Dragonfly DF1330 User manual

Before operating the appliance, please read the instruction manual completely and keep it handly for
future reference.
SAFETY INSTRUCTIONS
READ AND FAMILIARIZE YOURSELF WITH THE SAFETY INSTRUCTIONS BEFORE USING the PUMP
●Compare the incoming voltage and frequency of your electrical circuit with the data on the model
plate. This data must correspond.
●Before reaching in the water always unplug power cords of devices in the water.
●The cable cannot be changed or lengthened. The pump may not be operated if the cable or the housing
are defective.
●Pay close attention when this pump are used near children's activity areas.
Keep way from moving part to avoid any harm.
●Please disconnect all accessories if the pump does not work.
●Do not carry or pull the pump by the connecting power cord.
●Do not change the pump impellor with any other brand/type of pump, as parts are not interchangable.
●Lay the power cord in a protected conduit to prevent the possibility of cable damage
Installation
Insert the suction cups or rubber feet at the base of the pump motor body, then install the pump
submersed under water surface completely.

Use
The flow rate can be adjusted at the flow control valve. Pump with switch on immediately after plug is
plugged into power supply.
Maintenance
The bearing, shaft and shaft sleeve will wear, and perish and/or break over time. As a result, it will sound
noisy. You can then change the impellor part when necessary.
●How to change:
① Unplug the power, ② Open the impeller chamber, replace the old impellor with the new one. Taking
care to replace all the parts and not break the (ceramic) shaft.
Caution
To avoid possible electric shock, special care should be taken when handling this product.
In each of the following situations, do not attempt repair unit by yourself. Discard the appliance:
★ If the appliance shows any sign of abnormal water leakage, immediately unplug unit from the power
source.
★ Do not operate any appliance if it has a damaged cable or plug, if it is malfunctioning or it has been
dropped or damaged in any manner.
★ To avoid the possibility of the plug getting wet, please ensure that the power supply is sufficiently far
away from the unit before plugging into power supply.
★If the plug or receptacle does get wet, don't unplug the cord. First disconnect the fuse or circuit
breaker that supplies power to the appliance. Then unplug and examine.
Technical Specifications
Model No
Voltage
Frequency
Power
Max Head
Max Flow
Working Conditions
DF-330
220~240V
50Hz
5w
0.8m
400LPH
Fresh Water
DF-440
8w
1m
600LPH
DF-880
16w
1.3m
800LPH
DF-1050
22w
1.6m
1000LPH
DF-1770
40w
2.5m
1800LPH
Fresh&Salt Water
DF-2050
55w
2.5m
2000LPH
DF-3050
85w
3.5m
3000LPH
DF-5050
70w
5.6m
8000LPH
The DF2050, 3050 and 5050 can be used in and out of water. i.e. They are amphibious.
