Directed MA3 2018 User manual

MA3
INSTALLATION GUIDE
This product is intended for installation by a professional installer only! Attempts to install this
product by a person other than a trained professional may result in severe damage to a vehicle’s
electrical system and components.
2018-03-06
© 2018 Directed, Vista CA
Directed Digital
Solutions
Designed by Installers for Installers

Contents
Warning! Safety first ....................................................................................................................... 3
Introduction .................................................................................................................................... 4
Pre-installation and application warnings ..................................................................................... 4
Vehicle application guide........................................................................................................... 5
Wiring connections ......................................................................................................................... 6
Main power harness (H1), 12-pin thick gauge connector ............................................................... 6
Auxiliary output harness (H2), 16-pin black connector ................................................................... 6
Analog harness (H3), 18-pin white connector ............................................................................... 7
MC501 harness (H4), 8 thick-gauge wires (optional)..................................................................... 7
Installation (wiring diagrams & vehicle wiring reference charts) ............................................................ 8
Type 1 with T-Harness (THMAC1) (Rev-1) ..................................................................................... 8
Type 1 ..................................................................................................................................... 9
Type 2 with T-Harness (THMAC1) (Rev-1) ................................................................................... 12
Type 3 with T-Harness (THMAC1) (Rev-1) ................................................................................... 15
Type 3 ................................................................................................................................... 16
Type 4 with T-Harness (THMAC1) (Rev-1) ................................................................................... 18
Type 4 ................................................................................................................................... 19
Type 5 ................................................................................................................................... 21
Accessing the parking light circuit ............................................................................................ 23
Immobilizer interface .............................................................................................................. 23
Connecting the module .................................................................................................................. 24
Important! .............................................................................................................................. 24
Manual or automatic transmission selection ................................................................................ 24
Optional sensors ..................................................................................................................... 24
RF Systems ............................................................................................................................. 25
When used in conjunction with SmartStart.................................................................................. 25
Module programming.............................................................................................................. 26
LED diagnostics and troubleshooting.......................................................................................... 28
Soft reset................................................................................................................................ 30
Hard reset .............................................................................................................................. 30
Learning the Tach (not needed with Virtual Tach) ............................................................................... 31
Initializing Virtual Tach (not needed with hardwired or data tach applications) ..................................... 31
Limited lifetime consumer warranty .................................................................................................. 32
Quick Reference Guide.................................................................................................................. 33

Warning! Safety first
The following safety warnings must be observed at all times:
• Due to the complexity of this system, installation of this product must only be performed by an authorized Directed dealer.
• When properly installed, this system can start the vehicle via a command signal from the remote control. Therefore, never
operate the system in an area that does not have adequate ventilation.
The following precautions are the sole responsibility of the user; however, authorized Directed dealers should:
• Never use a test light or logic probe when installing this unit. Always use a multimeter.
• Never operate the system in an enclosed or partially enclosed area without ventilation (such as a garage).
• When parking in an enclosed or partially enclosed area or when having the vehicle serviced, the remote start system must
be disabled using the installed toggle switch. It is the user’s sole responsibility to properly handle and keep out of reach from
children all remote controls to assure that the system does not unintentionally remote start the vehicle.
• USER MUST INSTALL A CARBON MONOXIDE DETECTOR IN OR ABOUT THE LIVING AREA ADJACENT TO THE VEHICLE.
ALL DOORS LEADING FROM ADJACENT LIVING AREAS TO THE ENCLOSED OR PARTIALLY ENCLOSED VEHICLE
STORAGE AREA MUST REMAIN CLOSED AT ALL TIMES.
Use of this product in a manner contrary to its intended mode of operation may result in property damage, personal injury, or
death. Except when performing the Safety Check outlined in this installation guide, (1) Never remotely start the vehicle with
the vehicle in gear, and (2) Never remotely start the vehicle with the keys in the ignition. The user is responsible for having the
neutral safety feature of the vehicle periodically checked, wherein the vehicle must not remotely start while the car is in gear.
This testing should be performed by an authorized Directed dealer in accordance with the Safety Check outlined in this product
installation guide. If the vehicle starts in gear, cease remote start operation immediately and consult with the user to fix the problem
immediately.
OPERATION OF THE REMOTE START MODULE IF THE VEHICLE STARTS IN GEAR IS CONTRARY TO ITS INTENDED MODE OF
OPERATION. OPERATING THE REMOTE START SYSTEM UNDER THESE CONDITIONS MAY RESULT IN PROPERTY DAMAGE
OR PERSONAL INJURY. IMMEDIATELY CEASE THE USE OF THE UNIT AND REPAIR OR DISCONNECT THE INSTALLED REMOTE
START MODULE. DIRECTED WILL NOT BE HELD RESPONSIBLE OR PAY FOR INSTALLATION OR REINSTALLATION COSTS.
Remote starters for manual transmission pose significant risks if not properly installed and operated. When testing to ensure the
installation is working properly, only remote start the vehicle in neutral gear, on a flat surface and with a functional, fully engaged
parking brake. Do not allow anyone to stand in front of or behind the vehicle.
This product should not be installed in any convertible vehicles, soft or hard top with a manual transmission. Installation in such
vehicles may pose certain risk.
3Directed Digital Solutions MA3
© 2018-03-06 Directed. All rights reserved.

Introduction
The MA3 firmware for Directed Digital Solutions is compatible with specific Mazda, Scion and Toyota vehicles.
It is a complete solution for remote start, security (if applicable), bypass interface, and convenience. This guide
provides information on the installation of the module using MA3. If you would prefer using this system as a
digital solution, go to www.directechs.com and search for the make, model and year of the vehicle. This will
allow you to find the proper firmware and corresponding installation guide.
Warning! This module can only be programmed via the web tool, which can be found on www.directechs.com or using the
Directechs Mobile application for mobile devices. Features and functions will become accessible when you connect the module
using the XKLoader.
Pre-installation and application warnings
Firmware notes: This section highlights important information for this specific firmware and will assist in
pricing accordingly, as well as bringing awareness to any operational or vehicle limitations.
T-Harness
compatible THMAC1 Keys required for programming 1Keys required for operation
see note
5
Important! In these vehicles, the factory keyless entry module is sensitive to interference and may cease to operate without
notice. Please ensure you disconnect the (-) terminal of the battery prior to disconnecting and reconnecting the connectors at
the start-stop module below the steering wheel to avoid damage to the keyless entry module.
The optional Plug & Play THMAC1 T-Harness is sold separately.
Scion iA and Toyota Yaris Sedan are not compatible with T-Harness THMAC1
The OBDII Diagnostic Connector features will remain the same even when the T-Harness is installed.
All connectors are displayed from the wire side (unless specified otherwise).
Refer to the "Vehicle wiring reference chart" following each installation type.
No takeover feature is available. The vehicle will shut down as soon as a door is opened.
To remote start the engine, the hood, hatch, and all doors must be closed.
When installing this solution with T-Harness THMAC1 in one of the vehicles from this guide, the vehicle's OEM alarm will
no longer be functional. The installation of a hybrid system (remote starter and alarm combo) is highly recommended to
preserve vehicle security.
It is normal for the key symbol to flash during remote start runtime.
Parking lights for Mazda 3 can also be found in drivers kick. Please refer to www.directechs.com for additional information.
General notes: This section highlights important information for this specific firmware.
[1] The installation of an aftermarket hood pin is ONLY required on vehicles that are NOT equipped with a factory hood pin.
[2] The siren is ONLY required when enabling the security features during module flashing.
[3] Only required to retain OEM remote functionality during remote start runtime if not using the THMAC1 T-Harness.
[4] See page 22 for more information about accessing the parking wiring. Parking lights for Mazda 3 can also be found in
drivers kick. Please refer to www.directechs.com for additional information.
[5] Type 5 vehicles only are not compatible with THMAC1 THarness. 1 (one) key is required for operation. For key wrap
instructions, refer to page 22.
[6] Connection required when enabling the security features during module flashing.
[7] Connection required when using a T-Harness THMAC1.
Additional parts required (maximum required):
Diode 6A
0 x 1A Diodes 86 85
30
87a
87
2 x Relay
Resistor 100Ω
0 x Resistor
Fuse 7.5A
1 x Fuse
4Directed Digital Solutions MA3
© 2018-03-06 Directed. All rights reserved.

Vehicle application guide
The following table lists the vehicles and features which are compatible with this product. The number assigned to each year
allows you to determine which installation type should be used for your vehicle.
Vehicles
2018 2017 2016 2015 2014 2013 PK-Immobilizer Bypass-Data No Key Req'd PK-Universal RF Bypass- Key Req'd DL-Door Lock Control DL-Door Unlock DL-Driver Priority Unlock DL-Trunk / Hatch Release FOB-Control of aftermarket alarm with OEM remote
RS-3x LOCK START (Start control using OEM Remote)
RS-3x LOCK STOP (Stop control using OEM Remote) RS-SmartStart RS-Tach / RPM Output SS-Entry Monitoring ALL Door Pins SS-Entry Monitoring Hood Pin SS-Entry Monitoring Trunk/Hatch Pin ST-Brake Status (foot brake) ST-E-Brake Status ST-Ignition Status
Mazda
3 (Smart Key) 33333 • •••••••••••••••
6 (Smart Key) 2222 • •••••••••••••••
CX-3 (Smart Key) 444 • •••••••••••••••
CX-5 (Smart Key) 111111• •••••••••••••••
Scion
iA (Smart Key)
[5] 5 ••••••••••••••••
Toyota
Yaris Sedan (Smart Key)
[5] 555 ••••••••••••••••
Legend:
PK: Transponder & Immobilizer Override
DL: OE Door Lock & Alarm Controls
FOB: Sync CAN Interface w/ FOB Remote
RS: Remote Start & Engine Controls
SS: Integrated Security & Monitoring
ST: Function/Feature Status
5Directed Digital Solutions MA3
© 2018-03-06 Directed. All rights reserved.

Wiring connections
The wiring connections listed below are specific to this firmware.
Main power harness (H1), 12-pin thick gauge connector
Conn./Pin Color Description
H1/1 White Relay 3 COM – (+)12V Input1
H1/2 White/Brown Relay 3 N.O. – (+) Starter Output 1
H1/3 Brown/Red Relay 2 N.O. - (+) Ignition Output
H1/4 Yellow/Red Relay 2 COM – (+)12V Input1
H1/5 Orange/Red Relay 2 N.C. – No Connection
H1/6 Yellow Relay 1 COM – Parking Light interrupt (conn.) 1
H1/7 White Relay 3 COM – (+) 12V Input 1
H1/8 White/Brown Relay 3 N.O. – (+) Starter Output 1
H1/9 Black (-) Ground
H1/10 Red (+) 12V Input
H1/11 Orange/Yellow Relay 1 N.C. – Parking Lights interrupt (vehicle) 1
H1/12 Brown Relay 1 N.O. – No Connection 1
Auxiliary output harness (H2), 16-pin black connector
Conn./Pin Color Description
H2/1 Violet/Brown (MUX) Door Lock Output (T-Harness ONLY)
H2/2 Yellow/Black No Connection
H2/3 Orange/Black Keyless Data Output
H2/4 Tan HS CAN Low
H2/5 Tan/Black HS CAN High
H2/6 Light Green No Connection
H2/7 Orange/Green No Connection
H2/8 Orange/Brown No Connection
H2/9 Violet/Green (MUX) Door Lock Output (T-Harness ONLY)
H2/10 Green/Black (-) Parking Light Output 2
H2/11 White/Violet No Connection 2
H2/12 White/Red (+) Accessory 1 Output 2
H2/13 Lt. Blue/Black (-) Push-to-Start Output 2
H2/14 Green/Red (+) Accessory 2 Output 2
H2/15 N/A No Connection
H2/16 Violet/Yellow No Connection
1. If these outputs are not used by the firmware, they can be configured by the installer when the module is flashed.
2. If these outputs are not used by the firmware, they can be configured by the installer when the module is flashed. Note that they are low current and a relay
may be necessary.
6Directed Digital Solutions MA3
© 2018-03-06 Directed. All rights reserved.

Analog harness (H3), 18-pin white connector
Conn./Pin Color Description
H3/1 Lt. Blue/Red No Connection
H3/2 Black/White (-) Parking Brake Input (manual transmission) 2
H3/3 Gray (-) Hood Input 2
H3/4 N/A No Connection
H3/5 Gray/Black (+) Trunk Shunt Input 2
H3/6 Violet/White (AC) Tach Input 2
H3/7 Dark Blue (-) Ignition Interrupt Output1
H3/8 Brown/Black (-) No Connection 1
H3/9 Red/White (-) Trunk Release Output 1
H3/10 White/Green (-) Door Input 2
H3/11 Yellow/Green (+) Door Input 2
H3/12 Blue/Red No Connection
H3/13 Light Blue (-) Trunk Trigger Input 2
H3/14 Pink/Yellow (-) Activation (start) Input
H3/15 Dark Green No Connection 1
H3/16 Brown/White (+) Brake Input 2
H3/17 Brown (+) Siren Output 1
H3/18 Blue/White (-) Key Wrap Output 1
MC501 harness (H4), 8 thick-gauge wires (optional)
Conn./Pin Color Description
H4/1 Pink/White (+) Ignition 2/Flex Relay Output 3
H4/2 Red/White (+) Fused (30A) Ignition 2/Flex Relay Input
H4/3 Pink (+) Ignition Output (also input to Yellow in ribbon cable)
H4/4 Red (+) 12 Volt (battery) Input
H4/5 Orange (+) Accessory Output
H4/6 Red (+) 12 Volt (battery) Input
H4/7 Green Starter Input (from key switch) 4
H4/8 Violet (+) Starter Output (to starter)
1. If these outputs are not used by the firmware, they can be configured by the installer when the module is flashed. Note that they are low current and a relay
may be necessary.
2. These connections are only required if the corresponding statuses are not supported by the firmware. See "Vehicle application guide" on page 5 for a
list of compatible features.
7Directed Digital Solutions MA3
© 2018-03-06 Directed. All rights reserved.

Installation (wiring diagrams & vehicle wiring reference charts)
Type 1 with T-Harness (THMAC1) (Rev-1)
Refer to "Pre-installation and application warnings" on page 4 for important information, such as the description of each special note referenced in the diagram ( ).
(-) Trunk Release Output: Red/White
(+) Trunk Shunt Input: Gray/Black
Siren
The Remote Start
Safety Override
Switch MUST be in
the ON position.
Remote Start Safety
Override Switch
Hood Pin
(-) Hood Input: Gray
(+) Siren Output: Brown
(-) Parking Lights Output: Green/Black
(MUX) Door Lock Output: Violet/Green
(MUX) Door Lock Output: Violet/Brown
Factory Alarm/
Door Lock:
White/Green
Driver Kick Panel
(-) Trunk Release:
White/Blue,
pin 3
(+) Trunk Release Actuator: Green, pin 2
Orange/Yellow: Parking Light
Interrupt (vehicle side)
Parking Light
Switch Assembly
65
4
3
2
1
Parking Lights Interrupt:
Green, pin 4
(-) Parking Lights:
Yellow, pin 3
Yellow: Parking Light Interrupt (conn.side)
13
23
1112 18
109
17
86 7
14
54 1615 1
Start/Stop Unit
(White conn. at steering column)
Cut
1 2 3
THMAC1
(optional
T-Harness)
Start/Stop Unit
(White conn. at steering column
T-Harness
Relays
Trunk Release Switch
(White conn. in driver dash)
Trunk Release Actuator
(Blue conn. at left rear quarter panel)
8Directed Digital Solutions MA3
© 2018-03-06 Directed. All rights reserved.

Type 1
Refer to "Pre-installation and application warnings" on page 4 for important information, such as the description of each special note referenced in the diagram ( ).
(-) PTS: pin 20
(+) Ign. 2 Interr.: Gray/Red or Brown, pin 3
Optional
Siren
The Remote Start
Safety Override
Switch MUST be in
the ON position.
Remote Start Safety
Override Switch
Hood Pin
(-) Hood Input: Gray: 3
(+) Siren Output: Brown: 17
HS CAN Low: Tan : 4
HS CAN High: Tan/Black: 5
(-) Push-to-Start Output: Lt. Blue/Black: 13
(+) Accessory 2 Output: Green/Red: 14
(-) Parking Lights Output: Green/Black: 10
(+) Accessory 1 Output: White/Red: 12
24 1314151617 18
192021
2223
12 123
45
6
7
8
910
11
(+) Starter:
Brown/Black
or Brown, pin 23
(+) Ignition: Pink
or Lt. Green/Red,
pin 10
HS CAN Low: Red/Yellow or Red, pin 8
HS CAN High: White/Black or White, pin 7
(+) Accessory 1: Yellow/Green
or Yellow, pin 2
(+) Accessory 2:
Brown/Red or Pink, pin 14
10: Red: (+) 12V Input
2 & 8 : White/Brown: (+) Starter Output
1 & 7 : White: (+) 12V Input
3 : Brown/Red: (+) Ignition Output
4 : Yellow/Red: (+) 12V Input
11: Orange/Yellow: Parking Light
Interrupt (vehicle side)
9: Black: (-) Ground
Parking Light
Switch Assembly
1
65
4
3
2
1
Parking Lights (cut):
Green, pin 4
(-) Parking Lights:
Yellow, pin 3
(+) 12V:
White,
pin 1
6 : Yellow: Parking Light Interr. (conn. side)
16
32 31 30 29 28 27 26 25 24 23 22 21 20 19 18
12456789101112131415
30
86 8587
87a
30
86 85
87
87a
(+)12V
3
17
Cut
Cut
Cut
(-) Ignition Interrupt Output: Dark Blue: 7
Start/Stop Unit
(White conn. at
steering column)
Start/Stop Unit
(White conn. at
steering column)
Fuse Box
(White conn.
at drivers kick)
Keyless Data Output: Orange/Black: 3
Keyless Data:
Green/Orange
or Green, pin 9
(+) Ign. 3 Interrupt:
Violet, pin 17
13
23
1112 18
109
17
86 7
14
54 1615 1
(+) Trunk Shunt Input: Gray/Black: 5
(+) Trunk Release Actuator: Green, pin 2
Trunk Release Actuator
(Blue conn. at left rear quarter panel)
9Directed Digital Solutions MA3
© 2018-03-06 Directed. All rights reserved.

Vehicle wiring reference chart
This section provides vehicle wiring information to guide you through the various stages of your installation. Refer to
www.directechs.com for additional information.
Wire Information Connector Information
Function Color Pin Polarity Location Color Pins Ref.
Mazda CX-5 (Smart Key) 2013-2016
HS CAN High White/Black 7 Data Start/Stop unit in steering column. White 24 A
HS CAN Low Red/Yellow 8 Data Start/Stop unit in steering column. White 24 A
Accessory 1 Yellow/Green 2 (+) Start/Stop unit in steering column. White 24 A
Accessory 2 Brown/Red 14 (+) Start/Stop unit in steering column. White 24 A
Ignition 1 Lt. Green/Red 10 (+) Start/Stop unit in steering column. White 24 A
Starter Brown/Black 23 (+) Start/Stop unit in steering column. White 24 A
PTS 1 Green/White or Lt.
Green/Red 20 (-) Start/Stop unit in steering column. White 32 B
Ignition 2 Interrupt [3] Gray/Red 3 Cut Start/Stop unit in steering column. White 32 B
Ignition 3 Interrupt [3] Violet 17 Cut Start/Stop unit in steering column. White 32 B
Keyless Data Green/Orange 9 Data Start/Stop unit in steering column White 32 B
12V White 1 (+) Fusebox in driver kick. White 1 C
Parking Lights Yellow 3 (-) Parking light assembly switch. White 6 D
Parking Lights Interrupt Green 4 Cut Parking light assembly switch. White 6 D
Door Lock [6] White/Green 12 MUX Driver kick, door harness. White 32 C
Trunk Release Actuator
[6]
Green 2 (+) BCM in left rear quarter panel. Blue 18 -
Trunk Release [7] White/Blue 3 (-) Trunk release switch. White 3 E
10 Directed Digital Solutions MA3
© 2018-03-06 Directed. All rights reserved.

Wire Information Connector Information
Function Color Pin Polarity Location Color Pins Ref.
Mazda CX-5 (Smart Key) 2017-2018
HS CAN High White 7 Data Start/Stop unit in steering column. White 24 A
HS CAN Low Red 8 Data Start/Stop unit in steering column. White 24 A
Accessory 1 Yellow 2 (+) Start/Stop unit in steering column. White 24 A
Accessory 2 Pink 14 (+) Start/Stop unit in steering column. White 24 A
Ignition 1 Pink 10 (+) Start/Stop unit in steering column. White 24 A
Starter Brown 23 (+) Start/Stop unit in steering column. White 24 A
PTS 1 Lt. Green 20 (-) Start/Stop unit in steering column. White 32 B
Ignition 2 Interrupt [3] Brown 3 Cut Start/Stop unit in steering column. White 32 B
Ignition 3 Interrupt [3] Violet 17 Cut Start/Stop unit in steering column. White 32 B
Keyless Data Green 9 Data Start/Stop unit in steering column White 32 B
12V White 1 (+) Fusebox in driver kick. White 1 C
Parking Lights Yellow 3 (-) Parking light assembly switch. White 6 D
Parking Lights Interrupt Green 4 Cut Parking light assembly switch. White 6 D
Door Lock [6] White/Green 12 MUX Driver kick, door harness. White 32 C
Trunk Release Actuator
[6]
Green 2 (+) BCM in left rear quarter panel. Blue 18 -
Trunk Release [7] White/Blue 3 (-) Trunk release switch. White 3 E
11 Directed Digital Solutions MA3
© 2018-03-06 Directed. All rights reserved.

Type 2 with T-Harness (THMAC1) (Rev-1)
Refer to "Pre-installation and application warnings" on page 4 for important information, such as the description of each special note referenced in the diagram ( ).
(-) Trunk Release Output: Red/White
(+) Trunk Shunt Input: Gray/Black
Siren
The Remote Start
Safety Override
Switch MUST be in
the ON position.
Remote Start Safety
Override Switch
Hood Pin
(-) Hood Input: Gray
(+) Siren Output: Brown
(-) Parking Lights Output: Green/Black
(MUX) Door Lock Output: Violet/Green
(MUX) Door Lock Output: Violet/Brown
Factory Alarm/
Door Lock:
White/Green
Driver Kick Panel
(-) Trunk Release:
Green/Red, pin 1
(+) Trunk Release Actuator:
Green or Brown, pin 2
Orange/Yellow: Parking Light
Interrupt (vehicle side)
Parking Light
Switch Assembly
65
4
3
2
1
Parking Lights Interrupt:
Green, pin 4
(-) Parking Lights:
Yellow, pin 3
Yellow: Parking Light Interrupt (conn.side)
13
23
1112 18
109
17
86 7
14
54 1615 1
Start/Stop Unit
(White conn. at steering column)
Cut
THMAC1
(optional
T-Harness)
Start/Stop Unit
(White conn. at steering column
T-Harness
Relays
Trunk Release Actuator
(Blue conn. at left rear quarter panel)
Trunk Release Switch
12 3 4
12 Directed Digital Solutions MA3
© 2018-03-06 Directed. All rights reserved.

Type 2
Refer to "Pre-installation and application warnings" on page 4 for important information, such as the description of each special note referenced in the diagram ( ).
(-) PTS: Green/White or
Lt. Green/Red, pin 20
(+) Ign. 2 Interrupt: Gray/Red, pin 3
Optional
(-) Ignition Interrupt Output: Dark Blue: 7
Siren
The Remote Start
Safety Override
Switch MUST be in
the ON position.
Remote Start Safety
Override Switch
Hood Pin
(-) Hood Input: Gray: 3
(+) Siren Output: Brown: 17
HS CAN Low: Tan : 4
HS CAN High: Tan/Black: 5
(-) Push-to-Start Output: Lt. Blue/Black: 13
(+) Accessory 2 Output: Green/Red: 14
(-) Parking Lights Output: Green/Black: 10
(+) Accessory 1 Output: White/Red: 12
24 1314151617 18
192021
2223
12 123
45
6
7
8
910
11
(+) Starter:
Brown/Black,
pin 23
(+) Ignition:
Lt. Green/Red,
pin 10
HS CAN Low: Red, pin 8
HS CAN High: White, pin 7
(+) Accessory 1:
Yellow/Green, pin 2
(+) Accessory 2:
Brown/Red, pin 14
10: Red: (+) 12V Input
2 & 8 : White/Brown: (+) Starter Output
1 & 7 : White: (+) 12V Input
3 : Brown/Red: (+) Ignition Output
4 : Yellow/Red: (+) 12V Input
11: Orange/Yellow: Parking Light
Interrupt (vehicle side)
9: Black: (-) Ground
Parking Light
Switch Assembly
1
65
4
3
2
1
Parking Lights (cut):
Green, pin 4
(-) Parking Lights:
Yellow, pin 3
(+) 12V:
White,
pin 1
6 : Yellow: Parking Light Interr. (conn. side)
16
32 31 30 29 28 27 26 25 24 23 22 21 20 19 18
12456789101112131415
30
86 8587
87a
30
86 85
87
87a
(+)12V
3
17
Cut
Cut
Cut
Start/Stop Unit
(White conn. at
steering column)
Start/Stop Unit
(White conn. at
steering column)
Fuse Box
(White conn.
at drivers kick)
Keyless Data Output: Orange/Black: 3
Keyless Data:
Green/Orange, pin 9
(+) Ign. 3 Interrupt:
Violet, pin 17
(+) Trunk Release Actuator:
Green or Brown, pin 2
13
23
1112 18
109
17
86 7
14
54 1615 1
(+) Trunk Shunt Input: Gray/Black: 5
Trunk Release Actuator
(Blue conn. at left rear quarter panel)
13 Directed Digital Solutions MA3
© 2018-03-06 Directed. All rights reserved.

Vehicle wiring reference chart
This section provides vehicle wiring information to guide you through the various stages of your installation. Refer to
www.directechs.com for additional information.
Wire Information Connector Information
Function Color Pin Polarity Location Color Pins Ref.
Mazda 6 (Smart Key) 2014-2017
HS CAN High White 7 Data Start/Stop unit in steering column. White 24 A
HS CAN Low Red 8 Data Start/Stop unit in steering column. White 24 A
Accessory 1 Yellow/Green 2 (+) Start/Stop unit in steering column. White 24 A
Accessory 2 Brown/Red 14 (+) Start/Stop unit in steering column. White 24 A
Ignition 1 Lt. Green/Red 10 (+) Start/Stop unit in steering column. White 24 A
Starter Brown/Black 23 (+) Start/Stop unit in steering column. White 24 A
PTS 1 Green/White or Lt. Green/
Red
20 (-) Start/Stop unit in steering column. White 32 B
Ignition 2 Interrupt [3] Gray/Red 3 Cut Start/Stop unit in steering column. White 32 B
Ignition 3 Interrupt [3] Violet 17 Cut Start/Stop unit in steering column. White 32 B
Keyless Data Green/Orange 9 Data Start/Stop unit in steering column. White 32 B
12V White 1 (+) Fusebox in driver kick. White 1 C
Parking Lights Yellow 3 (-) Parking light assembly switch. White 6 D
Parking Lights Interrupt Green 4 Cut Parking light assembly switch. White 6 D
Door Lock [6] White/Green 12 MUX Driver kick, door harness. White 32 C
Trunk Release Actuator
[6]
Green or Brown 2 (+) BCM in left rear quarter panel. Blue 18 -
Trunk Release [7] Green/Red 1 (-) Trunk release switch. White 4 E
14 Directed Digital Solutions MA3
© 2018-03-06 Directed. All rights reserved.

Type 3 with T-Harness (THMAC1) (Rev-1)
Refer to "Pre-installation and application warnings" on page 4 for important information, such as the description of each special note referenced in the diagram ( ).
(-) Trunk Release Output: Red/White
(+) Trunk Shunt Input: Gray/Black
Siren
The Remote Start
Safety Override
Switch MUST be in
the ON position.
Remote Start Safety
Override Switch
Hood Pin
(-) Hood Input: Gray
(+) Siren Output: Brown
(-) Parking Lights Output: Green/Black
(MUX) Door Lock Output: Violet/Green
(MUX) Door Lock Output: Violet/Brown
Factory Alarm/
Door Lock:
Lt. Blue
Driver Kick Panel
(-) Trunk Release:
White, pin 1
(+) Trunk Release Actuator:
Blue, pin 2
Orange/Yellow: Parking Light
Interrupt (vehicle side)
Parking Light
Switch Assembly
65
4
3
2
1
Parking Lights Interrupt:
Green, pin 4
(-) Parking Lights:
Yellow, pin 3
Yellow: Parking Light Interrupt (conn.side)
13
23
1112 18
109
17
86 7
14
54 1615 1
Start/Stop Unit
(White conn. at steering column)
Cut
THMAC1
(optional
T-Harness)
Start/Stop Unit
(White conn. at steering column
T-Harness
Relays
Trunk Release Actuator
(Blue conn. at left rear quarter panel)
Trunk Release Switch
12 3 4
15 Directed Digital Solutions MA3
© 2018-03-06 Directed. All rights reserved.

Type 3
Refer to "Pre-installation and application warnings" on page 4 for important information, such as the description of each special note referenced in the diagram ( ).
(-) PTS: Brown, pin 20
(+) Ign. 2 Interrupt: Gray/Red, pin 3
Optional
(+) Ign. 3 Interrupt:
Violet, pin 17
(-) Ignition Interrupt Output: Dark Blue: 7
Siren
The Remote Start
Safety Override
Switch MUST be in
the ON position.
Remote Start Safety
Override Switch
Hood Pin
(-) Hood Input: Gray: 3
(+) Siren Output: Brown: 17
HS CAN Low: Tan : 4
HS CAN High: Tan/Black: 5
(-) Push-to-Start Output: Lt. Blue/Black: 13
(+) Accessory 2 Output: Green/Red: 14
(-) Parking Lights Output: Green/Black: 10
(+) Accessory 1 Output: White/Red: 12
24 1314151617 18
192021
2223
12 123
45
6
7
8
910
11
(+) Starter:
Green,
pin 23
(+) Ignition:
Lt. Green,
pin 10
HS CAN Low: Red, pin 8
HS CAN High: White, pin 7
(+) Accessory 1:
Pink, pin 2
(+) Accessory 2:
Brown, pin 14
10: Red: (+) 12V Input
2 & 8 : White/Brown: (+) Starter Output
1 & 7 : White: (+) 12V Input
3 : Brown/Red: (+) Ignition Output
4 : Yellow/Red: (+) 12V Input
11: Orange/Yellow: Parking Light
Interrupt (vehicle side)
9: Black: (-) Ground
Parking Light
Switch Assembly
1
65
4
3
2
1
Parking Lights (cut):
Green, pin 4
(-) Parking Lights:
Yellow, pin 3
(+) 12V:
White,
pin 1
6 : Yellow: Parking Light Interr. (conn. side)
16
32 31 30 29 28 27 26 25 24 23 22 21 20 19 18
12456789101112131415
30
86 8587
87a
30
86 85
87
87a
(+)12V
3
17
Cut
Cut
Cut
Start/Stop Unit
(White conn. at
steering column)
Start/Stop Unit
(White conn. at
steering column)
Fuse Box
(White conn.
at drivers kick)
Keyless Data Output: Orange/Black: 3
Keyless Data:
Lt. Blue, pin 9
(+) Trunk Release Actuator:
Blue, pin 2
13
23
1112 18
109
17
86 7
14
54 1615 1
Trunk Release Actuator
(Blue conn. at left rear quarter panel)
(+) Trunk Shunt Input: Gray/Black: 5
16 Directed Digital Solutions MA3
© 2018-03-06 Directed. All rights reserved.

Vehicle wiring reference chart
This section provides vehicle wiring information to guide you through the various stages of your installation. Refer to
www.directechs.com for additional information.
Wire Information Connector Information
Function Color Pin Polarity Location Color Pins Ref.
Mazda 3 (Smart Key) 2014-2018
HS CAN High White 7 Data Start/Stop unit in steering column. White 24 A
HS CAN Low Red 8 Data Start/Stop unit in steering column. White 24 A
Accessory 1 Pink 2 (+) Start/Stop unit in steering column. White 24 A
Accessory 2 Brown 14 (+) Start/Stop unit in steering column. White 24 A
Ignition Lt. Green 10 (+) Start/Stop unit in steering column. White 24 A
Starter Green 23 (+) Start/Stop unit in steering column. White 24 A
PTS Brown 20 (-) Start/Stop unit in steering column. White 32 B
Ignition 2 Interrupt [3] Gray/Red 3 Cut Start/Stop unit in steering column. White 32 B
Ignition 3 Interrupt [3] Violet 17 Cut Start/Stop unit in steering column. White 32 B
Keyless Data Lt. Blue 9 Data Start/Stop unit in steering column. White 32 B
12V White 1 (+) Fuse box in drivers kick. White 1 C
Parking Lights Yellow 3 (-) Parking light assembly switch. White 6 D
Parking Lights Interrupt Green 4 Cut Parking light assembly switch. White 6 D
Door Lock [6] Lt. Blue 12 MUX Driver kick, door harness. White 32 C
Trunk Release Actuator
[6]
Blue 2 (+) BCM in left rear quarter panel. Blue 18 -
Trunk Release [7] White 1 (-) Trunk release switch. White 4 E
17 Directed Digital Solutions MA3
© 2018-03-06 Directed. All rights reserved.

Type 4 with T-Harness (THMAC1) (Rev-1)
Refer to "Pre-installation and application warnings" on page 4 for important information, such as the description of each special note referenced in the diagram ( ).
Factory Alarm/Door Lock:
Brown, pin 22
White 32-pin connector
(BCM bottom left plug)
(-) Trunk Release
Red, pin 10
(-) Trunk Release Output: Red/White
(+) Trunk Shunt Input: Gray/Black
Siren
The Remote Start
Safety Override
Switch MUST be in
the ON position.
Remote Start Safety
Override Switch
Hood Pin
(-) Hood Input: Gray
(+) Siren Output: Brown
(-) Parking Lights Output: Green/Black
(MUX) Door Lock Output: Violet/Green
(MUX) Door Lock Output: Violet/Brown
Orange/Yellow: Parking Light
Interrupt (vehicle side)
Parking Light
Assembly Switch
65
4
3
2
1
Parking Lights Interrupt:
Black, pin 2
(-) Parking Lights:
Blue, pin 1
Yellow: Parking Light Interrupt (conn. side)
(+) Trunk Release Actuator:
White, pin 4
12 3 4
5 6 7 8
Cut
THMAC1
(optional
T-Harness)
T-Harness
Relays
ESU (Electrical Supply Unit)
(White conn. at drivers kick)
Start/Stop Unit
(White conn. at steering column)
Start/Stop Unit
(White conn. at steering column)
18 Directed Digital Solutions MA3
© 2018-03-06 Directed. All rights reserved.

Type 4
Refer to "Pre-installation and application warnings" on page 4 for important information, such as the description of each special note referenced in the diagram ( ).
(-) PTS: Blue, pin 20
(+) Ign. 2 Interrupt: Gray/Red, pin 3
Optional
(+) Ign. 3 Interrupt:
Brown, pin 17
(-) Ignition Interrupt Output: Dark Blue: 7
Siren
The Remote Start
Safety Override
Switch MUST be in
the ON position.
Remote Start Safety
Override Switch
Hood Pin
(-) Hood Input: Gray: 3
(+) Siren Output: Brown: 17
HS CAN Low: Tan : 4
HS CAN High: Tan/Black: 5
(-) Push-to-Start Output: Lt. Blue/Black: 13
(-) Parking Lights Output: Green/Black: 10
(+) Accessory 1 Output: White/Red: 12
24 1314151617 18
192021
2223
12 123
45
6
7
8
910
11
(+) Starter:
Gray,
pin 23
(+) Ignition:
Yellow,
pin 10
HS CAN Low: Red, pin 8
HS CAN High: Green, pin 7
(+) Accessory 1: Pink, pin 2
10: Red: (+) 12V Input
2 & 8 : White/Brown: (+) Starter Output
1 & 7 : White: (+) 12V Input
3 : Brown/Red: (+) Ignition Output
4 : Yellow/Red: (+) 12V Input
11: Orange/Yellow: Parking Light
Interrupt (vehicle side)
9: Black: (-) Ground
Parking Light
Switch Assembly
1
65
4
3
2
1
Parking Lights (cut):
Black, pin 2
(-) Parking Lights:
Blue, pin 1
(+) 12V:
White,
pin 1
6 : Yellow: Parking Light Interr. (conn. side)
16
32 31 30 29 28 27 26 25 24 23 22 21 20 19 18
12456789101112131415
30
86 8587
87a
30
86 85
87
87a
(+)12V
3
17
Cut
Cut
Cut
Start/Stop Unit
(White conn. at
steering column)
Start/Stop Unit
(White conn. at
steering column)
Fuse Box
(White conn.
at drivers kick)
Keyless Data Output: Orange/Black: 3
Keyless Data:
Pink, pin 9
(+) Trunk Release Actuator: White, pin 4
12 3 4
5 6 7 8
ESU (Electrical Supply Unit)
(White conn. at drivers kick)
(+) Trunk Shunt Input: Gray/Black: 5
19 Directed Digital Solutions MA3
© 2018-03-06 Directed. All rights reserved.

Vehicle wiring reference chart
This section provides vehicle wiring information to guide you through the various stages of your installation. Refer to
www.directechs.com for additional information.
Wire Information Connector Information
Function Color Pin Polarity Location Color Pins Ref.
Mazda CX-3 (Smart Key) 2016 - 2018
HS CAN High Green 7 Data Start/Stop unit in steering column. White 24 A
HS CAN Low Red 8 Data Start/Stop unit in steering column. White 24 A
Accessory Pink 2 (+) Start/Stop unit in steering column. White 24 A
Ignition Yellow 10 (+) Start/Stop unit in steering column. White 24 A
Starter Gray 23 (+) Start/Stop unit in steering column. White 24 A
PTS Blue 20 (-) Start/Stop unit in steering column. White 32 B
Ignition 2 Interrupt [3] Pink 3 Cut Start/Stop unit in steering column. White 32 B
Ignition 3 Interrupt [3] Brown 17 Cut Start/Stop unit in steering column. White 32 B
Keyless Data Pink 9 Data Start/Stop unit in steering column. White 32 B
12V White 1 (+) Fuse box in drivers kick. White 1 C
Parking Lights Blue 1 (-) Parking light assembly switch. White 6 D
Parking Lights Interrupt Black 2 Cut Parking light assembly switch. White 6 D
Door Lock [6] Brown 22 MUX BCM bottom left plug. White 32 C
Trunk Release Actuator
[6]
White 4 (+) ESU (Electrical Supply Unit) in drivers kick panel. White 8 E
Trunk Release [7] Red 10 (-) BCM above driver kick panel. White 32 C
20 Directed Digital Solutions MA3
© 2018-03-06 Directed. All rights reserved.
