Daktronics All sport 5500 series User manual

201 Daktronics Drive

Brookings, SD 57006-5128

www.daktronics.com/support

800.325.8766

ALL SPORT®5500 SERIES

CONTROL CONSOLE

OPERATION MANUAL

P1389

ED-16809

Rev 9

9 February 2018

responsibility for errors or omissions. No part of this book covered by the copyrights hereon may be reproduced or copied

in any form or by any means—graphic, electronic, or mechanical, including photocopying, taping, or information

storage and retrieval systems—without written permission of the publisher.

Daktronics trademarks are property of Daktronics, Inc. All other trademarks are property of their respective companies.

– i –

Table of Contents

1 Introduction��1

Important Safeguards ...............................1

Specications Label ..................................2

Resources ...................................................2

Console Revision History............................2

Daktronics Exchange and Repair &

Return Programs ........................................2

Exchange Program ��2

Repair & Return Program ��3

Daktronics Warranty & Limitation of

Liability��3

2 Basic Operation ��4

Console Operation....................................4

Sport Inserts.................................................5

Start Up .......................................................6

Standard Keys ............................................6

Start ��6

Stop��6

Enter/Yes ��6

Clear/No��7

Edit ��7

Menu ��7

Set Main Clock ��7

Count Up/Down ��8

Auto Horn ��9

Manual Horn ��9

Remote Start/Stop Controls......................9

Main Clock Control ��9

Shot Clock Control ��9

Setting Radio Channels ..........................10

Single Controller System ��11

Multiple Controller System with Single

Broadcast Group ��12

Multiple Controller with Multiple

Broadcast Groups��13

Menu.........................................................14

New Game��14

New Code ��15

Dimming Menu ��15

Display Menu ��15

Color Menu ��16

Time of Day ��17

Switch Output��18

General Multi-Purpose Timer ..................18

Standard Keys��18

Segment Timer ��18

Team Name Entry ....................................19

WIDTH��19

HEIGHT ��19

FONT��19

3 Segment Timer Operation��20

Segment Timer Overview........................20

Accessing Segment Timer ......................20

Accessing 2-Digit or 6-Digit Display

Segment Timer .........................................21

Segment Timer Keys ................................21

Segment Number & Time��21

First Segment��21

Last Segment��22

Interval Time��22

Display Interval ��22

Copy Range��22

Auto Stop��23

Reset to First��23

Reset Current Segment ��23

Current Segment ��23

Edit.............................................................23

Current Segment ��23

Menu.........................................................23

New Code ��24

Warning Time ��24

Dimming Menu ��24

Default Settings ��24

4 Basketball Operation ��25

Basketball Keys.........................................25

Set Shot Time��25

Recall Shot Time ��26

Time Out On/Off��26

Blank Player Foul ��26

Period +1 ��27

Time Out ��27

Score (+1/+2/+3/-1) ��27

Team Fouls (+1/-1) ��28

Bonus ��29

Possession ��29

– ii –

Table of Contents

In Game/Out of Game ��29

Delete Player��29

Player��29

Individual Substitution ��30

Mass Substitution ��31

Edit.............................................................31

Time Out ��31

Score (+1/+2/+3/-1) ��32

Team Fouls (+1/-1) ��32

Period +1 ��32

Time Out On/Off��32

Menu.........................................................33

New Game��33

New Code ��33

Dimming Menu ��33

Home Roster, Guest Roster ��33

Display Menu ��34

Color Menu ��34

Time of Day ��34

Edit Settings ..............................................35

Number of Periods��35

Main Clock��35

Shot Clock��36

Time Outs��36

Team Score ��37

Team Fouls ��37

Select Captions ��38

Select Team Foul Display��38

Score by Quarter ��38

Shot Horn Control��38

Light Control��38

Switch Output��39

Default Settings ��39

5 Volleyball Operation��40

Volleyball Keys .........................................40

Time Out On/Off��40

Time Out ��41

Match Number +1, Sets +1 ��41

Score (+1/-1)��41

Sets Won +1, Subs +1��42

Aces +1, Kills +1, Blocks +1, Digs +1 ��42

Serve��42

In Game/Out of Game ��43

Delete Player��43

Player��43

Individual Substitution ��44

Mass Substitution ��45

Edit.............................................................45

Time Out ��45

Score (+1/-1)��46

Match Number +1, Sets +1 ��46

Sets Won +1, Subs +1��46

Aces +1, Kills +1, Blocks +1, Digs +1 ��46

Time Out On/Off��46

Menu.........................................................47

New Game��47

New Code ��47

Dimming Menu ��47

Home Roster, Guest Roster ��47

Display Menu ��49

Color Menu ��49

Time of Day ��49

Edit Settings ..............................................49

Main Clock��49

Time Outs��49

Team Stats ��50

User Def 1 & User Def 2 .....................50

Select Captions ��51

Shot Horn Control��51

Light Control��51

Switch Output��51

Default Settings ��52

6 Wrestling Operation��53

Wrestling Keys...........................................53

Match Number +1 ��53

Period +1 ��53

Set Main Clock (Period Times) ��54

Home Advantage, Guest Advantage,

Stop Advantage Clock ��54

Team Score (+1/-1) ��55

Match Score (+1/+2/+3/-1) ��55

Start/Stop Injury Time ��55

Reset Match ��56

Start/Stop Blood Time��56

– iii –

Table of Contents

Start/Stop Recovery Time ��57

Edit.............................................................57

Home Advantage��57

Guest Advantage��57

Blood Time��58

Injury Time ��58

Match Number, Period, Team Score,

Match Score��58

Menu.........................................................58

New Game��58

New Code ��58

Dimming Menu ��59

Home Roster, Guest Roster ��59

Weight Class ��60

Display Menu ��60

Color Menu ��60

Time of Day ��60

Edit Settings ..............................................60

Main Clock��60

Blood/Injury Time��61

Recovery Time ��61

Select Captions ��62

Weight Class ��62

Display Lines for Weight Class ��62

Display Team Score��62

Shot Horn Control��62

Light Control��63

Switch Output��63

Default Settings ��63

A Reference Drawings ��65

B Sport Inserts ��77

C Sport Code Numbers��85

D Quick Reference��87

All Sport 5500 Standard Keys..................87

Segment Timer .........................................88

Basketball .................................................89

Volleyball ..................................................90

Wrestling ...................................................91

E Supplementary Documents��93

F Daktronics Warranty and Limitation

of Liability��99

This page intentionally left blank.

Introduction

1 Introduction

This manual explains the operation of All Sport®5500 series control consoles. For

additional information regarding the safety, installation, operation, or service of this

system, refer to the telephone numbers listed in Daktronics Exchange and Repair & Return

Programs (p� 2).

Important Safeguards

• Read and understand all instructions, both general and for specic sports.

• Always turn off and/or unplug the control equipment when it is not in use� Never yank

the power cord to pull the plug from the outlet� Grasp the plug and pull to disconnect�

• Do not drop the control console or allow it to get wet�

• This device shall not be exposed to dripping or splashing, and no objects lled with

liquid shall be placed upon it�

WARNING! To reduce the risk of re or electric shock, do not expose this device to

rain or moisture�

• Console may include internal battery backup, or external battery pack�

CAUTION! DANGER OF EXPLOSION IF BATTERY IS INCORRECTLY REPLACED�

REPLACE ONLY WITH THE SAME OR EQUIVALENT TYPE�

WARNING! Do not expose batteries to excessive heat, such as direct sunlight or re.

• Do not let the power cord touch hot surfaces or hang over the edge of a table that

would damage or cut the cord�

• If an extension cord is necessary, use a three-pronged, polarized cord� Arrange the

cord with care so that it will not be tripped over or pulled out�

• Before using an extension cord, inspect the cable thoroughly and verify its

compliance with the local electric codes�

• Do not disassemble control equipment or electronic controls of the display; failure to

follow this safeguard will make the warranty null and void�

• Inspect console for shipping damage such as rattles and dents, and verify that all

equipment is included as itemized on the packing slip� Immediately report any

problems to Daktronics; save all packing materials if exchange is necessary�

All Sport consoles receive external power through a standard 8’ (2.44 m) long three-

pronged power cord plugged into a 120 VAC grounded outlet. The outlet shall be

installed near the console and easily accessible. Contact Daktronics for information on

running an All Sport console via optional battery power pack.

Note: The console features an internal time delay 1/8 amp, 250 V fuse. In the unlikely

event the fuse needs to be replaced, contact Daktronics Customer Service.

Introduction

Specications Label

Power specications as well as product assembly information can be found on the rear

of the console. When calling Daktronics customer service, please have the assembly

number and the date manufactured available to ensure the request is serviced as

quickly as possible.

Resources

Figure 1 illustrates a Daktronics drawing

label. This manual refers to drawings by

listing the last set of digits. In the example,

the drawing would be referred to as

DWG-1007804. All references to drawing

numbers, appendices, gures, or other

manuals are presented in bold typeface.

Any drawings referenced in a particular

section are listed at the beginning of it as

shown below:

Reference Drawing:

System Riser Diagram....................................................................................... DWG-1007804

Daktronics identies manuals by the DD or ED number located on the cover page.

Console Revision History

For a complete history of revisions to the console rmware, refer to All Sport & OmniSport

Revision Histories (DD3679410), available online at www.daktronics.com/manuals.

Daktronics Exchange and Repair & Return Programs

Exchange Program

The Daktronics Exchange Program is a service for quickly replacing key components

in need of repair. If a component fails, Daktronics sends a replacement part to the

customer who, in turn, returns the failed component to Daktronics. This decreases

equipment downtime. Customers who follow the program guidelines explained below

will receive this service.

Before contacting Daktronics, identify these important numbers:

Assembly Number: ___________________________________________________________________

Job/Contract Number: _______________________________________________________________

Date Manufactured/Installed: _________________________________________________________

Daktronics Customer ID Number: ______________________________________________________

To participate in the Exchange Program, follow these steps:

1� Call Daktronics Customer Service�

Market Description Customer Service Number

Schools (including community/junior colleges), religious

organizations, municipal clubs, and community centers

877-605-1115

Fax: 605-697-4444

Universities and professional sporting events, live events for

auditoriums, and arenas

866-343-6018

Fax: 605-697-4444

Drawing Number

Figure 1: Drawing Label

Introduction

2� When the new exchange part is received, mail the old part to Daktronics�

If the replacement part xes the problem, send in the problem part being replaced.

a� Package the old part in the same shipping materials in which the replacement

part arrived.

b� Fill out and attach the enclosed UPS shipping document.

c� Ship the part to Daktronics.

3� The defective or unused parts must be returned to Daktronics within 5 weeks of initial

order shipment�

If any part is not returned within ve (5) weeks, a non-refundable invoice will be

presented to the customer for the costs of replenishing the exchange parts inventory

with a new part. Daktronics reserves the right to refuse parts that have been

damaged due to acts of nature or causes other than normal wear and tear.

Repair & Return Program

For items not subject to exchange, Daktronics offers a Repair & Return Program. To send

a part for repair, follow these steps:

1� Call or fax Daktronics Customer Service�

Refer to the appropriate number in the chart on the previous page.

2� Receive a case number before shipping�

This expedites repair of the part.

3� Package and pad the item carefully to prevent damage during shipment�

Electronic components, such as printed circuit boards, should be placed in an

antistatic bag before boxing. Daktronics does not recommend using packing

peanuts when shipping.

4� Enclose:

• name

• address

• phone number

• the case number

• a clear description of symptoms

5� Ship to:

Daktronics Customer Service

[Case #]

201 Daktronics Drive, Dock E

Brookings, SD 57006

Daktronics Warranty & Limitation of Liability

The Daktronics Warranty & Limitation of Liability is located at the end of this manual. The

Warranty is independent of Extended Service agreements and is the authority in matters

of service, repair, and display operation.

Basic Operation

2 Basic Operation

Console Operation

The console face consists of a 2-line by 16-character liquid crystal display (LCD), number/

menu keypads, horn/clock controls with LED status indicators, and an area for a sport-

specic insert. Refer to Figure 2 to locate these components on the control console face.

In most cases, the top line of the LCD shows the main clock time, direction the clock is

counting, and when the main horn is sounding, while the bottom line typically shows the

HOME and GUEST team scores.

The standard xed keys and functions on the right side of the console are explained in

Standard Keys (p� 6). All of the keys that pertain to a specic sport code insert are

explained in detail in their respective sport section.

In addition, Quick References and Menu Flowcharts for the Standard Keys and many of

the more common individual sports are provided in Appendix D.

Throughout this manual, the names or letters of keys on the keypad are enclosed in

angle brackets (such as <ENTER>).

LCD

Horn

Control

Navigation

Clock

Control

Number

Keypad

Sport-Speciﬁ c Insert

LCD

Horn

Control

Navigation

Clock

Control

Number

Keypad

Sport-Speciﬁ c Insert

LCD

Sport-

Speciﬁ c

Insert

LCD

Figure 2: All Sport 5500 Layout

Table of contents

Other Daktronics Music Mixer manuals
