EDIC-mini Tiny A31 User manual

1
Short Operating Instruction
for EDIC-mini Tiny A31
300h/600h/1200h
The EDIC-mini Tiny A31 digital recorder is a pro-
fessional device that provides high quality voice
recording on to built-in ash memory. The recorder
can be used for audio recording and as a ash
drive for saving les of any formats.
The recorder has:
- USB interface allows high-speed data
exchange (up to 0,7 Mb/sec.)
- Voice activation system, which allows to
compress pauses while recording
- Built-in real time clock
- Timers, which allow to record automatically
at the preset time Information protection
system.
Supplied software provides:
-To save recorded messages on a computer’s
hard drive as standard audio les
- To restore compressed pauses, when
saving recordings on a computer’s hard
drive

2
- To set the recorder’s parameters
- To administrate the recorder’s operating
- To update the recorder’s software.
Appearance
Record button
USB connector
Reset button
LED
Microphone

3
Technical Characteristics
- Recording time with fully-charged
rechargeable battery – up to 25 hours;
- Digits in the models’ names show the built-
in ash memory capacity (A31-300h/600h/
1200h):
- 300h – 17920 min (2Gb);
- 600h – 35840 min (4Gb);
- 1200h – 71680 min (8Gb).
(2 bit ADPCM, sampling rate 8 kHz);
- Data exchange speed: 0.7 Mb/sec
- Temperature range: 0-40°C;
- Bandwidth while recording:
100-10,000 Hz;
- Sound/noise ratio: -72 Db;
- Built-in microphone operating distance:
7-9 m;
- Flash memory’s shelf life: not less than 10
years;
- Period of time needed to charge
rechargeable battery: 3 hours;
- Rechargeable battery: 75 mA/h, Li-Pol;
- Dimensions: 29x15x12mm;
- Weight: not more than 6,5 gram.

4
Functional test
Trial record. Press the Record button and keep it
pressed for about two seconds. The recorder’s
LED will ash 5 times. To stop recording, keep
the Rec button pressed for 2 seconds. When
the recorder stops recording, the LED will ash
once. The duration of the ashes can be different
depending on the recorder’s memory size. When
recording, the sequences of LED ashes show the
level of charge of the battery and memory capacity
(you can nd a more detailed description in the
Operating Instruction).
You can listen to the recording only after uploading
the recordings to the computer’s hard drive by
means of the program RecManager (you will nd
it on the applied software CD).
Charging the Recorder
Connect the recorder to a computer USB port
using the shipped USB cable. The recorder will
start charging automatically. While charging, the
recorder’s LED ashes gradually with a 5 seconds
interval. After the rechargeable battery is fully
charged, the LED will ash continuously.

5
Box Contents
- Voice recorder
- USB cable
- Software CD or Flash drive
- Instructions
- Warranty Coupon
Additional Accessories
- External microphone with compressor
*The full version of the Operating Instruction is in
the build-in memory of the recorder. You can also
nd it at our website www.ts-market.com

6

7
Designed and manufactured by the
Telesystems Ltd.
The Manufactory Warranty Coupon
Warranty: The Telesystems Company provides
warranty repair for 1 year from the selling date,
but not more than 2 years from the manufacturing
date.
This warranty is voided if the recorder is:
- improperly used
- mechanically damaged
- received without supplier warranty tag on
this document
All questions regarding product exchange and
return must be solved with the seller’s company
according to Protection of Consumers Law.

Edic-mini Pro model A31
□EM Pro A31 - 300 h
□EM Pro A31 - 600 h
□EM Pro A31 - 1200 h
Number __________________________________
QC______________________________________
Selling date _____________________________
Seller ________________________________
