Digitalk 2 - WAY COMMUNICATOR Manual

2 - WAY COMMUNICATOR
PLEASE READ THIS
OWNER MANUAL
CAREFULLY BEFORE USE.
KEEP FOR YOUR
REFERENCE.
FOR INSTALLATION INSTRUCTIONS PLEASE SEE PAGE 6.
Special Features
PRODUCT DESCRIPTION
The COMMUNICATOR is the newest generation in personal two-way
communications.The COMMUNICATOR operates in a radio band ,on
any of the 40 channels.(Refer to "channel table" section on page 19 for
more information.)
The COMMUNICATOR is a lightweight,compact two-way communication
device that can be used to communicate with family or friends at parks,
shopping malls,sporting events,concerts -- any indoor or outdoor activity!
The COMMUNICATOR is compatible with other brands utilizing the same
frequency band (operating in the frequency range from 476.425MHz to
477.400MHz).
The COMMUNICATOR has 40-CHANNELS,featuring a multi-functional LCD
Screen (which displays the current channel and various status icons).
Other features include ELECTRONIC VOLUME CONTROL, BATTERY SAVE
CIRCUITRY and DUPLEX MODE.
Please read this Owner's Manual carefully to get the most out of your
TWO-WAY COMMUNICATOR.
NOTE: The maximum transmission range will vary depending on terrain
and environment.Range will be greater in open fields,while range
is shorter within and around buildings or large structures.
This unit may not ensure privacy of communication.
Contents Contents
Preparation
Communicator Controls - Location & Function.......................................4
Getting Started
Removing Belt Clip.......................................................................................6
Installing Belt Clip.........................................................................................6
Battery Installation.......................................................................................7
LCD Screen...................................................................................................8
Turning the Unit ON......................................................................................9
Turning the Unit OFF......................................................................................9
Adjusting Speaker Volume..........................................................................9
Receiving a Signal.......................................................................................9
Transmitting a Signal....................................................................................9
Operation
Changing Channels....................................................................................10
Monitor..........................................................................................................10
Enter / Back-Light / Button Lock ................................................................10
Channel Scan..............................................................................................11
Sending Call Tones.......................................................................................11
Battery Level Indicator................................................................................12
Battery Charge Indication..........................................................................12
To Charge the Communicator...................................................................12
Dual Watch ..................................................................................................13
Internal VOX Control Function ...................................................................13
Second Counter Function .........................................................................14
Duplex Function ..........................................................................................14
Other Information
Troubleshooting............................................................................................15
Care and Maintenance..............................................................................16
Specifications............................................................................................... 19
2 3
1
OWNER'S MANUAL AND
OPERATING INSTRUCTIONS
M
C
BUSY
SCAN
VOX
DW

5
Communicator Controls
4
Communicator Controls
7
Getting Started
6
Getting Started
Carefully remove your communicator from its packing. If there is any
visible damage,do not attempt to operate this communicator. Return
it to the place of purchase
Removing the BELT CLIP:
1. Pull the BELT CLIP LATCH away from the unit.
2. While pulling the BELT CLIP LATCH,push up on the BELT CLIP to remove
it from the unit.See Figure 1.
Installing the Belt Clip:
1. Slide the BELT CLIP into the BELT CLIP SLOT.See Figure 2.
2. A "click" indicates the BELT CLIP is locked into position.
Battery Installation:
1. Release the BATTERY COMPARTMENT COVER LATCH located on the
rear side of the unit (see Figure 3) and remove the BATTERY
COMPARTMENT COVER from the BATTERY COMPARTMENT (See Figure
4).
2. Install 4x1.5V AAA alkaline batteries or Ni-MH rechargeable batteries
(not included) as shown.
3. Reinstall the BATTERY COMPARTMENT COVER and lock the BATTERY
COMPARTMENT COVER LATCH into position.
The COMMUNICATOR has a built in POWER SAVER feature for maximum
battery life.But when the COMMUNICATOR is not being used,conserve
battery power by pressing the button to OFF.Remove the batteries if
the unit will not be used for a long period of time.
1. Antenna (Pg.16,18)
2. LCD Screen: Displays current channel selection and other radio status
symbols.(Pgs.8-10,12,13)
3. Up ▲button (VOLUME/CHANNEL): Press to adjust volume level and
change channels.(Pgs.9-11,13-15)
4. Down ▼button (VOLUME/CHANNEL): Press to adjust volume level and
change channels.(Pgs.9-11,13-15)
5. Call Cbutton: Press to transmit CALL TONES.(Pg.11,13)
6. Enter button: Used to turn LCD Screen LAMP ON/OFF Buttons
are locked when pressed and held. (Pg.10,11,13,14)
7. Speaker (Pg.9)
8. Battery Compartment (LOCATED ON THE REAR): Houses 4 x "AAA"
alkaline or Ni-MH rechargeable batteries (not included).(Pgs.7,15)
9. Battery Compartment Cover Latch (LOCATED ON THE REAR): Secures
Battery Compartment cover.(Pg.7)
10. Mic: Microphone.(Pgs.9,15)
11. Monitor Mbutton: Press to tune in and hold onto weak signals.(Pgs.
9-11,13,15)
12. Menu button: Allows you to change channels.(Pgs.10,11,13-15)
13. PUSH TO TALK PTT button: Press to transmit.(Pgs.9,11,13,14)
14. Power On/Off button: Press and hold the button to turn your unit
ON/OFF.(Pgs.7,9)
15. TX (Transmission) LED indicator: Illuminates red when transmitting.(Pgs.
9,11,12,14)
16. SP. Jack: When earphone is connected into this jack, voice of the
speaker will shift to earphone.
17. Belt Clip (LOCATED ON THE REAR) (Pg.6)
18. Mic. Jack / Battery Charge Jack (Pg.12)
Figure 1. Figure 2.
M
C
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
Figure 3. Figure 4.
BUSY
SCAN
VOX
DW

Getting Started Getting Started
8 9
11
Operation
10
Operation
Changing Channels:
The COMMUNICATOR has 40 available channels.To change channels:
1. Press the MENU button until the current channel number flashes
on the LCD Screen.
2. While the channel number is flashing:
Press the Up sbutton to move to a higher channel.
Press the Down tbutton to move to a lower channel.
The channel changes from 1 to 40,or from 40 to 1.
3. Press the ENTER button to confirm the selected channel and
return to the NORMAL mode.
4. Channel change operations are disabled during BUTTON LOCK mode.
NOTE: Refer to the "Channel Table" section of this Owner's Manual for
detailed frequency listings.
Monitor:
You can use the MONITOR feature to check for weak signals in the
current channel.
1. Press the MONITOR Mbutton.
2.Press and hold the MONITOR Mbutton unit it "beeps" for continuous
monitoring.
ENTER / Back-light / Button Lock:
1. Press and immediately release the ENTER button to light up the
LCD Screen.The BACKLIGHT will automatically shut off after 4 seconds
if no other buttons have been pressed.
2. Press and hold the ENTER button until the BUTTON LOCK icon is
displayed on the LCD Screen.
NOTE: Volume and Channel Change Operations as well as Call &
Monitor Operations are disabled during BUTTON LOCK mode.
Press and hold the ENTER button again to deactivate
BUTTON LOCK mode.
Channel Scan:
CHANNEL SCAN performs searches for active signals in an endless loop
from 1 to 40.
1. Press MENU button twice and Up s ,Down tbuttons to activate
CHANNEL SCAN. The channel number on the LCD Screen changes
rapidly until an active signal is detected.
During CHANNEL SCAN mode.
Press ENTER button or PTT button to confirm the selected channel.
Press the CALL Cbutton to change to CALL function and to send
a CALL TONE on that active channel.
Press the MENU button 4 times to deactivate CHANNEL SCAN
mode.
2. When an active signal (one of 40 channels) is detected. CHANNEL
SCAN pauses keeping the active signal broadcasted.
3. Press the PTT button to communicate through the active signal channel
and CHANNEL SCAN is deactivated.
4. When an active signal (one of 40 channels) is detected,but another
channel is desired,press the MONITOR Mbutton 2 times to bypass the
current channel and continue to search for another active channel.
Sending Call Tones
You can use CALL TONES to alert the other when you are attempting to
contact them.You can also use CALL TONES to signal the beginning or
the end of a transmission.
1. Press the CALL Cbutton,the red TX LED indicator will light up and the
CALL TONE continues for 3 seconds.
2. Release the CALL Cbutton,your CALL TONES will transmit to nearby
receivers set to the same channel.
LCD Screen:
SCAN Displayed during CHANNEL SCAN mode.
Press and hold the ENTER button
until the BUTTON LOCK symbol is displayed.
BUSY Displayed when receiving a signal.
Channel Number changes from 1 to 40
as selected by user.
Displays current BATTERY LEVEL.
Displays current VOLUME LEVEL.
DW Displayed during DUAL WATCH mode.
VOX Displayed during VOX mode is on.
REP Displayed during Duplex mode is on.
RX Icon Turning the Unit ON:
Press and hold the button.The unit will "beep" with dual tone and the
LCD SCREEN will briefly display a SELF-TEST Screen.
Turning the Unit OFF:
Press and hold the button.The unit will "beep" with a signal tone and
the LCD Screen will turn blank.
Adjusting Speaker Volume:
1. Press the Up sbutton to increase the SpeakerVolume.
2. Press the Down tbutton to decrease the Speaker Volume.
3. The SpeakerVolume level is indicated by the number of bars displayed
in the lower right corner of the LCD Screen.
NOTE: Volume Up sand Down tbuttons are disabled during BUTTON
LOCK mode
Receiving a Signal:
The unit is continuously in the RECEIVE mode when the unit is ON and not
Transmitting.When you receive a signal on the current channel,the RX
icon (BUSY) is displayed.(See "LCD SCREEN" for details).
Transmitting a Signal:
1. Check the channel activity by pressing and holding the MONITOR M
button.You'll hear static if the channel is unoccupied.Don't TRANSMIT
if someone is talking on the channel.Press and hold the PTT button to
TRANSMIT. The TX LED Indicator will light up in red.Hold the unit in a
vertical position with the MICROPHONE 2 to 3 inches from the mouth.
2. While holding the PTT button,speak into the unit using a normal tone
of voice.
3. Release the PTT button when you have finished transmitting.
NOTE: In order for other people to receive your transmission, they must
also be on the same channel you are currently using.Refer to the
"Changing Channels" section for more information.
Channel Number Battery Indicator
Volume Level
Channel
Scan
Selection
Button Lock
Dual Watch
Duplex Icon
BUSY
SCAN
VOX
DW
REP

SYMPTOM
No power.
Reception is
weak.
Cannot change
channels.
Range is limited.
Sound distortion
problems.
SOLUTION
=Check batteries.Ensure that the batteries are installed properly.
=The batteries may be weak.
=Replace old batteries with four (4) new "AAA" alkaline batteries
or Ni-MH rechargeable batteries.
=Press the Up sbutton to increase VOLUME.
=The receiving signal may be weak and/or out of range.
=If this happens,press the MONITOR Mbutton.
=To change channels, press the MENU button until the
channel number flashes on the LCD Screen.
=Press the Up sor Down tbuttons to change channels.
=Batteries may be weak.
=BATTERIES may be weak.
=Replace with new batteries if the BATTERY LEVEL indicator is
low.
=The maximum range will vary depending on terrain and
environment.
=Open fields provide the maximum range,while steel/concrete
structures,heavy foliage and use in buildings and in vehicles
may limit the range significantly.
=Wearing the radio close to the body,such as in a pocket or
on a belt,will decrease range; change the location of the
radio.
=If you are transmitting,speak in a normal tone of voice,2 to
3 inches away from the MICROPHONE.
=If you are receiving,lower the volume to a comfortable level.
=Radios too close.Radios must be at least 5 feet apart; increase
your distance.
=Radios too far apart. Obstacles interfere with transmission.
Talk range is up to 2 miles in clear unobstructed conditions.
15
Operation
14
Operation Operation
12 13
Troubleshooting
Dual Watch:
You can use Dual Watch to monitor 2 channels.
To enter Dual Watch mode:
1. Press MENU button 3 times.
2. Press Up sand Down tbuttons to select desired channel.
3. Once Dual Watch is on,automatically scan the channel that between
2 prefixed channel and the carrier stop on either activated channel
to receive.Dual Watch restarts when the carrier disppears.
4. Press MONITOR Mbutton to monitor weak signal.
5. Press ENTER ,PTT or CALL Cbutton to end the Dual Watch mode.
Internal VOX Control Function
On VOX mode,automatically transmitting and receiving signals without
pressing any button.
To turn on the VOX function:
1.Press MENU button 4 times to enter the VOX mode;
2.While the VOX icon is flashing;
3.Press Up sbutton to select higher VOX sensitivity;
4.Press Down tbuttons to select lower VOX sensitivity;
5.Press MENU button twice to confirm the selected mode.
Note: 1.The VOX sensitivity is indicated by the number of bars displayed
in the lower right corner of the LCD Screen.
2.You can press the ENTER button twice to stop transmitting
for 4 seconds and adjust the VOX sensitivity to lower level if the
surroundings is too noisy which cause transmitting continuously.
To turn off the VOX function:
1.While the VOX icon is flashing,press Down tbuttons until the number
of bars disappears.
2.Press the MENU button twice to confirm the VOX off mode.
Battery Level Indicator:
1. The BATTERY LEVEL is indicated by the number of squares present
inside the BATTERY icon on the LCD Screen.
2. When the BATTERY LEVEL is low,the BATTERY icon will flash to indicate
that the batteries need to be replaced.
3. Do not charge this unit using an AC/DC adaptor with regular "AAA"
alkaline batteries installed. Only use optional AC/DC adaptor with
"AAA" Ni-MH rechargeable batteries (not included).
Battery Charge Indication
During BATTERY CHARGE mode, the BATTERY indicator will keep flashing.
NOTE: Please ensure that the unit is turned off during BATTERY CHARGE
mode.
To Charge The COMMUNICATOR
In the event you wish to use the unit with rechargeable batteries (not
Included) you will be required to use an AC/DC adaptor - Input 230VAC
50 Hz - Output 6 VDC 100MA (not included).
Remark: Please make sure that the polarity of the plug of the adaptor
is correct. If not, there will be the danger of burning the
COMMUNICATOR. For detailed information of the AC/DC
adaptor,please contact your local dealer.
= Insert 4 "AAA" NI-MH rechargeable batteries (not included)
=Turn the unit OFF
=Plug the adaptor into the wall and insert the round end into the
CHARGE JACK marked CHG on the top of the COMMUNICATOR.
=After charging,unplug the adaptor. Turn the unit ON.The BATTERY
LEVEL INDICATOR on the LCD Screen will display the new BATTERY
LEVEL.
Note: It takes approximately 6 hours to fully charge the batteries if they
are at their lowest level or takes around 14 hours to fully charge
the new batteries.
CAUTION: Do not use non-rechargeable batteries with external AC/DC
adaptor as may cause an explosion,Consult your local dealer.
To activate theVOX sensitivity:
1. While theVOX mode is on,plug the connector of the headset (not included)
into SPK/MIC jacks of the communicator and then speak through the
microphone of the headset to activate the transmitting mode.
2. Transmitting mode will turn on automatically and on standby mode.
3. The TX LED indicator illuminates red when transmitting.
Note: TheVOX sensitivity is automatically activated once plug the connector
of the Headset (not included) into SPK/MIC jacks of the communicator.
You don't have to push the PTT button of the headset while transmitting.
Second Counter Function:
Use for counter second meter from 00 to 99 seconds.
To enter Second Counter mode:
Press MENU button 5 times to enter Second Counter mode.
While the Second Counter Meter is flashing:
1.Press Up sbutton to run Second Counter continuously;
2.Press Down tbutton to pause the Second Counter.
3.Press MENU button to confirm the second counter and return to
the original default channel automatically;
4.If an active signal is detected while in Second Counter mode,the unit
will return to RECEIVE mode automatically;
To reset the Second Counter meter:
Once enter the Second Counter mode and while it is flashing, press
ENTER button to reset the Second Counter to 00 status and press
MENU button to confirm.
Duplex Function
This function allows user to use REPEATER feature.
To activate the Duplex function:
Press POWER button once to enter Duplex or Repeater mode.
Press the button one more time to release the function.
During Duplex mode is on,display will show REP icon.

Care and Maintenance Care and Maintenance
16 17
19
Care and Maintenance
18
* Repeater channels
# Emergency calling channel.Use this channel only for emergency.
NOTE: The maximum transmission range will vary depending on terrain
and environment.
Specifications
For Portable Two-way Communicators:
= When transmitting with a COMMUNICATOR,hold the COMMUNICATOR
in a vertical position with its MICROPHONE 1 to 2 inches (2.5 to 5.0 cm)
away from your mouth. Keep the ANTENNA at least 1 inch (2.5 cm)
from your head and body.
= If you wear a COMMUNICATOR on your body,ensure that the ANTENNA
is at least one inch (2.5 cm) from your body when transmitting.
Electromagnetic Interference/Compatibility:
Nearly every electronic device is susceptible to electromagnetic
interference (EMI) if inadequately shielded, designed or otherwise
configured for electromagnetic compatibility.
= Turn your unit OFF in any facilities where posted notices instruct you
to do so. Hospitals or health care facilities may be using equipment
that is sensitive to external RF energy.
= Turn your unit OFF when on board an aircraft when instructed to do
so.Any use of the unit must be accordance with airline regulations or
crew instructions.
95-D5901100
! CAUTION
Damaged ANTENNA:
Do not use any COMMUNICATOR that has a damaged ANTENNA.If a
damaged ANTENNA comes in contact with the skin, a minor burn may
result.
Batteries:
All batteries can cause property damage and/or bodily injury such as
burns if conductive material such as jewelry, keys or beaded chains
touches exposed terminals. The material may complete an electrical
circuit (short circuit) and become quite hot.Exercise care in handling any
charged battery, particularly when placing it inside a pocket,purse or
other container with metal objects.
! WARNING
ForVehicles with an Air Bag:
Do not place your COMMUNICATOR in the area over an air bag or in the
air bag deployment area. Air bags inflate with great force. If a
COMMUNICATOR is placed in the air bag deployment area and the air
bag inflates, the COMMUNICATOR may be propelled with great force
and cause serious injury to the occupants of vehicle.
Potentially Explosive Atmospheres:
Turn your COMMUNICATOR OFF when in any area with a potentially
explosive atmosphere,unless it is a type specifically qualified for such use
(for example,Factory Mutual Approved).Sparks in such areas could cause
an explosion or fire resulting in bodily injury or even death.
Batteries:
Do not replace or charge batteries in a potentially explosive atmosphere.
Contact sparking may occur while installing or removing batteries and
cause an explosion.
Blasting Caps and Areas:
To avoid possible interference with blasting operations, turn your
COMMUNICATOR OFF near electrical blasting caps or in a "blasting area"
or in areas posted: "Turn off two-way radio".Obey all signs and instructions.
NOTE: Areas with potentially explosive atmospheres are often, but not
always,clearly marked.They include fueling areas such as below
deck on boats,fuel or chemical transfer or storage facilities; areas
where the air contains chemicals or particles,such as grain,dust,
or metal powders; and any other area where you would normally
be advised to turn off your vehicle engine.
Care and Maintenance
To clean the unit,wipe with a soft cloth dampened with water.Don't use
cleaner or solvents on the unit; they can harm the case and leak inside,
causing permanent damage.Battery contacts may be wiped with a dry,
lint-free cloth.
If the unit gets wet,turn it off and remove the batteries immediately.Dry
the BATTERY COMPARTMENT with a solf cloth to minimize potential water
damage.Leave the cover off the BATTERY COMPARTMENT overnight or
until completely dry.Do not use the unit until completely dry.
To ensure optimal unit performance,the following operating procedures
should be observed:
476.925
476.950
476.975
477.000
477.025
477.050
477.075
477.100
477.125
477.150
477.175
477.200
477.225
477.250
477.275
477.300
477.325
477.350
477.375
477.400
Channels Available 40 Channels
Output Power (TX) 0.5W (Maximum RF Power)
Battery Life 25 Hours (typical)
Range About 5 Km
MAJOR FUNCTION
CHANNEL TABLE
CHANNEL NUMBER FREQUENCY (MHz)
476.425
476.450
476.475
476.500
# 476.525
476.550
476.575
476.600
476.625
476.650
476.675
476.700
476.725
476.750
476.775
476.800
476.825
476.850
476.875
476.900
* 1
* 2
* 3
* 4
* 5
* 6
* 7
* 8
9
10
11
12
13
14
15
16
17
18
19
20
CHANNEL TABLE
CHANNEL NUMBER FREQUENCY (MHz)
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
