do not operate the oven if door seals or sealing surfaces are damaged, or if door is bent, or if hinges
are loose or broken.
Do not operate the oven empty. This will damage the oven.
Do not attempt to dry clothes, newspapers or other materials in the oven. They may catch on fire.
Do not use recycled paper products as they may contain impurities which may cause sparks or fires.
Do not hit or strike the control panel with hard objects. This can damage the oven.
Food
Never use your microwave oven for home canning. The oven is not designed for proper home
canning.
Improperly canned food may spoil and be dangerous to consume.
Always use the minimum recipe cooking time. It is better to undercook rather than over cook foods.
Undercooked foods can be returned to the oven for more cooking. If food is overcooked, nothing can
be done.
Heat small quantities of food or foods with low moisture carefully. These can quickly dry out, burn or
catch on fire.
Do not heat eggs in the shell. Pressure may build up and eggs can explode.
Potatoes, apples, egg yolks and sausages are examples of food with non-porous skins.
These must be pierced before cooking to prevent bursting.
Do not attempt to deep fat fry in your microwave oven.
Always stir liquids before heating. Heated liquids can erupt, if not mixed with air.
Do not pop popcorn in a paper bag unless it is the commercially prepared Microwave Popcorn
product.
The kernels can overheat and ignite a brown paper bag.
Do not exceed the Microwave Popcorn manufacturers’suggested popping time. Longer popping
does not yield more popcorn but it can result in scorch burn of fire. Remember, the popcorn bag and
tray can be too hot to handle. Remove with caution and use pot holders.
19
KOR-611Q0A(¿ )02.2.1912:30PM˘`19
