AIR MOVER MANUAL
TEMPEST™TYPHOON™

Congratulations on your purchase of a Dry Air Technology Air Mover. Dry Air Technology Air Movers
are conveniently small and extremely lightweight yet powerful enough to create airflow beyond your
expectations. They have been engineered to be durable, long lasting and high performing. These air
movers have been rigorously tested for heavy-duty us.
Your new unit was designed to provide the maximum performance. Please read this owner’s manual
carefully to insure that you get the most from your unit.
SAFETY INFORMATION
CAUTION!
Unit operates on alternating current:
110/120 volt, 60 Hz or 220/240 volt, 50 Hz
Do not operate your air mover with a cut or frayed power cord. Do not unplug your unit by pulling on its
cord. Grasp the plug firmly and pull it out of the wall socket or power receptacle. The plug has a safety
ground pin installed that must not be removed. If the pin is damaged or missing, have the power cord
replaced at once. Visually inspect the power cord before each use. Ignoring these safety precautions
may result in a fire or an electric shock.
To reduce the risk of fire or electric shock, do not use this fan with any solid state speed control device.
Never operate electrical equipment in standing water. There is a shock hazard.
Never drop the unit. Sudden and severe impact may result in damage to internal components.
Your air mover should never be operated with the safety grills removed. Personal injury may result.
Drop cloths or other loose fabrics can be drawn against the unit thereby restricting airflow. This
condition may cause the unit to overheat. Keep the air inlet clear of any obstructions.
Save the shipping carton in case your air mover must be returned for repair.
This unit should never be serviced or cleaned while it is plugged into a live electrical power source.
WARNING: Ignoring these safety precautions may result in serious personal injury.

TEMPEST™TYPHOON™
OPERATING INSTRUCTIONS
Please inspect your unit upon receipt for any freight damages. Be sure to keep all original packaging.
Original packaging will help protect unit from freight damage upon return.
If you discover any damages during inspection, please contact Dry Air Technology.
The unit as packaged is ready to be put into service. If you have a 220v model, attach the appropriate
plug for your region.
Inspect the unit completely for any shipping damage. Place the unit on the ground or on a very stable
platform.
Plug the unit into a grounded alternating current circuit and switch the unit on.
MAINTENANCE
When turning on equipment for use, always check to make sure the unit is running properly.
When the unit is first turned on, check for excessive vibration or noise. This would indicate a major
problem. If your unit is running abnormally, troubleshoot to find the cause and make any necessary
adjustments or repairs. Do not allow the unit to run when problem persists. A simple adjustment
problem can turn into complete motor failure if not corrected.
Warning
Disconnect the unit from the power supply before cleaning or servicing.
SPECIFICATIONS
Model Voltage Motor RPM Speed Amps Max
SP Dimensions (H x L x W) Weight
Tempest 230V 50/60Hz .4 HP 1050 2 2 1.50 17” x 18.5” x 15.5” 28 lbs
Tempest 115V 60Hz .4 HP 1050 2 4 1.50 17” x 18.5” x 15.5” 28 lbs
Typhoon 115V 60Hz .4 HP 1050 3 4 1.50 17” x 18.5” x 15.5” 28 lbs
Wheel Size for all units is 9.5” x 9.5”.

ATTN: PRODUCT UPDATE
The new Typhoon Air Mover is now equipped with a .4 HP motor, GFCI receptacle and 15 amp breaker. The GFCI
Receptacle and 15 amp breaker gives you the ability to plug one fan into another, reducing the chaos and clutter of extension
cords and power cords crisscrossing the drying site. This outlet is GFCI (Ground Fault Circuit Interrupter) protected and
incorporates a dedicated circuit breaker. You can plug three Typhoon Air Movers into each other on a 15 amp circuit. For
your convenience a 3mm Allen Wrench is included to remove the intake grill to provide access to the blower wheel and
motor.
TROUBLE SHOOTING
Problem Cause Solution
Unit will not run. 1. GFCI has tripped
2. No power to unit.
3. Switch not on.
4. Switch is faulty.
5. Faulty/broken cord or motor wire.
1. Reset GFCI, it must be a properly
grounded receptacle.
2-A. Check the 15 amp circuit breaker
on control panel. Reset if necessary.
2-B. Check the building fuse or circuit
breaker. Reset breaker or replace fuse.
3. 3. Place in “ON” position.
4. Replace switch.
5. Perform continuity check, using
volt/amp meter. Repair/replace faulty
broken wire.
Unit runs but fan makes
loud scraping noise. 1. Unit has been severely jolted causing fan to rub against housing.
2. Unit has been severely jolted causing
housing to deform.
1. Remove motor and replace damaged
motor mounts.
2. Replace fan blade.
Unit runs but vibrates
excessively. 1. Severe jolt has bent motor shaft causing unit to be out of balance.
2. Fan blade damaged.
3. Dirt build up on one side of
fan blade.
1. Remove and replace motor.
2. Replace blade if necessary.
3. Clean fan blade.
Unit runs but fan does not
turn. 1. Fan is jammed against housing.
2. Capacitor wire has broken/come loose,
capacitor has failed.
3. Housing has been damaged such that it
presses on fan blade.
1. Remove motor and replace damaged
motor mounts. Replace fan blade if
necessary.
2. Repair/replace wires/capacitor as
necessary.
3. Replace housing/unit as necessary.
Unit runs briefly, and then
shuts off. 1. Motor bearings are failing or motor has developed an internal electrical fault.
2. Intake grill and/or exhaust grill
is obstructed.
3. Excessive duct length.
1. Replace motor.
2. Remove obstruction.
3. Reduce the duct length to the
recommended maximum.

Trouble Shooting
Problem Cause Solution
Unit will not run. 1. No power to unit.
2. Switch not on.
3. Switch is faulty.
4. Faulty/broken cord or motor wire.
1. Plug unit in. Check circuit
breaker.
2. Place in “ON” position.
3. Replace switch.
4. Perform continuity check, using
volt/amp meter. Repair/replace
faulty broken wire.
Unit runs but air
mover makes loud
scraping noise.
1. Unit has been severely jolted
causing blower wheel to rub against
housing.
2. Unit has been severely jolted
causing housing to deform.
1. Remove motor and replace
damaged motor mounts.
2. Replace blower wheel.
Unit runs but vibrates
excessively. 1. Severe jolt has bent motor shaft causing unit to be out of balance.
2. Air mover blade damaged.
3. Dirt build up on one side of
air mover blade.
1. Remove and replace motor.
2. Replace blade if necessary.
3. Clean air mover blade.
Unit runs but blower
wheel does not turn. 1. Blower wheel is jammed against housing.
2.Capacitor wire has broken/come
loose, capacitor has failed.
3. Housing has been damaged such
that it presses on blower wheel.
1. Remove motor and replace
damaged motor mounts. Replace
blower wheel if necessary.
2.Repair/replace wires/capacitor
as necessary.
3. Replace housing/unit as
necessary.
Unit runs briefly, then
shuts off on overload. 1. Motor bearings are failing or motor has developed an internal
electrical fault.
2. Intake grill and/or exhaust grill
is obstructed.
3. Excessive duct length.
1. Replace motor.
2. Remove obstruction.
3.Reduce duct length to
recommended maximum.

Dry Air Technology 10 Year Limited Warranty
Axial and Centrifugal Air Flow Products
Warrantor: Dry Air Technology, 313 North Oak Street, Burlington, WA 98233. Telephone: 888-755-
9176, local: 360-755-9176, fax: [phone].
Who Is Covered: This warranty extends to the original end-user of axial and centrifugal air flow devices
manufactured by Dry Air Technology, and may not be assigned or transferred.
Warranty Period: The term of the warranty coverage from the date of purchase is:
10 years on the cabinet, chassis and housing
1 year on parts, labor and reasonable shipping costs, excluding filters and accessories.
Warranty Coverage: Dry Air Technology warrants that, for one year, axial and centrifugal air flow
devices manufactured by Dry Air Technology will operate free from defects in material or workmanship, or
Dry Air Technology, at its option, will repair or replace the defective part(s), free of charge.
Dry Air Technology further warrants that for a period of ten (10) years, the cabinet, chassis and housing of
axial and centrifugal air flow devices manufactured by Dry Air Technology, will be free from defects in
material or workmanship, or Dry Air Technology, at its option, will repair or replace the defective part(s),
provided that all labor and shipping costs for the defective part(s) shall be borne by the end-user.
This warranty does not cover any defect, malfunction, etc. resulting from misuse, abuse, lack of normal care,
corrosion from chemicals, freezing, tampering, modification, unauthorized or improper repair or operation,
accident, acts of nature or any other cause beyond Dry Air Technology’s reasonable control.
End-User Responsibilities: Warranty service must be performed by a firm or individual authorized by
Dry Air Technology. If the end-user is unable to locate or obtain warranty service from an authorized firm or
individual, he should contact Dry Air Technology at the above location, which will arrange for covered
warranty service. All covered warranty service will be performed during normal business hours.
Limitations and Exclusions: If any part of a axial or centrifugal air flow device manufactured by Dry
Air Technology is repaired or replaced, the new part shall be warranted only for the remainder of the original
warranty period of the air flow device (but all warranties will be extended by the period of time, if any, that
the Dry Air Technology air flow device is out of service while waiting for covered warranty service).
UPON THE EXPIRATION OF THE WRITTEN WARRANTY APPLICABLE TO THE DRY AIR TECHNOLOGY AIR FLOW
DEVICE OR ANY PART THEREOF, ALL OTHER WARRANTIES IMPLIED BY LAW, INCLUDING MERCHANTABILITY
AND FITNESS FOR A PARTICULAR PURPOSE, SHALL ALSO EXPIRE. ALL WARRANTIES MADE BY DRY AIR
TECHNOLOGY ARE SET FORTH HEREIN, AND NO CLAIM MAY BE MADE AGAINST DRY AIR TECHNOLOGY
BASED ON ANY ORAL WARRANTY. IN NO EVENT SHALL DRY AIR TECHNOLOGY, IN CONNECTION WITH THE
SALE, OPERATION, REPAIR OR REPLACEMENT OF ANY DRY AIR TECHNOLOGY AIR FLOW DEVICE OR PART
THEREOF BE LIABLE UNDER ANY LEGAL THEORY FOR ANY SPECIAL, INDIRECT OR CONSEQUENTIAL
DAMAGES INCLUDING WITHOUT LIMITATION WATER DAMAGE (THE END-USER SHOULD TAKE
PRECAUTIONS AGAINST SAME), LOST PROFITS, DELAY, OR LOSS OF USE OR DAMAGE TO ANY REAL OR
PERSONAL PROPERTY.
Some states do not allow limitations on how long an implied warranty lasts, and some do not allow the
exclusion or limitation of incidental or consequential damages, so one or both of these limitations may not
apply to you.
Legal Rights: This warranty gives you specific legal rights, and you may also have other rights which
vary from state to state. DRY AIR TECHNOLOGY, BURLINGTON, WASHINGTON
