DEL DL Series User manual

OPERATORS / MAINTENANCE
MANUAL
COLUMN TAILIFTS

3 Issue J
Del Equipment (UK) Ltd Operator/Maintenance Manual - Column Tailifts
INTRODUCTION
This manual covers the operation and maintenance of the column tailift range DL, DD,
DT, DO,FC, GB, NL, S, and TL. The procedures detailed in this manual must be un-
derstood before the tailift is used. The manual should be kept with the vehicle and rec-
ords of regular maintenance must be entered in the spaces provided to form a service
record for the lift.
IMPORTANT
This manual forms part of the Inspection record for the tailift, and should be passed on
to the end user, together with the installation handbook.
CONTENTS
OPERATORS MANUAL PAGE
1. Warranty……………………………………………………………………… 4
2. Operating systems………………………………………………………….. 8
3. Safety features……………………………………………………………….. 9
4. Warning decals……………………………………………………………….. 10
5. Intended and unsafe uses………………………………………………….. 13
6. Safety procedure…………………………………………………...……..…. 13
7. Hand controls…………………………………………………………..…….. 14
8. Working area…………………………………………………….……..…….. 15
9. Operating instructions - Stow lock lifts ……..……………………………… 16
10 Operating instructions - Power lock lifts …...………………..…………….. 17
11 Operating instructions - Combination latch lock lifts ..….......................... 18
12 Operating instructions - Anti-luce lock lifts ……….................................... 19
13 Operating instructions - Dump over lifts ….......……………………........ 20
14 Operating instructions - Dump through ….............................................. 22
15 Operating instructions - Full Closure ……………………………………… 24
16 Safety guard operation.................................................................................. 25
17 Loading and unloading procedure…………………………………………. 30
18 Link bridge procedure………………………………………………..……… 30
MAINTENANCE MANUAL
1. Introduction.....…………………………………………….………................ 31
2. Notes about Loler and Puwer regulations................................................ 31
3. Safety information…………………………………………………….…..….. 33
4. Maintenance procedure………………………………………….………… 34
5. Thorough examinations….…………………………………….…..………. 36
6. Tailift service record………………………..……….…..………………….. 41
7. Tailift service Schedule………………………………………….………….. 43
8. Record of major repairs…………………………………………….……….. 47
9. Fault finding ……………………………………………….………………… 48
10. Wiring and hydraulic diagrams…………………………………………….. 50
11. DEL Warranty and registration form...................................................... 54

4 Issue J
Del Equipment (UK) Ltd Operator/Maintenance Manual - Column Tailifts
1. WARRANTY
The lift you have purchased is one of the DEL Equipment range of Tailifts. We are
pleased you have chosen DEL and would like to ensure that you have the best ser-
vice throughout the life of the lift.
Our lifts are covered by a 12-month warranty against faulty parts or assembly, subject
to our conditions below and our normal conditions of sale. To obtain details of your
nearest service centre plus updated information of the DEL range please complete
and return the enclosed registration form.
PRODUCT WARRANTY TERMS AND CONDITIONS
Date of Issue: January 1st, 2010
Scope: This document replaces all previous documents issued and is effective from
the date of issue. Unless otherwise agreed in writing the following terms and condi-
tions will apply.
DEL Equipment (UK) Ltd (herein referred to as DEL) withhold the right to revise these
terms and conditions without prior notice at any time in the future.
General Terms and Conditions
1.1 DEL warrants its Customer and/or End User of its products, provided it has re-
ceived payment in full for the goods, that it will repair/replace, either in its factory or
through one of its approved Service Agents, without charge, any original part of any
DEL product found to be faulty within twelve months of installation or within fifteen
months after the date of despatch from its factory, whichever is the shortest, which is
proven to the satisfaction of DEL to be defective.
1.2 Warranty covers failure of DEL products and does not include installation (unless
fitted by DEL) of the product or any part of the product associated with the installation.
This is solely at DEL’s discretion.
1.3 To substantiate the claim DEL will want clear product identification (the serial num-
ber), may require proof of purchase, may want to inspect the product on its Custom-
er’s premises and may insist that the defective product be returned to DEL (at DEL’s
cost).
1.4 In the event repairs are required to a DEL product “in the field”, DEL will authorise
its own engineers or instruct (with a relevant authorisation number) one of its ap-
proved Service Agents to carry out the necessary work and will pay the Service Agent
direct. In the event that the Customer or End User is willing and capable of carrying
out the repair work themselves, costs must be agreed in advance and a pre authorisa-
tion number must be obtained from DEL.
1.5 If during the warranty period, the DEL product is rejected by the bodybuilder/DEL
product fitter, as being not fit for purpose due to poor

5 Issue J
Del Equipment (UK) Ltd Operator/Maintenance Manual - Column Tailifts
workmanship, sub-standard performance or other quality defects, DEL will replace or
repair the DEL product either on site or in its own factory. Costs covered by DEL would
include any removal and re-fitting of the DEL product to the vehicle, additional trans-
portation and labour plus materials to replace/repair.
1.6 In the event the DEL product is not accepted by the Customer because the wrong
specification was ordered or because the End User changed his mind after DEL prod-
uct build, DEL will endeavour to take the DEL product back into stock but reserve the
right to apply a handling charge and to recover all of its transportation costs. In addition
a product devaluation charge will be applicable, the value of which will be dependent
on the condition and age of the DEL product and upon whether the DEL product is a
“special” or a standard DEL product.
1.7 The warranty will be invalid if any of the following (but not limited to) is shown to
have happened: accidental damage, product overload, operator error/abuse, product
not installed properly, product not serviced (and greased) regularly.
1.8 The warranty will be invalid if the cause of the breakdown (or other problem) is
found to be the result of a defect with another part of the vehicle e.g. a PTO problem or
a vehicle electrical fault.
1.9 The warranty will be invalid if it is established that DEL has not received payment in
full for the DEL product, e.g. if the goods have been stolen or if DEL’s customer has
been unable or unwilling to pay for the goods.
1.10 The warranty will be invalid if it is shown that the problem/failure has been caused
(or contributed to) by non-DEL parts, which were fitted during an earlier service.
1.11 The warranty will be invalid if the failure is shown to have been caused by any un-
authorised modifications to the DEL product. DEL approved modifications must always
be in writing.
1.12 On no account will DEL accept consequential losses of any description. These
include but are not limited to: handling charges, replacement vehicle hire, delivery pen-
alty clause, loss of business opportunity.
1.13 Because DEL’s service network covers all of the UK, the warranty applies only to
DEL products which have been purchased in the UK and which remain on the main-
land.
1.14 If during the warranty period, DEL replacement parts have been fitted; these re-
placement parts will have a further 12 months warranty for both parts and labour.
1.15 Warranty consideration will only be given providing the customer and Service
Agent follow the correct warranty procedure. The customer must contact DEL prior to
carrying out any work for authorisation or contact DEL or a DEL approved Service
Agent if they require breakdown assistance. DEL

6 Issue J
Del Equipment (UK) Ltd Operator/Maintenance Manual - Column Tailifts
Service Agents must adhere to the Service Level Agreement they have signed with
DEL (Service Agents see Service Agent SLA).
1.16 Any breakdown at any location found not to be covered by DEL warranty, regard-
less of fault, will be chargeable to the company that called the job in to DEL. Calling a
breakdown in to DEL or a DEL Service Agent will be taken as acceptance of this condi-
tion.
1.17 No warranty will be given for any failure due to chemical corrosion and physical
erosion
1.18 No warranty will be given for any failure caused by Fire, Theft, Freezing, Riot or
Explosion
1.19 No warranty will be given for failure caused by Lightning, Earthquake, Windstorm,
Hail, Water, or Flood.
1.20 No warranty will be given for any part of a Wanderlead Control Assembly.
1.21 Although DEL will always endeavour to repair/replace parts putting the product
back to its original condition, this does not include repainting any part of the product
that has been painted after leaving DEL’s premises. Galvanised/Plated parts will be re-
placed where ever possible, but DEL reserves the right to replace parts using non gal-
vanised/plated parts on occasion, but with a minimum of a primer finish.
Customer Responsibility
2.1 The customer is responsible for the maintenance of the product as specified in the
Operation and Maintenance Handbook issued with the product at point of sale. It is the
customers responsibility to ensure that all operators have read, understood and adhere
to the details given in this booklet. If this booklet is not available, a copy is available
from DEL’s website to download free of charge (visit: www.del-uk.com).
2.2 In addition to regularly greasing the product (see point 2.1); it is the customer’s re-
sponsibility to replace grease/lubricant that has been removed from the product due to
washing/cleaning the vehicle and/or product. This includes products that are on con-
tract maintenance.
2.3 The customer must retain all service documentation, including weight tests and
Statutory Thorough Examinations (STE), which must be available upon request to vali-
date any warranty claim. Failure to maintain the product may invalidate the warranty.
This is solely at DEL’s discretion.
2.4 The customer is responsible for ensuring the product is being used for its intended
purpose only, and has been operated in accordance with the issued instructions.
2.5 In the event of failure, the customer must:

7 Issue J
Del Equipment (UK) Ltd Operator/Maintenance Manual - Column Tailifts
 Use all reasonable means to protect the product from further damage
 Notify DEL Service Department as soon as possible
 Present where requested, proof of warranty coverage and Tailift service
history.
 Use only genuine DEL Parts
3. Additional Specific Standard Warranty Exclusions
In addition to the above terms and conditions the following warranty exclusions will ap-
ply. Please note that some of these exclusions are product specific and therefore may
not be relevant to all products.
3.1 First Year Exclusions:
 Minor adjustments such as (but not limited to) chain adjustment, pressure ad-
justment, flow adjustment.
 Any form of maintenance such as (but not limited to) lubrication, oil replace-
ment.
 Pressure Filters – Filters are required to be replaced on all bin lifts, where ap-
plicable, after the first 3000 cycles (approximately 1 month of use for a typical
user) and then every 6 months thereafter.
 The following parts are excluded after 12 weeks from the start of the warranta-
ble period (see point 1.1): bulbs, fuses, electrical connections
4. Additional Specific Extended Warranty Exclusions
In addition to the above terms and conditions the following warranty exclusions will ap-
ply to products purchased with extended warranty and/or put on Contract Maintenance
with extended warranty. Please note that some of these exclusions are product specific
and therefore may not be relevant to all products.
4.1 Second Year exclusions:
 Hydraulic hoses
 All hydraulic fittings, including loose fittings
 All electrical wiring, including loose connections
 All maintenance replacement parts such as (but not limited to) bushes, bear-
ings, rollers, pins
 Wear and tear on any part
 All non standard electrical lift options such as (but not limited to) flashing
lights, warning buzzers
4.2 Third Year exclusions:
 Chain stretch/wear
 Torsion Bar failure or loss of torsion

8 Issue J
Del Equipment (UK) Ltd Operator/Maintenance Manual - Column Tailifts
2. OPERATING SYSTEMS
The tailift is powered from the vehicle battery. A wire is taken from the battery positive to
the powerpack starter switch and the hand control. These circuits are protected by in-line
fuses. The power to the hand control is isolated by a switch in the driver’s cab. When the
isolation switch is switched on, the up button on the hand control provides power to the
starter switch, which operates the powerpack motor. This pumps high-pressure hydraulic
fluid to extend the ram. On release of the up button the fluid is held in the ram due to a non
return valve which locks the ram in position therefore holding the platform stationary. Push-
ing the down button powers the lowering solenoid, which allows the hydraulic fluid back
from the ram to the power pack reservoir. The ram is connected to the powerpack with two
pipes, one is the high pressure feed hose the other is the low pressure return hose to the
reservoir. The ram pushes two chains, which, via a sprocket system, are connected to the
sliders at each side of the platform, which run inside the lift columns. When the down but-
ton is pressed the platform lowers by gravity. Each slider has a load safety device, which,
in the unlikely event of a chain break, jams the slider in its column. The opening and clos-
ing of the platform is torsion bar assisted. The torsion bar is pre-set on manufacture and
located inside the platform and is not a user serviceable part. The platform is stowed verti-
cally when not in use and is held in place by the platform locks. Care must be taken when
stowing the platform that the locks are correctly engaged and the stow indicator (if fitted) in
the drivers cab is off.

9 Issue J
Del Equipment (UK) Ltd Operator/Maintenance Manual - Column Tailifts
3. SAFETY FEATURES
Before operating the tailift be sure you understand the safety devices fitted, and ensure
that they are in good working order by following the regular maintenance program.
CIRCUIT BREAKERS
Fuses protect the electrical circuits. In the case of any electrical fault they will protect the
tailift from any damage to its electrical systems. It is possible to disconnect the electrical
supply by removing the fuse.
ISOLATION SWITCH
The isolation switch located in the drivers cab ensures that the lift cannot be operated
whilst the vehicle is moving or whilst it is left unattended. The lift must ALWAYS be isolat-
ed after use.
LIFTING LOADS – RELIEF VALVE
The power pack is equipped with a pressure relief valve, which ensures that a gross over-
load of the lift, which may damage critical parts cannot be lifted. This valve is set on in-
stallation to ensure that the lift cannot raise a load 25% more than the safe working load.
LOWERING LOADS – FLOW REGULATOR
The returning oil from the ram passes through a flow regulator valve, ensuring the plat-
form lowers at a controlled speed irrespective of the load.
Note – The platform must not be overloaded on lowering, as this will cause permanent
damage to the lift operation.
LOAD SAFETY DEVICE (LSD)
Each slider has its own LSD located inside the column. In the unlikely event of a chain
failure the LSD will activate, jamming the slider in the column. The lift will not drop more
than 100mm from its position at the time of failure.
3 WAY FOLDING RAMP/CART STOP
On platforms equipped with a 3 way folding ramp, the edge of the ramp can be fixed in a
vertical position to ensure that loads cannot roll/fall from the loading edge of the platform
whilst lifting or lowering. A platform fitted with ‘cart stops’ has a similar effect.
CONTROL BOXES
The buttons are designed so they are just large enough to be operated by one finger. This
prevents accidental operation by other objects hitting the control box. The control boxes
themselves are mounted in a steel protective cover.
TOE GUARD
The toe guard is angled in such a way so to reduce the risk of feet being crushed while
the lift is being raised.
PLATFORM
The platform has a rough, anti-skid surface, which ensures that the platform is not slip-
pery in most weather conditions.
STOW INDICATOR (IF FITTED)
The stow indicator in the drivers cab activates when the platform is not in its stowed posi-
tion. Ensure that it is not active before driving the vehicle. If it activates whilst driving, stop
as soon as possible and check that the platform is stowed correctly.
HANDRAILS (IF PROVIDED)
Handrails are fitted wherever there is a risk of falling more than 2 meters.

10 Issue J
Del Equipment (UK) Ltd Operator/Maintenance Manual - Column Tailifts
4. WARNING DECALS
A - LOCATED NEXT TO THE CONTROL BOX. WITH
REMOTE CONTROL OPERATION IT IS LOCATED
ON THE PASSENGER SIDE, AS CLOSE TO THE
LIFT AS POSSIBLE AND AT EYE LEVEL (APPROX.
5 FEET FROM THE GROUND)
B - LOCATED NEXT TO 'A'
C - LOCATED ON THE MAIN HOUSING COVER
ABOVE THE TOE GUARD ON BOTH THE
PASSENGER AND DRIVER SIDE.
D - LOCATED ON THE MAIN HOUSING COVER
ABOVE THE TOE GUARD OR TO THE RIGHT
OF 'B'
E - LOCATED NEXT TO 'B'
F - LOCATED AROUND THE
POSITIVE CABLE FROM THE
LIFT TO THE BATTERY
G - LOCATED IN THE DRIVERS CAB AS
CLOSE TO THE STOW INDICATOR
AS POSSIBLE.
J - REFLECTIVE FLAGS LOCATED AT
THE TOP OF THE PLATFORM ON
BOTH SIDES
H - LOCATED IN THE DRIVERS CAB AS
CLOSE TO THE ISOLATION SWITCH
AS POSSIBLE.
K - LOCATED ON THE MAIN HOUSING
OR ON THE POWER PACK BOX
(CHASSIS PACKS)
L - LOCATED ON THE EDGE OF BOTH
SIDES OF THE PLATFORM
A) TAILIFT OPERATION B) CAUTION C) WARNING
D) MAX LOAD E) MAINTENANCE F) TAILIFT ISOLATION
AUDIBLE-VISUAL WARNING SIGNAL
Audible-Visual warning signals are provided wherever there is a risk of falling more than 2
metres.

11 Issue J
Del Equipment (UK) Ltd Operator/Maintenance Manual - Column Tailifts
G) STOW INDICATOR (ON
DASHBOARD)
TEL. [phone] Pt No 52415
ON T
A
I
L
I
F
T
I
S
O
L
A
T
O
R
H) ISOLATION
(ON DASHBOARD)
J - FLAGS
K) ISOLATE POWER SUPPLY L) KEEP FEET CLEAR
FULL SURROUND GUARD OPERATION
(WHERE APPLICABLE) (UNDER B AREA)
N)SELF ERECT GUARD OPERATION
(WHERE APPLICABLE)
GUARDS WARNING DECALS
M
N

12 Issue J
Del Equipment (UK) Ltd Operator/Maintenance Manual - Column Tailifts
IMPORTANT
Before use, the lift should be inspected to check that all warning decals are present and
legible, if not contact DEL Sales for replacements.
LIFT OPERATION DECAL POSITIONS, DUMPOVER LIFTS
Affix the ‘TAILIFT OPERATION, and ‘HOLD HERE TO OPEN & CLOSE PLATFORM’
decals where shown.
DUMPOVER TAILIFT OPERATION HOLD HERE TO OPEN & CLOSE
PLATFORM
M)DUAL MODE GUARDS AND DROP
DOWN OPERATION (WHERE APPLICABLE)
N)DUAL MODE GUARDS AND DROP
DOWN OPERATION (WHERE APPLICABLE)

13 Issue J
Del Equipment (UK) Ltd Operator/Maintenance Manual - Column Tailifts
5. INTENDED AND UNSAFE USES
INTENDED USES
The Column Lifts are intended for: -
 Lifting of loads vertically from the ground to vehicle bed height and vice-versa.
 Lifting of the load and the operator only, where the operator has been trained to
use the lift following all safety procedures.
 Lifting and lowering of loads no heavier than the safe working load of the lift fitted.
 DO/DT type lifts are to be used on tipping vehicles and form the vehicle tailgate.
UNSAFE USES
The following are un- safe practices, which may damage the lift and cause
risk of personnel injury: -
 Driving a forklift onto the platform.
 Using the lift as a jack.
 Using the lift as a link bridge.
 Using the platform as a step to the truck bed.
 Lifting unstable/wheeled loads without special precautions
 Use as a passenger lift
 Driving the vehicle with the platform open.
 Overloading the platform when loading from the vehicle to the platform.
6. SAFETY PROCEDURE
Before operating the lift be sure to understand the following instructions: -
1. Read and be familiar with the safety instructions and warning decals before oper-
ating the lift.
2. Be sure the vehicle is on level ground, securely braked and that there is adequate
lighting in the working area.
3. Inspect the lift for maintenance or damage. If there are any signs of damage do
not use the lift or attempt repairs unless you have been specifically trained.
4. Clear the working area of any obstructions.
5. Do not overload the lift. Note that the safe working load of the lift applies to both
lifting and lowering operations.
6. Make sure the centre of the load is placed as near to the centre of the platform as
possible. If wheeled loads are lifted ensure these are securely braked and that
available safety devices are used (3 way folding ramp/cart stop)
7. Make sure that whenever you intend to ride the platform that you leave enough
room to stand without risk of falling.
8. Make sure the platform is securely stowed in its travelling locks and that the stow
indicator (if fitted) is out before driving the vehicle
9. Always isolate the lift (with the in-cab switch) after use.

14 Issue J
Del Equipment (UK) Ltd Operator/Maintenance Manual - Column Tailifts
7. HAND CONTROLS
STANDARD CONTROL
SWITCH
LOWER
RAISE
LOWER CONTROL
UPPER CONTROL
RAISE
LOWER
Standard control mounted at the
rear of the trailer on the passen-
ger side.
The 3-button control has a rotary
switch, which isolates the 2 button
when the 3 button is in use.
The 3-button control is typically sit-
uated at the rear inside of the body
at hand height.
DUAL CONTROL

15 Issue J
Del Equipment (UK) Ltd Operator/Maintenance Manual - Column Tailifts
WORKING AREA
DANGER ZONE
SURROUNDING AREA
8. WORKING AREA
The push button controls are located is such a position to give: -
 A good view of the working and surrounding areas.
 A secure position away from passing traffic
 Where two hand controls are used they provide protection for the hands from
crushing.
The position of the controls should not be changed.
Always ensure that there is sufficient lighting to the working and surrounding area
NOTE
The danger zone is the area in which the platform travels, and under no circumstances
should this be entered while the platform is in its operating position.
The working area is the area around the platform in which the operator can stand while
the platform is in its operating position. If anyone other than the operator enters this area
while the lift is in use, any raising or lowering operation, which is being performed, must
be stopped immediately.
Surrounding area is the area around the working area. The operator should be aware of
the surrounding area and look for any potential hazards.

16 Issue J
Del Equipment (UK) Ltd Operator/Maintenance Manual - Column Tailifts
REVERSE SIDE
PLATFORM EAR
LIFT CATCH
HOLD HERE
LOWER PLATFORM
TO HORIZONTAL POSITION
LOWER PLATFORM
9. OPERATING INSTRUCTIONS – STOW LOCK LIFTS
1. Switch on the tailift isolation switch in the driver’s cab or plug in the Wan-
derlead control.
2. Ensure the working area is clear from obstructions
3. Press the raise button to ensure the lift is at bed height.
4. Approaching the lift from the passenger side, hold the edge of the platform and
lift the stow lock catch.
IMPORTANT – Always stand to one side of the lift when opening the platform,
Never in front of the platform
5. Lower the platform to the horizontal position before lowering the platform to the
floor using the hand control.
TO CLOSE
1. Raise the platform to bed level
2. Fold up the platform into the stow lock.
3. Using the hand control, lower the platform into the lock.
4. Switch off the isolation switch or disconnect the Wanderlead control and ensure
that the stow warning light (where fitted) is out before driving the vehicle.

17 Issue J
Del Equipment (UK) Ltd Operator/Maintenance Manual - Column Tailifts
10. OPERATING INSTRUCTIONS – POWER LOCK LIFTS
1. Switch on the tailift isolation switch in the driver’s cab or plug in the Wanderlead
control.
2. Ensure the working area is clear from obstructions.
3. Stand to the left side of the platform (Caution: Do not stand in the path of the
platform).
4. Push the ‘LOWER’ button, to lower the platform out of it’s lock to a convenient
safe height for opening (see drawing 1).
5. Lift the safety catch (see drawing 2) and open the platform to the horizontal posi-
tion (see drawing 3).
Caution: In the event of torsion bar spring failure, the platform may deploy from
its stowed position with greater force than usual.
DO NOT ATTEMPT TO CONTROL THE OPENING OF THE PLATFORM.
Release the platform and stand clear.
6. Lower the platform to the ground.
1.
TO CLOSE
1. Push the ‘RAISE’ button, to raise the platform to a convenient height for closing
(Note that this must be at least 100mm below bed level for the stow ear to clear
the power lock)
2. Release the anti-tilt catch (see drawing 4) and close the platform to the vertical
position, ensuring that the safety catch engages (see drawing 5).
3. Raise the platform up into the ‘stow’ position, ensuring that the platform ear lo-
cates fully into the power lock (see drawing 6).
4. Switch off the isolation switch or disconnect the Wanderlead control and ensure
that the stow warning light (where fitted) is out before driving the vehicle.

18 Issue J
Del Equipment (UK) Ltd Operator/Maintenance Manual - Column Tailifts
11. OPERATING INSTRUCTIONS - COMBINATION LATCH LOCK LIFTS
1. Switch on the tailift isolation switch in the driver’s cab or plug in the Wanderlead
control.
2. Ensure the working area is clear from obstructions.
3. Stand to the left side of the platform (Caution: Do not stand in the path of the
platform).
4. Push the ‘LOWER’ button, to lower the platform out of it’s lock to a convenient safe
height for opening (see drawing 1).
5. Rotate / Lift the safety catch (see drawing 2) and open the platform to the horizontal
position (see drawing 3).
Caution: In the event of torsion bar spring failure, the platform may deploy from its
stowed position with greater force than usual.
DO NOT ATTEMPT TO CONTROL THE OPENING OF THE PLATFORM.
Release the platform and stand clear.
6. Lower the platform to the ground.
1.
TO CLOSE
1. Push the ‘RAISE’ button, to raise the platform to a convenient height for closing (Note
that this must be at least 100mm below bed level for the stow ear to clear the power
lock)
2. Rotate / Lift the platform catch (see drawing 4) and close the platform to the vertical
position, ensuring that the safety catch engages (see drawing 5).
3. Raise the platform up into the ‘stow’ position, ensuring that the platform ear locates ful-
ly into the power lock (see drawing 6).
4. Switch off the isolation switch or disconnect the Wanderlead control and ensure that
the stow warning light (where fitted) is out before driving the vehicle.

19 Issue J
Del Equipment (UK) Ltd Operator/Maintenance Manual - Column Tailifts
12. OPERATING INSTRUCTIONS - ANTI-LUCE LOCK LIFTS
1. Switch on the tailift isolation switch in the driver’s cab or plug in the Wanderlead
control.
2. Ensure the working area is clear from obstructions.
3. Stand to the left side of the platform (Caution: Do not stand in the path of the
platform).
4. Push the ‘LOWER’ button, to lower the platform to a convenient safe height for
opening (see drawing 1).
5. Open the Anti-Luce catch both sides (see drawing 2) and open the platform to the
horizontal position (see drawing 3).
Caution: In the event of torsion bar spring failure, the platform may deploy from its
stowed position with greater force than usual.
DO NOT ATTEMPT TO CONTROL THE OPENING OF THE PLATFORM.
Release the platform and stand clear.
6. Lower the platform to the ground.
1.
TO CLOSE
1. Push the ‘RAISE’ button, to raise the platform to a convenient height for closing
(Note that this must be at least 100mm below bed level for the stow ear to clear the
power lock).
2. Release the anti-tilt catch (see drawing 4) and close the platform to the vertical po-
sition, ensuring that the Anti-Luce catches engage (see drawing 5).
3. Close Anti-Luce catch both sides.
4. Raise the platform up into the ‘stow’ position, ensuring that the platform ear locates
fully into the power lock (see drawing 6).
5. Switch off the isolation switch or disconnect the Wanderlead control and ensure
that the stow warning light (where fitted) is out before driving the vehicle.

20 Issue J
Del Equipment (UK) Ltd Operator/Maintenance Manual - Column Tailifts
13. OPERATING INSTRUCTIONS - DUMP OVER
OPENING INSTRUCTIONS
1. Switch on the isolator switch in the driver’s cab.
2. Lower the platform from the tailgate position to a midway position between the two
locks (see drawing 1)
3. Lift platform catch (see drawing 2)
4. Open the platform to the horizontal position (see drawing 3).
5. Unfold platform and lower the lift to the ground (drawing 4).
