Dynamco Cyclops 661 User manual

661 REMOTE CAR ALARM
USER INSTRUCTIONS
Proudly designed and engineered
in Australia by Dynamco Pty Ltd.
Congratulations on having one of the worlds most advanced
and unique Australian designed and engineered vehicle
security systems, installed in your vehicle!
IMPORTANT NOTICE:
Ensure your installer has programmed your individual PIN code before
taking your vehicle. (see “programming new PIN” section).
BUTTON#1
Arm/Disarm/SirenStopPanic
a. Arming: During the arm procedure
the siren chirps once, the indicators
flash once, and the LED flashes slowly.
The siren will chirp three times if a door
isopenwhilearmingthesystem.
b. Triggering: The alarm system may
be triggered (except shock sensor) two
seconds after the last door is closed.
Theshock sensoris activeten seconds
afterthelastdoorisshut.
c. Siren stop: When alarm siren is
sounding, press button #1 to stop the
siren sounding. The alarm will remain
armed.Pressthelockbuttononcemoretodisarmthealarm.
d. Disarm: During the disarm procedure the siren will chirp twice, the
indicators will flash twice and the LED will flash quickly if passive arm is
enabled.
e.Diagnostics:If thealarmhasbeentriggered,whendisarming,thesiren
will chirp four times and the indicators will flash four times (instead of
twice).
f. Lock/Unlock by remote: if the ignition switch is on, only the central
lockingwillrespondtotheremotecontrol.
g. Panic: Hold button #1 for longer than two seconds to sound the siren
andflashtheindicatorsforthirtyseconds.
h. Re-arm: The alarm will auto arm & lock the doors in 30 seconds if the
vehicledoorshavenotbeenopenedsincedisarming.
BUTTON#2
OneTimeMuteArm-Disarm/CarLocator/BootRelease
a. Temporary chirp disable: To disable the siren for one arm/disarm
procedure, press button #2
momentarily before pressing button
#1. The siren will still chirp three
timesifadoorisleftopen.
b. Car locator: Press button #2 for
longer than two seconds while the
alarm is armed to cause the siren to
pulse and the indicators to flash for
fiveseconds.
c. Boot release: Press button #2 for
longer then two seconds to disarm
the system and open the boot. The
vehicleindicatorswill flash fourtimes
toconfirmbootreleasesignal.
RE-ARM&RELOCK
a.Relock:Thealarmwillrearm&relockthedoorsin30secondsifnodoors
havebeenopened.Thisistopreventaccidentaldisarm.
b. Passive arm: the alarm will automatically arm after 30 seconds if the
ignition is turned off, then the doors are closed. This feature can be
disabled.
c. Passive lock: The alarm will automatically lock the doors 30 seconds
after the ignition is turned off and the last door is closed. This feature can
beenabled.Warning:Stronglyrecommendednottobeused.
d. Anti Hi-jack: When enabled, the alarm will lock the doors four seconds
after the ignition switch is turned on. The alarm will unlock the door
immediately after the ignition is switched off. This feature will not activate
whilethedoorisopen.
Special Considerations:
Ensure the interior light of your vehicle is extinguished before
arming the 661. A fading dome light will “trick” the alarm into thinking
one of the doors is open during the arm cycle. An open door
warning is signalled by 3 chirps
PROGRAMMINGNEWREMOTE
1.Disarmthealarmbypressingthebutton#1.
2.Openthedriver'sdoorandleavedooropen.
3.SwitchignitionswitchOffandOn7times.
4.Whenthe7thcountisreached,leaveignitionswitchintheONposition.
5.Vehicleindicators will begin flashingwhenalarm is readytoaccept new
remotecodes.
6.Pressbutton#1onnewremotecontrol.
7.Testremotesbyarminganddisarmingthealarmsystem.
OPTIONSETTINGS
PassiveArm/TransmitterCode-Learning/PassiveLock/Ignition
Lock&Unlock/SetOverridePIN.
1.Disarmthealarmbypressingbutton#1.
2.Openthedriver'sdoorandleavedooropen.
3.TurnignitionswitchOnthenumberoftimescorrespondingtothefeature
youwishtoalter.RefertotheOptionTableforoptionselectionnumber.
4.Whenthecorrectcountisreached,leaveignitionswitchON.
5.Vehicleindicatorswillflashwhenalarmisreadytochangeoption.
6.Pressbutton#1onavalidremotecontrol.
7.Alarm willflashvehicleindicatorsto confirmchange,seeoptiontable for
one/threeflashmeaning.
***Warningthisfunctioncanresultinkeysbeinglockedinvehicle!!
Ignition Switches Feature One flash Three flashes
5Passive arming Disabled Enabled
6Pasive lock Disabled Enabled
7Program new transmitter
8Ignition lock/unlock Disabled Enabled
9Set new PIN
Press new remote control
Begin changing PIN
EMERGENCYPINOVERRIDE
Intheeventaremoteislost,stolenorbroken,the#661maybeoverridden
byusingtheprogrammedtwodigitPersonalIdentificationNumber(PIN).
1.Insertignitionkeyintovehicleignitionswitch.
2.Turnkey tothe ONposition(the positionjust beforeenginecrank). The
redstatusLEDwillglowconstantly.
3. Return the key to the ACC position (the first position that powers your
radio).
4.ThestatusLEDwillbeginflashingslowly.Counttheflashes.
5. When the flashes match the first number in your PIN, turn the ignition
switchtotheONpositionagain.
6.Repeatstep#5fortheseconddigitofthePIN.
7. The status LED will extinguish and the 661 will now be disarmed and
enginewillstart.
PROGRAMMINGNEWPIN
1.Disarmthealarmbypressingbutton#1.
2.Openthedriver'sdoorandleavedooropen.
3.SwitchignitionswitchOffandOn9times.
4.Whenthe9thcountisreached,leaveignitionswitchON.
5. Vehicle indicators will flash when alarm is ready accept new remote
PIN.
6. Press button #1 the number of times corresponding to the first digit of
the new PIN. Press button #2 the number of times corresponding to the
seconddigitofthenewPIN.
7. Alarm will flash vehicle indicators three times to confirm successful
programming.
*** All central locking and boot release features require additional
hardware, which is not supplied with the 661 alarm system. Vehicles with
centrallocking and/orelectronicbootreleasewillstillrequire connections
tothe661whicharenotapartofastandardinstallation.

ENGINEIMMOBILISATION
When the system is armed the
engine is immobilised. The actual
point of immobilisation varies from
vehicletovehicle,normallyfuel and
startermotorareimmobilised.
SPECIFICATIONS
Manufacturedby DynamcoPtyLtd
ModelNumber Cyclops661
Supplyvoltage +12VDC
Currentconsumption <10mA
BATTERYREPLACEMENT
Using a small Phillips-head screwdriver, remove the screw(s) at the back
of the remote and carefully separate the two body housings taking take
care not to disturb the circuit board. Remove the old battery whilst paying
attention to the orientation of the positive and negative terminals. Insert
new battery in identical fashion to the original and re-assemble remote.
Replace screw(s) and test remote control by pressing main button. For
furtherinformation,pleasecontactyourlocalCyclopsservicecentre.
Remote battery type 23a.
PROBLEMSOLVING
Systemwon'tactivatewhenthedoorisopened
-Make sureyouhaveusedthe remotetosetthesystem. Itwillnottriggerif
thesystemhasautoarmed.
- Make certain the system is activated. LED should be flashing on the
dashboard.
-Makesurethattheinteriordomelighthasnotbeenleftinthepermanently
ONposition.
- Make sure that you have allowed at least 10 seconds after setting the
system,beforeopeningthedoor.
Systemwon'tactivateordeactivate. LEDwon'tflashorextinguish
-MakesurethatignitionswitchisintheOFFposition.
-Makesurethevehiclebatteryisnotflat.
-Tryyourspareremotetransmitterunit.
Theremotefailstooperate
Iftheremotefails tooperateandtheLED doesnotlightupwhenthebutton
is pressed then change the battery. To do this you will need a small Philips
headscrewdriver.(SeeBatteryReplacement)
MANUFACTURER’SHISTORY
Dynamco has been involved in
the science of electronic vehicle
security technology for over 12
years. From small beginnings
Dynamco has grown steadily to
become one of the world’s
leading specialist companies in
electronic vehicle security,
designing and customizing
systems to combat the
increasingly sophisticated
professional car thief without
compromising the user friendliness of the systems. Systems are exported
all over the world, it is easy to name drop when your customer list is so
impressive.RecentlyaddtothelistofBMW&HondainHongKong,Toyota
Indonesia, the FBI in the USA, Australia's largest Hyundai dealer,
Australia’s largest Mitsubishi dealer, as well asAMWAYof New Zealand.
Government departments all over Australia, including the WestAustralian
Police Force plus hundreds of thousands of motorists world wide have
learned to rely on the sophistication and reliability and effectiveness of
Dynamco’s electronic vehicle security systems Each working day over
1000of systemsareinstalledsomewherein theworld,fromPerthto Paris,
from Sydney to Seattle. Dynamco pioneered Radio Frequency
Identification Systems and Random Encryption Technology (Code
Hopping). Both techniques now being fundamental to the majority of
vehiclesecuritysystems installedworldwide. Dynamco iscognisant ofthe
stringent requirements of vehicle electronics and the extremely hostile
environment to which the equipment is subjected. All Dynamco designs
therefore take these and many other factors into consideration. In 1990
Dynamco won the prestigious Australian Design Award but we haven’t
rested on our laurels. Our engineers keep Dynamco at the cutting edge of
electronicvehiclesecurity.
OVERRIDEPINNUMBER: __ __
ANNUALINSPECTION
Dynamco prides itself on the durability and integrity of its car security
systems. We welcome users to contact a Cyclops service centre every
twelve months for an annual inspection. (Please note a charge may be
leviedforthisinspection)
WARRANTYTERMS&CONDITIONS
The Dynamco range of Cyclops Security Systems is covered by an
extensivewarranty(SeeBelow ForPeriod).Intheunlikelyeventofa faulty
system Dynamco will either replace or repair the system at no cost during
thedetailedperiod.Thewarrantydoesallowforthefollowingconditions~
Subject to the conditions stated below, Dynamco Pty Ltd warranty the
product to be free from manufacturing defects and faulty material within
thewarrantyperiodstated.
· Thatthewarrantyregistrationhas beencompletedin fullatthetime of
purchase/installationandisproducedwhenwarrantyserviceissought
· Thewarranty doesnotcovergeneralmaintenance suchascleaning/
adjusting of door, boot, bonnet or any entry point switch, nor replacement
of consumables items such as transmitter batteries, lighting circuit bulbs /
switches.
Thewarrantyshallbenull&voidif:-
1. Any person other than by an Authorised Cyclops Sales, Service &
InstallationCentrehasrepairedtheproduct.
2. Should a system / part defect become apparent within the warranty
period DYNAMCO PTY LTD will repair the product free of charge for parts
and labour. The warranty does not cover service labour content or mobile
servicecontent.
3. The product has been altered or tampered with in any way, or the
serialnumberaltered,defacedorremoved.
4. The defect has been caused by negligence by the owner or their
agent/thirdparty.
5. The product has not been operated correctly, installed by an
unauthorised Cyclops installer or has been subjected to misuse or undue
wearandtear
6. Siren, control module, remote controls or any other system part are
damagedbywater.
Thewarrantydoesnotcoverthefollowingcosts:-
7. TransportoftheproducttoandfromCyclopsServiceCentres.
8. Insurance of the product whilst in transit to or from the Cyclops
ServiceCentres
9. Costofanyservicecall/labourwheretheproductisfoundbyCyclops
to be in good working order The benefits conferred by this Warranty are in
addition to all other rights and remedies, which the consumer has
conferredinlaw.
Noliabilityis acceptedfor anyloss, lossfrom,damage toor inabilitytouse
thevehicletowhichthesystemisinstalled.
WARRANTY REGISTRATION
MUST BE COMPLETED BY RETAILER AT TIME OF INSTALLATION
DATE OF INSTALL’:
PURCHASED FROM :
OWNER’S NAME :
TYPE OF VEHICLE :
VEHICLE REGO’ :
WARRANTY PERIOD :
A) CONTROL MODULE ONLY :
B) REMOTE CONTROLS
AND SIREN :
AUTHORISED BY
SIGNED :
