Dexion Richards-Wilcox Aurora User manual

Aurora Shelving Products 6”
Drawer Installation Instructions
Figure 1
Figure 2
Figure 3
Figure 5
Back of Slide
Lances Slide Bracket
Rivet
Bracket
Part No. 3524 Rev. A
®
NOTE: Shelving unit must be anchored to the
floor through the Quik-Bases in front and back
and must be anchored to a wall or other shelv-
ing unit in back.
1. Starting from the bottom, install shelf supports
in the front and back (4) keyhole slots (6”) up
from the Quik-Base. Secure the back shelf
support to the posts using a Tek screw
through the holes in the ears of the shelf
support (see figure 1).
2. Install slides in slide brackets by slipping
lances in slides into the slots in the slide brack-
ets. (LH slide in LH bracket, RH slide in RH
bracket (see figure 2).
3. Drop the ears of the slide brackets into the top
of the channel of the shelf supports and se-
cure using #10-32 x 1/2screws and #10 nuts.
(see figures 3). If this is your second drawer or
more, install the wire interlock rod between the
slides on each side (see figure 5).

Figure 7
Figure 6
Drawer Side
Hanger Bar
600 South Lake Street, Aurora, IL 60506 Toll Free: 1-800-277-1699 Fax: [phone]
www.richardswilcox.com
®
Part No. 3524 Rev. A
4. Remove the screw(s) joining the drawer
front to the drawer front liner, then place
the drawer body on the drawer front
and liner and secure with #10 x 3/8sheet
metal screws (see figure 6).
5. Fully extend slides, then drop the
drawer onto the slides. Fit the lances of
the drawer slide into the embossed
pockets in the slide (see figure 7).
6. The drawer fronts may need to be
adjusted to line up evenly.
