Dynamic LC5000 User manual

Pasadena Massage Chair
LC5000
Owner’s Manual

Thank you for choosing the Pasadena Edition Massage Chair to complement your lifestyle and
comfort needs. Carefully and thoroughly read this manual before using this product to ensure
proper operation. We recommend keeping this manual for regular review and future reference.
This Owner’s Manual should be kept on hand for easy reference. This product is intended for
residential indoor use only. Product is subject to change. Color may have slight variation.
Pictures used throughout this Owner’s Manual are for representation purposes only and may not
be exact to your specific model.
Contents
Safety Precautions ------------------------------------------------------------------------------------- 1
Features and Functions ------------------------------------------------------------------------------- 6
Components and Descriptions----------------------------------------------------------------------- 7
Before Use ------------------------------------------------------------------------------------------------ 9
Adjusting The Massage Chair ----------------------------------------------------------------------- 13
Starting The Massage Chair ------------------------------------------------------------------------- 16
Troubleshooting ------------------------------------------------------------------------------------------- 22
Care and Storage ------------------------------------------------------------------------------------------ 23
Specifications ----------------------------------------------------------------------------------------------- 24
Warranty ----------------------------------------------------------------------------------------------------- 25
Warranty Card ---------------------------------------------------------------------------------------------- 27
The recommended massage session is 15 minutes. Do not use the massage chair for
longer than 15 minutes and do not continue to massage a specific area for longer than 15
minutes. You must rest for at least 30 minutes before using the massage chair again.
Usage greater than 15 minutes without a 30 minute rest period can result in over-
stimulation of muscles and nerves.
This product is not a medical device and is not intended to cure ailments. If you feel any
discomfort at any time during use, discontinue use immediately. If you find any abnormal
condition, stop using the massage chair immediately.

Safety Precautions
Carefully and thoroughly read this manual before using this product. The Owner’s Manual
should be kept in an easily accessible place for future reference. Please pay special attention to
all “caution” and “warning” symbols and labels throughout this manual and on the massage
chair. The Owner’s Manual contains important information about how to use the massage chair
safely and correctly avoiding any possible damage to property and injury to users. If you feel
any discomfort at any time during use, discontinue use immediately.
This action could result in serious injury or death.
This action could result in personal injury or damage to personal property.
This symbol means “DO NOT DISASSEMBLE”.
This action means to “UNPLUG THE CHAIR”.
This action means “PROHIBITED USE”.
If you find any abnormal condition, stop using the massage chair immediately.
oIf you find that the massage chair is malfunctioning, stop operation immediately, unplug
the massage chair cord from the wall receptacle and contact the service provider. If you
continue to operate the massage chair, it can lead to damage of the massage chair,
electric shock, fire, and/or serious bodily injury.
oIf there is a lightning storm, do not use the massage chair and unplug the massage chair
cord from the wall receptacle.
oIf any liquid is spilled onto the massage chair, any abnormal noise heard from the
massage chair, any obstacle placed onto the massage chair, or the massage chair is
drooping down, tipping over, or has broken parts, stop any and all operation of the
massage chair and unplug the massage chair cord from the wall receptacle.
-1-

oIf you become uncomfortable at any time when using the massage chair, stop
using the chair immediately.
oOnly use the massage chair when it is placed on a level floor.
oWhen operating the massage chair, make sure the switches are operational with
reference to their intended functions.
oAny persons having the following conditions must not use the massage chair:
Persons who have thrombosis, severe aneurism, acute varicosity, or skin
infections including inflammation of the hypodermis
Persons who feel discomfort when using the massage chair
oAny persons with any of the following conditions should seek medical advice from his/her
medical physician before use:
Persons who have electronic medical devices or have electronic medical devices
easily susceptible to electromagnetic interference
Persons with malignant tumors
Persons with serious heart disease
Woman who are in their menstrual period or pregnant
Persons with sensory disturbance caused by peripheral circulatory disorder due to
diabetes
Persons with sensory disturbance caused by other medical disorders
Persons being treated for personal injuries
Persons with a high fever greater than 100oF/38oC
Persons with medical conditions such as acute inflammation, high blood pressure,
or chills
Persons with sickness or under bed rest orders
Persons with Osteoporosis, spinal fractures, or acute pain
Persons with inflammation due to sprains or muscle strain
-2-

Do not use the massage chair when your hands or body is wet as it can
result in electric shock and personal injury.
Do not spill water or other liquid onto the massage chair. Do not place
massage chair in a humid environment such as a bathroom. Placing the
massage chair in a humid environment can result in electric shock and
personal injury.
Do not operate the massage chair with children or pets playing on or near
the massage chair. Make sure before operating the massage chair that
you can do so when children and pets are at a safe distance away.
Do not attempt to disassemble or repair the massage chair, power cord,
or controller on your own. It may result in electric shock, personal injury,
or malfunction of the massage chair.
Do not tamper with or manipulate the power cord. The power cord should
not be damaged in any way when operating the massage chair. Do not
bend, stretch, twist, or wrap the power cord. Do not hang the power cord
up on objects or furniture. A damage power cord can result in electric
shock, fire, and/or personal injury.
oThis product is not intended for use by children or persons with reduced mental
capabilities. Keep children, persons with reduced mental capabilities and pets away from
the massage chair when in use.
oDo not use this product with any other power source other than AC 110V-120V. Do not
wrap the power cord around the power chair as this can result in electric shock, fire
and/or personal injury.
oDo not let children or pets sit and play on the massage chair as this can result in physical
injury or malfunction.
-3-

oWhen the massage chair is in use, do not place your fingers into the gap between the
housing and cushion of the massage chair as this can result in physical injury.
oDo not use the massage chair to massage the head or stomach as this can result in
nausea and/or physical injury.
oDo not use the massage chair without its cloth cover.
oDo not use the massage chair if the cloth becomes damaged or ripped.
In the event of a power failure, switch the main power switch to OFF. Then disconnect
the power cord from the wall receptacle. This will prevent any unexpected sudden
operation when the power failure is restored.
Do not touch the wall receptacle, plug, or power cord with wet hands.
When not using or if a power failure occurs when the massage chair is in operation, turn
the main power switch OFF and disconnect the power cord from the wall receptacle to
prevent electric shock or accidental injury.
In the event of cleaning the massage chair, turn the main power switch OFF on the
massage chair and disconnect the power cord from the wall receptacle to prevent
electric shock or accidental injury.
When disconnecting the massage chair power cord, please do so by removing the plug
and not by grabbing the massage chair power cord and pulling. Pulling on the massage
chair power cord can result in electric shock, short circuit, fire, and/or physical injury.
Do not use the massage chair immediately after a meal or drinking fluids as this may
result in discomfort.
Do not hang any object using the massage chair power cord.
Handle the controller with care. Do not drop the controller as it could result in electric
shock, fire, and/or personal injury.
Do not use the massage chair near any open flames, such as a fire place, or any other
heating device. Do not place the massage chair near floor heating systems as it could
result in fire.
Do not smoke while operating the massage chair and do not place the massage chair
where there is underfloor heating.
-4-

oDo not rip, tear, or cut the massage chair fabric cover. This can result in personal injury
and malfunction of the massage chair.
oDo not bend, twist, or stretch the power cord as this could result in electric shock and/or
fire.
oDo not operate the massage chair if the power cord shows any signs of damages. Do
not plug the massage chair cord into a loose or damaged wall receptacle as this could
result in electric shock, fire, and/or personal injury.
oDo not force any overloading of each function setting as it will result in malfunction of the
massage chair and possible personal injury.
oDo not operate the massage chair if you are drowsy or sleepy. Do not fall asleep while
the massage chair is operating as this can lead to unconsciousness and result in
discomfort and/or personal injury.
oDo not drag the massage chair over the floor as this can damage your floor and cause
the massage chair to malfunction. Carry or roll the massage chair (if it has wheels)
carefully so as to not damage the massage chair or scratch your flooring.
oThis product is designed for home use and not for commercial purposes.
oDo not operate the massage chair under any cloth materials, such as a blanket. This
could lead to excessive heating of the massage chair and can result in a fire and/or
personal injury.
oMake sure the massage chair power cord fits snuggly into the wall receptacle. Be sure
there is no dust obstructing the connection between the massage chair power cord and
wall receptacle.
oDo not stand or tread on the massage chair. Do not force overloading the massage chair
as this can lead to personal injury.
-5-

oDo not use the massage chair near any open flames or flammable gas. This can result in
a possible fire, personal injury, or malfunction and damage of the massage chair.
oDo not use the massage chair near areas where aerosol spray products are used as this
can damage the massage chair.
oDo not clean or spray the massage chair with abrasive cleaning agents such as
detergent, alcohol, or other chemical based agents as this can lead to fire, electric shock
and/or damage the massage chair.
oKeep children and persons with reduced mental capabilities away from the massage
chair when it is being operated.
oThis product is not to be used by children, persons on bed rest, or persons with reduced
mental capabilities unless directed by a medical physician.
Features and Functions
Features:
1. Integrated Massage Function:
The Integrated Massage Function is compact with exceptional performance. This function
allows for roller massage from the neck to the shoulder while air massaging on the
shoulders, pelvic, hip, and legs. In addition, the toes will also receive the airbag massage.
2. Actuator Reclining Function:
The Actuator Reclining Function allows for easy adjustment for the most comfortable
positioning. The backrest can be adjusted in a range of approximately 115oto 165owhile
the footrest has coordinated up and down adjustments.
3. Various Functions:
The preset programs will help rejuvenate and relive the body of fatigue. By selecting the
Optimal program according to your own personal preference, you can experience the ideal
massage. You can choose the manual selection which allows you to combine massage
functions with up to 81 possible massage combinations.
-6-

Functions:
As a therapeutic massage device for home use, the massage chair provides such
benefits as relaxing the muscles, relieving the body from minor muscle aches and
pains, and helpful in improving sleep.
Components and Descriptions
-7-

1. ON/OFF: When the ON/OFF button is pressed, the massage
12 chair will enter standby mode. If the ON/OFF button is pressed
again, the rollers will return back to their initial position. Please
note that when the power is ON, the red LED light is illuminated.
When the power is OFF, the red LED light will turn off.
3 2. STOP: When the STOP button is pressed, all of the airbags will
deflate and all functions will stop. The STOP button should be
4 used in case of emergency or malfunction of the massage chair.
53. PROGRAM SELECTION: Press this button to select among the
different programs.
4. ADJUST ROLLER POSITION: These buttons allow you to
6manually adjust the rollers to specific positions.
5. VIBRATION: When the VIBRATION button is pressed, you
will be able to select the strength and massage function.
76. AUTO: When the AUTO button is pressed, you can select
kneading, tapping, or knead/tapping massage.
87. ADJUST (MANUAL): These buttons are used to adjust the
massage area of the roller massage, width, and strength.
8. ADJUST BACKREST: Press this button to adjust the reclining
of the backrest and the footrest.
-8-

oDo not splash water or any other liquid onto the massage chair or controller.
oDo not operate the massage chair with wet hands.
oTo not sit, drop, or tamper/dismantle the controller. Do not pull excessively on the
controller wire.
oDo not bring the controller, including the LCD monitor, within contact of any sharp objects
as it may cause damage.
Before Use
This massage chair may be packaged with the backrest folded. If so and
before use, please raise up the backrest.
Please carefully and thoroughly follow the instructions for assembling the massage chair.
The massage chair is packaged with the massage chair back lying flat. Before operation,
the massage chair back will need to be put to the upright position using the controller. If
the backrest cover is not already zippered onto the backrest of the massage chair, then
you will need to install it. You can do this by attaching the backrest cover using the
zippers on the left/right side and the top of the backrest of the massage chair.
When using the massage chair, do not operate the massage chair in a humid
environment. Be sure not to drastically change the room temperature in which the
massage chair resides. Drastic changes in room temperature can lead to rusting of the
metal parts and greatly affect the operation of the massage chair causing damage.
Massage Chair Placement –Please be sure to have a clearance in front and behind the
massage chair of approximately 20”/50 cm to prevent it from touching any objects or
walls in the declined position.
Over 20”/50cm
Over 20”/50cm
-9-

oDo not use the massage chair in the bathroom or any other humid
environment.
oMake sure the massage chair is assembled and operated on a flat level,
non-slippery floor.
oDo not use the massage chair in dusty and high ambient temperature
environments. The ambient room temperature needs to be below
104oF/40oC.
oDo not place the massage chair in direct sunlight or near heating
equipment.
oDo not smoke or operate the massage chair near any open flames.
Proceed in laying a rug or mat (optional) under the massage chair to prevent
damages to your floor. This is optional and will reduce operational noises. Never
place the massage chair on and electric blanket/rug.
Make sure the floor which the massage chair will be placed on can support the
massage chair. Be careful not to damage your floor by dragging the massage chair.
The placement of the massage chair needs to be at least 3.5 ft away from any and all
audio devices such as a television or radio to avoid product interference.
The weight limit of the massage chair is 220lbs/100kgs.
Confirm Product Contents –
Make sure that all of the massage chair parts are included.
-10-

How to Move –When moving the massage chair, make sure the main power switch is in
the OFF position and the massage chair cord is unplugged from the wall receptacle.
When moving the massage chair using When lifting and moving the massage chair,
the caster wheels, straighten the massage lay the back of the massage chair flat into
chair to the upright position and grab hold the reclined position and grab hold of the front
of the metal bar under the leg support at and rear of the massage chair. Now lift and
the front of the massage chair. Lift and roll move the massage chair to the desired
the massage chair to the desired location. location.
Hold the chair
by both
sides of the
backrest
Hold the
the chair by
footrest
To prevent damages to your floor, you can Be sure not to drop the massage chair as this
lay something over your floor such as a may cause damage to the massage chair as
blanket or cardboard. well as your floor.
oThe massage chair cannot be moved through doorways that measure less than 32” (in
most cases).
oDue to the weight of the massage chair, do not attempt to lift the massage chair if it is to
heavy. Be cautious when lifting so that you do not injury yourself.
oBe careful to not damage or drop the controller as it is attached to the massage chair.
oDo not lift the massage chair when someone is sitting in it.
oMake sure the massage chair power cord is disconnected from the wall receptacle before
attempting to move the massage chair.
-11-

How to Connect the Power Source
1. Connect the massage chair power 2. Turn the main power switch ON at the
cord to the lower right front of the lower right front of the massage chair.
massage chair and plug the other
end into the wall receptacle.
Please Note: If the massage chair rollers get stuck, turn the main power switch ON and
press the ON/OFF button to return the massage chair to its default position.
oDo not plug the massage chair power cord into an external transformer.
oMake sure the massage chair main power switch is in the OFF position before plugging
the massage power cord into the wall receptacle.
oMake sure the massage chair power cord fits snug and tight into the wall receptacle.
-12-

Confirm the Material
Before using the massage chair, make sure the massage chair leather and other
massage chair coverings are not damaged. Unzip the zipper and put your hand/finger
into the gap between the chair back and the back cushion to check whether the fabric
material is broken or damaged.
oBefore using the massage chair, make sure there are no damages to the leather
material/cloth material/plastic material of the massage chair. Even if a small tear is
located, do not operate the massage chair and contact your dealer. Any damaged
material is a safety hazard and the massage chair must not be operated.
Adjusting The Massage Chair
Please follow the instructions for adjusting the massage chair. Failure to do so can result in
damaging the massage chair.
Sitting in the Massage Chair
In the default setting, the massage chair back rollers are displaced at the lower waist of
the chair back. For safety reasons, please make sure that the rollers are situated in the
correct position before sitting in the massage chair. If the positions are incorrect, restart
the massage chair using the controller. After the rollers return to their default positions,
proceed in slowly sitting in the massage chair and placing your legs on the footrest.
Please note: Before exiting the massage chair, make sure to first remove your legs
and place them on the floor.
-13-

oOnce you have raised the footrest using the controller, do not sit in the massage chair.
You must only sit in the massage chair once the footrest is lowered.
oBefore entering the massage chair, make sure the massage chair is in the upright
position. Once you are in the massage chair, you can adjust the angle of the chair using
the controller.
oNever stand on the massage chair as this can damage the massage chair.
Adjusting the Angle of the Massage Chair
Press this button to lay Press this button to raise
the massage chair flat the massage chair upright
During the adjusting of the massage chair, the footrest will adjust accordingly.
-14-

You can adjust the angle of the massage chair by pressing the corresponding button on the
controller. If you hold the button for over 3 seconds and then let go with the indicator light
flashing, the massage chair will adjust to your position preference until the button or reverse
button is pressed again.
Please note: The main power switch at the right front of the chair overrides the
controller. If the ON/OFF button on the controller is OFF, you will still be able to
adjust the angle of the massage chair. If you press the STOP button, you will
not be able to adjust the angle of the massage chair.
oBe sure children and pets are kept away from the massage chair when it is in use. Do
not adjust the massage chair angles when children or pets are near the massage chair.
Make sure you have enough clearance at the front and rear of the massage chair when
adjusting the angle of the massage chair back and footrest.
oBe sure children and pets are kept away from the massage chair when you descend the
massage chair back and footrest. Never place your hands, fingers or objects under the
footrest.
-15-

Starting The Massage Chair
I. Massage Selections (AUTO)
The preset programs make it easy to select a function that suits your preferences. Once
you have chosen the desired function, the massage chair will enter the body scanning
mode.
This selection is recommended for users who are melancholy or who feel a
lack of energy.
This selection is recommended for users who seldom use the massaging
equipment. This selection may also improve sleeping.
This selection is recommended for those users seeking a less intense
massage. Typically, this selection is for older users and users who desire a
softer massage.
II. Massage Selections (MANUAL)
The Manual mode allows you to combine your desired massage functions. You can
adjust the massage speed, massage area, and massage strength.
Knead Tap Knead/Tap Vibration
Roller kneading on Roller tapping on Kneading and tapping Vibrator on seat
the back the back on the back and leg rest
III. Start Massage
Once the power cord is plugged into the wall outlet and connected to the massage chair,
the red LED light will illuminate. Press the ON/OFF button and the massage chair will be
in standby mode. The screen will alert the user to choose the massage function.
-16-

IV. Select Function
A. Auto Program
Select one of the buttons in the AUTO program. There are 3 programs available
to help relieve fatigue.
B. Manual Program
Select one of the buttons in the MANUAL program. You can also combine a roller
massage and an air massage.
Combined selections available
When you make a selection, the indicator light will illuminate. You will have the option of
selecting air massage, kneading, tapping, kneading/tapping per your preference.
V. Adjusting the Roller Position
You can adjust the roller position, width, and massage area.
-17-

VI. How To Use
A. Under the AUTO selection, you can select one of the AUTO programs. During the
operation, you can switch to either of the 3 AUTO programs.
B. You can adjust the backrest to move upward or downward.
During the massage, you can stop the massage operation by pressing the ON/OFF
button. If you feel any discomfort or if the massage chair malfunctions, you can press
the STOP button. For safety, all of the mechanical moving parts of the massage chair will
stop operating and the airbags will deflate. The massage chair also has built in safety
features which can stop the massage operation if the massage chair malfunctions.
-18-
