Philips DCM2025 User manual

DCM2025
Register your product and get support at
www.philips.com/welcome
Always there to help you
Manual del usuario 23
User manual 3
Question?
Contact
Philips
Question?
Contact
Philips
DCM2025_12_UM_Book1_V3.0.indb 1 9/26/2012 3:30:13 PM

3
English
EN
Contents
1 Important 4
Safety 4
Notice 5
2 Your Micro Music System 7
Introduction 7
What's in the box 7
Overview of the main unit 8
Overview of the remote control 9
3 Get started 10
Connect speakers 10
Connect FM aerial 11
Connect power 11
Prepare the remote control 11
Turn on 12
Set clock 12
Demonstrate the unit's features 12
Store radio stations automatically 12
4 Play 13
Basic play operations 13
Play from disc 13
Play from USB 13
Adjust sound 13
5 Play iPod/iPhone/iPad 14
Compatible iPod/iPhone/iPad 14
Load the iPod/iPhone/iPad 14
Charge the iPod/iPhone/iPad 15
Listen to the iPod/iPhone/iPad 15
Remove the iPod/iPhone/iPad 15
6 Listen to FM radio 16
Tune to FM radio stations 16
Program radio stations automatically 16
Program radio stations manually 16
Tune to a preset radio station 16
Show RDS information 16
7 Other features 18
Set alarm timer 18
Set sleep timer 18
Listen to external audio device 18
Listen through headphone 19
8 Product information 20
Specications 20
USB playability information 20
Supported MP3 disc formats 21
9 Troubleshooting 22
DCM2025_12_UM_Book1_V3.0.indb 3 9/26/2012 3:30:13 PM

4EN
1 Important
Safety
This 'bolt of lightning' indicates uninsulated
material within your unit may cause an electrical
shock. For the safety of everyone in your
household, please do not remove product
covering.
The 'exclamation point' calls attention to
features for which you should read the enclosed
literature closely to prevent operating and
maintenance problems.
WARNING:Toreducetheriskofreor
electric shock, this apparatus should not be
exposedtorainormoistureandobjectslled
with liquids, such as vases, should not be placed
on this apparatus.
CAUTION: To prevent electric shock, match
wide blade of plug to wide slot, fully insert.
Important Safety Instructions
• Heed all warnings.
• Follow all instructions.
• Do not use this device near water.
• Clean only with dry cloth.
• Do not block any ventilation openings.
Install in accordance with the
manufacturer's instructions.
• Do not install near any heat sources such
as radiators, heat registers, stoves, or other
devices(includingampliers)thatproduce
heat.
• Protect the power cord from being
walked on or pinched, particularly at plugs,
convenience receptacles, and the point
where they exit from the device.
• Onlyuseattachments/accessoriesspecied
by the manufacturer.
• Unplug this device during lightning storms
or when unused for long periods of time.
• Referallservicingtoqualiedservice
personnel. Servicing is required when the
device has been damaged in any way, such
as power-supply cord or plug is damaged,
liquid has been spilled or objects have
fallen into the device, the device has been
exposed to rain or moisture, does not
operate normally, or has been dropped.
• Battery usage CAUTION – to prevent
battery leakage which may result in bodily
injury, property damage, or damage to the
unit:
• Install all batteries correctly, + and - as
marked on the unit.
• Do not mix batteries (old and new or
carbonandalkaline,etc.).
• Remove batteries when the unit is not
used for a long time.
• Batteries (battery pack or batteries
installed)shallnotbeexposedto
excessiveheatsuchassunshine,re,or
the like.
• Devices shall not be exposed to dripping
or splashing.
• Do not place any sources of danger on
thedevice(e.g.liquidlledobjects,lighted
candles).
• Where the MAINS plug or an appliance
coupler is used as the disconnect device,
the disconnect device shall remain readily
operable.
DCM2025_12_UM_Book1_V3.0.indb 4 9/26/2012 3:30:13 PM

5
English
EN
Warning
•Never remove the casing of this apparatus.
•Never lubricate any part of this apparatus.
•Never place this apparatus on other electrical
equipment.
•Keep this apparatus away from direct sunlight, naked
amesorheat.
•Ensure that you always have easy access to the power
cord, plug or adaptor to disconnect the apparatus from
the power.
Hearing safety
Listen at a moderate volume.
• Using headphones at a high volume can
impair your hearing.This product can
produce sounds in decibel ranges that may
cause hearing loss for a normal person,
even for exposure less than a minute.The
higher decibel ranges are offered for those
that may have already experienced some
hearing loss.
• Sound can be deceiving. Over time your
hearing 'comfort level' adapts to higher
volumes of sound. So after prolonged
listening, what sounds 'normal' can actually
be loud and harmful to your hearing.To
guard against this, set your volume to a safe
level before your hearing adapts and leave
it there.
To establish a safe volume level:
• Set your volume control at a low setting.
• Slowly increase the sound until you can
hear it comfortably and clearly, without
distortion.
Listen for reasonable periods of time:
• Prolonged exposure to sound, even
at normally 'safe' levels, can also cause
hearing loss.
• Be sure to use your equipment reasonably
and take appropriate breaks.
Be sure to observe the following guidelines
when using your headphones.
• Listen at reasonable volumes for
reasonable periods of time.
• Be careful not to adjust the volume as your
hearing adapts.
• Do not turn up the volume so high that
you can't hear what's around you.
• You should use caution or temporarily
discontinue use in potentially hazardous
situations. Do not use headphones while
operating a motorized vehicle, cycling,
skateboarding,etc.;itmaycreateatrafc
hazard and is illegal in many areas.
Notice
This product complies with the radio
interference requirements of the European
Community.
This product complies with the requirements
of the following directives and guidelines:
2004/108/EC + 2006/95/EC
Anychangesormodicationsmadetothis
device that are not expressly approved by
Philips Consumer Lifestyle may void the user’s
authority to operate the equipment.
Your product is designed and manufactured
with high quality materials and components,
which can be recycled and reused.
When this crossed-out wheeled bin symbol is
attached to a product it means that the product
is covered by the European Directive 2002/96/
EC.
DCM2025_12_UM_Book1_V3.0.indb 5 9/26/2012 3:30:14 PM

6EN
Please inform yourself about the local separate
collection system for electrical and electronic
products.
Please act according to your local rules and
do not dispose of your old products with your
normal household waste. Correct disposal of
your old product helps to prevent potential
negative consequences for the environment and
human health.
Your product contains batteries covered by
the European Directive 2006/66/EC, which
cannot be disposed with normal household
waste.Please inform yourself about the local
rules on separate collection of batteries
because correct disposal helps to prevent
negative consequences for the environmental
and human health.
Environmental information
All unnecessary packaging has been omitted.
We have tried to make the packaging easy to
separateintothreematerials:cardboard(box),
polystyrenefoam(buffer)andpolyethylene
(bags,protectivefoamsheet.)
Your system consists of materials which can
be recycled and reused if disassembled by
a specialized company. Please observe the
local regulations regarding the disposal of
packaging materials, exhausted batteries and old
equipment.
The making of unauthorized copies of copy-
protected material, including computer
programs,les,broadcastsandsound
recordings, may be an infringement of
copyrights and constitute a criminal offence.
This equipment should not be used for such
purposes.
“Made for iPod,”“Made for iPhone,” and “Made
for iPad” mean that an electronic accessory
hasbeendesignedtoconnectspecicallyto
iPod, iPhone, or iPad, respectively, and has
beencertiedbythedevelopertomeet
Apple performance standards. Apple is not
responsible for the operation of this device
or its compliance with safety and regulatory
standards. Please note that the use of this
accessory with iPod, iPhone, or iPad may affect
wireless performance.
iPod and iPhone are trademarks of Apple Inc.,
registered in the U.S. and other countries. iPad
is a trademark of Apple Inc.
This apparatus includes this label:
Note
•The type plate is located on the bottom of the
apparatus.
DCM2025_12_UM_Book1_V3.0.indb 6 9/26/2012 3:30:15 PM

7
English
EN
2 Your Micro
Music System
Congratulations on your purchase, and
welcometoPhilips!Tofullybenetfromthe
support that Philips offers, register your product
at www.philips.com/welcome.
Introduction
With this unit, you can:
• enjoy audio from discs, USB devices, iPod,
iPhone, iPad, and other external devices
• listen to radio stations
You can enrich sound output with these sound
effects:
• DigitalSoundControl(DSC)
• DynamicBassBoost(DBB)
The unit supports these media formats:
What's in the box
Check and identify the contents of your
package:
• Main unit
• Remote control
• Speakerboxes(×2)
• FM antenna
• Rubber pad for iPad 2
• User manual
• Quick start guide
DCM2025_12_UM_Book1_V3.0.indb 7 9/26/2012 3:30:15 PM

8EN
Overview of the main unit
a Dock for iPod/iPhone/iPad
b Disc compartment
• Hold the disc.
c
• USB socket.
d MP3 LINK
• Connect external audio device.
e
• Headphone socket.
f
• Turn on the unit.
• Switch to standby or Eco power
standby mode.
g IR sensor
• Detect signals from the remote control
(always point the remote control
towardstheIRsensor).
a
b
c
d
e
f
g
h
ijk
o
n
m
l
h SOURCE
• Select a source.
i /
• Skip to previous/next track.
• Search within a track/disc.
• Tune to a radio station.
j
• Start or pause play.
k
• Stop play.
• Erase a program.
l - PRESET/ALBUM+
• Skip to previous/next album.
• Select a preset radio station.
• Navigate through iPod/iPhone/iPad
menu.
m Display panel
• Display current status.
DCM2025_12_UM_Book1_V3.0.indb 8 9/26/2012 3:30:17 PM

9
English
EN
n
• Open or close the disc tray.
o VOLUME
• Adjust volume.
• Adjust time.
Overview of the remote
control
PRESET/ALBUM
PROG/
CLOCK SET
SLEEP/
TIMER
DSCDBB
FM
VOL
REPEAT/
SHUFFLE
3
456
789
1
0
2
CD
DOCK
DISPLAY
RDS
OK
MENU
USB
MP
3
LINK
a
b
c
e
f
g
p
o
d
h
i
j
m
n
k
l
s
r
q
a
• Turn on the unit.
• Switch to standby or Eco Power
standby mode.
b
• Mute volume.
c CD
• Select CD source.
d /
• Skip to previous/next track.
• Search within a track/disc.
• Tune to a radio station.
e USB/ MP3 LINK
f RDS/DISPLAY
• For selected FM radio stations: display
RDS information.
• Synchronize clock with RDS station.
• Display play information.
g
• Start or pause play.
h VOL +/-
• Adjust volume.
i Numeric keypad
• Select a track directly.
j PROG/CLOCK SET
• Program tracks.
• Program radio stations.
• Set clock.
k SLEEP/TIMER
• Set sleep timer.
• Set alarm timer.
l DSC
• Select a preset sound setting.
m DBB
• Turn on or off dynamic bass
enhancement.
n REPEAT/SHUFFLE
• Play tracks randomly.
• Select a repeat play mode.
DCM2025_12_UM_Book1_V3.0.indb 9 9/26/2012 3:30:18 PM

10 EN
o /MENU
• Stop play.
• Erase a program.
• Access iPod/iPhone/iPad menu.
p DOCK
• Select the dock source for iPod/
iPhone/iPad.
q OK
• Conrmaselection.
• Select FM stereo or FM mono.
r PRESET/ALBUM /
• Skip to previous/next album.
• Select a preset radio station.
• Navigate through iPod/iPhone/iPad
menu.
s FM
• Select FM radio source.
3 Get started
Caution
•Use of controls or adjustments or performance of
procedures other than herein may result in hazardous
radiation exposure or other unsafe operation.
Always follow the instructions in this chapter in
sequence.
If you contact Philips, you will be asked for the
model and serial number of this apparatus.The
model number and serial number are on the
bottom of the apparatus.Write the numbers
here:
Model No. __________________________
Serial No. ___________________________
Connect speakers
Note
•For optimal sound, use the supplied speakers only.
•Connect only speakers with impedance that is the
same or higher than the supplied speakers. Refer to the
Specicationssectionofthismanual.
1 Insert the speaker wires completely into
the speaker input sockets on the back of
the unit.
DCM2025_12_UM_Book1_V3.0.indb 10 9/26/2012 3:30:19 PM

11
English
EN
Connect FM aerial
Tip
•For optimal reception, fully extend and adjust the
position of the antenna.
•For better FM stereo reception, connect an outdoor
FM antenna to the FM AERIAL socket.
•The unit does not support MW radio reception.
1 Connect the supplied FM antenna to the
FM AERIAL socket on the main unit.
Connect power
Caution
•Risk of product damage! Ensure that the power supply
voltage corresponds to the voltage printed on the back
or the underside of the unit.
•Risk of electric shock! When you unplug the AC power
cord, always pull the plug from the socket. Never pull
the cord.
•Before you connect the AC power cord, ensure that
you have completed all other connections.
FM
1 Connect the power cable to the wall
socket.
Prepare the remote control
Caution
•Risk of explosion! Keep batteries away from heat,
sunshine,orre.Neverdiscardbatteriesinre.
To insert the remote control battery:
1 Open the battery compartment.
2 Insert 2 AAA batteries with correct
polarity(+/-)asindicated.
3 Close the battery compartment.
Note
•If you are not going to use the remote control for a
long time, remove the batteries.
•Do not use old and new or different types of batteries
in combination.
•Batteries contain chemical substances, so they should
be disposed of properly.
a
b
c
DCM2025_12_UM_Book1_V3.0.indb 11 9/26/2012 3:30:20 PM

12 EN
Turn on
1 Press .
» The unit switches to the last selected
source.
Switch to standby mode
1 Press for over 3 seconds to switch the
unit to Eco Power Standby mode.
» The backlight on the display panel
turns off.
To switch the unit to standby mode:
1 In Eco Power Standby mode, press for
over 3 seconds.
» Theclock(ifset)appearsonthe
display panel.
Set clock
1 In standby mode, press and hold
PROG/CLOCK SET for more than two
seconds to activate clock setting mode.
» [CLOCK SET](clockset)scrollson
the display, and then the time format
[24H] and [12H] is displayed.
2 Press / to select 24H or 12H, and
then press PROG/CLOCK SET.
» The hour digits begin to blink.
3 Press / to set hour, and then press
PROG/CLOCK SET again.
» The minute digits begin to blink.
4 Press / to set minute.
5 Press PROG/CLOCK SETtoconrmthe
clock setting.
Note
•To exit clock setting mode without storing, press .
•If no button is pressed in 90 seconds, the system exits
clock setting mode automatically.
Demonstrate the unit's
features
1 In the standby mode, press until "DEMO
ON" is displayed.
» This system's features are displayed
one by one.
• To turn off the demonstration, press
again.
Store radio stations
automatically
If no radio stations are stored, the unit can store
radio stations automatically.
1 Turn on the unit.
2 Press FM.
» [AUTO INSTALL -- PRESS PLAY --
STOP CANCEL] (press to start
automatic installation, or press to
cancel)isdisplayed.
3 Press .
» Theradiostationswithsufcientsignal
strength are stored automatically.
» After all available radio stations are
stored,therststoredradiostation
broadcasts automatically.
DCM2025_12_UM_Book1_V3.0.indb 12 9/26/2012 3:30:21 PM

13
English
EN
4 Play
Basic play operations
You can control play through following
operations.
Key Function
/ Toselectatrackorle.
Press and hold to fast-forward/
fast-backward the track during
playback, then release to
resume play.
To pause/resume play during
playback.
DISPLAY To select different play
information.
REPEAT/
SHUFFLE
To select a repeat play mode:
[REP](repeat):playcurrent
track repeatedly.
[REP ALL](repeatall):playall
tracks repeatedly.
[SHUF](shufe):playtracks
randomly.
Press repeatedly to return to
normal play.
You can also use numeric keys to select a track
directly.
Play from disc
1 Press CD to select the CD source.
2 Press OPEN/CLOSE.
» The disc compartment opens.
3 Place a disc with the printed side facing up,
then press .
4 Play starts automatically.
• If play does not start, press / to
select a track, then press .
Play from USB
Ensure that the USB device contains playable
audio contents for supported formats.
1 Insert the USB device into the USB socket.
2 Press USB to select the USB source.
» Play starts automatically. If not, press
PRESET/ALBUM to select a folder and
/ toselectale.ThenpressOK
to start play.
Adjust sound
During play, you can adjust volume through
following operations.
Key Function
VOL
+/-
To increase/decrease the volume.
To mute/restore sound.
DBB To turn on or off dynamic bass
enhancement.
If DBB is activated, [DBB] is displayed.
DSC To select your desired sound effect:
[POP](pop)
[JAZZ](jazz)
[ROCK](rock)
[CLASSIC](classic)
[FLAT](at)
DCM2025_12_UM_Book1_V3.0.indb 13 9/26/2012 3:30:22 PM

14 EN
5 Play iPod/
iPhone/iPad
This system is equipped with a dock for iPod/
iPhone/iPad.You can enjoy audio from the
docked system through the powerful speakers.
Compatible iPod/iPhone/iPad
The unit supports these iPod/iPhone/iPad
models:
Made for:
• iPod touch (1st, 2nd, 3rd, and 4th
generation)
• iPod classic
• iPod with video
• iPod nano (1st, 2nd, 3rd, 4th, 5th, and 6th
generation)
• iPod with color display
• iPod mini
• iPhone 4
• iPhone 3GS
• iPhone 3G
• iPhone
• iPad 2
• iPad
Load the iPod/iPhone/iPad
1 Push the lock key to open the lid of the
dock.
2 Load the iPod/iPhone/iPad onto the dock.
Install the rubber pad
Note
•If your iPad 2 is not in case, you need to use the
supplied rubber pad to keep it stable.
1 Open the dock, and place the rubber pad
onto the dock compartment as indicated.
2 Load your iPad 2.
DCM2025_12_UM_Book1_V3.0.indb 14 9/26/2012 3:30:22 PM

15
English
EN
Charge the iPod/iPhone/iPad
When the unit is connected to power, the
docked iPod/iPhone/iPad starts charging
automatically.
Note
•iPod with color display, iPod classic, and iPod with video
are not compatible with dock charging.
Tip
•For certain iPod models, it may take up to a minute
before the charging indication appears.
Listen to the iPod/iPhone/
iPad
1 Press DOCK to select the iPod/iPhone/
iPad source.
2 Play the selected track on your docked
iPod/iPhone/iPad.
• To pause/resume the play, press .
• To search during play: press and hold
/ , and then release to resume
normal play.
• To scroll through the menu, press
/ .
• Toconrmaselection,pressOK to
conrm.
Remove the iPod/iPhone/iPad
1 Unload the iPod/iPhone/iPad from the
dock.
2 Flip down the lid to hide the dock.
DCM2025_12_UM_Book1_V3.0.indb 15 9/26/2012 3:30:23 PM

16 EN
6 Listen to FM
radio
Tune to FM radio stations
Note
•Ensure that you have connected and fully extended the
supplied FM antenna.
1 Press FM.
2 Press and hold / to tune to a radio
station.
3 When the frequency starts to change,
release the button.
» The FM tuner tunes to a station with
strong reception automatically.
4 Repeat steps 2-3 to tune to more stations.
To tune to a weak station:
Press / repeatedlyuntilyoundoptimal
reception.
Program radio stations
automatically
Note
•You can program a maximum of 20 preset radio
stations.
1 In FM tuner mode, press PROG/CLOCK
SET for 3 seconds to activate automatic
programming.
» [AUTO](auto)isdisplayed.
» The unit stores all the FM radio
stations automatically and then
broadcaststherstpresetradio
station.
Program radio stations
manually
Note
•You can program a maximum of 20 preset radio
stations.
1 Tune to a radio station.
2 Press PROG/CLOCK SETto activate
programming mode.
3 Press / to select a number from
1–20 for this radio station, then press
PROG/CLOCK SETtoconrm.
» The preset number and the frequency
of the preset station are displayed.
4 Repeat steps 2-3 to program other
stations.
Note
•To overwrite a programmed station, store another
station in its place.
Tune to a preset radio station
1 Press / to select a preset number.
Show RDS information
RDS(RadioDataSystem)isaservice
that allows FM stations to show additional
information. If you tune to an RDS station, an
RDS icon and the station name are displayed.
1 Tune to an RDS station.
2 Press RDS repeatedly to scroll through the
followinginformation(ifavailable):
» Station name
DCM2025_12_UM_Book1_V3.0.indb 16 9/26/2012 3:30:23 PM

17
English
EN
» Program type such as [NEWS](news),
[SPORT](sport),[POP M] (pop
music)...
» RDS clock
» Frequency
Synchronize clock with RDS
You can synchronize time shown on the unit
with that on the RDS station.
1 Tune to a RDS radio station that transmits
time signals.
2 Press RDS for over 2 seconds.
» [CT SYNC] is displayed and the unit
reads RDS time automatically.
» If no time signal is received, [NO CT]
is displayed.
Note
•The accuracy of the transmitted time depends on the
RDS station that transmits the time signal.
DCM2025_12_UM_Book1_V3.0.indb 17 9/26/2012 3:30:23 PM

18 EN
7 Other features
Set alarm timer
This unit can be used as an alarm clock.You can
select DISC, iPod/iPhone/iPad, playlist,TUNER
or USB as alarm source.
Note
•Make sure that you have set the time correctly.
1 In standby mode, press and hold
SLEEP/TIMER until [TIMER SET](timer
set)scrollsonthedisplay.
» [SELECT SOURCE](selectsource)
scrolls on the screen.
2 Press SOURCE repeatedly to select a
source: DISC, USB,TUNER, iPod/iPhone/
iPad or playlist.
• If iPod/iPhone/iPad playlist is selected
as the alarm source, you need create
a playlist called "PHILIPS" in your iPod/
iPhone/iPad.
3 Press SLEEP/TIMERtoconrm.
» The hour digits are displayed and begin
to blink.
4 Press / repeatedly to set hour, then
press SLEEP/TIMERagaintoconrm.
» The minute digits are displayed and
begin to blink.
5 Press / to set minute, then press
SLEEP/TIMERtoconrm.
» VOL(volume)isdisplayedandbegins
to blink.
6 Press / to adjust volume, then press
SLEEP/TIMERtoconrm.
» is displayed.
Activate/deactivate alarm timer
1 In standby mode, press SLEEP/TIMER
repeatedly to activate or deactivate timer.
» If timer is activated, is displayed.
Note
•Alarm timer is not available in MP3 LINK mode.
•If DISC/USB/iPod/iPhone/iPad source is selected, yet no
disc is placed or no USB/iPod/iPhone/iPad connected,
the system switches to the tuner source automatically.
•If no playlist named “PHILIPS” exists in the iPod/iPhone/
iPad or the playlist includes no playable track, this
product switches the alarm source to iPod/iPhone/
iPad library.
Set sleep timer
1 When the unit is turned on, press
SLEEP/TIMER repeatedly to select a time
period(inminutes).
» When sleep timer is activated, is
displayed.
» To deactivate sleep timer, press
SLEEP/TIMER again until disappears.
Listen to external audio
device
You can listen to an external audio device such
as MP3 player through this unit.
1 Connect the audio device.
• For audio device with headphone
sockets:
Connect MP3 Link cable to the MP3
LINK socket and to the headphone
socket on the audio device.
2 Select MP3 LINK source.
3 Play the device.
DCM2025_12_UM_Book1_V3.0.indb 18 9/26/2012 3:30:24 PM

19
English
EN
Listen through headphone
1 Plug a headphone into the socket on
the unit.
DCM2025_12_UM_Book1_V3.0.indb 19 9/26/2012 3:30:24 PM

20 EN
8 Product
information
Note
•Product information is subject to change without prior
notice.
Specications
Amplier
Maximum Output
Power
2X20W RMS
Frequency Response 40Hz-20kHZ, ±3dB
Signal to Noise Ratio >77dB
MP3-Link Input 600mV RMS 22 kohm
Disc
LaserType Semiconductor
Disc Diameter 12cm/8cm
Support Disc CD-DA, CD-R, CD-RW,
MP3-CD,WMA-CD
Audio DAC 24Bits / 44.1kHz
Total Harmonic
Distortion
<0.8%(1kHz)
Frequency Response 4Hz-20kHz(44.1kHz)
S/N Ratio >77dBA
Tuner (FM)
Tuning Range 87.5 - 108MHz
Tuning grid 50 KHz
Sensitivity
- Mono, 26dB S/N
Ratio
- Stereo, 46dB S/N
Ratio
< 22 dBf
< 43 dBf
Search Selectivity <28 dBf
Total Harmonic
Distortion
<2%
Signal to Noise
Ratio
>55 dB
Speakers
Speaker Impedance 6 ohm
Speaker Driver 10 cm full range
Sensitivity >84dB/m/W ±
4dB/m/W
General information
AC power 220~240V ~, 50/60 Hz
Operation Power
Consumption
25W
Eco Standby Power
Consumption
<0.5W
USB Direct Version 2.0 HS
Dimensions
- Main Unit
(WxHxD)
- Speaker Box
(WxHxD)
200 x 118 x 210 mm
140 x 224 x 144 mm
Weight
- Main Unit
- Speaker Box
1.3 kg
1.1 kg x 2
USB playability information
Compatible USB devices:
•USBashmemory(USB2.0orUSB1.1)
•USBashplayers(USB2.0orUSB1.1)
•memory cards (requires an additional card
readertoworkwiththisunit)
DCM2025_12_UM_Book1_V3.0.indb 20 9/26/2012 3:30:24 PM

21
English
EN
Supported formats:
•USBormemoryleformatFAT12,FAT16,
FAT32(sectorsize:512bytes)
•MP3bitrate(datarate):32-320Kbpsand
variable bit rate
•WMA v9 or earlier
•Directory nesting up to a maximum of 8
levels
•Number of albums/ folders: maximum 99
•Number of tracks/titles: maximum 999
•ID3 tag v2.0 or later
•File name in Unicode UTF8 (maximum
length:64bytes)
Unsupported formats:
•Empty albums: an empty album is an album
thatdoesnotcontainMP3/WMAles,and
is not be shown in the display.
•Unsupportedleformatsareskipped.For
example,Worddocuments(.doc)orMP3
leswithextension.dlfareignoredand
not played.
•AAC,WAV,PCMaudioles
•DRMprotectedWMAles(.wav,.m4a,
.m4p,.mp4,.aac)
•WMAlesinLosslessformat
Supported MP3 disc formats
• ISO9660, Joliet
• Maximum title number: 512 (depending on
lenamelength)
• Maximum album number: 255
• Supported sampling frequencies: 32 kHz,
44.1kHz, 48 kHz
• SupportedBit-rates:32~320(kbps),
variable bit rates
DCM2025_12_UM_Book1_V3.0.indb 21 9/26/2012 3:30:24 PM
