Dawnway UVC100 User manual

UVC100
UV-C LED Disinfection Faucet
SGS Test-approved disinfection rate >99.9%
User's Manual
1
UVC Module
Indicator Light
UNIT : [INCH]
mm
Specifications
Power supply：Input 100VAC~240VAC / Output DC12V-2A
Water Quality：Light penetration rate >=90%
Impurity Particle Size <= 10 μM
Water Temperature：5 ~ 40 ℃
Water Pressure：Max. 100 psi
Flow Control：Max. 2LPM
Ambient Temperature：0 ~ 55 ℃
Mounting
Hole
( Fig. 1 ) ( Fig. 2 )

2
Installation Steps (Please refer to Fig. 3, Fig. 4)
1. Ensure a ∮35mm mounting hole in the countertop.
2. do not remove or loosen the lock nut (8).
3. Ensure that the waterproof O-ring (7) is attached to the base plate
of the faucet, remove the horseshoe gasket (2) and set it aside,
and leave the rest of the parts on faucet .
4. Install faucet with the inlet threaded tube (1), water flow switch
(5) and power cable(4) through the mounting hole(∮35mm ) in
the countertop.
5. Place the horseshoe gasket (2) under the countertop (9) between
the hex lock nut (3) and countertop(9) and then tighten the hex
lock nut (3) . (Please make sure that the power cable (4) must
pass through the gap of the horseshoe gasket (2), otherwise the
power cable will be damaged and thereby cause damage to the
UVC module.)
6. Please prepare a 1/4” PE pipe of suitable length, and connect it to
the water flow switch (5) and the water supply connector.
Power Cable(4)
Water Flow Switch(5)
Arrow Tip(5-2)
points upward
Horseshoe Gasket(2)
Inlet Threaded Tube(1)
Black Socket(4-1)
connects to
power supply
Green Socket(4-2)
connects to
flow switch
connects to
water supply
Green Plug(5-1)
Of Power Cable
Black
Plug(6)
Hex Lock Nut(3)
( Fig. 3 )
Lock Nut(8)

3
Light Indicator
1. When the power cord is plugged into the power supply, the red
and blue lights will flash once that means work.
2. Turn the faucet on, if the blue light is on, it means UVC module
work (disinfection in process).
3. Red light on : It means UVC module is overheating, please refer
to the troubleshooting guide.
4. Both red, blue lights on : It means UVC module failure, please
refer to the troubleshooting guide.
5. Turn the faucet off, the light indicator goes off.
Waterproof
O-ring(7)
Hex Lock Nut(3)
Lock Nut(8)
Countertop(9)
Horseshoe
Gasket(2)
( Fig. 4 )
7. Connect the black plug (6) of the adapter with the black socket (4-1) of the power cable,
and connects to power supply. When the power cord is plugged into the power supply, the
red and blue lights will flash once indicate that the faucet function is in normal standby
state.
8. Turn on the water supply.
9. Do not disassemble the water flow switch (5) unless necessary, once disassembled, please
ensure the arrow tip(5-2) of the water flow switch (5-1) is pointing upward, and the green
plug (4-2)of the power cable(4) and the green socket (5-1) of the water flow switch(5) are
connected.

4
Safety Guidelines
1. Please follow the instructions of the installation steps. It is recommended that you hire a qualified
professional to complete the installation to prevent personal injury or damage.
2. Please consult your local dealer or official after-sales service personnel for any inquiry.
3. It is strongly recommended to use this with water purification equipments.
4. Water supply range: 15 ~ 40 PSI, Water quality: light penetration rate >= 90%, Particle Size: <= 10
μM.
5. Please finish the disinfection water within four hours.
6. This product is a Hi-Tech electronic product; do not use abrasive or chemical cleaners to clean
faucets.
7. Do not hang heavy object to this product and keep away from heat source, to avoid product
deformation or damage.
8. Check the power supply and the product appearance regularly, if any damage is found, please turn
off and suspend all use, and contact your local dealers or official after-sales service personnel for
repair.
9. Please do not attempt to repair or replace the product with non-original spare parts, the warranty
does not cover for damage as a result thereof.
10. Please read the manual and operate accordingly.

5
Troubleshooting Guide
Problem Cause Remedy
No water or low water pressure,
the blue light is not on
Insufficient water pressure
Check if the water source is completely
turned on
Check if the water purifier is working
properly
Faucet failure
Contact the local dealer or official after-
sales service personnel
water flows normally, the blue light
is not on
Power supply failure Check the power supply
Water flow switch arrow
pointing in wrong direction
ensure the arrow of the water flow switch
is pointing upward (the arrow should
point towards the faucet)
Re-install
Water flow switch failure
Contact the local dealer or official after-
sales service personnel
Control panel failure
Red light is on UVC module overheating
Discontinue use for one minute before
re-use
Water temperature too high
Lower water temperature
Both red and blue lights is on UVC module failure
Contact the local dealer or official after-
sales service personnel

6
Dawnway Enterprise Co., Ltd
69, Lane 466, Siangshang Road, Sec.9, Wuchi, Taichung, 43547, Taiwan
www.dawnway.com.tw
