Dive Rite LT6078LED-500 User manual

User Product Data Sheet 27FEB08
LT6078LED-500 - LED Flashlight 1 / 4
175 NW Washington Street
Lake City, Florida 32055, USA
Web: www.diverite.com
Phone: [phone]
Fax: [phone]
LT6078LED-500
LED Flashlight
Product description
The LED Flashlight comes fully
assembled and is ready for underwater
use. The light is small, easy to use, and
fits comfortably in your hand. The light
runs on eight standard AA batteries (not
provided). The head of the light rotates to
turn the light on and off. The light can be
used as a primary light for night diving,
wreck diving, and cave diving or it can be carried as a backup light. The light provides
a minimum of 12 hours of burn time when using alkaline batteries.
Specifications
Lens: Flat glass port
Bulb: 3 LEDs (Light Emitting Diodes)
Bulb life: 10 to 15 years if used underwater with water temperatures no warmer than
75 degrees Fahrenheit
Color temperature: 6,500 degrees Kelvin
Light output: >500 lumens per square meter at 10 feet
Size Length: 8 inches (20.3 cm)
Diameter: 1.8 inches (4.5 cm)
Batteries: 8 AA (1.2 V rechargeable NiMH batteries or 1.5 V alkaline batteries) (see
“Battery notes” below)
Weight: 1.35 lbs. (0.8 lbs. in fresh water)
Installing the batteries
Before using the light, the batteries must be installed.
Battery notes
• Use only AA sized 1.2 V rechargeable NiMH batteries or 1.5 V alkaline batteries.
• If using alkaline batteries, Dive Rite recommends using quality batteries, such as
Duracell or Eveready. Do not use the long life type alkalines as they are not
designed for the power demands of the light.
• Do not use mixed lots of batteries.
• All eight batteries should be of the same make and age. Do not mix used
batteries with new batteries.

27FEB08 User Product Data Sheet
2 / 4 LT6078LED-500 - LED Flashlight
To install the batteries:
1. Unscrew the handle of the light where it attaches to the light head.
2. Slide the handle down and off the battery holder.
3. Pull the battery holder out of the light head.
4. Install the batteries as detailed in the battery holder.
5. Ensure that the O-rings are free from dirt and debris.
6. Insert the battery holder into the light head, making sure the contacts at the top of
the battery holder line up with contacts at the base of the light head.
7. Slide the handle over the battery holder until it contacts the light head.
8. Screw the base onto the light head.
Turning the light on and off
Before using the light, make sure the batteries are installed and in good working order.
Caution: The light can be used out of the water. However, exercise caution when
using the light out of the water. The light is designed primarily for use underwater.
Water serves to remove heat from the LEDs. Excessive use out of the water can
shorten the life of the LEDs. If the light head begins to feel exceptionally warm, turn
the light off. Avoid looking directly at the LEDs when the light is turned on.

User Product Data Sheet 27FEB08
LT6078LED-500 - LED Flashlight 3 / 4
To turn the light on and off:
1. Grip the base of the light with one hand.
2. Grip the top of the light with your other hand.
3. Rotate the base clockwise to turn the light on.
Note: Do not turn the base until it comes in contact with the top of the light. This
can damage the battery holder. The light will turn on with just a couple small
rotations of the base.
4. Rotate the base counter-clockwise to turn the light off.
Post dive care
• Inspect the light for any leakage or other damage
• Rinse the light thoroughly in fresh water and allow it to dry
Dealing with a flooded light
Determining if a light is flooded can be as obvious as pouring water out of your
canister or as subtle as seeing a small amount of water in the lens.
What to do: If your light floods, do not continue to use the light. Turn the light off and
disconnect the battery pack. DO NOT TAKE THE LIGHT APART! Arrange with your
dealer to return the light to Dive Rite for repair. Flooding damage cannot be fixed or
corrected in the field. Trying to repair the light in the field can void your warranty.
Warranty information
Dive Rite will—at its sole discretion—repair or replace LED Flashlight components
proved to be damaged by faulty manufacture or material, at no cost, for a period of up
to one year (365 days) from the date of purchase.
This warranty applies only to the original retail purchaser. It does not cover
commercial or rental use, nor does it extend to units purchased from other than an
authorized Dive Rite dealer.
If we deem a LED Flashlight component to be beyond repair — through no fault of the
user — then, and only then, will we replace the affected component(s).
To make a claim under this warranty, the owner must have registered his/her warranty
using Dive Rite’s website (www.diverite.com). All warranty repairs (international or
domestic) must be accompanied by a copy of the purchase receipt. For warranty
repairs (international or domestic) the product must be returned to the store where the
item was purchased or directly to Dive Rite. A Return Authorization must be obtained
by calling Dive Rite corporate offices (386-752-1087) to send items to Dive Rite. No
warranty service will be performed for other than registered owners. Note: Local
dealers and distributors are not responsible for service of items purchased from
unauthorized dealers, internet dealers, or dealers from other territories.
This warranty becomes void if the LED Flashlight components are damaged by
anything other than normal recreational diving use, or if they have been serviced or
repaired by other than authorized Dive Rite dealers.
Repairs made under this warranty will not extend the warranty period.
All further claims, especially for damage after diving accidents, are excluded from
coverage under this warranty.

27FEB08 User Product Data Sheet
4 / 4 LT6078LED-500 - LED Flashlight
Dive Rite has no obligation to honor any extension of this warranty.
This warranty is in lieu of all other warranties, expressed or implied. No other person
or representative is authorized to assume for Dive Rite any other liability in connection
with the sale of this product.
Activating and utilizing your warranty
1. To activate your warranty, you must register your LED Flashlight within 30 days
of purchase through our online product warranty registration. This is located
within our website at www.diverite.com/warranty.
2. Proof of original ownership is provided by your purchase receipt and should be
retained for your records.
3. If you intend to receive your service directly from Dive Rite, you must first obtain
a Return Merchandise Authorization (RMA) number by calling Dive Rite at 386-
752-1087. Your RMA number is to be printed on the address label of your
package.
