Denios PolySafe Depot Type C User manual

User Manual
216374_BA_PSD_C_2C_D_004_EN
10.06.15
User Manual
PolySafe Depot Type C / 2C / D
Type C
Type D
Type 2C
DENIOS AG
Dehmer Straße 58-66
32549 Bad Oeynhausen
Tel.: [phone]
Fax: [phone]
E-mail: [email protected]
Find your local contact on our website www.denios.com

User Manual
216374_BA_PSD_C_2C_D_004_EN
Page 2 of 8 10.06.15/2015
1General Instructions ........................................................................................................................ 3
1.1 Intended use of the equipment ...................................................................................................3
1.2 Misuse.........................................................................................................................................3
1.3 Claims for defects and liability ....................................................................................................4
2Safety instructions........................................................................................................................... 4
3Transport, placement and installation .............................................................................................. 4
3.1 Transport using lifting equipment................................................................................................4
3.2 Conditions for placement ............................................................................................................4
3.3 Installation and placement ..........................................................................................................5
4Technical data ................................................................................................................................ 5
4.1 Dimensions and data ..................................................................................................................5
5Operation........................................................................................................................................ 6
5.1Safety instructions.......................................................................................................................6
5.2 Loading the Depot.......................................................................................................................6
6Maintenance and care..................................................................................................................... 6
7Disposal.......................................................................................................................................... 6

User Manual
216374_BA_PSD_C_2C_D_004_EN
Page 3 of 8 10.06.15/2015
1General Instructions
The instructions in this user manual must be carefully noted and followed. All those involved in the
installation, operation, maintenance and repair of the product must have read and understood this user
manual.
We reserve the right to make technical changes to the illustrations and details in the user manual in order
to improve the storage system.
NOTE
The national guidelines and safety regulations with respect to hazardous materials,
safety regulations, occupational safety and operator duties must be observed.
1.1 Intended use of the equipment
PolySafe Depots Type C / 2C / D are suited to the storage of water-polluting substances in all water-
polluting classes WGK 1-3 in accordance with WHG / VAUwS (Water Hazard Law / Ordinance on Facilities
for Handling Substances Hazardous to Water) with a flashpoint over 100°C, which are stored in approved
containers, either indoors or outdoors. Fluids in accordance with DIBt media list 40-1.1 with a reduction
ratio A2 = 1.0 require no special proof of sealing and resistance, which also applies to the following
materials groups: aqueous solutions of organic acids up to 10%, mineral acids up to 20 % as well as acid
hydrolising salts in an aqueous solution (ph<6) apart from hydrofluoric acid and oxidising acids and salts,
inorganic alkalis as well as alkali hydrolising salts in an aqueous solution (pH > 8), with the exception of
ammonia solutions and oxidising solutions of salts (eg hypochlorite), solutions of inorganic non-oxidising
salts with a pH value between 6 and 8.
The storage systems should be used exclusively within the performance parameters listed in "
Technical data".
1.2 Misuse
The following are considered as misuse:
Storage of inadmissible materials: The resistance of the sump material to the storage medium must
be demonstrated.
Use of the sump for purposes other than those specified in section 1.1 Intended use of the
equipment .
Storage of inadmissible containers: Containers must comply with guidelines for the transport of
hazardous goods.
Unapproved combinations: Media which can react with one another may not be stored above the
same sump.
Exceeding storage quantity and load capacity.

User Manual
216374_BA_PSD_C_2C_D_004_EN
Page 4 of 8 10.06.15/2015
1.3 Claims for defects and liability
We are not liable for claims for defects and liability for injury to persons or property caused by one or more
of the following:
Improper use of equipment
Incorrect installation, operation and maintenance.
Unapproved modifications.
2Safety instructions
WARNING
Refrain from any unsafe working practices.
Observe the applicable rules for health and safety at work.
No fire, naked flames or smoking.
Packaging and containers must meet the transport regulations.
Only store materials for which the sump is designed.
Do not exceed the load capacity of the sump.
Store materials so that all containers and the sump are visible.
Any build up of snow on the cover must be removed immediately.
3Transport, placement and installation
3.1 Transport using lifting equipment
Transport the Depot only when empty.
The Depot can be lifted and transported from two sides by a forklift truck or a pallet truck.
3.2 Conditions for placement
The Depot must only be assembled on even, paved surfaces. The Depot is suitable for installation
outdoors or indoors. The Depot must not be located on a roadway and must be protected from damage by
vehicles using appropriate means (eg impact protection barriers). When located outdoors, the Depot must
have sufficient protection from wind, rain and snow etc. and direct sunshine (eg by a shelter).

User Manual
216374_BA_PSD_C_2C_D_004_EN
Page 5 of 8 10.06.15/2015
3.3 Installation and placement
Remove the packing foil.
Ensure the PolySafe Depot is installed
level at the final placement location (base
plates are available). When correctly
installed, the doors should be able to be
easily closed and locked.
Mounting kit (optional)
Mark the mounting points.
Drill the holes for the pins (ø12mm,
140mm deep) for the ground anchor
supplied.
Fit the ground anchor in the holes.
Install the PolySafe Depot (using the
base plates if necessary).
Secure the Depot to the floor and secure
the mounting brackets to the internal
thread on the lower edge of the sump.
Tighten the nuts to a torque of
Tinst = 45 Nm.
4Technical data
The Depot is manufactured from weather resistant, corrosion-free polyethylene (PE-LLD). The double wing
doors can be locked. The Depot is supplied ready for mounting to the floor. Operational temperature range:
-20°c to +40°C.
4.1 Dimensions and data
Model
W (mm)
D (mm)
H (mm)
Max. load
Sump capacity (l)
Type D
1540
1060
1980
800 kg / evenly distributed load
250
Type C
1540
1530
2330
1800 kg / installation location
1150
Type 2C
3200
1750
2170
1800 kg / installation location
1200

User Manual
216374_BA_PSD_C_2C_D_004_EN
Page 6 of 8 10.06.15/2015
5Operation
5.1 Safety instructions
WARNING
Note safety regulations!
The safety instructions in section "Safety instructions" must be observed.
5.2 Loading the Depot
Open the Depot doors.
Use suitable equipment to help load the Depot.
Check containers are stable after setting them down.
When filling, the handling area must be over the sump, dispensing containers (eg cans) must not
extend over the edge of the sump.
Close the doors once loading is complete.
6Maintenance and care
Regular maintenance and care will extend the life of the Depot.
NOTE
Keep the sump dry and free from contamination.
Check the sump regularly for leaked fluids, and check underneath too.
Safely dispose of leaked fluids immediately.
Lubricate the locks and hinges with commercially available grease.
Check and if necessary tighten the floor mounting bolts.
Only use manufacturer's original replacement parts.
7Disposal
NOTE
Clean the sump thoroughly before disposal to remove any hazardous material residue.
The sump is made from mainly plastic and metal parts. After decommissioning, follow local legislation
when disposing of any waste.

User Manual
216374_BA_PSD_C_2C_D_004_EN
Page 7 of 8 10.06.15/2015

User Manual
216374_BA_PSD_C_2C_D_004_EN
Page 8 of 8 10.06.15/2015
Copyright
In legal terms this User Manual is certification to counteract unfair competition.
Copyright is held by
DENIOS AG
Dehmer Straße 58-66
32549 Bad Oeynhausen
Tel.: [phone]
Fax: [phone]
E-Mail: [email protected]
This User Manual is intended for the operator of the storage system and its personnel. It contains texts,
images and drawings which need the express consent of DENIOS AG before they can be
reproduced,
distributed or
otherwise shared, either in full or in part.
© Copyright DENIOS AG 2015 Not subject to the revision service.
