Denon UD-M50 Installation guide

Micro Systems Designed ForThe Way YouLive
Componmttsin the D-M50S series areonly 210 mm wide, yet they are endowedwith circuitry for superior quality sound andsport anattractive
designtha bends easy w h any interior. The front panel is made of silver aluminum, anda half mirror has beenadded to the displaywindow to
enhance heappearance The UD-M50 includes the high-end Source Direct function, andtheaudio and power drcuits in allcomponents ofthe
seriesfeature highly-acclaimed DENONtechnologyto ensure thatthe sound you hearis perfectly smooth andtransparent. TheUD-M50 CD receiver
canbeconnected to the optional CDR-M30 CD-R recorderor DRR-M30 cassettedeckif desired.The remotecontroller that comes with the UD-M50
canalso beusedto operatethe basic functions ofthese optional units.
UD-M5OICDR-M3OIDRR-M3OIMS-50
Half mirror disotay v¢indow
UD-M503-CDReceiver
B_lS'50 CompactLoudspeaker
• New Tweeter (25 mm Soft Dome)
•110 mm Profiles Bass Unit
•New Front Baffle Mounting and Finish
•Newly Tuned Crossover to Match D_M30/MS0
•Anti*magnetic Design
•General
Enclosure ................................ 2-Way Reflex
impedance .............................. 6 ohms
Recomn_ended _mplifier powel 20 - 50 W (watts/channel)
Frequency response ............... 75 Hz -20 kHz (3 dB)
Dimensions .............................. 140 (W) x 240 (H) x 200 (D) mm
55"(W) x94"(H)x79"(O I
Weight ................................. 24 kg, 53 Ibs
•Amplmer Section
Power Output ........................ 30 W + 30 W (6 ohms)
• S.D.B. {Super Dynamic Bass)
•Tone Controls (Bass, Treble)
•Source Direct Function
•2 Audio inputs and 2 Audio Outputs
•2-ch PRE Outputs (MonotStereo)
•Easy-to-Use Remote Control
•Headphone Jack
•Compact Disc Section
•Versatile Repeat Function For 3-Disc Changer
•A wealth of Playback/Recording Functions
AM/FM Stereo Receiver with 3-Disc CD Auto Changer
Tire UD-M50 is a Super Micro Component System that lets you enjoy CD and
tuner functions in a sing)e unit, The CDsection features a 3-disc changer that lets
you listen to music without interruption. The UD-M50 packs high output power of
30 W + 30 W, and the audio circuitry is endowed with DENON's renowned Hi-Fi
technology to produce a beautifully clean,spacious sound. The D-MSOSsystem is
supplied with apair of Mission MS-50 loudspeakers.
•Optical Digital Output Jack for Direct Transmission
of Digital Signals
•Auto Edit Function
•Tuner Section
•AM/FM 40 Station Preset Memory Tuning
•EverydaytOnce/Sleep Timer
•24-Hour Clock
•General
Power Supply ............................... 120 V 60 Hz, 70 W
Dimensions 210 (W) x 13_ (H) x 381 (D) mm
83" (W) x53" (H) x 150" (D)
Weight .......................................... 55 kg, t2 llbs

CDR-M30CO-.,CO-.,W.°°o,,or
E wah Optional Remote Controller ]
Micro-Size CD Recorder for HighQuality DigitalRecording
TheCDis probablythe easiestwayto Iisteeto music whereveryou go.Just about everyonehasa CD
playerthese days, so it would bewonderful if you could also record that high-quality digital sound
onto CDs,not just playit back.On this CD,you could recordonly the music you wantto listen, and
play it in your caror onyour portable playeras w5{Ias at home. if you usea CD-RWdisc, you can
record onit as manytimes asyou like.And of course,DENONmakessurethe quality ofthe sound is
nodifferentfrom that ofconventionatCDs.
• Sampling Rate Converter
•I Set Analog Stereo inputs and Analog Stereo Outputs
•2 Sets of Optical Digital inputs
•Serial Copy Management System (SCMS)
•Synchronized one-touch recording of both ansiog and digital signals
(An/l track) *UD-M50 only
•Digital REC Volume
•Dual Speed Finalizing
•Text input and Display
*A portion of the text input on a commercially available disc suppolting
CD text maynot be correctly displayed on the CDR-MJO
• General
Power Supply ....................... 120 V 60 Hz, 15 W
Dimensions ............................ 210 (W) x 95 (H) x 318 (D) mm
83" (W) x 37" (H) x125" (D)
Weight .................................. 30 kg, 66 Ibs
Note: CD-R audio discs recorded on the CDR-MJO can be played on most, but not all, standard CD players CD-RW audio discs
recorded on the CDR-MJ0 cannot be played on models that do not support OD-RW Some DVD players cannot playback
CD-R and/or OD-RW audio discs - check your DVD player's owneCs manual for further information
DRR-M30co..,,.°.°,
rrll=ur e
Single Cassette Deck with DolbyB noise reduction
The DRR-MJOis asiegle cassettedeckfeaturing ahodzonta_Ioadiegmechanismto ensuresmooth,
stabletapetravel,andthe DolbyBnoisereductionsystem.When connectedto the UD-MJOor UD-M50,
the DRR-MJO'sCD-SRSfunction letsyou start recordingCDsontotape atthe singletouch of abutton.
The DRR-MJOalso provides a wealth of editing and playback functions, including One-TouchAuto
Reverseand Music Search,to makethis deckatruly versatilememberofthis system.
•Horizontal Loading Mechanism for Smooth, Stable Tape Travel
•Dolby B Noise Reduction System
•CD-SRS for One-Touch Recording from CD
•AWealth of Editing and Playback Functions
•One-Touch Auto Reverse Operation
•Music Search
•Auto Tape Selector
• General
Power Supply ....................... 120 V 60 Hz, 10 W
Dimensions ............................ 210 (W) x 95 (H) x 318 (D) mm
83" (W) x 37' (H) x 125" (D)
Weight .................................. 30 kg, 66 Ibs
*Design and specifications are subject to change without notice
