DKS microPLUS User manual

Interference Information
This equipment may interfere with radio communications, AM/FM radio and
TV reception. Use the following suggestions to correct the interference:
FCC Compliance
This device will provide reliable remote access control. Be aware of the
following limitations:
• Relocate the receiving antenna.
• Increase the space between the equipment and transmitter receiver.
• Connect the equipment into another outlet, different from the
transmitter receiver.
• Consult a technician for help.
DoorKing’s transmitters are ideal for applications that require RF wireless
access. Users can remain comfortably inside their vehicle while activating
the RF transmitter without having to use a keypad or card reader. When
activated, a data stream is sent to the remote SuperHet receiver. This data
includes the transmitter serial number, facility code, and button code. In
addition MicroPLUS transmitters have an encrypted sync-code that changes
each time the transmitter is used.
This equipment has been certified to comply with the limits for a class B
computing device, pursuant to FCC Rules. To maintain compliance with FCC
regulations, shielded cables must be used with this equipment. Operation
with non-approved equipment or unshielded cables may result in
interference to radio and TV reception.
This Class [B] digital apparatus meets all requirements of the Canadian
Interference Causing Equipment Regulations. Cet appareil numrique de la
classe [B] respecte toutesles exigences du Reglement sur le materiel
brouilleur du Canada.
•
•
•
microPLUS / microCLICK - transmitters
1Button 2Button 3Button
This device complies with FCC Rules and Regulations, Part 15 and
Canadian Interference Causing Equipment Regulations. Because of
this, they have limited transmitter power and limited range.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received, including
interference that may cause undesired operation.
The receiving device cannot respond to more than one transmitted
signal at a time. Radio signals near the receiver operating frequency
may block the transmitter signal regardless of the code setting. If
this occurs, the radio receiver may have to be repositioned.
Any changes or modifications may
void compliance with FCC Rules
and Regulations.
