Denon DN-2600F User manual

DOUBLE CD PLAYER
DN-2600F
FOR ENGLISH READERS PAGE 007 ~ PAGE 027
FÜR DEUTSCHE LESER SEITE 028 ~ SEITE 048
POUR LES LECTEURS FRANCAIS PAGE 049 ~ PAGE 069
PARA LECTORES DE ESPAÑOL PAGINA 070 ~ PAGINA 090
VOOR NEDERLANDSTALIGE LEZERS PAGINA 091 ~ PAGINA 111
FÖR SVENSKA LÄSARE SIDA 112 ~ PAGINA 132
OPERATING INSTRUCTIONS
BEDIENUNGSANLEITUNG
MODE D’EMPLOI
INSTRUCCIONES DE OPERACION
GEBRUIKSAANWIJZING
BRUKSANVISNING
DN-2600F
DN-2600F
REMOTE CONTROL UNIT RC-46
12
OPEN/
CLOSE
1MEMO
PROGRAM
BRAKE PITCH
PITCH BEND
KEY.
CONT./SINGLE TIME
NEXT TR.
SEARCH
EFFECT
START
LOOP
SEARCH SCAN
CUE PLAY/PAUSE MODE
DATA MASTER
PUSH ENTER
PRESET
A
FIL
TAP ON/OFF
RVB FLG
B
END MON.
0%
D
I
G
I
-
S
K
E
Y
B
E
N
D
+
-
REVERSE
LOOP PITCH
PLAY/WRITE STOP
CONT.
ELAPSED
PITCH %
ms
f
LOOP
BRAKE PROG.
A1 B
LOOP
SAMP
DN-2600F
12
OPEN/
CLOSE
1MEMO
PROGRAM
BRAKE PITCH
PITCH BEND
KEY.
CONT./SINGLE TIME
NEXT TR.
SEARCH
EFFECT
START
LOOP
SEARCH SCAN
CUE PLAY/PAUSE MODE
DATA MASTER
PUSH ENTER
PRESET
A
FIL
TAP ON/OFF
RVB FLG
B
END MON.
0%
D
I
G
I
-
S
K
E
Y
B
E
N
D
+
-
REVERSE
LOOP PITCH
PLAY/WRITE STOP
CONT.
ELAPSED
PITCH %
ms
f
LOOP
BRAKE PROG.
A1 B
LOOP
SAMP
DN-2600F
DN-2600F

2
LABELS (for U.S.A. model only)
CERTIFICATION
THIS PRODUCT COMPLIES WITH DHHS RULES 21 CFR SUBCHAPTER
J APPLICABLE AT DATE OF MANUFACTURE.
CAUTION:
1. Handle the power supply cord carefully
Do not damage or deform the power supply cord. If it is damaged or
deformed, it may cause electric shock or malfunction when used. When
removing from wall outlet, be sure to remove by holding the plug
attachment and not by pulling the cord.
2. Do not open the top cover
In order to prevent electric shock, do not open the top cover.
If problems occur, contact your DENON dealer.
3. Do not place anything inside
Do not place metal objects or spill liquid inside the CD player.
Electric shock or malfunction may result.
Please, record and retain the Model name and serial number of your set shown
on the rating label.
Model No. DN-2600F Serial No.
NOTE:
This CD player uses the semiconductor laser. To allow you to enjoy music at a
stable operation, it is recommended to use this in a room of 5 °C (41 °F) –35 °C
(95 °F).
CAUTION:
USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCE-
DURES OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT IN HAZ-
ARDOUS RADIATION EXPOSURE.
THE COMPACT DISC PLAYER SHOULD NOT BE ADJUSTED OR REPAIRED
BY ANYONE EXCEPT PROPERLY QUALIFIED SERVICE PERSONNEL.
This device complies with Part 15 of the FCC Rules. Operation
is subject to the following two conditions : (1) This device may
not cause harmful interference, and (2) this device must accept
any interference received, including interference that may
cause undesired operation.
This Class B digital apparatus meets all requirements of the
Canadian Interference-Causing Equipment Regulations.
Cet appareil numérique de la classe B respecte toutes les
exigences du Règlement sur le matériel brouilleur du Canada.
CLASS 1 LASER PRODUCT
LUOKAN 1 LASERLAITE
KLASS 1 LASERAPPARAT
,
CLASS 1
LASER PRODUCT,
,,
ADVARSEL: USYNLIG LASERSTRÅLING VED ÅBNING, NÅR
SIKKERHEDSAFBRYDERE ER UDE AF FUNKTION.
UNDGÅ UDSAETTELSE FOR STRÅLING.
VAROITUS! LAITTEEN KÄYTTÄMINEN MUULLA KUIN TÄSSÄ
KÄYTTÖOHJEESSA MAINITULLA TAVALLA SAATTAA
ALTISTAA KÄYTTÄJÄN TURVALLISUUSLUOKAN 1
YLITTÄVÄLLE NÄKYMÄMTTÖMÄLLE LASERSÄTEILYLLE.
VARNING– OM APPARATEN ANVÄNDS PÅ ANNAT SÄTT ÄN I DENNA
BRUKSANVISNING SPECIFICERATS, KAN ANVÄNDAREN
UTSÄTTAS FÖR OSYNLIG LASERSTRÅLNING SOM
ÖVERSKRIDER GRÄNSEN FÖR LASERKLASS 1.
•FOR U.S.A. & CANADA MODEL ONLY
CAUTION
TO PREVENT ELECTRIC SHOCK DO NOT USE THIS
(POLARIZED) PLUG WITH AN EXTENSION CORD,
RECEPTACLE OR OTHER OUTLET UNLESS THE BLADES
CAN BE FULLY INSERTED TO PREVENT BLADE EXPOSURE.
•POUR LES MODELES AMERICAINS ET
CANADIENS UNIQUEMENT
ATTENTION
POUR PREVENIR LES CHOCS ELECTRIQUES NE PAS
UTILISER CETTE FICHE POLARISEE AVEC UN
PROLONGATEUR UNE PRISE DE COURANT OU UNE AUTRE
SORTIE DE COURANT, SAUF SI LES LAMES PEUVENT ETRE
INSEREES A FOND SANS EN LAISSER AUCUNE PARTIE A
DECOUVERT.
IMPORTANT TO SAFETY
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO
NOT REMOVE COVER (OR BACK). NO USER-
SERVICEABLE PARTS INSIDE. REFER SERVICING
TO QUALIFIED SERVICE PERSONNEL.
The lightning flash with arrowhead symbol, within an
equilateral triangle, is intended to alert the user to the
presence of uninsulated “dangerous voltage” within
the product’s enclosure that may be of sufficient
magnitude to constitute a risk of electric shock to
persons.
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of
important operating and maintenance (servicing)
instructions in the literature accompanying the
appliance.
WARNING:
TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE
THIS APPLIANCE TO RAIN OR MOISTURE.

3
SAFETY INSTRUCTIONS
1. Read Instructions – All the safety and operating
instructions should be read before the appliance is
operated.
2. Retain Instructions – The safety and operating instructions
should be retained for future reference.
3. Heed Warning – All warnings on the appliance and in the
operating instructions should be adhered to.
4. Following Instructions – All operating and use instructions
should be followed.
5. Water and Moisture – The appliance should not be used
near water – for example, near a bathtub, washbbowl,
kitchen sink, laundry tub, in a wet basement, or near a
swimming pool, and the like.
6. Carts and Stands – The appliance should be used only with
a cart or stand that is recommended by the manufacturer.
6A. An appliance and cart
combination should be
moved with care.
Quick stops, excessive
force, and uneven
surfaces may cause
the appliance and cart
combination to overturn.
7. Wall or Ceiling Mounting – The appliance should be
mounted to a wall or ceiling only as recommended by the
manufacturer.
8. Ventilation – The appliance should be situated so that its
location or position does not interfere with its proper
ventilation. For example, the appliance should not be
situated on a bed, sofa, rug, or similar surface that may
block the ventilation openings; or, placed in a built-in
installation, such as a bookcase or cabinet that may
impede the flow of air through the ventilation openings.
9. Heat – The appliance should be situated away from heat
sources such as radiators, heat registers, stoves, or other
appliances (including amplifiers) that produce heat.
10. Power Sources – The appliance should be connected to a
power supply only of the type described in the operating
instructions or as marked on the appliance.
11. Grounding or Polarization – Precautions should be taken so
that the grounding or polarization means of an appliance is
not defeated.
12. Power-Cord Protection – Power-supply cords should be
routed so that they are not likely to be walked on or
pinched by items placed upon or against them, paying
particular attention to cords at plugs, convenience
receptacles, and the point where they exit from the
appliance.
14. Cleaning – The appliance should be cleaned only as
recommended by the manufacturer.
15. Power Lines – An outdoor antenna should be located away
from power lines.
16. Outdoor Antenna Grounding – If an outside antenna is
connected to the receiver, be sure the antenna system is
grounded so as to provide some protection against voltage
surges and built-up static charges. Article 810 of the
National Electrical Code, ANSI/NFPA 70, provides
information with regard to proper grounding of the mast
and supporting structure, grounding of the lead-in wire to
an antenna-discharge unit, size of grounding conductors,
location of antenna-discharge unit, connection to grounding
electrodes, and requirements for the grounding electrode.
See Figure A.
17. Nonuse Periods – The power cord of the appliance should
be unplugged from the outlet when left unused for a long
period of time.
18. Object and Liquid Entry – Care should be taken so that
objects do not fall and liquids are not spilled into the
enclosure through openings.
19. Damage Requiring Service – The appliance should be
serviced by qualified service personnel when:
A. The power-supply cord or the plug has been damaged;
or
B. Objects have fallen, or liquid has been spilled into the
appliance; or
C. The appliance has been exposed to rain; or
D. The appliance does not appear to operate normally or
exhibits a marked change in performance; or
E. The appliance has been dropped, or the enclosure
damaged.
20. Servicing – The user should not attempt to service the
appliance beyond that described in the operating
instructions. All other servicing should be referred to
qualified service personnel.
FIGURE A
EXAMPLE OF ANTENNA GROUNDING
AS PER NATIONAL
ELECTRICAL CODE ANTENNA
LEAD IN
WIRE
GROUND
CLAMP
ELECTRIC
SERVICE
EQUIPMENT
ANTENNA
DISCHARGE UNIT
(NEC SECTION 810-20)
GROUNDING CONDUCTORS
(NEC SECTION 810-21)
GROUND CLAMPS
POWER SERVICE GROUNDING
ELECTRODE SYSTEM
(NEC ART 250, PART H)
NEC - NATIONAL ELECTRICAL CODE

4
NOTE ON USE / HINWEISE ZUM GEBRAUCH / OBSERVATIONS RELATIVES A L’UTILISATION
NOTAS SOBRE EL USO / ALVORENS TE GEBRUIKEN / OBSERVERA
• Avoid high temperatures.
Allow for sufficient heat dispersion when
installed on a rack.
• Vermeiden Sie hohe Temperaturen.
Beachten Sie, daß eine ausreichend
Luftzirkulation gewährleistet wird, wenn
das Gerät auf ein Regal gestellt wird.
• Eviter des températures élevées.
Tenir compte d’une dispersion de chaleur
suffisante lors de l’installation sur une
étagère.
• Evite altas temperaturas.
Permite la suficiente dispersión del calor
cuando está instalado en la consola.
• Vermijd hoge temperaturen.
Zorg voor een degelijk hitteafvoer indien
het apparaat op een rek wordt geplaatst.
• Undvik höga temperaturer.
Se till att det finns möjlighet till god
värmeavledning vid montering i ett rack.
• Keep the set free from moisture, water,
and dust.
• Halten Sie das Gerät von Feuchtigkeit,
Wasser und Staub fern.
• Protéger l’appareil contre l’humidité, l’eau
et lapoussière.
• Mantenga el equipo libre de humedad,
agua y polvo.
• Laat geen vochtigheid, water of stof in het
apparaat binnendringen.
• Utsätt inte apparaten för fukt, vatten och
damm.
• Do not let foreign objects in the set.
• Keine fremden Gegenstände in das Gerät
kommen lassen.
• Ne pas laisser des objets étrangers dans
l’appareil.
• No deje objetos extraños dentro del
equipo.
• Laat geen vreemde voorwerpen in dit
apparaat vallen.
• Se till att främmande föremål inte tränger in
i apparaten.
• Do not let insecticides, benzene, and
thinner come in contact with the set.
• Lassen Sie das Gerät nicht mit Insektiziden,
Benzin oder Verdünnungsmitteln in
Berührung kommen.
• Ne pas mettre en contact des insecticides,
du benzène et un diluant avec l’appareil.
• No permita el contacto de insecticidas,
gasolina y diluyentes con el equipo.
• Laat geen insektenverdelgende middelen,
benzine of verfverdunner met dit apparaat
in kontakt komen.
• Se till att inte insektsmedel på spraybruk,
bensen och thinner kommer i kontakt med
apparatens hölje.
• Never disassemble or modify the set in any
way.
• Versuchen Sie niemals das Gerät
auseinander zu nehmen oder auf jegliche
Art zu verändern.
• Ne jamais démonter ou modifier l’appareil
d’une manière ou d’une autre.
• Nunca desarme o modifique el equipo de
ninguna manera.
• Nooit dit apparaat demonteren of op
andere wijze modifiëren.
• Ta inte isär apparaten och försök inte bygga
om den.
• Unplug the power cord when not using the
set for long periods of time.
• Wenn das Gerät eine längere Zeit nicht
verwendet werden soll, trennen Sie das
Netzkabel vom Netzstecker.
• Débrancher le cordon d’alimentation
lorsque l’appareil n’est pas utilisé pendant
de longues périodes.
• Desconecte el cordón de energía cuando
no utilice el equipo por mucho tiempo.
• Neem altijd het netsnoer uit het
stopkontakt wanneer het apparaat
gedurende een lange periode niet wordt
gebruikt.
• Koppla ur nätkabeln om apparaten inte
kommer att användas i lång tid.
* (For sets with ventilation holes)
• Do not obstruct the ventilation holes.
• Die Belüftungsöffnungen dürfen nicht
verdeckt werden.
• Ne pas obstruer les trous d’aération.
• No obstruya los orificios de ventilación.
• De ventilatieopeningen mogen niet worden
beblokkeerd.
• Täpp inte till ventilationsöppningarna.
• Handle the power cord carefully.
Hold the plug when unplugging the cord.
• Gehen Sie vorsichtig mit dem Netzkabel
um.
Halten Sie das Kabel am Stecker, wenn Sie
den Stecker herausziehen.
• Manipuler le cordon d’alimentation avec
précaution.
Tenir la prise lors du débranchement du
cordon.
• Maneje el cordón de energía con cuidado.
Sostenga el enchufe cuando desconecte el
cordón de energía.
• Hanteer het netsnoer voorzichtig.
Houd het snoer bij de stekker vast wanneer
deze moet worden aan- of losgekoppeld.
• Hantera nätkabeln varsamt.
Håll i kabeln när den kopplas från el-uttaget.
ENGLISHDEUTSCHFRANCAISNEDERLANDSSVENSKA ESPAÑOL

5
ENGLISH DEUTSCH FRANCAIS ESPAÑOL NEDERLANDS SVENSKA
Main Unit / Hauptgerät / Unité principale / Unidad principal / Hoofdtoestel / Huvudenhet /
238 18
DN-2600F
ANALOG
OUT
DIGITAL
OUT FADER REMOTE
2ANALOG
OUT
DIGITAL
OUT FADER
1
L
R
L
R
$2 $3
DN-2600F
DN-2600F
REMOTE CONTROL UNIT RC-46
12
OPEN/
CLOSE
1MEMO
PROGRAM
BRAKE PITCH
PITCH BEND
KEY.
CONT./SINGLE TIME
NEXT TR.
SEARCH
EFFECT
START
LOOP
SEARCH SCAN
CUE PLAY/PAUSE MODE
DATA MASTER
PUSH ENTER
PRESET
A
FIL
TAP ON/OFF
RVB FLG
B
END MON.
0%
D
I
G
I
-
S
K
E
Y
B
E
N
D
+
-
REVERSE
LOOP PITCH
PLAY/WRITE STOP
CONT.
ELAPSED
PITCH %
ms
f
LOOP
BRAKE PROG.
A1 B
LOOP
SAMP
DN-2600F
12
OPEN/
CLOSE
1MEMO
PROGRAM
BRAKE PITCH
PITCH BEND
KEY.
CONT./SINGLE TIME
NEXT TR.
SEARCH
EFFECT
START
LOOP
SEARCH SCAN
CUE PLAY/PAUSE MODE
DATA MASTER
PUSH ENTER
PRESET
A
FIL
TAP ON/OFF
RVB FLG
B
END MON.
0%
D
I
G
I
-
S
K
E
Y
B
E
N
D
+
-
REVERSE
LOOP PITCH
PLAY/WRITE STOP
CONT.
ELAPSED
PITCH %
ms
f
LOOP
BRAKE PROG.
A1 B
LOOP
SAMP
DN-2600F
482
465
re t t re
88
76.2
qw
250 50
2
uoiyuiy
132
57.2
482
465
#0#2 @8 @6
#1 @9 @7 @5#3
#4
#5#6
#7
#9$1
#8
$0
#0#2 @8 @6
#1 @9 @7 @5#3
#4
#5#6
#7
#9$1
#8
$0
@0 @2
!9 @1 @3
!8
!7
!0 !2 !6!4
!5!3!1 @4
@0 @2
!9 @1 @3
!8
!7
!0 !2 !6!4
!5!3!1 @4
7 x 10 hole
Loch 7 x 10
Trou de 7 x 10
Orificio de 7 x 10
Opening 7 x 10
Hål, 7 x 10
Remote Control Unit / Fernbedienungsgerät / Unité de télécommande /
Unidad de control remoto / Afstandsbediening / Fjärrkontroll /
Unit: mm
Gerät: mm
Unité: mm
Unidad: mm
Toestel: mm
Enhet: mm
7 x 10 hole
Loch 7 x 10
Trou de 7 x 10
Orificio de 7 x 10
Opening 7 x 10
Hål, 7 x 10
Unit: mm
Gerät: mm
Unité: mm
Unidad: mm
Toestel: mm
Enhet: mm

6
ENGLISH DEUTSCH FRANCAIS ESPAÑOL NEDERLANDS SVENSKA
• Use compact discs that include the mark.
CD’s with special shapes (heart-shaped CD’s,
octagonal CD’s etc.) cannot be played on this set.
Attempting to do so may damage the set. Do not use
such CD’s.
• Benutzen Sie Compact Discs, die das
Zeichen tragen.
Speziell geformte CD’s (herzförmige CDs, achteckige
CDs, usw.) können auf dieser Anlage nicht abgespielt
werden.
Der Versuch derartige CDs abzuspielen kann die
Anlage beschädigen. Verzichten Sie auf die Benutzung
solcher CDs.
• Utiliser des disques compacts portant le logo .
Des CD avec des formes spéciales (CD en forme de
coeur, des CD octogonaux, etc.) ne peuvent pas être
lus sur cet appareil.
Le fait de l’essayer, risque d’endommager le lecteur.
Ne pas utiliser de tels CD.
• Use discos compactos con la marca .
En este equipo no es posible reproducir CDs con
formas especiales (CDs con forma de corazón, CDs
octagonales, etc.).
Si intenta hacerlo, el equipo podrá resultar dañado. No
use este tipo de CDs.
• Gebruik compact discs voorzien van het logo .
CD’s met speciale vormen (bijv. CD’s in de vorm van
een hart, achthoekige CD’s, enz.) kunnen met dit
toestel niet worden afgespeeld.
Wanneer u dit toch probeert, zal u het toestel
beschadigen. Speel dergelijke CD’s dus niet af.
• Använd CD-skivor med -märket.
Specialformade CD-skivor (hjärtformade, åttkantiga, m
m) går inte att spela på den här apparaten.
Utrustningen kan skadas om du försöker göra detta.
Använd inte CD-skivor av denna typ.
DIGITAL AUDIO
COMPACT
DIGITAL AUDIO
COMPACT
DIGITAL AUDIO
COMPACT
DIGITAL AUDIO
COMPACT
DIGITAL AUDIO
COMPACT
DIGITAL AUDIO
COMPACT
•DECLARATION OF CONFORMITY
We declare under our sole responsibility that this product, to which
this declaration relates, is in conformity with the following standards:
EN60065, EN55013, EN55020, EN61000-3-2 and EN61000-3-3.
Following the provisions of 73/23/EEC, 89/336/EEC and 93/68/EEC
Directive.
•ÜBEREINSTIMMUNGSERKLÄRUNG
Wir erklären unter unserer Verantwortung, daß dieses Produkt, auf
das sich diese Erklärung bezieht, den folgenden Standards
entspricht:
EN60065, EN55013, EN55020, EN61000-3-2 und EN61000-3-3.
Entspricht den Verordnungen der Direktive 73/23/EEC, 89/336/EEC
und 93/68/EEC.
•DECLARATION DE CONFORMITE
Nous déclarons sous notre seule responsabilité que l’appareil, auquel
se réfère cette déclaration, est conforme aux standards suivants:
EN60065, EN55013, EN55020, EN61000-3-2 et EN61000-3-3.
D’après les dispositions de la Directive 73/23/EEC, 89/336/EEC et
93/68/EEC.
•DECLARACIÓN DE CONFORMIDAD
Declaramos bajo nuestra exclusiva responsabilidad que este
producto al que hace referencia esta declaración, está conforme con
los siguientes estándares:
EN60065, EN55013, EN55020, EN61000-3-2 y EN61000-3-3.
Siguiendo las provisiones de las Directivas 73/23/EEC, 89/336/EEC y
93/68/EEC.
•EENVORMIGHEIDSVERKLARING
Wij verklaren uitsluitend op onze verantwoordelijkheid dat dit
produkt, waarop deze verklaring betrekking heeft, in
overeenstemming is met de volgende normen:
EN60065, EN55013, EN55020, EN61000-3-2 en EN61000-3-3.
Volgens de bepalingen van de Richtlijnen 73/23/EEC, 89/336/EEC en
93/68/EEC.
•ÖVERENSSTÄMMELSESINTYG
Härmed intygas helt på eget ansvar att denna produkt, vilken detta
intyg avser, uppfyller följande standarder:
EN60065, EN55013, EN55020, EN61000-3-2 och EN61000-3-3.
Enligt stadgarna i direktiv 73/23/EEC, 89/336/EEC och 93/68/EEC.
DIGITAL AUDIO
COMPACT
Disc
• The disc may not play normally if there is residue along the edges of the
center hole.
• When using new discs in particular, use a pen, etc., to remove the residue.
• Die Disk kann nicht normal abgespielt werden, wenn sich ein Rückstand
entlang der Mittellochenden befindet.
• Insbesondere, wenn Sie neue Disks benutzen, dann entfernen Sie mit
einem Stift, etc. den Rückstand.
• Le disque peut ne pas être lu normalements s’il y a un résidu le long des
bord du trou central.
• Lors de l’utilisation de nouveaux disques en particulier, utiliser un stylo à
bille, etc., pour enlever le résidu.
• El disco no puede ser reproducido normalmente debido a la terminación
deficiente de los bordes del agujero central.
• Para quitar estos residuos de material, especialmente cuando vaya a re-
producir discos nuevos, utilice un bolígrafo, o algo similar.
• Het is mogelijk dat de disc niet normaal wordt weergegeven als de randen
van het middengat van de schijf oneffenheden vertonen.
• Verwijder vooral bij gebruik van nieuwe discs de oneffenheden met een
pen of iets dergelijks.
• Det kan uppstå fel vid CD-avspelningen om det finns plastrester kvar i
mitthålet.
• Tänk på att bort dessa med en penna, e d, särskilt om CD-skivan är ny.
Residue
Rückstand
Résidu
Residuos
Oneffenheid
Plastrester

ENGLISH
7
— TABLE OF CONTENTS —
zMain features …………………………………………………………7
xConnections/Installation ……………………………………………7
cPart names and functions ……………………………………8 ~ 11
vCompact discs ………………………………………………………11
bBasic operation ……………………………………………………12
nPitch/Brake/Platter/Key control ……………………………………13
mNext track reserve …………………………………………………14
,Seamless loop/Hot start/Stutter ……………………………15, 16
.Sampler/Digital scratch/Effector ……………………………17 ~ 20
⁄0 Memo ………………………………………………………………21
⁄1 Programmed playback …………………………………………22, 23
⁄2 Random playback …………………………………………………24
⁄3 Preset functions and operations ……………………………25, 26
⁄4 Cleaning the optical pick-up lens …………………………………27
⁄5 Specifications ………………………………………………………27
•ACCESSORIES
Check that the following parts are included in addition to the main unit:
qOperating instructions ……………………………………………1
wConnection cords for signal output (RCA) ………………………2
eRemote control unit (RC-46) ………………………………………1
rRemote control connection cable ………………………………1
1MAIN FEATURES
The DN-2600F is a double CD player equipped with a variety of
functions and rich performance characteristics. Use it for example
for DJ mixing and remixing.
Control section
1. The DN-2600F can be easily mounted on a standard 19-inch
rack.
2. Improved visibility thanks to a large fluorescent display, self-
lighting buttons and disc holder illumination.
3. Improved operability thanks to a large jog/shuttle dial and
track select knob.
Functions
1. Shockproof function protecting against external vibrations
2. Auto Level Search / Instant Start
3. Pitch Bend (Button & Jog)
4. Seamless Loop
Playback can be looped between any two positions with no break
in the sound. Two loop start points (A-1 and A-2) can be set.
5. Hot Start / Stutter
Playback can be started instantaneously from points A-1 and A-2.
In the stutter mode, the disc is only played while the button is
pressed.
6. Sampler
The sound of the CD can be sampled and played for
approximately 15 seconds. The loop, reverse, pitch adjustment,
playback level adjustment and key adjustment functions can be
used with the sampled sound.
7. Digital-Scratch
This function allows scratching in a way similar to analog discs.
18. Effector (Filter, Reverb, Flanger)
Three different effector functions can be used to create a variety
of effect sounds.
19. Brake / Platter
The playing speed can be gradually lowered to play and stop
discs with a sound similar to that of analog discs.
10. Next Track Reserve
The next track to be played can be selected so that playback
continues with no break in the sound.
11. Memo
Up to 300 sets of such data as the cue point, loop A/B points
and pitch can be stored in a permanent memory (one set of data
per track).
12. Key Control / Key Adjust
Key control function for adjusting the playback key. In addition,
the key can be adjusted automatically when the playing pitch
changes so that the key remains the same.
13. End Monitor
The ends of tracks can be monitored.
14. Program / Random playback
Up to 25 tracks can be programmed, and programs for up to six
discs can be stored in a permanent memory. Random playback
is performed for the discs in both disc holders.
15. Fader input
16. Servo Auto Stop function for Spindle Motor / Disc Holder
Auto Close
17. Preset function for setting functions according to the usage
purpose
2CONNECTIONS/INSTALLATION
1. Turn off the POWER switch.
2. Connect the RCA pin cords to the inputs on your mixer.
3. Connect the control cord to the REMOTE connector on the RC-46.
CAUTION:
• Be sure to use the supplied control cord. Using another type of
cable may result in damage.
• Be sure the power is off when connecting the control cord.
Otherwise the units may not work properly.
• Never connect any remote controllers other than the RC-46.
Doing so can damage the equipment.
15°
DN-2600F
The DN-2600F will work normally when
the player unit is mounted within 15
degrees off the vertical plane at the front
panel. If the unit is tilted excessively, the
disc may not be loaded or unloaded
properly.

ENGLISH
8
3PART NAMES AND FUNCTIONS
(1) DN-2600F Front Panel
qPOWER button (¢ON £OFF)
• Press this button to turn the power on.
NOTE:
• Be sure to close the disc holders before turning off the
power.
wPOWER indicator
• This lights when the power is on.
eDisc holder
• Place discs in this holder.
• Press the disc holder OPEN/CLOSE button to open and close
the disc holder.
CAUTION:
• Do not place foreign objects in the disc holders. Doing so
could damage the player.
• Do not push the disc tray in manually when the power is off,
as this may result in malfunction and damage the player.
rDisc holder LED
• This flashes while the disc holder is opening and closing.
• The LED lights when the disc holder is open and serves as
the disc holder illumination.
tDisc holder OPEN/CLOSE button
• Press this button to open and close the disc holder.
• The disc holder will not open during playback. Stop playback
before pressing this button.
(2) DN-2600F Rear Panel
yAnalog output jacks 1, 2
(ANALOG OUT 1, 2)
• These are unbalanced output jacks. The audio signals from
the CD players are output from these jacks.
uDigital output jacks 1, 2
(DIGITAL OUT 1, 2)
• Digital data is output from these jacks according to the
presettings.
• We recommend using a 75Ω/ohm pin cord (available in
stores) for connections.
NOTES:
• Turn PITCH control OFF when making digital recordings.
Most digital recorders will not accept a variable pitched
digital signal.
• The functions are limited when outputting digital data. (The
loop, brake, Plat, Bend-Jog, scratch, sampler, effector and
key control functions cannot be used.)
(3) RC-46 Front Panel
!0 EFFECT button
• Press this button is pressed to select the jog dial operating
mode.
Pitch bend mode:
When the jog dial is turned, the playing speed changes at a
fixed rate. (The BEND LED lights.)
Plat-H mode:
When the jog dial is turned, the playing speed changes in
function of the speed at which the jog dial is turned.
(The BEND LED and the “ ” indicator light.)
Key mode:
The key can be adjusted by turning the jog dial. (The KEY
LED lights.)
Scratch mode:
Scratching is possible by turning the jog dial. (The DIGI-S
LED lights.)
!1 SEARCH button
• When this button is pressed while the jog dial operating
mode is set to pitch bend, plat-H, key or scratch, the jog and
shuttle dial operating mode is set to the search mode.
!2 Shuttle dial (outer side)
• The shuttle dial can be used in the search mode.
• Use this dial to select the scanning direction and speed.
• The disc is scanned in the forward direction when the shuttle
dial is turned clockwise from the neutral position, and in the
reverse direction when the shuttle dial is turned
counterclockwise.
• The scanning speed increases as the wheel is turned further.
PLAT-H
iFader input jacks 1, 2
(FADER 1, 2)
• Use this when using the unit with a console fader. (Mini
Jack)
(FADER INPUT LEVEL HCMOS (Ii=–3mA))
• The fader can be activated using the switch circuit shown on
the diagram below.
GND*
SW 2
SW 1 Lch
GND
• Connect SW1 to the “Lch” stereo mini jack.
• Connect SW2 to the “GND” stereo mini jack.
• Connect GND* to the analog output “GND” terminal.
• Do not use the “Rch” jack.
• When SW1 is pressed, the hot start play mode selected with
the A1 and A2 buttons starts.
• When SW2 is pressed, the hot start play mode stops.
✽Load the hot start data before starting fader playback.
oRemote control connector (REMOTE)
• Connect this connector to the RC-46 control unit using the
included control cord.

ENGLISH
9
!3 Jog dial (inner side)
• In the search mode, turn this dial during the search operation
to move the playing point in units of frames.
• In the pitch bend and plat-H modes, turn this to change the
playing speed.
• In the key mode, turn this to adjust the key.
• In the scratch mode, turn this to scratch.
!4 Filter/Reverse button
(FIL/REVERSE)
• In the sampler mode, press this button to turn the sampler
reverse play mode on and off.
• In the effector mode, press this button to set the filter
parameter input mode.
!5 Reverb/Loop button (RVB/LOOP)
• In the sampler mode, press this button to turn the sampler
loop play mode on and off.
• In the effector mode, press this button to set the reverb
parameter input mode.
!6 TAP (TAP/BPM)/STOP button
• In the sampler mode, press this button to stop sample
recording/playback.
• In the sampler mode, press this button for over 2 seconds to
delete the sample data.
• In cases other than the above, the tempo at which the button
is pressed is measured and this is input as the BPM. When
the button is pressed only once, the BPM is displayed.
!7 CUE button
• Pressing the CUE button during play provides a return to the
position at which play was started. Alternately pressing the
PLAY/PAUSE button and the CUE button allows the CD to be
played from the same position any number of times.
• The button lit, when the standby mode is set.
• When in the sleep mode, cancel the sleep mode.
!8 Flanger/Pitch button (FLG/PITCH)
• In the sampler mode, press this button to set the sampler
parameter input mode.
• In the effector mode, press this button to set the flanger
parameter input mode.
!9 PLAY/PAUSE button (13)
• Use this button to start playback.
• Press once to start playback, once again to set the pause
mode, and once more to resume playback.
• In the brake mode, press this button to brake.
@0 ON/OFF, PLAY/WRITE button
• In the sampler mode, press this button to start sample
recording/playback.
• Press this button to turn the various effectors on and off.
@1 PRESET button
• Press this button once to turn the preset input mode on.
Press it again to turn the preset input mode off.
@2 MODE button
• When this button is pressed, the ASP operation selection
mode is set.
@3 Track select/Data master knob
(8–9/PUSH ENTER)
• Turn this knob to select the next track to be played.
• Turn the knob clockwise by one click to move one track
forward, counterclockwise by one click to move one track
backward.
• When the knob turned while pressing it in, one click
corresponds to 10 tracks.
• In the preset mode, use this knob to set and enter preset
settings.
• When setting programs, use this knob to select, enter and
check the program.
• In the memo mode, use the knob to set the item, to enter
the setting, to check the setting and to delete the setting.
• This knob is used to select the ASP operation mode and to
set data in various modes.
@4 Pitch slider
• Use this to adjust the playing speed.
• The playing speed decreases when slid upwards and
increases when slid downwards.
@5 PITCH BEND + button
• The playing speed increases while this button is pressed.
• When the button is released, the playing speed returns to
the previous speed.
@6 Key control button (KEY)
• When this button is pressed, the key control mode is set and
the key can be adjusted with the jog dial.
• When pressed again, the key adjust mode is turned on and
the key remains the same even if the pitch is changed. (KEY
ADJUST)
@7 PITCH button
• Press this button to switch to the play speed set with the
Pitch slider. The PITCH LED lights.
• When the button is pressed again, the fixed pitch mode is
set and the PITCH LED flashes.
• Press the button again to cancel the pitch play mode and
return to normal speed.
@8 PITCH BEND – button
• The playing speed decreases while this button is pressed.
• When the button is released, the playing speed returns to
the previous speed.
@9 BRAKE button
• Press this button to select the brake mode (BRAKE/PLAT-S
mode).
#0 MEMO button
• Press this button to set the memo mode.
• The following data is stored in the memory:
Standby position, A-1 point, A-2 point, B point, playing pitch.
#1 PROGRAM button
• Press this button to set the program mode.

ENGLISH
10
#2 EXIT/RELOOP button
• When this button is pressed during loop playback, loop
playback stops and the normal play mode is set (EXIT). When
pressed again, loop playback resumes.
#3 B (B-LOOP) button
• Press this button to set the end point for loop playback (point
B).
#4 A button (1, 2)
• Press this button to set the start point for loop playback
(point A-1 or A-2).
• Press this button to use the stutter and hot start functions.
The hot start mode is set when the loop mode is on, the
stutter mode is set when the loop mode is off.
#5 Display
• See page 10.
#6 LOOP (FLIP) button
• Press this button to switch between the loop mode/hot start
mode and stutter mode.
• The “ ” indicator lights when in the loop mode/hot start
mode.
• When in the next track mode, program mode or random
mode, press this button to turn the repeat mode on and off.
#7 End monitor / Next track start button
(END MON. / START)
• Press this button in the standby mode to monitor the end of
the track.
• When this button is pressed during playback in the next track
mode, the selected track is search for. When pressed again
after the search operation, playback starts.
LOOP
(4) RC-46 Rear Panel
$2 Connector for signal transfer between remote
control units
• When this connector is connected to the connector of
another RC-46 using a stereo mini-plug cord (cross cable),
signals can be transferred between two units.
$3 Control connector
• Connect this connector to the REMOTE connector on the
DN-2600F (main unit) using the included control cord.
#8 TIME button
• Press this to switch the time display between the elapsed
time or remaining time per track or per disc.
#9 Disc holder OPEN/CLOSE button
• Press this button to open and close the disc holder.
• The disc holder will not open during playback. Stop playback
before pressing this button.
$0 Continue/Single button
(CONT./SINGLE)
• Press this button to switch between the single and
continuous play modes.
• The selected mode is indicated by the SINGLE or CONTINUE
indicators on the display.
$1 Next track button (NEXT TR.)
• Press this button to set the next track mode.
• When the next track mode is set, the “NEXT TR” indicator
lights and the next track to be played can be selected using
the track select knob.
CONT. SINGLE REPEAT
TOTAL REMAIN ELAPSED
NEXT TR PITCH %
ms
f
LOOP EXIT
BRAKE PLAT-S
MEMO PROG. PLAT-H
EOM
A1 B
A2 B
GO!
LOOP
RVS
SAMP
DIGI-S
EFFECT
LOCKFULLD.OUT
¡¡¡¡¡ ¡¡¡¡¡¡
rewq yt u i o !0 !1
!4!3!2 !5 !6 !8!7 !9 @0 @1 @2
(5) Display
qPLAT-S indicator
• This lights when in the PLAT-S mode.
wBrake indicator
• This lights when in the brake mode.
eMemo indicator
• This lights when memo data is stored in the memory.
rPlay mode indicators
• “SINGLE” lights when in the single track play mode.
• “CONT.” lights when in the continuous play mode.
tProgram indicator
• This lights when program data has been input and when
program data is stored in the memory.
yRepeat indicator
• This lights when the repeat mode is set.
uDigital scratch enabled indicator
• This lights when it is possible to start digital scratching.
iTrack, minute, second and frame displays
• These displays indicate information on the current position
and time.

ENGLISH
11
oTime mode indicators
• When the TIME button is pressed, the time display switches
as follows:
When “ELAPSED” is lit:
The track’s elapsed time is displayed.
When “REMAIN” is lit:
The track’s remaining time is displayed.
When “TOTAL” and “ELAPSED” are lit:
The disc’s total elapsed time is displayed.
When “TOTAL” and “REMAIN” are lit:
The disc’s total remaining time is displayed.
!0 Next track display
• This displays the number of the next tack to be played.
!1 Pitch display
• This indicates the playback speed (pitch).
(–16.0 to +16.0)
!2 PLAT-H indicator
• This lights when in the PLAT-H mode.
!3 Loop mode indicators
• “ ” lights when in the loop mode.
• “ ” lights when point B is set for point A-1.
• “ ” lights when point B is set for point A-2.
• “ ” lights when in the seamless loop pause mode.
!4 Digital out indicator
• This lights when the digital output is turned on with the
presettings.
!5 Shockproof data indicator
• This lights when the shockproof memory is full.
!6 Button lock indicator
• Some of the buttons do not function when this indicator is lit.
!7 Character display
• Operation messages are displayed here.
!8 Bar indicator
• This provides a visual indication of where the pickup is within
the currently playing track.
!9 EOM indicator
• This flashes when the EOM time set with the presettings is
reached.
@0 ASP mode indicators
• “ ” lights when the ASP is set to the sampler playing
mode.
• “ ” lights when the ASP is set to the digital scratch
mode.
• “ ” lights when the ASP is set to the effector
mode.
@1 Effector operating mode indicators
• “ ” lights when in the filter mode.
• “ ” lights when in the reverb mode.
• “ ” lights when in the flanger mode.
@2 Sampler playing mode indicators
• “LOOP” lights when in the sampler loop playing mode.
• “RVS” lights when in the sampler reverse playing mode.
EFFECT
DIGI-S
SAMP
EXIT
A2 B
A1 B
LOOP
4COMPACT DISCS
1. Precautions on handling compact discs
• Do not allow fingerprints, oil or dust to get on the surface of the
disc.
If the disc is dirty, wipe it off with a soft dry cloth.
• Do not use benzene, thinner, water, record spray, electrostatic-
proof chemicals, or silicone-treated cloths to clean discs.
• Always handle discs carefully to prevent damaging the surface;
in particular when removing a disc from its case or returning it.
• Do not bend the disc.
• Do not apply heat.
• Do not enlarge the hole in the center of the disc.
• Do not write on the label (printed side) with a hard-tipped
implement such as a pencil or ball point pen.
• Condensation will form if a disc is brought into a warm area
from a colder one, such as outdoors in winter. Do not attempt
to dry the disc with a hair dryer, etc.
2. Precautions on storage
• After playing a disc, always unload it from the player.
• Always store the disc in the jewel case to protect from dirt or
damage.
• Do not place discs in the following areas:
1) Areas exposed to direct sunlight for a considerable time.
2) Areas subject to accumulation of dust or high humidity.
3) Areas affected by heat from indoor heaters, etc.

ENGLISH
12
5BASIC OPERATION
PLAY/PAUSE and CUE
★The operation switches between playback and pause each time
the PLAY/PAUSE button is pressed.
★When the CUE button is pressed during playback, the pickup
returns to the position at which playback was started.
The diagrams below show playback patterns when the PLAY/PAUSE
and CUE buttons are pressed.
PLAY and PAUSE
When the PLAY/PAUSE button is pressed, playback starts and
proceeds as shown by the arrow on the diagram above.
If the PLAY/PAUSE button is pressed again during playback, the
pause mode is set at that point. Press the PLAY/PAUSE button again
to resume playback.
PLAY and CUE
When the CUE button is pressed after starting playback by pressing
the PLAY/PAUSE button, the pickup returns to the position at which
playback was started and prepares for the next playback.
Press the PLAY/PAUSE and CUE buttons alternately to start playback
repeatedly from the same position. (Checking the playback position)
This function is called “Back Cue”.
PLAY/PAUSE
button
pressed
PLAY/PAUSE
button
pressed PLAY/PAUSE button pressed
Position on disc
Pause mode set at this point
Section
played
Section
played
PLAY/PAUSE
button
pressed
CUE button pressed
Position on disc
Section
played Back Cue
PLAY, PAUSE and CUE
If the pause mode is set and playback is then resumed, the position
to which the pickup returns with the Back Cue function changes.
Sleep mode
• The sleep mode is set if no operation is performed for 30
minutes while in the standby or pause mode. In the sleep
mode, disc rotation is stopped in order to reduce wear due
to unnecessary rotation of the motor.
• The sleep mode can be canceled by pressing the
PLAY/PAUSE or CUE button. (The time after which the
sleep mode is set can be selected with the presettings.)
PLAY/PAUSE
button
pressed
PLAY/PAUSE
button
pressed
PLAY/PAUSE
button
pressed
Section
played
Section
played
Position on disc
CUE
button pressed
Starting playback from the Middle of a track
(Manual Search)
★When the track is selected with the track select knob and the
PLAY/PAUSE button is pressed, playback starts from the beginning
of that track. If you wish to start from a different position, use the
procedure described below to search for the desired position.
1
2
Find the play start position.
Press the SEARCH button to set the jog/shuttle dial to the
search mode.
Turn the shuttle dial to change the playback position quickly.
(Search for the approximate playback position.)
§
SEARCH
SCAN
67
I I
I
RVS FWD
The fast forward/reverse mode is set when
the shuttle dial (outer side) is turned.
The speed changes according to the angle
at which the dial is turned.
• When operated during playback, playback resumes after
the operation.
• When playback is started, the jog dial is set to the bend
mode.
• When turned fully in either direction, the disc skips 1
minute forward or backward then plays for 3 seconds,
and this is repeated.
Turn the jog dial. (Search for the precise playback position.)
§
SEARCH
SCAN
67
I I
I
RVS FWD
When the jog dial (inner side) is turned, the
frame move mode is set.
The playback position can be moved in
units of one frame.
Listen to the sound and find the desired play start position.
Checking the position at which playback will stop
★In the standby mode, press the END MON. button.
• If the CUE button is pressed during the end monitor operation, the
end monitor operation is canceled, the pickup returns to the play
start position and the standby mode is set.standby mode is set.
END MON.
• The end monitored, then the pickup returns to the play
start position and the standby mode is set. (End
Monitor)
• In the single track play mode, the end of the current
track is monitored.
• In the continuous play mode, the end of the final track
is monitored.
Shockproof memory
• A maximum of approximately 10 seconds worth of audio
data is stored in the memory during playback, thereby
reducing skipping and interruptions in the sound due to track
skipping and other problems generated by vibrations.
• If advanced data reading is not possible due to scratches or
dirt on the disc, playback stops once the data stored up to
that point is read.
• If less than 3 seconds worth of data remains in the memory,
“Read Error” flashes on the character display, indicating that
playback will stop.
• The display returns to normal once the amount of data in the
memory increases.

ENGLISH
13
6PITCH/BRAKE/PLATTER/KEY CONTROL
★There are two ways to change the playing speed.
• Adjust the Pitch using the pitch slider (±10% and ±16%).
• The PITCH BEND button or jog dial can be used to temporarily change the pitch.
★The playing speed can be changed greatly to achieve effects similar to those achievable with analog discs.
Pitch/Platter-H
1-1
1-2
2-1
2-2
3
[Pitch slider]
Set the variable speed mode.
Press the PITCH button to light the PITCH LED.
0%
Pitch
decreases
The Pitch decreases when the pitch
slider is moved upwards, increases
when the pitch slider is moved
downwards.
• The pitch can be locked by pressing the PITCH button
again.
[PITCH BEND button]
Press the PITCH BEND + (or PITCH BEND –) button.
• The Pitch increases or decreases temporarily while the
PITCH BEND + or PITCH BEND – button is pressed.
• The extent to which the PITCH BEND button changes the
Pitch is proportionate to the amount of time the button is
pressed. The longer the button is held down, the greater
the percentage of change.
Set the jog dial to the pitch bend mode.
Press the EFFECT button to light the BEND LED.
• The playing speed increases gradually when the jog dial is
turned clockwise and decreases gradually when the jog
dial is turned counterclockwise. When you stop turning
the jog dial, the playing speed returns to the previous
speed.
• When playback is stopped, the jog/shuttle dial is set to
the search mode.
Set the jog dial to the platter hold mode.
Press the EFFECT button to light the BEND LED.
• The playing speed changes in function of the speed at
which the jog dial is turned, resulting in a sound similar to
that of when using an analog disc.
• The playing speed increases when the jog dial is turned
clockwise and decreases when the jog dial is turned
counterclockwise. When you stop turning the jog dial,
the playing speed returns to the previous speed.
Pitch
increases
Brake/Platter-S
★Use this function to achieve two effects similar to analog players.
1
Select the brake or platter mode.
Press the BRAKE button.
• When “ ” is lit: Brake mode
An effect sound similar to that of when playback is
stopped on an analog player can be achieved by pressing
the PLAY/PAUSE button during playback.
• The brake time can be selected with the presettings.
• When “ ” is lit: Platter start/stop mode
The platter stop effect is achieved when the PLAY/PAUSE
button is pressed during playback and the platter start
effect is achieved when the PLAY/PAUSE button is
pressed in the standby or pause mode. The platter stop
and start effects are effect sounds similar to when
playback is started or stopped on an analog player.
• The start and stop times time can be selected with the
presettings.
PLAT-S
BRAKE
Key control
★This function allows you to adjust the key of the playback sound.
★A key adjust function adjusts the key automatically when the
playing pitch changes so that the key remains the same.
1
2-1
2-2
3
Set the key control mode.
Press the KEY button to light the KEY LED.
[Adjusting the key]
Set the jog dial to the key mode.
Press the EFFECT button to light the KEY LED.
Adjust the key.
Turn the jog dial.
[Key adjust mode]
Compensate for the change in the key when the playing
speed is changed with the pitch slider.
Press the KEY button to make the KEY LED flash.
• The key is kept at the same key as when the pitch is 0%.
✽The key cannot be adjusted with the jog dial.
§
SEARCH
SCAN
67
I I
I
The key increases when the jog dial is
turned clockwise and decreases when the
jog dial is turned counterclockwise.
• The key is indicated on the bar indicator. The original key
is at the center, and one bar corresponds to two steps.
• The key adjustment range is ±16.0.
NOTE:
• When the disc holder is opened, the key data is cleared.

ENGLISH
14
7NEXT TRACK RESERVE
★With this function, the blank sections between tracks when in the continuous play mode can be cut (AUTO MODE). It is also possible to
freely search for and select the next track to be played while the current track is playing so that playback continues with no break in the sound
(MANUAL MODE).
1
2
3
4
5
Set the next track mode.
Press the NEXT TR. button.
Select the track to be played next.
During playback, turn the track select knob.
[Next track manual mode]
Switch playback to the selected track.
If you wish to switch to the selected track while the current
track is still playing, press the START button.
[Next track auto mode]
When the next track is selected and the START button is not
pressed, playback of the next track starts automatically once
the currently playing track is finished, with no break in the
sound.
• In the single track play mode, the standby mode is set at
the beginning of the next track.
• You can choose whether to turn the repeat function on or
off using the LOOP button.
[Canceling the next track reserve mode]
Press the NEXT TR. button again.
✽The NEXT TR. button may not function if there are less
than 20 seconds remaining in the currently playing track.
✽The next track mode cannot be selected when the A and
B points are set in the loop mode.
✽If no next track is selected, the current track is selected
when in the single track play mode and the following
track is selected when in the continuous play mode.
• When “Next Tr. OK” is displayed, press the START button
again to stop the currently playing track and start playing
the next track.
• If the START button is not pressed again when “Next Tr.
OK” is displayed, playback of the currently playing track
stops after a maximum of approximately 10 seconds,
then playback of the selected track starts. The remaining
time of the current track is indicated on the time display.
NEXT TR.
NEXT TR
Lit
NEXT TR
PUSH ENTER
B.WIDE
Next Tr. OK
NEXT TR.
NEXT TR
Off
NOTE:
• The “ ” indicator lights from the time the standby
mode is set at the next track until playback starts.
During this time, it is not possible to set the pause mode, to
use the manual search, scan or next track functions or to
switch between the single track and continuous play
modes.
LOCK
[Example: To play track 3 next]

ENGLISH
15
8SEAMLESS LOOP/HOT START/STUTTER
★Use this function to play the specified section between points A and B in a seamless loop (with no break in the sound).
★Two A points and one B point can be set.
★The data of the A points can be used for the hot start and stutter functions.
1
2
3
Start playback.
Press the PLAY/PAUSE button.
Load the start point (A).
Press the A-1 (or A-2) button.
Set the end point (B).
Press the B (B-LOOP) button.
• The seamless loop mode is set as soon as point A is set.
• The “ ” indicator lights and “LoadA” is displayed
on the character display while the A point data is being
loaded.
✽The seamless loop mode cannot be set when in the next
track mode. If you wish to set it, turn the next track
mode off.
✽Data cannot be loaded for both A1 and A2 at the same
time.
✽Depending on the conditions, it may not be possible to
load points A1 and A2. In this case, “Not Load” is
displayed.
LOCK
A
1212
LOOP
B
A1 B A2 B
Lit Lit
Lit Lit
or
or
When the end point (B) is set, the
disc is played from the start point
(A) with no break.
After this, the disc is played from
the start point (A) to the end point
(B) with no break.
Start point End point
Start point End point
Seamless loop
• If the B (B-LOOP) button is pressed again after the B
point has been set, the B point is reset (moves).
• Whenever the A-1 (or A-2) button is pressed while in the
seamless loop mode, playback starts over from the A
point.
• When point B is set for point A-1 and the A-2 button is
pressed, point B is cleared. In the same way, when point
B is set for point A-2 and the A-1 button is pressed, point
B is cleared.
Starting seamless loop playback Temporarily canceling seamless looping
4
Press the EXIT/RELOOP button during seamless looping.
(EXIT mode)
EXIT EXIT
Flashing Lit
Start point End point
• When the end point (B) is reached, playback continues,
without returning to the start point (A).
Replaying a seamless loop
5
Press the EXIT/RELOOP button or the B (B-LOOP) button
during normal playback. (When the B (B-LOOP) button is
pressed, that point is set as the new loop end point (B).)
B
Start point
End point
• Playback returns to the start point (A) and seamless
looping resumes.
Press the EXIT/RELOOP
or B button.
Clearing the start (A) and end (B) points
6
While pressing the LOOP (FLIP) button, press the A button
you want to clear (A-1 or A-2) for at least 2 seconds.
LOOP A
12
A1 B A2 B
1 2
• The A-1 point (or A-2 point) and the B point are cleared.
Off
Off
or
Off
Off
or
NOTE:
• When the disc holder is opened, the start (A) and end (B)
point settings are cleared.
Lit

ENGLISH
16
Clearing all the seamless loop settings
7
Press the LOOP (FLIP) button for at least 2 seconds.
LOOP
LOOP
• When this is done, the settings for the start points (A-1
and A-2) and the end point (B) are all cleared.
Off
NOTE:
• When A-1 or A-2 is cleared during seamless looping, it may
take about 2 seconds before A-2 or A-2 can be set again.
Fine-adjusting the start points (A-1 and A-2) and
end point (B)
1
2
3
4
Adjust the start point (A).
To fine-adjust the position of the A-1 (or A-2) point once it
has been set, in the standby mode press the A-1 (or A-2)
button while pressing the CUE button.
Use the scan or manual search function to fine-adjust the A-
1 (or A-2) point, then press the A-1 (or A-2) button again.
Adjust the end point (B).
Press the A-1 (or A-2) button, then in the standby mode
press the B (B-LOOP) button while pressing the CUE
button.
• The standby mode is set at the B point.
As in step 2above, use the scan or manual search function
to fine-adjust the B point, then press the B (B-LOOP) button
again.
• The end point (B) moves to the position at which the
button is pressed.
CUE
A
12
A1 StdBy
§
SEARCH
SCAN
67
I I
I
A1 Moving Load A1
• The standby mode is set at the A-1 (or A-2) point.
★The A-1, A-2 and B points can also be used to set the standby
mode at the respective point.
NOTE:
• It is not possible to set an A point at a position after the B
point or the B point at a position before the A point.
Hot starting
★Hot starting is possible when no end point (B) has been set in the
seamless loop mode or when in the exit mode.
1
With the data for A-1 or A-2 loaded, press the A-1 (or A-2)
button to hot start.
• Playback starts immediately from the start point (A) when
the button is pressed.
• “H/S” is displayed when hot starting is possible.
✽If point B is set, set the exit mode.
✽When data is loading, hot starting is only possible for the
point (A-*) whose data is loading.
Stuttering
★Stuttering is possible when the seamless loop mode is off and the
start point (A) is set.
1
In the stutter mode, press the A-1 (or A-2) button.
• Playback starts immediately from the start point (A) when
the button is pressed and stops when the button is
released.
• “STR” is displayed when stutter playback is possible.
✽When the PLAY/PAUSE button is pressed from the above
stop mode, hot starting begins from the start point (A).
NOTES:
• The hot start and stutter functions cannot be used when in
the next track mode.
• When the “ ” indicator is lit, it is not possible to set
the pause mode or to use the manual search and scan
functions.
LOCK

ENGLISH
17
9SAMPLER/DIGITAL SCRATCH/EFFECTOR
★DN-2600F’s ASP (Audio Signal Processor) has three modes - sampler, digital scratch and effector - that can be selected freely according to the
purpose.
2Sampler
• The sound of the disc can be recorded/played for approximately
15 seconds.
• The recorded sound can be looped in the normal or reverse
direction.
• The playing speed and level can be changed. In addition, the
key adjust function makes it possible to keep the key constant
even when the playing speed is changed.
2Digital scratch
• The jog dial can be used to scratch with a feeling similar to
when scratching with an analog player.
2Effector
• Three different effect functions can be used to create original
sounds. (In the effector mode, the playing level is 6dB lower
than the normal playing level.)
Selecting the ASP mode
1
2
3
4
Set the stop mode.
Set the ASP operation selection mode.
Press the MODE button.
Select the sampler, digital scratch or effector mode.
Turn the data master knob (8—9).
Set the mode you want to operate.
Press the data master knob (8—9).
Sampler?
D-Scratch?
Effector?
PUSH ENTER
SAMP
DIGI-S EFFECT
Lit
oror
(1) Sampler
Recording samples
1
2-1
2-2
Set the ASP to the sampler mode.
Start recording.
Press the PLAY/WRITE button.
[Sampling the seamless loop]
• When the end point (B) is set for the start point (A), the
standby mode is set at the start point (A) and recording is
started, recording stops at the end point (B). (During
recording, “Samp Load-B” is displayed on the character
display.)
• If the section between points A and B is more than 15
seconds long, recording stops after 15 seconds.
✽For instructions on setting the standby mode at point A,
refer to “Fine-adjusting the start points” (page 16).
Lit
ON/OFF
PLAY/WRITE
ON/OFF
PLAY/WRITE
Samp Write
• The disc plays and the sound is recorded for
approximately 15 seconds. (The STOP LED lights when
recording is over.)
• Recording can be stopped before the 15 seconds is up by
pressing the STOP button.
Playing the sampled sound
3
Press the PLAY/WRITE button.
• Playback of the sampled sound starts.
• The stop mode is set automatically once the end of the
recording is reached.
Stopping sampler playback
4Press the STOP button.
• Sampler playback stops.
Clearing the recorded sample
5
Press the STOP button for at least 2 seconds.
• The recorded sample is cleared.
✽The sampler playback parameters and the LOOP and RVS
settings are reset to the default values.

ENGLISH
18
Selecting the sampler playback parameter
★The playing pitch, playback level and key adjust mode can be
selected.
1
2
3
Set the sampler playback parameter selection mode.
Press the FLG/PITCH button.
Select the pitch, level or key adjust mode.
Turn the data master knob (8—9).
Set the mode whose parameter you want to change.
Press the data master knob (8—9).
SAMP Pitch?
SAMP Level?
SAMP Key.?
PUSH ENTER
Changing the sampler playing pitch
4-1
4-2
After setting the parameter to “sampler pitch”, turn the data
master knob (8—9).
[Canceling the sampler pitch mode]
Press the data master knob (8—9).
• The player returns to the same status as in step 2and
other parameters can be changed.
• The speed changes by 0.5% for each click of the knob.
(The adjustment range is ±16%.)
PUSH ENTER
Turn the knob clockwise to increase the
sampler playing speed, counterclockwise to
decrease it.
Changing the sampler playback level
5-1
5-2
After setting the parameter to “sampler level”, turn the data
master knob (8—9).
[Canceling the sampler level mode]
Press the data master knob (8—9).
• The player returns to the same status as in step 2and
other parameters can be changed.
• The level can be set in five steps.
NOTE:
• Depending on the recording level, clipping may occur in
the playback sound if the playback level is increased.
PUSH ENTER
Turn the knob clockwise to increase the
sampler playback level, counterclockwise
to decrease it.
Sampler key adjust setting
6-1
6-2
After setting the parameter to “key adjust”, turn the data
master knob (8—9).
• Turn key adjust on or off.
[Canceling the sampler key adjust setting mode]
Press the data master knob (8—9).
• The player returns to the same status as in step 2and
other parameters can be changed.
Canceling the sampler playback parameter
selection mode
7Press the FLG/PITCH button again.
Playing the sample backwards
1
2
Set the sampler reverse playback mode.
Press the FIL/REVERSE button.
• After pressing the FIL/REVERSE button, press the
PLAY/PAUSE button to start playing the sample
backwards, starting from the end point.
[Canceling the sampler reverse playback mode]
Press the FIL/REVERSE button again.
• After pressing the FIL/REVERSE button, press the
PLAY/PAUSE button to resume normal sample playback.
Playing the sampler in a loop
1
2
Set the sampler loop playback mode.
Press the RVB/LOOP button.
• The sample is played in a loop.
[Canceling the sampler loop playback mode]
Press the RVB/LOOP button again.

ENGLISH
19
(2) Digital scratch
Using the scratch function
1
2
3
4
Set the ASP to the scratch mode.
• Refer to “Selecting the ASP mode” on page 17.
Check that it is possible to start scratching.
Press the PLAY/PAUSE button.
Set the jog dial to the scratch mode.
Press the EFFECT button so that the DIGI-S LED flashes or
lights.
✽The DIGI-S LED lights when scratching is performed
once.
• If the “ ” indicator is lit, scratching is possible.
GO!
Lit
PLAY / PAUSE
GO!
Change the playing speed and direction of playback.
Turn the jog dial.
• Press the PLAY/PAUSE button during the scratch mode to
pause in the PLAT-S mode.
• If the scratch operation is performed during normal
playback, normal playback resumes once scratching is
stopped.
• If the scratch operation is performed in the pause mode,
the pause mode is set once scratching is stopped.
§
SEARCH
SCAN
67
I I
I
The disc is played in the forward direction
when the jog dial is turned clockwise, in
the reverse direction when the jog dial is
turned counterclockwise.
The playing speed changes according to
the speed at which the dial is turned.
(3) Effector
Setting the effector mode
1
2
Set the ASP to the effector mode.
• Refer to “Selecting the ASP mode” on page 17.
✽In the effector mode, the playing level is 6dB lower than
the normal playing level.
After setting the effector mode, set the track’s BPM.
Press the TAP (TAP/BPM) button several times in beat with
the music.
• The track’s BPM is set according to the tempo at which
the button is pressed.
• This tempo is set as the reverb and flanger operating
time.
✽When the BPM is input after starting playback from the
standby position or after hot starting, the BPM can be set
individually for the different modes.
STOP
TAP
115bpm
Using the filter function
★With this function, the sound is filtered to reduce the low or high
range frequencies.
0Hz 20kHz
Low range frequencies High range frequencies
1-1
1-2
2-1
After setting the effector mode, set the filter low
frequency input mode.
Press the FIL/REVERSE button.
Select the low frequency range to be filtered.
Turn the data master knob (8—9).
Set the filter high frequency input mode.
Press the data master knob (8—9).
L--H Freq.L
EFFECT
Low range frequencies Flashing
• The frequency can be set between 100 Hz and 20 kHz (or
none).
✽It is not possible to set the low frequency to a frequency
higher than the high frequency.
PUSH ENTER
Freq.H L--H
The frequency increases when the knob is
turned clockwise and decreases when the
knob is turned counterclockwise.
High range frequencies

ENGLISH
20
2-2
3
4
Select the high frequency range to be filtered.
Turn the data master knob (8—9).
• If the data master knob (8—9) is pressed again, the
player returns to the same status as in step 1-2.
• The frequency can be set between 100 Hz and 20 kHz (or
none).
✽The high frequency cannot be set below than the low
frequency.
NOTE:
• For some tracks, clipping may occur in the playback
sound.
Start filtered playback.
Press the ON/OFF button at any point between steps 1-1
and 2-2.
Canceling the filter frequency input mode.
Press the FIL/REVERSE button.
• The “ ” indicator is lit when the filter is on.
• The “ ” indicator is not lit when the filter is off.
• When pressed again, the filter turns off.
FIL ON FIL OFF
Using the reverb function
★With this function, an echo is produced at the set tempo.
1-1
1-2
2-1
2-2
Set the reverb delay time input mode.
Press the RVB/LOOP button.
Select the reverb delay time.
Turn the data master knob (8—9).
Set the reverb feedback number mode.
Press the data master knob (8—9).
Select the reverb feedback number.
Turn the data master knob (8—9).
• If the data master knob (8—9) is pressed again, the
player returns to the same status as in step 1-2.
• The time can be set to 2/1, 1/1, 3/4, 1/2, 1/4 or 1/8 the
BPM set with the TAP (TAP/BPM) button.
***bpm 1/2
***bpm 1/2
EFFECT
Flashing
L F.Back H

Feedback number
PUSH ENTER
The feedback number increases when the
knob is turned clockwise and decreases
when the knob is turned counterclockwise.
3
4
Start reverb playback.
Press the ON/OFF button at any point between steps 1-1
and 2-2.
Canceling the reverb data setting mode.
Press the RVB/LOOP button.
• The “ ” indicator is lit when the reverb mode is on.
• The “ ” indicator is not lit when the reverb mode is
off.
• When pressed again, reverb playback stops.
RVB ON RVB OFF
Using the flanger function
★With this function you can create swelling sounds.
1-1
1-2
2-1
2-2
3
4
Set the flanger time input mode.
Press the FLG/PITCH button.
Select the flanger time.
Turn the data master knob (8—9).
• The time can be set to 4/1, 2/1, 1/1, 3/4, 1/2, 1/4 or 1/8
the BPM set with the TAP (TAP/BPM) button.
Set the flanger gain input mode.
Press the data master knob (8—9).
Select the flanger gain.
Turn the data master knob (8—9).
Start flanger playback.
Press the ON/OFF button.
Canceling the flanger data setting mode.
Press the FLG/PITCH button.
• The “ ” indicator is lit when the flanger mode is on.
• The “ ” indicator is not lit when the flanger mode is
off.
• When pressed again, flanger playback stops.
***bpm 1/4
EFFECT
Flashing
L Gain H
Gain
• If the data master knob (8—9) is pressed again, the
player returns to the same status as in step 1-2.
PUSH ENTER
The gain increases when the knob is turned
clockwise and decreases when the knob is
turned counterclockwise.
FLG ON FLG OFF
NOTE:
• For some tracks, clipping may occur in the playback sound.
