Dixon Mower User manual

Operator Manual
Ram Ultra 52, 25 KOH / 966985301
Ram Ultra 61, 25 KOH / 966985401
Ram Ultra 72, 27 KOH / 968999724
Ram Ultra 52, 25 KOH BF / 966985302
Ram Ultra 61, 25 KOH BF / 966985402
Ram Ultra 72, 27 KOH BF / 968999773
Please read the operator’s manual carefully and make sure you
understand the instructions before using the machine.

©2008 HTC. All rights reserved.
Beatrice, NE. Printed in U.S.A.
In order to implement improvements, specications and designs can be altered without prior
notication.
Note that no legal demands can be placed based on the information contained in these instructions.
Use only original parts for repairs. The use of other parts voids the warranty.
Do not modify or install non-standard equipment to the unit without consent from the manufacturer.
Modications to the unit may cause unsafe operations or damage the unit.

CONTENTS
English-3
INTRODUCTION............................................................... 5
Driving and Transport on Public Roads ...................... 5
Towing......................................................................... 5
Operating.................................................................... 5
Good Service.............................................................. 6
Manufacturing Number ......................................... 6
SYMBOLS AND DECALS................................................. 7
SAFETY ............................................................................ 9
Safety Instructions ...................................................... 9
Personal Safety Equipment ...................................... 11
Slope Operation........................................................ 11
Safe Handling of Gasoline........................................ 13
General Maintenance ............................................... 14
Transport .................................................................. 16
CONTROLS .................................................................... 17
Control Locations...................................................... 17
Steering Control Levers............................................ 18
Parking Brake ........................................................... 19
Throttle Control......................................................... 19
Blade Switch............................................................. 19
Ignition Switch........................................................... 20
Choke Control........................................................... 20
Fuses........................................................................ 20
Fuel Tank .................................................................. 21
Fuel Shut Off Valve................................................... 22
Cutting Height Adjuster............................................. 22
Hour Meter................................................................ 23
OPERATION ................................................................... 24
Training..................................................................... 24
Steering .................................................................... 24
Before Starting.......................................................... 25
Starting the Engine ................................................... 25
Weak Battery ............................................................ 27
Jumper Cables.................................................... 27
Running .................................................................... 28
Operating On Hills .................................................... 29
Mowing Tips ............................................................. 30
Stopping the Engine ................................................. 31
Moving by Hand........................................................ 32
Pump Release Valves......................................... 32
MAINTENANCE.............................................................. 33
Maintenance Schedule ............................................. 33
Battery ...................................................................... 35
Ignition System ......................................................... 36
Safety System........................................................... 36
Engine Cooling Air Intake ......................................... 37
Throttle Cable ........................................................... 37
Choke Cable ............................................................ 37
Air Filter .................................................................... 38
Fuel Filter.................................................................. 39
Fuel Pump Air Filter .................................................. 39
Tire Pressures .......................................................... 40
Parking Brake ........................................................... 40
V-belts....................................................................... 40
Deck Belt............................................................. 41
Pump Belt ........................................................... 42
Cutting Blades .......................................................... 42
Blade Replacement............................................. 43
Adjusting the Mower Deck........................................ 44
Leveling............................................................... 44
Cutting Height ..................................................... 44
Anti-Scalp Rollers ............................................... 45
Cleaning.................................................................... 46
Caster Wheels .......................................................... 46
Hardware .................................................................. 46
LUBRICATION ................................................................ 47
Cables................................................................. 48
Front Wheel Mount ............................................. 48
Front Wheel Bearings ......................................... 48
Deck Spindle....................................................... 48
Deck Outer Spindle............................................. 49
Engine Oil ................................................................. 49
Changing the Engine Oil..................................... 50
Engine Oil Levels................................................ 50
Hydraulic Pump ....................................................... 51
Fluid Change....................................................... 51
Purging ............................................................... 51
TROUBLESHOOTING.................................................... 52
STORAGE....................................................................... 54
Winter Storage.......................................................... 54
Service...................................................................... 54
SCHEMATICS................................................................. 55
TECHNICAL DATA.......................................................... 56
Accessories .............................................................. 58
Torque Specications................................................ 58
CONFORMITY CERTIFICATES ..................................... 59
WARRANTY.................................................................... 60
SERVICE JOURNAL....................................................... 61

WARNING!
Failure to follow cautious operating practices can result in serious injury to the
operator or other persons. The owner must understand these instructions, and must
allow only trained persons who understand these instructions to operate the mower.
Each person operating the mower must be of sound mind and body and must not be
under the inuence of any mind altering substance.
English-4
WARNING!
Engine exhaust, some of its constituents, and certain vehicle components contain or
emit chemicals known to the State of California to cause cancer and birth defects or
other reproductive harm.
WARNING!
Battery posts, terminals and related accessories contain lead and lead compounds,
chemicals known to the State of California to cause cancer and birth defects or other
reproductive harm. Wash hands after handling.

INTRODUCTION
Dixon-5
Congratulations
Thank you for purchasing a Dixon ride-on mower. This
machine is built for superior efciency to rapidly mow
primarily large areas. A control panel easily accessible
to the operator and a hydrostatic transmission
regulated by steering controls both contribute to the
machine’s performance.
This manual is a valuable document. Read the
contents carefully before using or servicing the
machine. The following of instructions (use, service,
maintenance) by all who operate this machine is
important for the safety of the operator and others.
It can also considerably increase the life span of the
machine and increase its resale value.
If you sell your machine, be sure to give the operator’s
manual to the new owner.
The nal chapter of this operator’s manual provides a
Service Journal. Ensure that service and repair work
are documented. A well-kept service journal reduces
service costs for the maintenance and affects the
machine’s resale value. Please contact your dealer for
more information. Take the operator’s manual along
when the machine is taken to your dealer for service.
General
In this operator’s manual, left and right, backward and
forward are used in relation to the machine’s normal
driving direction.
Continuous dedication to improve our products require
that specications and design are subject to change
without notice.
Driving and Transport on Public Roads
Check applicable road trafc regulations before
transporting on public roads. If the machine is
transported, you must always use approved fastening
equipment and ensure that the machine is well
anchored. DO NOT operate this machine on public
roadways.
Towing
If machine is equipped with a tow hitch, use extreme
caution when towing. Never allow children or others in
or on the towed equipment. Make wide turns to avoid
jack-kning. Travel slowly and allow extra distance to
stop.
Do not tow on sloped ground. The weight of the towed
equipment may cause loss of traction and loss of
control.
Follow the manufacturer's recommendation for weight
limits for towed equipment. Do not tow near ditches,
canals, and other hazards.
Operating
This machine is constructed only for mowing grass
on lawns and even ground without obstacles such
as stones, tree stumps, etc. The machine can also
be used for other tasks when equipped with special
accessories provided by the manufacturer. Operating
instructions for the accessories are provided with
delivery. All other types of uses are incorrect. The
manufacturer’s directions concerning operation,
maintenance, and repairs must be carefully followed.
Lawn mowers and all power equipment, can be
potentially dangerous if used improperly. Safety
requires good judgement, careful use in accordance
with these instructions and common sense.
The machine must only be operated, maintained, and
repaired by persons familiar with the machine’s special
characteristics and who are also knowledgeable about
the safety instructions. Use only approved repair parts
to maintain this machine.
Accident prevention regulations, other general safety
regulations, occupational safety rules, and trafc
regulations must be followed without fail.
Unauthorized modications to the design of the
machine may absolve the manufacturer from liability
for any resulting personal injury or property damage.

INTRODUCTION
6-Dixon
Good Service
Dixon’s products are sold only in specialized retail stores with complete service. This ensures that you as
a customer receive only the best support and service. Before the product is delivered, the machine has, for
example, been inspected and adjusted by your retailer. See the certicate in the Service Journal in this operator’s
manual.
When you need spare parts or support in service questions, warranty issues, etc., please consult the following
professional:
Manufacturing Number
The machine’s manufacturing number can be found on the printed plate afxed to the right side in the engine
compartment. Stated on the plate, from the top are:
The machine’s type designation (I.D.).
The manufacturer’s type number (Model).
The machine’s serial number (Serial no.)
Please have the type designation and serial number available when ordering spare parts.
The engine’s manufacturing number is stamped on one of the valve covers.
The plate states:
The engine’s model.
The engine’s type.
Code
Please have these available when ordering spare parts.
The wheel motors and hydrostatic pumps have a barcode decal afxed at the rear.
This Operator’s Manual belongs to the machine with
the manufacturing number:
Engine Transmission

SYMBOLS AND DECALS
Dixon-7
These symbols are found on the machine and in the operator’s manual.
Study them carefully so that you know what they mean.
Used in this publication to notify the reader of a risk of personal injury or death, particularly if the reader should
neglect to follow instructions given in the manual.
Used in this publication to notify the reader of a risk of material damage, particularly if the reader should neglect
to follow instructions given in the manual. Used also when there is a potential for misuse or misassembly.
WARNING!
Xxxx xxxxxx xxxxx xxxx
xxxxxxxxx xxxxxx xxxxxxxxx. xx
xxxxxxxx xxxx xxxxxx.
IMPORTANT INFORMATION
Xxxx xxxxxx xxxxx xxxx xxxxxxxxx xxxxxx
xxxxxxxxx. xx xxxxxxxx xxxx xxxxxx.
R N
Reverse Neutral Fast Slow Choke Fuel
Warning! Parking Brake CE conformity Warning! Rotating blades, Do not touch parts
marking. Only for keep away from the
European market discharge deck
Battery acid is corrosive, explosive and ammable Do not stand here
Noise emissions to the
surroundings in accordance with
the European Union’s directive.
The machine’s emission is stated
in the chapter TECHNICAL DATA
and on the decals.
Only machines for European
market
Use protective glasses Use protective gloves

SYMBOLS AND DECALS
8-Dixon
Read Shut off engine and Keep a safe Use on slopes No passengers
Operator’s remove key before distance from no greater
Manual performing any the machine than 10°
maintenance or repair work
Whole body Severing of ngers Do not open or Careful backing up, Careful going
exposure to and toes remove safety watch for other forward, watch for
thrown objects shields while people other people
engine is running
Moving sharp blades under cover

SAFETY
Dixon-9
Safety Instructions
These instructions are for your safety. Read them carefully.
IMPORTANT: THIS CUTTING MACHINE IS CAPABLE OF AMPUTATING HANDS AND FEET AND THROWING
OBJECTS. FAILURE TO OBSERVE THE FOLLOWING SAFETY INSTRUCTIONS COULD RESULT IN
SERIOUS INJURY OR DEATH.
General Operation
Read, understand, and follow all instructions on•
the machine and in the manual before starting.
Do not put hands or feet near rotating parts or•
under the machine. Keep clear of the discharge
opening at all times.
Only allow responsible adults, who are familiar•
with the instructions, to operate the machine.
Clear the area of objects such as rocks, toys, wire,•
etc., which could be picked up and thrown by the
blades.
Be sure the area is clear of bystanders before•
operating. Stop machine if anyone enters the area.
Never carry passengers. The machine is only•
intended for use by one person.
Do not mow in reverse unless absolutely•
necessary. Always look down and behind before
and while backing.
Never direct discharged material toward anyone.•
Avoid discharging material against a wall or
obstruction. Material may ricochet back toward the
operator. Stop the blades when crossing gravel
surfaces.
Do not operate machine without the entire grass•
catcher, discharge guard, or other safety devices
in place and working
Slow down before turning.•
Never leave a running machine unattended.•
Always turn off blades, set parking brake, stop
engine, and remove keys before dismounting.
Disengage blades when not mowing. Shut off•
engine and wait for all parts to come to a complete
stop before cleaning the machine, removing the
grass catcher, or unclogging the discharge guard.
Operate machine only in daylight or good articial •
light.
Do not operate the machine while under the•
inuence of alcohol or drugs.
8011-512
Read the operator’s manual before starting the machine
8011-513
Clear the area of objects before mowing
WARNING!
This symbol means that important safety instructions need to be emphasized. It concerns
your safety.

SAFETY
10-Dixon
8011-520
Never take passengers
Watch for trafc when operating near or crossing •
roadways.
Use extra care when loading or unloading the•
machine into a trailer or truck.
Always wear eye protection when operating•
machine.
Data indicates that operators age 60 years and•
above are involved in a large percentage of riding
mower-related injuries. These operators should
evaluate their ability to operate the riding mower
safely enough to protect themselves and others
from serious injury.
Follow the manufacturer’s recommendation for•
wheel weights or counterweights.
Anyone who operates this machine must rst read •
and understand this Operation Manual. Local laws
may regulate the age of the user.
Keep machine free of grass, leaves or other debris•
buildup which can touch the hot exhaust or engine
parts and burn. Do not allow the mower deck to
plow leaves or other debris, causing buildup to
occur.
Clean any oil or fuel spillage before operating or•
storing the machine.
Allow machine to cool before storage.•
WARNING!
Engine exhaust and certain vehicle
components contain or emit
chemicals considered to cause
cancer, birth defects, or other
reproductive system damage. The
engine exhaust contains carbon
monoxide, which is a odorless,
colorless, poisonous gas. Do not use
the machine in enclosed spaces.

SAFETY
Dixon-11
Personal Safety Equipment
8011-670a
Personal protective equipment
6003-004
Mow up and down, not side to side
Make sure that you have rst aid equipment close •
at hand when using the machine.
Never use the machine when barefoot.•
Always wear protective shoes or boots, preferably•
with steel toe caps.
Always wear approved protective glasses or a full•
visor when assembling or driving.
Always wear gloves when handling the blades.•
Never wear loose clothing that can get caught in•
moving parts.
Use ear protectors to avoid damage to hearing.•
Slope Operation
Slopes are a major factor related to loss of control and
tip-over accidents, which can result in severe injury or
death. Operation on all slopes requires extra caution. If
you cannot back up the slope or if you feel uneasy on
it, do not mow it.
Mow up and down slopes (10 degrees maximum),•
not across.
Watch for holes, ruts, bumps, rocks, or other•
hidden objects. Uneven terrain could overturn the
machine. Tall grass can hide obstacles.
Choose a low ground speed so that you will not•
have to stop while on the slope.
Do not mow on wet grass. Tires may lose traction.•
Avoid starting, stopping, or turning on a slope. If•
the tires lose traction, disengage the blades and
proceed slowly straight down the slope.
Keep movement on the slopes slow and gradual.•
Do not make sudden changes in speed or
direction, which could cause machine to roll over.
Use extra care while operating machine with grass•
catchers or other attachments; they can affect the
stability of the machine.
Do not use on steep slopes.•
Do not try to stabilize the machine by putting a foot•
on the ground.
Do not mow near drop-offs, ditches, or•
embankments. The machine could suddenly roll
over if a wheel is over the edge or if the edge
caves in.
WARNING!
When using the machine, approved personal protective equipment (shown in illustrations)
shall be used. Personal protective equipment cannot eliminate the risk of injury but it
will reduce the degree of injury if an accident does happen. Ask your retailer for help in
choosing the right equipment.
WARNING!
Do not drive up or down hills with
slopes greater than 10 degrees. And
do not drive across any slopes.

SAFETY
12-Dixon
8011-509
Be extra cautious when driving on slopes
8011-517
Never allow children to operate the machine
8011-518
Keep children away from work area
Children
Tragic accidents can occur if the operator is not
alert to the presence of children. Children are often
attracted to the machine and the mowing activity.
Never assume that children will remain where you last
saw them.
Keep children out of the mowing area and in the•
watchful care of a responsible adult other than the
operator.
Be alert and turn machine off if a child enters the•
area.
Before and while backing, look behind and down•
for small children.
Never carry children, even with the blades shut•
off. They may fall off and be seriously injured or
interfere with safe machine operation. Children
who have been given rides in the past may
suddenly appear in the mowing area for another
ride and be run over or backed over by the
machine.
Never allow children to operate the machine.•
Use extra care when approaching blind corners,•
shrubs, trees, or other objects that may block your
view of a child.

SAFETY
Dixon-13
Safe Handling of Gasoline
To avoid personal injury or property damage, use
extreme care in handling gasoline. Gasoline is
extremely ammable and the vapors are explosive.
Extinguish all cigarettes, cigars, pipes, and other•
sources of ignition.
Use only approved gasoline container.•
Never remove gas cap or add fuel with the engine•
running. Allow engine to cool at least two (2)
minutes before refueling.
Never fuel the machine indoors.•
Never store the machine or fuel container where•
there is an open ame, spark, or pilot light such as
on a water heater or other appliance.
Before you begin refueling, minimize the risk of•
static electricity by touching a metal surface.
Never ll containers inside a vehicle or on a •
truck or trailer bed with plastic liner. Always place
containers on the ground away from the vehicle
when lling.
Remove gas-powered equipment from the truck•
or trailer and refuel it on the ground. If this is not
possible, refuel such equipment with a portable
container, rather than from a gasoline dispenser
nozzle.
Keep the nozzle in contact with the rim of the fuel•
tank or container opening at all times until fueling
is complete. Do not use a nozzle lock-open device.
If fuel is spilled on clothing, change clothing•
immediately.
Never overll fuel tank. Replace gas cap and •
tighten securely.
Do not start the engine near spilled fuel.•
Never use gasoline as a cleaning agent.•
If leaks arise in fuel system, engine must not be•
started until problem has been resolved.
Check the fuel level before each use and leave•
space for the fuel to expand, as the heat from the
engine and the sun may otherwise cause the fuel
to expand and overow.
8011-516
Never ll the fuel tank indoors
WARNING!
The engine must not be started when the driver’s oor plate or any protective plate for the
mower deck’s drive belt is removed.
WARNING!
The engine and the exhaust system
become very hot during operation.
There is risk for burns if touched.
Allow engine and exhaust system to
cool at least two (2) minutes before
refueling.

SAFETY
14-Dixon
8011-515
Never drive the machine in an enclosed space
General Maintenance
Never operate machine in a closed area.•
Keep all nuts and bolts tight to be sure the•
equipment is in safe working condition.
Never tamper with safety devices. Check their•
proper operation regularly.
Keep machine free of grass, leaves, or other•
debris buildup. Clean oil or fuel spillage and
remove any fuel-soaked debris. Allow machine to
cool before storing.
If you strike a foreign object, stop and inspect the•
machine. Repair, if necessary, before restarting.
Never make any adjustments or repairs with the•
engine running.
Check grass catcher components and the•
discharge guard frequently and replace with
manufacturer’s recommended parts, when
necessary.
Mower blades are sharp. Wrap the blade or wear•
gloves, and use extra caution when servicing
them.
Check brake operation frequently. Adjust and•
service as required.
Maintain or replace safety and instruction labels,•
as necessary.
Do not modify safety equipment. Check regularly•
to be sure it works properly. The machine must not
be driven with defective or unmounted protective
plates, protective cowlings, safety switches, or
other protective devices.
Do not change the settings of governors and avoid•
running the engine with overly high engine speeds.
If you run the engine too fast, you risk damaging
the machine components.
Be very careful when handling battery acid. Acid•
on skin can cause serious corrosive burns. If you
spill battery acid on your skin, rinse immediately
with water.
Acid in the eyes can cause blindness, contact a•
doctor immediately.
Be careful when servicing the battery. Explosive•
gases form in the battery. Never perform
maintenance on the battery when smoking or near
open ames or sparks.
The battery can explode and cause serious injury•
or damage.
Ensure that nuts and bolts, especially the•
fastening bolts for the blade attachments, are
properly tightened, torqued and that the equipment
is in good condition.
WARNING!
The battery contains lead and lead
compounds, chemicals that are
considered to cause cancer, birth
defects, and other reproductive
system damage. Wash your hands
after handling the battery.
WARNING!
Use protective glasses for
maintenance work.

SAFETY
Dixon-15
Sparking can occur when working with the battery•
and the heavy cables of the starter circuit. This
can cause battery explosion, re or eye injury.
Sparking in this circuit can not occur after the
chassis cable (normally negative, black) is
removed from the battery.
Use protective goggles.•
Ensure that the fuel ller cap is mounted tightly •
and no ammable substances are stored in an
open vessel.
Never work with the starter circuit if there is spilled•
fuel.
Disconnect the chassis cable from the battery rst •
and reconnect it last.
Do not make a bridge short circuit across the•
starter relay to run the starter.
Never use the machine indoors or in spaces•
lacking proper ventilation. The exhaust fumes
contain carbon monoxide, an odorless, poisonous,
and lethal gas.
Stop to inspect the equipment if you run over or•
into anything. If necessary, make repairs before
starting.
Never make adjustments with the engine running.•
The machine is tested and approved only with the•
equipment originally provided or recommended by
the manufacturer. Only use approved repair parts
for the machine.
The blades are sharp and can cause cuts and•
gashes. Wrap the blades or use protective gloves
when handling them.
Check the parking brake’s functionality regularly.•
Adjust and service as necessary.
The mulch blades should only be used in familiar•
areas when higher quality mowing is desired.
Reduce the risk of re by removing grass, leaves, •
and other debris that may have accumulated on
the machine.
Allow the machine to cool before putting it in•
storage.
Regularly clean deck and underside of deck, avoid•
spraying engine and electrical components with
water.
6003-009
Do not smoke when performing maintenance on the battery.
The battery can explode and cause serious injury/damage.
8009-728
Risk of sparking
WARNING!
Avoid electrical sparking and its
consequences by the following
routines:

SAFETY
16-Dixon
IMPORTANT INFORMATION
The parking brake is not sufcient to lock the
machine in place during transport. Ensure that
the machine is well fastened to the transport
vehicle. Always reverse the machine onto the
transport vehicle to avoid tipping it over.
8011-514
Regularly clean deck
WARNING!
Escaping hydraulic oil under
pressure can have sufcient force
to penetrate the skin, causing
serious injury. If injured by escaping
uid, see a doctor at once. Serious
infection or reaction can develop
if proper medical treatment is not
administered immediately.
Transport
The machine is heavy and can cause serious•
crushing injuries. Be extra cautious when it is
loaded on or unloaded from a vehicle or trailer.
Use an approved trailer to transport the machine.•
Activate the parking brake, turn off the fuel supply,
and fasten the machine with approved fastening
devices, such as bands, chains, or straps, when
transporting.
Do not operate this machine on public roadways.•
Check and abide by local trafc regulations before •
transporting the machine on any road.
Do not tow this machine, it may cause damage to•
the drive system.
Do not tow any trailers, etc. with this mower. They•
may jackknife or overturn causing damage to the
mower and possibly serious injury to the operator.
Load the unit onto truck or trailer by driving up•
ramps of suitable strength using a slow speed. Do
not lift! The machine is not intended to be lifted by
hand.
WARNING!
This mower is equipped with an
internal combustion engine and
should not be used on or near any
unimproved forested, bush covered
or grassy lands unless the engine's
system is equipped with a spark
arrester meeting applicable local or
state laws (if any). If a spark arrester
is used, it should be maintained
in effective working order by the
operator.

CONTROLS
Dixon-17
This operator’s manual describes the Dixon Zero
Turn Rider. The rider is tted with a Kohler four-
stroke overhead valve engine developing 25-27 horse
power*.
Control Locations
Motion control levers1.
Parking brake2.
Throttle control3.
Blade switch4.
Ignition switch5.
Choke control6.
1
2
6
10
9 8
45
12
7
3
11
Fuses7.
Fuel tank cap8.
Fuel shut off valve9.
Deck lift10.
Seat adjustment lever11.
Hour meter12.
Transmission from the engine is made via a belt-driven
hydraulic pumps. Using the left and right steering
controls, the ow is regulated and thereby the direction
and speed.
*As rated by the engine manufacturer.

CONTROLS
18-Dixon
8011-789
Steering controls
Steering Control Levers
The machine’s speed and direction are continuously
variable using the two steering controls. The steering
controls can be moved forward or backward about
a neutral position. Furthermore, there is a neutral
position, which is locked if the steering controls are
moved outward.
When both controls are in the neutral position (N), the
machine stands still.
By moving both controls an equal amount forward
or backward, the machine moves in a straight line
forward or backward respectively.
In order, for example, to turn right while moving
forward, move the right control towards the neutral
position. The rotation of the right wheel is reduced and
the machine turns to the right.
Zero turn can be achieved by moving one control
backward (behind the neutral position) and carefully
moving the other steering control forward from its
neutral position. The rotation direction when zero
turning is determined by which steering control is
moved backward behind the neutral position. If the left
steering control is pulled backward, the machine turns
to the left. Use extra care when using this maneuver.
If the steering controls are in uneven positions when
standing still or do not t in the slots for moving the
controls outward, they can be adjusted.
8011-7912
1. Forward
2. Neutral
3. Neutral slot, Neutral lock
4. Reverse
Motion control lever, right side
WARNING!
The machine can turn very rapidly if
one steering control is moved much
further forward than the other.

CONTROLS
Dixon-19
Parking Brake
8061-019
Parking brake not activated
IMPORTANT INFORMATION
The machine must stand absolutely still when
applying the parking brake. Always set the
parking brake before dismounting. Release the
parking brake before moving the mower.
Blade Switch
In order to engage the mower deck, pull the knob out;
the mower blades are disengaged when the knob is
depressed.
Throttle Control
The throttle control regulates the engine speed and
thereby the rate of rotation of the blades, assuming the
blade switch is pulled out, see Engaging the Mower
Deck.
In order to increase or decrease the engine speed, the
control is moved forward or back respectively.
Avoid idling the engine for long periods, as there is a
risk of fouling the spark plugs.
USE FULL THROTTLE WHEN MOWING, for best
mower performance and battery charging.
8061-017
Throttle control
8061-017
Blade switch
The parking brake is found on the left of the machine.
Pull the lever backward to activate the brake and
forward to release it.

CONTROLS
20-Dixon
Ignition Switch
The ignition key is placed on the control panel and is
used to start and stop the engine.
Fuses
Fuses are located on the left hand side of the machine.
They are accessed by tilting the seat forward. They are
at pin fuses of the same type used in automobiles.
There are two fuses with ratings and functions:
20 A, Primary fuse.•
7.5 A, Mower deck coupling.•
8061-017
Ignition switch
8061-017
Choke control
Choke Control
The choke control is used for cold starts in order to
provide the engine with a richer fuel mixture.
For cold starts the control should be pushed to the ON
position.
8011-420
Fuses
