Digital Equipment Pro-Face PL-6700 43 Series User manual

PL-6700 43Series
Panel Computer
User's Manual
Digital Electronics Corporation

Preface
PL-6700 43 Series User’s Manual i
Digital’s PL-6700 series of Panel Computers are multipurpose factory
automation (FA) computers, which embody Digital’s latest, cost-effective
architecture.
Before using Digital’s PL-6700 Series of Panel Computers, which includes
the PL-6700T and which is hereafter referred to as the “ PL ”, be sure to
read this manual thoroughly to familiarize yourself with the PL’s operation
procedures and functions. Be sure to keep this manual handy for future
reference.
NOTE:
1. It is forbidden to copy the contents of this manual in whole, or in part, without the
permission of the Digital Electronics Corporation.
2. The information in this manual is subject to change without notice.
3. This manual was written with care; however, if you should find any error or
omissions, please contact Digital Electronics and inform them of your findings.
4. Please be aware that we are not responsible for any damages resulting from the
use of our products, regardless of article 3 above.
5. Specifications set out in this manual are for overseas products only, and, as a
result, some differences may exist between the specifications given here and the
Japanese ones.
All Company / Manufacture names used in this manual are the registered
trademarks of their respective companies.
© Copyright June 1998, Digital Electronics Corporation
Introduction
Introduction

Preface
PL-6700 43 Series User’s Manualii
This manual contains a variety of safety markings to help you safely and
correctly operate Digital’s PL-6700 series of Panel Computers.
Safety Icons
This manual uses the two icons below to call attention to information impor-
tant for the safe and correct use of the PL. Please pay attention to these
icons and follow all instructions given by them.
The safety icons and their meanings are:
Indicates a potentially hazardous situation which could result
in serious injury or even death, if the instructions are not
followed.
Indicates a potentially hazardous situation which could result
in minor injury or equipment damage if the instructions are
not followed.
Safe Product Usage
Safe Product Usage

Preface
PL-6700 43 Series User’s Manual iii
Essential Safety Precautions
BesuretofollowtheinstructionsgivenbelowtoensurethesafeuseofthePL.
To avoid a possiblity of electrical shock, be sure to connect the power cord
to the PL before connecting it to the main power supply.
A fire or electrical shock may result if voltages are used with the PL that are
beyondthespecifiedrange.Besuretoonlyuse the specified voltage.
Before opening the PL’s protective cover, be sure to turn the unit’s power
OFF. This is because the PL’s internal parts carry high voltages.
To avoid fires or electrical hazards, do not modify the product in any way.
Do not create touch panel switches that are used to either control or to
ensure the safety of equipment and personnel. Mechanical switches,
such as an emergency stop switch, a deadman (two-handed) start
switch, etc., must be installed and operated via a separate control
system.
If metal particles, water or other types of liquids contact any of the PL’s
internal parts, immediately turn the unit’s power OFF, unplug the power
cord, and contact either your dealer or Digital Electronics Corporation.
Read and understand Chapter 4 “Installation and Wiring” thoroughly in
order to select an appropriate installation location for the PL.
Before either plugging in or unplugging a board or interface connector,
be sure to turn the PL’s power OFF.
To prevent a possible explosion, do not install the PL in areas contain-
ing flammable gases.
The PL is not appropriate for use with aircraft control devices, aero-
space equipment, central trunk data transmission (communication)
devices, nuclear power control devices, or medical life support equip-
ment, due to these devices’ inherent requirements of extremely high
levels of safety and reliability.
When using the PL with transportation vehicles (trains, cars and ships),
disaster and crime prevention devices, various types of safety equip-
ment, non-life support related medical devices, etc. redundant and/or
failsafe system designs should be used to ensure the proper degree of
reliability and safety.
Do not push on the PL’s screen too strongly, with either your finger or
Essential Safety Precautions

Preface
PL-6700 43 Series User’s Manualiv
General Safety Precautions
General Safety Precautions
Follow the instructions given below for correct and safe use of the
PL.
Do not push on the PL’s screen too strongly, with either your finger or with a
hard object. Excessive pressure can scratch, crack or damage the screen.
Ifthescreenbecomesdirtyorsmudged,moistenasoftclothwithdilutedneutral
detergent, wring the cloth well, and wipe the display. Do not use thinner or
organicsolvents.
Do not use a pointed object, such as a mechanical pencil or screwdriver, to
pressany of the touch panel’s switches, since they can damage the display.
Avoid exposing and operating the PL in direct sunlight, high temperatures and
humidity,andinareaswhereexcessivedustandvibrationwilloccur.
Avoidusing thePL inareas wheresudden, extremechanges intemperature can
occur. Thismay cause condensation toforminside the unit,possiblyleading to
anaccident.
TopreventthePLfromoverheating,besureitsaircirculationventsareclearand
clean,andkeeptheunit’soperationarea well-ventilated.
AvoidoperatingorstoringthePLnearchemicals,orwherechemicalscancome
intocontactwiththeunit.
SincethePL-6700’sharddiskdrive(HDD)isaconsumableitem,i.e.ithasadefiniteusage
lifetime,besuretobackupitsdatafrequentlyandperformregularmaintenance.
Topreventfiledamage,besuretoshutdownyourPL’sOSbeforeturningthePLOFF.
Notes on Handling the LCD
ThePL'sLCDcontainsastrongirritant. If thepanelis evercrackedand theLCD's
liquidcontactsyourskin,besuretowashitwithrunningwaterforatleast15minutes.
Ifanyofthisliquidshouldenteryoureye,besuretoflushyoureyewithrunningwater
formorethan15minutes,andseeadoctorimmediately.
The current brightness of the LCD screen will depend on the screen's current
displayandtheLCD'scontrastadjustment.Anybrightnessvariationsthatresult
arenormal forLCD displays.
There are minute grid-points (Dark or light points) on the LCD surface. These
points are not defects and are a part of the PL panel’s design.
Occasionallycrosstalk(shadowsappearingonextendeddisplaylines)willappearonthe
display. ThisphenomenonisacommonattributeofLCDsandisnotadefect.
The displayed color will look different when viewed from an angle outside the
specifiedviewangle.Thisisalsonormal.

Preface
PL-6700 43 Series User’s Manual v
• The Digital Electronics Corporation cannot be held respon-
sible or provide any compensation for damage(s) caused by
the loss of data stored in the PL-6700’s hard disk drive
(HDD). It is therefore strongly suggested that all important
data and software be backed up regularly to an external data
backup device.
• Please be aware that the Digital Electronics Corporation
bears no responsibility for any damages resulting from the
customer’s application of this unit’s hardware or software.
• Please be aware that the Digital Electronics Corporation will
not provide compensation for any damages occurring as a
result of problems with this unit’s software or hardware.
!!
!!
!
Important
General Safety Precautions
Displaying a single screen image for long periods of time can cause an
afterimage to remain on the screen. To correct this, turn the unit OFF
for 5 to 10 minutes, then ON again. This phenomenon is a common
attribute of the LCDs, and is not a defect. To prevent this effect, you
can:
- use the Display OFF feature; if the same image is to be displayed for a
long period of time.
- change the screen display periodically to prevent the displaying of a
single image for a long period of time.
For further information about the PL’s LCD panel, please contact your local
PL distributor.

Preface
PL-6700 43 Series User’s Manualvi
The PL6700-T4* are (c)UL 1950 recognized products. (UL File No. E177793).
Please pay special attention to the following instructions when applying for
UL approval for machinery which includes one of these PL units built in.
Machinery with a PL mounted in it requires UL inspection for the combina-
tion of the PL and the machinery.
• PL conforms as a component to the following standards:
UL 1950, Third Edition, dated July 26, 1995 (Standard for Safety of
Information Technology Equipment, including Electrical Business
Equipment)
CSA-C22.2 No. 950-M93 (Standard for Safety of Information Tech-
nology Equipment, including Electrical Business Equipment)
PL6700-T4* (UL Registration Model No.: 0880044-1)
• If the PL is installed so as to cool itself naturally, be sure to install the
PL in a vertical position. Also, be sure that the PL is installed so that it
is at least 50mm away from any adjacent structures or devices. If these
requirements are not met, the heat generated by the PL’s internal
components may cause the unit to fail to meet UL standard require-
ments.
Notes on UL Application / Notes on CE Marking
Notes on CE Marking
Notes on UL Application
The PL6700-T4* are CE marked, EMC compliant products.
<Complies with the following EC Directives>
89/336/EEC, 92/31/EEC, 93/68/EEC, 73/23/EEC
<Complieswith the following Standards>
• Safety
IEC950 (A3:1995), EN60950 (A3:1995)
• EMI (EN50081-2)
EN55022 (Class A) (1994), EN61000-3-2 (1995), EN61000-3-3 (1995)
• EMS (EN50082-2)
EN61000-4-2 (1995), EN61000-4-4 (1995), EN61000-4-5 (1995),
EN61000-4-8 (1993), EN61000-4-11 (1994), ENV50140 (1993),
ENV50141 (1993), ENV50204 (1995)

Preface
PL-6700 43 Series User’s Manual vii
Thisunit'sprotectionratingofIP65fisactuallyacompositecode,consistingofthe
internationally recognized British "Ingress Protection" standard (BS EN
60529:1992) - "IP65", and the standard developed by the Japanese Electronics
Manufacturer'sAssociation(JEM) -"f".This codeisusedinthis manualtoiden-
tifyagivenproduct'sdegreeofstructuralresistancetoavarietyofenvironmental
elementsandthus,preventproblemsoraccidentsrelatedtothe inappropriateuse
of a product.
The individual meaning of each character of this code is explained below. This
codeindicatesthedegreeofingressprotectionprovidedfromthefrontfaceofthe
PL,andassumes that the PL is securely mounted into a metal panel.
IP 6 5 f
(1) (2) (3) (4)
(1) Designates the type of protection provided.
(2) Indicates the degree of protection provided to the human body by the unit,
andthe degree of protection provided by the unit's frontfacefrom particles/dust
intrusionintotheinterioroftheunit.
Here, "6" indicates that the unit is completely protected from dust intrusion.
(3) Indicates the degree of protection provided by the unit's front face from
waterintrusionintotheinterioroftheunit.
Here, "5" indicates that the unit is protected from water intrusion from a
direct water jet.
(4) Indicates the degree of protection provided by the unit's front face from oil
particleintrusionintotheinterioroftheunit.
Here, "f" indicates that the unit is completely protected from oil intrusion
via either oil particles or oil splashes from any direction (to the front panel).
For information about the PL's protective structure, refer to page 2-3.
What is IP65f?
Note:
What if IP65f?

Preface
PL-6700 43 Series User’s Manualviii
Introduction ...................................................................................................................... i
Safe Product Usage........................................................................................................ ii
Essential Safety Precautions ......................................................................................iii
General Safety Precautions ........................................................................................ iv
Notes on UL Application ............................................................................................. vi
What is IP65f?...............................................................................................................vii
Table of Contents....................................................................................................... viii
Prior To Using the PL................................................................................................... xi
New PL-6700 Features................................................................................................xii
PL Package Contents ................................................................................................ xiii
Symbol Information ....................................................................................................xiv
Chapter 1 Overview
1-1 System Configuration...................................................................................... 1- 1
1-2 Options ............................................................................................................... 1- 2
1-3 PL Series Code Name Explanation.............................................................. 1- 3
Chapter 2 Specifications
2-1 General Specifications.................................................................................... 2- 1
2-1-1. Electrical Specifications ............................................................................................ 2- 1
2-1-2. Environment Specifications.......................................................................................2- 1
2-1-3. Dimensions................................................................................................................2- 2
2-2 Performance Specifications............................................................................ 2- 2
2-2-1. Performance Specifications ......................................................................................2- 2
2-2-2. Display Functions...................................................................................................... 2- 3
2-2-3. Expansion Slots ......................................................................................................... 2- 3
2-3 Interface Specifications.................................................................................. 2- 4
2-3-1. Printer Interface (LPT1) .........................................................................................2- 4
2-3-2. Keyboard Interface ..................................................................................................2- 4
2-3-3. Mouse Interface .......................................................................................................2- 5
2-3-4. RS-232C Interface (COM1/COM2/COM3) ............................................................2- 5
2-3-5. CRT Interface (Video)..............................................................................................2- 5
2-4 PL External Features...................................................................................... 2- 6
Table of Contents
Preface

Preface
PL-6700 43 Series User’s Manual ix
Table of Contents
2-5 PL Dimensions.................................................................................................. 2- 8
2-5-1. PL-6700T General Dimensions ................................................................................2- 8
2-5-2. Full Sized Cover Attachment Dimensions .............................................................. 2- 10
2-5-3. Installation Slot Dimensions ................................................................................... 2- 11
Chapter 3 Installing Optional Units and Expansion Boards
3-1 Available Options and Expansion Boards................................................... 3- 1
3-2 Installing Options and Expansion Boards................................................... 3- 3
3-2-1. Attaching the PL’s Support.......................................................................................3- 3
3-2-2. Installing the DIM Module (PL-EM200)..................................................................3- 4
3-2-3. Removing or Installing the FDD Unit (PL-FD100) ..................................................3- 6
3-2-4. Removing or Installing the HDD Unit (PL-HD100) ................................................3- 7
3-2-5. Installing an Expansion Board...................................................................................3- 9
3-2-6. Installing the IDE Slave Adaptor (PL-SA100)....................................................... 3- 11
Chapter 4 Installation and Wiring
4-1 Installation Cautions ....................................................................................... 4- 1
4-2 Installing the PL............................................................................................... 4- 3
4-2-1. Installation Procedures.............................................................................................. 4- 3
4-3 Wiring the PL.................................................................................................... 4- 6
4-3-1. Connecting the Power Cord .....................................................................................4- 6
4-3-2. Power Supply Cautions.............................................................................................4- 8
4-3-3. Grounding Cautions...................................................................................................4- 9
4-3-4. Cautions When Connecting I/O Signal Lines ......................................................... 4- 10
Chapter 5 System Setup
5-1 Setup Procedures ............................................................................................. 5- 1
5-2 System Parameters.......................................................................................... 5- 2
5-2-1. STANDARD CMOS SETUP..................................................................................5- 2
5-2-2. BIOS FEATURES SETUP ......................................................................................5- 4
5-2-3. CHIPSET FEATURES SETUP...............................................................................5- 6
5-2-4. POWER MANAGEMENT SETUP........................................................................5- 7
5-2-5. PNP/PCI CONFIGURATION SETUP...................................................................5- 9
5-2-6. INTEGRATED PERIPHERALS SETUP............................................................. 5- 11
5-2-7. IDE HDD AUTO DETECTION SETUP............................................................. 5- 13
5-2-8. HDD LOW LEVEL FORMAT SETUP................................................................ 5- 14

Preface
PL-6700 43 Series User’s Manualx
Table of Contents
Chapter 6 Bundled Software
6-1 PL-6700 Floppy Disk File List ...................................................................... 6- 1
Chapter 7 Maintenance and Inspection
7-1 Cleaning the Display....................................................................................... 7- 1
7-2 Filter Cleaning .................................................................................................. 7- 2
7-3 Periodic Maintenance Check Points............................................................ 7- 3
Appendix
1 HardwareConfiguration ............................................................................. App-1
1. I/O Mapping .......................................................................................................... App-1
2. Memory Mapping ................................................................................................. App-3
3. IRQ Mapping ........................................................................................................ App-4
2 SerialCommunication ................................................................................. App-5
3 Printer Cable Connections ......................................................................... App-6
4 BIOS Lists..................................................................................................... App-7
INDEX

Preface
PL-6700 43 Series User’s Manual xi
Prior to actual use, be sure to setup your PL as follows.
Install the OS
Reference
Reference
Reference
Turn PL ON
Setup System Chapter 5 System Setup
4-3 Wiring the PL
After completing the hardware setup, before
any data or applications can be placed on the
drive, the OS (Windows or MS DOS, etc.)
must be used to initialize the HDD and create
partitions. For details concerning these pro-
cedures, refer to the OS maker’s installation
manual.
OS maker’s Installation Manual.
• For system setup and OS installation, a PS/2 type keyboard is
necessary.
• When using Windows®NT4.0, be sure to install the PL-6700
Driver & Utility Disk’s Display Driver (For installation proce-
dures, see the disk’s README files).
• For information on the PL-6700’s bundled utility software, see
the README files on the Driver & Utility Disk.
• Since the PL-6700’s hard disk drive (HDD) is a consumable
item, i.e. it has a definite usage lifetime, be sure to back up its
data frequently and perform regular maintenance.
!!
!!
!
Important
Prior To Using the PL
Prior To Using the PL

Preface
PL-6700 43 Series User’s Manualxii
The PL-6700 series displays are equipped with the following features:
The Latest, High-Performance Architecture
Designed around the MMX Pentium®200(MHz) CPU, the PL utilizes the
type of high performance architecture that offers you superior compatibility.
Add to this unrivalled support of the Windows®95 / NT®and other operating
systems.
Bright 12.1" LCD with a Wide Viewing Angle
The PL’s large 12.1-inch 800 x 600 dot LCD display is available with TFT
color, offering excellent visibility and brightness.
• Digital’s top of the line TFT color LCD model allows you to create detailed
and powerful visual images, with excellent brightness, a wide viewing
angle, and a display capable of 260,000 colors.
Easy Front Panel Installation
The PL is designed to be installed easily into the front of any panel or
device. It is also rugged enough for use in harsh, industrial environments,
such as those found in the factory automation industries and boasts an IP65f
rating.
High Resolution, Analog-Resistance-Film Touch Panel
Standard equipment with the PL is a high resolution 1024 × 1024 touch
panel. Also, the WindowsNT®4.0 / Windows®95 mouse emulation utilities
provide mouse-like functionality and pointer control.
Highly Expandable
For the easy enhancement of your PL unit, 4 ISA-bus expansion slots are
provided. (2 PCI slots are also available) These slots can accommodate both
Digital’s own optional boards as well as other commercially available
expansion boards.
Digital also offers a wide variety of optional products, such as an -5/-12V
DC power unit, DIM memory modules, etc. to name just a few.
Note:
New PL-6700 Features
New PL-6700 Features

Preface
PL-6700 43 Series User’s Manual xiii
The PL package should include the following items:
• Be careful when in-
stalling the PL -6700 to
not damage the built-
in HDD
Installation Brackets (8)
PL- 6700
Floppy Disks (2)
Power Cord
PL-6700 Unit
(PL-6700T)
• This cord is designed only for
100V use. Any other voltage
will require a different cable.
PL-6700
43 Series
User’s
Manual
(English)
Angle Plate (1)
Panel Computer PL-6700
43 Series User’s Manual
(Japanese)
PL-6700
43 Series
User’s
Manual
(Japanese)
PL Package Contents
!!
!!
!
Important !!
!!
!
Important
Panel Computer PL-6700
43 Series User’s Manual
(English)
PL Package Contents

Preface
PL-6700 43 Series User’s Manualxiv
Symbol Information
The list below describes the symbols used in this manual.
Symbol Information
Symbol Description
Incorrect operation resulting from negligence of this
instruction may cause death or serous injury.
Incorrect operation resulting from negligence of this
instruction may cause injury or damage to equipment.
Failure to observe this instruction may cause abnormal
operation of equipment or data loss.
Provides hints on correct use, or supplementary
information.
*
**
*Indicates useful or important supplemental information.
Indicates related (manual name, page number) information.
1) 2)
1) 2)1) 2)
1) 2) Indicates steps in a procedure. Be sure to perform these
steps in the order given.
!!
!!
!
Important
Note:
Reference
Caution
!!
!!
!
!!
!!
!
Warning

PL-6700 43 Series User’s Manual 1-1
Peripheral
Devices
HDD(2.5”)
CRT
Inverter Unit
Backlight Lamp (CFL type)
Display Unit (COLOR TFT)
Analog Resistance Film Touch Panel
AC IN 85 to 132V
170 to 265V
ISA Slots (4) (2 PCI slots are also available)
DIMM sockets (2)
Power Supply Unit
DC 5V/12V
Commercial
items
Optional Unit(s)
Mouse
Keyboard
Printer
CD-ROM
drive
Power Supply Unit
DC -5V/ -12V
Main Circuit Board
Front Mount
FD Unit
Reset Switch
Front Keyboard
Connector
IrDA I/F Unit
Inside Front
Maintenance Cover
32MB RAM Memory
(standard)
•Boxes marked with a border represent optional items.
•Boxes marked with a border represent User supplied items.
•The figure above shows simply the internal data flow and the
PL’s peripheral connections, and may differ from the actual
layout used by the customer.
Chapter 1Chapter 1
Chapter 1Chapter 1
Chapter 1
OverviewOverview
OverviewOverview
Overview
1. System Configuration
2. Options
3. PL Series Panel Types
The following figure shows the peripheral devices that can be connected to
the PL.
1-1 System Configuration
!!
!!
!
Important
Slave
Adapter
RS232C×3

Chapter 1 - Overview
PL-6700 43 Series User’s Manual1-2
Thefollowing tableprovides a listof optionalproducts for thePL.
Expansion Options
Accessories
Maintenance Options
Software Options
1-2 Options
1-2 Options
*1 Since the PL’s hard disk drive (HDD) is a consumable item, i.e. it has a definite usage
lifetime, be sure to back up its data frequently and perform regular maintenance.
*2 Depending on the customer’s OS (Operating System) one of these drivers will be
required to allow this type of touch operation. Please contact your local PL dis-
tributor for ordering details.
Name Model
number Description
DIM Module PL-EM200 Main Memory Board
FDD Unit PL-FD100 PC/AT Compatible 3.5” FDD unit
IDE Slave
Adapter PL-SA100 Adapter used for attaching an IDE (ATAPI) compliant CD-ROM
drive (DC power cord included)
IrDA Unit (under
development) PL-IR100 IrDA (Ver. 1.0) compatible infrared data transmissionmodule.
-5V/-12V Power
Unit PL-PW100 Provides –5V and –12V power to expansion slots. Can provide a
total of 200mA of current (sum of all four slots).
CD-ROM Drive
Unit PL-DK200 IDE (ATAPI) compliant CD-ROM drive unit
(Connection cable is included in unit)
Name Model
number Description
Screen
Protection Sheet PL-CS100 Disposable overlay sheets for display face protection and
stain resistance. Touch panel senses User’s touch through
sheet.
Name Model
number Description
TT-WIN/95*2
Touch Panel mouse driver that provides mouse-like
operability to the PL’s touch panel. (for Windows 95 OS)
TT-WIN/NT*2
Touch Panel mouse driver that provides mouse-like
operability to the PL’s touch panel. (for Windows NT OS)
Name Model
number Description
Mounting
Brackets GP070-
AT00-MS Used to install the PL into a panel or cabinet. Same as
original equipment brackets.
Moisture
Resistant Gasket PL-WS100 Used to prevent moisture from entering into the PL’s case
from the front face. Same as original equipment gasket.
HDD Unit *1 PL-HD100 Built-in 2.5”HDD unit
Full Sized Cover PL-FC100 Attached when ISA bus full-sized board is installed in
expansion slot.

Chapter 1 - Overview
PL-6700 43 Series User’s Manual 1-3
Model Number:
P L 6 7 00 - T4 3 - HU01x
PL-6700 series
HDD Revision No.
PL-6700’s
revision no.
F:FDD Installed
(no char.) :No FDD
Hard Disk Type
HU : OS Not Installed.
1-3 PL Series Panel Types
1-3 PL Series Code Name Explanation
Display Type:
TFT Color
LCD
This unit is a (c)UL
recognized, CE marked
and EMC Compliant
product.

MEMO

PL-6700 43 Series User’s Manual 2-1
Operating Voltage 85V AC to 132VAC / 170V AC to 265V AC 50/60 Hz
Power Consumption Less than 150W
Allowable Voltage
Drop less than 20ms
Voltage Endurance 1500V AC at 20mA for 1 minute (between the live wire and
the grounding (FG) terminal)
Isolation Resistance Greater than 10MΩ
ΩΩ
Ωat 500V DC (between the live wire and
the grounding (FG) terminal)
Operating
Temperature 5 to 40o C (with HDD and FDD not installed, 0 to 40o C)
Operating Humidity 30 to 85% RH (no condensation)
Storage Conditions -10 to 60o C/ 30 to 85% RH (no condensation)
Operating
Atmosphere Free of corrosive gas
Noise Immunity
(via noise simulator) Noise Voltage: 1500Vp-p
Pulse Duration: 50ns, 500ns, 1µ
µµ
µs
Electrostatic Voltage
Endurance 4kV
Vibration Endurance 2G: 10 to 25Hz applied in X, Y, and Z directions for 30 minutes
each (0.5G when using HDD unit, 1.0G when using FDD)
Rating*1
(with front panel closed)
Equivalent to IP65f (JEM1030)
1. Electrical Specifications
2. Environment Specifications
Chapter 2Chapter 2
Chapter 2Chapter 2
Chapter 2
SpecificationsSpecifications
SpecificationsSpecifications
Specifications
1. General Specifications 4. PL External Features
2. Performance Specifications 5. PL Dimensions
3. Interface Specifications
*1 The front face of the GP unit, installed in a solid panel, has been tested using conditions equivalent to the
standard shown in the specification . Even though the GP unit’s level of resistance is equivalent to the
standard, oils that should have no effect on the GP can possibly harm the unit. This can occur in areas
where either vaporized oils are present, or where low viscosity cutting oils are allowed to adhere to the
unit for long periods of time. If the GP’s front face protection sheet becomes peeled off, these conditions
can lead to the ingress of oil into the GP and separate protection measures are suggested. Also, if non-
approved oils are present, it may cause deformation or corrosion of the front panel’s plastic cover.
Therefore, prior to installing the GP be sure to confirm the type of conditions that will be present in the
GP’s operating environment.
If the installation gasket is used for a long period of time, or if the unit and its gasket are removed from
the panel, the original level of the protection cannot be guaranteed. To maintain the original protection
level, you need to replace the installation gasket regularly.
2-1 General Specifications
Table of contents
Popular Touch Panel manuals by other brands

Harman
Harman AMX MXT/D-2000XL-PAN Programming manual

syslogic
syslogic TFT/HB101PR8 Series User documentation

Weigel
Weigel SERANA-Q 96 operating manual

Avalue Technology
Avalue Technology SPC-1209 Quick reference guide

Crestron
Crestron TSW-560 Supplemental guide

Cincoze
Cincoze CV-108R-R10/P1001 user manual
