DeWalt XR Li-ION DCD995 User manual

DCD990 20V Max* Heavy-Duty 1/2"(13 mm) Brushless Cordless Drill/Driver
DCD995 20V Max* Heavy-Duty 1/2"(13 mm) Brushless Cordless Drill/Driver/Hammerdrill
Perceuse/visseuse industrielle, sans fil et sans balai, DCD990 20v max* 13mm (1/2po)
Perceuse/visseuse/perceuse à percussion industrielle, sans fil et sans balai, DCD995 20v max* 13mm (1/2po)
DCD990 Taladro/destornillador inalámbrico sin escobillas de 20 V Max* para trabajos pesados de 1/2"(13 mm)
DCD995 Taladro/destornillador/taladro percutor inalámbrico sin escobillas de 20 V Max* para trabajos pesados de 1/2"(13 mm)
INSTRUCTION MANUAL
GUIDE D'UTILISATION
MANUAL DE INSTRUCCIONES
INSTRUCTIVO DE OPERACIÓN, CENTROS DE SERVICIO Y PÓLIZA DE
GARANTÍA. ADVERTENCIA: LÉASE ESTE INSTRUCTIVO ANTES DE
USAR EL PRODUCTO.
If you have questions or comments, contact us.
Pour toute question ou tout commentaire, nous contacter.
Si tiene dudas o comentarios, contáctenos.
1-800-4-DEWALT • www.dewalt.com

1
English
Definitions: Safety Guidelines
The definitions below describe the level of severity for each signal
word. Please read the manual and pay attention to these symbols.
DANGER: Indicates an imminently hazardous situation
which, if not avoided, will result in death or serious injury.
WARNING: Indicates a potentially hazardous situation which, if
not avoided, could result in death or serious injury.
CAUTION: Indicates a potentially hazardous situation which, if
not avoided, may result in minor or moderate injury.
NOTICE: Indicates a practice not related to personal injury
which, if not avoided, may result in property damage.
IF YOU HAVE ANY QUESTIONS OR COMMENTS ABOUT THIS OR
ANY DEWALT TOOL, CALL US TOLL FREE AT: 1-800-4-DEWALT
(1-800-433-9258).
WARNING: To reduce the risk of injury, read the instruction
manual.
General Power Tool Safety Warnings
WARNING! Read all safety warnings and all instructions.
Failure to follow the warnings and instructions may result in
electric shock, fire and/or serious injury.
SAVE ALL WARNINGS AND INSTRUCTIONS
FOR FUTURE REFERENCE
The term “power tool” in the warnings refers to your mains-operated
(corded) power tool or battery-operated (cordless) power tool.
1) WORK AREA SAFETY
a) Keep work area clean and well lit. Cluttered or dark areas
invite accidents.
b) Do not operate power tools in explosive atmospheres,
such as in the presence of flammable liquids, gases or
dust. Power tools create sparks which may ignite the dust or
fumes.
c) Keep children and bystanders away while operating a
power tool. Distractions can cause you to lose control.
2) ELECTRICAL SAFETY
a) Power tool plugs must match the outlet. Never modify
the plug in any way. Do not use any adapter plugs with
earthed (grounded) power tools. Unmodified plugs and
matching outlets will reduce risk of electric shock.
b) Avoid body contact with earthed or grounded surfaces
such as pipes, radiators, ranges and refrigerators. There
is an increased risk of electric shock if your body is earthed or
grounded.
c) Do not expose power tools to rain or wet conditions. Water
entering a power tool will increase the risk of electric shock.
d) Do not abuse the cord. Never use the cord for carrying,
pulling or unplugging the power tool. Keep cord away
from heat, oil, sharp edges or moving parts. Damaged or
entangled cords increase the risk of electric shock.
e) When operating a power tool outdoors, use an extension
cord suitable for outdoor use. Use of a cord suitable for
outdoor use reduces the risk of electric shock.
f) If operating a power tool in a damp location is unavoidable,
use a ground fault circuit interrupter (GFCI) protected
supply. Use of a GFCI reduces the risk of electric shock.

2
English
b) Do not use the power tool if the switch does not turn it
on and off. Any power tool that cannot be controlled with the
switch is dangerous and must be repaired.
c) Disconnect the plug from the power source and/or the
battery pack from the power tool before making any
adjustments, changing accessories, or storing power
tools. Such preventive safety measures reduce the risk of
starting the power tool accidentally.
d) Store idle power tools out of the reach of children and do
not allow persons unfamiliar with the power tool or these
instructions to operate the power tool. Power tools are
dangerous in the hands of untrained users.
e) Maintain power tools. Check for misalignment or binding
of moving parts, breakage of parts and any other condition
that may affect the power tool’s operation. If damaged,
have the power tool repaired before use. Many accidents
are caused by poorly maintained power tools.
f) Keep cutting tools sharp and clean. Properly maintained
cutting tools with sharp cutting edges are less likely to bind
and are easier to control.
g) Use the power tool, accessories and tool bits, etc. in
accordance with these instructions, taking into account
the working conditions and the work to be performed. Use
of the power tool for operations different from those intended
could result in a hazardous situation.
5) BATTERY TOOL USE AND CARE
a) Recharge only with the charger specified by the
manufacturer. A charger that is suitable for one type of battery
pack may create a risk of fire when used with another battery
pack.
b) Use power tools only with specifically designated battery
packs. Use of any other battery packs may create a risk of
injury and fire.
3) PERSONAL SAFETY
a) Stay alert, watch what you are doing and use common
sense when operating a power tool. Do not use a power
tool while you are tired or under the influence of drugs,
alcohol or medication. A moment of inattention while
operating power tools may result in serious personal injury.
b) Use personal protective equipment. Always wear eye
protection. Protective equipment such as dust mask, non-
skid safety shoes, hard hat, or hearing protection used for
appropriate conditions will reduce personal injuries.
c) Prevent unintentional starting. Ensure the switch is in
the off position before connecting to power source and/
or battery pack, picking up or carrying the tool. Carrying
power tools with your finger on the switch or energizing power
tools that have the switch on invites accidents.
d) Remove any adjusting key or wrench before turning the
power tool on. A wrench or a key left attached to a rotating
part of the power tool may result in personal injury.
e) Do not overreach. Keep proper footing and balance at
all times. This enables better control of the power tool in
unexpected situations.
f) Dress properly. Do not wear loose clothing or jewelry.
Keep your hair, clothing and gloves away from moving
parts. Loose clothes, jewelry or long hair can be caught in
moving parts.
g) If devices are provided for the connection of dust
extraction and collection facilities, ensure these are
connected and properly used. Use of dust collection can
reduce dust-related hazards.
4) POWER TOOL USE AND CARE
a) Do not force the power tool. Use the correct power tool
for your application. The correct power tool will do the job
better and safer at the rate for which it was designed.

3
English
this tool without holding it with both hands. Operating this
tool with one hand will result in loss of control. Breaking through or
encountering hard materials such as re-bar may be hazardous as
well.
• Accessories and tool may get hot during operation. Wear
gloves when handling them if performing heat producing applications
such as hammerdrilling and drilling metals.
• Do not operate this tool for long periods of time. Vibration
caused by hammer action may be harmful to your hands and arms.
Use gloves to provide extra cushion and limit exposure by taking
frequent rest periods.
• Air vents often cover moving parts and should be avoided.
Loose clothes, jewelry or long hair can be caught in moving parts.
WARNING: ALWAYS use safety glasses. Everyday eyeglasses are
NOT safety glasses. Also use face or dust mask if cutting operation is
dusty. ALWAYS WEAR CERTIFIED SAFETY EQUIPMENT:
• ANSI Z87.1 eye protection (CAN/CSA Z94.3),
• ANSI S12.6 (S3.19) hearing protection,
• NIOSH/OSHA/MSHA respiratory protection.
WARNING: Some dust created by power sanding, sawing,
grinding, drilling, and other construction activities contains chemicals
known to the State of California to cause cancer, birth defects or
other reproductive harm. Some examples of these chemicals are:
• lead from lead-based paints,
• crystalline silica from bricks and cement and other masonry
products, and
• arsenic and chromium from chemically-treated lumber.
Your risk from these exposures varies, depending on how often you do
this type of work. To reduce your exposure to these chemicals: work
in a well ventilated area, and work with approved safety equipment,
such as those dust masks that are specially designed to filter out
microscopic particles.
c) When battery pack is not in use, keep it away from other
metal objects, like paper clips, coins, keys, nails, screws,
or other small metal objects, that can make a connection
from one terminal to another. Shorting the battery terminals
together may cause burns or a fire.
d) Under abusive conditions, liquid may be ejected from
the battery; avoid contact. If contact accidentally occurs,
flush with water. If liquid contacts eyes, additionally seek
medical help. Liquid ejected from the battery may cause
irritation or burns.
6) SERVICE
a) Have your power tool serviced by a qualified repair person
using only identical replacement parts. This will ensure that
the safety of the power tool is maintained.
Drill/Driver/Hammerdrill Safety Warnings
• Wear ear protectors when impact drilling. Exposure to noise
can cause hearing loss.
• Use auxiliary handle(s), if supplied with the tool. Loss of
control can cause personal injury.
•Hold power tool by insulated gripping surfaces, when
performing an operation where the cutting accessory may
contact hidden wiring. Cutting accessory contacting a “live” wire
may make exposed metal parts of the power tool “live” and could
give the operator an electric shock.
• Use clamps or other practical way to secure and support the
workpiece to a stable platform. Holding the work by hand or
against your body is unstable and may lead to loss of control.
• Wear safety goggles or other eye protection. Hammering and
drilling operations cause chips to fly. Flying particles can cause
permanent eye damage.
• Always use the side handle supplied with the tool. Keep a
firm grip on the tool at all times. Do not attempt to operate

4
English
RPM ............. revolutions per .................... earthing
..................... minute ........................ terminal
sfpm ............. surface feet ..................... safety alert
..................... per minute ........................ symbol
SPM ............. strokes per minute
Important Safety Instructions for All
Battery Packs
When ordering replacement battery packs, be sure to include the
catalog number and voltage. Consult the chart at the end of this manual
for compatibility of chargers and battery packs.
The battery pack is not fully charged out of the carton. Before using
the battery pack and charger, read the safety instructions below and
then follow charging procedures outlined.
READ ALL INSTRUCTIONS
• Do not charge or use the battery pack in explosive
atmospheres, such as in the presence of flammable liquids,
gases or dust. Inserting or removing the battery pack from the
charger may ignite the dust or fumes.
• NEVER force the battery pack into the charger. DO NOT
modify the battery pack in any way to fit into a non-
compatible charger as battery pack may rupture causing
serious personal injury. Consult the chart at the end of this
manual for compatibility of batteries and chargers.
• Charge the battery packs only in designated DEWALT chargers.
• DO NOT splash or immerse in water or other liquids.
• Do not store or use the tool and battery pack in locations
where the temperature may reach or exceed 105°F (40°C)
(such as outside sheds or metal buildings in summer). For
best life store battery packs in a cool, dry location.
• Avoid prolonged contact with dust from power sanding,
sawing, grinding, drilling, and other construction activities.
Wear protective clothing and wash exposed areas with soap
and water. Allowing dust to get into your mouth, eyes, or lay on the
skin may promote absorption of harmful chemicals.
WARNING: Use of this tool can generate and/or disperse dust,
which may cause serious and permanent respiratory or other
injury. Always use NIOSH/OSHA approved respiratory protection
appropriate for the dust exposure. Direct particles away from face
and body.
WARNING: Always wear proper personal hearing protection
that conforms to ANSI S12.6 (S3.19) during use. Under some
conditions and duration of use, noise from this product may contribute
to hearing loss.
CAUTION: When not in use, place tool on its side on a stable
surface where it will not cause a tripping or falling hazard. Some
tools with large battery packs will stand upright on the battery pack
but may be easily knocked over.
• The label on your tool may include the following symbols. The
symbols and their definitions are as follows:
V................... volts A...................... amperes
Hz................. hertz W..................... watts
min ............... minutes or AC.......... alternating
or DC... direct current ........................ current
................. Class I Construction or AC/DC... alternating
.....................
..................... (grounded) ........................ or direct
................. Class II Construction ........................ current
..................... (double insulated) no.................... no load
…/min .......... per minute ........................ speed
BPM ............. beats per minute
n ...................... rated
IPM............... impacts per minute ........................ speed

5
English
electrolyte is composed of a mixture of liquid organic carbonates
and lithium salts.
• Contents of opened battery cells may cause respiratory
irritation. Provide fresh air. If symptoms persist, seek medical
attention.
WARNING: Burn hazard. Battery liquid may be flammable if
exposed to spark or flame.
The RBRC™ Seal
The RBRC™ (Rechargeable Battery Recycling
Corporation) Seal on the nickel cadmium, nickel metal
hydride or lithium ion batteries (or battery packs)
indicate that the costs to recycle these batteries (or
battery packs) at the end of their useful life have already
been paid by DEWALT. In some areas, it is illegal to
place spent nickel cadmium, nickel metal hydride or lithium ion batteries
in the trash or municipal solid waste stream and the RBRC program
provides an environmentally conscious alternative.
RBRC™, in cooperation with DEWALT and other battery users, has
established programs in the United States and Canada to facilitate the
collection of spent nickel cadmium, nickel metal hydride or lithium ion
batteries. Help protect our environment and conserve natural resources
by returning the spent nickel cadmium, nickel metal hydride or lithium
ion batteries to an authorized DEWALT service center or to your local
retailer for recycling. You may also contact your local recycling center
for information on where to drop off the spent battery.
RBRC™ is a registered trademark of the Rechargeable Battery
Recycling Corporation.
Important Safety Instructions for All
Battery Chargers
SAVE THESE INSTRUCTIONS: This manual contains important
safety and operating instructions for battery chargers.
NOTE: Do not store the battery packs in a tool with the
trigger switch locked on. Never tape the trigger switch in the
ON position.
WARNING: Fire hazard. Never attempt to open the battery pack
for any reason. If the battery pack case is cracked or damaged, do
not insert into the charger. Do not crush, drop or damage the battery
pack. Do not use a battery pack or charger that has received a sharp
blow, been dropped, run over or damaged in any way (e.g., pierced
with a nail, hit with a hammer, stepped on). Damaged battery packs
should be returned to the service center for recycling.
WARNING: Fire hazard. Do not store or carry the battery pack
so that metal objects can contact exposed battery terminals.
For example, do not place the battery pack in aprons, pockets, tool
boxes, product kit boxes, drawers, etc., with loose nails, screws,
keys, etc. Transporting batteries can possibly cause fires if the
battery terminals inadvertently come in contact with conductive
materials such as keys, coins, hand tools and the like. The US
Department of Transportation Hazardous Material Regulations (HMR)
actually prohibit transporting batteries in commerce or on airplanes
(e.g., packed in suitcases and carry-on luggage) UNLESS they are
properly protected from short circuits. So when transporting individual
battery packs, make sure that the battery terminals are protected and
well insulated from materials that could contact them and cause a
short circuit.
SPECIFIC SAFETY INSTRUCTIONS FOR LITHIUM ION (Li-Ion)
• Do not incinerate the battery pack even if it is severely
damaged or is completely worn out. The battery pack can
explode in a fire. Toxic fumes and materials are created when
lithium ion battery packs are burned.
• If battery contents come into contact with the skin,
immediately wash area with mild soap and water. If battery
liquid gets into the eye, rinse water over the open eye for 15 minutes
or until irritation ceases. If medical attention is needed, the battery

6
English
• When operating a charger outdoors, always provide a dry
location and use an extension cord suitable for outdoor use.
Use of a cord suitable for outdoor use reduces the risk of electric
shock.
• An extension cord must have adequate wire size (AWG or
American Wire Gauge) for safety. The smaller the gauge number
of the wire, the greater the capacity of the cable, that is, 16 gauge
has more capacity than 18 gauge. An undersized cord will cause a
drop in line voltage resulting in loss of power and overheating. When
using more than one extension to make up the total length, be sure
each individual extension contains at least the minimum wire size.
The following table shows the correct size to use depending on cord
length and nameplate ampere rating. If in doubt, use the next heavier
gauge. The lower the gauge number, the heavier the cord.
Minimum Gauge for Cord Sets
Ampere Rating
Volts Total Length of Cord
in Feet (meters)
120 V 25
(7.6) 50 (15.2) 100 (30.5) 150 (45.7)
240 V 50
(15.2) 100 (30.5) 200 (61.0) 300 (91.4)
More
Than
Not
More
Than AWG
0 6 18 16 16 14
610 1816 14 12
10 12 16 16 14 12
12 16 14 12 Not Recommended
• Do not place any object on top of the charger or place the
charger on a soft surface that might block the ventilation
slots and result in excessive internal heat. Place the charger
• Before using the charger, read all instructions and cautionary
markings on the charger, battery pack and product using the battery
pack.
WARNING: Shock hazard. Do not allow any liquid to get inside the
charger. Electric shock may result.
CAUTION: Burn hazard. To reduce the risk of injury, charge only
DEWALT rechargeable battery packs. Other types of batteries may
overheat and burst resulting in personal injury and property damage.
NOTICE: Under certain conditions, with the charger plugged into the
power supply, the charger can be shorted by foreign material. Foreign
materials of a conductive nature, such as, but not limited to, grinding
dust, metal chips, steel wool, aluminum foil or any buildup of metallic
particles should be kept away from the charger cavities. Always unplug
the charger from the power supply when there is no battery pack in the
cavity. Unplug the charger before attempting to clean.
•DO NOT attempt to charge the battery pack with any
chargers other than the ones in this manual. The charger and
battery pack are specifically designed to work together.
• These chargers are not intended for any uses other than
charging DEWALT rechargeable batteries. Any other uses may
result in risk of fire, electric shock or electrocution.
• Do not expose the charger to rain or snow.
• Pull by the plug rather than the cord when disconnecting the
charger. This will reduce the risk of damage to the electric plug and
cord.
• Make sure that the cord is located so that it will not be
stepped on, tripped over or otherwise subjected to damage
or stress.
• Do not use an extension cord unless it is absolutely
necessary. Use of improper extension cord could result in risk of
fire, electric shock or electrocution.

7
English
3. The completion of charge will be indicated by the red light remaining
ON continuously. The pack is fully charged and may be used at this
time or left in the charger.
Indicator Light Operation
PACK CHARGING
PACK CHARGED
x
HOT/COLD DELAY
PROBLEM PACK OR CHARGER
PROBLEM POWERLINE
Charge Indicators
This charger is designed to detect certain problems that can arise.
Problems are indicated by the red light flashing at a fast rate. If this
occurs, re-insert the battery pack into the charger. If the problem
persists, try a different battery pack to determine if the charger is
working properly. If the new pack charges correctly, then the original
pack is defective and should be returned to a service center or other
collection site for recycling. If the new battery pack elicits the same
trouble indication as the original, have the charger and the battery pack
tested at an authorized service center.
HOT/COLD DELAY
This charger has a hot/cold delay feature: when the charger detects a
battery that is hot, it automatically starts a delay, suspending charging
until the battery has cooled. After the battery has cooled, the charger
automatically switches to the pack charging mode. This feature ensures
maximum battery life. The red light flashes long, then short while in the
hot/cold delay mode.
in a position away from any heat source. The charger is ventilated
through slots in the top and the bottom of the housing.
• Do not operate the charger with a damaged cord or plug.
• Do not operate the charger if it has received a sharp blow,
been dropped or otherwise damaged in any way. Take it to an
authorized service center.
• Do not disassemble the charger; take it to an authorized
service center when service or repair is required. Incorrect
reassembly may result in a risk of electric shock, electrocution or fire.
• Disconnect the charger from the outlet before attempting
any cleaning. This will reduce the risk of electric shock.
Removing the battery pack will not reduce this risk.
• NEVER attempt to connect 2 chargers together.
• The charger is designed to operate on standard 120V
household electrical power. Do not attempt to use it on any
other voltage. This does not apply to the vehicular charger.
Chargers
Your tool uses a DEWALT charger. Be sure to read all safety instructions
before using your charger. Consult the chart at the end of this manual
for compatibility of chargers and battery packs.
Charging Procedure H
FIG. 1
(Fig. 1)
1. Plug the charger into an appropriate
outlet before inserting the battery
pack.
2. Insert the battery pack (H) into
the charger, as shown in Figure 1,
making sure the pack is fully seated
in charger. The red (charging) light
will blink continuously, indicating
that the charging process has
started.

8
English
4. If the battery pack does not charge properly:
a. Check operation of receptacle by plugging in a lamp or other
appliance;
b. Check to see if receptacle is connected to a light switch which
turns power off when you turn out the lights;
c. Move the charger and battery pack to a location where the
surrounding air temperature is approximately 65 °F–75 °F
(18°–24°C);
d. If charging problems persist, take the tool, battery pack and
charger to your local service center.
5. The battery pack should be recharged when it fails to produce
sufficient power on jobs which were easily done previously.
DO NOT CONTINUE to use under these conditions. Follow the
charging procedure. You may also charge a partially used pack
whenever you desire with no adverse effect on the battery pack.
6. Foreign materials of a conductive nature such as, but not limited to,
grinding dust, metal chips, steel wool, aluminum foil, or any buildup
of metallic particles should be kept away from charger cavities.
Always unplug the charger from the power supply when there is no
battery pack in the cavity. Unplug the charger before attempting to
clean.
7. Do not freeze or immerse the charger in water or any other liquid.
WARNING: Shock hazard. Don’t allow any liquid to get inside the
charger. Electric shock may result.
WARNING: Burn hazard. Do not submerge the battery pack in
any liquid or allow any liquid to enter the battery pack. Never attempt
to open the battery pack for any reason. If the plastic housing of the
battery pack breaks or cracks, return to a service center for recycling.
Storage Recommendations
1. The best storage place is one that is cool and dry, away from direct
sunlight and excess heat or cold.
LEAVING THE BATTERY PACK IN THE CHARGER
The charger and battery pack can be left connected with the charge
indicator showing Pack Charged.
WEAK BATTERY PACKS: Weak batteries will continue to function but
should not be expected to perform as much work.
FAULTY BATTERY PACKS: This charger will not charge a faulty
battery pack. The charger will indicate faulty battery pack by refusing to
light or by displaying problem pack or charger.
NOTE: This could also mean a problem with a charger.
PROBLEM POWER LINE
Some chargers have a Problem Power Line indicator. When the charger
is used with some portable power sources such as generators or
sources that convert DC to AC, the charger may temporarily suspend
operation, flashing the red light with two fast blinks followed by a pause.
This indicates the power source is out of limits.
Important Charging Notes
1. Longest life and best performance can be obtained if the battery
pack is charged when the air temperature is between 65°F and
75 °F (18°–24 °C). DO NOT charge the battery pack in an air
temperature below +40°F (+4.5°C), or above +105°F (+40.5°C).
This is important and will prevent serious damage to the battery
pack.
2. The charger and battery pack may become warm to the touch
while charging. This is a normal condition, and does not indicate
a problem. To facilitate the cooling of the battery pack after use,
avoid placing the charger or battery pack in a warm environment
such as in a metal shed or an uninsulated trailer.
3. A cold battery pack will charge at about half the rate of a warm
battery pack. The battery pack will charge at that slower rate
throughout the entire charging cycle and will not return to maximum
charge rate even if the battery pack warms.

9
English
COMPONENTS (FIG. 2)
WARNING: Never modify the power tool or any part of it. Damage
or personal injury could result.
A. Trigger switch G. Side handle
B. Forward/reverse control button H. Battery pack
C. Worklight I. Battery release button
D. Chuck J. Belt hook
E. Torque adjustment collar K. Bit clip
F. Gear shifter L. Screw
Variable Speed Trigger Switch (Fig. 2)
To turn the tool on, squeeze the trigger switch (A). To turn the tool
off, release the trigger switch. Your tool is equipped with a brake. The
chuck will stop as soon as the trigger switch is fully released.
NOTE: Continuous use in variable speed range is not recommended.
It may damage the switch and should be avoided.
Side Handle (Fig. 2)
WARNING: To reduce the risk of personal injury, ALWAYS operate
the tool with the side handle properly installed. Failure to do so may
result in the side handle slipping during tool operation and subsequent
loss of control. Hold tool with both hands to maximize control.
Side handle (G) clamps to the front of the gear case and may be rotated
360° to permit right- or left-hand use. Side handle must be tightened
sufficiently to resist the twisting action of the tool if the accessory binds
or stalls. Be sure to grip the side handle at the far end to control the tool
during a stall.
If model is not equipped with side handle, grip drill with one hand on the
handle and one hand on the battery pack.
NOTE: Side handle comes equipped on both models.
2. For long storage, it is recommended to store a fully charged battery
pack in a cool dry place out of the charger for optimal results.
NOTE: Battery packs should not be stored completely depleted of
charge. The battery pack will need to be recharged before use.
SAVE THESE INSTRUCTIONS
FOR FUTURE USE
DE
A
B
FIG. 2 F
C
I
J
K
L
G
H
DCD995

10
English
WARNING: When the torque adjustment collar is in the drill or
hammerdrill positions, the drill will not clutch. The drill may stall if
overloaded, causing a sudden twist.
FIG. 3 FIG. 4 FIG. 5
F
E E
F
Three-Speed Gearing (Fig. 3–5)
The three-speed feature of your tool allows you to shift gears for greater
versatility. To select speed 1 (highest torque setting), turn the tool off and
permit it to stop. Slide the gear shifter (F) all the way forward. Speed 2
(middle torque and speed setting) is in the middle position. Speed 3
(highest speed setting) is to the rear.
NOTE: Do not change gears when the tool is running. Always allow
the drill to come to a complete stop before changing gears. If you have
trouble changing gears, depress and release the trigger switch and try
again.
Keyless Single Sleeve Chuck (Fig. 6–8)
WARNING: Do not attempt to tighten drill bits (or any other
accessory) by gripping the front part of the chuck and turning the
Forward/Reverse Control Button (Fig. 2)
A forward/reverse control button (B) determines the direction of the
tool and also serves as a lock-off button.
To select forward rotation, release the trigger switch and depress the
forward/reverse control button on the right side of the tool.
To select reverse, release the trigger switch and depress the forward/
reverse control button on the left side of the tool.
The center position of the control button locks the tool in the OFF
position. When changing the position of the control button, be sure
the trigger is released.
NOTE: The first time the tool is run after changing the direction of
rotation, you may hear a click on start up. This is normal and does not
indicate a problem.
Worklight (Fig. 2)
There is a worklight (C) located on the foot of the tool. The worklight is
activated when the trigger switch is depressed, and will automatically
turn off 20 seconds after the trigger switch is released. If the trigger
switch remains depressed, the worklight will remain on.
NOTE: The worklight is for lighting the immediate work surface and is
not intended to be used as a flashlight.
Torque Adjustment Collar/Electronic
Clutch (Fig. 3–5)
Your tool has an electronic adjustable torque screwdriver system for
driving and removing a wide array of fasteners. Circling the torque
adjustment collar (E) are numbers. These numbers are used to set the
clutch to deliver a torque range. The higher the number on the collar,
the higher the torque and the larger the fastener that can be driven. To
select any of the numbers, rotate until the desired number aligns with
the arrow.

11
English
Belt Hook and Bit Clip (Fig. 2)
WARNING: To reduce the risk of serious personal injury, DO
NOT suspend tool overhead or suspend objects from the belt hook.
ONLY hang tool’s belt hook from a work belt.
WARNING: To reduce the risk of serious personal injury,
ensure the screw holding the belt hook is secure.
IMPORTANT: When attaching or replacing the belt hook (J) or bit clip
(K), use only the screw (L) that is provided. Be sure to securely tighten
the screw.
The belt hook (J) and bit clip (K) can be be attached to either side of
the tool using only the screw (L) provided, to accommodate left- or
right- handed users. If the hook or bit clip is not desired at all, it can be
removed from the tool.
To move belt hook or bit clip, remove the screw (L) that holds it in place
then reassemble on the opposite side. Be sure to securely tighten the
screw.
OPERATION
WARNING: To reduce the risk of serious personal injury, place
the forward/reverse button in the lock-off position or turn tool
off and disconnect battery pack before making any adjustments
or removing/installing attachments or accessories. An accidental
start-up can cause injury.
Installing and Removing the Battery Pack
(Fig. 9)
NOTE: For best results, make sure your battery pack is fully charged.
To install the battery pack (H) into the tool handle, align the battery
pack with the rails inside the tool’s handle and slide it into the handle
until the battery pack is firmly seated in the tool and ensure that it does
not disengage.
tool on. Damage to the chuck and personal injury may result. Always
lock off trigger switch and disconnect tool from power source when
changing accessories.
WARNING: Always ensure the bit is secure before starting the
tool. A loose bit may eject from tool causing possible personal injury.
Your tool features a keyless chuck with one rotating sleeve for one-
handed operation of the chuck. To insert a drill bit or other accessory,
follow these steps.
FIG. 7 FIG. 8
D
FIG. 6
1. Turn tool off and disconnect tool from power source.
2. Grasp the black sleeve of the chuck (D) with one hand and use
the other hand to secure the tool as shown in Figure 6. Rotate the
sleeve counterclockwise (as viewed from the front) far enough to
accept the desired accessory.
3. Insert the accessory about 3/4" (19 mm) into the chuck and tighten
securely by rotating the chuck sleeve clockwise with one hand
while holding the tool with the other hand. Continue to rotate the
chuck sleeve until several ratchet clicks are heard to ensure full
gripping power.
Be sure to tighten chuck with one hand on the chuck sleeve and one
hand holding the tool for maximum tightness.
To release the accessory, repeat Steps 1 and 2 above.

12
English
NOTE: The fuel gauge is only an indication of the charge left on the
battery pack. It does not indicate tool functionality and is subject to
variation based on product components, temperature and end-user
application.
For more information regarding fuel gauge battery packs, please call
1-800-4-DEWALT (1-800-433-9258) or visit our website www.dewalt.
com.
Screwdriving (Fig. 3)
1. Select the desired speed/torque range using the gear shifter to
match the speed and torque to the planned operation.
2. Turn the torque adjustment collar (E) to the desired position.
NOTE: Use the lowest torque setting required to seat the fastener
at the desired depth. The lower the number, the lower the torque
output.
3. Insert the desired fastener accessory into the chuck as you would
any drill bit.
4. Make some practice runs in scrap or on unseen areas of the
workpiece to determine the proper position of the torque
adjustment collar.
5. Always start with lower torque settings, then advance to higher
torque settings to avoid damage to the workpiece or fastener.
NOTE: When torque is achieved in screwdriving mode, the unit will
automatically shut off with a set of short pulses.
Drilling (Fig. 4)
NOTICE: If drilling thin material, use a wood “back-up” block to
prevent damage to the material.
1. Select the desired speed/torque range using the gear shifter to
match the speed and torque to the planned operation. Turn the
collar (E) to the drill symbol.
To remove the battery pack from the tool, press the release button (I)
and firmly pull the battery pack out of the tool handle. Insert it into the
charger as described in the charger section of this manual.
FIG. 9
I
H
FUEL GAUGE BATTERY PACKS (FIG. 10)
Some DEWALT battery packs include a fuel gauge which consists of
three green LED lights that indicate the level of charge remaining in the
battery pack.
To actuate the fuel gauge, press and hold the fuel gauge button (M). A
combination of the three green LED lights will illuminate designating the
level of charge left. When the level of charge in the battery is below the
usable limit, the fuel gauge will not illuminate and the battery will need
to be recharged.
M
FIG. 10

13
English
3. Drill straight, keeping the bit at a right angle to the work. Do not
exert side pressure on the bit when drillling as this will cause
clogging of the bit flutes and a slower drilling speed.
4. When drilling deep holes, if the hammer speed starts to drop off,
pull the bit partially out of the hole with tool still running to help clear
debris from the hole.
NOTE: A smooth, even flow of dust from the hole indicates proper
drilling rate.
MAINTENANCE
WARNING: To reduce the risk of serious personal injury, place
the forward/reverse button in the lock-off position or turn tool
off and disconnect battery pack before making any adjustments
or removing/installing attachments or accessories. An accidental
start-up can cause injury.
Cleaning
WARNING: Blow dirt and dust out of all air vents with clean, dry air
at least once a week. To minimize the risk of eye injury, always wear
ANSI Z87.1 approved eye protection when performing this.
WARNING: Never use solvents or other harsh chemicals for
cleaning the non-metallic parts of the tool. These chemicals may
weaken the plastic materials used in these parts. Use a cloth
dampened only with water and mild soap. Never let any liquid get
inside the tool; never immerse any part of the tool into a liquid.
CHARGER CLEANING INSTRUCTIONS
WARNING: Shock hazard. Disconnect the charger from the AC
outlet before cleaning. Dirt and grease may be removed from the
exterior of the charger using a cloth or soft non-metallic brush. Do not
use water or any cleaning solutions.
2. Use sharp drill bits only. For MASONRY, such as brick, cement,
cinder block, etc., use carbide-tipped bits rated for percussion
drilling.
3. Always apply pressure in a straight line with the bit. Use enough
pressure to keep drill biting, but do not push hard enough to stall
the motor or deflect the bit.
4. Hold tool firmly with both hands to control the twisting action of the
drill. If model is not equipped with side handle, grip drill with one
hand on the handle and one hand on the battery pack.
WARNING: Drill may stall if overloaded causing a sudden twist.
Always expect the stall. Grip the drill firmly to control the twisting
action and avoid injury.
5. IF DRILL STALLS, it is usually because it is being overloaded
or improperly used. RELEASE TRIGGER IMMEDIATELY,
remove drill bit from work, and determine cause of stalling. DO
NOT DEPRESS TRIGGER ON AND OFF IN AN ATTEMPT
TO START A STALLED DRILL — THIS CAN DAMAGE THE
DRILL.
6. To minimize stalling or breaking through the material, reduce
pressure on drill and ease the bit through the last fractional part of
the hole.
7 . Keep the motor running when pulling the bit back out of a drilled
hole. This will help prevent jamming.
Hammerdrilling (Fig. 5)
1. Select the desired speed/torque range using the gear shifter to
match the speed and torque to the planned operation. Turn the
collar (E) to the hammerdrill symbol.
IMPORTANT: Use carbide-tipped or masonry bits rated for
percussion drilling only.
2. Drill with just enough force on the hammer to keep it from bouncing
excessively or "rising" off the bit. Too much force will cause slower
drilling speeds, overheating, and a lower drilling rate.

14
English
Accessories
WARNING: Since accessories, other than those offered by
DEWALT, have not been tested with this product, use of such
accessories with this tool could be hazardous. To reduce the risk of
injury, only DEWALT recommended accessories should be used with
this product.
Recommended accessories for use with your tool are available at
extra cost from your local service center. If you need any assistance
in locating any accessory, please contact DEWALT Industrial Tool Co.,
701 East Joppa Road, Baltimore, MD 21286, call 1-800-4-DEWALT
(1-800-433-9258) or visit our website: www.dewalt.com.
MAXIMUM RECOMMENDED CAPACITIES
DCD990 DCD995
WOOD
Auger 1-1/4" (32 mm) 1-1/4" (32 mm)
Paddle 1-1/2" (38 mm) 1-1/2" (38 mm)
Twist 1/2" (13 mm) 1/2" (13 mm)
Self-feed 2-9/16" (65 mm) 2-9/16" (65 mm)
Hole saw 4" (100 mm) 4" (100 mm)
METAL
Twist 1/2" (13 mm) 1/2" (13 mm)
Hole saw 1-3/8" (35 mm) 1-3/8" (35 mm)
MASONRY
Carbide – 1/2" (13 mm)
Repairs
The charger and battery pack are not serviceable. There are no
serviceable parts inside the charger or battery pack.
To assure product SAFETY and RELIABILITY, repairs, maintenance
and adjustments should be performed by a DEWALT factory service
center, a DEWALT authorized service center or other qualified service
personnel. Always use identical replacement parts.
Register Online
Thank you for your purchase. Register your product now for:
• WARRANTY SERVICE: Registering your product will help you
obtain more efficient warranty service in case there is a problem
with your product.
• CONFIRMATION OF OWNERSHIP: In case of an insurance loss,
such as fire, flood or theft, your registration of ownership will serve
as your proof of purchase.
• FOR YOUR SAFETY: Registering your product will allow us to
contact you in the unlikely event a safety notification is required
under the Federal Consumer Safety Act.
Register online at www.dewalt.com/register.
Three Year Limited Warranty
DEWALT will repair, without charge, any defects due to faulty materials
or workmanship for three years from the date of purchase. This warranty
does not cover part failure due to normal wear or tool abuse. For further
detail of warranty coverage and warranty repair information, visit www.
dewalt.com or call 1-800-4-DEWALT (1-800-433-9258). This warranty
does not apply to accessories or damage caused where repairs have
been made or attempted by others. This warranty gives you specific
legal rights and you may have other rights which vary in certain states
or provinces.

15
English
In addition to the warranty, DEWALT tools are covered by our:
1 YEAR FREE SERVICE
DEWALT will maintain the tool and replace worn parts caused by
normal use, for free, any time during the first year after purchase.
2 YEARS FREE SERVICE ON DEWALT BATTERY PACKS
DC9071, DC9091, DC9096, DC9280, DC9360, DC9180, DCB120,
DCB201 and DCB203
3 YEARS FREE SERVICE ON DEWALT BATTERY PACKS
DCB200, DCB204
DEWALT BATTERY PACKS
Product warranty voided if the battery pack is tampered with in any
way. DEWALT is not responsible for any injury caused by tampering and
may prosecute warranty fraud to the fullest extent permitted by law.
90 DAY MONEY BACK GUARANTEE
If you are not completely satisfied with the performance of your DEWALT
Power Tool, Laser, or Nailer for any reason, you can return it within 90
days from the date of purchase with a receipt for a full refund – no
questions asked.
LATIN AMERICA: This warranty does not apply to products sold in
Latin America. For products sold in Latin America, see country specific
warranty information contained in the packaging, call the local company
or see website for warranty information.
FREE WARNING LABEL REPLACEMENT: If your warning labels
become illegible or are missing, call 1-800-4-DEWALT (1-800-433-
9258) for a free replacement.

Français
16
Définitions: lignes directrices en
matière de sécurité
Lesdéfinitionsci-dessousdécriventleniveaudedangerpourchaque
mot-indicateur employé. Lire le mode d’emploi et porter une
attention particulière à ces symboles.
DANGER: indique une situation dangereuse imminente qui,
si elle n’est pas évitée, entraînera la mort ou des blessures
graves.
AVERTISSEMENT : indique une situation potentiellement
dangereuse qui, si elle n’est pas évitée, pourrait entraîner la
mort ou des blessures graves.
ATTENTION : indique une situation potentiellement
dangereuse qui, si elle n’est pas évitée, pourrait entraîner des
blessures légères ou modérées.
AVIS : indique une pratique ne posant aucun risque de
dommages corporels mais qui par contre, si rien n’est fait pour
l’éviter, pourrait poser des risques de dommages matériels.
POUR TOUTE QUESTION OU REMARQUE AU SUJET DE CET OUTIL
OU DE TOUT AUTRE OUTIL DEWALT, COMPOSEZ LE NUMÉRO
SANS FRAIS : 1-800-4-DEWALT (1-800-433-9258).
AVERTISSEMENT : afin de réduire le risque de blessures, lire le
mode d’emploi de l’outil.
Avertissements de sécurité généraux pour
les outils électriques
AVERTISSEMENT! lire tous les avertissements de
sécurité et toutes les directives. Le non-respect des
avertissements et des directives pourrait se solder par un
choc électrique, un incendie et/ou une blessure grave.
CONSERVER TOUS LES AVERTISSEMENTS
ET TOUTES LES DIRECTIVES POUR UN
USAGE ULTÉRIEUR
Le terme « outil électrique » cité dans les avertissements se rapporte
à votre outil électrique à alimentation sur secteur (avec fil) ou par piles
(sans fil).
1) SÉCURITÉ DU LIEU DE TRAVAIL
a) Tenir l’aire de travail propre et bien éclairée. Les lieux
encombrés ou sombres sont propices aux accidents.
b) Ne pas faire fonctionner d’outils électriques dans un
milieu déflagrant, tel qu’en présence de liquides, de
gaz ou de poussières inflammables. Les outils électriques
produisent des étincelles qui pourraient enflammer la poussière
ou les vapeurs.
c) Éloigner les enfants et les personnes à proximité pendant
l’utilisation d’un outil électrique. Une distraction pourrait en
faire perdre la maîtrise à l’utilisateur.
2) SÉCURITÉ EN MATIÈRE D’ÉLECTRICITÉ
a) Les fiches des outils électriques doivent correspondre
à la prise. Ne jamais modifier la fiche d’aucune façon.
Ne jamais utiliser de fiche d’adaptation avec un outil
électrique mis à la terre. Le risque de choc électrique sera
réduit par l’utilisation de fiches non modifiées correspondant à
la prise.
b) Éviter tout contact physique avec des surfaces mises à la
terre comme des tuyaux, des radiateurs, des cuisinières
et des réfrigérateurs. Le risque de choc électrique est plus
élevé si votre corps est mis à la terre.

Français
17
c) Empêcher les démarrages intempestifs. S’assurer que
l’interrupteur se trouve à la position d’arrêt avant de relier
l’outil à une source d’alimentation et/ou d’insérer un bloc-
piles, de ramasser ou de transporter l’outil. Transporter un
outil électrique alors que le doigt repose sur l’interrupteur ou
brancher un outil électrique dont l’interrupteur est à la position
de marche risque de provoquer un accident.
d) Retirer toute clé de réglage ou clé avant de démarrer
l’outil. Une clé ou une clé de réglage attachée à une partie
pivotante de l’outil électrique peut provoquer des blessures
corporelles.
e) Ne pas trop tendre les bras. Conserver son équilibre en
tout temps. Cela permet de mieux maîtriser l’outil électrique
dans les situations imprévues.
f) S’habiller de manière appropriée. Ne pas porter de
vêtements amples ni de bijoux. Garder les cheveux, les
vêtements et les gants à l’écart des pièces mobiles. Les
vêtements amples, les bijoux ou les cheveux longs risquent de
rester coincés dans les pièces mobiles.
g) Si des composants sont fournis pour le raccordement de
dispositifs de dépoussiérage et de ramassage, s’assurer
que ceux-ci sont bien raccordés et utilisés. L’utilisation
d’un dispositif de dépoussiérage peut réduire les dangers
engendrés par les poussières.
4) UTILISATION ET ENTRETIEN D’UN OUTIL ÉLECTRIQUE
a) Ne pas forcer un outil électrique. Utiliser l’outil électrique
approprié à l’application. L’outil électrique approprié
effectuera un meilleur travail, de façon plus sûre et à la vitesse
pour laquelle il a été conçu.
b) Ne pas utiliser un outil électrique dont l’interrupteur
est défectueux. Tout outil électrique dont l’interrupteur est
défectueux est dangereux et doit être réparé.
c) Ne pas exposer les outils électriques à la pluie ou à
l’humidité. La pénétration de l’eau dans un outil électrique
augmente le risque de choc électrique.
d) Ne pas utiliser le cordon de façon abusive. Ne jamais
utiliser le cordon pour transporter, tirer ou débrancher un
outil électrique. Tenir le cordon éloigné de la chaleur, de
l’huile, des bords tranchants et des pièces mobiles. Les
cordons endommagés ou enchevêtrés augmentent les risques
de choc électrique.
e) Pour l’utilisation d’un outil électrique à l’extérieur, se servir
d’une rallonge convenant à cette application. L’utilisation
d’une rallonge conçue pour l’extérieur réduira les risques de
choc électrique.
f) S’il est impossible d’éviter l’utilisation d’un outil électrique
dans un endroit humide, brancher l’outil dans une prise
ou sur un circuit d’alimentation dotés d’un disjoncteur de
fuite à la terre (GFCI). L’utilisation de ce type de disjoncteur
réduit les risques de choc électrique.
3) SÉCURITÉ PERSONNELLE
a) Être vigilant, surveiller le travail effectué et faire preuve
de jugement lorsqu’un outil électrique est utilisé. Ne
pas utiliser d’outil électrique en cas de fatigue ou sous
l’influence de drogues, d’alcool ou de médicaments. Un
simple moment d’inattention en utilisant un outil électrique peut
entraîner des blessures corporelles graves.
b) Utiliser des équipements de protection individuelle.
Toujours porter une protection oculaire. L’utilisation
d’équipements de protection comme un masque antipoussière,
des chaussures antidérapantes, un casque de sécurité ou des
protecteurs auditifs lorsque la situation le requiert réduira les
risques de blessures corporelles.

Français
18
c) Lorsque le bloc-piles n’est pas utilisé, le tenir éloigné
des objets métalliques, notamment des trombones, de
la monnaie, des clés, des clous, des vis ou autres petits
objets métalliques qui peuvent établir une connexion
entre les deux bornes. Le court-circuit des bornes du bloc-
piles risque de provoquer des brûlures ou un incendie.
d) En cas d’utilisation abusive, le liquide peut gicler hors
du bloc-piles; éviter tout contact avec ce liquide. Si un
contact accidentel se produit, laver à grande eau. Si le
liquide entre en contact avec les yeux, obtenir également
des soins médicaux. Le liquide qui gicle hors du bloc-piles
peut provoquer des irritations ou des brûlures.
6) RÉPARATION
a) Faire réparer l’outil électrique par un réparateur
professionnel en n’utilisant que des pièces de rechange
identiques. Cela permettra de maintenir une utilisation
sécuritaire de l’outil électrique.
Avertissements de sécurité relatifs au
marteau perforateur/perceuse/visseuse
• Porter une protection auditive lors du perçage à percussion.
Une exposition au bruit peut entraîner une perte auditive.
• Utiliser la/les poignée(s) auxiliaire(s) si fournie(s) avec l’outil.
Une perte de contrôle de l’outil pourrait occasionner des dommages
corporels.
•Tenir l’outil par les surfaces isolées prévues à cet effet
pendant toute utilisation où l’organe de coupe pourrait
entrer en contact avec des fils électriques cachés. Tout
contact de l’organe de coupe avec un fil sous tension mettra les
parties métalliques exposées de l’outil sous tension et électrocutera
l’utilisateur.
• Utiliser des brides de fixation ou tout autre dispositif de
fixation pratique permettant de soutenir et de retenir la
c) Débrancher la fiche de la source d’alimentation et/ou du
bloc-piles de l’outil électrique avant de faire tout réglage
ou changement d’accessoire ou avant de ranger l’outil.
Ces mesures préventives réduisent les risques de démarrage
accidentel de l’outil électrique.
d) Ranger les outils électriques hors de la portée des enfants
et ne permettre à aucune personne n’étant pas familière
avec un outil électrique ou son mode d’emploi d’utiliser
cet outil. Les outils électriques deviennent dangereux entre les
mains d’utilisateurs inexpérimentés.
e) Entretien des outils électriques. Vérifier si les pièces
mobiles sont mal alignées ou coincées, si des pièces sont
brisées ou présentent toute autre condition susceptible
de nuire au bon fonctionnement de l’outil électrique. En
cas de dommage, faire réparer l’outil électrique avant
toute nouvelle utilisation. Beaucoup d’accidents sont
causés par des outils électriques mal entretenus.
f) S’assurer que les outils de coupe sont aiguisés et propres.
Les outils de coupe bien entretenus et affûtés sont moins
susceptibles de se coincer et sont plus faciles à maîtriser.
g) Utiliser l’outil électrique, les accessoires, les forets,
etc. conformément aux présentes directives en tenant
compte des conditions de travail et du travail à effectuer.
L’utilisation d’un outil électrique pour toute opération autre que
celle pour laquelle il a été conçu est dangereuse.
5) UTILISATION ET ENTRETIEN DU BLOC-PILES
a) Ne recharger l’outil qu’au moyen du chargeur précisé par
le fabricant. L’utilisation d’un chargeur qui convient à un type
de bloc-piles risque de provoquer un incendie s’il est utilisé
avec un autre type de b loc-piles.
b) Utiliser les outils électriques uniquement avec les blocs-
piles conçus à cet effet. L’utilisation de tout autre bloc-piles
risque de causer des blessures ou un incendie.
