DLP S200 User manual

QUICK GUIDE
LOCATION OF PARTS AND CONTROLS
1: Lens
2: Air outlet
3: Up
4: Confirm
Return(press more than 2 seconds)
5: Right
6: Left
7: Down
8: Power indicator
9: Audio output(3.5mm)
10: USB input/Power out
11: HDMI input
12: DC input (15V/1.5A)
LOCATION OF PARTS AND CONTROLS
1: Power
2: Speaker
3: Air inlet
4: Tripod dock
5: Rating Label
6: Non-slip mat
7: Focus wheel
8: Speaker
1 2
3
4
5
6
7 8
REMOTE CONTROL
The 2.4G wireless remote control must be paired with projector before using.
Within 2 minutes after power on, press and hold the Vol+ and Vol- around 3
seconds，then the indicator light in the remote will be flashing quickly, when the
quick flashing stopped, it will pair successfully.
12
3
4
5
6
7
8
9 10 11 12
15V
HDMIUSBAUDIO
R
AAA Battery
Volume
Power off Home
Confirm
Direction Key
Menu
Mouse
Return
Indicator
This device complies with Part 15 of the FCC rules. Operation is subject to the
following two conditions: 1) this device may not cause harmful interference, and 2)
this device must accept any interference received, including interference that may
cause undesired operation.
Note: This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
--Reorient or relocate the receiving antenna.
--Increase the separation between the equipment and receiver.
--Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
--Consult the dealer or an experienced radio/TV technician for help.
Changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
Radiation Exposure Statement
This device complies with RF radiation exposure limits set forth for an
uncontrolled environment. This transmitter must not be co-located or operating in
conjunction with any other antenna or transmitter.
FCC StatementFCC Statement
IC Note:
This device complies with Industry Canada's licence-exempt RSSs. Operation is
subject to thefollowing two conditions:
(1) This device may not cause interference; and
(2) This device must accept any interference, including interference that may
cause undesired operation of the device.
Cet appareil est conforme aux CNR exemptes de licence d'Industrie Canada . Son
fonctionnement est soumis aux deux conditions suivantes :
(1) Ce dispositif ne peut causer d'interférences ; et
(2) Ce dispositif doit accepter toute interférence , y compris les interférences
qui peuvent causer un mauvais fonctionnement de l'appareil.
Projector
S200
AOME

Devices with HDMI
port
Devices with mini
HDMI port
Devices with micro
HDMI port
★ HDMI to HDMI cable (included)
★ HDMI to HDMI cable★ Mini HDMI to HDMI adapter
★ HDMI to HDMI cable★Micro HDMI to HDMI adapter
1
2
3
USB DRIVE INPUT
Insert the USB drive to the USB port, then the projector can read the video or
other files directly.
USB-C
USB-C
iOS devices with
lightning port
Devices with USB-C
(USB type C) port
Devices with USB-C
(USB type C) port
★ HDMI to HDMI cable★Lightning digital AV adapter
★ HDMI to HDMI cable★USB-C to HDMI adapter
★USB type C to HDMI cable
4
5
6
15V
HDMIUSBAUDIO
R
The products don’t include any HDMI adapter
POWER OUT
When the projector is power on, connect the charging cable of your device to the
projector’s USB port, and then the projector turned into a power bank, it can
charge your mobile devices, and the output is 5V/1A.
AUDIO OUT
The projector build in 2 speakers for normal use, but it can output the audio also,
Plug the earphone or line-in cable of speaker to the projector’s 3.5mm AUDIO OUT
port as below image.
+
Earphone Speaker
15V
HDMIUSBAUDIO
R
POWER BUTTON
Press and hold the switch button 3 seconds both for turn on and turn off.
The main menu of the projector will display the remaining capacity of battery.
CHARGING
Please use the original charger, and fully charge the battery when first use.
FOCUS ADJUSTMENT
Simply roll the focus wheel control up and down to adjust the clarity of the
projected image.
ADAPTER
15V/1.5A
15V
HDMIUSBAUDIO
R
INDICATOR LED:
1, RED LED flashing: Battery Low.
2, RED LED on: In charging.
3, White LED on: Completed charging.
2, Stream mirroring(DLNA):
Connect wifi to the internet, and open the DLNA, then the projector will be ready
for connecting, The projector name is ‘Projector’.
NOTE: Be sure the video APPS or web support DLNA, such as youtube...
Screen Mirroring
PRO-XXXX is waiting for the connection
SCREEN MIRRORING
1, Screen mirroring (Miracast):
Turn on the wifi, and open the Miracast, then connect your Android device to the
projector, The projector name is ‘PRO-XXXX’.
NOTE: Be sure your device support Miracast.
DLNA Stream mirroring
Projector is waiting for the connection
HDMI input
Connect the device to the projector by HDMI cable, HDMI can work directly.
The projector can be connected to a variety of HDMI compatible devices via a
wired connection, such as laptop, smart phone, tablets, PSP, etc.
NOTE: Some devices may require an adapter to connect to your device.
To determine what type of adapter you need to use, please reference the
compatibility list of below. (For example, iPhone or iPad need a Lighting
to HDMI AV adapter as below.)
15V
HDMIUSBAUDIO
R
