Owner’s Manual & Safety Instructions
Save This Manual Keep this manual for the safety warnings and precautions, assembly,
operating, inspection, maintenance and cleaning procedures. Write the product’s serial number in the
back of the manual near the assembly diagram (or month and year of purchase if product has no number).
Keep this manual and the receipt in a safe and dry place for future reference. 20k
When unpacking, make sure that the product is intact
and undamaged. If any parts are missing or broken,
please call 1-888-866-5797 as soon as possible.
Copyright© 2020 by Harbor Freight Tools®. All rights reserved.
No portion of this manual or any artwork contained herein may be reproduced in
any shape or form without the express written consent of Harbor Freight Tools.
Diagrams within this manual may not be drawn proportionally. Due to continuing
improvements, actual product may differ slightly from the product described herein.
Tools required for assembly an d se rv ic e may n ot b e in cl uded.
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE THIS MANUAL.

Page 2 For technical questions, please call 1-888-866-5797. Item 58033
WARNING SYMBOLS AND DEFINITIONS
This is the safety alert symbol. It is used to alert you to potential
personal injury hazards. Obey all safety messages that
follow this symbol to avoid possible injury or death.
Indicates a hazardous situation which, if not avoided,
will result in death or serious injury.
Indicates a hazardous situation which, if not avoided,
could result in death or serious injury.
Indicates a hazardous situation which, if not avoided,
could result in minor or moderate injury.
Addresses practices not related to personal injury.
IMPORTANT SAFETY INFORMATION
Read all safety warnings, instructions, illustrations and specifications provided with this power tool.
Failure to follow all instructions listed below may result in electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference.
Before start-up, note the following:
The pump must be connected to a GFCI protected plug which has been installed according
to regulations. The plug must have a supply voltage of 120 VAC at 60 Hz.
CAUTION
This pump has been evaluated for use with water only.
WARNING
IMPORTANT! For your own safety –
before starting to run the pump, please have
the following items checked by an expert:
1. Risk of electric shock – This pump is supplied
with a grounding conductor and grounding-type
attachment plug. To reduce the risk of electric shock,
be certain that it is connected only to a properly
grounded, grounding-type receptacle.
2. Risk of electric shock – This pump has not been
investigated for use in swimming pool areas.
3. The electrical connections must be
protected from moisture.
4. If there is danger of flooding, the electrical
connections must be taken to higher ground.

Page 3For technical questions, please call 1-888-866-5797.Item 58033
5. Circulation of caustic fluids, as well as the circulation
of abrasive materials, must be avoided at all costs.
6. The pump must be protected from frost.
7. The pump must be protected from running dry.
8. Access by children should also be
prevented with appropriate measures.
9. To prevent death from electric shock,
pump must be connected only to a GFCI
protected outlet.
10. Do not pump flammable materials. Motor
brushes may spark and cause
explosions.
11. Do not use an extension cord with this item.
12. People with pacemakers should consult their
physician(s) before use. Electromagnetic fields in
close proximity to heart pacemaker could cause
pacemaker interference or pacemaker failure.
13. The warnings, precautions, and instructions
discussed in this instruction manual cannot cover all
possible conditions and situations that may occur.
It must be understood by the operator that
common sense and caution are factors
which cannot be built into this product, but
must be supplied by the operator.
Fluid Type
The Pump is designed for use with water with a maximum temperature of 95° F (35°C). Do not use the pump
for other fluids, especially not fuels, cleaning fluids, or other chemical products.
Specifications
Electrical Rating 120VAC / 60Hz / 9.6A
Power Cord Length 10′
Maximum Flow @ 0’ 2500 GPH
Maximum Head lift @ 0 Flow 100′
Discharge Port 1″ NPT
Installation
The pump must be installed in a stationary position with either:
a. A fixed pipeline or
b. A flexible hose pipe.
Please note!
1. Do not install the pump by suspending it
unsupported from its delivery pipe or power cord.
The pump must be suspended from the handle
or be placed on the bottom of the basin.
To ensure that the pump works properly, keep the
bottomfree from sludge and dirt of all kinds.
2. If the water level sinks too low, any sludge in the
basin will dry out and stop the pump from starting.
To help ensure the pump will start as required,
check the pump regularly with start-up tests.
Power Supply
1. The pump is equipped with a shock-proof plug
according to regulations. The pump is designed to be
connected to 120 VAC, 60 Hz GFCI protected socket.
2. Make sure that the socket is sufficiently
secured and is in excellent condition.
3. When the plug is inserted into the socket,
the pump will be on standby.
4. WARNING: To prevent death from electric
shock, pump must be connected only to
a GFCI protected outlet.
WARNING! If the power cord or plug is damaged,
do not use the pump. The power cord or plug
may only be repaired by a certified electrician.

Page 4 For technical questions, please call 1-888-866-5797. Item 58033
Areas of use
1. This pump is designed to pump water only.
2. This pump is designed to be used for:
General purpose removal or transfer of clear water.
3. This pump should NOT be used for:
Continuous run, fountain/pond water features.
Removing water from swimming pools or
spas. Septic or sewage systems.
4. This pump can also be used to transfer water
(e.g., household, farming, plumbing).
Installation Instructions
1. Attach hose to Pump intake port. Attach
second hose to Pump discharge port.
2. Position Pump on solid surface so that
both hoses are free from kinks. Plug Power
Cord into GFCI protected outlet.
GFCI-
Protected
Receptacle
Figure A: GFCI Plug
3. Place unused end of intake hose in water to
be transferred. Place unused end of discharge
hose as needed to direct the water discharge
at least 3 feet away from the source.
Figure B: Pump Position
Operation
After reading these instructions, consider the following points before starting the pump:
1. Verify that the discharge pipe is properly connected.
2. Verify that the electrical connection
is 120 VAC, 60 Hz.
3. Verify that the electrical socket is GFCI
protected and in good condition. Test
GFCI protected outlet before use.
4. Verify that water and moisture cannot
get near the power supply socket.
5. Verify that the pump is installed so
as to prevent running dry.
Maintenance
TO PREVENT SERIOUS INJURY FROM ACCIDENTAL OPERATION:
Unplug the Pump from its electrical outlet before performing any
inspection, maintenance, or cleaning procedures.
If the pump is moved during operation, flush it out with clean water after every use.

Page 5For technical questions, please call 1-888-866-5797.Item 58033
Quarterly Maintenance
The below maintenance must be performed at least once every 3 months under optimal conditions.
For frequent use, or dirty areas, more frequent maintenance is required.
1. Clean sludge and debris from the bottom of the basin.
2. Clean sludge/debris from inlet screen.
3. Make sure discharge pipe is free from leaks.
4. Make sure check valve is functioning properly.
5. Manually operate any separate flow
switch (not included) to determine that
pump turns on/off as intended.
Carbon Brush Maintenance
The carbon brushes may require maintenance when
the motor performance of the pump decreases or
stops working completely. To maintain the brushes:
1. Remove the carbon brushes from the
housing. Keep track of which orientation
the old carbon brushes were in to prevent
needless wear if they will be reinstalled.
2. If either carbon brush is worn down by more
than 1/2, replace both carbon brushes.
3. To clean old carbon brushes before reusing them,
rub the contact areas with a pencil eraser.
4. Reinsert the old carbon brushes in the
same orientation to reduce wear.
5. When installing the carbon brushes, make sure the
carbon portions of the carbon brushes contact the
motor armature, and that the springs face away from
the motor. Also, make sure the springs operate freely.
Note: New carbon brushes tend to spark when first used
until they wear and conform to the motor’s armature.

Page 6 For technical questions, please call 1-888-866-5797. Item 58033
Parts List and Diagram
PLEASE READ THE FOLLOWING CAREFULLY
THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY DIAGRAM
IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR DISTRIBUTOR
MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE OR SHE IS
QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS QUALIFIED TO REPLACE
ANY PARTS OF THE PRODUCT. IN FACT, THE MANUFACTURER AND/OR DISTRIBUTOR EXPRESSLY
STATES THAT ALL REPAIRS AND PARTS REPLACEMENTS SHOULD BE UNDERTAKEN BY CERTIFIED AND
LICENSED TECHNICIANS, AND NOT BY THE BUYER. THE BUYER ASSUMES ALL RISK AND LIABILITY
ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS
THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION OF REPLACEMENT PARTS THERETO.
Parts List
Part Description Qty.
1 Rubber Foot 3
2 Pump Facing 1
3 Hose Fitting 1 2
4 O-Ring 1
5 Cap 1
6 Pump Gasket 1
7 Impeller 1
8 Spring Washer 4
9 Mechanical Seal 1
10 Hex Head Screw 4
11 Water Retaining Washer 1
12 Guide Plate 1
13 Grooved Pan Head Screw 2
14 Spring Washer 5
15 Flat Washer 2
16 Ball Bearing 1
17 Carbon Brush Combination 2
18 Armature 1
19 Ball Bearing 1
Part Description Qty.
20 Stator 1
21 Pump Housing 1
22 Cable Box 1
23 Allen Flat End Set Screw 2
24 Copper Terminals 2
25 Wiring Cap 2
26 Grooved Pan Head Screw 2
27 Power Cord Clamp 1
28 Connection Buckle 1
29 Waterproof Power Switch 1
30 Power Cord 1
31 Grounding Screw 1
32 Earthing Terminal 1
33 External Serrated Lock Washer 1
34 Basket Filter 1
35 Hose Fitting 2 2
36 Cage Filter 1
37 Collapsible Tube (not shown) 2
Record Product’s Serial Number Here:
Note: If product has no serial number, record month and year of purchase instead.
Note: Some parts are listed and shown for illustration purposes only, and are not available
individually as replacement parts. Specify UPC 193175431028 when ordering parts.

Page 7For technical questions, please call 1-888-866-5797.Item 58033
Assembly Diagram

Limited 90 Day Warranty
Harbor Freight Tools Co. makes every effort to assure that its products meet high quality and durability standards,
and warrants to the original purchaser that this product is free from defects in materials and workmanship for the
period of 90 days from the date of purchase. This warranty does not apply to damage due directly or indirectly,
to misuse, abuse, negligence or accidents, repairs or alterations outside our facilities, criminal activity, improper
installation, normal wear and tear, or to lack of maintenance. We shall in no event be liable for death, injuries
to persons or property, or for incidental, contingent, special or consequential damages arising from the use of
our product. Some states do not allow the exclusion or limitation of incidental or consequential damages, so the
above limitation of exclusion may not apply to you. THIS WARRANTY IS EXPRESSLY IN LIEU OF ALL OTHER
WARRANTIES, EXPRESS OR IMPLIED, INCLUDING THE WARRANTIES OF MERCHANTABILITY AND FITNESS.
To take advantage of this warranty, the product or part must be returned to us with transportation charges
prepaid. Proof of purchase date and an explanation of the complaint must accompany the merchandise.
If our inspection verifies the defect, we will either repair or replace the product at our election or we may
elect to refund the purchase price if we cannot readily and quickly provide you with a replacement. We will
return repaired products at our expense, but if we determine there is no defect, or that the defect resulted
from causes not within the scope of our warranty, then you must bear the cost of returning the product.
This warranty gives you specific legal rights and you may also have other rights which vary from state to state.
26541 Agoura Road • Calabasas, CA 91302 • 1-888-866-5797
