Ekopower EkoHeat Series User manual

INSTALLATION AND OPERATING INSTRUCTIONS
EKOHEAT

Thank you for choosing a EKOPOWER heating boiler. You have
chosen from a range of EKOPOWER products designed to provide
efficient and sustainable heating for the ideal level of comfort for your
home.
This manual forms an essential part of the product and it must be
given to the end user. We recommend you read the warnings and
recommendations in the manual carefully, as they contain important
information on the safety, use and maintenance of the installation.
These boilers must be installed by qualified personnel only, in
accordance with the local legislation and following the manufacturer’s
instructions.
Start-up of these boilers and any maintenance operations must only
be carried out by EKOPOWER’s Authorised Technical Assistance
Services.
Incorrect installation of these boilers could result in damage to
people, animals or property, and the manufacturer will hold no liability
in such cases.

EKOHEAT
1
CONTENTS Page
1 LIST OF COMPONENTS.................................................................................................................................................................2
2 CONTROL COMPONENTS.............................................................................................................................................................3
3 INSTALLATION INSTRUCTIONS....................................................................................................................................................4
3.1 LOCATION.......................................................................................................................................................................................4
3.2 HYDRAULIC INSTALLATION ...............................................................................................................................................................4
3.3 INSTALLING A SANIT HOT WATER TANK (OPTIONAL)...........................................................................................................................5
3.4 FUEL ..............................................................................................................................................................................................5
3.5 INSTALLING THE RESERVE TANK.......................................................................................................................................................6
3.6 ELECTRICAL CONNECTION...............................................................................................................................................................7
3.7 COMBUSTION PRODUCT REMOVAL....................................................................................................................................................7
3.8 EXAMPLE OF A RADIATOR HEATING INSTALLATION .............................................................................................................................8
3.9 EXAMPLE OF A HEATING INSTALLATION WITH RADIATORS AND A DHW STORAGE TANK........................................................................9
3.10 EXAMPLE OF A ZONED HEATING INSTALLATION..............................................................................................................................10
3.11 EXAMPLE OF AN INSTALLATION WITH A BUFFER TANK FOR 2UNDERFLOOR HEATING CIRCUITS AND A DHW TANK..............................10
3.12 EXAMPLE OF INSTALLATION WITH THE MS HYDRAULIC KIT.............................................................................................................12
3.13 EXAMPLE OF INSTALLATION WITH THE DMS HYDRAULIC KIT..........................................................................................................13
3.14 EXAMPLE OF A HEATING INSTALLATION WITH RADIATORS AND BACK-UP FOR A SOLAR INSTALLATION FOR DHW PRODUCTION. ..........14
4 EXTERNAL CIRCULATION KIT.....................................................................................................................................................16
4.1 LIST OF COMPONENTS...................................................................................................................................................................16
4.2 ELECTRICAL CONNECTION FOR THE CIRCULATING PUMP..................................................................................................................16
4.3 HYDRAULIC INSTALLATION OF THE EXTERNAL CIRCULATION KIT........................................................................................................17
5 STARTING UP THE BOILER.........................................................................................................................................................19
5.1 PRIOR WARNINGS..........................................................................................................................................................................19
5.2 FILLING THE INSTALLATION ............................................................................................................................................................19
5.3 ELECTRICAL CONNECTION.............................................................................................................................................................19
5.4 START-UP.....................................................................................................................................................................................19
5.5 INSTALLATION DELIVERY................................................................................................................................................................19
6 DIGITAL DISPLAY:........................................................................................................................................................................20
7 OPERATION..................................................................................................................................................................................21
7.1 SELECTING THE BOILER SETPOINT TEMPERATURE...........................................................................................................................21
7.2 SELECTING THE DHW SETPOINT TEMPERATURE (WITH HOT WATER TANK ONLY)..............................................................................21
7.3 CHANGING THE OPERATING SETTINGS............................................................................................................................................22
8 "INFO" DISPLAY............................................................................................................................................................................22
9 CONFIGURATION MENU..............................................................................................................................................................23
9.1 CLEANING SETTINGS .....................................................................................................................................................................23
9.2 TIME PROGRAMMER ......................................................................................................................................................................24
9.3 FEED AUGER CALIBRATION ............................................................................................................................................................25
9.4 BURNER LUBRICATION...................................................................................................................................................................27
9.5 LANGUAGE/IDIOMA/LANGUE...........................................................................................................................................................27
9.6 DATE AND TIME .............................................................................................................................................................................27
10 SERVICE MENU..........................................................................................................................................................................28
10.1 FUEL (0.1-7.0 KG.)......................................................................................................................................................................29
10.2 FUEL FOR IGNITION (0-200 GR.)...................................................................................................................................................29
10.3 BURNER CLEANING DEVICE MOVEMENT (38-42 SEC.) ....................................................................................................................29
10.4 FAN FUNCTIONING.......................................................................................................................................................................31
10.5 MINIMUM POWER (%) ..................................................................................................................................................................31
10.6 MAXIMUM POWER (%) .................................................................................................................................................................31
10.7 DHW CIRCUIT.............................................................................................................................................................................31
10.8 MINIMUM PUMP TEMPERATURE (0-60ºC) ......................................................................................................................................32
10.9 MANUAL ASH CLEANING...............................................................................................................................................................32
10.10 MODEL SELECTION....................................................................................................................................................................32
10.11 AUTO-TEST...............................................................................................................................................................................32
10.12 RESET DEFAULT CONFIGURATION...............................................................................................................................................32
10.13 NEW SOFTWARE........................................................................................................................................................................32
11 CLEANING THE ASH DRAWER..................................................................................................................................................33
12 SAFETY CUT-OUTS....................................................................................................................................................................34
12.1 BURNER CUT-OUT .......................................................................................................................................................................34
12.2 NO FLAME CUT-OUT.....................................................................................................................................................................34
12.3 TEMPERATURE SAFETY CUT-OUT .................................................................................................................................................34
13 SHUTTING DOWN THE BOILER ................................................................................................................................................34
14 BOILER MAINTENANCE.............................................................................................................................................................35
14.1 BOILER AND FLUE MAINTENANCE FREQUENCIES............................................................................................................................35
14.2 CLEANING THE BURNER...............................................................................................................................................................36
14.3 LUBRICATING THE BURNER CLEANING DEVICE...............................................................................................................................37
14.4 DRAINING THE CONDENSATION WATER.........................................................................................................................................38
14.5 BOILER WATER CHARACTERISTICS ...............................................................................................................................................38
14.6 CLEANING THE VENT. ..................................................................................................................................................................39
15 TECHNICAL CHARACTERISTICS ..............................................................................................................................................40
16 DIAGRAMS AND MEASUREMENTS...........................................................................................................................................41
17 ELECTRICAL DIAGRAM .............................................................................................................................................................44
17.1 BOILER.......................................................................................................................................................................................44
17.2 BURNER .....................................................................................................................................................................................43
18 CIRCULATING PUMP FLOW CURVES.......................................................................................................................................44

2
19 SETTINGS FOR SENSORS ..............................................................................................ERROR! BOOKMARK NOT DEFINED.
20 ALARM CODES...........................................................................................................................................................................45
21 GUARANTEE CONDITIONS........................................................................................................................................................46
LIST OF COMPONENTS
1
3
2
4
5
6
1. Feed auger.
2. Heat exchanger.
3. Vent cleaning device.
4. Fan.
5. Burner.
6. Ash drawer.

EKOHEAT
3
1 CONTROL COMPONENTS
13
11
12
7
8
9
10
7. Boiler temperature selector:
This is used to select the boiler set point
temperature.
8. DHW temperature selector:
This is used to select the desired domestic
hot water set point temperature.
9. Digital display:
This is the boiler functioning display, where
all the operating information, settings and
values appear. This display is also used to
access the appliance’s configuration and
technical settings. The temperatures
detected by the sensors, the flame lux level
and the combustion values can all be viewed
during functioning. If any malfunctioning
should occur, an error description will appear
on the visual display.
10. START touch button:
Touch this symbol to start up or switch off
boiler functioning.
11. INFO touch button:
Touch this symbol to access boiler
information.
12. MENU touch button:
Touch this symbol to access the different
boiler menus.
13. Safety thermostat:
This ensures the boiler temperature does not
exceed 110ºC, by cutting off the electrical
supply.

4
2 INSTALLATION INSTRUCTIONS
The boiler must be installed by personnel authorised by the relevant national authorities, in
compliance with the applicable laws and regulations.
This boiler is suitable for heating water to a temperature below boiling point at atmospheric
pressure. It must be connected to a heating installation and/or a domestic hot water distribution
network, which must always be compatible with its performance and power.
This appliance must only be used for the purpose for which it has been expressly designed. Any
other use is considered unsuitable and therefore hazardous. The manufacturer shall not be
considered liable under any circumstances for damage caused by unsuitable, erroneous or
irrational use.
Remove all the packaging and check the contents are complete. In case of doubt, do not use
the boiler. Contact your supplier. Keep the packaging elements out of reach of children, as they
can be dangerous.
When you no longer wish to use the boiler, disable the parts that could be a potential source of
hazard.
2.1 Location
The boiler must be installed in a sufficiently ventilated site, away from humidity. It must be
located so that the air grilles on the premises are not obstructed and normal boiler
maintenance is possible even if it is placed between items of furniture. One metre of free
space must be left above the boiler for this purpose.
2.2 Hydraulic installation
The hydraulic installation must be made by qualified personnel. The applicable installation
legislation is to be complied with, and the following recommendations should also be taken
into account:
- It is obligatory and essential to install the external circulation kit supplied by
EKOPOWER with the boiler, to prevent any water condensation in the heat exchanger.
To correctly install the boiler, carefully follow the instructions given in the section
“Installing the external circulation kit” . If this requirement is not complied with,
EKOPOWER’s guarantee of the appliance will automatically be null and void.
- The inside of the installation piping should be thoroughly cleaned before switching on the
boiler.
- We recommend inserting cut-off valves between the installation piping and the boiler to
simplify maintenance tasks.
- Leave a free space around the boiler for carrying out any maintenance and repair
operations.
- Drain valves and suitable devices for correctly bleeding the air from the circuit during the
boiler filling stage should be fitted.
- Install all the necessary safety elements (expansion vessel, safety valve, etc.) to comply
with the applicable regulations for the installation.
- If the boiler is installed at a lower height than the heating installation, it is recommendable
to create a siphon at the boiler outlet, to prevent the installation from heating up due to
natural convection when heating is not required.

EKOHEAT
5
2.3 Installing a Sanit hot water tank (Optional)
The procedure for suitably connecting a Sanit DHW tank to the Ekoheat boiler is as follows:
- Unplug the boiler from the mains.
- Connect a DHW temperature sensor (supplied optionally) to the sensor terminal strip J2
(Sa; terminals 10 and 11) (see ”Electrical Diagram" page 44).
- Insert the temperature sensor bulb in the bulb-holder sheath provided on the hot water
tank.
- Connect the 3-way DHW diverter valve to the supply terminal strip J1 (V3V; terminals 3
and 6) (see "Electrical Diagram" page 44).
The hydraulic installation for the 3-way DHW diverter valve should be made so that the
heating circuit can flow through the valve when it is in rest position (not energised):
HEATING
BOILER
D.H.W.
NA/ NO
NC
V3V
For correct hydraulic installation of the hot water tank, carefully follow the assembly and
connection instructions enclosed with the same.
2.4 Fuel
The EkoHeat boiler must be fuelled by EN PLUS certified wood pellet. The EN PLUS certificate
assures that the fuel’s humidity levels and calorific value are ideal for optimum boiler
functioning. If this requirement is not complied with, EKOPOWER’s guarantee of the appliance
will automatically be null and void.
The following points should be taken into account for correct fuel storage:
- The stored pellets should be kept dry all year round.
- The applicable legislation in each country for correct fuel storage must be complied with.

6
2.5 Installing the reserve tank
EKOPOWER supplies a reserve tank for storing the pellets with the boiler. The tank is
reversible and can be mounted on either the left or right side of the boiler. It is also equipped
with adjustable feet for height regulation.
IMPORTANT: Ensure the height of the elliptical holes on the sides of the boiler and on
the reserve tank coincide, for correct insertion of the feed auger. To do
this, make the necessary adjustments for height (using the adjustment
feet) and depth (correctly positioning the reserve tank).

EKOHEAT
7
2.6 Electrical Connection
The EkoHeat boiler is equipped with a 230 V~ 50 Hz mains connection plug. The socket
should have an appropriate earth connection.
The terminal strip J1 includes terminals for connecting the feed auger, the external circulation
kit circulating pump, an ambient thermostat and the 3-way diverter valve for the optional
DHW circuit. The terminal strip J2 includes terminals for connecting a sensor for the optional
DHW circuit. This sensor must be supplied by EKOPOWER.
For correct connection of the burner, the burner connections should be made to terminal
strips J3 and J4 (see "Electrical Diagram" page 44).
IMPORTANT: Before carrying out any work on the boiler’s electrical installation,
always ensure it is disconnected from the mains.
2.7 Combustion product removal
The EkoHeat boiler is a biomass boiler and it is essential for it to be connected to a flue, i.e.
a smoke duct able to create a pressure drop (which in this case should be between 0.15 and
0.20 mbar), in compliance with the applicable laws to this regard.
The combustion product exhaustion ducts must be installed by qualified personnel and must
comply with the regulations in force. For the flue to create a pressure drop, the following
recommendations should be taken into account:
- It should be suitably insulated.
- It should be independently located, with a separate flue for each boiler.
- It should be vertical, avoiding any angles greater than 45º.
- It should always have the same diameter. It is recommendable for it to be circular, and
never any narrower than the boiler outlet.
- It is obligatory to install a fume inspection plate with condensation collection, to
remove the condensation generated in the flue. Otherwise, the condensation may
reach the inside of the boiler and cause irreparable damage, which would not be
covered by EKOPOWER’s guarantee. The condensation pipe should lead to a drain
outlet, as a large amount of water may be generated. This connection must be made in
compliance with the regulations for draining off condensation water to the drain network.
- It is recommended to install a draught stabiliser to prevent any pressure drop
variations in the flue due to atmospheric conditions, which could affect correct boiler
combustion. This draught stabiliser must be installed below the fume inspection
plate to prevent any leakage of combustion gases.

8
2.8 Example of a radiator heating installation
The EkoHeat boiler is equipped with an electronic control that can govern a radiator heating
circuit, with an external circulation kit to prevent condensation in the heat exchanger.
The external circulation kit consists of:
- Circulating pump.
- 55ºC 3-way anti-condensation valve.
- Safety valve, calibrated to 3 bar.
- Boiler blow-off valve.
The figure below shows an example of a hydraulic diagram of a radiator heating installation:
EkoHeat + External Kit
SF:Heating safety valve.
CP:Circulating pump.
RV:Anti-condensation return valve.
EV:Expansion vessel.
DV:Drain valve.
BV:Blow-off valve.
IMPORTANT: Fit drain valves and devices for correctly bleeding the air from the
heating circuit.
IMPORTANT: Before any servicing, disconnect the boiler from the mains.

EKOHEAT
9
2.9 Example of a heating installation with radiators and a DHW storage tank.
The EkoHeat boiler is equipped with an electronic control that can govern a radiator heating
circuit, an external circulation kit to prevent condensation in the heat exchanger and,
optionally, a DHW storage tank loading circuit.
The external hydraulic kit consists of:
- Circulating pump.
- 55ºC 3-way anti-condensation valve.
- Safety valve, calibrated to 3 bar.
- Boiler blow-off valve.
To control a DHW circuit, connect a DHW sensor from the hot water tank to the boiler
(optionally supplied by EKOPOWER) and a 3-way diverter valve (see "Electrical Diagram”
page 44).
The figure below shows an example of a hydraulic diagram for a heating installation with
radiators and a DHW tank:
EkoHeat + External Kit
SF:Heating safety valve.
CP:Circulating pump.
RV:Anti-condensation return valve.
EV:Expansion vessel.
DV:Drain valve.
BV:Blow-off valve.
3WV: 3-way diverter valve.
HS:Hot water tank sensor.
NV: Non-return valve.
DSV: DHW safety valve.
DEV: DHW expansion vessel.
IMPORTANT: Fit drain valves and devices for correctly bleeding the air from the
heating circuit.
IMPORTANT: Before any servicing, disconnect the boiler from the mains.
IMPORTANT: The 3-way DHW valve should be fitted to enable the flow to the heating
circuit when it is not activated.

10
2.10 Example of a zoned heating installation
Apart from the examples described in the previous sections, the EkoHeat boiler can be fitted
in an installation with several separate heating zones, by installing the suitable control
devices for each zone, e.g. zone valves controlled by ambient thermostats fitted in each of
the zones to be controlled.
Two or more radiator zones can be controlled with any of the previous installation diagrams.
The figure below shows an example of a hydraulic diagram for a heating installation with two
radiator zones and a DHW tank:
EkoHeat + External Kit
SF:Heating safety valve.
CP:Circulating pump.
RV:Anti-condensation return valve.
EV:Expansion vessel.
DV:Drain valve.
BV:Blow-off valve.
3WV: 3-way diverter valve.
HS:Hot water tank sensor.
NV: Non-return valve.
DSV: DHW safety valve.
DEV: DHW expansion vessel.
ZV: Zone valve with micro switch.
IMPORTANT: Fit drain valves and devices for correctly bleeding the air from the
heating circuit.
IMPORTANT: Before any servicing, disconnect the boiler from the mains.
IMPORTANT: The 3-way DHW valve should be fitted to enable the flow to the heating
circuit when it is not activated.
2.11 Example of an installation with a buffer tank for 2 under floor heating circuits and a
DHW tank.
The EkoHeat boiler is equipped with an electronic control that can govern a radiator heating
circuit, an external circulation kit to prevent condensation in the heat exchanger and,
optionally, a DHW storage tank loading circuit. In an installation with a buffer tank, the

EKOHEAT
11
components installed after the buffer tank are not controlled by the boiler control panel.
Suitable control devices for each installation need to be installed for them to function
correctly.
The external hydraulic kit consists of:
- Circulating pump.
- 55ºC 3-way anti-condensation valve.
- Safety valve, calibrated to 3 bar.
- Boiler blow-off valve.
The figure below shows an example of an installation with a buffer tank for 2 underfloor
heating circuits and a DHW tank.
Eko
EkoHeat + External Kit
SF:Heating safety valve.
CP:Circulating pump.
RV:Anti-condensation return valve.
EV:Expansion vessel.
DV:Drain valve.
BV:Blow-off valve.
NV: Non-return valve.
DSV: DHW safety valve.
DEV: DHW expansion vessel.
DP: DHW tank feed pump.
IP: Underfloor heating circuit impeller pump.
MV:Underfloor heating mixing valve.
IMPORTANT: Fit drain valves and devices for correctly bleeding the air from the
heating circuit.
IMPORTANT: Before any servicing, disconnect the boiler from the mains.
IMPORTANT: The components installed after the buffer tank are not controlled by the
boiler control panel.

12
2.12 Example of installation with the MS Hydraulic Kit
The EkoHeat boiler is equipped with an electronic control able to govern a heating circuit via
an external circulation kit to prevent condensation, and, optionally, an MS hydraulic kit
supplied by EKOPOWER may also be acquired and installed, for installation and control of
an underfloor heating circuit and a DHW storage circuit. The MS hydraulic kit includes a
central electronic adjustment unit, to manage the functioning of the kit components
independently from the boiler control panel.
The external hydraulic kit consists of:
- Circulating pump.
- 55ºC 3-way anti-condensation valve.
- Safety valve, calibrated to 3 bar.
- Boiler blow-off valve.
The figure below shows an example of installation with an MS hydraulic kit:
EkoHeat + External Kit
SF:Heating safety valve.
CP:Circulating pump.
RV:Anti-condensation return valve.
EV:Expansion vessel.
DV:Drain valve.
BV:Blow-off valve.
NV: Non-return valve.
DSV: DHW safety valve.
DEV: DHW expansion vessel.
MSK: MS hydraulic kit.
HS: MS hydraulic kit hot water tank sensor.
ES: External sensor.
IMPORTANT: Fit drain valves and devices for correctly bleeding the air from the
heating circuit.
IMPORTANT: Before any servicing, disconnect the boiler from the mains.

EKOHEAT
13
2.13 Example of installation with the DMS Hydraulic Kit
The EkoHeat boiler is equipped with an electronic control able to govern a heating circuit via
an external circulation kit to prevent condensation, and, optionally, a DMS hydraulic kit
supplied by EKOPOWER may also be acquired and installed, to install and control a radiator
heating circuit and a DHW storage circuit. The DMS hydraulic kit includes a central
electronic adjustment unit, to manage the functioning of the kit components independently
from the boiler control panel.
The external hydraulic kit consists of:
- Circulating pump.
- 55ºC 3-way anti-condensation valve.
- Safety valve, calibrated to 3 bar.
- Boiler blow-off valve.
The figure below shows an example of installation with a DMS hydraulic kit:
EkoHeat + External Kit
SF:Heating safety valve.
CP:Circulating pump.
RV:Anti-condensation return valve.
EV:Expansion vessel.
DV:Drain valve.
BV:Blow-off valve.
NV: Non-return valve.
DSV: DHW safety valve.
DEV: DHW expansion vessel.
DMSK: DMS hydraulic kit.
HS: MS hydraulic kit hot water tank sensor.
ES: External sensor.
IMPORTANT: Fit drain valves and devices for correctly bleeding the air from the
heating circuit.
IMPORTANT: Before any servicing, disconnect the boiler from the mains.

14
2.14 Example of a heating installation with radiators and back-up for a solar installation
for DHW production.
The EkoHeat boiler is equipped with an electronic control that can govern a radiator heating
circuit, an external circulation kit to prevent condensation in the heat exchanger and,
optionally, a back-up circuit for a solar installation for DHW production by storage. The solar
circuit must be controlled by a specific device, separate from the boiler.
The external hydraulic kit consists of:
- Circulating pump.
- 55ºC 3-way anti-condensation valve.
- Safety valve, calibrated to 3 bar.
- Boiler blow-off valve.
To control the back-up circuit for the solar DHW circuit, connect a DHW sensor from the hot
water tank to the boiler (optionally supplied by EKOPOWER) and a 3-way diverter valve (see
"Electrical Diagram”page 44).
The figure below shows an example of a hydraulic diagram of a heating installation with
radiators and a solar circuit back-up system:
EkoHeat +External Kit
SF:Heating safety valve.
CP:Circulating pump.
RV:Anti-condensation return valve.
EV:Expansion vessel.
DV:Drain valve.
BV:Blow-off valve.
NV: Non-return valve.
DSV: DHW safety valve.
DEV: DHW expansion vessel.
3WV: 3-way diverter valve.
HS:Hot water tank sensor.
SK:Solar circuit hydraulic kit.
IMPORTANT: Fit drain valves and devices for correctly bleeding the air from the
heating circuit.
IMPORTANT: Before any servicing, disconnect the boiler from the mains.

EKOHEAT
15
IMPORTANT: The 3-way DHW valve should be fitted to enable the flow to the heating
circuit when it is not activated.

16
3 EXTERNAL CIRCULATION KIT
3.1 List of components
The following components are supplied in the external circulation kit box, for correct
installation on the boiler: Before proceeding to mount the kit, carefully check that all the
components on the following list have been supplied:
COMPONENTS BAG
RETURN VALVE SUB-UNIT
3-WAY VALVE SUB-UNIT
1
2
3
4
5
6
8
7
1 Pump hose.
2 MM buttress (2 units).
3 1” black seal (2 units).
4 1” Belpa seal (5 units).
5 Safety valve.
6 Return valve sub-unit.
7 3-way valve.
8 Return bend.
SAFETY VALVE SUB-UNIT
HEATING PIPES
CIRCULATING PUMP
9
11
10
TL
TC
12
9 Safety valve sub-unit.
10 Long boiler pipe (TL).
11 Short boiler pipe (TC).
12 Circulating pump.
3.2 Electrical connection for the circulating pump
Connect the Molex connector on the hose (1) supplied in the component bag to the
circulating pump (12). Connect the other end of the cable to connection strip J1 on the boiler
(BC; terminals 3and 5), as described in the "Electrical Diagram" page 44.
DETALLE A
A
1
Pump hose
