DLS CD ONE User manual
Owner’s Manual
DLS CD ONE
Audio for Life
The information contained in this manual is subject to
change without prior notice. The most current version of
this manual is available on our official website at:
www.dls.se
Copyright c DLS Svenska AB. All rights reserved
Copyright c DLS Svenska AB. All rights reserved
Table of Contents
Congratulations ………………….........
1
Unpacking ……………………………....
1
Quick setup guide …...........................
1
Introduction ………………………….....
2
Installation and placement …………..
2
Cleaning ………………………………...
2
Front panel controls …………………..
3
Rear panels connections …………….
4
Remote control ………………………...
5
Operating ………………………………..
6
Warranty ………………………………...
7
Obtaining service …………………......
7
Troubleshooting ……………………….
8
Your own notes....................................
9
Technical specifications
Analogue outputs:
1 pair balanced (XLR), 2 pair unbalanced
(RCA)
Digital outputs:
1 set coaxial 75 Ohm (RCA),
1 set optical (TOSlink)
Signal to noise ratio:
> 112 dB
Harmonic distortion (THD):
< 0,005% at 1 kHz
Channel separation:
>110 dB
AC power requirements*:
120 V / 240 V, 50 - 60 Hz
Power consumption:
16 W
Power consumption in Standby:
7 W
Dimensions (WxDxH):
432 x 432x 128 mm (17 x 17 x 5,04 inches)
Weight:
6,8 Kg (15 lbs)
This product must be returned to the separate col lec tion
system for electronic products. Do not dis po se this pro-
duct together with general household waste.
Marking by the ”CE” symbol indicates compliance of this
device with the EMC (Electromagnetic Compatibility) and
LVD (Low Voltage Directive) standards of the European
Community
*Connect the CD ONE only to an AC source of the
proper voltage. A label on the rear panel will indicate the
correct voltage. Use of any other voltage will damage
the unit and void the warranty
Congratulations!
Thank you for selecting the DLS CD ONE as a part of your music system.
When we designed this CD-player, we decided to enter with ”A Big Bang”. This CD has a high-tech
interior, but a ”no-nonsense”, user-friendly exterior.
The CD-player has been designed and assembled by highly skilled DLS craftsmen to offer state-
of-the-art high-end performance in a luxury elegant package.
We have spared no effort to ensure that it is one of the finest CD-player available in its class. We
hope you enjoy listening to the CD ONE as much as the pride we have taken in creating this audio
product.
Before setting up your CD ONE, please read this manual thoroughly to assure
yourself with its features.
Unpacking
The DLS CD ONE should be removed from its box with care.
The following accessories should be included inside the box with your
CD ONE
:
1.
R4U remote control
2.
Two ”AAA” batteries
3.
AC power Cable
4.
This owner’s manual
As soon as the CD player is safely removed from its box, perform a thorough physical inspection
and report any damage to your dealer
immediately
.
immediately. immediately
We suggest that you keep all of the original
packaging, storing it in a safe, dry place in the event that you’re required to transport the CD
player.
Please write the serial number of the CD ONE (on rear panel) in the space provided below for
future reference:
Serial No:_______________________________________________
Date of purchase:_________________________________________
Dealers name:___________________________________________
Quick setup
- Carefully unpack your CD ONE.
- Connect the AC cable to the CD player and to an AC wall outlet. Make sure you connect to
the proper voltage marked on your amplifier.
- Connect your CD player to the amplifier.
- Switch the main switch (at the back panel on CD player) to ”ON”. (Wait during the ”Warming-up”
period has been done.)
- Switch the ”Standby” knob (at the front panel) to ”ON”.
- Press the ”Play button” and ENJOY! During your first listening session, please read this manual
thoroughly to properly acquaint yourself with its features.
1
Introduction
A ”BURN-IN” or ”BREAK-IN” period is required before the CD player will reach its maximum sonic
potential.
The performance of your CD ONE will continue to improve during the first 200 hours of listening.
A ”Burn-in” period is required for the numerous high quality electronic parts used in this CD player.
We recommend the CD player to be left on Repeat mode during the first week when the CD player
is out of use for active listening sessions. This will speed up the ”burn-in” process.
If the CD ONE is unused it automaticly goes to stand-by mode after 5 minutes to save the laser
unit. The CD-player should not be switched off by using the main switch at the rear panel, unless it
will be out of use for a significant period of time during vacations etc.
Installation and Placement
The CD ONE requires reasonable ventilation to maintain an optimum and consistent operating
temperature. As a result, it should be placed in a location with empty space around it for proper
heat dissipation. As well, it should be placed on a solid level surface. You should never place the
CD player to near heat sources such as radiators, stoves, fireplaces or other heat-producing app-
liances or inside a closed cabinet. Avoid placing the CD player where it will be subjected to direct
sunlight or extremely low temperature. Avoid placing the CD player near electromagnetic fields,
such as large power amplifiers etc. Placement of the unit near these fields can lead to problems
with hum.
Cleaning
To clean the CD ONE, use only a soft tissue. Never apply abrasive cleaners to the surfaces of the
unit.
At no time should liquid cleaners be applied directly to the CD ONE, as direct application of liquids
may result in damage to electronic components within the unit.
2
Front panel controls
On the front panel you have six push button knobs. These six controls let you operate your CD
ONE in daily use, or if you prefer, use the remote control R4U which is included.
1. Standby
Turn the CD player to ON mode. (Turns Off automatically)
2. Play (and Pause)
To start playback, press once. To Pause a playing disc, press Play
again. To start playing a disc after pause, press Play again
3. Next
Step to the next track
4. Prev
Restart the current track, or step to the previous track
5. Stop
Stop playing disc
6. Display
Shows all disc related information; track/chapter numbers, time of
tracks/chapter/discs, type of media; CD and SACD
7. Open
Open and close the drawer
3
1
7
2
3
4
5
6
Rear panel connections
1. Mains Power Input and Fuse
Plug the AC cord firmly into the AC jacket.
Make sure
you connect to the proper voltage marked on your
amplifier.
Connect the male end directly to an AC wall outlet.
Avoid use of an extension cord or power split since these
often degrade sound quality .
The mains power turns the CD totally off.
In the fuse box you will also find a spare main fuse.
Please check that it is the same value before switching.
2. Balanced outputs
Used if your amplifier have XLR-Inputs. If your amplifier
is not equipped with XLR-Inputs, please use the line
inputs with RCA-connectors.
3. RCA outputs 1 and 2
RCA 1: High Line Level
RCA 2: Normal Line Level
4. Digital out RCA
SPDIF Coaxial for connection to a D/A Converter
5. Digital out TOSLINK
Optical for connection to a D/A Converter
4
1
2
3
4
5
5
Remote control R4U
The same remote is used for both CD ONE and AMPLIFIER ONE.
The functions used to control the CD are
bold
in the text below.
1.
AMP
Changes the AMPLIFIER ONE between ON and Standby mode
2.
CD
Changes the CD ONE between ON and Standby mode
3.
DIM AMP
Dims the display at AMPLIFIER ONE in three steps and off
4.
DIM CD
Dims the display at the CD front panel in three steps
5.
TAPE LOOP
Loop signal to external equipment
6.
RANDOM
Random play for Compact disc
7.
SURR
Press the button for 1 second to entry ”SURROUND” mode
8.
TIME
Displays track and elapsed time of track or CD
9.
DISP EDIT
Editing display on amplifier
10.
MUTE AMP
Mute control button for the amplifier
11.
SOURCE
Use - or + to change the current input source
12.
VOL
VOL VOL
Output level + / -
13.
Stop playing disc
14.
Play disc
15.
Open / Close CD drawer
16.
Pauses playing disc
17.
Restart current track, or step to previous track
18.
Step to next track
19.
Reverse Scan
20.
Forward Scan
21.
REPEAT
Repeat track (press once), Repeat Disc (press twice).
To cancel, press until
Repeat Off
shows in the display
Repeat Off shows in the displayRepeat Off
22.
CD/SACD
In Stop-mode: Changes between SACD-STEREO
2
6
4
The R4U remote control
Functions used to control CD ONE are marked, all the other buttons are only used to control
AMPLIFIER ONE
15
16
17
18
19
20
13
14
21
22
8
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
6
Operating
We recommend that you leave your CD ONE powered up at all times to maintain optimal perfor-
mance. If you plan to be away from your home for a few days, powering off the CD may not be a
bad idea. Don’t forget, if you do so, it will require several hours before it reaches its peak perfor-
mance after you’ve powered up again!
Turning on your CD ONE for the first time:
Prior to turning the CD player on for the first time, make sure that every cable is properly connec-
ted to avoid any problems. Then turn on your CD player in the following manner:
1.
Turn on the main switch labeled AC POWER to the position ON at the rear side.
Make sure you connect to the proper voltage marked on your amplifier.
You will now see
”-----------”
in the display, wait a few seconds until the message disap
peares. Now the CD player is in Standby mode.
2.
Press the Standby button on the front side, or the CD button on the remote
control R4U. The display window will now show
LOAD
.
3.
Open the drawer by pressing the
"OPEN"
button on the front panel
4.
Insert a disc with the label side facing up.
5.
Press Open to close the the drawer.
6.
Press Play to start playing the disc.
7.
To stop playback, press
"STOP"
on the CD player, or on the remote control.
Disc Compatibility:
CD / SACD / CD-R / CD-RW
NOTE:
Use the remote control for this selection and only in STOP mode
7
Warranty
Contact your authorized DLS Dealer for details of our local warranty policy
Obtaining service
If your DLS CD ONE must be serviced, please contact your local dealer.
You can also consult the DLS web-site www.dls.se and contact the exclusive Hi-Fi distributor for
your country
Important!
It is extremely important that the in for ma tion about a problem is explicit and complete. A specific,
comprehensive description of the problem helps your dealer and the technical service department
to locate and repair the fault as quickly as possible. A copy of the original bill or sales receipt will
serve to verify the warranty status. Please include it with the unit when it is brought in for warranty
service.
Warning!
All returned units must be properly packaged in their original packaging material. If the packa-
ging to protect the unit is, in our opinion or that of our dealer, inadequate, we reserve the right
to repackage the return shipment at the owners’ expense. Neither DLS nor your dealer can be
responsible for shipping damage due to improper (that is, non-original) packaging. Your dealer can
order a new set of shipping materials for you if you need to ship your CD ONE and no longer have
the original materials. There will be a charge for this service. We strongly recommend saving all
packaging materials in case you need to ship your unit some day
8
Troubleshooting
Problem: Cause: Solution:
No sound
No sound
Power AC Mains cable
unplugged or power not
switched on
SACD in the drawer
Pause ON
Internal fuse blown
Cable not properly connected
External Electrical Chock
No sound in
No sound in
Input lead disconnected
one of the channels
one of the channels
or damaged
Remote control not working
Remote control not working
Batteries need to be replaced
or are incorrectly installed
IR transmitter or receiver
windows obstructed.
Check if AC Mains cable
is plugged in and power
switched on
Choose SACD format
Press Play button
Consult dealer
Check cables
Switch Off Main Power
Switch for minimum 5
seconds
Check leads and
connections
Replace or check
the batteries
Remove obstruction.
Your own notes
Make you own notes regarding settings, installation etc.
9
Contact:
DLS Svenska AB
P.O Box 13029
SE-402 51 Göteborg
SWEDEN
Phone: +46 31 840060
Fax: +46 31 844021
e-mail: [email protected]
www.dls.se
Table of contents
