e2v ELIIXA+ 16K/8K CXP MONO User manual

ELIIXA+ Family
CMOS Multi-Line Camera
e2v.com/cameras
USER MANUAL
ELIIXA+ 16K/8K CXP MONOCHROME

USER MANUAL ELIIXA+ 16K/8K CXP MONO –REV K–06/2017
PA G E |2
Table of Contents
1 CAMERA OVERVIEW ................................................................................................................5
1.1 Features................................................................................................................................................... 5
1.2 Key Specifications.................................................................................................................................... 5
1.3 Description............................................................................................................................................... 6
1.4 Typical Applications................................................................................................................................. 6
1.5 Models..................................................................................................................................................... 6
2 CAMERA PERFORMANCES .......................................................................................................7
2.1 Camera Characterization ......................................................................................................................... 7
2.2 Image Sensor .......................................................................................................................................... 8
2.3 Multi-Lines modes ................................................................................................................................... 8
2.4 Response & QE curves............................................................................................................................. 9
2.4.1 Quantum Efficiency .......................................................................................................................... 9
2.4.2 Spectral Response ............................................................................................................................ 9
3 CAMERA HARDWARE INTERFACE...........................................................................................11
3.1 Mechanical Drawings............................................................................................................................. 11
3.2 Input/output Connectors and LED......................................................................................................... 12
3.2.1 Power Over CoaXPress ................................................................................................................... 13
3.2.2 Status LED Behaviour...................................................................................................................... 13
3.2.3 Trigger Connector........................................................................................................................... 14
4 STANDARD CONFORMITY ......................................................................................................15
4.1 CE Conformity........................................................................................................................................ 15
4.2 FCC Conformity...................................................................................................................................... 15
4.3 RoHs Conformity.................................................................................................................................... 15
5 GETTING STARTED.................................................................................................................16
5.1 Out of the box........................................................................................................................................ 16
5.2 Setting up in the system........................................................................................................................ 16
6 CAMERA SOFTWARE INTERFACE ............................................................................................17
7 Camera Commands ...............................................................................................................18
7.1 Device Control ....................................................................................................................................... 18
7.2 Image Format ........................................................................................................................................ 20
7.2.1 Structure of the Sensor................................................................................................................... 21
7.2.2 Binning modes ................................................................................................................................ 21

USER MANUAL ELIIXA+ 16K/8K CXP MONO –REV K–06/2017
PA G E |3
7.2.3 Multi-Line Gain ............................................................................................................................... 22
7.2.4 HDR mode (Only available on “BH0” Models)................................................................................ 22
7.2.5 Test Image Pattern Selector ........................................................................................................... 23
7.3 Acquisition Control ................................................................................................................................ 24
7.3.1 External Triggers on GPIO Connector............................................................................................. 25
7.3.2 CXP Trigger Line.............................................................................................................................. 25
7.3.3 Scan Direction................................................................................................................................. 26
7.3.4 Full Exposure Control Mode ........................................................................................................... 27
7.3.5 GenICam Triggers ........................................................................................................................... 29
7.3.6 Trigger Presets................................................................................................................................ 30
7.3.7 Rescaler .......................................................................................................................................... 31
7.4 Digital I/O Control.................................................................................................................................. 32
7.5 Counters & Timers Control.................................................................................................................... 33
7.5.1 Counters ......................................................................................................................................... 33
7.5.2 Timers ............................................................................................................................................. 35
7.6 Gain and Offset...................................................................................................................................... 36
7.7 Flat Field Correction .............................................................................................................................. 39
7.7.1 Automatic Calibration..................................................................................................................... 42
7.7.2 Manual Flat Field Correction .......................................................................................................... 42
7.7.3 Save & Restore FFC in User Memory Banks ................................................................................... 43
7.8 Look Up Table ........................................................................................................................................ 44
7.8.1 Save & Restore LUT in User Memory Banks................................................................................... 44
7.9 Statistics and Line Profile....................................................................................................................... 46
7.10 Privilege Level...................................................................................................................................... 47
7.11 Save & Restore Settings in User Memory Banks ................................................................................. 48
APPENDIX ................................................................................................................................49
Appendix A. Test Patterns ........................................................................................................50
A.1 Test Pattern 1: Vertical wave ................................................................................................................ 50
A.2 Test Pattern 2: Fixed Horizontal Ramps ................................................................................................ 50
A.1.2 In 8 bits (Full) format –No Binning (16384 pixels)......................................................................... 50
A.2.2 In 12 bits (Medium) format –No Binning (16384 pixels)............................................................... 51
A.3.2 In 8/12 bits Full/Medium format with Binning (8192 Pixels)......................................................... 52
Appendix B. Timing Diagrams ...................................................................................................53
B.1 Synchronization Modes with Variable Exposure Time.......................................................................... 53
B.2 Synchronisation Modes with Maximum Exposure Time....................................................................... 54

USER MANUAL ELIIXA+ 16K/8K CXP MONO –REV K–06/2017
PA G E |4
B.3 Timing Values ........................................................................................................................................ 54
Appendix C. HDR Mode ............................................................................................................55
C.1 HDR Block .............................................................................................................................................. 55
C.2 Example with Ratio 2 and 10bits output ............................................................................................... 55
C.3 HDR With LUT 10bits => 8bits ............................................................................................................... 56
C.4 Example of difference between “AB” and “C” Line :............................................................................. 56
Appendix D. Data Cables ..........................................................................................................57
Appendix E. Lenses Compatibility .............................................................................................58
Appendix F. Revision History ....................................................................................................59

USER MANUAL ELIIXA+ 16K/8K CXP MONO –REV K–06/2017
PA G E |5
1CAMERA OVERVIEW
1.1 Features
 Cmos Sensor 4x 16384 Pixels, 5 x 5µm
 Multi-Line structure (1, 2 or 4 lines to adapt the sensitivity)
 Interface :
 CoaXPress® (4x Links)
 Line Rate :
 Up to 100000 l/s
 Data Rate :
 Up to 1,6GB/s in CoaXPress®
> CXP-3 : 4x3,125 Gbps
> CXP-6 : 4x6,25 Gbps
 Bit Depth : 8, 10 or 12bits
 Flat Field Correction
 Look Up Table
 Low Power Consumption : <18W
 Compliant with Standard Lenses of the Market
 Full Exposure Control, even in 4S “TDE” mode
 New Sensor version and HDR mode on “BH0” Models
1.2 Key Specifications
Note : All values in LSB is given in 12 bits format
Characteristics
Typical Value
Unit
Sensor Characteristics at Maximum Pixel Rate
Resolution
4 x 16384
4 x 8192
Pixels
pixel size (square)
5 x 5
10 x 10
µm
Max line rate
100
100
kHz
Radiometric Performance at Maximum Pixel Rate and minimum camera gain
Bit depth
8, 10, 12
Bits
Response (broadband)
450
LSB/(nJ/cm²)
Full Well Capacity
27300 (in 2S or 4S mode and MultiGain at 1/2)
electrons
Response non linearity
0,3
%
PRNU HF Max
3
%
Dynamic range (1S / 2S / 4S mode)
67,6 / 70,7 / 68,7
dB

USER MANUAL ELIIXA+ 16K/8K CXP MONO –REV K–06/2017
PA G E |6
Functionality (Programmable via GenICam Control Interface)
Analog Gain
Up to 12 (x4)
dB
Offset
-4096 to +4096
LSB
Trigger Mode
Timed (Free run) and triggered (Ext Trig, Ext ITC) modes
Mechanical and Electrical Interface
Size (w x h x l)
100 x 156 x 36
mm
Weight
700
g
Lens Mount
M95 x 1
-
Sensor alignment ( see chapter 4 )
±100
µm
Sensor flatness
±35
µm
Power supply
Power Over CoaXPress : 24
V
Power dissipation –Typ. while grabbing
< 18
W
General Features
Operating temperature
0 to 55 (front face) or 70 (Internal)
°C
Storage temperature
-40 to 70
°C
Regulatory
CE, FCC and RoHS compliant
1.3 Description
e2v’s next generation of line scan cameras are setting new, high standards for line rate and image quality.
Thanks to e2v’s recently developed multi line CMOS technology, the camera provides an unmatched
100 000 lines/s in a 16k pixel format and combines high response with an extremely low noise level; this
delivers high signal to noise ratio even when short integration times are required or when illumination is
limited. The 5μm pixel size is arranged in four active lines, ensuring optimal spatial resolution in both
scanning and sensor directions with off-the-shelf lenses. An outstanding data rate in excess of 1.6 Gpixels
per second, delivered via a new CoaXPress interface, allows for extremely high throughput and opens up an
array of new possibilities for the next generation of inspection systems for demanding applications such as
flat panel display, PCB and solar cell inspection.
1.4 Typical Applications
 Flat Panel Display Inspection
 PCB Inspection
 Solar Cell Inspection
 Glass Inspection
 Print Inspection
1.5 Models
Part Number
Sensor
Details
Max Line Rate
EV71YC4MCP1605-BA0
4x Lines, 16k 5µmx5µm
-
100 KHz
EV71YC4MCP1605-BH0
4x Lines, 16k 5µmx5µm
New Sensor + HDR Modes
100 KHz

USER MANUAL ELIIXA+ 16K/8K CXP MONO –REV K–06/2017
PA G E |7
2CAMERA PERFORMANCES
2.1 Camera Characterization
Unit
Mode 1S (0dB)
Mode 2S (0dB)
Mode 4S (0dB)
Min
Typ.
Max
Min
Typ.
Max
Min
Typ.
Max
Dark Noise RMS
LSB
-
1,7
2,2
2,4
3,1
3
4
Dynamic Range
-
-
2394:1
-
-
3412:1(*)
-
-
2730:1(*)
-
Readout Noise
e-
-
5,7
-
-
8
-
-
10
-
Full Well Capacity
e-
-
13650
-
-
27300
-
-
27300
-
SNR
dB
-
40
-
-
43(*)
-
-
43(*)
-
Peak Response (660nm)
LSB/
(nJ/cm2)
-
137
-
-
274
-
-
547
-
Non Linearity
%
-
0,3
-
-
0,3
-
-
0,3
-
Without Flat Field Correction :
FPN rms
LSB
-
0,4
1,5
-
0,7
1,5
-
0,8
1,5
FPN pk-pk
LSB
-
3,2
15
-
5
15
-
5,6
15
PRNU hf (3/4 Sat)
%
-
0,13
0,25
-
0,1
0,25
-
0,1
0,25
PRNU pk-pk (3/4 Sat)
%
-
1
3
-
0,8
3
-
0,8
3
Test conditions :
Figures in LSB are for a 12bits format.
Measured at exposure time = 50µs and line period = 50µs in Ext Trig Mode (Max Exposure Time)
Maximum data rate
Stabilized temperature 30/40/55 °C (Room/Front Face/Internal)
SNR Calculated at 75% Vsat with minimum Gain.
(*) In mode 2S/4S, only with the use of the Multi-Line Gain

USER MANUAL ELIIXA+ 16K/8K CXP MONO –REV K–06/2017
PA G E |8
2.2 Image Sensor
The Eliixa+ 16k sensor is composed of two pairs
of sensitive lines. Each pair of lines use the
same Analog to Digital Column converter (ADC
Column). An appropriate (embedded) Time
delay in the exposure between each line this
allows to combine two successive exposures in
order to double the sensitivity of a single line.
This Time Delay Exposure is used only in the 4S
multi-line modes (4 Lines) as described below.
The 16384 Pixels of the whole sensor are
divided in 4 blocks of 4096 pixels.
2.3 Multi-Lines modes
a
b
c
d
a
b
c
d
B
a
b
c
d
C
B
A
C
D
Mode 1S = B
Mode 2S = B+C (FPGA)
Mode 4S = (A.B)+(C.D)
Note : (A.B) = summation in the sensor
Multi-Lines Modes (16k Pixels Output)
a
b
c
d
a
b
c
d
A
A
B
Mode 1SB = A
Mode 2SB = (A+B)
Binning Modes (8k Pixels Output)
ADC Column
ADC Column
Memory Node
Pixel Line A
Pixel Line B
Pixel Line C
Pixel Line D
Memory Node

USER MANUAL ELIIXA+ 16K/8K CXP MONO –REV K–06/2017
PA G E |9
2.4 Response & QE curves
2.4.1 Quantum Efficiency
2.4.2 Spectral Response
Single Modes : 1S, 2S, 4S
0
100
200
300
400
500
600
400 450 500 550 600 650 700 750 800 850 900 950 1000 1050 1100
LSB12bits/(nJ/cm2))
nm
Response in 16k Pixels 5µm
4S 2S
0%
10%
20%
30%
40%
50%
60%
70%
80%
360 460 560 660 760 860 960 1060
Quantum Efficiency

USER MANUAL ELIIXA+ 16K/8K CXP MONO –REV K–06/2017
PA G E |10
Binning Modes : 1SB, 2SB
0
100
200
300
400
500
600
700
800
900
1000
1100
1200
400 450 500 550 600 650 700 750 800 850 900 950 1000 1050 1100
LSB12bits/(nJ/cm2))
nm
Response in 8k Pixels 10µm
1SB 2SB

USER MANUAL ELIIXA+ 16K/8K CXP MONO –REV K–06/2017
PA G E |11
3CAMERA HARDWARE INTERFACE
3.1 Mechanical Drawings
Z
X
Y
The Step file is available on
the web :
www.e2v.com/cameras

USER MANUAL ELIIXA+ 16K/8K CXP MONO –REV K–06/2017
PA G E |12
3.2 Input/output Connectors and LED
Sensor alignment
Z = -9.4 mm
±100µm
X = 9 mm
±100 µm
Y = 50mm
±100 µm
Flatness
±50 µm
Rotation (X,Y plan)
±0,1°
Tilt (versus lens mounting plane)
50µm
USB Connector
For Firmware
upgrade
Trigger Connector
Multi-Colored LED
for Status and
diagnostic
CoaXPress
Connectors

USER MANUAL ELIIXA+ 16K/8K CXP MONO –REV K–06/2017
PA G E |13
3.2.1 Power Over CoaXPress
The ELIIXA+ CXP is compliant with the Power Over CoaXPress : There is no Power connector as the power is
delivered through the Coaxial Connectors 1 and 2.
In the Standard, the Power Over CoaXPress allows to deliver 13W (under 24V) per Channel.
The ELIIXA+ CXP requires 18W then two connectors are required for the power : The two first are used for
this purpose.
If you want to Power ON the Camera you have to connect the Coaxial connector output 1 of the camera to
the coaxial connector 1 of the Frame Grabber.
Note 1 : Only the connector 1 position is mandatory. The 3 others connectors can be inverted but the
camera still needs the 2 first connectors to get it power and be able to start up.
Note 2 : With some frame grabber you have access to a specific command (from the Frame Grabber
interface) for shutting down/up the power of the CoaxPress : This solution, with the complete reboot, is the
better solution to ensure a complete power On of the Camera.
3.2.2 Status LED Behaviour
The Power LED behavior detail is the following :
Colour and State
Meaning
Off
No power
Solid orange
System booting
Fast flash green Shown for a minimum of 1s even if
the link detection is faster
Link detection in progress
Slow flash alternate red / green
Device / Host incompatible
Slow pulse green
Device / Host connected, but no data being
transferred
Slow pulse orange
Device / Host connected, waiting for event (e.g.
trigger, exposure pulse)
Solid green whenever data transferred (i.e. blinks
synchronously with data)
Device / Host connected, data being transferred
500ms red pulse In case of multiple errors, there
shall be at least 200ms green before the next error is
indicated
Error during data transfer (e.g. CRC error, single bit
error detected)
Fast flash red
System error (e.g. internal error)

USER MANUAL ELIIXA+ 16K/8K CXP MONO –REV K–06/2017
PA G E |14
3.2.3 Trigger Connector
Camera connector type: Hirose HR10A-7R-5SB or compliant
Cable connector type: Hirose HR10A-7P-5P (male) or compliant, Provided with the Camera
IN1/IN2 are connected respectively to Line0/Line1 and allow to get external line triggers or the
forward/Reverse “Live” indication.
On the Connector side, the 120Ω termination is validated only if the input is switched in LVDS or RS422. The
electrical schematic is detailed below :
Signal
Pin
LVDS IN1+ / TTL IN1
1
LVDS IN1-
2
LVDS IN2+ / TTL IN2
3
LVDS IN2-
4
GND
5
1
2
3
5
5
4
Receptacle viewed from camera back

USER MANUAL ELIIXA+ 16K/8K CXP MONO –REV K–06/2017
PA G E |15
4STANDARD CONFORMITY
The ELIIXA+ cameras have been tested using the following equipment:
A shielded Trigger cable
A 10m CoaXPress Cable for the data transfer, certified at 6Gb/s
e2v recommends using the same configurationto ensure the compliance with the following standards.
4.1 CE Conformity
The ELIIXA+ cameras comply with the requirements of the EMC (European) directive
2004/108/CE (EN50081-2, EN 61000-6-2) (see next page).
4.2 FCC Conformity
The ELIIXA+ cameras further comply with Part 15 of the FCC rules, which states that: Operation is subject to
the following two conditions:
This device may not cause harmful interference,and
This device must accept any interference received, including interference that may cause undesired
operation
This equipment has been tested and found to comply with the limits for Class A digital device, pursuant to
part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful
interferencewhen the equipment is operated in a commercial environment.This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications.Operation of this equipment
in a residential area is likely to cause harmful interference in which case the user will be required to correct
the interferenceat his own expense.
Warning: Changes or modifications to this unit not expressly approved by the party responsible for
compliance could void the user's authority to operate this equipment.
4.3 RoHs Conformity
ELIIXA+ cameras comply with the requirements of the RoHS directive 2011/65/EU.

USER MANUAL ELIIXA+ 16K/8K CXP MONO –REV K–06/2017
PA G E |16
5GETTING STARTED
5.1 Out of the box
The contains of the Camera box is the following :
One Camera ELIIXA+
Trigger connector ( Hirose HR10A-7P-5P-male or compliant)
There is no CDROM delivered with the Camera : This User Manual , and any other
corresponding documents can be dowlaoded on the Web site.
Main Camera page : www.e2v.com/cameras
Select the appropriate Camera Page (ELIIXA+)
5.2 Setting up in the system
The Compliant Lenses and their accessories are detailed in Appendix E
FOV
Focal Plan
Sensor Plan
f
L
w
s
w
f
FOV
L
=

USER MANUAL ELIIXA+ 16K/8K CXP MONO –REV K–06/2017
PA G E |17
6CAMERA SOFTWARE INTERFACE
The ELIIXA+ CoaxPress Camera is compliant with GenICam 2.1 and the SFNC 1.5 standards.
This means that the Camera embeds its own definition and parameter description in an xml file.
Most of these Parameters are compliant with the SNFC. The specific parameters (non SNFC) are still
compliant with GenICam and can be detailed through the GenICam API process to the application.
The Frame Grabber software is supposed to propose a feature Brother, based on GenICam, which lists and
allows the modification of the parameters of the Camera.
This feature brother based on GenICam API uploads the xml file of the parameters description embedded in
the Camera.
Then the following description of the parameters and commands is based on the GenICam name of these
parameters. Behind each parameter is a register address in the Camera memory.
The mapping of these registers is not given in this manual because it can change from one version or the
firmware to the next one.

USER MANUAL ELIIXA+ 16K/8K CXP MONO –REV K–06/2017
PA G E |18
7Camera Commands
7.1 Device Control
These are Identification values of the Camera. They can be accessed in the “Device Control” section
Feature
CXP @
Size
in
bytes
R/W
Description
DeviceVendorName
0x02000
Boostrap
32
RO
Get camera vendor name as a string (including ‘\0’)
DeviceModelName
0x02020
Boostrap
32
RO
Get camera model name as a string (including ‘\0’)
DeviceManufacturerInfo
0x02040
Boostrap
48
RO
Get camera ID as a string (including ‘\0’)
DeviceVersion
0x02070
Boostrap
32
RO
Get camera version as a string (hardware version)
(including ‘\0’)
DeviceFirmwareVersion
0x02090
Boostrap
32
RO
Get camera synthetic firmware version (PKG version)
as a string (including ‘\0’)
DeviceSFNCVersionMajor
Xml
RO
DeviceSFNCVersionMinor
Xml
RO
DeviceSFNCVersionSubMinor
Xml
RO
DeviceID
0x020B0
Boostrap
16
RO
Read Serial Nb
DeviceUserID
0x020C0
Boostrap
16
RW
Get device user identifier as a string (including '\0')
ElectronicBoardID
0x08000
32
RO
Read Electronic Board ID
ElectronicBoardTestStatus
0x08020
16
RO
Read Electronic board status
DeviceFirmwareVersion
0x02090
Boostrap
32
RO
Get camera synthetic firmware version (PKG version)
as a string (including ‘\0’)
DeviceTemperature
0x08E04
4
RO
Read Main board internal temperature (format signed
Q10.2 = signed 8 bits, plus 2 bits below comma. Value
from -512 to +511) in °C
DeviceTemperatureSelector
Xml
RO
Device Temperature selector
Standby
0x08E08
4
RW
0 :Disable standby mode (“False”)
1 :Enable standby mode (“True”), no more video available
but save power and temperature
STATUS REGISTER
0x08E0C
4
RO
StatusWaitForTrigger
Bit 0: true if camera waits for a trigger during more than
1s
Status trigger too fast
Bit 1: true if camera trigger is too fast
StatusSensorConnexion
Bit 2: true if sensor pattern checking has failed
Status3V7
Bit 3: true if 3V7 failure
Status3V3
Bit 4: true if 3V3 failure
Status1V0
Bit 5: true if 1V0 failure
Status1V8
Bit 6: true if 1V8 failure
Status1V8ANA
Bit 7: true if 1V8ANA failure
StatusWarningOverflow
Bit 8: true if a an overflow occurs during FFC calibration

USER MANUAL ELIIXA+ 16K/8K CXP MONO –REV K–06/2017
PA G E |19
A standby mode, what for ?
The Standby mode stops all activity on
the sensor level. The power dissipation
drops down to about 6W. During the
standby mode, the grab is stopped
Once the Standby mode turned off, the
Camera recovers in less than 1ms to
send images again from the sensor.
or Tap balance (available only for integrator/user mode)
StatusWarningUnderflow
Bit 9: true if a an underflow occurs during FFC calibration
or Tap balance (available only for integrator/user mode)
Status2V5
Bit 10: true if 2V5 failure
CC3 Scrolling direction
Bit 11: 0 : forward, 1: reverse
StatusErrorHardware
Bit 16 : true if hardware error detected
Internal Temperature
25
30
35
40
45
50
55
60
65
70
75
0
5
7
10
20
30
40
50
60
70
80
90
100
110
120
130
140
Time (mn)
°C
Standby Off
Standby On

USER MANUAL ELIIXA+ 16K/8K CXP MONO –REV K–06/2017
PA G E |20
7.2 Image Format
Feature
CXP @
Size
in
bytes
R/W
Description
Width
0x07000
4
RO
Mapped on SensorWidth : 16384 or 8192 in binning
mode
Height
0x07004
4
RO
AcquisitionMode
0x07008
RW
1: Continuous
AcquisitionStart
0x0700C
WO
0: Start the acquisition
AcquisitionStop
0x07010
WO
0: Stop the acquisition
PixelFormat
0x07014
4
RW
0x0101: Mono8
0x0102: Mono10
0x0103: Mono12
PixelCoding
NA
-
RO
Mono
PixelSize
NA
-
RO
Bpp8, Bpp10 or Bpp12 depending on PixelFormat
PixelColorFilter
NA
-
RO
None
PixelDynamicRangeMin
NA
-
RO
0
PixelDynamicRangeMin
NA
-
RO
255, 1023 or 4095 depending on PixelFormat
SensorWidth
0x08200
4
RO
Get sensor physical width.
SensorHeight
Xml
RO
WidthMax
-
RO
Mapped on SensorWidth : 16384 or 8192 in binning
mode
HeightMax
Xml
RO
SensorMode
0x08204
4
RW
0: Set sensor mode to DualLine “1S”
1: sensor mode to MultiLine “2S”
2: Set sensor mode to QuadriLine “4S”
3: Set sensor mode to Binning MonoLine “1SB”
4: Set sensor mode to Binning DualLine “2SB”
5: Set in HDR Mode
MultiLineGain
0x08208
4
RW
0: Set MultiLine gain to “x1”
1: Set MultiLine gain to “x1/2” : not available if
SensorMode = 0 (“1S” mode)
ReverseReading
0x08210
4
RW
0: Set reverse reading to “disable”
1: Set reverse reading to “enable”
TestImageSelector
0x08214
4
RW
0:Set test (output FPGA) image pattern to “Off”,
processing chain activated
1: Set test (output FPGA) image pattern to
“GreyHorizontalRamp”, processing chain disabled
2: Set test (output FPGA) image pattern to “White
pattern”, processing chain disabled
3: Set test (output FPGA) image pattern to “gray pattern”,
processing chain disabled
4: Set test (output FPGA) image pattern to “Black
pattern”, processing chain disabled
5: Set test (output FPGA) image pattern to
“GreyVerticalRampMoving”, processing chain disabled
InputSource
0x08218
4
RW
0: Set signal source to CMOS sensor, processing chain
activated
HDRMode
0x08234
4
RW
Set The Output in HDR Mode (when SensorMode = HDR)
Only available on “BH0” Models
0: Bottom Line Only
1: Top Line Only
2: HDR Line (Top + Bottom Combined)
HDR Ratio
0x08238
4
RW
Set The Output in HDR Ratio (when SensorMode = HDR)
Only available on “BH0” Models
