DS Automobiles DS 7 CROSSBACK User manual

DS 7 CROSSBACK
HANDBOOK

Access to the Handbook
MOBILE APPLICATION
Install theScan MyDSapplication(content available
offline).
ONLINE
Visit the DS AUTOMOBILES website and select the
‘MyDS’ section to view or download the handbook or go
to the following address:
http://service.dsautomobiles.com
Scan this QR Code for direct access.
This symbol indicates the latest
information available.
Then select:
– the vehicle,
– the issue period corresponding to the vehicle’s initial
registration date.
Select:
– the language,
– the vehicle and body style,
– the issue period of the handbook corresponding to the
vehicle’s initial registration date.

WELCOME
Thank you for choosing a DS7 CROSSBACK or a DS7 CROSSBACK E-TENSE.
This document presents the key information and recommendations required
for you to be able to explore your vehicle in complete safety. We strongly
recommend familiarising yourself with this document and the Warranty and
Maintenance Record.
Your vehicle will be fitted with only some of the equipment described in this
document, depending on its trim level, version and the specification for the
country in which it was sold.
The descriptions and illustrations are for guidance only.
The DS AUTOMOBILES brand is marketed by Automobiles CITROËN, a public
limited company with capital of €159,000,000, the headquarters of which is
at 7 rue Henri Sainte-Claire Deville, 92500 Rueil-Malmaison, France, registered
with the Nanterre Trade and Companies Register under no. 642 050199,
hereafter referred to as the “Manufacturer”, which reserves the right to modify
thetechnical specifications, equipment and accessories without having to
update this edition of the handbook.
If ownership of your vehicle is transferred, please ensure this Handbook is
passed on to the new owner.
Key
Safety warning
Additional information
Environmental protection feature
Left-hand drive vehicle
Right-hand drive vehicle
Location of the equipment / button
describedusing a black area.

2
Contents
Overview
Eco-driving
01 Instruments
9Instrument panels
12 Warning and indicator lamps
18 Indicators
21 Manual test
21 Total distance recorder
22 Lighting dimmer
22 Trip computer
23 Clock
23 Touch screen
26 Remote features (Hybrid)
02 Access
27 Electronic key with remote control function
and built-in key,
28 Keyless Entry and Starting
30 Central locking
31 Back-up procedures
33 Doors
33 Boot
34 Hands-free tailgate
37 Alarm
39 Electric windows
40 Panoramic sunroof
03 Ease of use and comfort
42 Driving position
43 Front seats
47 Steering wheel adjustment
47 Mirrors
49 Rear seats
51 DS SENSORIAL DRIVE function
51 Heating and Ventilation
53 Manual air conditioning
54 Dual-zone automatic air conditioning
57 Front demist - defrost
57 Rear screen demist - defrost
57 Heated windscreen
58 Additional heating/ventilation system
59 Thermal pre-conditioning (Hybrid)
60 Front fittings
64 Touch-sensitive courtesy lamps
64 Interior ambience lighting
65 Rear fittings
65 Boot fittings
04 Lighting and visibility
68 Exterior lighting control stalk
69 Daytime running lamps / Sidelamps
70 Direction indicators
70 Automatic illumination of headlamps
70 Guide-me-home and welcome lighting
71 DS NIGHT VISION
72 Automatic headlamp dipping
74 Adaptive Front System (AFS)
75 Dynamic bend lighting
76 Headlamp adjustment
76 Wiper control stalk
78 Changing a wiper blade
79 Automatic wipers
05 Safety
80 General safety recommendations
80 Hazard warning lamps
81 Horn
81 Pedestrian horn(Hybrid)
81 Emergency or assistance call
83 Electronic stability control (ESC)
85 Advanced Traction Control
86 Seat belts
88 Airbags
90 Child seats
92 Deactivating the front passenger airbag
95 ISOFIX child seats
99 i-Size child seats
99 Child lock
06 Driving
101 Driving recommendations
102 Anti-theft protection
102 Starting/Switching off the engine
103 Starting hybrid vehicles
104 Electric parking brake
107 Manual gearbox
107 Automatic gearbox
110 e-EAT8 electric automatic gearbox (Hybrid)
111 DS ACTIVE SCAN SUSPENSION
111 Driving modes
113 Hill start assist
114 Gear efficiency indicator
114 Stop & Start
116 Tyre under-inflation detection
117 DS ConnectedCAM
118 Driving and manoeuvring aids -
General recommendations
119 Speed Limit Recognition and Recommendation
122 Speed limiter
123 Cruise control - particular recommendations
124 Programmable cruise control
125 DS DRIVE ASSIST

3
Contents
bit.ly/helpPSA
Access to additional videos
125 Adaptive Cruise Control
129 Active Lane Keeping Assist
133 Active Safety Brake with Collision Risk Alert and
Intelligent emergency braking assistance
135 Distraction detection
136 Lane Departure Warning System
137 Active Lane Departure Warning System
140 Blind Spot Detection
142 Active Blind Spot Detection
142 Parking sensors
144 Reversing camera - 360 Vision
148 Park Assist
150 DS PARK PILOT
07 Practical information
156 Compatibility of fuels
156 Refuelling
157 Misfuel prevention (Diesel)
157 Hybrid system
161 Charging the traction battery (Hybrid)
163 Towing device
165 Energy economy mode
165 Very cold climate screen
166 Snow chains
166 Roof bars
167 Bonnet
168 Engine compartment
169 Checking levels
171 Checks
172 AdBlue® (BlueHDi)
174 Free-wheeling
175 Advice on care and maintenance
08 In the event of a breakdown
177 Warning triangle
177 Running out of fuel (Diesel)
178 Tool kit
179 Temporary puncture repair kit
181 Spare wheel
185 Changing a bulb
188 Changing a fuse
190 12V battery
193 Accessory batteries (Hybrid)
195 Towing the vehicle
09 Technical data
198 Engine technical data and towed loads
199 Petrol engines
201 Diesel engines
203 Hybrid engines
204 Dimensions
204 Identification markings
10 DS CONNECT RADIO
205 First steps
206 Steering mounted controls
207 Menus
208 Applications
208 Radio
210 DAB (Digital Audio Broadcasting) radio
210 Media
211 Telephone
215 Settings
216 Frequently asked questions
11 DS CONNECT NAV
218 First steps
219 Steering mounted controls
219 Menus
221 Voice commands
224 Navigation
227 Connected navigation
229 Applications
232 Radio
233 DAB (Digital Audio Broadcasting) radio
234 Media
235 Telephone
238 Settings
240 Frequently asked questions
Alphabetical index

4
Overview
Instruments and controls
These illustrations and descriptions are intended
as a guide. The presence and location of certain
elements may vary, depending on the version or
trim level.
1. Bonnet release
2. Dashboard fuses
3. Courtesy lamp
Warning lamp display for seat belts and front
passenger airbag
Panoramic sunroof controls
Interior rear view mirror/driving indicator LED
in ELECTRIC mode (Hybrid)
Emergency and assistance call buttons
Deactivation of the alarm's interior
volumetric and anti-tilt monitoring
4. Starting/switching off the engine
Clock
5. Touch screen with DS CONNECT RADIO or DS
CONNECT NAV
6. Wireless smartphone charger
12V socket / USB socket
7. Electric parking brake
Select a driving mode
8. Glove box
Deactivate the front passenger airbag
9. Electric windows
Central locking
Electric child lock
10. Gearbox
11. Horn
Driver front airbag
12. Instrument panel
Steering mounted controls
1. External lighting controls / Direction
indicators
2. Infra-red camera
3. Wiper controls / Screenwash / Trip computer

5
Overview
4. Audio system controls
A. Choice of instrument panel display mode
B. Voice commands
C. Decrease / increase volume
D. Select previous / next media
Confirm a selection
E. Access to the Telephone menu
Manage calls
F. Select an audio source
G. Display the list of radio stations / audio tracks
5. Cruise control / speed limiter controls
Side switch panel
1. Halogen headlamp beam height adjustment
2. Door mirrors adjustment
3. Stop & Start
4. Heated windscreen
5. Lane departure warning system
6. Programmable heating operation indicator
lamp
7. Active lane departure warning system
8. Lane positioning assist
9. Opening / closing the hands-free tailgate
10. Opening the fuel filler flap (Hybrid)
Central switch panel
1. Access to theHybridmenu or to theDS
SENSORIAL DRIVEfunction (depending on
version)
2. Automatic visibility programme
3. Rear screen demisting / defrosting
4. Ventilation off
5. Manual recirculation of the interior air
6. Access to the Climate menu
7. Audio system on/off
8. Volume adjustment
9. Access to the RadioMedia menu
10. Access to the Navigation menu
11. Access to the Driving or Vehicle menu
12. Access to the Applications menu
13. Access to the Telephone menu
14. Hazard warning lamps
Rechargeable hybrid system
1. Petrol engine
2. Front and rear electric motors (depending on
version)
3. Traction battery
4. 12 V accessory batteries
5. 8-speed electric automatic gearbox (e-EAT8)
6. Charging flap
7. Fuel filler flap
8. Driving mode selector
9. Charging cable
The rechargeable hybrid technology combines
two sources of energy: that of the petrol engine
and that of one or two electric motors (depending
on version).

6
Overview
The engine and the motor can operate alternately
or simultaneously, according to the operating
mode selected and the driving conditions.
Electric power alone provides the mobility of the
vehicle in ELECTRIC mode, and in HYBRID mode
in case of moderate demand. It assists the petrol
engine during the phases of starting-up and
acceleration.
Electric power is supplied by a rechargeable
traction battery.

7
Eco-driving
Eco-driving
Eco-driving refers to a range of everyday practices
that allow the motorist to optimise their fuel
consumption and CO2emissions.
Optimise your use of the gearbox
With a manual gearbox, move off gently and
change up promptly. While accelerating, change
up early.
With an automatic gearbox, favour automatic
mode and avoid pressing the accelerator pedal
heavily or suddenly.
The gear efficiency indicator prompts you to
engage the most suitable gear: whenever this
indication is displayed on the instrument panel,
follow it straight away.
With an automatic gearbox, this indicator
appears only in manual mode.
Drive smoothly
Maintain a safe distance between vehicles, use
engine braking rather than the brake pedal and
press the accelerator gradually. These attitudes
help to save fuel, reduce CO2emissions and
decrease general traffic noise.
Favour the use of the "Eco" driving mode by
selecting it using the "Drive Mode" control.
If the vehicle has the steering-mounted "CRUISE"
control, use cruise control at speeds above 25
mph (40km/h) when the traffic is flowing well.
Use electrical equipment wisely
Before moving off, if the passenger compartment
is too warm, ventilate it by opening the windows
and air vents before using the air conditioning.
At speeds above 31mph (50km/h), close the
windows and leave the air vents open.
Consider using equipment that can help keep the
temperature in the passenger compartment down
(sunroof blind and window blinds, etc.).
Unless automatically regulated, switch off the air
conditioning as soon as the desired temperature
has been reached.
Switch off the demisting and defrosting
functions, if they are not managed automatically.
Switch off the heated seat as soon as possible.
Switch off the headlamps and foglamps when the
visibility conditions do not require their use.
Avoid running the engine before moving off,
particularly in winter; your vehicle will warm up
much faster while driving.
As a passenger, avoid connecting your multimedia
devices (film, music, video game, etc.) to help
reduce consumption of electrical energy, and
hence fuel.
Disconnect all portable devices before leaving the
vehicle.
Limit the causes of excess consumption
Spread loads throughout the vehicle; place the
heaviest items in the boot, as close as possible to
the rear seats.
Limit the loads carried in the vehicle and minimise
wind resistance (roof bars, roof rack, bicycle
carrier, trailer, etc.). Preferably, use a roof box.
Remove roof bars and roof racks after use.
At the end of winter, remove snow tyres and refit
summer tyres.
Comply with servicing instructions
Check tyre pressures regularly, with the tyres
cold, referring to the label in the door aperture on
the driver's side.
Carry out this check in particular:
– before a long journey.
– at each change of season.
– after a long period out of use.
Do not overlook the spare wheel and, where
applicable, the tyres on your trailer or caravan.
Have your vehicle serviced regularly (engine oil,
oil filter, air filter, passenger compartment filter,
etc.) and observe the schedule of operations in
the manufacturer's service schedule.
With a BlueHDi Diesel engine, if the SCR system
is faulty, your vehicle will emit pollution; visit a
dealer or a qualified workshop as soon as possible
to restore your vehicle’s nitrogen oxide emissions
to regulatory compliance.
When filling the fuel tank, do not continue after
the third nozzle cut-out, to avoid overflow.

8
Eco-driving
You will only see the fuel consumption of your new
vehicle settle down to a consistent average after
the first 1,900 miles (3,000 kilometres).
Optimising the driving range (hybrid vehicles)
Connect the vehicle as soon as possible.
Favour the ECO zone of the power indicator by
driving smoothly and at a steady speed.
Anticipate slowing down as much as possible and,
if possible, favour decelerations with regenerative
braking (power indicator in the CHARGE zone).
When GPS navigation is activated, select the
HYBRID mode to optimise electric consumption.

9
Instruments
01
Matrix instrument panel
Dials
1. Analogue speedometer (mph or km/h)
2. Fuel gauge
3. Engine coolant temperature indicator (°C)
4. Rev counter (x 1,000 rpm)
Central display
5. Status of cruise control / speed limiter
6. Gear shift indicator
Status of automatic gearbox
7. Customised display area
Alert messages
8. Total distance recorder (miles or km)
9. Service spanner
Selecting the type of information
To modify the type of information in the
customised display area of the screen:
► Rotate the dial located to the left of the
steering wheel to display and scroll through the
different types of information.
The new display is applied instantly.
Depending on the vehicle's equipment level, the
following types of information are available:
– Digital speedometer.
– Trip computer.
– Traffic sign recognition.
– Driving aids.
– Vigilance level.
– Reminder of navigation instructions.
– Dynamic vehicle parameters (Sport mode).
Digital instrument panel
This digital instrument panel can be customised.
Depending on the display mode selected, certain
information is hidden or presented differently.
Example with the “PERSONAL” display mode:
1. Fuel gauge
2. Trip computer

10
Instruments
01
3. Gear shift indicator
Status of the automatic gearbox
Driving mode
4. Digital speedometer (mph or km/h)
5. Cruise control / speed limiter settings
6. Display of speed limit signs
7. Status of the Lane positioning assist
8. Rev counter (x 1,000 rpm)
9. Engine coolant temperature indicator (°C)
10. Total distance recorder (miles or km)
11. Service spanner
Digital instrument panel
(Hybrid)
This digital instrument panel can be customised.
Depending on the display mode selected, certain
information is hidden or presented differently.
Example with the "ÉNERGIE"display mode:
1. Fuel gauge and remaining range (miles or km)
2. Status of the gearbox
Active driving mode
3. Speedometer (mph or km/h)
READY indicator lamp
4. Cruise control / speed limiter settings
Display of speed limit signs
5. Total distance recorder (miles or km)
6. Power indicator
7. Power flow
8. Battery charge level and remaining range
(miles or km)
Displays
Some lamps have a fixed location, the others can
alter location.
For certain functions that have indicator lamps
for both operation and for deactivation, there is
only one dedicated location.
Permanent information
In the standard display, the instrument panel
shows:
– in fixed locations:
• Fuel gauge.
• Engine coolant temperature indicator.
• Charge level and driving range indicator
(Hybrid).
• Total distance recorder.
– in variable locations:
• Gearbox and gear shift indicator information.
• Digital speedometer.
• Power indicator (Hybrid).
• Status or alert messages displayed
temporarily.
Optional information
Depending on the display mode selected and the
active features, additional information may be
displayed:
– Rev counter.
– Trip computer.
– Driving aid functions.
– Speed limiter or cruise control.
– Media currently playing.
– Navigation instructions.
– Engine information (G-meters, Power-meters,
Boost, Torque) in Sport mode.
– DS NIGHT VISION function.
– Power flow (Hybrid).
Customising the instrument
panel
You can modify the appearance of the instrument
panel by choosing:
– a display colour.
– a display mode.
Display language and units
These depend on the touch screen
settings.
When travelling abroad, the speed must be
shown in the official units of the country you
are driving in (mph, miles or km/h, km).
As a safety measure, these adjustments
must be carried out with the vehicle
stationary.

11
Instruments
01
Choosing a display colour
The display colour can be selected in the setting
of a profile in the Settings touch screen menu.
It can also be related to the ambience activated
by the DS SENSORIAL DRIVE function.
Depending on version, the possible choices are:
– “Cashmere": purple,
– “Titanium": crimson,
– "Normal" (no ambience activated): white and
champagne.
For more information on the DS SENSORIAL
DRIVEfunction, refer to the corresponding
section.
Setting the display mode
In each mode, specific types of information are
displayed on the instrument panel.
Changing the display mode
► Turn the thumbwheel on the left of the
steering wheel to display and scroll through
the various modes on the right-hand side of the
instrument panel.
► Press the thumbwheel to confirm the mode.
If you do not press the thumbwheel, the selected
display mode is automatically applied after a few
moments.
Display mode overview
– "DIALS": standard display of analogue and
digital speedometers, distance recorder and:
• fuel gauge, coolant temperature indicator and
rev counter (Petrol or Diesel).
• fuel gauge, battery charge indicator and
power indicator (Hybrid).
– NAVIGATION": standard display plus current
navigation information (map and navigation
instructions).
– "DRIVING": standard display, plus information
relating to active driving aid systems.
– "MINIMAL": restricted display with digital
speedometer, distance recorder and:
• fuel gauge and engine coolant temperature
indicator (Petrol or Diesel).
• fuel gauge and battery charge indicator
(Hybrid).
– "NIGHT VISION": minimal display, plus the
infrared camera image (associated with the DS
NIGHT VISION function).
– "ÉNERGIE": standard display plus a visual
representation of the vehicle’s energy flows
(Hybrid).
– "PERSONAL": minimal display, with the ability
to select and display optional information in the
customisable areas on the left and right.
Configuring a "PERSONAL" display mode
With DS CONNECT RADIO
► Press Settings in the upper banner of
the touch screen.
► Select "Configuration".
► Select "Instrument panel
personalisation".
With DS CONNECT NAV
► Press Settings in the side banner of the
touch screen.
► Select "OPTIONS".
► Select "Instrument panel
personalisation".
► For each customised display area (i.e. left
and right), select a type of information using the
corresponding scroll arrows on the touch screen:
• "Driving aids".
• "Default" (empty).
• "Engine info" (Sport mode).
• "G-metres" (Sport mode).
• "Temperatures" (engine oil).
• "Media".
• "Navigation".
• "Trip computer".
• "Rev counter".
• "Energy flow" (depending on version).
• "Power indicator" (depending on version).

12
Instruments
01
• "Energy consumption" (depending on
version).
• "Night vision".
• "Vigilance level".
► Confirm to save and exit.
The "PERSONAL" display mode is enabled
immediately.
Warning and indicator
lamps
Displayed as symbols, the warning and indicator
lamps inform the driver of the occurrence of a
malfunction (warning lamps) or of the operating
status of a system (operation or deactivation
indicator lamps). Certain lamps light up in two
ways (fixed or flashing) and/or in several colours.
Associated warnings
The illumination of a lamp may be accompanied
by an audible signal and/or a message displayed
in a screen.
Relating the type of alert to the operating status
of the vehicle allows you to determine whether
the situation is normal or whether a fault has
occurred: refer to the description of each lamp for
further information.
When the ignition is switched on
Certain red or orange warning lamps come on for
a few seconds when the ignition is switched on.
These warning lamps should go off as soon as the
engine is started.
For more information on a system or a function,
refer to the corresponding section.
Warning lamp continuously lit
The illumination of a red or orange warning lamp
indicates the occurrence of a fault that needs
further investigation.
If a warning lamp remains lit
The references (1), (2) and (3) in the warning and
indicator lamp description indicate whether you
should contact a qualified professional in addition
to the immediate recommended actions.
(1): You must stop the vehicle.
Stop as soon as it is safe to do so and switch off
the ignition.
(2): Contact a dealer or a qualified workshop.
(3): Visit a dealer or a qualified workshop.
List of warning and indicator
lamps
Red warning/indicator lamps
STOP
Fixed, associated with another warning
lamp, accompanied by the display of a
message and an audible signal.
A serious fault with the engine, braking system,
power steering, automatic gearbox or a major
electrical fault has been detected.
Carry out (1) and then (2).
Maximum engine coolant temperature
Fixed, with the needle in the red
zone, accompanied by the STOP
warning lamp.
The cooling system temperature is too high.
Carry out (1), then allow the engine to cool before
topping up the level, if necessary. If the problem
persists, carry out (2).
Fixed, accompanied by the STOP
warning lamp.
The cooling system temperature is too high.
Carry out (1), then allow the engine to cool before
topping up the level, if necessary. If the problem
persists, carry out (2).
Engine oil pressure
Fixed.
There is a fault with the engine lubrication
system.
Carry out (1) and then (2).
System malfunction (Hybrid)
Fixed.
The rechargeable hybrid system is faulty.
Carry out (1) and then (2).
Cable connected (Hybrid)
Fixed.
It is not possible to start the vehicle while
the charging cable is connected to the vehicle’s
connector.
Disconnect the charging cable and close the flap.

13
Instruments
01
12 V battery charge*
Fixed.
The battery charging circuit has a fault
(dirty terminals, slack or cut alternator belt, etc.).
Carry out (1).
If the electric parking brake is no longer working,
immobilise the vehicle:
► With the manual gearbox, engage a gear.
► With the automatic gearbox, fit the chocks
against one of the wheels.
Clean and tighten the terminals. If the warning
lamp does not go off when the engine is started,
carry out (2).
Braking
Fixed.
The brake fluid level in the braking circuit
has dropped significantly.
Carry out (1), then top up with fluid that complies
with the manufacturer's recommendations. If the
problem persists, carry out (2).
Fixed.
The electronic brake force
distribution(EBFD) system is faulty.
Carry out (1) and then (2).
Electric parking brake
Fixed.
The electric parking brake is applied.
Flashing.
Application/release is faulty.
* Depending on country of sale.
Carry out (1): park on flat ground (on a level
surface).
With a manual gearbox, engage a gear.
With an automatic gearbox, select modeP.
Switch off the ignition and carry out (2).
Door(s) open
Fixed, associated with a message
identifying the access.
An audible signal supplements the alert if the
speed is higher than 6 mph (10km/h).
A door or the boot is not properly closed.
Seat belts not fastened/unfastened
Fixed or flashing, accompanied by an
increasing audible signal.
A seat belt has not been fastened or has been
unfastened.
Orange warning/indicator lamps
Service
Temporarily on, accompanied by the
display of a message.
One or more minor faults, for which there is/are
no specific warning lamp(s), have been detected.
Identify the cause of the fault using the message
displayed in the instrument panel.
It is possible to deal with some faults yourself,
such as changing the battery of the remote
control.
For other faults, such as with the tyre under-
inflation detection system, carry out (3).
Fixed, accompanied by the display of a
message.
One or more major faults, for which there is/are
no specific warning lamp(s), have been detected.
Identify the cause of the fault using the message
displayed in the instrument panel, then carry out
(3).
Fixed, accompanied by the message
"Parking brake fault".
Automatic release of the electric parking brake is
unavailable.
Carry out (2).
Service warning lamp fixed and
service spanner flashing then fixed.
The servicing interval has been exceeded.
The vehicle must be serviced as soon as possible.
Only with BlueHDi Diesel engines.
Braking
Fixed.
A minor fault with the braking system has
been detected.
Drive carefully.
Carry out (3).
Malfunction (with electric parking brake)
Fixed, accompanied by the message
"Parking brake fault".
The vehicle cannot be immobilised with the
engine running.

14
Instruments
01
If manual application and release commands are
not working, the electric parking brake control
lever is faulty.
The automatic functions must be used at all times
and are automatically re-enabled in the event of a
control lever fault.
Carry out (2).
Fixed, accompanied by the
message "Parking brake
fault".
The parking brake is faulty: manual and
automatic functions may not be working.
When stationary, to immobilise the vehicle:
► Pull and hold the control lever for
approximately 7 to 15 seconds, until the indicator
lamp comes on on the instrument panel.
If this procedure does not work, secure the
vehicle:
► Park on a level surface.
► With a manual gearbox, engage a gear.
► With an automatic gearbox, selectP, then
place the supplied chocks against one of the
wheels.
Then carry out (2).
Deactivation of the automatic functions (with
electric parking brake)
Fixed.
The "automatic application" (on switching
off the engine) and "automatic release" (on
acceleration) functions are deactivated.
If automatic application/release is no longer
possible:
► Start the engine.
► Use the control lever to apply the parking
brake.
► Take your foot fully off the brake pedal.
► Hold the control lever pressed in the release
direction for between 10 and 15 seconds.
► Release the control lever.
► Depress and hold the brake pedal.
► Hold the control lever in the “Application”
direction for 2seconds.
► Release the control lever and the brake pedal.
Anti-lock braking system (ABS)
Fixed.
The anti-lock braking system has a fault.
The vehicle retains conventional braking.
Drive carefully at moderate speed, then carry out
(3).
Engine self-diagnostic system(Petrol or Diesel)
Flashing.
The engine management system has a
fault.
There is a risk that the catalytic converter will be
destroyed.
You must carry out (2).
Fixed.
The emissions control system has a fault.
The warning lamp should go off when the engine
is started.
Carry out (3) quickly.
Dynamic stability control (DSC)/Anti-slip
regulation (ASR)
Flashing.
DSC/ASR regulation is activated in the
event of a loss of grip or trajectory.
Fixed.
The DSC/ASR system has a fault.
Carry out (3).
Emergency brake malfunction (with electric
parking brake)
Fixed, accompanied by the message
"Parking brake fault".
Emergency braking does not deliver optimal
performance.
If automatic release is not available, use manual
release or carry out (3).
Hill start assist
Fixed, accompanied by the message
"Anti roll-back system fault".
The system has a fault.
Carry out (3).
Under-inflation
Fixed.
The pressure in one or more tyres is too
low.
Check the pressure of the tyres as soon as
possible.
Reinitialise the detection system after adjusting
the pressure.
Under-inflation warning lamp
flashing then fixed and Service

15
Instruments
01
warning lamp fixed.
The tyre pressure monitoring system is faulty.
Under-inflation detection is no longer monitored.
Check the tyre pressures as soon as possible and
carry out (3).
Parking sensors
Fixed, accompanied by the display of a
message and an audible signal.
The system has a fault.
Carry out (3).
Engine pre-heating (Diesel)
Temporarily on
(up to approximately 30 seconds in severe
weather conditions).
When switching on the ignition, if the weather
conditions and the engine temperature make it
necessary.
Wait until the warning lamp goes off before
starting.
When the warning lamp goes off, starting will
occur immediately if you press and hold:
– the clutch pedal with a manual gearbox.
– the brake pedal with an automatic gearbox.
If the engine does not start, make the engine
starting request again, while keeping your foot on
the pedal.
Airbags
Fixed.
One of the airbags or seat belt pyrotechnic
pretensioners is faulty.
Carry out (3).
Front passenger airbag (ON)
Fixed.
The front passenger airbag is activated.
The control is in the "ON" position.
In this case, do NOT install a "rearward facing"
child seat on the front passenger seat - risk of
serious injury!
Front passenger airbag (OFF)
Fixed.
The front passenger airbag is deactivated.
The control is in the "OFF" position.
A "rearward facing" child seat can be installed,
unless there is a fault with the airbags (Airbags
warning lamp on).
Low fuel level
or Fixed (warning lamp or LED) and
needle in the red zone (depending
on version), accompanied by an audible signal
and a message.
The audible signal and the message are repeated
with increasing frequency as the level drops
towards zero.
When it first comes on, there remains
approximately 6 litres of fuel in the tank (reserve).
Refuel without delay to avoid running out of fuel.
Never drive until completely empty, as this could
damage the emissions control and injection
systems.
Pedestrian horn(Hybrid)
Fixed.
Horn fault detected.
Carry out (3).
Collision Risk Alert/ Active Safety Brake
Fixed, accompanied by the display of a
message.
The system has been deactivated via the touch
screen ( Driving/ Vehiclemenu).
Collision Risk Alert/Active Safety Brake
Flashing.
The system activates and brakes the
vehicle momentarily so as to reduce the speed of
collision with the vehicle ahead.
Fixed, accompanied by a message and an
audible signal.
The system has a fault.
Carry out (3).
Lane Departure Warning System
Flashing, accompanied by an audible
signal.
A lane marking has been crossed on the left or
right.
Turn the steering wheel in the opposite direction
to return to the correct trajectory.
Fixed, accompanied by the display of a
message.
The system has a fault.
Stay alert and drive carefully, then carry out (3).
Active Lane Departure Warning System
Fixed.
The system has been automatically
deactivated or placed on standby.

16
Instruments
01
Flashing.
You are about to cross a broken lane
marking without operating the direction
indicators.
The system is activated, then corrects the
trajectory on the side of the lane marking
detected.
Fixed, accompanied by the display
of a message and an audible signal.
The system has a fault.
Carry out (3).
Lane positioning assist
Fixed, accompanied by the Service
warning lamp.
The system has a fault.
Carry out (3).
Stop & Start
Fixed, accompanied by the display of a
message.
The Stop & Start system has been deactivated
manually.
The engine will not switch off at the next traffic
stop.
Press the button to reactivate Stop & Start.
Fixed.
The Stop & Start system has been
deactivated automatically.
The engine will not switch off at the next traffic
stop, if the exterior temperature is:
– below 0°C.
– above +35°C.
Flashing then fixed, accompanied by a
message.
The system has a fault.
Carry out (3).
AdBlue®(BlueHDi)
On for around 30 seconds when starting
the vehicle, accompanied by a message
indicating the driving range.
The driving range is between 1,500 and 500 miles
(2,400 and 800km).
Top up the AdBlue®.
Fixed, on switching on the ignition,
accompanied by an audible signal and a
message indicating the driving range.
The driving range is between 500 and 62 miles
(800 and 100km).
Promptly top up the AdBlue®, or carry out(3).
Flashing, accompanied by an audible
signal and a message indicating the
driving range.
The driving range is less than 62 miles (100km).
You must top up the AdBlue®to avoid engine
starting being prevented, or carry out(3).
Flashing, accompanied by an audible
signal and a message indicating that
starting is prevented.
The AdBlue®tank is empty: the regulatory engine
immobiliser prevents the engine from being
restarted.
To restart the engine, top up the AdBlue®, or carry
out(2).
You must add at least 5 litres ofAdBlue®to its
tank.
SCR emissions control system(BlueHDi)
Fixed when the ignition is
switched on, accompanied
by an audible signal and a message.
A fault with the SCR emissions control system has
been detected.
This alert disappears once the exhaust emissions
return to normal levels.
AdBlue®warning lamp
flashing upon switching on
the ignition, with the Service and Engine
self-diagnostics warning lamps on fixed,
accompanied by an audible signal and a message
indicating the driving range.
Depending on the message displayed, it may be
possible to drive for up to 685miles (1,100km)
before the engine immobiliser is triggered.
Carry out (3) without delay, to avoid starting
being prevented.
AdBlue®warning lamp
flashing upon switching on
the ignition, with the Service and Engine
self-diagnostics warning lamps on fixed,
accompanied by an audible signal and a message
indicating that starting is prevented.
The engine immobiliser prevents the engine from
restarting (over the authorised driving limit after
confirmation of a fault with the emissions control
system).
To start the engine, carry out (2).
Particle filter(Diesel)
Fixed, accompanied by an audible signal
and a message about the risk of particle

17
Instruments
01
filter blockage.
The particle filter is starting to saturate.
As soon as the traffic conditions permit,
regenerate the filter by driving at a speed of at
least 37mph (60km/h) until the warning lamp
goes off.
Fixed, accompanied by an audible signal
and a message signalling that the additive
level in the particle filter is too low.
The minimum level of the additive tank is reached.
Quickly have the tank topped up: carry out (3)
Rear foglamps
Fixed.
The lamps are on.
DS NIGHT VISION
Fixed.
The system has been activated, but
the vehicle is travelling too fast or the exterior
temperature conditions are outside the operating
range.
The display is available with the "Night vision"
mode but the system does not emit an alert.
Green warning/indicator lamps
Stop & Start(Petrol or Diesel)
Fixed.
When the vehicle stops, the Stop & Start
puts the engine into STOP mode.
Flashing temporarily.
STOP mode is momentarily unavailable or
START mode is automatically triggered.
Vehicle ready to drive (Hybrid)
Fixed, accompanied by an audible signal
when it comes on.
The vehicle is ready to drive.
The indicator lamp goes out upon reaching a
speed of approximately 3 mph (5km/h) and lights
up again when the vehicle stops moving.
The lamp will go out when you turn off the engine
and exit the vehicle.
Eco mode
Fixed.
ECO mode is active.
Certain parameters are adjusted with a view to
reducing fuel consumption.
Park Assist or DS PARK PILOT
Fixed.
The function is active.
Active Lane Keeping Assist
Fixed.
The function has been activated.
All the conditions have been met: the system is
operating.
Automatic wiping
Fixed.
Automatic windscreen wiping is activated.
Direction indicators
Direction indicators with audible signal.
The direction indicators are on.
Sidelamps
Fixed.
The lamps are on.
Dipped beam headlamps
Fixed.
The lamps are on.
Front foglamps
Fixed.
The front foglamps are lit.
DS NIGHT VISION
Fixed.
The function has been activated.
All the conditions have been met: the system is
operating.
The infrared camera image is available with the
"Night vision" mode in the instrument panel.
Automatic headlamp dipping
Fixed.
The function has been activated via
the touch screen (Driving/ Vehicle menu).
The lighting control stalk is in the "AUTO" position.
Blue warning/indicator lamps
Main beam headlamps
Fixed.
The lamps are on.
eSave (Hybrid)
Fixed, accompanied by the electric range
saved.
TheeSave function is activated.

18
Instruments
01
Black/white warning lamps
Automatic gearbox (EAT8) or Electric
automatic gearbox (e-EAT8) (Hybrid)
Fixed.
The automatic gearbox is locked.
You must press the Unlock button to unlock it.
Indicators
Service indicator
The servicing information is expressed in terms of
distance (kilometres or miles) and time (months
or days).
The alert is given at whichever of these two terms
is reached first.
The servicing information is displayed in the
instrument panel. Depending on the version of the
vehicle:
– The distance recorder display line indicates
the distance remaining before the next service
is due, or the distance travelled since it was due
preceded by the "-" sign.
– An alert message indicates the distance
remaining, as well as the period before the next
service is due or how long it is overdue.
The value indicated is calculated
according to the distance covered and the
time elapsed since the last service.
The alert may also be triggered close to a due
date.
Service spanner
On temporarily when the ignition is
switched on.
Between 620 and 1,860 miles (1,000 and 3,000
km) remain before the next service is due.
Fixed, when the ignition is switched on.
The next service is due in less than 620
miles (1,000 km).
Have your vehicle serviced very soon.
Service spanner flashing
Flashing then fixed, when the
ignition is switched on.
(With BlueHDi Diesel engines, combined with the
Service warning lamp.)
The servicing interval has been exceeded.
Have your vehicle serviced as soon as possible.
Resetting the service indicator
The service indicator must be reset after each
service.
If you have serviced your vehicle yourself:
► Switch off the ignition.
► Press and hold the button located on the end
of the wiper control stalk.
► Switch on the ignition; a temporary display
window appears and a countdown begins.
► When the display indicates =0, release the
button; the spanner disappears.
If you have to disconnect the battery
following this operation, lock the vehicle
and wait at least 5 minutes for the reset to be
registered.
Retrieving the servicing information
You can view the servicinginformation by
pressing the "Check/ Diagnostic" button
in the Driving/ Vehicle touch screen menu.
Engine oil level indicator
(Depending on version.)
On versions fitted with an electric oil level
indicator, the engine oil level status is displayed
on the instrument panel for a few seconds upon
switching the ignition on, after the servicing
information, in the form of messages.
The level read will only be correct if the
vehicle is on level ground and the engine
has been off for more than 30 minutes.
Oil level incorrect
This is indicated by the display of a message
prompting you to top up, accompanied by the
