Ehx Ei nano 22 caliber User manual

- FCC COMPLIANCE -

This device complies with part 15 of the FCC Rules. Operation is subject to the

following two conditions: (1) This device may not cause harmful interference,

and (2) this device must accept any interference received, including interference

that may cause undesired operation. If the device is not installed and used in

accordance with the instructions, it may cause harmful interference to radio

communications and void the user's authority to guarantee the equipment.

Note:

This equipment has been tested and found to comply with the limits for a

Class B digital device, pursuant to part 15 of the FCC Rules. These limits are

designed to provide reasonable protection against harmful interference in a

residential installation. This equipment generates, uses and can radiate radio

frequency energy and, if not installed and used in accordance with the

instructions, may cause harmful interference to radio communications. However,

there is no guarantee that interference will not occur in a particular installation.

If this equipment does cause harmful interference to radio or television

reception, which can be determined by turning the equipment off and on, the

user is encouraged to try to correct the interference by one or more of the

following measures:

•

Reorient or relocate the receiving antenna.

•

Increase the separation between the equipment and receiver.

•

Connect the equipment into an outlet on a circuit different from that to

which the receiver is connected.

•

Consult the dealer or an experienced radio/TV technician for help.

Modifications not expressly approved by the manufacturer could void the user's

authority to operate the equipment under FCC rules.

22 CALIBER

Guitar Power Amplifier

Congratulations on your purchase of the

22 CALIBER

guitar amplifier!

The 22 CALIBER is a 22 Watt

power amplifier for guitar that fits in the palm of your hand. Its excellent tone and extreme portability will

guarantee it to become a mainstay for performance, rehearsal or recording. The 22 CALIBER delivers

everything that you would expect in a much larger amplifier. Though the 22 CALIBER’s input and gain

structure was optimized for guitar it will work great with other instruments as well. Please read this manual

to become familiar with the correct use of the 22 CALIBER.

-CONTROLS and JACKS-

VOLUME Knob

–Controls the volume or loudness of the amplifier. As you turn the VOLUME knob

clockwise, the 22 CALIBER’s output gets louder. At a certain point in the VOLUME knob’s travel the output

will start to overdrive, at this point you are beginning to exceed 22 Watts on your loudest notes. Turning

the VOLUME knob further clockwise will produce a more overdriven sound which is the result of pure

power amp saturation.

BRIGHT Switch

When engaged the BRIGHT switch adds a subtle high end boost or presence to your

output signal. When in the normal position it is defeated yielding a signal that passes from input to output

uncolored.

WARNING: USE ONLY THE 18 VDC / 1.66A ADAPTER THAT THE 22

CALIBER COMES SUPPLIED WITH. Do not use any other adapters. Using

other adapters, even those made by Electro-Harmonix, could cause harm

to the unit, the adapter or you. The 22 CALIBER does not use batteries.

WARNING:

THE 22 CALIBER IS A POWER AMP, NOT AN EFFECTS PEDAL.

Do not

connect the output of the 22 CALIBER to the input of another AMPLIFIER, EFFECTS

PEDAL, MIXER, COMPUTER, COMPUTER INTERFACE or other similar device.

Connect the output of the 22 CALIBER to a speaker cabinet only.

INPUT Jack

Plug the output of your guitar, effects pedals or any other instrument into the INPUT jack

using a standard ¼” instrument cable. The input impedance presented at the INPUT jack is 2 M



4 –16



OUTPUT Jack

–

Connect the 22 CALIBER’s OUTPUT jack directly to a speaker cabinet.

WARNING:

NEVER CONNECT THE OUTPUT OF THE 22 CALIBER TO THE INPUT OF ANOTHER

AMPLIFIER, AN EFFECTS PEDAL, MIXER, COMPUTER, COMPUTER INTERFACE OR OTHER SIMILAR

DEVICE.

We recommend using a

speaker cable

between the 22 CALIBER and speaker cabinet as you would with

any power amplifier, though you can get away with using an instrument cable if absolutely necessary. The

impedance of the speaker cabinet must be rated between 4



and 16



(



= ohms). 8



is the ideal load

for the 22 CALIBER though it will work into loads ranging from 4



to 16



. Additionally the speaker

cabinet must have a power rating equal to or greater than the 22 CALIBER’s output power capability. We

recommend a speaker cabinet with a 30 W rating.

WARNING:

Make sure the 22 CALIBER’s output is connected to a speaker cabinet before applying power.

18VDC/1.5A POWER Jack –

Connect the output plug from the 22 CALIBER’s supplied power supply

to the power jack at the top of the unit. Only use the power supply that the 22 CALIBER was supplied with.

The 22 CALIBER requires a power supply capable of delivering at least 1.5 A (more current is better) at

exactly 18 VDC. DO NOT EXCEED 18 VDC ON THE POWER JACK, doing so will damage the 22 CALIBER.

DO NOT CONNECT AN AC POWER SUPPLY VOLTAGE TO THE 22 CALIBER, USE DC POWER ONLY. The

polarity of the power jack is center positive.

-WARNINGS (PLEASE READ!!)-

THE 22 CALIBER IS A POWER AMP, NOT AN EFFECTS PEDAL:

Connect the output of the 22

CALIBER to a speaker cabinet only. DO NOT CONNECT THE OUTPUT OF THE 22 CALIBER TO THE INPUT

OF ANOTHER AMPLIFIER, EFFECTS PEDAL, MIXER, COMPUTER, COMPUTER INTERFACE or similar device.

SPEAKER CABINET:

Only plug the output of the 22 CALIBER into a speaker cabinet rated for an

impedance in the range of 4



to 16



(4 to 16 ohms).

OUTPUT FIRST THEN POWER:

Connect the output of the 22 CALIBER to a proper speaker cabinet

before applying power to the 22 CALIBER. If you connect the 22 CALIBER to a speaker cabinet while it is

powered up, the 22 CALIBER may automatically mute its output to prevent a short circuit on the output

jack. In this situation simply remove power from the 22 CALIBER, wait a few seconds and then re-apply

power to the 22 CALIBER, it should work normally.

- WARRANTY INFORMATION -

Please register online at http://www.ehx.com/product-registration or complete and return the

enclosed warranty card within 10 days of purchase. Electro-Harmonix will repair or replace, at

its discretion, a product that fails to operate due to defects in materials or workmanship for a

period of one year from date of purchase. This applies only to original purchasers who have

bought their product from an authorized Electro-Harmonix retailer. Repaired or replaced units

will then be warranted for the unexpired portion of the original warranty term.

If you should need to return your unit for service within the warranty period, please contact the

appropriate office listed below. Customers outside the regions listed below, please contact EHX

Customer Service for information on warranty repairs at info@ehx.com or +1-718-937-8300.

USA and Canadian customers: please obtain a Return Authorization Number (RA#) from

EHX Customer Service before returning your product. Include with your returned unit: a written

description of the problem as well as your name, address, telephone number, e-mail address,

and RA#; and a copy of your receipt clearly showing the purchase date.

United States & Canada

EHX CUSTOMER SERVICE

ELECTRO-HARMONIX

c/o NEW SENSOR CORP.

47-50 33rd Street

LONG ISLAND CITY, NY 11101

Tel: 718-937-8300

Email: info@ehx.com

Europe

JOHN WILLIAMS

ELECTRO-HARMONIX UK

13 CWMDONKIN TERRACE

SWANSEA SA2 0RQ

UNITED KINGDOM

Tel: +44 179 247 3258

Email: electroharmonixuk@virginmedia.com

This warranty gives a purchaser specific legal rights. A purchaser may have even greater rights

depending upon the laws of the jurisdiction within which the product was purchased.
