Doheny's 2716 Guide

Above Ground &
In-ground Pumps
Item #s 2601, 6578, 6579, 2716 & 6589
6950 51st Street Kenosha WI 53144|Orders and Customer Care: 1-800-574-7665|Fax: [phone]|Doheny.com

To prevent potential injury and to avoid unnecessary service calls, read this manual carefully and completely.
SAVE THIS INSTRUCTION MANUAL Use of appointed replacement parts voids warranty.
ATTENTION INSTALLER – THIS MANUAL CONTAINS IMPORTANT INFORMATION
ABOUT THE INSTALLATION, OPERATION, AND SAFE USE OF THIS PUMP THAT MUST
BE PROVIDED TO THE END USER OF THIS PRODUCT. FAILURE TO READ AND FOLLOW
ALL INSTRUCTIONS COULD RESULT IN SERIOUS INJURY.
INSTALLATION, OPERATION & PARTS
Above Ground Pump
Item #s 2601, 6578 & 6579
Above Ground Deluxe Pump
Item #s 4657 & 5014
In-ground Pump
Item #s 2716 & 6589

6950 51st Street Kenosha WI 53144|Orders and Customer Care: 1-800-574-7665|Fax: [phone]|Doheny.com
Symbol means:
▲DANGER
Indicates that if failure to avoid potential hazard,
will cause severe personal injury or death or
property damage.
▲WARNING
Indicates that failure to avoid potential hazard,
could result in severe personal injury or death or
property damage.
▲CAUTION
Indicates that failure to avoid potential hazard, will
or could cause moderate personal injury or
property damage.
CHAPTER 1:
IMPORTANT SAFETY INSTRUCTIONS
READ AND FOLLOW ALL INSTRUCTIONS
▲WARNING Pay Attention to Children.
1. To reduce risk of injury, do not permit children to use
or climb on this product. Closely supervise children
 at all times. Components such as the ltration
system, pumps, and heaters must be positioned to
prevent children from using them as a means of
access to the pool.
2. This pump is intended for use on permanently
installed swimming pools and may also be used with
hot tubs and spas if so marked. Do NOT use with
storable pools. A permanently installed pool is
constructed in or on the ground or in a building such
that it cannot be readily disassembled for storage. A
storable pool is constructed so that it is capable
of being readily disassembled for storage and
reassembled to its original integrity.
3. Though this product is designed for outdoor use, it is
strongly advised to protect the electrical components
fromtheweather.Selectawell-drainedarea,onethat
 willnotoodwhenitrains.Itrequiresfreecirculation
of air for cooling. Do not install in a damp or non-
ventilated location.
4. Pool and spa components have an nite life. All
 components should be inspected frequently and
 replacedatleasteveryveyears,oriffoundtobe
damaged, broken, cracked, missing, or not securely
attached.
▲WARNING Risk of Electric Shock.
Applies to Inground Pumps
5. Hazardous voltage. Can shock, burn, or cause
death. To reduce the risk of electric shock, do NOT
use an extension cord to connect unit to electric
supply. Provide a properly located outlet. It is
 requiredthatlicensedelectriciansdoallelectrical
wiring. All electrical wiring MUST be in conformance
with applicable local and national codes and
regulations. Before working on pump or motor,
disconnect motor wiring.
6. To reduce the risk of electric shock, replace damaged
cord immediately. Do NOT bury cord. Locate cord to
prevent abuse from lawn mowers, hedge trimmers
 andotherequipment.
7. Risk of Electric Shock. Connect only to a branch
circuit protected by a ground-fault circuit-interrupter
(GFCI). Contact a professional electrician if you
cannot verify that the receptacles are protected by
a GFCI.
8. Failure to bond pump to pool structure will increase
risk for electrocution and could result in injury
or death. To reduce the risk of electric shock, see
installation instructions and consult a professional
electrician on how to bond pump. Also, contact a
licensed electrician for information on local electrical
 codesforbondingrequirements.
9. Use a solid copper conductor, size 8 or larger.
Run a continuous wire from external bonding lug to
reinforcing rod or mesh. Connect a No. 8 AWG
(8.4 mm2) solid copper bonding wire to the pressure
wire connector provided on the motor housing and
to all metal parts of swimming pool, spa, or hot tub,
 andtoallelectricalequipment,metalpiping(except
gas piping), and conduit within 5 feet (1.5m) of inside
walls of swimming pool, spa or hot tub.
IMPORTANT: Reference NEC codes for all wiring
standards including, but not limited to, grounding,
bonding and other general wiring procedures.
NOTE: The National Electrical Code (NEC) permits
use of a cord with a maximum 3 feet (1m) length. If
 yourpumpisequippedwithacordcomplyingwith
the NEC, the preceding four hazards apply.
10. Do not install within an outer enclosure or beneath
the skirt of a hot tub or spa.
11. SAVE THESE INSTRUCTIONS.
12. These pumps are not pool side pumps.
▲WARNING Suction Entrapment Hazard.
13. Suction in suction outlets and/or suction outlet
covers, which are damaged, broken, cracked,
missing, or unsecured, cause severe injury and/or
death due to the following entrapment hazards:
Hair Entrapment: Hair can become entangled in
suction outlet cover.
Limb Entrapment: A limb inserted into an opening
of a suction outlet sump or suction outlet cover that
is damaged, broken, cracked, missing, or not
securely attached can result in a mechanical bind
or swelling of the limb.
Body Suction Entrapment: A pressure applied to
a large portion of the body or limbs can result in an
entrapment.

Evisceration/Disembowelment: A negative
pressure applied directly to the intestines through
an unprotected suction outlet sump or suction outlet
cover which is damaged, broken, cracked,
missing, or unsecured can result in evisceration/
disembowelment.
Mechanical Entrapment: There is potential for
 jewelry,swimsuits,hairdecorations,ngers,toes,
or knuckles to be caught in an opening of a suction
outlet cover resulting in mechanical entrapment.
▲WARNING Reduce Risk of Entrapment Hazards.
14. When outlets are small enough to be blocked by a
person, a minimum of two functioning suction
outlets per pump must be installed. Suction outlets
 inthesameplane(oororwall),mustbeinstalled
a minimum of 3 feet [0.91 meter] apart, as measured
from near point to near point.
 •Dual suction ttings shall be placed in such
locations and distances to avoid ‘dual blockage’ by
a user.
 •Dualsuctionttingsshallnotbelocatedonseating
areas or on the backrest for such seating areas.
 •Themaximumsystemowrateshallnotexceed
the values shown in the ‘Pipe Sizing Chart’ found
at this manual.
 •Never use pool or spa if any suction outlet
component is damaged, broken, cracked, missing,
or not securely attached.
 •Replace damaged, broken, cracked, missing,
or not securely attached suction outlet components
immediately.
 •Installationofavacuumreleaseorventsystem,
recommended, relieves entrapping suction.
▲WARNING Hazardous Pressure.
15. Pool and spa water circulation systems operate
under hazardous pressure during start-up, normal
operation, and after pump shut-off. Stand clear
 ofcirculationsystemequipmentduringpumpstart-
up. Failure to follow safety and operation instructions
could result in violent separation of the pump
housing and cover due to pressure in the system,
which could cause property damage, severe
personal injury, or death. Before servicing pool and
spa water circulation system, all system and pump
 controls must be in off position and lter manual
air relief valve must be in open position. Before
starting system pump, all system valves must be
set in a position to allow system water to return
 backtothepool.Donotchangeltercontrolvalve
position while system pump is running. Before
 startingsystem pump, fullyopen ltermanual air
 relief valve. Do not close lter manual air relief
valve until a steady stream of water (not air or air
and water) is discharged. All suction and discharge
valves MUST be OPEN when starting the circulation
system. Failure to do so could result in severe
personal injury and/or property damage.
▲WARNING Separation Hazard.
16. Failure to follow safety and operation instructions
could result in violent separation of pump
components. Strainer cover must be properly
secured to pump housing with strainer cover
lock ring. Before servicing pool and spa circulation
system, all system and pump controls must be in
 offposition and ltermanualair relief valve must
be in open position. Do not operate pool and
spa circulation system if a system component is
not assembled properly, damaged, or missing. Do
not operate pool and spa circulation system unless
 lterairreliefvalvebodyisinlockedpositioninlter
upper body. All suction and discharge valves MUST
be OPEN when starting the circulation system.
Failure to do so could result in severe personal
injury and/or property damage.
17. Never operate or test the circulation system at
more than 40 psi.
▲WARNING Fire and burn hazard.
18. Motors operate at high temperatures and if they are
 notproperlyisolatedfromanyammablestructures
 or foreign debris, they can cause res, which
may cause severe personal injury or death. It is
also necessary to allow the motor to cool for at
least 20 minutes prior to maintenance to minimize
the risk for burns.
19. Motor must be grounded in accordance with local
and national electrical codes.
20. To prevent electrical shock or injury, do not run
pump dry.
21. To reduce the risk of electric shock, install at least
10 feet from the inside walls of the pool. Do not use
an extension cord.
CHAPTER 2: INSTALLATION INSTRUCTIONS
▲WARNING This product should be installed and
serviced only by a qualied professional.
1. Pump Mounting:Installpumponarm,levelbase
or pad to meet all local and national codes. Fasten
pump to base or pad with screws or bolts to further
reduce vibration and stress on pipe or hose joints.
The base MUST be solid, level, rigid, and vibration free.
Pump Mount Must:
 •Allow pump inlet height to be as close to water
level as possible.
 •Allowuseofshort,directsuctionpipe(toreduce
friction losses).
 •Allow for gate valves in suction and discharge
piping.
 •Beprotectedfromexcessmoistureandooding.
6950 51st Street Kenosha WI 53144|Orders and Customer Care: 1-800-574-7665|Fax: [phone]|Doheny.com

 •Allow adequate access for servicing pump and
piping.
Pipe Sizing Chart
NOTE: It is recommended that a minimum length
of piping, equivalent to 10 pipe diameters, be used
betweenthepumpsuctioninletandanyplumbingttings.
▲WARNING Hazardous Pressure.
 Pumps,lters,andotherequipment/components
 ofaswimmingpoolltrationsystemoperateunder
pressure. Incorrectly installed and/or improperly
 testedltrationequipmentand/orcomponentsmay
fail resulting in injury and/or property damage.
2. Plumbing: Use Teon tape to seal threaded
connections on molded plastic components. All
 plasticttingsmustbeneworthoroughlycleaned
before use. NOTE: Do NOT use Plumber’s
Pipe Dope as it may cause cracking of the plastic
components.WhenapplyingTeontapetoplastic
threads, wrap the entire threaded portion of the
 malettingwithonetotwolayersoftape.Windthe
tape clockwise as you face the open end of the
 tting,beginningattheendofthetting.Thepump
suction and outlet ports have molded-in thread
stops. Do NOT attempt to force hose connector
tting past this stop. It is only necessary to tighten
 ttingsenoughtopreventleakage.Tightenttingby
 hand and then use a tool to engage tting an
 additional1-1/2turns.UsecarewhenusingTeon
tape as friction is reduced considerably. Do NOT
over-tighten tting or you may cause damage. If
 leaksoccur,removeconnector,cleanoffoldTeon
tape, re-wrap with one to two additional layers of
 Teontape,andre-installconnector.
3. Fittings:Fittingsrestrictow.Forbetterefciency,
 use the fewest possible ttings (but at least two
 suctionoutlets).Avoidttingsthatcouldcausean
 airtrap.PoolandspattingsMUSTconformtothe
International Association of Plumbing and
 Mechanical Ofcials (IAPMO) standards. Use a
 non-entrapping suction tting in pool (multiple
drains) or double suction (skimmer and main drain).
CHAPTER 3: ELECTRICAL
1. Ground and bond motor before connecting to
electrical power supply. Failure to ground and bond
pump motor can cause serious or fatal electrical
shock hazard.
2. Do NOT ground to a gas supply line.
3. To avoid dangerous or fatal electrical shock, turn
OFF power to motor before working on electrical
connections.
4. Ground Fault Circuit Interrupter (GFCI) tripping
indicates electrical problem. If GFCI trips and won’t
reset, consult electrician to inspect and repair
electrical system.
▲WARNING Fire Hazard.
5. Match supply voltage to motor nameplate voltage.
Insure that the electrical supply available agrees
with the motor’s voltage, phase, and cycle, and
 that the wire size is adequate for the H.P. (KW)
rating and distance from the power source.
NOTE: All electrical wiring MUST be performed
by a licensed electrician, and MUST conform
to local codes and NEC regulations. Use copper
conductors only.
6. Voltage: Voltage at motor MUST NOT be more
than 10% above or below motor name plate rated
voltage, or motor may overheat, causing overload
tripping and reduced component life. If voltage is
less than 90% or more than 110% of rated voltage
when motor is running at full load, consult Power
Company.
7. Grounding and Bonding: Install, ground, bond,
and wire motor in accordance with local or national
 electricalcoderequirements.Permanentlyground
motor. Use green ground terminal provided under
motor canopy or access place; use size and type
 wire required by code. Connect motor ground
terminal to electrical service ground. Bond motor
to pool structure. Bonding will connect all metal
parts within and around the pool with a continuous
wire. Bonding reduces the risk of a current passing
between bonded metal objects, which could
potentially cause electrical shock if grounded
6950 51st Street Kenosha WI 53144|Orders and Customer Care: 1-800-574-7665|Fax: [phone]|Doheny.com
MAXIMUM RECOMMENDED SYSTEM FLOW
Pipe Size Flow Rate GPM
[mm] [Liter/Min]
1 in. [32 mm] 20 GPM [75]
1-1/4 in. [40 mm] 30 GPM [110]
1-1/2 in. [50 mm] 45 GPM [170]
2 in. [63 mm] 80 GPM [300]
2-1/2 in. [75 mm] 110 GPM [415]
3 in. [90 mm] 160 GPM [600]
MAX RATE FULL RATE 60 HZ 1PH
HP KW HP KW Voltage Amps Wire
- - 1/2 0.37 208-230 10A 14 AWG
115 15A 14 AWG
1 0.75 3/4 0.55 208-230 10A 14 AWG
115 15A 14 AWG
1-1/2 1.10 1 0.75 208-230 15A 14 AWG
115 20A 12 AWG

6950 51st Street Kenosha WI 53144|Orders and Customer Care: 1-800-574-7665|Fax: [phone]|Doheny.com
or shorted. Reference NEC codes for all wiring
standards including, but not limited to,
grounding, bonding and general wiring
procedures. Use a solid copper conductor, size
8 or larger. Run wire from external bonding lug to
reinforcing rod or mesh. Connect a No. 8 AWG (8.4
mm2) solid copper bonding wire to the pressure
wire connector provided on the motor housing and
to all metal parts of swimming pool, spa, or hot tub,
 andtoallelectricalequipment,metalpiping(except
gas piping), and conduit within 5 feet (1.5 m) of
inside walls of swimming pool, spa, or hot tub.
▲WARNING All Wiring Must be Done by a Licensed
Electrician.
8. Wiring: Pump MUST be permanently connected
to circuit. If other lights or appliances are also on
the same circuit, be sure to add their amp loads
before calculating wire and circuit breaker sizes. Use
the load circuit breaker as the Master On-Off switch.
Install a Ground Fault Circuit Interrupter (GFCI)
in circuit; it will sense a short-circuit to ground and
disconnect power before it becomes dangerous
 to pool users. For size of GFCI required and test
procedures for GFCI, see manufacturer’s instructions.
In case of a power outage, check GFCI for tripping,
which will prevent normal pump operation. Reset if
necessary. NOTE: If you do not use conduit when
wiring motor, be sure to seal wire opening on end of
motor to prevent dirt & bugs from entering.
CHAPTER 4: START-UP & OPERATION
PRIOR TO START-UP
NOTICE: If it is necessary to perform a pressure
test prior to initial use to ensure pump is functioning
properly, then the following criteria should be
maintained for this test:
1. Have a professional perform this test.
2. Ensure all pump and system components are
sealed properly to prevent leaks.
3. Remove any trapped air in the system by fully
 openingltermanualairreliefvalveuntilasteady
stream of water is discharged.
4. Allow no more than 40 psi (276 kPa) at a water
temperature no higher than 100ºF (38ºC).
5. Run pressure test for no longer than 24 hours.
Immediately inspect all parts to verify they are
intact and functioning properly. Fill strainer housing
with water to suction pipe level. NEVER OPERATE
THE PUMP WITHOUT WATER. Water acts as a
coolant and lubricant for the mechanical shaft seal.
▲WARNING If pump is being pressure tested (40
psi MAXIMUM), be sure pressure has been
 released, using the lter manual air relief valve,
before removing strainer cover.
▲CAUTION NEVER run pump dry. Running pump
 drymaydamageseals,causingleakage,ooding,
and voids warranty. Fill strainer housing with water
before starting motor.
6. Do NOT add chemicals to pool/spa system directly
in front of pump suction.Adding undiluted chemicals
may damage pump and voids warranty.
7. Before removing strainer cover:
1. STOP PUMP before proceeding.
2. CLOSE VALVES in suction and outlet pipes.
3. RELEASE ALL PRESSURE from pump and
   pipingsystemusingltermanualairreliefvalve.
   Seelterowner’smanualformoredetail.
PRIMING PUMP
▲CAUTIONAllsuctionanddischargevalvesMUST
 beOPEN,aswellaslterairreliefvalve(ifavailable)
 onlter,whenstartingthecirculatingpumpsystem.
Failure to do so could result in severe personal injury.
1. Releaseallpressurefromlter,pump,andpiping
system. See lter owner’s manual.
2. If water source is higher than the pump, pump will
prime itself when suction and outlet valves are
opened. If water source is lower than the pump,
 unscrew and remove strainer cover, ll strainer
housing with water.
3. Clean and lubricate strainer cover O-ring each time
it is removed. Inspect O-ring and re-install on
strainer cover.
4. Replace strainer cover on strainer housing, turn
clockwise to tighten cover.
NOTE: Tighten strainer cover by hand only (no
wrenches).
▲CAUTION Turn on power and wait for pump to
 prime,whichmaytakeuptoveminutes.Priming
time will depend on vertical length of suction lift and
horizontal length of suction pipe. If pump does NOT
 primewithinveminutes,stopmotoranddetermine
cause. Be sure all suction and discharge valves
are open when pump is running. See Trouble-
 shootingGuide.Waitvesecondsbeforere-starting
pump. Failure to do so may cause reverse rotation
 of motor and consequent serious pump damage.
Closeltermanualairreliefvalveafterpumpisprimed.

6950 51st Street Kenosha WI 53144|Orders and Customer Care: 1-800-574-7665|Fax: [phone]|Doheny.com
CHAPTER 5: MAINTENANCE
 •Clean strainer basket regularly. Do NOT strike
basket to clean. Inspect strainer cover gasket
regularly and replace as necessary.
 •Pumps have self-lubricating motor bearings and
shaft seals. No lubrication is necessary.
 •Keepmotorclean.Insureairventsarefreefrom
obstruction to avoid damage. Do NOT use water
to hose off motor.
 •Occasionally, shaft seals must be replaced, due
to wear or damage. See ‘Shaft Seal Change
Instructions’ in this manual.
CHAPTER 6: STORAGE/WINTERIZATION
▲WARNING Separation Hazard.
1. Do not purge the system with compressed air.
Purging the system with compressed air can cause
components to explode, with risk of severe injury
or death to anyone nearby. Use only a low pressure
(below 5 psi), high volume blower when air purging
 thepump,lter,orpiping.
2. Allowing the pump to freeze will void the warranty.
3. Use ONLY propylene glycol as antifreeze in your
pool/spa system. Propylene glycol is nontoxic and
will not damage plastic system components; other
anti-freezes are highly toxic and may damage
plastic components in the system.
4. Drain all water from pump and piping when
expecting freezing temperatures or when storing
pump for a long time (see instructions below).
5. Keep motor dry and covered during storage. To
avoid condensation/corrosion problems, do NOT
 coverorwrappumpwithplasticlmorbags.
Storing Pump For Winterization
▲WARNING To avoid dangerous or fatal electrical
shock hazard, turn OFF power to motor before
draining pump. Failure to disconnect power may
result in serious personal injury or death.
1. Drain water level below all inlets to the pool.
2. Remove drain plugs from bottom of strainer body,
and remove strainer cover from strainer housing.
3. Disconnect pump from mounting pad, wiring
system (after power has been turned OFF), and
piping system.
4. Once the pump is removed of water, re-install the
s trainer cover and drain plugs. Store pump in a dry area.
Shaft Seal Change Instructions
IMPORTANT SAFETY INSTRUCTIONS, PLEASE
READ AND FOLLOW ALL INSTRUCTIONS.
Modications done to the pumps will void the
warranty.
 Whenservicingelectrical equipment, basicsafety
precautions should always be observed including
the following. Failure to follow instructions may
result in injury.
A. To reduce risk of injury, do not permit children to
use this product.
B. Disconnect all electrical power service to pump
before beginning shaft seal replacement.
C. Onlyqualiedpersonnelshouldattemptrotaryseal
replacement. Contact your local authorized Dealer
 orservicecenterifyouhaveanyquestions.
D. The National Electrical Code requires either a
three foot maximum twist-lock cord set with a GFCI
 protected receptacle (may be required and sold
at your local hardware store) or hard wire (conduit)
connection for swimming pool pump installation.
Do not use extension cords.
E. Exercise extreme care in handling both the rotating
and the stationary sections of the two-part
replacement seal. Foreign matter or improper
handling will easily scratch the graphite and ceramic
sealing surfaces.
CHAPTER 7: TROUBLESHOOTING
A. Motor Will NOT Start – Check For:
Make sure the terminal board connections agree
with the wiring diagram on motor data plate label.
 Be sure motor is wired for available eld supply
voltage (see pump operating label).
1. Improper or loose wiring connections; open
switches or relays; tripped circuit breakers, GFCIs,
or blown fuses.
Solution: Check all connections, circuit breakers,
and fuses. Reset tripped breakers or replace blown
fuses.
2. Manually check rotation of motor shaft for free
movement and lack of obstruction.
Solution: Refer to ‘Shaft Seal Change Instructions’
in this manual.
3. If you have a timer, be certain it is working properly.
Bypass it if necessary.
B. Motor Shuts OFF – Check For:
1. Lowvoltageatmotororpowerdrop(frequentlycaused
by undersized wiring or extension cord use).
Solution: Contact qualied professional to check
that the wiring gauge is heavy enough. NOTE: Your
 pumpmotorisequippedwithan‘automaticthermal
overload protector.’ The motor will automatically
shut off if power supply drops before heat damage
can build up causing windings to burn out. The
‘thermal overload protector’ will allow the motor to
automatically restart once the motor has cooled. It
will continue to cut On/Off until the problem is
corrected.
Be sure to correct cause of overheating.

6950 51st Street Kenosha WI 53144|Orders and Customer Care: 1-800-574-7665|Fax: [phone]|Doheny.com
C. Motor Hums, But Does NOT Start – Check For:
1. Impeller jammed with debris.
Solution:Haveaqualiedrepairprofessionalopen
the pump and remove the debris.
D. Pump Won’t Prime, Check For:
1. Empty pump/strainer housing.
Solution:Makesurepump/strainerhousingislled
with water and cover O-Ring is clean. Ensure O-Ring
is properly seated in the cover O-Ring groove.
Ensure O-ring is lubricated and that strainer cover
 is locked rmly in position. Lubricant will help to
create a tighter seal.
2. Loose connections on suction side.
Solution: Tighten pipe/union connections. NOTE:
Any self-priming pump will not prime if there are
suction air leaks. Leaks will result in bubbles
 emanatingfromreturnttingsonpoolwall.
3. Leaking O-ring or packing glands on valves.
Solution: Tighten, repair, or replace valves.
4. Strainer basket or skimmer basket loaded with
debris.
Solution: Remove strainer housing cover or
 skimmer cover, clean basket, and rell strainer
housing with water. Tighten cover.
5. Suction side clogged.
Solution: Contact a qualied repair professional.
Block off to determine if pump will develop a
vacuum. You should have 5 in. to 6 in. of vacuum
at the strainer cover (Only your pool dealer can
conrm this with a vacuum gauge). You may be
able to check by removing the skimmer basket and
holding your hand over the bottom port with
skimmer full and pump running. If no suction is felt,
check for line blockage.
a. If pump develops a vacuum, check for blocked
suction line or dirty strainer basket. An air leak
in the suction piping may be the cause.
b. If pump does not develop a vacuum and pump
   hassufcient“primingwater”:
i. Re-check strainer housing cover and all
threaded connections for suction leaks.
Check if all system hose clamps are tight.
ii. Check voltage to ensure that the motor is
rotating at full RPM’s.
iii. Open housing cover and check for clogging
or obstruction in suction. Check impeller for
debris.
iv. Remove and replace shaft seal only if it is
leaking.
E. Low Flow – Generally, Check For:
1. Clogged or restricted strainer or suction line.
Solution:Contactaqualiedrepairprofessional.
2. Undersized pool piping.
Solution: Correct piping size.
3. Pluggedorrestricteddischargelineoflter,valve
partially closed (high gauge reading).
Solution: Sand Filters: backwash as per
manufacturer’s instructions; D.E. Filters: backwash
as per manufacturer’s instructions; Cartridge Flters:
clean or replace cartridge.
4. Air leak in suction (bubbles issuing from return
 ttings).
Solution: Re-tighten suction and discharge
 connections using Teon tape. Inspect other
 plumbingconnectionsandtightenasrequired.
5. Plugged, restricted, or damaged impeller.
Solution: Replace including new seal assembly.
F. Noisy Pump – Check For:
1. Air leak in suction piping, cavitations caused by
restricted or undersized suction line or leak at any
joint, low water level in pool, and unrestricted
discharge return lines.
Solution: Correct suction condition or throttle
return lines, if practical. Holding hand over return
 ttingwillsometimesprovethispointorputtingina
 smallereyeballtting.
2. Vibration due to improper mounting.
Solution: Mount the pump on a level surface and
 securethepumptotheequipmentpad.
3. Foreign matter in pump housing. Loose stones/
debris hitting impeller could be cause.
Solution: Clean the pump housing.
4. Motor bearings noisy from normal wear, rust,
overheating, or concentration of chemicals causing
seal damage which will allow chlorinated water
to seep into bearings, wiping out the grease and
causing bearing to whine.
Solution: All seal leaks should be replaced at once.
CHAPTER 8: TECHNICAL DATA
Pump performance table
ITEM# HP VOLT AMPS MAX MAX
(GPM) HEAD (ft)
2601 3/4 115 7.3 62 30
6578 1 115 9 75 38
6579 1.5 115 12 83 40
2716 1 115/230 11.5/5.7 83 15
6589 1.5 115/230 14.2/7.1 97 20
4657 1 115 11.5 82 50
5014 1.5 115 15 95 68

Above Ground Pump Item #s 2601, 6578 & 6579
Above Ground Deluxe Pump Item #s 4657 & 5014
In-ground Pump Item #s 2716 & 6589
25 inches
21 inches
21.75 inches
8 inches Floor to Suction Port
6.5 inches
Floor to Suction Port
8 inches
Floor to Suction Port
9.75 inches
Floor to Discharge Hose
12 inches Floor to Discharge Hose
7.75 inches
Floor to Discharge Hose
6950 51st Street Kenosha WI 53144|Orders and Customer Care: 1-800-574-7665|Fax: [phone]|Doheny.com


6950 51st Street Kenosha WI 53144|Orders and Customer Care: 1-800-574-7665|Fax: [phone]|Doheny.com
In-ground Pump Item #’s 2716 & 6589
REF PART DESCRIPTION No.
No. NUMBER REQ’D
1 16578 Clear Cover 1
2 26578 Lid O-Ring 1
3 36578 Pump Basket 1
4 76578 Pump Housing 1
5 86578 O-Ring 1
6 96578 Screw ST4.2x38 2
7 106578 Diffuser 1
8a 116578 Impeller for 1 HP Pump (2716) 1
8b 126578 Impeller for 1.5 HP Pump (6589) 1
9 136578 O-Ring 1
10 146578 Pump Cover 1
11 156578 Gasket M10 6
12 166578 Screw 3/8-16 1-1/2 UNC 6
13 176578 Seal Assembly 1
14 186578 Supporting Foot 1
15 196578 Mounting Foot 1
16 206578 Screw M6x20 2
17 216578 Gasket M6 2
18 226578 Nut M6 2
19 236578 Nut 3/8-16 6
20 56578 Drain Gasket 1
21 66578 Drain Plug 1
22 246578 Gasket M10 4
23 256578 Screw M10x25 4
24a 266578 1 HP Motor for 2716 1
24b 276578 1.5 HP Motor for 6589 1

6950 51st Street Kenosha WI 53144|Orders and Customer Care: 1-800-574-7665|Fax: [phone]|Doheny.com

Above Ground Pump Item #’s 2601, 6578 & 6579
REF PART DESCRIPTION No.
No. NUMBER REQ’D
1 16578 Clear Cover 1
2 26578 Lid O-Ring 1
3 36578 Pump Basket 1
4 46578 Retainer Clip 1
5 286578 Strainer Housing 1
6 296578 Pump Cover 1
7a 306578 Impeller for 3/4 HP Pump (2601) 1
7b 316578 Impeller for 1 HP Pump (6578) 1
7c 326578 Impeller for 1.5 HP Pump (6579) 1
8 336578 Seal Assembly 1
9 346578 Pump Housing 1
10 356578 O-Ring 1
11 366578 Screw ST5.5x25 8
12 376578 O-Ring 1
13 56578 Drain Gasket 1
14 66578 Drain Plug 1
15 386578 Motor Mounting Plate 1
16a 396578 3/4 HP Motor for 2601 1
16b 406578 1 HP Motor for 6578 1
16c 416578 1.5 HP Motor for 6579 1

6950 51st Street Kenosha WI 53144|Orders and Customer Care: 1-800-574-7665|Fax: [phone]|Doheny.com
Above Ground Pump Item #’s 4657 & 5014
REF PART DESCRIPTION No.
No. NUMBER REQ’D
1 647252772000 Clear Cover 1
2 65431042080 Lid O-Ring 1
3 647252704001 Pump Basket 1
4 647254201080 Pump Housing 1
5 65431032080 O-Ring 1
6 647254203080 Diffuser 1
7b 647274371000 Impeller for 1 HP Pump (4657) 1
7c 647254271000 Impeller for 1.5 HP Pump (5014) 1
8 65431075080 O-Ring 1
9 647254202080 Pump Cover 1
10 65244005000 Gasket M8 8
11 65221009000 Screw M8X40 8
12 65028003000 Seal Assembly 1
13 65231004106 Nut M8 8
14 65432002080 Gasket 1
15 648860105080 Drain Plug 1
16 647254205080 Foot Insert 1
17 647254204080 Mounting Foot 1
18b 65023020000 1 HP Motor for 4657 1
18c 65023021000 1.5 HP Motor for 5014 1

General Maintenance
1. Clean strainer basket regularly. Do NOT strike
basket to clean. Inspect strainer cover gasket
regularly and replace as necessary.
2. Pumps have self-lubricating motor bearings and
shaft seals. No lubrication is necessary.
3. Keep motor clean. Ensure air vents are free from
obstruction to avoid damage. Do NOT use water
to hose off motor.
4. Occasionally, shaft seals must be replaced, due to
wear or damage.
Storage/Winterization Maintenance
1. Do not purge the system with compressed air. Use only a low
pressure (below 5 psi), high volume blower when air purging
the pump, filter or piping.
2. Allowing the pump to freeze will void the warranty.
3. Use ONLY propylene glycol as antifreeze in your pool/spa system.
4. Drain all water from pump and piping when expecting
freezing temperatures or when storing pump for a long time.
5. Keep motor dry and covered during storage. To avoid
condensation/corrosion problems, do NOT cover or wrap
pump with plastic film or bags.
1 Year Limited Doheny's Pool Pump Warranty
Please read installation instructions before installing pool pump
This pump was inspected before shipment from our warehouse. To original purchasers of this pump, Doheny
Enterprises, Inc., 6950 51st Street, Kenosha, Wisconsin, warrants its products free from defects in materials and
workmanship for a period of ONE (1) year from the date of purchase.
Parts which fail or become defective during the warranty period, except as a result of freezing, negligence,
improper installation, use, or care, shall be replaced, at our option, without charge, within 90 days of the receipt
of defective product, barring unforeseen delays.
After 90 days, to obtain warranty replacements, defective components should be returned, transportation paid, to
the place of purchase. For further Doheny’s service, contact Doheny’s customer care department. No returns may
be made directly to the factory without the express written authorization of Doheny Enterprises, Inc.
To original purchasers of this pump, Doheny Enterprises, Inc. warrants its pump housing/strainer to be free from
defects in materials and workmanship for a period of ONE (1) year from the date of purchase.
Strainers which become defective during the warranty period, except as a result of freezing, negligence, improp-
er installation, use or care, or as the result of a use in association with an automatic valving system.
All other conditions and terms of the standard warranty apply.
Doheny shall not be responsible for cartage, removal and/or reinstallation labor or any other such costs incurred
in obtaining warranty replacements.
The Doheny Enterprises, Inc. warranty does not apply to components manufactured by others. For such products,
the warranty established by the respective manufacturer will apply.
Some states do not allow a limitation on how long an implied warranty lasts, or the exclusion or limitation of inci-
dental or consequential damages, so the above limitation or exclusion may not apply to you.
This warranty gives you specific legal rights, and you may also have other rights, which vary from state to state.
