Duemmegi Domino DFMETEO User manual

Domino
DFMETEO
DFMETEO: meteorological data detection
module for Domino bus
DFMETEO module allows the detection of several meteo-
rological data. The module interfaces, on one side, to the
Domino bus and, on the other side, to a special sensor
trough a dedicated communication line.
DFMETEO module reports the value of three parameters:
✗temperature
✗da light
✗wind speed
DFMETEO module provides 9 digital points to inform about
the following conditions:
✗Rain
✗Twilight
✗Temperature ≥ Threshold
✗Da light ≥ Threshold
✗Wind speed ≥ Threshold
✗Light from South
✗Light from West
✗Light from East
✗Sensor failure
The module features a 2-wa fixed terminal block for the
connection to Domino bus and a 3-wa fixed terminal block
for the connection, through lines A and B, to the meteoro-
logical sensor.
Near to the bus terminal block, a small push-button allows
the address assignment and a green LED shows when the
module is read to receive the address itself; the same
LED normall flashes ever 2 seconds about to signal that
the module is properl operating. A red LED near to the 3-
wa terminal block signals the communication presence on
the lines A and B. Under the cover of the bus terminal
block, a small 3-wa connector (PRG) allows the connec-
tion to the optional tester/programmer.
DFMETEO module is housed in a DIN 2M modular box for
rail mounting.
Address programming
DFMETEO module takes, inside the Domino bus, 4 con-
secutive input addresses and, if enabled b the configura-
tion panel of BDTools, 3 consecutive output addresses.
However, onl a unique base address has to be assigned
to the module to make it operating; assigning an address n,
it will take the input address from n to n+3 and the output
address from n to n+2 (if enabled). For the details about
the address programming refer to the related documenta-
tion. A white label on the front panel allows to write the
base address for an immediate visual identification.
Wiring diagram
The schematic diagram in the figure 1 shows the connec-
tions to be made between DFMETEO module and Domino
bus and the meteorological station (terminals A and B). The
meteorological station must be supplied b 24Vdc voltage.
The meteorological station has a 5-wa removable terminal
block with a premounted diode for reverse polarit protec-
tion; however, pa attention to the connection of the meteo
station because, in the opposite case, it could be irre-
versibl damaged. The connections must be executed be-
fore to appl the power suppl .
For the connection of the meteorological station use a ca-
ble with 2 twisted pairs, with proper section (for instance
2x2x0,8mmq); use a pair for the power suppl and the oth-
er pair for the communication line (A e B). If the chosen ca-
ble provides the shield, connect it to the terminal Sh of
DFMETEO module, leaving it unconnected on the side of
meteorological station. The maximum allowed length for
this cable is 100 meters.
Information reported on the bus
Input section:
As said above, DFMETEO takes, inside Domino bus, 4 in-
put addresses; said n the assigned base address, the infor-
mation mapped on the input section are:
Point n n+ n+2 n+3
Tempera-
ture value
in tenth of
°K (Kelvin
degrees
multiplied
b 10)
Da light
value in
tens of
LUX
(LUX di-
vided b
10)
Wind
speed
value
in tenth of
meters per
second
(m/s multi-
plied b
10)
Rain
2Twilight
3Temp.>= Th..
4Da light>= Th.
5Wind>= Th.
6Light fr. South
7Light fr. West
8Light fr. East
9
0
-
2 -
3 -
4 -
5 Sensor failure
6 -
DUEMMEGI s.r.l. - Via Longhena, 4 - 20139 MILANO
Tel. [phone] - Fax [phone] – www.duemmegi.it
Rel.: 2.0 Februar 2019 Page 1 of 6

Domino
DFMETEO
In details, the input addresses n, n+1 and n+2 respectivel
report:
✗measurement of the temperature in °K multiplied
b 10; called X the value reported the address n,
to convert it to °C use the formula (X–2730)/10.
The temperature in BDTools will be instead direct-
l displa ed in °C
✗measurement of the da light value in tenth of lux;
called Y the value reported b the address n+1, to
convert it to lux value multipl Y b 10. the da -
light in BDTools is directl displa ed in lux (0 to
99000 lux)
✗measurement of the wind speed in m/s multiplied
b 10 (0.0m/s to 70.0m/s). The wind speed in BD-
Tools will be instead directl displa ed in m/s.
The address n+3 reports some digital points that, when ac-
tivated, signals the presence of the following conditions:
✗Rain
✗Twilight
✗Temperature ≥ Threshold
✗Da light ≥ Threshold
✗Wind speed ≥ Threshold
✗Light from South
✗Light from West
✗Light from East
✗Sensor failure
The points related to the light direction will be enabled onl
if the da light is greater than 20000 lux. The digital point re-
lated to the rain status will be disabled, from when this me-
teorological condition is no more true, with a dela of 6 min-
utes about. The digital point related to the twilight status is
activated when the da light is lower than 15 lux and deacti-
vated in the opposite case.
Output section:
The module can feature, as said above, 3 output addresses
for setting the thresholds via bus; these addresses have to
be enabled, if required, b the DFMETEO configuration
panel, as described in the following. Said n the assigned
base address, the information mapped on the output sec-
tion are the following:
Punto n n+ n+2
Set the tempera-
ture threshold in
tenths of Kelvin
degrees
Set the da light
threshold in tens
of lux (LUX divid-
ed b 10)
Set the wind
speed threshold
in tenth of me-
ters per second
(m/s divided b
10)
2
3
4
5
6
7
8
9
0
2
3
4
5
6
DUEMMEGI s.r.l. - Via Longhena, 4 - 20139 MILANO
Tel. [phone] - Fax [phone] – www.duemmegi.it
Rel.: 2.0 Februar 2019 Page 2 of 6
Figure 1: Wiring diagram
+
BUS _
SENSOR
A B Sh
DUEMMEGI
MILANO-ITALY
ADDRESS
DFMETEO
+_
Domino
PATENTED
+24V
0V
+24V dc
GND
A (+)
B (-)
A
B
2
A (+)
B (-)

Domino
DFMETEO
In details, the output addresses n, n+1and n+2 respectivel
report:
✗Temperature threshold in °K multiplied b 10;
called X the desired value in °C, to convert it to °K
multiplied b 10 use the formula (X+273)x10. The
threshold in BDTools will be instead directl set in
°C.
✗Da light threshold in LUX divided b 10; called Y
the desired value, the value to be written at the
output address n+1 is Y divided b 10. The thresh-
old in BDTools will be instead directl set in LUX.
✗Wind speed threshold in m/s multiplied b 10;
called K the desired value, the value to be written
at the output address n+2 is K multiplied b 10.
The threshold in BDTools will be instead directl
set in m/s.
Masking times and thresholds
As will be described in the following, the configuration pan-
el of DFMETEO (inside the BDTools) allows to set the
masking times (or dela times) and the desired threshold
values.
The masking times can be applied to the following mea-
surements:
✗Da light
✗Wind speed
These masking times are used to dela the deactivation of
the bits of input address n+3 related to the just listed mea-
surements. The switching from 0 to 1 is instead instanta-
neous in respect to the overcoming of the related threshold.
The thresholds can be set b the configuration panel or b
the output address as described in the previous paragraph,
and the appl to the following meteorological measure-
ments:
✗Temperature
✗Da light
✗Wind speed
Setting a value for each of these measurements, a thresh-
old will be set on the activation of the related bits of ad-
dress n+3.
Installation of the meteorological station
Position
Choose an installation position in the building where wind,
rain and sun can be easil measured from an direction b
the sensors. The meteorological station must not be in-
stalled underneath an structural parts from which water
can still drip onto the rain sensor after it has stopped rain-
ing or snowing. The meteorological station must be orient-
ed toward the SUD direction and it must not be shaded b
an thing, such as building structures or trees. At least 60
cm of free space underneath the meteorological station are
mandator to allow it to measure the wind correctl and to
avoid malfunctions caused b the snow.
View inside the sensor
1. Connector for the wires of the rain sensor
2. Connector for the wiring of:
✗1: +24Vdc
✗2: GND
✗A: Communication line +
✗B: Communication line -
3. Not used
4. Not used
Mounting
The meteorological station must be mounted onto a vertical
wall or pole.
The meteorological station must be mounted horizontall in
the lateral direction.
Positioning the support for meteorological station
The meteorological station comes with a combination
wall/pole mount. Mount the support verticall on the wall or
on the pole as described in the following.
DUEMMEGI s.r.l. - Via Longhena, 4 - 20139 MILANO
Tel. [phone] - Fax [phone] – www.duemmegi.it
Rel.: 2.0 Februar 2019 Page 3 of 6

Domino
DFMETEO
Wall mounting: flat surface on wall, collar upward lock on
with screws (not provided).
Pole mounting: curved side on pole, collar downward; lock
on with metallic fasteners (not provided).
Preparing the meteorological station
The meteorological station cover with the rain sensor snaps
in on the left and right along the bottom edge. Remove the
meteorological station cover. Proceed carefull , so as not
to pull off the wire connecting the PCB in the bottom part
with the rain sensor in the cover (wire with push-
connector). Push the connection cable through the rubber
seal on the bottom of the meteorological station and con-
nect the power and communication cables to their related
terminals. The connection is b t pical telephone cable (J-
Y(ST)Y 2 × 2 × 0.8).
Mounting the meteorological station
Close the housing b putting the cover back over the bot-
tom part. The cover must snap in on the left and right with a
definite click.
Make sure the cover and bottom part are properl snapped
together. The following figure shows the meteorological
station closed in correct wa (bottom view).
Push the meteorological station from above into the fas-
tened mount. The bumps on the mount must snap into the
rails in the housing.
To remove it, the meteorological station can be simpl
pulled upwards out of the mount, against the resistance of
the fastening.
Notes on installation
Do not open the meteorological station if water (rain) could
get in: even a few drops could damage the electronics in-
side. When mounting, take care not to damage the temper-
ature sensor (small PCB on the bottom of the housing).
Also, the wire connecting the PCB with the rain sensor
must not be pulled off or kinked at the terminal.
Note: it will take 30 seconds after appl ing the power be-
fore the wind measurement will be output.
Maintenance
The meteorological station must be checked for dirt on a
regular, twice- earl basis and cleaned if necessar . A dirt
meteorological station can lead to strange results, such as
the wind sensor failing to work, the station constantl an-
nouncing rain, or failure to detect sunlight.
DUEMMEGI s.r.l. - Via Longhena, 4 - 20139 MILANO
Tel. [phone] - Fax [phone] – www.duemmegi.it
Rel.: 2.0 Februar 2019 Page 4 of 6

Domino
DFMETEO
DFMETEO configuration panel
DFMETEO module must be set through BDTools or DCP
Ide. From main menu, select Configuration, Sensors and
then DFMETEO; the following windows will be shown:
Module Address: it is the address of DFMETEO module to
be configures or to be read.
Output Address: enabling this option, the output address-
es of DFMETEO will be activated (the value of the base
output address will be the same assigned to the input).
Read: this option allows to read the current configuration
of the selected DFMETEO module.
Program: this option allows to write, into the memor of the
module, the desired values for the masking times and the
thresholds.
Id & Ver.: ask for the firmware version of DFMETEO.
Default: this option restores the default values in the con-
figuration panel; these ones are:
✗Address: 1
✗Output address: disabled
✗Masking times:
○Temperature: 0sec
○Da light: 15sec
○Wind speed: 60sec
✗Fixed thresholds in memor :
○Temperature: -273
○Da light: 0
○Wind speed: 0
Close: quit the configuration panel.
Masking times
Temperature: entering a value in this field, a dela in sec-
onds will be introduced before the deactivation of the digital
point related to Temperature >= Threshold.
Daylight: entering a value in this field, a dela in seconds
will be introduced before the deactivation of the digital point
related to Da light >= Threshold.
Wind speed: entering a value in this field, a dela in sec-
onds will be introduced before the deactivation of the digital
point related to Wind Speed >= Threshold.
Note: the temperature threshold features 1°C h steresis.
Setpoint (Fixed thresholds in memory)
Temperature: setting the threshold value to -273°C, the
comparison will be disabled and the related digital points
will be alwa s ‘0’. Setting a different value, a threshold will
be fixed for the digital point related to the temperature.
Daylight: setting this parameter to ‘0’, the digital point re-
lated to da light measurement will not have an threshold.
Setting a value greater than ‘0’, a threshold will be fixed for
the related digital point.
Wind speed: setting this parameter to ‘0’, the digital point
related to the wind speed will not have an threshold. Set-
ting a value greater than ‘0’, a threshold will be fixed for the
related digital point.
The check box near to the threshold value will enable (if
checked) the comparison with the related values, otherwise
the comparison will be executed with the value sent via bus
through the output address.
Mapping
BDTools and DCP Ide allows to show the map of DFME-
TEO module as in the following figure.
The OUT check-box allows to show the information about
the output section.
As usual, the background of the module is green if the
module is connected and well working, otherwise the back-
ground is red.
In the case of a fault sensor, the background of the ad-
dress field of the input section is shown in red color.
Note: The failed sensor condition will be activated with a
dela of 10 seconds; this dela time is fixed and cannot be
modified.
DUEMMEGI s.r.l. - Via Longhena, 4 - 20139 MILANO
Tel. [phone] - Fax [phone] – www.duemmegi.it
Rel.: 2.0 Februar 2019 Page 5 of 6

Domino
DFMETEO
Technical characteristics
DFEMETEO module suppl
voltage
B specific centralized power
suppl mod. DFPW2
Meteo station suppl voltage 24V ± 15%
DFMETEO current consumption Equal to 4 standard modules
Meteo station current consump-
tion
100mA MAX
Temperature range -30 ¸ +50 °C
Da light range 0 ¸ 99000 lux
Wind speed range 0 ¸ 70 m/s
DFMETEO module operating
temperature
-10 ¸ +50 °C
Meteo station operating temper-
ature
-30 ¸ +50 °C
Storage temperature
(DFMETEO + sensor)
-30 ¸ +85 °C
Protection degree of module DF-
METEO
IP20
Protection degree of sensor IP44
Outline dimensions
90mm
35,8mm 58mm
SENSOR
A B Sh
DUEMMEGI
MILANO-ITALY
ADDRESS
DFMETEO
+_
Domino
PATENTED
Correct disposal of this product
(Waste Electrical & Electronic Equipment)
(Applicable in the European Union and other
European countries with separate collection s s-
tems). This marking on the product, accessories or
literature indicates that the product should not be
disposed of with other household waste at the end
of their working life. To prevent possible harm to
the environment or human health from uncontrolled waste dispos-
al, please separate these items from other t pes of waste and re-
c cle them responsibl to promote the sustainable reuse of materi-
al resources. Household users should contact either the retailer
where the purchased this product, or their local government of-
fice, for details of where and how the can take these items for en-
vironmentall safe rec cling. This product and its electronic ac-
cessories should not be mixed with other commercial wastes for
disposal.
Installation and use restrictions
Standards and regulations
The design and the setting up of electrical s stems must be per-
formed according to the relevant standards, guidelines, specifica-
tions and regulations of the relevant countr . The installation, con-
figuration and programming of the devices must be carried out b
trained personnel.
The installation and the wiring of the bus line and the related de-
vices must be performed according to the recommendations of the
manufacturers (reported on the specific data sheet of the product)
and according to the applicable standards.
All the relevant safet regulations, e.g. accident prevention regula-
tions, law on technical work equipment, must also be observed.
Safety instructions
Protect the unit against moisture, dirt and an kind of damage dur-
ing transport, storage and operation. Do not operate the unit out-
side the specified technical data.
Never open the housing. If not otherwise specified, install in closed
housing (e.g. distribution cabinet). Earth the unit at the terminals
provided, if existing, for this purpose. Do not obstruct cooling of the
units. Keep out of the reach of children.
Setting up
The ph sical address assignment and the setting of parameters (if
an ) must be performed b the specific softwares provided togeth-
er the device or b the specific programmer. For the first installa-
tion of the device proceed according to the following guidelines:
Check that an voltage suppl ing the plant has been removed
Assign the address to module (if an )
Install and wire the device according to the schematic dia-
grams on the specific data sheet of the product
Onl then switch on the 230Vac suppl ing the bus power sup-
pl and the other related circuits
Applied standards
This device complies with essential requirements of the following
directives and norms:
2014/30/UE (EMC)
2014/35/UE (Low Voltage)
2011/65/UE (RoHS)
Note
Technical characteristics and this data sheet are subject to change
without notice.
DUEMMEGI s.r.l. - Via Longhena, 4 - 20139 MILANO
Tel. [phone] - Fax [phone] – www.duemmegi.it
Rel.: 2.0 Februar 2019 Page 6 of 6
