DeWalt DCN890 Configuration guide

H
H
H
H
DCN890 Disassembling Procedure
and General Information

H
H
H
H
Battery Indicator
BATTERY INDICATOR
Low Battery
Replace battery with charged back
Hot Pack
Let the battery cool or replace it
with a cool pack
Jam/Stall Condition
Rotate the stall release lever to
release Refer to stall release
Hot Tool
Let the tool cool down before
continuing use
Error
Reset the tool by removing and
reinstalling battery pack, or
cycling trigger lock off.
If error code persist, take the tool
to an authorized DEWALT
service center

H
H
H
H
CONTACT TRIPS REMOVAL & REPLACEMENT
1
2
Magnetic Contact Trip
DCN8902
DEWALT DCN8903-XJ NON-
MAGNETIC CONTACT

H
H
H
H
REPLACEMENT
DRIVER
DCN8901-XJ
ACCESSORIES

H
H
H
H
ENGINEERING –DRIVER SYSTEM
VIEW FROM TOP
VIEW FROM UNDERSIDE
CONTACT TIP BUMPER INTERFACE
FRICTION SURFACE
FRICTION SURFACE
RETURN RACK

H
H
H
H
Return System –Multi Stroke Solenoid Ratchet
Operation
•Return in < 0.3 s
•4 Strokes
•Basic Engineering
Analysis / Testing
•Dynamic simulations
•Rig test at 55K… running
•Extreme temp, low voltage
•End-user validation on framer
ENGINEERING –RETURN SYSTEM
Solenoid/Plunger
Return Paw
Profile / Rack

H
H
ENGLISH GERMAN ITALIAN FRENCH SPANISH PORTUGUESE DUTCH
CHECK ÜBERPRÜFEN CONTROLLARE CONTROLER COMPROBAR VERIFIQUE CONTROLEREN
ATTENTION ! ACHTUNG ! ATTENZIONE ! ATTENTION ! ATENCION ! ATENÇÃO! ATTENTIE !
TURN COUNTER
CLOCKWISE DREHEN GEGEN UHRZEIGERSINN GIRARE IN SENSO ANTIORARIO
TOURNEZ DANS LE
SENS INVERSE DES
AIGUILLES D’UNE
MONTRE
GIRO IZQUIERDA GIRAR SENTIDO ANTI- HORARIO DRAAI LINKSOM
TURN
CLOCKWISE DREHEN IN UHRZEIGERSINN GIRARE IN SENSO ORARIO
TOURNEZ DANS LE
SENS DES AIGUILLES
D’UNE MONTRE GIRO DERECHA GIRAR NO SENTIDO
HORARIO DRAAI RECHTSOM
MOVE IN THIS
DIRECTION IN RICHTUNG BEWEGEN MUOVI IN DIREZIONE BOUGEZ DANS CETTE DIRECTION DIRECION DE LA FLECHA AVANÇAR NESSA DIREÇAO BEWEEG IN DE RICHTING VAN DE PIJL
CORRECT RICHTIG CORRETTO CORRECT CORRECTO CORRECTO GOED
NOT CORRECT NICHT RICHTIG NON CORRETTO INCORRECT NO ES CORRECTO NÃO É CORRECTO FOUT
LIFT OVER ANHEBEN SOLLEVARE SOULEVEZ LEVANTAR LEVANTAR SOBRE A OPHEFFEN

H
H
ENGLISH GERMAN ITALIAN FRENCH SPANISH PORTUGUESE DUTCH
PUSH DRÜCKEN PREMERE APPUYEZ APRETAR EMPURRAR DUWEN
DISCONNECT TRENNEN SCOLLEGARE DEBRANCHEZ DESCONECTADO DESLIGAR ONTKOPPELEN
ATTENTION!
REMOVE NAILS ACHTUNG NÄGEL ENTNEHMEN ATTENZIONE RIMUOVERE I CHIODI
ATTENTION !
RETIREZ LES
PROJECTILES
ATENCION!
QUITAR LOS CLAVOS ATENÇÃO! RETIRAR OS PREGOS
OPGELET !
VERWIJDER DE
NAGELS
CHECK THE
CORRECT NAILS
HAVE BEEN USED
ÜBERPRÜFEN DASS
DIE NÄGEL KORREKT
SIND
CONTROLLARE CHE I
CHIODI SONO
CORRETTI
VERIFIEZ QUE LES
CLOUS UTILISES
SOIENT CORRECTS
VER SI LOS CLAVOS
USADOS SON LOS
CORRECTOS
VERIFIQUE SE
FORAM UTILIZADOS
OS PREGOS
CORRECTOS
CONTROLEER DAT
DE JUISTE NAGELS
GEBRUIKT WORDEN
CHECK THE
CHARGE OF THE
BATTERY
LADEGERÄT
ÜBERPRÜFEN
CONTROLLARE CHE
LA BATTERIA SIA
CARICA
VERIFIEZ LA CHARGE
DE LA BATTERIE
COMPRUEBE LA
CARGA DE LA
BATERIA
VERIFIQUE A CARGA
DA BATERIA CONTROLEER DE BATTERIJ

H
H
ENGLISH GERMAN ITALIAN FRENCH SPANISH PORTUGUESE DUTCH
LUBRICATION BEFETTEN LUBRIFICAZIONE LUBRIFICATION ENGRASE LUBRIFICAÇÃO SMERING
HEX KEY SIZE GRÖSSE INNENSECHSKANT-
SCHLÜSSEL
DIMENSIONE VITE
ESAGONALE TAILLE SIX PAN TAMAÑO LLAVE EXAGONAL
TAMANHO CHAVE
HEX AFMETING VAN DE
INBUSSLEUTEL
SCREW THREAD
SIZE AND LENGTH
SCHRAUBENKOPF
GRÖSSE UND
SCHRAUBENLÄNGE
CARATTERISTICHE
DELLA VITE
FILETAGE DE LA VIS,
DIAMETRE ET
LONGUEUR
ROSCA DEL
TORNILLO TAMAÑO,
LONGITUD
TAMANHO DE ROSCA
E COMPRIMENTO DO
PARAFUSO SCHROEFTYPE EN
AFMETINGEN
SPANNER SCHRAUBEN-
SCHLÜSSEL CHIAVE CLEF LLAVE FIJA CHAVE DE
BOCAS MOERSLEUTEL
QUESTION ? FRAGE? DOMANDE ? QUESTION ? ¿PREGUNTA? PERGUNTA? VRAGEN?
GO TO WEB SITE
FOR MORE
INFORMATION
GEHE ZUR WEB SEITE
FÜR WEITERE
INFORMATIONEN
VISITARE IL SITO PER
MAGGIORI
INFORMAZIONI
ALLEZ SUR NOTRE
SITE POUR PLUS
D’INFORMATION
VISITA LA PAGINA
WEB PARA MAS
IMFORMACION
PARA MAIS
INFORMAÇÕES
VISITE PAGINA WEB
GA NAAR ONZE
WEBSITE VOOR
MEER INFORMATIE
M5X20
…mm
WWW.2HELPU.
COM
….mm

H
H
ENGLISH GERMAN ITALIAN FRENCH SPANISH PORTUGUESE DUTCH
ACTIVATE SCHIESSEN SPARARE ACTIVEZ ACTIVAR ACTIVAR SCHIETEN
CLEANING
MACHINE WASCH MASCHINE LAVAPEZZI BAC DE LAVAGE MAQUINA DE LIMPIEZA MÁQUINA DE LIMPEZA WASMACHINE
FUNCTION TEST
FUNKTIONSTEST
DURCHFÜHREN ESEGUIRE IL TEST TEST FONCTIONNEL PRUEVA DE FUNCIONAMIENTO TESTE DE FUNCIONAMENTO FUNCTIETEST
NUMBER OF
NAILS FIRED
ANZAHL DER
VERSCHOSSENE
N NÄGEL CHIODI SPARATI NOMBRE
DE CLOUS
TIRES
NUMERO DE CLAVOS
DISPARADOS
NÚMERO DE PREGOS
DISPARADOS
AANTAL AFGEVUURDE
NAGELS
CLEAN THE TOOL
GERÄT REINIGEN
PULIRE L’UTENSILE NETTOYEZ L’OUTIL LIMPIEZA DE
HERRAMIENTAS
LIMPE A FERRAMENTA
REINIG HET
TOESTEL
SEND THE TOOL
TO THE
CUSTOMER
GERÄT ZUM
KUNDEN SENDEN
SPEDIRE L’UTENSILE
AL CLIENTE EXPEDIEZ
L’OUTIL AU
CLIENT
ENVIAR LA
HERRAMIENTA AL
CLIENTE
ENVIAR A
FERRAMENTA AO
CLIENTE
VERZEND HET
TOESTEL NAAR DE
KLANT

H
H
H
H
The CCN does have the
blinking LED’s to signal 1k
shots. Hold the trigger for
10 -15 seconds before the
blinking will start.
Before dismantling

H
H
H
H
Before dismantling

H
H
H
H
Before dismantling

H
H
H
H
2017 33-59
Before dismantling

H
H
H
H
Magazine Removal

H
H
H
H
TAB ENGAGES INTO
CONTACT TRIP AND STOPS
MOVEMENT
ENGINEERING –DRY FIRE LOCK OUT
TAB IS EXPOSED WHEN NO
NAILS ARE IN MAGAZINE

H
H
H
H
Profile Removal
4.5x19 Tx20

H
H
H
H
Profile Removal

H
H
H
H
Profile Removal
1.Klick

H
H
H
H
Profile Removal
