EHX Nano 44 Magnum User manual

FCC COMPLIANCE
Note: This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to part 15 of the CC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Modifications not expressly approved by the manufacturer could void the
user's authority to operate the equipment under CC rules.
44 MAGNUM
Guitar Power Amplifier
Congratulations on your purchase of the 44 MAGNUM guitar amplifier! The
44 MAGNUM produces a powerful 44 watts and is small enough to fit in the
palm of your hand. Despite this amp’s small size, at 44 watts the 44
MAGNUM will have no problems being heard at the gig. The 44 MAGNUM’s
sweet sound and extreme portability guarantee it to be an integral part of
your rig for rehearsal, recording, or playing out. The 44 MAGNUM was
designed with the guitar in mind and can be used alone, or with your
favorite preamp driving the input to the 44 MAGNUM. The 44 MAGNUM also
sounds great with other instruments such as bass and keyboard. Please read
this manual to become familiar with the correct use of the 44 MAGNUM.
-CONTROLS a d JACKS-
VOLUME CONTROL – This knob controls the volume or loudness of the
amplifier. As you turn the VOLUME knob clockwise, the 44 MAGNUM’s output
gets louder. At a certain point in the VOLUME knob’s travel the output will
start to overdrive, at this point you are beginning to exceed 44 Watts on
your loudest notes. Turning the VOLUME knob further clockwise will produce
a more overdriven sound which is the result of pure power amp saturation.
BRIGHT/NORM CONTROL- When engaged, the BRIGHT switch adds a
subtle top boost or presence to your signal. When in the NORM position, the
top boost is defeated.
INPUT Jack- Plug the output of your guitar, effects pedals or any other
instrument into the INPUT jack using a standard ¼” instrument cable. The
input impedance presented at the INPUT jack is 2 MΩ.
WARNING: USE ONLY THE 24 VDC / 3A ADAPTER THAT THE 44 MAGNUM
COMES SUPPLIED WITH. Do not us any oth r adapt rs. Using oth r
adapt rs, v n thos mad by El ctro-Harmonix, could caus harm to th
unit, th adapt r or you. Th 44 MAGNUM do s not us batt ri s.
WARNING: THE 44 MAGNUM IS A POWER AMP, NOT AN EFFECTS PEDAL. DO NOT
co ect the output of the 44 MAGNUM to the i put of a other amplifier, effects
pedal, mixer, computer, computer i terface or other similar device. Co ect the
output of the 44 MAGNUM to a 8 -16
Ω
speaker cabi et ONLY.

8 – 16 Ω OUTPUT Jack – Connect the 44 MAGNUM’s OUTPUT jack directly
to a speaker cabinet. 8 Ω - 16 Ω only.
WARNING: NEVER CONNECT THE OUTPUT O THE 44 MAGNUM TO THE
INPUT O ANOTHER AMPLI IER, AN E ECTS PEDAL, MIXER, COMPUTER,
COMPUTER INTER ACE OR OTHER SIMILAR DEVICE.
We recommend using a speaker cable between the 44 MAGNUM and speaker
cabinet as you would with any power amplifier, though you can get away
with using an instrument cable if absolutely necessary. The impedance of the
speaker cabinet must be rated between 8 Ω and 16 Ω (Ω = ohms). 8 Ω is
the ideal load for the 44 MAGNUM. Additionally the speaker cabinet must
have a power rating equal to or greater than the 44 MAGNUM’s output
power capability. We recommend a speaker cabinet with at least a 50W peak
rating (or 25W RMS).
WARNING: Make sure the 44 MAGNUM’s output is connected to a speaker
cabinet before applying power.
24VDC/3A POWER Jack – Connect the output plug from the 44
MAGNUM’s supplied power supply to the power jack at the top of the unit.
Only use the power supply that the 44 MAGNUM was supplied with. The 44
MAGNUM requires a power supply capable of delivering at least 2A (more
available current is better) at exactly 24 VDC. DO NOT EXCEED 24 VDC ON
THE POWER JACK, doing so will damage the 44 MAGNUM. DO NOT
CONNECT AN AC POWER SUPPLY VOLTAGE TO THE 44 MAGNUM, USE DC
POWER ONLY. The polarity of the power jack is center positive.
-WARNINGS (PLEASE READ!!!)-
THE 44 MAGNUM IS A POWER AMP, NOT AN EFFECTS PEDAL:
Connect the output of the 44 MAGNUM to a speaker cabinet only. DO NOT
CONNECT THE OUTPUT O THE 44 MAGNUM TO THE INPUT O ANOTHER
AMPLI IER, E ECTS PEDAL, MIXER, COMPUTER, COMPUTER INTER ACE or
similar device.
SPEAKER CABINET: Only plug the output of the 44 MAGNUM into a
speaker cabinet rated for an impedance in the range of 8 Ω to 16 Ω (8 to 16
ohms); the speaker cabinet power rating should be 50W peak rating (or 25W
RMS).
OUTPUT FIRST THEN POWER: Connect the output of the 44 MAGNUM to
a proper speaker cabinet before applying power to the 44 MAGNUM. If you
connect the 44 MAGNUM to a speaker cabinet while it is powered up, the 44
MAGNUM may automatically mute its output to prevent a short circuit on the
output jack. In this situation simply remove power from the 44 MAGNUM,
wait a few seconds and then re-apply power to the 44 MAGNUM, it should
work normally.
- WARRANTY INFORMATION -
Please register online at http://www.ehx.com/product-registration or
complete and return the enclosed warranty card within 10 days of purchase.
Electro-Harmonix will repair or replace, at its discretion, a product that fails
to operate due to defects in materials or workmanship for a period of one
year from date of purchase. This applies only to original purchasers who
have bought their product from an authorized Electro-Harmonix retailer.
Repaired or replaced units will then be warranted for the unexpired portion
of the original warranty term.
If you should need to return your unit for service within the warranty period,
please contact the appropriate office listed below. Customers outside the
regions listed below, please contact EHX Customer Service for information on
warranty repairs at [email protected] or [phone]. USA and Canadian
customers: please obtain a Retur Authorizatio Number (RA#) from
EHX Customer Service before returning your product. Include with your
returned unit: a written description of the problem as well as your name,
address, telephone number, e-mail address, and RA#; and a y of your
receipt clearly showing the purchase date.
U ited States & Ca ada
EHX CUSTOMER SERVICE
ELECTRO-HARMONIX
c/o NEW SENSOR CORP.
55-01 2ND STREET
LONG ISLAND CITY, NY 11101
Tel: [phone]
Email: [e-mail]
Europe
JOHN WILLIAMS
ELECTRO-HARMONIX UK
13 CWMDONKIN TERRACE
SWANSEA SA2 0RQ
UNITED KINGDOM
Tel: [phone]
Email: [e-mail]
This warranty gives a purchaser specific legal rights. A purchaser may have
even greater rights depending upon the laws of the jurisdiction within which
the product was purchased.
To hear demos on all EHX pedals visit us on the web at www.ehx.com
Email us at i [email protected]m
