domi LNCF0544 User manual

ASSEMBLY MANUAL
160 US GAL Metal Deck Box
d mi
o u t d o o r l i v i n g
Missing part? Damaged? Contact us via email at
[email protected]
Copyright 2022-2024 domi LLC. I All Rights Reserved.
©
SKU：LNCF0544

BEFORE STARTING ASSEMBLY
① Some parts have metal edges. Please be careful when handling
components. Always wear work gloves.
② Please check all parts and components to ensure that there are
no damages or missing items BEFORE starting the construction of
the product.
③ Please do not fully tighten the bolts prior to complete assembly.
④ Retain for future reference. Read carefully. For domestic use.

Please do not fully tighten the bolts prior to complete assembly.
！
1

St4x16
St4x16
2
(1) Place part #C on part #A, align the screw holes,
and secure with 4 bolts #X3.
(2) Repeat the above procedure to assemble the other side.
Step 1: Place 2 part #D on part #A, align the screw holes,
and secure with 9 bolt #X3.
Step 2: Place part #F and part #E on part #A, align the
screw holes, and secure with 9 bolt #X3.

Outside
3
St4x16
(1) Insert 4 part #L into the 4 corners of the deck box
and secure with 8 bolt #X3.

4
Step 1: Place part #H on the
storage panel #E & #F as shown,
align the screw holes, and secure
with 9 gaskets and bolts #X2.
Step 2: Place part #I on the
storage panel #D as shown,
align the screw holes, and
secure with 9 gaskets and
bolts #X2.
Step 3: Place part #J on the storage panel as shown, align
the screw holes, and secure with 4 gaskets and bolts #X2.
Step 4: Place part #K on the storage panel as shown, align
the screw holes, and secure with 4 gaskets and bolts #X2.
St4x8

5
Place 4 part #M on the inside of the
box frame, secure with 8 gaskets and
bolts #X1 as shown.
Cover 4 part #N on the corner of the box,
secure with 8 bolt #X3 as shown.
St4x16
M4x10

6
St5x16
M6x25
M4x10
Step 1: Connect part #P and part #Q.
Step 2: Use bolt #Y to secure them to the storage panel.
Use bolt #W2 and gasket #T
to secure part #V on the storage panel as shown.
Place part #B on the storage panel #E & #F, align the screw
holes, and secure with 6 gaskets and bolts #X1 as shown.

7
M6x16
M4x10
St4x8
(1) Use bolt #W1 and nut #U
to connect part #V with the bracket under the lid.
Tighten all the bolts.
！
(2) Use gasket and bolt #X2 to fix part #S to the storage
frame as shown.
(1) Use gasket and bolt #X1 to fix part #R
to the lid as shown.

8

www.domioutdoorliving.com
CARE & SAFETY
It is of utmost importance to assemble all of the parts according to the
directions. Do not skip any step.
Wear safety goggles and always follow the manufacturer's instructions
when using power tools.
Hot items such as recently used grills, blowtorches, etc., must not be
stored in the box.
Not designed for carrying items.
Do not stand on lid.
To prevent risk of suffocation, do not allow children to play inside the box.
IF THERE ARE MISSING OR BROKEN PARTS, PLEASE DO NOT RETURN
THE PRODUCT DIRETCLY.
Please log onto our website, or contact Customer Service.
