Toyota HILUX Configuration guide

Applicable to Rugged X
and Rogue Models
Publication No. TSO2001
Issue: 2005-00
Owner’s Manual Supplement
For your safety and comfort, read carefully and keep in the vehicle.

30/04/2020 - Hilux Rugged 30/04/2020 - Hilux Rugged
Hilux_Rugged_Cover.indd, Spread 2 of 2
TOYOTA MOTOR CORPORATION AUSTRALIA LIMITED
A.B.N. 64 009 686 097
© 2020 TOYOTA MOTOR CORPORATION AUSTRALIA LIMITED
All rights reserved. This material may not be reproduced or copied, in whole or part,
without the written permission of Toyota Motor Corporation Australia Limited,
155 Bertie Street, Port Melbourne, Victoria.

Pictorial index Search by illustration
1Driving Operations and advice which are necessary for
driving
2Maintenance Caring for your vehicle and maintenance
procedures
3Vehicle
specications Vehicle specications, etc.
4Index Search alphabetically

2

3TABLE OF CONTENTS
For your information ..................... 4
Reading this manual ..................... 5
Pictorial index ............................... 6
1Driving
1-1. LED Driving lights ............. 9
1-2. Snorkel.............................. 10
1-3. Recovery points ................ 11
1-4. Tow bar ............................. 14
1-5. Sports bar ......................... 15
1-6. Heavy duty rock rails......... 16
1-7. Roller cover and resin
sports bar.......................... 17
1-8 12 volt power socket
- tub..................................22
1-9. Tub tray and tailgate
protection.........................24
1-10. Textile liner .......................25
2Maintenance and care
2-1. Cleaning and protection
of the vehicle
3
3-1. ........29
3-2. Maintenance data .............30
4Index
Vehicle specications
Vehicle specications
26
.....................

4
For your information
Owner’s Manual Supplement
This supplement manual is designed to be read in conjunction with the
main Owner’s Manual. To the extent that information in the main Owner’s
Manual and this Supplement Manual are inconsistent, the information in
this Supplement Manual should be preferred.
Please note that this manual applies to a range of Hilux models and may
include optional equipment, therefore you may nd some sections of this
manual will not apply to your vehicle.
All specications provided in this manual are current at the time of printing.
However, because of the Toyota policy of continual product improvement,
we reserve the right to make changes at any time without notice.
Depending on your vehicle’s specications and optional equipment, the
vehicle shown in the illustrations may dier from your vehicle.

5
Reading this manual
WARNING:
Explains something that, if not obeyed, could cause death or
serious injury to people.
NOTICE:
Explains something that, if not obeyed, could cause damage to or
a malfunction in the vehicle or its equipment.
Indicates operating or working procedures. Follow the steps in
numerical order.
Indicates the action
(pushing, turning, etc.) used
to operate switches and
other devices.
Indicates the outcome of an
operation (e.g. a lid opens).
Indicates the component or
position being explained.
Means “Do not”, “Do not
do this”, or “Do not let this
happen”.

Pictorial index Pictorial index
6Pictorial index
Pictorial index
Exterior: Rugged X
LED Driving lights ..................................................................... 9
Recovery points (Front)............................................................12
Recovery points (Rear) .............................................................13
Tow bar ....................................................................................14
Sports bar ................................................................................15
Snorkel.....................................................................................10
Heavy duty rock rails................................................................16
Tub tray and tailgate protection ............................................. 24

Pictorial index Pictorial index
7Pictorial index
Pictorial index
Exterior: Rogue
Roller cover and resin sports bar..............................................17
12 volt power socket - tub ....................................................... 22
Textile liner ............................................................................. 25

Pictorial index
8Pictorial index
Interior
LED Driving lights switch .......................................................... 9
