Defy F616 User manual

Page 1
DFF402
INSTRUCTION MANUAL
The manufacturer strives for continuous improvement.
For this reason, the text and illustrations in this manual
are subject to change without notice.
Part number
5718140000/AA
N
F616 R FRIG RATOR

Page 2
Read this manual before initial installation and operation of the
product!
Dear customer,
Your new Defy refrigerator was manufactured in a state of the art facility and has passed the
strictest quality control procedures.
lease read this manual carefully before using your product for the first time and then store it
within easy reach for future reference.
We trust you will enjoy years of trouble free use.
The user manual:
• This manual will provide you with information on how to safely operate and care for your
product in order that you gain the maximum benefit from it.
• ay particular attention to any safety instructions.
• lease read all additional documents supplied with your product.
• lease note that this manual may be used for several similar but different models. lease
check for relevance regarding your particular model.
xplanation of symbols used in this manual
Important safety information. Warning for hazardous situations with regard to life and
property.
Caution; Warning for supply voltage.
Caution; Warning for fire hazard.
Caution; Warning for hot surfaces.
Read the instructions.
Useful information. Important information or useful hints about usage.
Unpacking
Remove all packaging.
Ensure that packing material is disposed of in a responsible manner and that any plastic bags
are cut up to prevent children playing with them and accidentally suffocating.
If the refrigerator is damaged in any way do not use it. Report the damage to your dealer who
will take the necessary corrective action.

Page 3
1. Your Refrigerator 4
2. Important Safety Information 5
Warnings 5
Child safety 6
HCA Warning 6
Refrigerators with a water dispenser 6
Things to be done for energy saving 7
3. Installation 8
oints to be considered when
re-transporting your refrigerator 8
Before operating your refrigerator 8
Electric connection 8
Adjusting the feet 9
lacing and Installation 9
Door height adjustment 10
Adjusting the gap on the upper door 11
4. Installing the water filter 12
Water connection to the refrigerator 13
Connection of water hose to jug 13
Fitting the water filter 14
Connection of water pipe to cold water
mains line 16
Before first use of ice/water dispenser 17
5. Using your refrigerator 18
Indicator anel 18
lacing food 19
Setting the fridge compartment
temperature 19
Setting the freezer compartment
temperature 19
Fresh Freeze function 19
Quick Cool function 20
Vacation button 20
Auto Eco button 20
Ioniser 20
Key Lock button 20
Water dispenser illumination 20
Water/ice type selection 20
Ice Water dispenser 20
Using the ice dispenser 21
Using the water dispense r 22
Blue Light 23
Egg tray 23
Fresh Freeze compartment 23
Crisper humidity control sliders 23
6. The freezer compartment 24
Deep Freeze packaging information 25
Freezer compartment settings 25
7. Chiller compartments 26
Icebox and water reservoir 26
8. Maintenance and cleaning 27
Owners responsibility 27
Replacing the interior light bulb 27
9. Trouble Shooting 29
10. Refrigerator specifications 31
11. Service Centres 32
12. Warranty 33
Contents

Page 4
Your Refrigerator
1
1. Freezer compartment
2. Fridge compartment
3. Fridge compartment interior light
4. Butter and cheese lid
5. Fan
6. Ioniser
7. Fridge compartment glass shelves
8. Egg tray
9. Fridge compartment door racks
10. Wine cellar
11. Chiller compartment
12. Bottle holder
13. Bottle shelves
14. Crisper compartments
15. Crisper cover
16. Adjustable front legs
17. Blue light
18. Water reservoir
19. Ventilation lid
20. Freezer compartment drawers
21. Freezer Compartment glass shelves
22. Ice duct lid
23. Freezer compartment interior light
24. Fresh Freeze compartment
25. Ice container
*OPTIONAL
Figures represented in this instruction manual are schematic and may not
correspond exactly with your refrigerator. If the parts are not included in the
refrigerator you have purchased, they may be model specific and therefore
only valid for some models.

Page 5
is damaged. See HCA warning overleaf.
Do not damage the refrigerant circuit.
• Keep ventilation openings, in the
refrigerator or in the built-in structure, clear
of obstructions.
• Repairs must be carried out by authorised
persons only. Repairs carried out by
incompetent persons create a user risk.
• Unplug the refrigerator when cleaning,
during routine maintenance or if it will not
be used for an extended period.
• To unplug the refrigerator, remove the plug
by pulling on the plug and not the cable!
• Do not operate a damaged refrigerator.
Consult with your nearest DEFY service
centre should you have any concerns.
• The electrical safety of the refrigerator is
only guaranteed if the earth system of your
home is compliant to national standards.
• Exposing the refrigerator to rain, snow, sun
and wind is an electrical safety risk.
• Should the mains lead of the refrigerator
become damaged or should it need
replacing at any time, it must be replaced
by a special purpose made mains lead
which can only be obtained from a DEFY
Authorised Service Agent.
• Never plug the refrigerator into the wall
socket during installation. Death or serious
injury may result.
• Never connect your refrigerator to
electricity saving systems as they may
damage the refrigerator.
• Do not store medicine or academic
research samples which require strict
temperature control in the refrigerator.
• Do not store or use flammable gas,
benzene, petrol or volatile substances in or
near the refrigerator.
• Do not store explosive substances such as
aerosol cans with a flammable propellant
in the refrigerator.
• In the event of a malfunction, disconnect
the refrigerator from the power supply.
• Do not overload your refrigerator with
excessive amounts of food. If overloaded,
the food items may fall down and injure
you and damage the refrigerator when you
open the door. Never place objects on top
of the refrigerator, they may fall down and
injure you when you open or close the
refrigerator door.
• If there is a blue light fitted on the
refrigerator, do not look at the blue light
through optics.
Important safety information
lease review and observe the following
information. Failure to do so may result in
injuries or material damage and will render
any warranty and reliability commitments
void. The usage life of the refrigerator you
have purchased is 10 years. This is the time
period that spare parts will be stocked for the
refrigerator to meet any maintenance or
service requirements.
This refrigerator is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities or
lack of experience and knowledge, unless
they have been given supervision or
instruction concerning the use of the
refrigerator by a person responsible for their
safety. Children should be supervised to
ensure that they do not play with the
refrigerator.
Warnings
• Hand this owners manual over to the new
owner should ownership change.
• The refrigerator must only be used for its
intended purpose, i.e. the storing of edible
foodstuff.
• The refrigerator is intended to be used in
household and similar applications such as
staff kitchen areas in shops, offices and
other working environments; farm houses
and by clients in hotels, motels and other
residential type environments; bed and
breakfast type environments; catering and
similar non-retail applications.
• Consult with your authorised DEFY service
centre for all questions and problems
relating to the refrigerator. Only authorised
agents are to carry out repairs.
• Vapour and vaporized cleaning materials
must never be used in the cleaning and
defrosting the refrigerator. The vapour may
come into contact with the electrical parts
and cause a short circuit or electric shock.
• Do not allow children to hang on the
refrigerator door as the unit could topple
forward risking personal injury. Never use
the parts on your refrigerator, such as the
door, as a means of support or step.
• Do not use electrical appliances inside the
refrigerator or freezer.
• Do not drill, cut or modify the refrigerator.
Injuries may result if the refrigerant circuit
2

Page 6
• Ensure that there is sufficient spacing
between the refrigerator and surrounding
walls.
• Unplug the refrigerator from the mains
when you clean the refrigerator.
Child safety
• If the door has a lock, the key should be
kept out of reach from children.
• If you are discarding an old refrigerator
with a lock or latch fitted to the door,
disable the lock/latch, and ensure that the
refrigerator is left in a safe condition to
prevent children from being trapped inside
and suffocating.
• Children must be supervised to prevent
them from tampering with the refrigerator.
HCA Warning
Refrigerator cooling systems containing
R600a:
At DEFY, the care and protection of our
environment is an on going commitment.
This DEFY refrigerator is particularly
environmentally friendly and contains non
CFC / HFC natural substances in the cooling
system (Called R600a) and in the insulation
(Called cyclopentane). These are potentially
flammable if exposed to fire. Therefore, take
care not to damage, the cooling circuit /
pipes of the refrigerator in transportation and
in use.
In case of damage do not expose the
refrigerator to fire or potential ignition
sources and immediately ventilate the
room where the refrigerator is situated.
Ignore this warning if your refrigerators
cooling system contains R134a.
Never dispose of the Refrigerator in a
fire.
Do not dispose of your Refrigerator
along with regular household waste.
Contact your local authority for disposal
information and facilities available.
For refrigerators with a water dispenser
ressure of water mains should be at a
minimum of 1 bar. ressure of the water
mains should be at a maximum of 8 bars.
• Use only potable water.
• The refrigerator may move if the
adjustable legs are not properly levelled
on the floor. Levelling the adjustable legs
on the floor helps prevent the refrigerator
from moving.
• When carrying the refrigerator, do not hold
on the door handle as this may cause the
handle to break.
• When placing your refrigerator next to
another refrigerator or freezer, the
distance between the devices should be at
least 80 mm. Failure to do so may cause
adjacent walls to humidify.
• For refrigerators with a freezer
compartment; Do not put bottled and
canned liquid beverages in the freezer
compartment as they may burst.
• Do not touch frozen food with your hands;
they may stick to your hand.
• Never pour or spray water into or on the
refrigerator and do not store liquids, pot
plants or open containers on top of the
refrigerator as these might spill causing
electrical shorting.
• For manually controlled refrigerators, wait
at least 5 minutes before starting the
refrigerator after a power failure.
• Avoid any damage to the power cable
when transporting the refrigerator.
• Bending the cable may cause a fire.
• Never place heavy objects on the power
cable.
• Do not touch the plug with wet hands.
• Do not plug in the refrigerator if the wall
socket is loose.
• On delivery, check to make sure that the
refrigerator is not damaged and that all the
parts and accessories are in perfect
condition.
• Ensure that the plug remains readily
accessible. Do not use multiple adapter
plugs or an extension cable.

Page 7
Things to be done for energy
saving
• Do not leave the doors of your refrigerator
open for long periods of time.
• Do not put hot food or drinks in your
refrigerator.
• Do not overload your refrigerator. This
restricts effective air circulation in the
refrigerator.
• Do not install your refrigerator under direct
sunlight or near heat emitting appliances
such as ovens, dishwashers or radiators.
• ay attention to keep your food in closed
containers.
• For refrigerators with a freezer
compartment; You can store maximum
amount of food items in the freezer when
you remove the shelf or drawer of the
freezer. The energy consumption value
stated for your refrigerator has been
determined by removing the freezer shelf
or drawer and under maximum load. There
is no harm in packing a shelf or drawer
with a variety of different shapes and sizes
of food to be frozen.
• Thawing frozen food in the fridge
compartment will provide both energy
saving and preserve the food quality.
Recommendations for freshfood
compartment (Optional)
• lease do not let any foods come into
contact with the temperature sensor in the
freshfood compartment. In order to
maintain the freshfood compartment at the
ideal storage temperature, the sensor
must not be interfered with by any foods.
• Do not place hot foods in your refrigerator.

Page 8
3. Clean the interior of the refrigerator as
recommended in the “Maintenance and
cleaning” section.
4. lug the refrigerator into the wall socket.
When the fridge door is open the fridge
compartment interior light will come on.
5. You may hear a noise as the compressor
starts up. The liquid and gases sealed
within the refrigeration system may also
give rise to noise, even if the compressor
is not running, this is quite normal.
6. The front edges of the refrigerator may feel
warm. This is normal. These areas are
designed to be warm to avoid
condensation.
lectrical connection
Connect your refrigerator to a grounded
socket which is protected by a fuse with the
appropriate capacity.
Important
The connection must be in compliance with
national regulations.
The power cable plug must be easily
accessible after installation.
The specified voltage must be equal to your
mains voltage.
Extension cables and multiway plugs must
not be used for connection.
A damaged power cable must be
replaced by a qualified electrician.
A damaged refrigerator must not be
operated before it is repaired! There is
danger of an electric shock!
Installation
lease remember that the manufacturer
shall not be held liable if the information
given in the instruction manual is not
followed.
Points to be considered when re-
transporting your refrigerator
1. Your refrigerator must be emptied and
cleaned prior to any transportation.
2. The shelves, accessories, crisper etc.
In your refrigerator must be fastened
securely with adhesive tape to protect
against any jolts before repackaging
3. ackaging must be tied with thick tape and
strong rope and the transportation
guidelines printed on the package must be
followed.
Before operating your refrigerator
Before using your refrigerator please check
the following:
1. Is the interior of the refrigerator dry and
can the air circulate freely at the rear of it?
2. The 2 plastic wedges can be fitted as
illustrated in the figure below. The plastic
wedges will provide the required distance
between your refrigerator and the wall in
order to allow for free air circulation. (The
illustrated figure is an example only and
may not match your refrigerator exactly).
3

Page 9
Placing and Installation
If the entrance door of the room where the
refrigerator is to be installed is not wide
enough for the refrigerator to fit through,
then call an authorized service centre and
have them remove the doors of your
refrigerator in order that the refrigerator can
fit sideways through the door.
1. Install your refrigerator in a place that
allows for ease of use.
2. Keep your refrigerator away from heat
sources, humid places and direct sunlight.
3. There must be appropriate air ventilation
around your refrigerator in order to achieve
efficient operation.
The refrigerator is to have at least a 50
mm space from the ceiling and at least a
50 mm space from the wall.
If the floor is covered with a carpet, your
refrigerator must be elevated 25 mm from
the floor.
4. lace your refrigerator on an even floor
surface to prevent jolts.
5. Do not keep your refrigerator in ambient
temperatures under 10°C.
Your refrigerator should be installed at least
300 mm away from heat sources such as
hobs, ovens, central heaters and stoves and
at least 50 mm away from electrical ovens
and should not be located under direct
sunlight.
lease make sure that the interior of your
refrigerator is cleaned thoroughly.
If two refrigerators are to be installed side by
side, there should be at least 20 mm
distance between them.
When operating your refrigerator for the
first time, please observe the following
instructions during the initial six hours:
The door should not be opened frequently.
The refrigerator must be operated empty
without any food in it. Do not unplug your
refrigerator. If a power failure occurs out of
your control, please see the warnings in the
“Recommended solutions for the problems”
section. Original packaging and foam
materials should be kept for any future
transportation or moving.
Adjusting the feet
If your refrigerator is unbalanced
The refrigerator may move if the adjustable
legs are not properly levelled on the floor.
Levelling the adjustable legs on the floor:
You can level your refrigerator by turning the
front legs as shown in the illustrated. (See
figure A)
The corner where the legs are is lowered
when the leg is turned in the direction of the
black arrow and raised when turned in the
opposite direction.
Having someone to carefully assist in tilting
the refrigerator slightly will help facilitate this
process.
.

Page 10
• If the freezer compartment door is higher
than the fridge compartment door, bring
them to the same level by turning the
elevation screw on the freezer
compartment side in the reverse direction
of the arrow (as illustrated in Figure D)
using an M6 Allen wrench .
After adjusting the doors to the same level
with the aid of the elevation screws, ensure
that the doors of the refrigerator close
properly. If the doors do not close properly,
this may adversely affect the efficiency of the
refrigerator.
Door height adjustment
In case there is a problem with the alignment
of the doors in relation to one another, they
may be re-aligned vertically by following the
steps below. Ensure that the door shelves
are empty when adjusting the door height.
1. Remove the lower ventilation cover by
unscrewing its screws as shown in the
figure below. (See Figure B)
2. Using a screwdriver, loosen the three
screws on the hinges of the lower door
which you wish to lift as shown in the
figure below. (Do not remove completely)
(See Figure C)
• If the freezer compartment door is lower
than the fridge compartment door, bring
them to the same level by turning the
elevation screw on the freezer
compartment side in the direction of the
arrow (as illustrated in Figure D) using a
M6 Allen wrench .

Page 11
Using a screwdriver, remove the screw of
the upper hinge cover of the door you want
to adjust.
Adjust the door as required by loosening the
screws.
Set the door you have adjusted by tightening
the screws. Be careful not to change the
door position whilst tightening the screws.
Replace the hinge cover and fasten with the
securing screw.
Adjusting the gap on the upper door
You can adjust the gap between the fridge
compartment doors as illustrated in the
figures.
The door shelves should be empty when
adjusting the door height.
Important! Before removing hinge
covers switch off the refrigerator power
as there are wires in the hinge cover of the

Page 12
The lace where the external filter is going
to be fitted should first be determined.
(Applies to the filter being used outside the
refrigerator.) Then, determine the distance
between the filter and the refrigerator and
required hose lengths from the filter to the
refrigerator water inlet.
The water filter must be held upright as
shown in the figure. It is important to attach
the filter properly to the water inlet and water
outlet points.
After attaching the filter, do not use the first 3
-4 glasses of water.
Installing the Water Filter
(in some models)
Installation Requirements
Two different water sources may be
connected to the refrigerator for the water
supply: the mains cold water supply and
water in a jug.
A pump should be used for water jug usage.
Check that the parts stated below are
supplied with your refrigerator.
1. Union for connection of the water pipe to
the rear of the refrigerator .
2. 3 pipe clips (if required to secure the water
pipe).
Note:
Since the following parts are not required to
be used with a jug, they may not be found in
the refrigerator you have purchased.
3. 5 meter long water pipe (1/4 inch in
diameter)
4. Cold mains water valve with mesh filter
(Tap Adapter)
5. Water Filter to be fitted to the bracket
inside the fridge compartment.
4

Page 13
Water connection to the refrigerator
Please follow the instructions carefully.
Connection of the Water Pipe to the
Refrigerator
1. After installing the union onto the water
pipe, fit the water pipe to the refrigerator
inlet valve by pressing downwards firmly.
2. Fit the union as seen in the above figure,
by squeezing it by hand onto the
refrigerator inlet valve.
Parts:
a- Water ipe,
b- Union,
c- Valve
Note:
You should not need to tighten the union
with a tool to achieve a water tight assembly.
In case of a leak use a correctly sized
spanner to tighten the union.
Connection of Water Hose to a Jug
(in some models)
To connect water to the refrigerator from a
jug, a pump is needed.
Follow the instructions below. Start by
connecting one end of the water pipe from
the outward flow of the pump and the other
end onto the refrigerator inlet valve as
described on the “water connection to the
refrigerator”.
1. Complete the connection by pushing the
pump inlet water pipe into the inlet of the
pump as shown in figure A.
2. lace and fix the pump pipe into the jug
as shown in figure A.
3. After completing the connection, plug in
and run the pump.
To ensure efficient operation of the pump,
wait for 2-3 minutes after starting the pump.
Note:
lease refer to your pump user manual
whilst making the water connection. There is
no need of a water filter when a jug is used.
A pump must be used when using a jug.
Figure A

Page 14
Fitting the water filter
lease follow the instructions below referring
to the figures supplied:
1. ress ice cancel button on the display.
2. Remove the filter cover in the fridge
compartment by pulling it forward.
3. Take out the water filter by-pass cover by
rotating it downwards.
Warning:
Make sure that the “Ice off” mode is active
before taking out the by-pass cover.

Page 15
Fitting the water filter (continued)
The water filter should be replaced every 6
months. The water filter must be removed as
shown in the figure when it is going to be
replaced or when it will no longer be used
and the by-pass cover must be attached.
Ensure that Ice Off mode is active before
removal of the water filter.
Warning:
The water filter cleans some foreign particles
in the water. It does not purify water from
microorganisms.
Warning:
The Ice Off button must always be pressed
during replacement of the water filter or
installing the by-pass cover.
Note: It is normal for a few drops of water to
drip after the cover has been removed.
4. Remove the lid on top of the water filter to
place it as shown in the figure and turn
upwards to lock it.
5. ress ice cancel button on the display
again to exit from this mode.

Page 16
Note -1:
There is no need to use a water filter in case
a jug is used.
Note -2:
A pump must be used when using the jug.
Connection of the Water Pipe to the Cold
Water Mains Line (in some models)
If you want to use your refrigerator by
connecting it to the cold water mains line,
you will have to connect a standard 1/2”
valve connection fitting to the cold water
supply in your house. (In case this valve is
not present or if you are unsure, please
consult a qualified plumber).
1. Separate the union from the tap adaptor.
(Figure A).
2. Install the tap adaptor to a 1/2” valve fitting
as shown in the figure. (Figure B).
3. After inserting the water pipe to the union,
install it to the tap adaptor and insert to
the tap as shown in the figure. (Figure C).
4. Tighten the union manually. In case of a
leak use a correctly sized spanner to
tighten the union.
Warning:
Secure the water pipe to suitable points by
means of the pipe clips supplied to avoid any
damage or displacement or accidental
disconnection.
Warning:
After turning on the water valve, make sure
that there is no leakage at both connection
points of the water pipe. In case of a leak,
turn off the valve immediately and tighten all
joints again using a correctly sized spanner.
Warning:
Make sure that standard 1/2" valve fitting fed
by the cold mains water supply is available
and is turned off fully.

Page 17
The first 10 glasses of water should not be
consumed.
lease note, ice cubes will not be ready for
the first 12 hours after switching on the
refrigerator.
If there is not enough ice in the ice
dispenser, ice may not be obtained from ice
dispenser.
The first 30 cubes of ice to be obtained from
the Ice Dispenser must not be used.
Always use the water filter when a jug is not
being used.
Open door warning
An audio warning will be given when the
fridge or freezer compartment door of your
refrigerator is left open for a certain period of
time. This audio warning signal will mute
when any button on the indicator is pressed
or when the door is closed.
Before first use of Ice/Water Dispenser
Water mains pressure must not be below 1
bar.
Water mains pressure must not be over 8
bars.
umps must be used in case the supply
water pressure drops below 1 bar or if a jug
is going to be used.
The water system of the refrigerator must be
connected to the cold water line. It must not
be connected to the hot water line.
No water may be obtained in the initial start-
up of the refrigerator. This is caused by the
air in the system. To discharge air from the
system, press the Dispenser latch for 1
minute periods until water flows from the
Dispenser. Water flow may be irregular in
the beginning. Irregular water flow will be
normalized after the air in the system is
discharged.
After the initial start-up of the refrigerator
approximately 12 hours must pass before
cold water can be obtained.
Water mains pressure must be between 1-8
bars for the operation of Ice/Water Dispenser
smoothly. For this, check that 1 glass of
water (100 cc) can be filled in 10 seconds.

Page 18
Using your refrigerator
5
Figures represented in this instruction manual are schematic and may not
correspond exactly with your refrigerator. If the parts are not included in the
refrigerator you have purchased, they may be model specific and therefore
only valid for some models.
1. Fridge Set button
2. Vacation mode button
3. Quick fridge button
4. Key lock button
5. Ice Off button
6. Water Dispenser Lights
7. Ice / Waste selection button
8. Water Dispenser light button
9. Filter Reset button
10. Auto Eco button
11. Fresh freeze button
12. Freezer Set button
13. Economy mode indicator
14. High humidity indicator
15. Quick cool indicator
16. Fridge temperature setting indicator
17. High temperature/error warning indicator
18. Fridge door open indicator
19. Key Lock indicator
20. Vacation mode indicator
21. Water indicator
22. No ice indicator
23. Crash Ice indicator
24. Cube Ice indicator
25. Auto Eco indicator
26. Filter reset indicator
27. Freezer door open indicator
28. Freezer Compartment Temperature
Setting indicator
29. Fast Freeze indicator
30. Ioniser indicator
*OPTIONAL

Page 19
Freezer compartment shelves Various frozen food such as meat, fish, ice
cream, and vegetables
Egg holder Eggs
Fridge compartment shelves Food in pans, covered plates and closed
containers
Fridge compartment door shelves Small and packaged food or drinks (such
as milk and fruit juice)
Crisper Vegetables and fruits
Chiller compartment Delicatessen products (cheese and
butter)
Setting the fridge compartment
temperature
The fridge compartment temperature can be
set at one of the following temperatures:
8,6,4 and 2°C
ress the Fridge Set button to change. The
temperature will decrease by 2°C. Every
time you press the button, the temperature
will go down and then return to the highest
setting. Release at the desired temperature
and the new set temperature will be stored.
If your food is colder than you desire, you
can adjust the temperature setting of the
fridge compartment to 6 or 8.
Setting the freezer compartment
temperature
Freezer temperature can be set at one of the
following temperatures : -15 / -18 / -21 / -24
and -24°C
ress the Freezer Set button to change. The
temperature will decrease by 2°C.
Every time you press the button, the
temperature will go down and then return to
the highest setting. Release at the desired
temperature and the new set temperature
will be stored.
Fresh Freeze Function
When you press “Fresh Freeze” button, the
compressor will run for about 14 hours.
Fresh Freeze indicator will glow. To cancel
this function press Fresh Freeze button
again. Fresh Freeze indicator will turn off
and return to its normal settings. Fresh
Freeze will cancel itself automatically after
about 12 hours if you do not cancel it.
If you want to freeze large amounts of fresh
food, press the Fresh Freeze button 14
hours before putting the food into the freezer
compartment.
Placing food

Page 20
Quick Cool Function
When you press Quick Cool button, the
temperature of the compartment will be
colder than the adjusted values. This
function can be used for food placed in the
fridge compartment and required to be
cooled down rapidly.
After pressing the Quick Cool button, Quick
Cool indicator will glow. To cancel this
function press the Quick Cool button again.
The Quick Cool indicator will turn off and
return to its normal settings. The Quick Cool
function will cancel itself automatically in
case you do not cancel it.
Vacation Button
In case the fridge compartment will not be
used for a long time, the usage of the fridge
compartment may be cancelled by pressing
the Vacation Button. In this way, the
refrigerator may operate more economically.
ress on Vacation Button for 3 seconds to
activate this function. When this function is
active, the door of the fridge compartment
must be kept closed and no food must be left
in the fridge compartment.
Auto co Button (Special conomy
function)
When the “Auto Eco” button is pressed, the
Auto Economy Function will be activated. If
the door of the fridge compartment is kept
closed for a long time when this function is
selected, the fridge compartment will switch
to a more economic operation mode to save
electricity automatically.
When the Auto Eco button is pressed again,
this function is deactivated.
Ioniser
The ioniser helps purify the air in the fridge,
the process is carried out automatically
Key Lock Button
The key lock is activated when this button is
pressed for 3 seconds and all buttons and
the dispenser latch will not work. If you want
to deactivate the key lock press again for 3
seconds.
Water Dispenser Illumination
When the Light button is pressed, the water
dispenser lamp will light up and it will go off
when the button is pressed again. This
illumination will also light up when the water
dispenser latch is pressed, and it will go off a
short while after the latch is released.
Water/Ice Type Selection
With the Dispenser Selection button, either
one of “water”, “ice cube” or “crushed ice”
options is selected.
Ice/Water Dispenser
With its three different functions, the
dispenser efficiently meets your cold water,
cube ice and crushed ice needs without
having to open the door of the refrigerator. It
is a continuous cold water and ice source
without adding water.
User friendly control panel provides the
following dispensing functions:
Note:
• Water or ice can be dispensed for a
maximum of 90 seconds at each use.
• When the freezer door is open, the
dispenser will not work.
