docherty Excelsior User manual

Excelsior
Twin wall insulated chimney system
Suitable for both external and internal
applications
Manufactured and approved to
European Standard EN1856-1
with designation
T450 N1 D V2 L50050 G50
316L inner liner material specification
and 304L outer liner material
specification with 10 year warranty
Specialist distributor of ues, chimneys &heating appliances
www.docherty.co.uk
approved
25mm insulated cavity

Excelsior is a twin-walled
stainless steel chimney
system designed and
approved for use with all
fuels including gas, oil,
wood and approved solid
fuels.
Excelsior
2
Customer Service
The Docherty Group directly employs a
team of dedicated sales professionals,
all comprehensively trained to exacting
standards and offering the very best
pre-sales technical and practical
support for our industry customers.
We always deliver the products our
customers want - when they want them
and, with an unrivalled branch network,
we’re never too far away!
Quality
We operate a Quality Management
System with accreditation to European
Standard ISO 9001:2008.
We’re the leading independent UK
manufacturer and distributor of flue
and chimney systems and renewable
fuel appliances.
With over 50 years of experience, our
name is synonymous with consistent
quality, reliable supply and excellent
customer care, delivered through a
network of our own branches and
accredited dealers.
The Group also offers specialist HETAS
approved training courses for installers
from a purpose-built facility.
Complete
capability
from the
Docherty Group

Material Specification
and Warranty
Excelsior is supplied with a ten year
conditional warranty.
The inner is manufactured from high
grade 316L stainless steel with a
nominal thickness of 0.5mm and the
outer case is manufactured from 304
grade stainless steel. The 25mm cavity
is insulated with mineral wool.
Construction
Manufactured to exacting standards
under a Quality Management System
accredited to European Standard ISO
9001:2008.
The components are of twin wall
construction with a male spigot coupler
and a female socket coupler to provide
simple and rapid installation.
Excelsior is designed to be installed
with the spigot end facing upwards, the
socket end facing downwards.
The components twist lock together and
finally secured using a locking band.
Dimensions and
Components
Excelsior is available in 125mm, 150mm,
180mm and 200mm internal diameter.
A wide range of components including
lengths, elbows, tees, adaptors, terminals,
flashings and fittings are available to
offer a complete chimney system that
complements any residential or
commercial installation. Matt black
option is also available
Approval
Manufactured and approved to European
Standard EN 1856-1 with designation
T450 N1 D V2 L50050 G50.
Excelsior is also CE Approved ensuring it
meets European Union safety, health and
environmental requirements.
3

Excelsior
Components
4
Straight
Length
15oElbow
30oElbow
Adjustable
Length
Diameter (Ø) 125mm (5”) 150mm (6”) 180mm (7”) 200mm (8”)
Height (L) 84mm 84mm
A 61mm 63mm
B 48mm 50mm
Code EXB1513 EXB1515 EXB1518 EXB1520
Diameter (Ø) 125mm (5”) 150mm (6”) 180mm (7”) 200mm (8”)
Height (L) 69mm 81mm
A 64mm 77mm
B 64mm 64mm
Code EXB3013 EXB3015 EXB3018 EXB3020
Nominal Length 200mm 500mm 1000mm
Effective Length (L) 167mm 467mm 967mm
Ø125mm EX2013 EX5013 EX10013
Ø150mm EX2015 EX5015 EX10015
Ø180mm EX2018 EX5018 EX10018
Ø200mm EX2020 EX5020 EX10020
Nominal Length 280mm - 500mm
Effective Length (L) 247mm - 467mm
Ø125mm EXPP13
Ø150mm EXPP15
Ø180mm EXPP18
Ø200mm EXPP20
L
Ø
Ø
Ø
Ø
L
L
L
45oElbow Diameter (Ø) 125mm (5”) 150mm (6”) 180mm (7”) 200mm (8”)
Height (L) 43mm 42mm
A 79mm 83mm
B 70mm 74mm
Code EXB4513 EXB4515 EXB4518 EXB4520
Ø
L
A
B
A
A
B
B
For matt black option add a 'P' to the end of product code to get priced in black

5
45oTee
90oTee Diameter (Ø) 125mm (5”) 150mm (6”) 180mm (7”) 200mm (8”)
Height (L) 250mm 275mm
A 130mm 160mm
B 150mm 185mm
Code EXT9013 EXT9015 EXT9018 EXT9020
Diameter (Ø) 125mm (5”) 150mm (6”) 180mm (7”) 200mm (8”)
Height (L) 330mm 360mm
A 260mm 280mm
B 255mm 275mm
Code EXT4513 EXT4515 EXT4518 EXT4520
Tee Plug Diameter (Ø) 125mm (5”) 150mm (6”) 180mm (7”) 200mm (8”)
Height (L) 27mm 27mm
Code EXTE13 EXTE15 EXTE18 EXTE20
Adaptor Diameter (Ø) 125mm (5”) 150mm (6”) 180mm (7”) 200mm (8”)
Height (L) 100mm 100mm
Code EXAD13 EXAD15 EXAD18 EXAD20
Ø
Ø
Ø
Ø
L
L
L
L
A
Drain Plug Diameter (Ø) 125mm (5”) 150mm (6”) 180mm (7”) 200mm (8”)
Height (L) 90mm 90mm
Code EXRBK13 EXRBK15 EXRBK18 EXRBK20
Ø
L
Increasing
Adaptor
Diameter (Ø) 125mm (5”) 150mm (6”) 180mm (7”) 200mm (8”)
Height (L) 75mm 75mm
A 100mm 120mm
Code EXIA1013 EXIA1315 EXIA1518 EXIA1820
Ø
L
A
Wall Band Diameter (Ø) 125mm (5”) 150mm (6”) 180mm (7”) 200mm (8”)
A 160mm 160mm
B 280mm 280mm
Code EXWB13 EXWB15 EXWB18 EXWB20
B
Ø
A
Guy Wire
Bracket
Diameter (Ø) 125mm (5”) 150mm (6”) 180mm (7”) 200mm (8”)
Code EXGWB13 EXGWB15 EXGWB18 EXGWB20
B
B
A
For matt black option add a 'P' to the end of product code to get priced in black

6
Wall Support
Base
Support
Diameter (Ø) 125mm (5”) 150mm (6”) 180mm (7”) 200mm (8”)
A 300mm 300mm
B 256mm 265mm
C 310mm 310mm
D 450mm 450mm
Code EXSA13 EXSA15 EXSA18 EXSA20
Diameter (Ø) 125mm (5”) 150mm (6”) 180mm (7”) 200mm (8”)
A 450mm 450mm
B 175mm 200mm
C 275mm 300mm
D 215mm 215mm
Code EXWSB13 EXWSB15 EXWSB18 EXWSB20
Roof Support Diameter (Ø) 125mm (5”) 150mm (6”) 180mm (7”) 200mm (8”)
A 150mm 150mm
B 250mm 250mm
Code EXRSB13 EXRSB15 EXRSB18 EXRSB20
Ceiling Support Diameter (Ø) 125mm (5”) 150mm (6”) 180mm (7”) 200mm (8”)
A 340mm 340mm
Code EXCSP13 EXCSP15 EXCSP18 EXCSP20
A
B
D
A
Storm Collar Diameter (Ø) 125mm (5”) 150mm (6”) 180mm (7”) 200mm (8”)
Height (L) 40mm 40mm
Code EXCS13 EXCS15 EXCS18 EXCS20
Ø
L
C
D
C
B
A
B
Top Stub
Rain Cap Diameter (Ø) 125mm (5”) 150mm (6”) 180mm (7”) 200mm (8”)
A 300mm 300mm
Code EXRC13 EXRC15 EXRC18 EXRC20
Diameter (Ø) 125mm (5”) 150mm (6”) 180mm (7”) 200mm (8”)
Height (L) 215mm 215mm
Code EXTS13 EXTS15 EXTS18 EXTS20
Ø
Ø
L
A
Storm Cowl Diameter (Ø) 125mm (5”) 150mm (6”) 180mm (7”) 200mm (8”)
Height (L) 155mm 155mm
A 305mm 305mm
Code EXSTCL13 EXSTCL15 EXSTCL18 EXSTCL20
A
Ø
A
L
For matt black option add a 'P' to the end of product code to get priced in black

7
Structural
Locking Band
Diameter (Ø) 125mm (5”) 150mm (6”) 180mm (7”) 200mm (8”)
Height (L) 250mm 250mm
Code EXSLB13 EXSLB15 EXSLB18 EXSLB20
Ø
L
Standard
Locking Band
Diameter (Ø) 125mm (5”) 150mm (6”) 180mm (7”) 200mm (8”)
Code EXLB13 EXLB15 EXLB18 EXLB20
Ø
Ventilated
Fire Stop Kit
Diameter (Ø) 125mm (5”) 150mm (6”) 180mm (7”) 200mm (8”)
A 300mm 350mm
B 330mm 430mm
Code EXVFSK13 EXVFSK15 EXVFSK18 EXVFSK20
A B
Ventilated
Fire Stop
Diameter (Ø) 125mm (5”) 150mm (6”) 180mm (7”) 200mm (8”)
B 380mm 380mm
C 380mm 380mm
Code EXFSP13 EXFSP15 EXFSP18 EXFSP20
B
Fire Stop with
Clamp
Diameter (Ø) 125mm (5”) 150mm (6”) 180mm (7”) 200mm (8”)
B 380mm 380mm
C 380mm 380mm
Code EXFSPC13 EXFSPC15 EXFSPC18 EXFSPC20
Flat Flasing Diameter (Ø) 125mm (5”) 150mm (6”) 180mm (7”) 200mm (8”)
L 315mm 315mm
A 470mm 490mm
Code EXFF13 EXFF15 EXFF18 EXFF20
5° to 30°
Flashing
Diameter (Ø) 125mm (5”) 150mm (6”) 180mm (7”) 200mm (8”)
L 160mm 160mm
A 550mm 550mm
Code EXSF13 EXSF15 EXSF18 EXSF20
30° to 45°
Flashing
Diameter (Ø) 125mm (5”) 150mm (6”) 180mm (7”) 200mm (8”)
L 120mm 120mm
A 1000mm 1000mm
Code EXLF13 EXLF15 EXLF18 EXLF20
B
Adaptor
to Flex
L
A
L
L
A
A
C
C
Ø
LDiameter (Ø) 125mm (5”) 150mm (6”) 180mm (7”) 200mm (8”)
Height (L) 70mm 70mm
Code EXAF13 EXAF15 EXAF18 EXAF20
For matt black option add a 'P' to the end of product code to get priced in black

Components
8
Docherty Group chimney systems are manufactured to the
highest quality standards. Under normal operating conditions,
Excelsior provides many years of reliable service and carries a
10 year conditional warranty depending on application,
installation and maintenance.
The components within the range can be vulnerable when exposed
to the products of combustion from solid fuel appliances and
this is especially true for terminals. Condensate collectors are
also vulnerable, particularly if the flue system is not regularly
maintained and cleaned. These components are considered
‘incidental‘ and their life expectancy will vary depending on location,
application, fuel usage and maintenance. For this reason, these
fittings are covered by a 2 year warranty and not the 10 year
conditional warranty.
Excelsior carries a 10 year conditional warranty for any defect
due to faulty manufacture, this is provided the system has been
installed in accordance with the installation instructions, and has
been used for the purpose it was designed for. Furthermore, the
system must be regularly cleaned, maintained and inspected.
This should be carried out at least once per year, and more
regularly if the appliance is used continuously or frequently, by a
member of one of the HETAS recognised chimney sweep
associations (APICS, GMCS or NACS) or a HETAS Approved
Engineer. Written documentation to demonstrate the inspection
and cleaning of the chimney must be kept to validate the ten
year warranty. When burning mineral fuel or smokeless fuel
in your appliance, care should always be taken to use a high
quality fuel. Only HETAS or SFA (Solid Fuel Association) approved
fuels must be used with Excelsior. For guidance on fuel choices
please visit www.hetas.co.uk.
Under no circumstances should an appliance be located where
there is the potential of chemical contamination of the combustion air.
Where the chimney system is exposed to severe coastal locations,
you must ensure adequate protection to the outer components
of Excelsior. A chimney fire will invalidate the warranty; in the event
of a chimney fire it is always advisable to replace the complete
chimney system.
Warranty terms and conditions
Wall Sleeve Diameter (Ø) 125mm (5”) 150mm (6”) 180mm (7”) 200mm (8”)
A 220mm 254mm
B 570mm 570mm
Code EXWS13 EXWS15 EXWS18 EXWS20
Elliptical
Trim Plate
Diameter (Ø) 125mm (5”) 150mm (6”) 180mm (7”) 200mm (8”)
A 195mm 208mm
B 272mm 287mm
Code EXETP13 EXETP15 EXETP18 EXETP20
A
A
B
B
45°

9
Installation Guide
Also see illustrations pages 10-11
Chimney and flue design
The chimney and flue design is the responsibility of the
engineer or installer and should conform to the requirements
of Approved Document J and, where appropriate, BS EN
15287 part 1.
Any variation will require the designer to ensure the
performance of the chimney meets the requirements of the
appliance by calculation using the methods given in BS EN
13384 part 1 or any proprietary software program based
on this standard.
Regulations and standards
The regulations and standards covering the design and
installation of a chimney system in the UK are as follows:
Building Regulations
England and Wales
-- Approved Document J - Combustion
Appliances and Fuel Storage Systems.
Scotland
-- Scottish Building Standards Technical Hand
Book Section 3.
Northern Ireland
– Building Regulations Part L – Combustion
Appliances and Fuel Storage Systems.
Standards
BS EN 15287 part 1 - Chimneys. Design, installation and
commissioning of chimneys Part 1: Chimneys for non-room
sealed heating appliances.
BS EN 13384 part 1 - Chimneys. Thermal and fluid
dynamic calculation methods.
Flue sizing
The sizing of flues for appliances should be based on the
type of fuel and the appliance to be used.
• Gas Appliances
In the case of gas appliances the Building regulations
Approved Document J table 5, the gas safety in use
regulations and in all cases as required by the
manufacturers’installation instructions.
• Oil Appliances
Flues for oil appliances should be sized in accordance with
the requirements of Approved Document J Paragraphs
4.4 and 4.5.
• Solid Fuel Appliances
The size of flues for solid fuel appliances should be in
accordance with the requirements of Approved Document
J Paragraphs 2.4 to 2.7 and as given in table 2 of ADJ.
For solid fuel appliances with back or side flue outlet, the
maximum permitted length of horizontal chimney or flue
pipe is 150mm.
Where the chimney passes through a wall, the opening
must be lined with a wall sleeve.
The termination height of the chimney will depend on
appropriate regulations and standards. The connection
between a connecting flue to Excelsior must be made in
the same room as the appliance. According to the UK
Building Regulations, the chimney must be accessible for
inspection and cleaning. We recommend the inclusion of
a tee to provide easy access. Each chimney section and
connected fittings shall be used as manufactured for
assembly on site without any alteration. Please make sure
that all elements are installed the right way up.
The system must be adequately supported with elements
supplied by Docherty Group. The support components
must be used at intervals depending on the load bearing
criteria quoted on pages 14 and 15. Wall brackets are
not load bearing and should be used to provide lateral
stability only, and at intervals not exceeding the criteria
quoted.
Where the chimney passes through a combustible floor,
a ventilated fire stop plate must be used both above and
below the aperture. A support clamp supports the weight
of the chimney on the upper fire stop plate. Both plates
must be secured using 6mm screws. The aperture must
be constructed to maintain 50mm distance from the outer
wall of the chimney to combustible materials.
The aperture must additionally be lined with a fire resistant
board. All subsequent floors having combustible floors
must be treated in this way.
Chimney joints must not be positioned in the thickness
of floor or ceiling joist spaces or within 50mm of floor or
ceiling.
Where the chimney passes through any occupied space
other than the room in which the appliance is installed, it
must be fully enclosed with fire resistant material
maintaining the 50mm clearance to the outer wall of the
chimney. The enclosure is to prevent damage to the
chimney, to prevent human contact and to ensure no
combustible material can be placed too close to the
chimney. The enclosure must have an access panel
measuring at least 100mm x 100mm.
Where the chimney passes through a roof space, it is
essential that it is adequately supported by bracing to
roof timbers. If there is a chimney run of more than 1.5m
from the ceiling support to the roof support, use a bracing
bracket and rigid stays for such application. Also, provision
must be made to ensure that no accidental placement
of combustible product can occur within 50mm of the
external casing of the chimney; for example, a mesh or
screen around the chimney. This must cover the first 1m
of the chimney and must go down to the upper face of the
ceiling.
Any change of direction in a flue will create resistance to
the flue gas movement. Building Regulations do not allow
any part of the chimney system to form an angle greater
than 45 degree from the vertical. Where the system is
used for solid fuels and oil, no system can be constructed
with more than two separate offsets in the chimney. If a
90 degree tee is used on the back of the appliance, this
constitutes one offset. The length of chimney between two
elbows must not exceed 20% of the total length of the
chimney.
Excelsior

10 Installation External Application
Structural Locking Band
When fitted increases unsupported length to
3.0 metres
Top Stub or Rain Cap
Wall Band
Maximum distance between wall brackets
2.0 metres
30° Elbows
Wall Band
Maximum distance between wall brackets
2.0 metres
Length
Locking Band
135° Tee
Adjustable Wall Sleeve
Base Support
Supports up to 10 metres of chimney
Drain Plug
Adaptor to Excelsior
45° Vitreous Elbow with Door
Vitreous Enamel Connecting Flue
Where a drain can be incorporated in the tee at the
base of the chimney then a top stub should be used.
Note: Rain water ingress can be reduced by use of
a terminal where a drain cannot be included
It is not a requirement, but ideally 30°°elbows should
be used to form the offset as this reduces risk of
blockage and corrosion of the inner skin
External Trim Plate
Internal Trim Plate
The use of a secured guy wire bracket can increase
unsupported length by 1.0 metre
Standard Unsupported Length
Maximum 1.5 metres
Minimum height of 600mm before an offset
Structural Locking Band
Excelsior
10 Installation External Application Excelsior

11
Installation Internal Application
Storm Collar
Wire Mesh
Shields chimney in loft space
Ventilated Fire Stop and Clamp
Length
Tee Cap
150mm maximum
Adaptor to Excelsior
Vitreous Enamel Connecting Flue
Roof Flashing
Rafter Support
Ventilated Firestop
Ventilated Fire Stop Kit
90° Vitreous Tee
425mm minimum
Locking Band
Fire Rated Board Around Aperture
Rain Cap or Top Stub
Where a drain can be incorporated in the tee at the
base of the chimney then a top stub should be used.
Note: Rain water ingress can be reduced by use of a
terminal where a drain cannot be included
Must cover at least 1.0 metre above floor level
Minimum 50mm clearance from the outer
casing of the chimney to the inner surface of a
30 minute fire rated enclosure
Minimum 50mm clearance to combustibles
Minimum 50mm clearance to rafters
Minimum 50mm clearance to combustibles
Must have access panel at least
100mm x 100mm
Adjustable Wall Support
Fire Rated Board Around Aperture

2
4
5
67
8
10
1
3
9
KW
IV
AB
PH
PA
DD
FK
G
KY
KA
ML
EH
TD
NE
DG
IM
CA
LA
DL
YO
LL
SY
SA
TR
PL
EX
DN
LN
PE
NN
NR
IP
NG
S
LD HR
NP
CF
GL
SN
TA
DT
BA
RG
LE
B
CB
OX
DE
SP
DH
TS
SR
HU
HG
BD
LS
BB
PR
WN
FY
L
CW
OL
HX WF
HD
SK
ST
TF WS
WV
DY CV
MK SG
CM
CO
SS
RM
SO
BH
BS
TQ
PO
GU RH
BN
DA
ME CT
TN
SL
AL
LU
HP
WR
BL
M
CH
WA
Group Head Ofce
Units 15/16 Colthrop Business Park
Colthrop Lane, Thatcham
Berkshire, RG19 4NB
T: 01635 292400
F: 01635 201737 E: info@docherty.co.uk
The Docherty Group in the UK
www.docherty.co.uk
Specialist distributor of ues, chimneys &heating appliances
Area Sales
Managers
Docherty Group
Flue House, 55 Woodburn Road
Birmingham
West Midlands, B66 2PU
T: 0121 555 6789
5
3
Docherty Group
Unit 15, Robin Hood Street Ind. Est.
off Alfred Street South
Nottingham, NG3 1GE
T: 01159 584734
4
2
Docherty Group
Eleventh Avenue,
Unit 15 Kingsway Interchange
Team Valley Trading Estate
Gateshead, NE11 0JY
T: 0191 488 1111
1
Docherty Group
Flue House, Portway Trading Estate
Portview Road,
Bristol, BS11 9LQ
T: 0117 982 8252
6
Docherty Group
Unit C Station Yard, Coombe Road
Norbiton, Kingston, KT2 7AZ
T: 020 8391 0093
8
Docherty Group
Units 15/16 Colthrop Business Park
Colthrop Lane, Thatcham
Berkshire, RG19 4NB
T: 01635 292400
7
Docherty Group
Unit 20, Flightway Business Park
Dunkeswell, Devon, EX14 4RD
T: 01404 890098
9
Sure Fire Training Services
Unit E, Fairview Buildings
Heage Road Industrial Estate
Ripley, Derbyshire, DE5 3GH
T: 01773 570408 •0345 260 0166
E: info@surere.org.uk
10
Docherty Group
Unit 7, Overland Park
Gelderd Road
Leeds, LS27 7JN
T: 01132 381200
Docherty Group
Unit 2, Rivington Court
Hardwick Grange
Warrington, WA1 4RT
T: 01925 807950
Adina Heating Products
Unit C, Fairview Buildings
Heage Road Industrial Estate
Ripley, Derbyshire, DE5 3GH
T: 01773 571 330
11
Issue: February 2016
Benjamin Chapman
07771 654897
bchapman@docherty.co.uk
Darren Willetts
07850 994 128
Jason Edwards
07918 561 431
jedwards@docherty.co.uk
Alan Smith
07545 503 575
asmith@docherty.co.uk
Sacha Aarons
07974 975 444
saarons@docherty.co.uk
Andy Bishop
07595 205 268
abishop@docherty.co.uk
Marc Foster
07918 561 430
mfoster@docherty.co.uk
Mark Kerry
07966 471 139
mkerry@docherty.co.uk
Phil Chaplain
07590 228 714
pchaplain@docherty.co.uk
Alex Daynes
07818 030 721
adaynes@docherty.co.uk
Table of contents
Popular Fan manuals by other brands

Swegon
Swegon COMPACT Air Installation and maintenance instructions

Hunter
Hunter Hunter Ceiling fans Installation and operation manual

Parrot Uncle
Parrot Uncle F6291 Installation & operating instructions

Lennox
Lennox LPVK-110 installation instructions

LEGRAND
LEGRAND HPM EFIL100SQWE instruction manual

Dyson
Dyson pure hot+cool user guide

Thomasville
Thomasville Carmel P2505 installation manual

Hinkley
Hinkley 54" Collier Series instruction manual

Applied Energy Products
Applied Energy Products XX100 Installation & operating instructions

Miele
Miele DUU 2900 Operating and installation instructions

Kichler Lighting
Kichler Lighting Surrey Climates 60 instruction manual

Econar
Econar FC3 Series Installation and operating instructions
