ECO Spot LED40DE User manual

ECO Spot LED40DE User Manual
The ECO Spot LED40DE is intended for exterior applications but
is also suitable for interior use. Thank you for choosing an ECO
Spot™ Gobo projector. This unit is equipped with a fan cooled heat
pipe to keep the 40W High Power LED running cool. It is also
available as interior version (ES-LED40D).
Please read this manual before installing or operating this fixture,
follow the safety precautions listed below and observe all warnings.
WARNING!
To prevent damage to the LED, always connect the driver
cable to the projector FIRST before plugging it into the
power outlet.
Package Contents

Projector, External LED Driver, Test Gobo, Spare gobo retaining ring and spare drive
belt, Gobo adapter ring for E-Size Gobos
Safety Information
ECO Spot™ LED40DE User Manual
•Place your fixture at a suitable place with good air flow.
•Keep flammable materials away from the fixture.
•Minimum distance to flammable material = 1 ft (0.3m).
•Minimum distance to illuminated surface = 3.3 ft (1.0m).
•Provide a minimum clearance of 4 in (10cm) around air vents.
•Use only genuine spare parts for part replacement.
•Do not look directly into the lamp; it can cause eye damage.
•Always unplug the unit from the power mains before any service is done.
•Light fixtures should be installed and maintained only by qualified personnel with
experience in lighting equipment and general electrical experience.
•Disconnect the fixture from AC power before handling the fixture.
•Always ground (earth) the fixture electrically.
•Use only a power source
that complies with local building and electrical codes and
has both, overload and ground-fault protection.
•Do not use the fixture if the power cable or power plug is in any way damaged,
defective or wet, or if they show signs of overheating.
Copyright © 2014 Globus New Media LLC Page 1

ECO Spot LED40DE User Manual
Handling Instructions
Warranty
One Year from Date of Purchase. Keep your receipt for reference and contact your dealer
in case of warranty issues.
Projection Lenses
The projector accommodates interchangeable projection lenses to allow optimizing the
projection size and resulting brightness at varying distances. The more narrow the lens,
the smaller and brighter the image will be at a given distance. For example, cutting the
projection size in half, will quadruple its brightness.
Gobo Rotator
If the fixture is equipped with a gobo rotator, it can be turned on/off with the silver push-
button on the front plate underneath the lens. There are no controls for rotating speed or
direction.
Focusing
•There is a weatherproof connector between the driver (power supply) and
projector, which can be opened for easier handling. Always make this
connection first before powering up the driver, otherwise the LED can be
damaged by the power surge.
•Before the initial start-up, please unpack and carefully check for damage caused
during transportation.
•Place your fixture at a suitable place with good air flow.
•Make sure there are no flammable materials close to the lamp.
•When suspending the fixture above ground level, verify that the structure
can hold
at least 10 times the weight of all installed devices.
•Verify that all external covers and rigging hardware are securely fastened and use
an approved means of secondary attachment such as a safety cable.
•Power up the projector.
•If the fixture is equipped with a gobo rotator, turn it on, once the gobo projects in
the desired position, turn it off.
•Loosen the outer ring around the lens that acts as a water seal.
•Focus the projection by twisting the lens in and out until
the image is well focused.
When used for the first time, the lens will often need to be twisted outwards many
rotations to reach the focusing point. When in doubt, keep going.
•Re-tighten the outer ring to ensure a tight seal of the lens.
Page 2 Copyright © 2014 Globus New Media LLC

ECO Spot LED40DE User Manual
Multi-functional Yoke
Gobo Placement (see Specifications for Gobo Dimensions)
The ES-LED40DE uses D-Size gobos or E-Size gobos with an adapter ring. See the
Specifications for exact dimensions. For max. image size and brightness use D-Size gobos.
The recommended gobo image diameter is 35mm. An Image Diameter of up to 40mm is
possible with some loss in focusing quality for optimal focus, stay within 32mm image
size.
•The yoke can slide over the whole length of the fixture body to accommodate a
wide range of pointing directions.
•The yoke can also serve as stand.
•The yoke can be screwed to a wall or ceiling or fastened with a C-clamp
•Unscrew the thumbscrews to remove the front cover with the projection lens.
•Push the two pins of the gobo retaining ring together and pull out the retaining
ring. Carefully remove the old gobo and replace it with the new gobo.
•Tip: Tilt the projector forward while placing the palm of your hand inside, the old
gobo will fall into your hand.
•If you have a glass gobo, place the more reflective side towards the light bulb.
•Replace the retaining ring and make sure it evenly pushes the gobo all the way
back.
•Replace the front cover and adjust the focus by threading
the projection lens in or
out.
Copyright © 2014 Globus New Media LLC Page 3

ECO Spot LED40DE User Manual
Line Voltage
100-240V, 50/60Hz, 0.6A, 48W
Ambient Operating Temperature
-13 to 104°F (-25 to 40°C)
Dimensions / Weight
Body without yoke:
10.5 x 6 x 3.75in (L x W x H)
(267 x 153 x 95mm)
The projection lens adds 0.5 to 2in (12 to
50mm) to the length.
Height with yoke: 7.75in (197mm)
Weight 7lbs (3kg)
Gobo Dimensions D-Size
Metal or Glass Gobos and Dichroic filters
The projector takes D-Size gobos:
Outer Diameter (OD): 53mm
Image Diameter (ID): 35mm (max 40mm)
Max Thickness: 4mm
Larger ID up to 40mm is possible with
some loss in focusing quality, for optimal
focus stay within 32mm image size. An
adapter for the smaller E-Size gobos is
included.
LED Lamp
Lens Options
The projector can be equipped with
standard projection lenses of the ECO
Spot line. These lenses are marked based
on a gobo image size of 25mm. With the
larger gobo image size, a given lens
produces a larger image than the lens
specification, see the effective lens angles
in () below. The more narrow the lens, the
smaller and brighter the image will be at
a given distance. Currently these lenses
are available:
IP Ratings
•Extremely high light density for
ultra-efficient projection.
•Power: 40W
•Bulb life 50,000h
•Color Temperature 5,500k, +/-
500k
•Rated Luminous flux: 2,000lm
•Effective luminous flux: 1,500lm
•Wide 25º (effective 35º)
•Medium 20º (eff. 28º)
•Medium Narrow 15º (eff. 21º)
•Narrow 10º (eff. 14º)
•LED Driver: IP65
•Fixture: equivalent to IP62
Page 4 Copyright © 2014 Globus New Media LLC
