dallmeier DF2000A Operating and maintenance instructions

Installation and Configuration
Color Video Camera
DF2000A
Rev. 3.1.0 / 060801
English

2
Color Video Camera DF2000A
DallmeierelectronicGmbH&Co.KG
Copyright © Dallmeier electronic GmbH & Co.KG
All rights reserved. This document may not be copied,
photocopied,reproduced,translated,transferredtoanelectronic
medium or converted to a machine-readable form either whole
orinpartwithout first receiving written permission from Dallmeier
electronic GmbH & Co.KG.
We reserve the right to make technical modifications.
The manufacturer accepts no liability for damage to property or
pecuniary damages arising due to minor defects of the product
or documentation, e.g. print or spelling errors, and for those not
caused by intention or gross negligence of the manufacturer.
Dallmeier electronic GmbH & Co.KG
Cranachweg 1
D 93051 Regensburg, Germany
www.dallmeier-electronic.com
[email protected]
Please store these instructions
for future use!

3
DallmeierelectronicGmbH&Co.KG
Table of contents
1 About this document .......................................................................... 5
1.1 Validity................................................................................................... 5
1.2 DocumentationforDF2000A ................................................................. 5
1.3 Convention ............................................................................................ 5
2 For your safety.................................................................................... 7
3 General instructions ........................................................................... 9
3.1 Scope ofsupply..................................................................................... 9
3.2 Transportationandpackaging................................................................ 9
3.3 Approveduse ........................................................................................ 9
3.4 Features ................................................................................................ 9
3.5 Certificates .......................................................................................... 10
3.6 Warranty ............................................................................................. 10
4 Notes on operating the camera........................................................ 11
5 Equipment and connections ............................................................ 13
6 Connection and installation ............................................................. 17
6.1 Noteambientconditionsatmountingsite ............................................ 17
6.2 Attachingthelens................................................................................ 17
6.3 Setting thebackfocus ......................................................................... 18
7 Preparing to configure...................................................................... 21
7.1 UTC RemoteBox ................................................................................ 22
7.2 DMS Recorder .................................................................................... 23
7.3 PView .................................................................................................. 23
8 Configuration .................................................................................... 25
8.1 Configurationforlenseswithmanualiris ............................................. 26
8.2 Presets................................................................................................ 26
8.3 Basic Functions .................................................................................. 28
8.3.1 CameraID........................................................................................... 28
8.3.2 CCTVSystem ..................................................................................... 29
8.3.3 HorizontalFlip ..................................................................................... 30
8.3.4 LensSelect ......................................................................................... 31
8.3.5 Color ................................................................................................... 31
8.3.6 Backlight ............................................................................................. 31
8.3.7 DigitalZoom ........................................................................................ 32
8.4 ImageFunctions.................................................................................. 33
8.4.1 Brightness ........................................................................................... 33
8.4.2 Saturation ............................................................................................ 33
8.4.3 Dynamic Range ................................................................................... 33
8.4.4 Metering .............................................................................................. 33
8.4.5 WhiteBalance..................................................................................... 34

4
Color Video Camera DF2000A
DallmeierelectronicGmbH&Co.KG
8.4.6 AGC.................................................................................................... 35
8.4.7 Progressive Rate ................................................................................. 35
8.5 Exit Menu ............................................................................................ 36
A Appendix ........................................................................................... 37
A1 Menustructure .................................................................................... 37
A2 TechnicalData..................................................................................... 39

5
DallmeierelectronicGmbH&Co.KG
1 About this document
1.1 Validity
This document applies to the DF2000A Color Video Camera. It
was created for Version 1.6 software.
1.2 Documentation for DF2000A
Start-up
The Quick Guide headed „Comissioning“ lists the most important
steps for the assembly, connection and commissioning of the
camera.
Installation and configuration (this document)
The instructions „Installation and configuration“ contains detailed
descriptions of the assembly, connection, commissioning and
configuration of the camera. You will also find general product
information and technical data in this section.
Storing the documents
Store the operating instructions in an accessible location near the
product and keep it in readable condition.
Ensurethat all documentationis passedonto any subsequent owner
or user of the system.
1.3 Convention
This document contains various warning words and symbols that
indicate potential sources of danger. Various symbols and formats
are used to maintain the clarity of the document.
DANGER
The warning word DANGER denotes an immedi-
ate danger that may cause death or serious
injury if it is not averted.

6
Color Video Camera DF2000A
DallmeierelectronicGmbH&Co.KG
WARNING
The warning word WARNING denotes a possible
danger that may cause death or serious injury
if it is not averted.
CAUTION
The warning word CAUTION denotes a possible
danger that may cause minor injury if it is not
averted.
IMPORTANT
The word IMPORTANT denotes information for
preventing damage, incorrect configurations or
incorrect actions.
NOTE
A NOTE offers information on principles, special
featuresand efficient procedure as wellasgeneral
recommendations.
Expressions in bold and italics generally indicate
acontrol elementonthe device(switchesor labels)
or on its user interface (buttons, menu entries).
Abbriviations in this document:
AC =Alternating Current
AGC =Automatic Gain Control
DC =Direct Current
ESD =Electrostatic Discharge
NTSC =National Television System Committee
PAL =Phase Alternation Line
PT =Pan Tilt
UTC =Up-The-Coax
UWDR =Ultra-Wide Dynamic Range
Expression

7
DallmeierelectronicGmbH&Co.KG
2 For your safety
Only use the camera if it is in proper technical working condition,
for the intended purpose and while keeping safety and potential
dangers in mind. Observe the technical specifications and the
corresponding instructions and/or documentation. Have
malfunctions that could compromise safety eliminated immediately!
This applies especially for damage to the power supply.
!!
!!
!Use professionals
Installation, mounting, connection, start-up and configuration
ofthe DF2000A may onlybe performed by trainedandauthorized
professionals (installers).
As far as not expressly specified otherwise, this specification
also applies for the maintenance, testing and repair of the
camera.
!!
!!
!Read and understand instructions
Readthedocumentationforthe camera carefully and completely
before using the camera.
!!
!!
!Observe the rated voltage
The applied voltage must constantly match the rated voltage of
the camera (see technical data).
!!
!!
!Protection against condensation
Wait approx. 8 hours for the camera to reach room temperature
before starting it up.
!!
!!
!Expansion components/peripheral devices
Use only expansion components conforming with the technical
specifications.
!!
!!
!Connection of the camera
Connection of the camera to a recording system or control panel
may only occur while the camera is de-energized. Pull the mains
plug!
!!
!!
!Penetration of foreign bodies and liquids
The camera may not be subjected to moisture or rain. No objects
or liquids may penetrate into the camera.

8
Color Video Camera DF2000A
DallmeierelectronicGmbH&Co.KG
!!
!!
!Danger when opening camera
If it is necessary that the camera be opened, unplug the power
plug before opening.
!!
!!
!ESD measures
Certaincomponentsof thecameramay be damagedor destroyed
by electrostatic discharge, even while disconnected from the
power supply.
Carry out equipotential bonding. Carry out work only with the
appropriate ESD protective measures in place.
!!
!!
!Do not make modifications
Dallmeier electronic GmbH & Co.KG accepts no liability for
damage resulting from unauthorized or improper modifications
to the camera.
!!
!!
!Mount the camera securely
Thecamera must be mounted securely to preventinjuryto others
(e.g. via falling camera) or damage to the camera.
!!
!!
!Observe regulations
Inform yourself on local regulations and requirements before
using the camera. Also observe the local laws regarding data,
working and environmental protection.
!!
!!
!Observe ratings
Ensurecompliance with all technicalratings,operating conditions
(Appendix) and requirements at the installation site.
!!
!!
!Disposal
Disconnect the camera from the power supply. Remove the po-
wercable and all the expansioncomponents/ peripheral devices.
Return the camera to your respective sales partner.

9
DallmeierelectronicGmbH&Co.KG
3 General instructions
3.1 Scope of supply
Included in the scope of supply:
1 x DF2000A Camera
1 x installation and configuration manual
1 x hexagonal wrench 6 mm
3.2 Transportation and packaging
Store the original packaging for transportation at a later date.
Dallmeier electronic is not responsible for damage resulting from
unprofessional/improper transportation.
Shipping should only occur in the original packaging.
If the original packaging is no longer available, ensure that the
packaging used sufficiently protects the unit against damage,
moisture, heat and cold.
3.3 Approved use
The DF2000A is a Color Video Camera for color or b/w imaging. It
isdesigned for indoor as well as for outdooruse (with corresponding
weather proof housing only). The camera can be mounted on walls
and ceilings.
3.4 Features
The DF2000A offers a resolution of more than 480 TV lines and a
volume range of 126 dB maximum. It has a low light sensitivity of
0.8 lux to provide images with greater color neutrality and clarity of
detail, even at low light levels. Designed to be free from glare, the
camera permits detailed recognition even against extreme back
lighting.

10
Color Video Camera DF2000A
DallmeierelectronicGmbH&Co.KG
The DF2000A also offers:
"Detailed reproduction of the highest quality for bright spots as
well as in shaded areas using UWDR.
"Suppression of all smearing and blooming effects.
"Prevention of movement artifacts (Progressive Rate).
"UTC configuration of the camera via the video cable using a
Dallmeier Recorder (DMS Series), Software PView or via the
UTC Remote Box.
"Factory settings suitable for many scenarios with varying light
conditions (Presets).
NOTE
For detailed information, please see Technical
Data in the Appendix.
3.5 Certificates
The following certifications were in effect for the DF2000A camera
at the time this document was produced:
"CE
"UVV-Kassen
"UL
3.6 Warranty
The warranty period is 36 months.
The terms and conditions valid at the signing of the contract apply.

11
DallmeierelectronicGmbH&Co.KG
4 Notes on operating the camera
!The camera can be operated at 12 V DC or 24 V AC.
!The DF2000A was designed for use with CS-mount lenses. An
adapter ring is required for use with C-mount lenses. Note the
lens type before using it. When using C-mount lenses without
an adapter ring, the camera could be damaged. This applies
especially for the sensors.
!Lenses with DC control can be used for automatic iris control.
Video signal-controlled lenses are not supported.
!If the camera or the cable connected to the cable is located near
sources of strong radiation, the video picture may be distorted.
!The camera is equipped with automatic gain control (AGC). In
low light the picture may be altered (e.g. noise). This is not a
camera malfunction.
!The quality of the video picture depends on the lens used, the
lighting and the monitor used to display the video picture.
!Automatic white balance depends on the lighting used and can
cause color distortions in artificial light.
!Poor lighting can lead to faulty white balance.

12
Color Video Camera DF2000A
DallmeierelectronicGmbH&Co.KG

13
DallmeierelectronicGmbH&Co.KG
5 Equipment and connections
Lens mount and back focus adjustment
The lens mount (threaded ring) is suitable for holding CS
lenses.
The threaded ring is also used to set the back focus (6.3
Setting the back focus).
Setting screw
Setting screw (2 mm Allen screw) for loosening/locking the
threaded ring when setting the back focus (6.3 Setting the
back focus).
1/4" thread insert
A 1/4" thread insert is located above and below for mounting
the camera to a tripod, a wall mount etc.
IMPORTANT
Possible damage to the camera caused by too
long screws.
Only use screws with a max. length of 7 mm for
mounting.

14
Color Video Camera DF2000A
DallmeierelectronicGmbH&Co.KG
Video signal output (Video OUT)
A composite video signal (CVBS) is output at the BNC jack.
Thesignal complies with either the PALor the NTSC standard,
depending on the signal system setting.
Operating voltage display
The LED illuminates when the camera is supplied with po-
wer.
Connection for iris control
Control voltage for automatic iris control on lenses with DC
control is available at this connection.
NOTE
Checkthe plug forcorrectcontactassignment (see
table) before connecting the lens.
PinNo. DC Iris
1 Damping -
2 Damping +
3 Drive +
4 Drive -

15
DallmeierelectronicGmbH&Co.KG
Selector
The selector is used for menu selection and to set the
corresponding parameters.
Set button
Press the Set button in normal operation at least 2 seconds
to display the camera menu.
Once the camera menu is displayed, a specific menu item or
setting is activated when the Set button is pressed.
Power supply connection
The camera can be operated at 12 V DC or 24 V AC.
Connect the cable for power supply to the screw terminals
of the camera.
IMPORTANT
Possible damage to the camera caused by
incorrect polarity.
You must ensure correct polarity of the cables
when using 12 V DC.
Useinsulated cables.Thecables for power supply
may not contact the housing of the camera.
Powersupply
12 V DC or 24 VAC - +

16
Color Video Camera DF2000A
DallmeierelectronicGmbH&Co.KG
IMPORTANT
Possible damage to the camera caused by an
inadequate power supply unit.
If used in North America, note the following:
You must use a UL-certified, limited-power Class 2
power supply unit (12V DC/0.42Aor 24VAC/0.20A)
for the camera power supply.
RS232c interface
The camera can receive control signals via the RS232c
interface or the video cable (coaxial cable).
The camera can additionally emit control signals via the
RS232c interface to a pan/tilt head (PT head). The control
signals are looped through the camera and transmitted via
the interface.
The PT head can thus be controlled via the UTC box, PView
Station or a DMS/DLS recorder. Additional cabling (control
unit for the PT head) is therefore no longer required.
PIN4 = RX input of camera
PIN3 = ground
PIN2 = ground
PIN1 = TX output of camera for PT
NOTE
Customer-specific adaptation for control of the
camera via the RS232c interface is available on
request.
Pin 4
Pin 3
Pin 2
Pin 1

17
DallmeierelectronicGmbH&Co.KG
a)max.5mm
6 Connection and installation
6.1 Note ambient conditions at mounting site
The camera was designed for indoor use. When used outdoors,
the camera must be mounted in an appropriate weatherproof
housing.
Do not install/operate the camera in places:
"with steam or oil vapors (e.g. kitchen)
"near sources of strong radiation, i.e. X-rays, radio transmitters
or magnetic fields
"with corrosive surroundings (e.g. gases or salt water)
"with large scale dust and dirt.
"with an ambient temperature above 50 °C.
6.2 Attaching the lens
IMPORTANT
Possibledamage to the sensor caused by too long
lens thread and protruding parts.
Ensure that the length (a) of the lens thread (see
following figure) plus any protruding parts does
not exceed 5 mm.
Check whether it is a CS-mount lens.
If a C-mount lens is used, an appropriate
adapter ring is to be used.
NOTE
The camera is pre-configured for use with DC-
controlled lenses. For lenses with manual iris
setting, the configuration is to be changed
according to section 8.1.

18
Color Video Camera DF2000A
DallmeierelectronicGmbH&Co.KG
IMPORTANT
Possible damage to the sensor caused by
improper cleaning.
Ensure that dirt does not end up on the sensor.
Use only clean compressed air if cleaning is
necessary. Under no circumstances may liquids
or cotton wool be used for cleaning.
Remove the protective cap from the lens mount.
Screw the lens onto the camera without using force.
6.3 Setting the back focus
The back focus is the distance between the lens support on the
camera and the picture sensor. Optimum focus is only possible
when the correct distance is set.
It may be necessary to set the back focus in individual cases due
to production tolerances of the lens.
The iris of the lens must be open as wide as possible (smallest iris
value) to set the back focus.
For lenses with automatic iris control, you will require an ND filter
(gray filter) to prevent the iris from closing in bright light.
Setting for lenses with a fixed focal distance
If the focus cannot be set exactly by turning the focus ring (lens),
proceed as follows:
1) Point the camera at an object with sufficient contrast. The
distance to the object should be greater than 1,000 x the focal
distance.
2) Open the iris on the lens.
3) Set the distance at the lens to infinity (∞).
4) Loosen the setting screw on the camera with the
accompanying hexagonal wrench.
5) Rotate the lens ring until the optimum focus is achieved.
6) Tighten the setting screw again.

19
DallmeierelectronicGmbH&Co.KG
Setting for lenses with a variable focal distance (zoom)
If the focus changes as the focal distance changes, proceed as
follows:
1) Pointthe camera at an object withsufficientcontrastat a distance
of approx. 2 m.
2) Open the iris on the lens.
3) Set the maximum focal distance (Tele) at the lens.
4) Set the optimum focus with the focus ring.
5) Set the smallest focal distance (wide angle).
6) Loosen the setting screw on the camera.
7) Rotate the lens ring until the optimum focus is obtained.
You may need to repeat Steps 3, 4, 5 and 7 several times to
obtain the best results.
8) Tighten the setting screw again.

20
Color Video Camera DF2000A
DallmeierelectronicGmbH&Co.KG
