dallmeier DDF3000A3 Operating and maintenance instructions

Installation and Configuration
Mini Fixed Dome
Color Video Camera
DDF3000A3(-DN)
DDF3000A3(-DN)
(Casino version)
Rev. 1.1.0 / 070702
English

2
DDF3000A3(-DN) / DDF3000A3(-DN) (Casino Version)
DallmeierelectronicGmbH&Co.KG
Copyright © Dallmeier electronic GmbH & Co.KG
All rights reserved. This document may not be copied,
photocopied,reproduced,translated,transferredtoanelectronic
medium or converted to a machine-readable form either whole
orinpartwithout first receiving written permission from Dallmeier
electronic GmbH & Co.KG.
We reserve the right to make technical modifications.
The manufacturer accepts no liability for damage to property or
pecuniary damages arising due to minor defects of the product
or documentation, e.g. print or spelling errors, and for those not
caused by intention or gross negligence of the manufacturer.
Dallmeier electronic GmbH & Co.KG
Cranachweg 1
D 93051 Regensburg, Germany
www.dallmeier-electronic.com
[email protected]

3
DallmeierelectronicGmbH&Co.KG
Table of contents
1 About this document .......................................................................... 5
1.1 Validity................................................................................................... 5
1.2 DocumentationforDDF3000A3 ............................................................ 5
1.3 Convention ............................................................................................ 5
2 For your safety.................................................................................... 7
3 General instructions ......................................................................... 11
3.1 Scopeofsupply................................................................................... 11
3.2 Transportationandpackaging.............................................................. 11
3.3 Approveduse ...................................................................................... 11
3.4 Features .............................................................................................. 11
3.5 Certificates .......................................................................................... 12
3.6 Warranty ............................................................................................. 12
4 Notes on operating the camera........................................................ 13
5 Viewing and connecting up.............................................................. 15
5.1 Viewing ............................................................................................... 15
5.2 Connectingup ..................................................................................... 15
6 Installation ......................................................................................... 17
6.1 Requirementsatthe installationsite .................................................... 17
6.2 Assembly ............................................................................................ 17
6.3 Settingup and adjustment ................................................................... 18
6.4 Closingthehousing ............................................................................. 20
7 Preparing to configure...................................................................... 21
7.1 UTCRemoteBox ................................................................................ 21
7.2 DMSRecorder .................................................................................... 22
7.3 PView .................................................................................................. 23
8 Configuration .................................................................................... 25
8.1 Presets................................................................................................ 26
8.2 Basic Functions .................................................................................. 29
8.2.1 CameraID ........................................................................................... 29
8.2.2 CCTVSystem ..................................................................................... 29
8.2.3 HorizontalFlip ..................................................................................... 31
8.2.4 LensSelect ......................................................................................... 31
8.2.5 Color ................................................................................................... 31
8.2.6 Day / Night Setup ................................................................................ 32
8.3 ImageFunctions.................................................................................. 33
8.3.1 Progressive Scan ................................................................................ 33
8.3.2 Backlight ............................................................................................. 33
8.3.3 DigitalZoom ........................................................................................ 34
8.3.4 WhiteBalance..................................................................................... 35
8.4 ExitMenu ............................................................................................ 36

4
DDF3000A3(-DN) / DDF3000A3(-DN) (Casino Version)
DallmeierelectronicGmbH&Co.KG
A Appendix ........................................................................................... 37
A1 Menustructure .................................................................................... 37
A2 Dimensions ......................................................................................... 38
A3 TechnicalData..................................................................................... 39

5
DallmeierelectronicGmbH&Co.KG
1 About this document
1.1 Validity
This document applies to the DDF3000A3(-DN) / DDF3000A3(-DN)
(Casino version) Mini Dome Color Camera. It has been procuded
on the basis of version 1.7 (software).
The descriptions in this document apply to both cameras. For
simplification reasons, the term „DDF3000A3“ is thus used for all
cameras.
1.2 Documentation for DDF3000A3
Start-up
The Quick Guide headed „Comissioning“ lists the most important
steps for the assembly, connection and commissioning of the
camera.
Installation and configuration (this document)
The instructions „Installation and configuration“ contains detailed
descriptions of the assembly, connection, commissioning and
configuration of the camera. You will also find general product
information and technical data in this section.
Storing the documents
Store the operating instructions in an accessible location near the
product and keep it in readable condition.
Ensurethatall documentationis passedontoany subsequent owner
or user of the system.
1.3 Convention
This document contains various warning words and symbols that
indicate potential sources of danger. Various symbols and formats
are used to maintain the clarity of the document.

6
DDF3000A3(-DN) / DDF3000A3(-DN) (Casino Version)
DallmeierelectronicGmbH&Co.KG
DANGER
The warning word DANGER denotes an immedi-
ate danger that may cause death or serious
injury if it is not averted.
WARNING
The warning word WARNING denotes a possible
danger that may cause death or serious injury
if it is not averted.
CAUTION
The warning word CAUTION denotes a possible
danger that may cause minor injury if it is not
averted.
IMPORTANT
The word IMPORTANT denotes information for
preventing damage, incorrect configurations or
incorrect actions.
NOTE
A NOTE offers information on principles, special
featuresandefficientprocedure as wellasgeneral
recommendations.
Expression Expressions in bold and italics generally indicate
acontrol elementonthe device(switchesorlabels)
or on its user interface (buttons, menu entries).

7
DallmeierelectronicGmbH&Co.KG
2 For your safety
Only use this unit if it is technically in proper working order, to the
intended purpose and while keeping safety and potential dangers
in mind. Have malfunctions or damages eliminated immediately!
Appoint a professional
Installation, mounting, connection, start-up and configuration of
the unit may only be carried out by trained and authorized
professionals (installers).
Unless otherwise expressly specified, this also applies to the
maintenance, testing and repair.
Read and pay attention to the documents
Carefully and completely read the documents included in delivery.
Always pay attention to the provided instructions, notes and
warnings.
Regulations surveillance systems
Theuseofvideoand audio surveillance systems is strictly regulated
inmostcountries.Therefore, inform yourselfonlawsand regulations
that govern individual applications before using the unit. Ensure
compliance with these laws and regulations and also observe
regulations regarding data, working and environmental protection.
Do not make modifications
Do not make any modifications to the unit (neither to the software
nor the hardware) without consulting Dallmeier electronic. Improper
modifications can cause malfunctions or damages. Dallmeier
electronic accepts no liability for damages resulting from
unauthorized or improper modifications to the unit.
Protection against condensation water
If the unit is brought from a cold to a warm environment,
condensation water can form inside the unit. Short-circuits may
then lead to damage to the system. Wait up to 8 hours for the unit
to reach room temperature before starting it up.

8
DDF3000A3(-DN) / DDF3000A3(-DN) (Casino Version)
DallmeierelectronicGmbH&Co.KG
Observe the rated voltage
The unit can be damaged or destroyed by the application of an
incorrect voltage.
The mains voltage must always match the rated voltage of the
unit. The rated voltage is specified on the rating plate of the unit.
Observe ratings
Unsuitable ambient conditions and improper installation (mainly
too high ambient temperature and insufficient ventilation) may
reduce the unit’s life cycle. Ensure compliance with the stated
operating conditions (see technical data), requirements at the
installation site and, if applicable, maintenance regulations.
Expansion components/peripheral devices
Use only expansion components conforming with the technical data
of the unit. Inappropriate peripheral devices may result in the
violation of local laws and regulations and damages to the unit.
Furthermore, the use of peripheral devices that are not tested and
approved by Dallmeier electronic results in loss of warranty. In case
of doubt, contact the sales partner responsible for your area.
Do not open the unit
Do not open the housing of the unit. There are no components
insidetheunitthatrequiremaintenancebytheuser.The inspection,
maintenance and repair with an open housing must only be carried
out by trained and authorized professionals (installer).
Penetration of foreign bodies and liquids
No objects or liquids may be allowed to get into the device. In this
case, immediately disconnect the unit from the power supply (pull
out the power plug). Please contact the sales partner responsible
for your area.
Measures to be taken in the event of damage and burnt
smell
If you notice burnt smell or formation of smoke from a unit,
immediately disconnect it from the power supply (pull out the po-
wer plug). Please contact the sales partner responsible for your
area.

9
DallmeierelectronicGmbH&Co.KG
Disposal
Disconnect the unit from the power supply. Remove all connected
units and system components. Return the unit to your respective
sales partner.

10
DDF3000A3(-DN) / DDF3000A3(-DN) (Casino Version)
DallmeierelectronicGmbH&Co.KG

11
DallmeierelectronicGmbH&Co.KG
3 General instructions
3.1 Scope of supply
Included in the scope of supply:
1 x DDF3000A3 Camera
2 x Screws and pins
1 x Cable (power supply/video)
1 x CD with user documentation
1 x Quick guide “Commissioning“
1 x Drilling template
3.2 Transportation and packaging
Store the original packaging for transportation at a later date.
Dallmeier electronic is not responsible for damage resulting from
unprofessional/improper transportation.
Shipping should only occur in the original packaging.
If the original packaging is no longer available, ensure that the
packaging used sufficiently protects the unit against damage,
moisture, heat and cold.
3.3 Approved use
The DDF3000A3 is a Mini Fixed Dome Video Camera for color or
b/w imaging. It is designed for indoor use.
3.4 Features
The DDF3000A3 offers a resolution of 540 TV lines and a volume
range of 120 dB maximum. Its light sensitivity and individual
exposure strategy on pixel level allow images with greater color
neutrality and clarity of detail, even at low light levels. Designed to
be free from glare, the camera permits detailed recognition even
against extreme back lighting.
The DDF3000A3 also offers:
zDetailed reproduction of the highest quality for bright spots as
well as in shaded areas using UWDR.

12
DDF3000A3(-DN) / DDF3000A3(-DN) (Casino Version)
DallmeierelectronicGmbH&Co.KG
zSuppression of all smearing and blooming effects.
zZoom with increased resolution using the special Progressive
Scan Process.
zProgressive Scan Process prevents movement artifacts.
zConfiguration via the video cable using a Dallmeier Recorder
(DMS Series), Software PView or via the UTC Remote Box.
zFactory settings suitable for many scenarios with varying light
conditions (Presets).
NOTE
For detailed information, please see Technical
Data in the Appendix.
3.5 Certificates
Thefollowing certifications wereineffect fortheDDF3000A3 camera
at the time this document was produced:
zCE
zFCC
zC-Tick
3.6 Warranty
The warranty period is 36 months.
The terms and conditions valid at the signing of the contract apply.

13
DallmeierelectronicGmbH&Co.KG
4 Notes on operating the camera
The camera can be operated at 12V DC or 24V AC (with
optionally available voltage adapter only).
If the camera or the cable connected to the cable is located near
sources of strong radiation, the video picture may be distorted.
The camera is equipped with automatic gain control (AGC). In
low light the picture may be altered (e.g. noise). This is not a
camera malfunction.
The quality of the video picture depends on the lens used, the
lighting and the monitor used to display the video picture.
Automatic white balance depends on the lighting used and can
cause color distortions in artificial light.
Poor lighting can lead to faulty white balance.

14
DDF3000A3(-DN) / DDF3000A3(-DN) (Casino Version)
DallmeierelectronicGmbH&Co.KG

15
DallmeierelectronicGmbH&Co.KG
5 Viewing and connecting up
5.1 Viewing
5.2 Connecting up
Fig. 5-1
Fig. 5-2
Housingring
Plexiglasdome
Cameramount
Camerasupport
Cameramodule Housingbase
plate
Video
Ground(black)
+12V (red)

16
DDF3000A3(-DN) / DDF3000A3(-DN) (Casino Version)
DallmeierelectronicGmbH&Co.KG

17
DallmeierelectronicGmbH&Co.KG
6 Installation
6.1 Requirements at the installation site
The DDF3000A3 is designed for indoor use. Unfavorable local
conditions may shorten the life of the product or lead to
malfunctions.
Do not install/operate the camera in places:
zwith large scale dust and dirt
zwith steam or oil vapors (e.g. kitchen)
zif placed in direct sunlight
zwith an ambient temperature below 0 °C or above 50 °C.
znear sources of strong radiation, i.e. X-rays, radio transmitters
or magnetic fields
zwith corrosive surroundings (e.g. gases or salt water)
6.2 Assembly
Use the template included for mounting the camera.
1. Makeanincision in thecenterofthe film.
2. Guide the cables suspended from the
wall/ceiling through the film.
3. Position the film with respect to the
subsequent camera position.
4. Adhere the film using a minimum of
pressure.
5. Mark the drill holes for the securing
screws.
6. Carefully peel off the film.
7. Drill the holes for the securing screws.
8. Connect the power supply/video cable.
Fig. 6-1

18
DDF3000A3(-DN) / DDF3000A3(-DN) (Casino Version)
DallmeierelectronicGmbH&Co.KG
6.3 Setting up and adjustment
1. Connect the camera to a
monitor for alignment
purposes using the Video
Preview output.
Fig. 6-3
WARNING
Danger of death from lightening strike.
Do not connect the power supply/video cable
during a thunderstorm.
9. Fix the housing base plate to
the wall or to the ceiling.
Fig. 6-2
Fig. 6-4
Ground(black)
+12V (red)
Video

19
DallmeierelectronicGmbH&Co.KG
IMPORTANT
Possible damage or malfunction caused by pulled
plugs or jammed/kinked cables.
Proceed with caution when aligning and adjusting
the camera. Do not use any force.
2. Align the camera.
3. Set the focal distance (A)
and focus (B).
Secure rings (A) and (B) using screws (C) after adjustment.
Fig. 6-5
Fig. 6-6

20
DDF3000A3(-DN) / DDF3000A3(-DN) (Casino Version)
DallmeierelectronicGmbH&Co.KG
6.4 Closing the housing
1. Place the dome and the housing ring onto the housing.
IMPORTANT
Possible damage to the lens and the dome with
extreme alignment of the camera (vertical, hori-
zontal).
When mounting, ensure that the dome does not
jam the lens. Do not use any force.
2. Adjust the viewing panel
on the dome.
3. Turn the housing ring in a
clockwise direction.
CAUTION
Danger of injury from the camera falling down.
Before initial startup, make sure that the dome
and the housing base plate are securely mounted.
Fig. 6-7
