DTC SOL8SDR-R Installation instructions

Resource Identifier 100217
Revision: 8.0
SOL8SDR Hardware Guide
Commercial in Confidence
DTC –Solent
Fusion 2
1100 Parkway
Solent Business Park
Whiteley
Hampshire
PO15 7AB
United Kingdom
[phone]

SOL8SDR Hardware Guide
Commercial in Confidence
Revision 8.0
The information contained in this document is the property of Domo Tactical Communications (DTC) Ltd.
Any copying or reproduction in any form whatsoever is prohibited without the written permission of DTC.
© 2016 Copyright Domo Tactical Communications (DTC) Limited. All rights reserved.
Page 0-1
0. Preface
0.1 About this Document
This document contains relevant information required to identify and install the equipment or system.
Since the available functions are licensed and depend on the specific implementation, not all the functions
and or applications contained in this document may be relevant or applicable to the system you will be
working with.
The actual presentation may differ from those in this document due to hardware or software changes.
0.2 Intended Audience
This document is for anyone interested in how the system can be used, but it is of most benefit to:
Operators who are in charge of the daily operation of the equipment
Installers who are responsible for the pre-installation, on-site installation and configuration of the
system in the end-user environment
Maintainers who are responsible for maintaining the equipment or system
0.3 Notice about this Publication
While DTC makes every attempt to maintain the accuracy of the information contained in its product
manuals, the information is subject to change without notice.
Performance specifications included in this manual are included for guidance. All particulars are given by
DTC in good faith, actual performance may vary.
0.4 Typographic Conventions
This document uses these typographic conventions to identify text that has a special meaning:
Typographic Convention
Example
TEXT in small capitals represents a specific key press on the console
keyboard or hardware panel.
ESC, F1, SHIFT
The + sign means “hold down the first key while pressing the
second key”.
Press CTRL+C to abort
<Text> Serves as a placeholder for variable text that you will
replace as appropriate to its context.
Use the filename
<system_name>.sys for…
Text in bold emphasises a new word or term of significance.
We call this a protocol and its
function is…
Text in italics can represent a link to place in the existing document
(often these are hyperlinks) or a reference to another document.
Refer to section 0.4 Typographic
Conventions.
Successive menu selections are shown using arrows to indicate a
sub-menu. In this example this would mean:
Select the Insert menu, then select picture, then select from file.
Insert>picture>from file

SOL8SDR Hardware Guide
Commercial in Confidence
Revision 8.0
The information contained in this document is the property of Domo Tactical Communications (DTC) Ltd.
Any copying or reproduction in any form whatsoever is prohibited without the written permission of DTC.
© 2016 Copyright Domo Tactical Communications (DTC) Limited. All rights reserved.
Page 0-2
0.5 Symbols
This document uses these symbols to highlight important information:
WARNING: A notice to the reader of when a situation might result in personal injury or loss of life, or
destruction of equipment.
CAUTION: A notice to the reader of when a situation may result in loss of data or damage to equipment.
Note: A notice to draw attention to something or to supply additional information.
0.6 Trademarks
All trademarks or registered trademarks that appear in this document are the property of their respective
owners.
© 2016 Domo Tactical Communications (DTC) Limited.
Domo Tactical Communications (DTC) Limited owns the copyright of this document which is supplied in
confidence and must not be used for any purpose other than for which it is supplied and must not be
reproduced without permission in writing from the owners.
0.7 Related Documents
All DTC documents can be downloaded from WatchDox. See section 6.1.
Document
Source
SOL8SDR Transmitter and Encoder Software User Guide
DTC
SOL8SDR Receiver Software User Guide
DTC
NETNode Phase 5 Software User Guide
DTC
SOL8SDR-C OEM Integration Document
DTC
Solo Concept Guide
DTC
IP Concept Guide
DTC

SOL8SDR Hardware Guide
Commercial in Confidence
Revision 8.0
The information contained in this document is the property of Domo Tactical Communications (DTC) Ltd.
Any copying or reproduction in any form whatsoever is prohibited without the written permission of DTC.
© 2016 Copyright Domo Tactical Communications (DTC) Limited. All rights reserved.
Page 0-3
0.8 Document History
This is a controlled document, written and produced by the DTC Technical Publications team. Changes are
recorded in the table below.
Revision
Date
Authors
Summary of Changes
1.0
02/08/2016
IR
Initial Release
2.0
06/01/2017
IR
Cable updates (CN02054)
3.0
13/01/2017
IR
SOL8SDR2x2W-P heatsink accessory
4.0
24/03/2017
IR
SOL8SDR-C with 2W Amplifier
5.0
10/05/2017
IR
Corrected 2W AMP part numbers
6.0
06/07/2017
IR
Updated SOL8SDR2X2W-P metalwork, USB peripheral adaptor
and DTC screenshots for Device Controller.
6.1
19/01/2018
IR
Updated AMP photo.
6.2
25/04/2018
IR
Added supported dongle list, SOL8SDR Receiver and passwords
section. USB stick contents updated.
7.0
14/12/2018
IR
Moved amplifier calibration to integration document.
8.0
15/01/2019
IR
USB serial adaptor. FCC compliance.

SOL8SDR Hardware Guide
Commercial in Confidence
Revision 8.0
The information contained in this document is the property of Domo Tactical Communications (DTC) Ltd.
Any copying or reproduction in any form whatsoever is prohibited without the written permission of DTC.
© 2016 Copyright Domo Tactical Communications (DTC) Limited. All rights reserved.
Page 0-4
Contents
0. Preface......................................................................................................0-1
0.1 About this Document .................................................................................................................... 0-1
0.2 Intended Audience ........................................................................................................................ 0-1
0.3 Notice about this Publication........................................................................................................ 0-1
0.4 Typographic Conventions.............................................................................................................. 0-1
0.5 Symbols ........................................................................................................................................ 0-2
0.6 Trademarks................................................................................................................................... 0-2
0.7 Related Documents....................................................................................................................... 0-2
0.8 Document History.......................................................................................................................... 0-3
1. Product Overview ......................................................................................1-1
1.1 Product Family .............................................................................................................................. 1-1
1.2 SOLO8 Software Defined Radio (Concealment)............................................................................. 1-1
1.3 SOLO8 Software Defined Radio (Robust) ...................................................................................... 1-2
1.4 SOLO8 Software Defined Radio (Plain) ......................................................................................... 1-3
1.5 Approval Notices ........................................................................................................................... 1-4
1.6 FCC EMC Compliance ................................................................................................................... 1-4
2. Product Package .......................................................................................2-5
2.1 Overview ....................................................................................................................................... 2-5
2.2 SOL8SDR-C Parts List................................................................................................................... 2-5
2.3 SOL8SDR-R Part List..................................................................................................................... 2-5
2.4 SOL8SDR2X2W-P Parts List .......................................................................................................... 2-6
2.5 Accessory Options......................................................................................................................... 2-7
2.6 Variants ........................................................................................................................................ 2-7
2.7 Labelling....................................................................................................................................... 2-9
2.8 Licensing Options ....................................................................................................................... 2-10
3. Connections, Controls and Indicators......................................................3-12
3.1 Introduction ................................................................................................................................ 3-12
3.2 Antenna Polarization................................................................................................................... 3-12
3.3 SOL8SDR Concealment ............................................................................................................... 3-12
3.4 SOL8SDR Robust......................................................................................................................... 3-14
3.5 SOL8SDR Plain............................................................................................................................ 3-15
3.6 SOL8SDR-C (D1804) Pinouts ...................................................................................................... 3-17
3.7 SOL8SDR-R Pinouts .................................................................................................................... 3-20
3.8 SOL8SDR2X2W-P Pinouts............................................................................................................ 3-21
3.1 Supported USB Dongles .............................................................................................................. 3-22
3.2 SOL8SDI Option as a Video Source.............................................................................................. 3-23
4. Getting Started .......................................................................................4-24
4.1 Introduction ................................................................................................................................ 4-24
4.2 Initial Connections...................................................................................................................... 4-24
4.3 Access the USB Stick .................................................................................................................. 4-24
4.4 Using Node Finder....................................................................................................................... 4-24
4.5 Installing the Domo Device Controller......................................................................................... 4-26
4.6 Using a Web Browser Application ............................................................................................... 4-27
4.7 Configure the SOL8SDR Application ........................................................................................... 4-28
4.8 Passwords................................................................................................................................... 4-28
4.9 Using Domo Device Controller via IP........................................................................................... 4-29
4.10 Using Domo Device Controller via USB.................................................................................... 4-31
4.11 Further Reading ...................................................................................................................... 4-34

SOL8SDR Hardware Guide
Commercial in Confidence
Revision 8.0
The information contained in this document is the property of Domo Tactical Communications (DTC) Ltd.
Any copying or reproduction in any form whatsoever is prohibited without the written permission of DTC.
© 2016 Copyright Domo Tactical Communications (DTC) Limited. All rights reserved.
Page 0-5
5. Appendix A –Reference Material.............................................................5-35
5.1 How to Configure a PC IP Address .............................................................................................. 5-35
5.2 SOL8SDR2x2W-P-HSK –Heatsink Accessory............................................................................... 5-36
6. Appendix B –After Sales Support............................................................6-37
6.1 Documentation and Software...................................................................................................... 6-37
6.2 Contact Technical Support.......................................................................................................... 6-37
6.3 Using the DTC RMA Service......................................................................................................... 6-37
7. Appendix C –Safety and Maintenance ....................................................7-39
7.1 Cautions and Warnings .............................................................................................................. 7-39
7.2 Repairs and Alterations .............................................................................................................. 7-40
7.3 Caring for your Equipment.......................................................................................................... 7-40
7.4 Charging..................................................................................................................................... 7-40
7.5 Working with Lithium Batteries................................................................................................... 7-40
7.6 Cleaning ..................................................................................................................................... 7-41
7.7 Storage ....................................................................................................................................... 7-41
8. Appendix D –Glossary.............................................................................8-42

SOL8SDR Hardware Guide
Commercial in Confidence
Revision 8.0
The information contained in this document is the property of Domo Tactical Communications (DTC) Ltd.
Any copying or reproduction in any form whatsoever is prohibited without the written permission of DTC.
© 2016 Copyright Domo Tactical Communications (DTC) Limited. All rights reserved.
Page 1-1
1. Product Overview
1.1 Product Family
The products that will be covered in this guide are:
Equipment Title
Part Number
SOLO8 Software Defined Radio (Concealment)
SOL8SDR-C
SOLO8 Software Defined Radio (Robust)
SOL8SDR-R
SOLO8 Software Defined Radio (Plain)
SOL8SDR2X2W-P
1.2 SOLO8 Software Defined Radio (Concealment)
1.2.1 Description
The SOLO8 Software Defined Radio is an ultra-miniature COFDM digital video transceiver from Domo
Tactical Communications (DTC), designed specifically for Point of View (PoV), body worn and concealment
applications. Dependent on the applications loaded, the platform can operate as a Transmitter, Receiver,
Dual Encoder, Standard IP Mesh and MIMO IP Mesh. Further information on software capability can found in
the SDRAPP datasheets.
The SOLO8 SDR Concealment is an ultra-miniature package ideal for integration into the smallest
concealment solutions.
The UHF version is larger than the standard SOL8SDR-C due to the lower frequency of operation (320-
470MHz). Please see the SOL8SDR UHF Operation Guidelines publication for important application notes.
One/two 2W PAs or a 2x1W PA can be connected via D1806 for extended range.
1.2.2 Features
Dual high profile HD H.264 independent video encoders
2x100mW COFDM transceivers for use as COFDM Transmitter, Receiver or IP Mesh
ISM band telemetry transceiver for control, PTZ and low power standby
Dual SD/HD-SDI video inputs for recording, transmission and analysis
Microphone inputs and headphone output for recording, transmission or talkback
Growing USB support for peripherals such as 3G/4G/Wi-Fi dongles
Ethernet, RS232 and RS485 connectivity, and 128GB built in storage
Compact packaging with ultra-miniature connectors

SOL8SDR Hardware Guide
Commercial in Confidence
Revision 8.0
The information contained in this document is the property of Domo Tactical Communications (DTC) Ltd.
Any copying or reproduction in any form whatsoever is prohibited without the written permission of DTC.
© 2016 Copyright Domo Tactical Communications (DTC) Limited. All rights reserved.
Page 1-2
Very low power consumption: typically 7.5W
Exceptionally small size: 50mm x 50mm x 18mm (24mm UHF)
Weighs only 70-82g
1.2.3 Basic Specifications
Dimensions (mm)
50 (L) x 50 (W) x 18 (D)
Weight
80g
Operating Temperature
-20°C to +60°C with additional cooling
Power Consumption
Typically 7.5W (SD), 8.5W (HD), 9.5W (Dual)
DC Input
8 to 18VDC reverse polarity protected
DC Output
1A pass through switchable
1.3 SOLO8 Software Defined Radio (Robust)
1.3.1 Description
The SOLO8 Software Defined Radio is an ultra-miniature COFDM digital video transceiver from Domo
Tactical Communications (DTC), designed specifically for Point of View (PoV), body worn and concealment
applications. Dependent on the applications loaded the platform can operate as a Transmitter, Receiver,
Dual Encoder, Standard IP Mesh and MIMO IP Mesh. Further information on software capability can found in
the SDRAPP datasheets.
SOLO8 SDR Robust provides a passively cooled IP66 rated enclosure ideal for outdoor, or body worn
applications.
The UHF version is larger than the standard SOL8SDR-R due to the lower frequency of operation (320-
470MHz). Please see the SOL8SDR UHF Operation Guidelines publication for important application notes.
1.3.2 Features
Dual high profile HD H.264 independent video encoders
2x100mW COFDM transceivers for use as COFDM Transmitter, Receiver or IP Mesh
ISM band telemetry transceiver for control, PTZ and low power standby
Dual SD/HD-SDI video inputs for recording, transmission and analysis
Microphone inputs and headphone output for recording, transmission or talkback
Growing USB support for peripherals such as 3G/4G/Wi-Fi dongles

SOL8SDR Hardware Guide
Commercial in Confidence
Revision 8.0
The information contained in this document is the property of Domo Tactical Communications (DTC) Ltd.
Any copying or reproduction in any form whatsoever is prohibited without the written permission of DTC.
© 2016 Copyright Domo Tactical Communications (DTC) Limited. All rights reserved.
Page 1-3
Ethernet, RS232 and RS485 connectivity, and 128GB built in storage
Robust packaging with IP66 rated connectors
Very low power consumption: typically 7.5W
Exceptionally small size: 130mm x 100mm x 25mm (30.5mm
UHF)
Weighs only 314-372g
1.3.3 Basic Specifications
Dimensions (mm)
130 (L) x 100 (W) x 25 (D)
Weight
314g
Operating Temperature
-20°C to +60°C
Power Consumption
Typically 7.5W (SD), 8.5W (HD), 9.5W (Dual)
DC Input
8 to 18VDC reverse polarity protected
DC Output
1A pass through switchable
1.4 SOLO8 Software Defined Radio (Plain)
1.4.1 Description
The SOLO8 Software Defined Radio is an ultra-miniature COFDM digital video transceiver from Domo
Tactical Communications (DTC), designed specifically for Point of View (PoV), body worn and concealment
applications. Dependent on the applications loaded the platform can operate as a Transmitter, Receiver,
Dual Encoder, Standard IP Mesh and MIMO IP Mesh. Further information on software capability can found in
the SDRAPP datasheets.
SOLO8 SDR Plain provides a compact higher power solution (2x2W) for increased range and enhanced
connectivity with native RJ45 and USB as standard.
1.4.2 Features
Dual high profile HD H.264 independent video encoders
2x2W COFDM transceivers for use as COFDM Transmitter, Receiver or IP Mesh
ISM band telemetry transceiver for control, PTZ and low power standby
Dual SD/HD-SDI video inputs for recording, transmission and analysis
Microphone inputs and headphone output for recording, transmission or talkback

SOL8SDR Hardware Guide
Commercial in Confidence
Revision 8.0
The information contained in this document is the property of Domo Tactical Communications (DTC) Ltd.
Any copying or reproduction in any form whatsoever is prohibited without the written permission of DTC.
© 2016 Copyright Domo Tactical Communications (DTC) Limited. All rights reserved.
Page 1-4
Growing USB support for peripherals such as 3G/4G/Wi-Fi dongles
Ethernet, RS232 and RS485 connectivity and 128GB built in storage
Higher power packaging without the need for breakout cables
Very low power consumption: typically 12.5W
Exceptionally small size: 200mm x 100mm x 27mm
Weighs only 950g
1.4.3 Basic Specifications
Dimensions (mm)
235mm (L) x 100mm (W) x 26mm (H).
Weight
950g
Operating Temperature
-10°C to +50°C.
Power Consumption
Typically 12.5W (SD), 13.5W (HD), 14.5W (Dual).
DC Input
8 to 18VDC reverse polarity protected.
DC Output
1A pass through switchable. 5V regulated output limited to 1A (switchable)
1.5 Approval Notices
1.5.1 EMC/Safety and Radio Approvals
The equipment has been designed to meet and has been tested against harmonized EMC and safety
standards.
1.5.2 CE Marking
The CE mark is affixed to all DTC products, the CE Declaration of Conformity as well as the technical file is
available on request.
1.6 FCC EMC Compliance
Where SOL8SDR-C and SOL8SDR-P devices carry an FCC compliance identifier on the label (see section
2.7), the following statement applies:
This device complies with part 15 of the FCC Rules. Operation is subject to the condition that this
device does not cause harmful interference.
The use of frequencies not listed in the grant filing are prohibited.
Changes or modifications not expressly approved by Domo Tactical Communications (DTC) could void
the user’s authority to operate the equipment.

SOL8SDR Hardware Guide
Commercial in Confidence
Revision 8.0
The information contained in this document is the property of Domo Tactical Communications (DTC) Ltd.
Any copying or reproduction in any form whatsoever is prohibited without the written permission of DTC.
© 2016 Copyright Domo Tactical Communications (DTC) Limited. All rights reserved.
Page 2-5
2. Product Package
2.1 Overview
Carefully open the packaging and remove the device and all other items. Verify that all the components
have been included in the package as shown in the packing list. Inspect the unit for shipping damage.
Note: If you do not have all the parts or you are not happy with the condition of your delivered product,
please call DTC and we will get this solved for you. See section 6.2.
Retain the packing list and all the packing materials for storage.
The codes in the packing list mean:
CA –cable assembly
SA –sub assembly
AP –assembly part
The part numbers are useful for identification and if you need to order a new part.
2.2 SOL8SDR-C Parts List
These items will be in the package.
Item
Notes
SOL8SDR-C
SOLO8 Software Defined Radio, Concealment (OEM)
CA2856
Ethernet JST cable
CA3043
JST-banana plug power cable
D1804
Gecko breakout PCB (for pinout see section 3.6)
D918
Ethernet Magnetics PCB
SA3774
SOL8SDR-C USB stick containing:
Device Controller, Node Finder, Video Download Tool, SDR USB driver, SOL8SDR
Hardware Guide, Software User Guides, Quick Start Guide and SOL8SDR-C
Integration Documentation
2.3 SOL8SDR-R Part List
These items will be in the package.
Item
Notes
SOL8SDR-R
SOLO8 Software Defined Radio, Robust
AP007377
USB A to micro USB B cable
CA0002
12V DC power cable 3m
CA2396 x 2
DIN 1.0/2.3 to BNC female cable
CA2519
Fischer power cable 3m

SOL8SDR Hardware Guide
Commercial in Confidence
Revision 8.0
The information contained in this document is the property of Domo Tactical Communications (DTC) Ltd.
Any copying or reproduction in any form whatsoever is prohibited without the written permission of DTC.
© 2016 Copyright Domo Tactical Communications (DTC) Limited. All rights reserved.
Page 2-6
Item
Notes
CA2521
Fischer Ethernet breakout cable
CA2522
Fischer USB breakout cable
CA3123
Fischer audio MIC/HEAD cable
SA3741
SOL8SDR-R USB stick containing:
Device Controller, Node Finder, Video Download Tool, SDR USB driver, SOL8SDR
Hardware Guide, Software User Guides and Quick Start Guide
2.4 SOL8SDR2X2W-P Parts List
These items will be in the package.
Item
Notes
SOL8SDR2x2W-P
SOLO8 Software Defined Radio, Plain
CA0002
12VDC power cable 3m
CA2396 x 2
BNC to DIN 1.0/2.3 RG179 cable
CA3172
12V power block
SA4233
SOL8SDR-P USB stick containing:
Device Controller, Node Finder, Video Download Tool, SDR USB driver, SOL8SDR
Hardware Guide, Software User Guides and Quick Start Guide

SOL8SDR Hardware Guide
Commercial in Confidence
Revision 8.0
The information contained in this document is the property of Domo Tactical Communications (DTC) Ltd.
Any copying or reproduction in any form whatsoever is prohibited without the written permission of DTC.
© 2016 Copyright Domo Tactical Communications (DTC) Limited. All rights reserved.
Page 2-7
2.5 Accessory Options
If you have purchased these items, they will also be in the package.
Note: If you have ordered the AMP2W or AMP2x1W, they will need to be calibrated with SOL8SDR-C using the
process detailed in SOL8SDR-C OEM Integration Document. A D1806 is an essential accessory.
Part Number
Equipment Title
SOL8SDR-CK
SOL8SDR Concealment Kit, including CAMuPHDK (HD-SDI pin-hole camera
and 3 lenses), microphone, ANT, battery, heatsink, Pelicase. Excludes
SOL8SDR-C.
SOL8SDR-RSK
SOL8SDR Robust Surveillance Kit, including CAMuPHDK (HD-SDI pin-hole
camera and 3 lenses), microphone, ANT, battery, heatsink, Pelicase.
Excludes SOL8SDR-R.
SOL8SDR-C-HSK
Passive heatsink assembly for SOL8SDR-C
SOL8SDR2x2W-P-HSK
Passive heatsink accessory for SOL8SDR2X2W-P only
SOL8KF-043
Three button key fob (433.05-434.79MHz)
SOL8KF-091
Three button key fob (902-928MHz)
SOL8SDI
HDMI/Composite to SDI converter
CAMuPHDK
Pin-hole HD camera kit
CA2830
DIN 1.0/2.3 to MMCX cable for CAMuPHDK
SOL8TELTRX
SOLO8 Telemetry Transmitter/Receiver
AMP2W-xxxxxx-B-OEM
2W PA OEM assembly with bypass, xxxxxx denotes frequency band
(SOL8SDR-C only)
AMP2x1W-xxxxxx-B-OEM
Dual 1W OEM AMP with bypass, xxxxxx denotes frequency band (SOL8SDR-
C only)
D1806
Gecko active breakout PCB required for PA accessories (SOL8SDR-C only)
SOL8SDR-C-CAKIT-A/B/C
Cable accessory kits A, B and C for SOL8SDR-C. Refer to CAKIT guide.
CA2520
AV/PTZ/data breakout cable (SOL8SDR-R only)
CA3164
Fischer DC/USB/RS485 Wire Breakout (SOL8SDR-R only)
CA3238
GlobalSat BU-353-S4 GPS with UltiMate (SOL8SDR-R only)
AP009131
GlobalSat BU-353-S4 GPS with Type-A USB
2.6 Variants
This part number will identify the product; it is also on the label.
2.6.1 SOL8SDR-C
Part Number
Description
SOL8SDR-C-039091
Software Defined Radio, Concealment, 320-470MHz, 902-928MHz Tel

SOL8SDR Hardware Guide
Commercial in Confidence
Revision 8.0
The information contained in this document is the property of Domo Tactical Communications (DTC) Ltd.
Any copying or reproduction in any form whatsoever is prohibited without the written permission of DTC.
© 2016 Copyright Domo Tactical Communications (DTC) Limited. All rights reserved.
Page 2-8
Part Number
Description
SOL8SDR-C-132043
Software Defined Radio, Concealment, 1.14-1.50GHz, 433.05-434.79MHz Tel
SOL8SDR-C-201043
Software Defined Radio, Concealment, 1.67-2.35GHz, 433.05-434.79MHz Tel
SOL8SDR-C-201091
Software Defined Radio, Concealment, 1.67-2.35GHz, 902-928MHz Tel
SOL8SDR-C-234043
Software Defined Radio, Concealment, 1.98-2.7GHz, 433.05-434.79MHz Tel
SOL8SDR-C-234091
Software Defined Radio, Concealment, 1.98-2.7GHz, 902-928MHz Tel
SOL8SDR-C-470043
Software Defined Radio, Concealment, 4.40-5.00GHz, 433.05-434.79MHz Tel
SOL8SDR-C-470091
Software Defined Radio, Concealment, 4.40-5.00GHz, 902-928MHz Tel
SOL8SDR-C-575091
Software Defined Radio, Concealment, 5.50-6.00GHz, 902-928MHz Tel
2.6.2 SOL8SDR-R
Part Number
Description
SOL8SDR-R-039091
Software Defined Radio, Robust, 320-470MHz, 902-928MHz Tel
SOL8SDR-R-132043
Software Defined Radio, Robust, 1.14-1.50GHz, 433.05-434.79MHz Tel
SOL8SDR-R-201043
Software Defined Radio, Robust, 1.67-2.35GHz, 433.05-434.79MHz Tel
SOL8SDR-R-201091
Software Defined Radio, Robust, 1.67-2.35GHz, 902-928MHz Tel
SOL8SDR-R-234043
Software Defined Radio, Robust, 1.98-2.7GHz, 433.05-434.79MHz Tel
SOL8SDR-R-234091
Software Defined Radio, Robust, 1.98-2.7GHz, 902-928MHz Tel
SOL8SDR-R-470043
Software Defined Radio, Robust, 4.40-5.00GHz, 433.05-434.79MHz Tel
SOL8SDR-R-470091
Software Defined Radio, Robust, 4.40-5.00GHz, 902-928MHz Tel
SOL8SDR-R-575091
Software Defined Radio, Robust, 5.50-6.00GHz, 902-928MHz Tel
2.6.3 SOL8SDR2x2W-P
Part Number
Description
SOL8SDR2x2W-P-132043
Software Defined Radio, Plain, 2x2W, 1.14-1.50GHz, 433.05-434.79MHz Tel
SOL8SDR2x2W-P-201043
Software Defined Radio, Plain, 2x2W, 1.67-2.35GHz, 433.05-434.79MHz Tel
SOL8SDR2x2W-P-201091
Software Defined Radio, Plain, 2x2W, 1.67-2.35GHz, 902-928MHz Tel
SOL8SDR2x2W-P-234043
Software Defined Radio, Plain, 2x2W, 1.98-2.70GHz, 433.05-434.79MHz Tel
SOL8SDR2x2W-P-234091
Software Defined Radio, Plain, 2x2W, 1.98-2.70GHz, 902-928MHz Tel
SOL8SDR2x2W-P -470091
Software Defined Radio, Plain, 2x2W, 4.40-5.00GHz, 902-928MHz Tel

SOL8SDR Hardware Guide
Commercial in Confidence
Revision 8.0
The information contained in this document is the property of Domo Tactical Communications (DTC) Ltd.
Any copying or reproduction in any form whatsoever is prohibited without the written permission of DTC.
© 2016 Copyright Domo Tactical Communications (DTC) Limited. All rights reserved.
Page 2-9
2.7 Labelling
2.7.1 Generic
All SOL8SDRs will be identified by generic label information.
No
Item
1
Part number –this is the variant explained above.
2
This symbol indicates that the unit should be disposed of in accordance with the WEEE Directive.
3
The CE mark certifies that a product has met EU consumer safety, health and environmental
requirements.
4
A barcoded, six-digit serial number. This may be required during a support call.
5
Power requirements.
2.7.2 SOL8SDR FCC Labelling
An FCC ID is a unique identifier assigned to a device registered with the United States Federal
Communications Commission, see section 1.6.
Where SOL8SDR is certified, the FCC identifier will be indicated on the label.
SOL8SDR-C FCC Label
SOL8SDR-P FCC Label

SOL8SDR Hardware Guide
Commercial in Confidence
Revision 8.0
The information contained in this document is the property of Domo Tactical Communications (DTC) Ltd.
Any copying or reproduction in any form whatsoever is prohibited without the written permission of DTC.
© 2016 Copyright Domo Tactical Communications (DTC) Limited. All rights reserved.
Page 2-10
2.8 Licensing Options
Some product functions are enabled by licenses.
SDR applications are used in combination with SOL8SDR products to add functionality. Combinations of
SDRAPP licenses may need to be purchased to meet the requirements.
2.8.1 SDRAPP-ENC
If the SOL8SDR is to be used as a Video Encoder, choose from the SDRAPP-ENC licenses.
Part Number
SDRAPP-ENC
Silver
Streaming and Recording
Gold
Silver plus MPEG-4 H.264 (SD)
Platinum
Gold plus MPEG-4 H.264 (HD)
2.8.2 SDRAPP-TX
If the SOL8SDR is to be used as a COFDM Transmitter, choose from the SDRAPP-TX licenses.
Part Number
SDRAPP-TX
Silver
DVB-T Modulation, Ultra Mobile Video Link (UMVL) and Telemetry.
Gold
Silver plus 1.25MHz and 2.5MHz Narrowband Modulation.
Platinum
Gold plus 625MHz Narrowband Modulation.
2.8.3 SDRAPP-RX
If the SOL8SDR is to be used as a Receiver, choose from the SDRAPP-RX licenses.
Part Number
SDRAPP-TX
Silver
DVB-T Modulation and Telemetry.
Gold
Silver plus 1.25MHz and 2.5MHz Narrowband Modulation.
Platinum
Gold plus 625MHz Narrowband Modulation.
2.8.4 SDRAPP-MESH
If the SOL8SDR is to be used as a Mesh IP Radio, the SDRAPP-MESH license will need to be applied.
Part Number
SDRAPP-MESH
Silver
Standard Mesh, MIMO Mesh and DES Mesh Encryption.
2.8.5 SDRAPP-IAS
If the SOL8SDR Mesh is to use the Interference Avoidance Scheme, the SDRAPP-IAS license will need to be
applied.
Part Number
SDRAPP-MESH
Silver
Interference Avoidance Scheme.

SOL8SDR Hardware Guide
Commercial in Confidence
Revision 8.0
The information contained in this document is the property of Domo Tactical Communications (DTC) Ltd.
Any copying or reproduction in any form whatsoever is prohibited without the written permission of DTC.
© 2016 Copyright Domo Tactical Communications (DTC) Limited. All rights reserved.
Page 2-11
2.8.6 Encryption
Encryption licenses are used for secure communications.
Part Number
SDRAPP-TX
AES128TX
AES 128-Bit Encryption License
AES256TX
AES 256-Bit Encryption License

SOL8SDR Hardware Guide
Commercial in Confidence
Revision 8.0
The information contained in this document is the property of Domo Tactical Communications (DTC) Ltd.
Any copying or reproduction in any form whatsoever is prohibited without the written permission of DTC.
© 2016 Copyright Domo Tactical Communications (DTC) Limited. All rights reserved.
Page 3-12
3. Connections, Controls and Indicators
3.1 Introduction
This chapter will help you identify all the connections and interfaces to help you install and control your
SOL8SDR device.
Each SOL8SDR has front and rear panels which contain all the interfaces for the unit. The SOL8SDR2X2W-P
also has a left panel with some connections.
3.2 Antenna Polarization
3.2.1 COFDM Transmitter/Receiver
COFDM links are very robust and are tolerant to changes in antenna location, but, it is important to try and
keep the antennas in the same plane if possible.
The antennas used with the COFDM links are usually linearly polarized.
3.2.2 MIMO Mesh
MIMO Mesh antennas are ideally polarised orthogonally, at right angles to each other.
3.3 SOL8SDR Concealment
CAUTION: The SOL8SDR-C product is an OEM module which will need careful consideration for heatsinking
or fan cooling as part of the installation. Please read SOL8SDR-C OEM Integration Document available on
DTC’s WatchDox facility.
3.3.1 Front Panel
No
Item
Purpose
1
SMP 50 jack (pin)
RF-A COFDM antenna connects here.
2
SMP 50 jack (pin)
RF-B COFDM antenna connects here. This is the default transmit
output.

SOL8SDR Hardware Guide
Commercial in Confidence
Revision 8.0
The information contained in this document is the property of Domo Tactical Communications (DTC) Ltd.
Any copying or reproduction in any form whatsoever is prohibited without the written permission of DTC.
© 2016 Copyright Domo Tactical Communications (DTC) Limited. All rights reserved.
Page 3-13
No
Item
Purpose
3
Harwin Gecko 34-way
header
This header accepts D1804 Gecko breakout PCB supplied with the unit
which breaks out to:
Power in, power out, Ethernet, PTZ control, RS232 debug, PA control,
headphone out, and left and right microphone inputs.
For pinout of the Gecko breakout PCB see section 3.6.
Note: If you have a power amplifier, you will need the D1806 PCB. For
integration, read the SOL8SDR-C OEM Integration Document.
4
MCX jack (socket)
SDI-1 video connects here.
5
MCX jack (socket)
SDI-2 video connects here.
6
USB 3.0 Micro-B jack
Use DTC cable AP007377 to connect to your PC.
A USB to serial adaptor can be used for serial data transfer.
If you want to attach USB peripheral devices, you will need a suitable
micro B to type A female adaptor.
3.3.2 Rear Panel
No
Item
Purpose
1
Threaded mounting
British Standard Whitworth (BSW) 1/4” x 20 for mounting.
2
SMP 50 jack (pin)
Telemetry antenna connects here.

SOL8SDR Hardware Guide
Commercial in Confidence
Revision 8.0
The information contained in this document is the property of Domo Tactical Communications (DTC) Ltd.
Any copying or reproduction in any form whatsoever is prohibited without the written permission of DTC.
© 2016 Copyright Domo Tactical Communications (DTC) Limited. All rights reserved.
Page 3-14
3.4 SOL8SDR Robust
3.4.1 Front Panel
No
Item
Purpose
1
SMA 50 jack (socket)
COFDM B antenna connects here. This is the default transmit
output.
2
SMA 50 jack (socket)
COFDM A antenna connects here.
3
SMA 50 jack (socket)
Telemetry antenna connects here.
4
DIN 1.0/2.3 jack (socket)
SDI-1 video connects here.
Note: SOL8SDI option will allow for a Composite or HDMI video
connection.
5
DIN 1.0/2.3 jack (socket)
SDI-2 video connects here.
Note: SOL8SDI option will allow for a Composite or HDMI video
connection.
3.4.2 Rear Panel
Note: For pinout of the four Fischer connectors, USB/485, ETH, Aud/232 and PWR, refer to section 3.7.
No
Item
Purpose
1
Fischer Ultimate 5-way jack
(pins) marked PWR
CA2519 (replaced by CA3173) connects here to provide 12V
Power In.
