Lincat EB3FX/HC Owner's manual

IS637 ECN 3846 Page 1 of 12
Installation, Operating and Servicing
Instructions
Water boiler and chiller - EB3FX/HC
Please make a note of your product details for
future use:
Date Purchased:_________________________
Model Number:__________________________
Serial Number:__________________________
Dealer:_________________________________
_______________________________________

IS637 ECN 3846 Page 2 of 12
CONTENTS
Important Information
2
Warnings and Precautions
3
Technical Data
4
Checklist of Enclosures
4
Installation and Commissioning
5
Operating Instructions
Wiring diagram/spares list
6
8
Cleaning
9
Descaling Servicing,
9
Maintenance and Component Replacement
10
Fault Finding
10
Spare Parts List
10
Accessories
10
Service Information and Guarantee
11
IMPORTANT INFORMATION
Read these instructions carefully before using this product, paying particular
attention to all sections that carry warning symbols, caution symbols and notices.
Ensure that these are understood at all times.
WARNING!
This symbol is used whenever there is a risk of personal injury.
CAUTION!
This symbol is used whenever there is a risk of damaging your Lincat product.
NOTE:
This symbol is used to provide additional information, hints and tips.
KEEP THIS MANUAL FOR FUTURE REFERENCE

IS637 ECN 3846 Page 3 of 12
WARNINGS AND PRECAUTIONS
This appliance must be installed, commissioned and serviced by a qualified person
with the installation instructions for the appliance and in accordance with national
and local regulations in force in the country of installation.
This appliance is intended for indoor use only and should never be installed
outdoors or exposed to the elements of nature. This unit must not be positioned in
an area that may be cleaned by a water jet and must not be cleaned by water jet.
The unit should be stood on a solid counter or shelf. Ensure that there is adequate
ventilation around the unit. In particular ensure that top and base are clear from
obstruction and ensure minimum of 50mm gap around the unit.
Do not install this unit close to any source of heat, which may result in operating
condition exceeding its design limits.
Ambient temperature range: minimum 160C, maximum 320C, Maximum relative
humidity 70%.
Switching on: If the unit has been laying on it’s side then allow at least 3 hours in
upright position before switching on.
If the supply cord is damaged, it must be replaced by the manufacturer, its service
agent or similarly qualified person.
Ensure that the plug/socket is accessible at all times.
Strip plastic coating and clean the appliance before use.
Do not allow young children, handicapped or infirmed persons to use without
supervision.
This appliance contains R134a refrigerant under pressure. No part of unit should be
exposed to a naked flame. Maintenance of the refrigeration unit must be carried out
by an accredited service provider or qualified refrigeration engineer.
Inform users that certain surface will become hot, especially the draw-off hot tap.
Care should be taken to avoid potential injury from burns & scolding whilst operating
this appliance.
Always disconnect this appliance before servicing, maintenance or cleaning.
This appliance must be earthed.
Keep these instructions in safe place near the unit for future reference.

IS637 ECN 3846 Page 4 of 12
TECHNICAL DATA
EB3FX/HC
Height (mm)
600
Width (mm)
250
Depth (mm)
570
Weight (kg)
15
Power rating(kW)
3
Current rating (A)
13
CHECK LIST OF ENCLOSURES
Warranty card
Instructions manual
Drip tray
Drip tray insert
Connection hose
Silicone drain hose assembly

IS637 ECN 3846 Page 5 of 12
INSTALLATION AND COMMISSIONING
This appliance must be earthed.
If replacing the plug connect the terminals as follows:
Green and Yellow wire Earth E
Blue wire Neutral N
Brown wire Live L
Install this appliance on a level surface ensuring all vents are unobstructed.
Only install this unit in locations where it can be overseen by trained personnel.
Inlet water pressure should be between 2 and 6 bar. (0.2MPa to 0.6MPa)
If water pressure exceeds 6bar fit a suitable pressure reduction valve.
Ambient air temperature shall be between 16 0C and 32 0C
Electrical supply
The EB3FX/HC is supplied with a 13 amp plug to BS1363.
Water supply connection
Connect the supplied white water inlet hose to the inlet connection point on the
base of the boiler and the other end to the mains supply via an accessible isolating
tap with a ¾” BSP thread.
Use the hose set supplied with the appliance - any previous hose set is not to be re-
used.
Potable water. If solid particles are known to be in the supply, add an extra inline
filter or strainer.

IS637 ECN 3846 Page 6 of 12
OPERATING INSTRUCTIONS
General arrangement
Only qualified or trained personnel should use this appliance.
First Use
New filters have a small amount of loose, harmless, carbon particles. Drain off
approximately 5 litres of water when first setting up or replacing filter.
Switch on the electricity supplies and leave the boiler to fill for 30 minutes. There is
a delay of 2 minutes for the chiller to come ‘ON’, this will happen every time when
electricity is interrupted.
The unit will display ‘Wait’ whilst it fills and heats/cool. It will display ‘Ready’ when
water can be drawn off.
1
Lid
9
Drain pipe
2
Touchscreen display
10
Drip tray
3
Dispense tap cold
11
Mains power lead
4
Dispense tap hot
12
Water inlet point
5
Serial plate location
13
Side condenser air vent
6
Water filter
14
Pressure reducing valve
7
Hot tank drain valve
15
Dip stick
8
Vent pipe
1
3
2
4
7
8
9
10
11
13
12
14
6
5
15

IS637 ECN 3846 Page 7 of 12
Touchscreen display configuration
When the boiler is supplied timed mode and clock function are all turned off.
To select these options press the “Power button”, select the feature required and
follow the on-screen instructions.
To adjust the temperature, clock or to perform a boiler descale press “Ready”, select
the option and follow the on-screen instructions.
All units are fitted with a settings PIN lock. Press Ready and then Settings to access
the PIN setting screen. Master PIN code is available from Lincat Service should you
forget the user set PIN.
Filter Replacement
The filter display shows the estimated life remaining in the filter cartridge. A reminder
message is displayed when the filter needs changing.
To replace the filter:
Twist the base of the filter (E) 90 degrees to the left and lower the cartridge out of the
appliance. It will contain a small amount of water. Only use a genuine Lincat Filter.
Insert the new filter into the recess and lock in place by twisting to the right.
Press the “Filter life icon” and follow the on-screen instructions to reset the filter life.
Drain off approximately 5 litres of water to remove any loose carbon particles from the
filter.
The boiler will not fill if the filter is removed as the filter head incorporates a shut-off
valve.
KEY
Icon
Pressing allows
1
Power button
On, off, Timed and ECO modes
2
Timed operation
Access to timer settings
3
Clock
Access to clock
4
Hot status
Status screen
5
Cold status
Status screen
6
Status
Cold-ready to use/wait
7
Status
Hot-ready to use/wait
8
Chiller module
Power to chiller module
9
Water in
Hot tank water filling
10
Filter
Filter life status
11
Fault
F03-Power board error
F04-Power board over temperature
F05-Power board fault
F06-Sensor fault
F07-Heating fault
F08-Thermistor fault
F09-Water supply fault
F10-Chiller condenser over heat
F11-Chiller- clean condenser
12
Element
Element ON
1
3
6
8
11
2
9
10
54
12
7

IS637 ECN 3846 Page 8 of 12
F10-Chiller condenser over heat: This could be due to condenser fan not working,
condenser air outlet blocked or condenser blocked.
F11-Chiller- clean condenser: This is a regular periodic warning to ensure the condenser
fins are not blocked that should be kept clean to ensure optimum operation of cooler water
cooling system.
WIRING DIAGRAM
COMPRESSOR
CONDENSER
CONDENSER
FAN
THERMOSTAT
PR100
PR101
SO23
BB
PR105
P1 P2
S1 S2
T1 T2
MA10
BR
BR
GR
GR
LE26
UPPER LEVEL
SENSOR
LE 68
LOW LEVEL
SENSOR
TH124
THERMISTOR
HOT TANK
TH126
THERMISTOR
COLD BLOCK
OR
GR
BL
GR
BR
EL296
TH123
95vCUTOUT
ON VENT
PIPE
TH88
120vCUTOUT
ON TANK
CA185
CA179 5 WIRE DATA CABLE
WL01
BR
BL
BL
BR
BR
W
BL
GR
GR
BL
W
YL
W
BL
RD
EBCM01
PL202

IS637 ECN 3846 Page 9 of 12
CLEANING
Do not use a water jet or steam cleaner, and do not immerse this appliance.
Clean all panels with warm water and mild detergent and do not use abrasive
materials. Dry with a soft cloth.
Slide out and empty the drip tray regularly, and wipe the dispensing tap spout daily
to remove limescale deposits.
DESCALING
De-scaling is an important maintenance task and must be performed to maintain the
warranty.
This range of units has a de-scaling routine built into the software. It guides the user
through the process and advises when to open /close valves and when to add the
de-scaler.
To decide if the boiler needs a de-scale, whilst wearing gloves carefully remove the
blue cap (with the scale dipstick attached) on the top of the boiler.
Allow the water to dry on the dipstick. Where the dipstick has been in the water it will
be covered in the same amount of scale as the rest of the tank. When it is about 0.5 to
1mm thick the tank should be de-scaled.
The de-scale routine takes about an hour to complete and the boiler cannot be used
during the routine.
Lincat offer a purpose designed de-scaler powder, part number DP10 that can be
used should you require it.
SPARES LIST
Part number
Description
PR105
Control/Display board
PR101
Auxiliary power board
PR100
Power board
TH88
Tank over heat cut out
TH123
Steam/over flow over heat cut out
TH124
Hot tank thermistor
TH126
Cold block thermistor
WL01
Level sensor cable
CA179
Interconnect data cable
CA185
Condenser signal cable
EBCM01
Chiller module

IS637 ECN 3846 Page 10 of 12
SERVICING, MAINTENANCE AND
COMPONENT REPLACEMENT
All maintenance and component replacement on this appliance should be carried
out by one of our recommended service engineers.
Please refer to the Service Help Desk number on the final page of this manual.
For spare parts for your water boiler/chiller please contact the Lincat Spares
department on 01522-875510. Refer to the serial plate for the model and serial
number of your water boiler, as this will help us quickly identify the part you require.
Part Number
Description
Used on
BR57
Wall bracket
EB3FX/HC
FC04
Replacement filter
cartridge
All models
DP10
Descaler powder
All models
FAULT FINDING
SPARE PARTS LIST
ACCESSORIES

IS637 ECN 3846 Page 11 of 12
For help with the installation, maintenance and use of your Lincat equipment,
please contact our service department:
UK: 01522 875520
For non-UK customers, please contact your local Lincat dealer
All service work, other than routine cleaning should be carried out by one of our
authorised service agents. We cannot accept responsibility for work carried out by
other persons.
To ensure your service enquiry is handled as efficiently as possible, please tell us:
Brief details of the problem
Product code
All available on serial plate
Type number
Serial number
Lincat reserve the right to carry out any work under warranty, given reasonable
access to the appliance, during normal working hours, Monday to Friday, 08:30 to
17:00.
GUARANTEE
This unit carries a comprehensive UK mainland 2 year warranty.
This requires you maintain and care for your product and follow maintenance
instructions. If you fail to maintain your unit or damage components Lincat may
charge you for a warranty repair.
The guarantee is in addition to, and does not diminish your statutory or legal rights.
The guarantee does not cover:
Accidental damage, misuse or use not in accordance with the manufacturer’s
instructions
Consumable items (such as filters, glass, bulbs, slot toaster elements and door
seals.)
Damage due to incorrect installation, modification, unauthorised service work or
damage due to scale, food debris build-up, etc.
The manufacturer disclaims any liability for incidental, or consequential damages.
Attendance is based on reasonable access to the appliance to allow the authorised
technician to carry out the warranty work.
SERVICE INFORMATION

IS637 ECN 3846 Page 12 of 12
This page intentionally blank
